Operation manual
[FORCED CONVECTION OVEN]
Model : OF-02G / 12G / 22G
Manual No : 00HAA0001159 ( Version : 5.0 )

Page 2

Page 3
Please read this operation manual carefully before you use this unit.
Especially, keep in mind and pay attention regarding safety secure
Safety Precautions
“Danger” means that the user may have
serious damage and even die by wrong
handling on this unit.
“Warning” means that the user may have
serious damage by wrong handling on this
unit.
“Caution” means that the user may have not
so serious damage and unit may have
physical damage by wrong handling on this
unit.
Thank you for purchasing a Lab companion product. We always do our
best to provide customer satisfaction. This unit is designed using our
own new technology and materials.
This operation manual describes the performance of the unit and gives
instructions for its correct use. All users must read this operation
manual carefully before you use this unit. Please use within the
recommended parameters as specified.
Copyright 2003 Jeio tech Co,. LTD. ALL RIGHT RESERVED.

Page 4
Contents
1. Purpose and peculiar of this unit........................................ 5
2. Installation ...................................................................... 6
3. Matters that require attention ............................................. 7
4. Name of each parts .......................................................... 8
5. Controller ......................................................................... 10
6. Maintenance of the unit ..................................................... 17
7. Action for malfunction ........................................................ 18
8. Warranty criterion .............................................................. 29
9. Specifications .................................................................... 20
10. Install lab tracer................................................................. 21
11. How to use lab tracer.......................................................... 22

Page 5
1. Purpose and specificity of this unit
1) Purpose
(1) Forced convection oven is used for rapid dry for glass ware test of thermal hardness and
thermal variation.
(2) Forced convection oven is used for preheating before heating test and test of dry for
architecture component and electric component and thermal durability.
(3) Forced convection oven is used for self life test of food in harshness condition, humidity
remove, harden and soften test of food and chemical by heating, moisture removal in the
sample and etc.
2) Specificity
(1) Forced convection oven is multi purpose instruments for Biotechnology, pharmacy, medical,
chemical, and biology. This has firstly developed CLS (Custom Logical Safe)-Control
system for convinces in use and safety to user.
(2) CLS-Control System means “Control system which has logical safety device specialized for
individual model”. Laboratory must have Thermal safety secure because there are a lot of
inflammable reagent. This system is highest safety secure control device (patent no.
0397583 and 0328729) and makes the unit suitable for this kind of environment.
(3) This unit is designed to stop the Heater and Blower in order to protect the user from heat
when its door opened while it works.
(4) This unit has insulation for high temperature in the outside of the inner chamber and inside
of the door and also has Chamber Silicone door for high temperature therefore insulation is
perfect and heat lose is very low.
(5) Triple observing window is good for insulation and observe. This is Optional
(6) Uniform temperature in the chamber is made by special design.
(7) Easy to lock door opening system is used.
(8) Safety circuit is used to protect the instrument from over charge and over temperature of the
heater.

Page 6
2. Installation
(1) Scope of delivery.
Main body(1set), Operation manual (1EA), Glass fuse (2EA), Shelf(2EA), Shelf guide(4EA),
Communication CD(1EA), RS-232 Communication cable(1EA)
(2) This unit will work correctly on proper power supply. Please check power supply and ID
Plate information are the same. User must use power supply connected earth and power
cord must be connected to wall outlet supplying ground point.
We don’t have any responsibility for accident and lose of personal and asset if the ground earth is not
connected.
(3) Please install the unit in the flat place where prevent vibration and shock.
(4) Please let the unit avoid heat source and direct sun light and let the unit located in ambient
temperature range in 5°C ~ 40°C relative humidity lower than 80%.
(5) Please don’t install the unit where water and organic solvent is easily penetrates in the unit.
They cause short circuit.
(6) Please don’t install the unit in dangerous place. (Where there are flammable gas and
explosive material)
(7) Please secure enough space for installation because the door of it opened 180°.
(8) Please secure enough space for installation. The blower is back side of the oven.
(9) Please don’t install the unit near by machines generating strong high frequency noise.
(10) This unit is quite heavy. Please move the unit with proper moving tool or 2 people together.
Please think about the safety of user and instrument when you find out a place to install.

Page 7
3. Matters that require attention
(1) Please don’t touch Power cord and electric part with wet hand.
(2) Please don’t put explosive and flammable chemicals (Alcohol, Benzene and etc) inside of
the oven.
(3) The samples inside of the oven are very hot when the oven is works and for a while after it
stops. Please take safety glove when you touch samples.
(4) Please don’t set flammable materials near by oven.
(5) Please don’t pour water on the unit directly when you clean the unit.
(6) Please don’t put some conductive and flammable materials through ventilation or power
supply port. It is dangerous and causing fire and electric shock.
(7) Circuit and electric component used in this unit are developed by Jeio tech. Please don’t try
to repair by yourself. Wrong combination of electric part may cause fire. You must ask to
official Jeio tech dealer or distributor in your region.
Don’t put explosive and flammable materials inside of the chamber.

Page 8
4. Name of each parts
(1) Main body
Made by iron plate and painted.
(2) Ventilation hole
It changes air volume of ventilation. It’s very hot, please wear safety glove when you need
to adjust it. The safety gloves must be dry. Wearing wet gloves causes burning and electric
shock.
(3) Shelf level adjustor
Shelf level is easily adjustable by the size of sample.
(OF-02→8 levels, OF-12→12 levels, OF-22→14 levels)
(4) Shelf
It’s made by Stainless steel wire. It’s easy to clean and ventilation is good. The surface of
it is electrically polished therefore it has beautiful face good anti-corrosion.

Page 9
(5) Door
There are air barrier between door surface and insulation of the door. Therefore the surface
of the door is cool.
(6) Window (option)
Observing glass is made by triple glass therefore it’s easy to observe.
(7) Door Handle
It is Door handle for door opening.
(8) Chamber
It’s made of stainless steel and there are Blower, Heater, Temp. sensor and Temp.
regulator inside of the chamber.
(9) Temperature Controller
This has a Micro processor (CPU) which has Digital PID Auto tuning function. It also has
temperature compensation function for temperature sensor and the highest class safety
level control system such as heating volume controller.
(10) Over temp. Limit.
If the heater temperature rises higher than set temperature it cut the power of the
temperature controller, makes the over temperature LED blinking and alarming beep
sounds. If you resume the operation, please set knob of it about 15% higher than set
temperature and press Start/Stop switch ones then check run led of temperature controller
is on.
(11) Door packing
A silicone rubber for high temperature keeps high air sealing.
(12) Control panel
Controller and electric component are there.
(13) Main switch & Fuse
This is the switch for main power. Fuse protects the instrument from electric shock. Please
check out correct power supply when you replace Fuse.

Page 10
(14) Communication port
User can monitor and control the unit via RS-232C protocol interface through COM1 or
COM2 port to computer device. The control values can be stored and printed out.
(15) Door limit switch
It’s installed inside of the unit. The Logic IC of this switch put off the main switch. This cut
off all 2 phase currency in the instrument therefore heater and blower stops for safety of
user. Door LED blinking to indicate the door is opened. If the door is opened more than 1
minute then the alarming buzzer sound in order to inform the user that the door is opened
for a while. (Restart the equipment by pressing START/STOP button after closing the door)
(16) Power cord
It is a cord that supplies the main power.
5. Controller
1) Specificity
(1) CLS-Control System temperature and heater output are controlled in Main CPU which can
do precise PID calculation. All control for safety is conducted by selective functional Logic
IC which is installed separately. This is designed to conduct safety performance against
any electric and electronic shock on the unit.
(2) CLS-Control System shuts down all 2 phase power supply to each part immediately and
informs user instability by audio and visual device then keeps in safe mode until all
instability conditions removed.
(3) CLS-Control System gives user two choice, one is resume operation of the unit and another
is keeps the unit in standstill when the unit operation were terminated by power failure and
then recovered.
(4) CLS-Control System, the safety device designed to keep very small amount of currency
(only 5V, 10mA) in contact point. This makes durability of contact point very long.

Page 11
2) Name and operation
(1) HEATER LED
It shows Heating function is “ON”
(2) Auto Tune LED
Flickering begins on Auto-tuning.
(3) Wait On Timer LED
This is the LED indicating operation start time. The LED is blinking when the timer works and
the LED off when the timer is in waiting condition.
(4) Wait Off Timer LED
This is the LED indicating operation stop time. The LED is blinking when the timer works and
the LED off when the timer is in waiting condition.
(5) Door open LED
The LED is on when the door is open.
(6) Over heating alarm LED
If the heater temperature rises higher than set temperature it cut the power of the
temperature controller, makes the over temperature LED blinking and alarming beep
sounds. If you resume the operation, please set knob of it about 15% higher than set
temperature and press Start/Stop switch ones then check run led of temperature

Page 12
(7) Temp. button.
This button is for temperature setting.
(8) Timer button.
This button is for timer setting.
(9) Up button.
This button is for increasing set value.
(10) Down button.
This button is for decreasing set value.
(11) Enter button.
This button is for saving value after varying set value.
(12) Start/Stop button.
This button is for start/stop of unit and for resuming operation after removing some
unstable factors when operation is terminated because of it.
(13) Lock button.
This is lock the controller buttons.
(14) Auto Tune button.
The auto tune begins if you press this button for 1 second.
(15) RUN LED
This LED indicates Work/Stop state of unit. It turns on when the unit runs and turns down
when the unit stops
(16) SV display
This display is for showing set temperature and showing remaining time when the timer
function is activated.
(17) PV display
This display is for showing present temperature.

Page 13
3) Temperature setting way
(1) Press button.
Set temperature value (SV) is blinking. This means you can vary set value.
(2) Press button to vary digit number and press button when you save the
value.
(3) It goes back to previous state without saving if you don’t touch any button for 10 seconds.
(4) Press button again when it is in SV set state then following additional functions are
activated.
4) Additional function of button
(1) Favorite values can be stored at Sv.1, Sv2, Sv3
for each operation.
Press 2 times and set temp. values by
pressing and , and conclude the
setting by pressing
Set temperature is saved on memory and set
temperature varies Sv1, Sv 2, Sv 3 are applied
the same.
Press button repeatedly then Sv1, Sv2,
Sv3 are shown and temperature unit set mode
shown by pressing 5 times repeatedly.

Page 14
(2) This is a function vary the unit of temperature
value.
Initial display is ℃ and it can be varied ℃ and
℉ by pressing and buttons.
(3) Next mode is shown by pressing 6 times.
This compensates the temp. value errors.
Requested values are put on PV display. Move
to the next mode by pressing and
buttons.
PV is put on the SV display and can be set as
exactly as shown on thermometer. Set the
value by pressing and , and conclude
the setting by pressing
5) Timer set way
(1) Press button.
Timer (On Timer / Off Timer) is shown on PV and time is shown on SV. Set time by pressing
button and save and finish by pressing button.
(2) W/ON LED turns on with Beep sound after finishing wait on timer set.
(3) Press button one more time. You can set wait off timer.
Set time by pressing button and save and finish by pressing button.

Page 15
(4) W/OFF LED turns on with Beep sound after finishing wait on timer set.
(5) The function of Timer is as follows.
Wait on Timer Wait off Timer
Temperature
Time
①Wait On Timer
- The unit begins to work after time passed programmed on Wait On Timer.
- Maximum is 99hr 59mim. and minimum is 1min.
②Wait Off Timer
- The unit stops after time passed programmed on Wait Off Timer since SV and PV meet.
③Combination of Wait On Timer & Wait Off Timer.
- The unit works as picture above
(6) Timer set deactivation
Press button in order to deactivate timer function then LED turns off and set timer
deactivated (Both On/Off timer deactivated). If you want only one timer set time of timer for
0 then the timer is deactivated.

Page 16
6) Additional function of button.
Press button once again on wait On/Off Timer function then following additional f
unction displayed.
(1) This is selection of unit state after power failure. If you set yes the unit will run or else the unit
will not run after power failure situation finished.
7) Auto Tuning
Perform Auto Tuning in order to get precise and rapid temperature control. PID value saved
automatically after Auto Tuning.
(1) Set temperature you want.
(2) Press button for a while(3seconds) then Auto Tune shown display like right hand side
picture and A/T LED blinking.
(3) Auto Tune time is various according to installed environment. LED turns off after finishing
Auto Tune and Present temperature & Set temperature meet.
8) Lock Function.
This is to lock controller buttons.
(1) Press button for a while (3seconds), then Lock function is set with Beep sound and
the unit wouldn’t corresponding any more key pressing.
(2) In order to deactivate this function please Press button for 3 seconds again.
(3) This protects improper pressing of the controller buttons while operation.

Page 17
6. Maintenance of this unit
(1) Turn off the main power switch and pull out a power plug from wall outlet.
(2) Remove all liquid in the bath.
(3) Wash with soft cloth containing neutral detergent.
(4) Wash with soft cloth containing distilled water.
(5) Dry with dry cloth.
(6) Don’t use organic solvent.
(7) If user try to clean this unit with other method not mentioned on this manual please
contact us in order not to damage to the unit.
(8) Put on Safety glove for harmful chemicals and Safety Mask for harmful gas and then
wash out pollutant with dried cloth when harmful chemicals and gases are spread out
on the unit.

Page 18
7. Action for malfunction
1) Check points when the unit doesn’t work.
(1) Check out power supply.
(2) Check out fuse if off.
(4) Check out Run LED on display is off. Please press Start / Stop button if it is off.
(5) Please check the power is out.
2) Malfunction check list.
☞ If you can’t recover the instrument please call a repair service.
Malfunction symptom What to check and what to do.
Buzzer sound
continuously(1)
If Door is opened, Press START/STOP Switch once and check out Run
LED turns on.
No temperature
control.
Check if there are machines generating strong high frequency noise
near by the unit.
Check if Some contaminants are in the control panel.
Do Auto tune again.
Air circulation is not
made in the chamber
Check the door switch (open and close the door 2~3times)
Check the blower works correctly
Abnormal sound
Check the Impeller of blower is OK inside of the chamber.
Open the back plate of the instrument and Check the Impeller of Blower
touches any part.
No power
Check the Main power Switch is on.
Check the power supply is on in the room.
Check the power failure.
Check the fuse is OK
Temperature wouldn’t
rise
Check the RUN LED is on.
Press the START/STOP Switch once if the RUN LED is off.
Check the door is opened.
Buzzer sound
continuously(2)
Check the Over temp. limit is set lower than current set value of the
temperature.
If it is, please set the value of the Over temp. limit at least 15% higher
than PV.
Press the START/STOP Switch once and the check the RUN LED.

Page 19
8. Warranty criterion
1) Warranty service duration
It covers for 1 year since you purchase the unit and then after the duration you need to pay for
service parts.
Please contact your authorized Jeio tech dealer when you need warranty service.
You have a right to repair, replacement and payback within the warranty service duration.
2) The case user can’t get warranty service
Damages on unit caused by fire and natural disaster like flood, earth quakes aren’t
covered by warranty service. Damaged by over voltage and abnormal conditional usage
aren’t covered by warranty service.

Page 20
9. Specifications
Model OF-02G OF-12G OF-22G
Chamber volume 60L 102L 151L
Permissible
environmental condition
Temperature 5℃ to 40℃
Maximum relative humidity 80%
Altitude up to 2,000m
Range Amb.+10℃ ~ 250℃
Uniformity ±1℃ at 100℃
Accuracy ±1℃ at 100℃
Controller Digital PID auto tuning
Sensor K-CA
Temperature
Heat up time 100℃ Within 15 min
Internal Stainless steel, 0.8t
External Steel, 0.8t power coating
Shelves Stainless steel wire, electro polished
Insulation Mineral wool (50mm)
Door gasket High temperature grade foamed silicone rubber
Viewing window
(Option) Tempered safety glass, three fold, 5t
Material
Ventilation slide Stainless steel, dia 38mm×2EA
Safety device CLS(Custom Logical Safe)-control system, ClassⅡ
Over temp. limit Hydraulic over temp. limit
Heater
Incoloy sheath
230VAC/1000W
120VAC/800W
Incoloy sheath
230VAC/1400W
120VAC/1000W
Incoloy sheath
230VAC/1700W
120VAC/1200W
Internal(㎜) 400×360×420 480×410×520 550×460×600
External(㎜) 577×642×760 657×692×870 727×742×974
Size
(W×D×H)
Window(㎜) 5t×150×280 5t×150×380
230VAC 50/60Hz,
4.4A
230VAC 50/60Hz,
6.1A
230VAC 50/60Hz,
7.4A
Electric requirement
120VAC 60Hz,
6.8A
120VAC 60Hz,
8.4A
120VAC 60Hz,
10.1A
Weight(net) 53kg 63kg 72.5kg
