Jetcom CCTV JCC-5120HQ User manual

9403-V1
1. Lead (Pb) Free RoHS Compliance
2. Performance: 550 TV lines of resolution.
3. Digital Signal Processor: SONY HQ1
4. Long life and high reliability are achieved by the use of a CCD image
device. This makes the camera 100 percent solid state. No longer is
an image tube needed.
5. The Minimum illumination 0.15Lux @ F=1.0
6. Ease of use in any application is achieved through the small size.
The lightweight also improves performance where shock and
vibration would affect larger tube type cameras.
7. Lower power consumption.
8. Built-in automatic electronic Iris. This camera can be used for most
indoor application without using the auto iris lens
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this
may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling could
damage the camera.
3. Requires a proper operating environment
This camera is designed for indoor use. The allowable temperature
range for operation of this camera is between -10°C~50°C and the
allowable humidity is 85% maximum. If the camera is to be placed
outdoors, a special weatherproof housing, which also has heaters
and cooling device included, should be used.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned before
lens installation or whenever the lens is changed. Cleaning should be
done using a chamois, a very fine soft cloth, lens tissue or cotton
tipped applicator and ethanol to carefully remove any fingerprints or
dust.
5. Check the power source voltage
The power source voltage should be within the specified range.
(Camera must meet the specification)
6. Object and Liquid Entry
Never push objects of any kind into this as this may touch dangerous
voltage points or short-out parts that could result in a fire or electric
shock. Never spill liquid of any kind on the video product.
7. Servicing
Do not attempt to service this video product yourself as opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
JCC-5120HQ
1/3” COLOR CCD CAMERA
8. Damage Requiring Service
Unplug this video product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video
product
c. If the video product has been exposed to rain or water.
d. If the video product has been dropped or the cabinet has been
damaged.
e. When the video product exhibits a distinct change in performance-
this indicates a need for service.
DIMENSIONS
(
Unit : mm
)
FEATURES
CAUTION
SPECIFICATION
TV system NTSC PAL
Digital Signal Processor SONY HQ1
Image Sensor 1/3” SONY SUPER HAD CCD
Number of Total Pixels 811(H)×508(V) 752(H)×582(V)
Synchronizing System Internal / Line Lock (AC Version Only)
Resolution 550TVL
Minimum Illumination 0.15Lux @ F1.0
Signal to Noise Ratio 50dB (AGC OFF)
Gamma Correction 0.45
Auto Iris Output D4 IRIS Jack
Auto White Balance YES
Video Output 1.0Vp-p Composite ; 75Ω
Iris Control Video / DC
Electronic Shutter Speed
Control AES ON: 1/50 (60) sec.~1/100,000 sec.
AES OFF: 1/50 (60) sec.
Lens Mount CS mount
Adjustment VR L.L V-phase; DC Level
Power Supply 12Vdc /24Vac ; 90~260Vac
Power Consumption 12Vdc /24Vac: 3.5W ; 90~260Vac: 4.5W
Lead Free YES
Operation Temperature -10℃~50℃
Operation Humidity Maximum: RH85﹪
Storage Temperature -20℃~60℃
Storage Humidity Maximum: RH90﹪
Dimensions 60(W)×49(H)×99(D)mm
Weight 12Vdc /24Vac: 250g ; 90~260Vac: 300g

9403-V1
Lens mount
This mount is used to install a CS-mount lens.
CS-adaptor ring is required if using a C mount lens.
Camera mounting screw holes
screw hole for fixing camera.
Mount adaptor
This adaptor can be attached to either the top or bottom of unit.
Mechanical focus adjustment
If focus needs to be adjusted after the lens had been mounted,
Losses the Flange back lock screw (A) and rotate the Adjustment
wheel to adjust.
Auto iris lens connector (4-pin type)
The lens connector supplies the auto-iris lens (not supplied) with DC
power and a video signal or DC control signal.
Control Switch
SW1. SYNC MODE: SYNC Mode Selection; L.L / INT switch.
SW2. BLC: Backlight compensation OFF / BLC switch
SW3. AGC:Automatic Gain Control OFF /AGC switch
SW4. Auto white balance mode: AWB (ATW) / PWB switch
VIDEO terminal
This is an output terminal for connection to a video monitor, etc(75Ω).
Auto Iris mode selection switch
For switching the output from the auto-iris connector (5). Shutter
speed is fixed at 1/50 sec. when switch is set to DC or VIDEO
position.
DC: To be set when using a non-amp auto-iris lens.
AES: To be set when using AES (Auto Electronic Shutter).
Video: To be set when using an auto-iris lens with build-in amp.
V.P (Vertical Phase adjuster)
This is used to adjust the vertical phase of the video output signal
Used to adjust video output level of DC driven auto iris lens.
Pow
Connect the power supply of 24Vac or 12Vdc.
er input terminal
Power input terminal
Connect the power supply of 90~260Vac.
CONTROL SWITCH OPERATIONNOMENCATURE AND FUNCTION
SW1. BLC (Back light compensation) mode switch:
When strong light (sun, sky, illumination, etc) is present behind the
object being photographed, the object will appear dark. In this
case, put this switch in the BLC position.
SW2. FLC (Flicker less):
FLC: Fixes shutter speed at NTCS: 1/100Sec.; PAL: 1/120Sec.
NOM: Normal position.
SW3. S.AGC/AGC:
S.AGC: When camera has installed at low light condition. The
sensitivity of the camera rises (26dB).
AGC: 26dB
SW4. SYNC MODE:
L.L. MODE: It synchronizes the video signal between cameras
using the frequency of the power supply without
external synchronous generator.
INT MODE: The camera maybe operated independently with the
internal crystal control.
PIN NO. VIDEO DC
1 DC + 12V CONTROL -
2 NC CONTROL +
3 VIDEO SIG DRIVE +
4 GND DRIVE -
