ELECTRIC FURNACE
MODELS: EB**F
Downflow/Upflow
INSTALLATION MANUAL
®
LIST OF SECTIONS
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
UNIT INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
DOWNFLOW FURNACE INSTALLATION . . . . . . . . . . . . . . . . . . . . .3
THERMOSTAT INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
OPTIONAL AIR CONDITIONING ACCESSORIES . . . . . . . . . . . . . . 9
WIRING DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
LIST OF FIGURES
Furnace Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Upflow Closet Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Duct Connector Depth (7990 Series) . . . . . . . . . . . . . . . . . . . . . . . . . .4
Duct Connector Dimensions (7990 Series) . . . . . . . . . . . . . . . . . . . . .4
Recommended Floor Cut-out (7990 Series) . . . . . . . . . . . . . . . . . . . .4
Duct Connector Screw Attachment (7990 Series) . . . . . . . . . . . . . . . .5
Duct Connector Tab Attachment (7990 Series) . . . . . . . . . . . . . . . . . .5
Duct System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installation of Furnace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Hanger Angle Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Blower Bracket and Duct Flange Attachment . . . . . . . . . . . . . . . . . . .6
Control Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Field Wiring Shield . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Thermostat Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Thermostat Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
EB10F Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
EB12F Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
EB15F Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
EB17F Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
EB20F Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
EB23F Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
LIST OF TABLES
Duct Connector for Electric Furnaces . . . . . . . . . . . . . . . . . . . . . . . . .4
Wiring Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 EB Series Blower Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
SECTION I: GENERAL
The following list includes important facts and information regarding the
EB furnace and its packaging inclusions:
1. Furnace is rated at 240 volts, 60 Hz, single phase.
2. Filters are furnished with each model, and are the same for all
models - 16 x 20 x 1 in top and 20 x 20 x 1 in the louvered door.
3. Furnace size is the same for all models. See Figure 1.
4. Four-wire thermostat operation for heating and cooling.
5. Coil cavity built into furnace (coil shelf accessory required).
6. All furnaces are equipped with an air conditioner blower and isA/C
or Heat Pump ready (coil shelf accessory required).
7. Holding strap furnished on top rear of furnace.
8. This furnace is designed for downflow application; however, it may
be converted to an upflow application. (See Page 6 for upflow con-
version instruction.)
9. This furnace must not be operated without the front panel
installed. NOTICE
This furnace and its components listed on the A/C and Heat Pump
equipment sticker are listed in combination as a system by Under-
writer's Laboratories for the United States and Canada. FIGURE 1: Furnace Dimensions
´
´
237,21$/%27720),(/'
:,5,1*(175<
$
%
&
'
(
)
+
*
-
.
/
0
1
´
´
´
´
´
´
´
´
´
´
´
´
´
-
+
&%$'
()*
1
0
/
.
68%%$6(,)
86('$''6
´025(72
727$/+(,*+7
$1'´72
:,'7+
7+(50267$7
:,5,1*
(175<
),(/'
:,5,1*
(175<
$
´

5165699-BIM-C-0516
2 Johnson Controls Unitary Products
SECTION II: SAFETY
This is a safety alert symbol. When you see this symbol on
labels or in manuals, be alert to the potential for personal
injury.
Understand and pay particular attention to the signal words DANGER,
WARNING, or CAUTION.
DANGER indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if not
avoided may result in minor or moderate injury. It is also used to
alert against unsafe practices and hazards involving only property dam-
age.
1. Install this electric furnace only in a location and position as speci-
fied in SECTION III of these instructions.
2. Always install the electric furnace to operate within the electric fur-
nace’s intended maximum outlet air temperature. Only connect the
air handler to a duct system which has an external static pressure
within the allowable range, as specified on the EB rating plate.
3. When an electric furnace is installed so that supply ducts carry air
circulated by the air handler to areas outside the space containing
the air handler, the return air shall also be handled by duct(s)
sealed to the air handler casing and terminating outside the space
containing the air handler.
4. The electric furnace is not to be used for temporary heating of
buildings or structures under construction.
5. The size of the unit should be based on an acceptable heat loss or
gain calculation for the structure. ACCA, Manual J or other
approved methods may be used.
SAFETY REQUIREMENTS
1. This electric furnace should be installed in accordance with all
national and local building/safety codes and requirements, local
plumbing or wastewater codes, and other applicable codes.
2. Refer to the unit rating plate for the EB model number, and then
see the dimensions page of this instruction for supply air plenum
dimensions in Figure 3. The plenum must be installed according to
the instructions.
3. Provide clearances from combustible materials as listed under
Clearances to Combustibles.
4. Provide clearances for servicing ensuring that service access is
allowed for electric furnace elements and blower.
5. Failure to carefully read and follow all instructions in this manual
can result in electric furnace malfunction, death, personal injury
and/or property damage.
6. Check the rating plate and power supply to be sure that the electri-
cal characteristics match.
7. Electric furnace shall be installed so the electrical components are
protected from water.
8. Installing and servicing heating/cooling equipment can be hazard-
ous due to the electrical components. Only trained and qualified
personnel should install, repair, or service heating/cooling equip-
ment. Untrained service personnel can perform basic maintenance
functions such as cleaning and replacing the air filters. When
working on heating/cooling equipment, observe precautions in the
manuals and on the labels attached to the unit and other safety
precautions that may apply.
9. These instructions cover minimum requirements and conform to
existing national standards and safety codes. In some instances
these instructions exceed certain local codes and ordinances,
especially those who have not kept up with changing residential
and non-HUD modular home construction practices. These
instructions are required as a minimum for a safe installation.
INSPECTION
As soon as a unit is received, it should be inspected for possible dam-
age during transit. If damage is evident, the extent of the damage
should be noted on the carrier’s freight bill. A separate request for
inspection by the carrier’s agent should be made in writing.Also, before
installation the unit should be checked for screws or bolts, which may
have loosened in transit. There are no shipping or spacer brackets
which need to be removed.
Also check to be sure all accessories such as heater kits, suspension
kits, and coils are available. Installation of these accessories or field
conversion of the unit should be accomplished before setting the unit in
place or connecting any wiring, electric heat, ducts or piping.
CODES
The electric furnace must be installed in accordance with the following
codes:
• Standard for the Installation of Air Conditioning and Ventilating
Systems (NFPA 90A)
• Standard for the Installation of Warm Air Heating and Air Condi-
tioning Systems (NFPA 90B)
• National Electric Code (NFPA 70)
• Canadian Electrical Code, Part I (CSA C22.1)
• All local codes (state/county/township).
WARNING
Improper installation may create a condition where the operation of
the product could cause personal injury or property damage.
Improper installation, adjustment, alteration, service or mainte-
nance can cause injury or property damage. Refer to this manual
for assistance or for additional information, consult a qualified con-
tractor, installer or service agency.
CAUTION
This product must be installed in strict compliance with the installa-
tion instructions and any applicable local, state, and national codes
including, but not limited to building, electrical, and mechanical
codes.
WARNING
FIRE OR ELECTRICAL HAZARD
Failure to follow the safety warnings exactly could result in serious
injury, death or property damage.
A fire or electrical hazard may result causing property damage, per-
sonal injury or loss of life.
!
!
!
NOTICE
All applicable codes take precedence over any recommendation
made in these instructions.

5165699-BIM-C-0516
Johnson Controls Unitary Products 3
SECTION III: UNIT INSTALLATION
LOCATION
Access for servicing is an important factor in the location of any furnace.
Provide a minimum of 24” (61 cm) in front of the furnace for access to
the heating elements and controls. This access may be provided by a
closet door or by locating the furnace 24” (61 cm) from a facing wall or
partition.
FURNACE CLEARANCE
Electric furnace is approved for zero (0) in. clearance to combustible
material on all or any part of the furnace exterior and the inlet or outlet
duct work. For furnaces installed in upflow application, there must be
1” (2.54 cm) clearance from the outlet duct work for a distance of 3 feet
(91.4 cm) from the supply air opening.
RETURN AIR
In order for the furnace to work properly, a closet or alcove must have a
certain total free area opening for return air.
For Heating Only Furnace
Minimum 200 sq. in (1290 sq. cm) free area opening. Use any return
Grille with minimum 200 sq. in free opening.
For up to 4 Ton AC and 3.5 Ton HP Applications (Standard
Blower)
Minimum 250 sq. in (1613 sq. cm) free area opening. The standard
blower assembly supplied with the furnace is capable of handling up 4
Ton AC and 3.5 Ton HP applications. Use any return grille with mini-
mum 250 sq. in (1613 sq. cm) free area opening.
For 5 Ton AC and 4 Ton HP Applications (Accessory
Blower)
Minimum 350 sq. in (2129 sq. cm) free area opening. Use 5 Ton AC/4
Ton HP blower accessory 3500-7901/A. Use accessory louvered door
3501-9311 or any return grille with a minimum 350 sq. in (2129 sq. cm)
free area opening.
The return air opening can be located in a closet front door or a sidewall
above the furnace casing, or in a louvered door on the furnace. If open-
ing for the return air is located in the floor, side walls or closet door any-
where below furnace casing height, 6” (15.2 cm) minimum clearance
must be provided on the furnace side where return is located to provide
for proper air flow. See Figure 2. The 6” (15.2 cm) minimum clearance
is not required if there is a return grille installed above the furnace
height. This return grille cannot start more than three feet above the fur-
nace height.
For Upflow installations, a closet 32” (81.3 cm) wide by 30” (76.2 cm)
deep with a 30” (76.2 cm) wide door is necessary. See Figure 3.
When installing furnace in a separate closet or room which is accessi-
ble only through an outside door, a minimum of 200 in2(1290 cm2) free
opening for return air must be provided. The supply and return air must
be ducted, securely attached and be sealed to the furnace casing if
there are grilles in the outside door to the closet. Openings where ducts
pass through walls, the floor or the ceiling must be sealed to prevent air
leakage into or from closet and the living area.
Provisions shall be made to permit the return of circulating air from all
rooms and living spaces, except the bathroom(s) to the circulating air
supply inlet of the furnace. Failure to comply may cause improper heat-
ing and may cause the furnace to cycle on the limit.
DUCT SYSTEM DESIGN
Electric furnace is designed to operate at a given static pressure.
In order to assure proper air flow through the furnace, the distribution
system must be designed so that the static pressure external to the fur-
nace does not exceed the static pressure rating shown on the furnace
rating plate.
The number, size and placement of registers should be such that even
distribution of heat is provided throughout the home.
SECTION IV: DOWNFLOW FURNACE
INSTALLATION
7900 SERIES DUCT CONNECTOR
We have designed our duct connector to eliminate a sub-base require-
ment. Table 1 will help you in deciding the part number of the duct con-
nector you need.
Provide adequate clearance for servicing.
1. Locate furnace conveniently away from wall facing or partitions to
permit easy removal of components.
2. A six (6) inch space minimum should be maintained between the
furnace and closet door when door is used for return air.
3. Two (2) feet of space must be available in front of furnace for
future servicing (blower, element or furnace removal, etc.).
FIGURE 2: Upflow Closet Clearances
30”
32”
30”
Wide Door Closet
25-1/2””
Return Air
Pass Through
Frame Width
1-5/8” Min., 2-3/8 Max.

5165699-BIM-C-0516
4 Johnson Controls Unitary Products
 - Indicates connector above or below could be used depending on tolerance
in floor to duct dimension.
 - Indicates connector above could be used depending on tolerance in floor
to duct dimension.
 - Indicates connector below could be used depending on tolerance in floor to
duct dimension.
DUCT CONNECTORS (7990 SERIES)
These duct connectors are for connecting the furnace to an under the
floor supply duct system. The furnace may be installed on combustible
flooring without a separate sub-base.
INSTALLATION OF SCREW ATTACHMENT DUCT
CONNECTOR (7990 SERIES)
1. Make floor cut out as shown in Figure 5.
2. Determine the depth of the floor cavity from the surface of the floor
to the top of the supply air duct and select the appropriate duct
connector from the chart.
3. Place locating bracket (supplied with the duct connector) to the
back edge of the floor opening. See Figure 6.
TABLE 1:
Duct Connector for Electric Furnaces
FLOOR TO
DUCT DIMENSIONS FINGERED STYLE SCREW TAB STYLE
1” (2.54 cm) 7990-6211 7990-6011
2” (5.1 cm) 7990-6221 7990-6021
3” (7.6 cm)  
4” (10.2 cm) 7990-6241 7990-6041
5” (12.7 cm)  
6” (15.2 cm) 7990-6261 7990-6061
7” (17.8 cm) 7990-6271 7990-6071
8” (20.3 cm) 7990-6281 7990-6081
9” (22.8 cm)  
10” (25.4 cm) 7990-6301 7990-6101
11” (282 cm)  
12” (30.5 cm) 7990-6321 7990-6121
13” (33 cm)  
FIGURE 3: Duct Connector Depth (7990 Series)
FIGURE 4: Duct Connector Dimensions (7990 Series)
Duct Connector
Depth
Floor
Floor
Joist
SUPPLY DUCT
12
13
11
14 See
Chart
18-3/4
18-3/4
2-3/8
4-3/8
2-3/8
SCREW ATTACHMENT
2-3/8
FIGURE 5: Recommended Floor Cut-out (7990 Series)
FIGURE 4: Duct Connector Dimensions (7990 Series)
13
11
14 See
Chart
12
DUCT
CUTOUT
DIMENSIONS
DUCT CONNECTORS FOR
TAB ATTACHMENT
18-3/4
2-3/8
18-3/4
2-3/8
4-3/8
2-3/4
Min.
23-1/4
20-1/2
9-7/8
2-1/8
1-3/8 6-3/8
9-3/4
20
3-1/4
1-1/8
15
15
1
Rear Wall
of Enclosure
Ceiling Cut-out
for Roof Jack
Floor Cut-out
for Duct Connector
Furnace
Outline
Optional
Electric
Entrance
Floor
Future Refrigerant
Line Entrance

5165699-BIM-C-0516
Johnson Controls Unitary Products 5
4. Apply a water based duct sealant to the 1/2” supply duct attach-
ment flange of the duct connector.
5. Determine which of the four positions the duct connector best cen-
ters over the supply duct and insert it through the floor cutout.
6. When properly aligned with the supply duct, secure the duct con-
nector to the floor with nails, flat head screws or staples.
7. Use screws as required to secure duct connector to supply duct.
8. Cut out the opening to the supply duct. If sealant was not used, the
installer should tape the mating flanges to provide a good air seal.
INSTALLATION OF TAB ATTACHMENT DUCT
CONNECTOR (7990 SERIES)
1. Make floor cut out as shown in Figure 5.
2. Determine the depth of the floor cavity from the surface of the floor
to the top of the supply air duct and select the appropriate duct
connector from the chart.
3. Place locating bracket (supplied with the duct connector) to the
rear of the floor area for the furnace. See Figure 7.
4. Determine which of the four positions the duct connector best cen-
ters over the supply duct and insert it through the floor cutout.
5. Mark cut-out location on the supply duct and remove the duct con-
nector.
6. Cut out the opening to the supply duct.
7. Bend tabs down through and back up under the supply duct.
8. Secure the duct connector to the floor with nails, flat head screws
or staples.
The duct connector is designed for use on ducts down to 12" in width.
When using the connector on smaller width ducts, there will not be suf-
ficient clearance to bend the tabs on two sides of the duct connector.
In such cases the tabs may be attached to the sides of the duct by
using sheet metal screws or other suitable fasteners. Holes for sheet
metal screws are provided in three (3) tabs on each side of the duct
connector. If more than 3 tabs need to be used to provide a more
secure and air tight connection, the remaining tabs can also be fas-
tened to the duct with screws after drilling the required screw holes.
PARALLEL DUCT SYSTEM
The EB Duct Connector Insert 37323716001 may be used on EB
Series Electric Furnaces where the duct system runs parallel to the fur-
nace. See Figure 8. The EB Duct Connector Insert should not be used if
the duct system runs perpendicular to the furnace or if the duct system
extends only one direction from the furnace.
The Duct Connector Insert cannot be used with 1” and 2” Duct Connec-
tors (7990-6011, 7990-6021, 7990-6211, and 7990-6221).
Follow Accessory Kit Installation Instruction 035-20632-001 provided
with the Duct Connector Insert.
FIGURE 6: Duct Connector Screw Attachment (7990 Series)
NOTICE
Duct sealant and tape must be classified as meeting HUD Standard
3280.715, U.L. Standard 181A.
FIGURE 7: Duct Connector Tab Attachment (7990 Series)
Locator Bracket
Nails, Flat Head Screws
or Staples
Screws
Floor
SUPPLY DUCT
Bend Tabs Under Duct
Opening to Secure to
the Supply Duct
SUPPLY DUCT
Locator Bracket
Nails, Flat Head Screws
or Staples
Floor
FIGURE 8: Duct System Configuration
FIGURE 9: Installation of Furnace
FURNACE DOOR
FURNACE DOOR
PERPENDICULAR LAYOUT
PARALLEL LAYOUT
Furnace Seated
Against the
Locator Bracket
Secure Furnace
to Floor with Two
Nails or Screws

5165699-BIM-C-0516
6 Johnson Controls Unitary Products
INSTALLATION OF THE FURNACE
1. Remove the front panels and set the furnace onto the duct con-
nector. Slide it back until the rear of the unit engages the locator
bracket.
2. Secure the front of the furnace with two screws at the mounting
holes provided. See Figure 9.
3. Secure the top of the furnace to a structural member using screw
through the strap at the top of the furnace. Strap may be moved to
any of the holes located along the top back of the furnace. Installer
may provide an equivalent method, such as screws through the
casing side.
FURNACE CONVERSION TO UPFLOW
APPLICATION
Upflow furnace conversion is easily accomplished by following the
steps listed below:
Provide adequate clearance for servicing:
1. Before Conversion, locate the furnace conveniently away from
wall facing or partitions to permit easy removal and installation of
components.
2. Two (2) feet of space must be available in front of furnace for
future servicing (blower or element removal, furnace removal,
etc.).
Upflow Flange Kit 3500-7211/A, Coil Shelf and Insulation Kit 3500-
8961/A, and Door 3501-9111 are required prior to performing the steps
below. Filter Adapter box 3500-5451 is an optional item required only
if there are no other means provided for filtering the return air:
1. Assemble the 3500-5451 filter box per instructions provided with
kit.
2. Remove furnace panel.
3. Remove air filter.
4. Remove strap on the top of the unit, saving the screw and strap for
later use.
5. Turn entire unit upside-down, so the filter box is on the floor.
6. Remove two (2) screws that are on the front of the unit at the top.
Obtain front panel hanger angle from the upflow kit 3500-7211/A.
Secure the hanger angle with two (2) screws removed from the
furnace casing See Figure 10.
7. Attach the strap that was removed in Step 4 to the top, side or
back of the furnace.
8. Install the duct flange plate on top of the inverted furnace as
shown in Figure 11.
9. If installing a POS, Standard or Deluxe Air Systems, proceed to
Step 10.
Optional start collar for the Economy POS system shipped with
3500-7211/A can be used for blend air flex duct installation. Punch
the lineset knockout out and position the start collar over it. Duct
connector edge can be pushed under the casing flange and
screws provided can be used to capture the other end of duct con-
nector. Secure collar to top of furnace.
10. The flange plate shipped with kit 3500.7211* is mounted to the fur-
nace using eight (8) screws supplied with kit 3500.8961A. Two
blunt screws should be used to secure the front edge of flange
plate to furnace. See Figure 11.
11. Secure the top of the furnace to a structural member using screws
and the strap on top of the furnace. The mobile home manufac-
turer may provide an equivalent strap, if required, to secure the
furnace.
12. If excessive movement is expected, then some blower support is
recommended.
* Kits are optional and not provided with the furnace and need to be
ordered prior to converting unit to the upflow configuration.
WIRING
Furnace wiring is complete except for the power supply and the thermo-
stat wires. See wiring diagrams (Figures 16-21) for wire and fuse size.
See Table 2 for ground wire sizes. Thermostat wires connect through
side of furnace and should also be no smaller than 22 gauge. Power
wires can enter through the side of the unit or through the auxiliary
entrance, located in the bottom of the unit. (See Figure 1). When bring-
ing wiring through the bottom of the furnace, cable connectors must be
installed to hold wiring in place and to relieve any strain on the wiring.
These connectors will also serve as a seal between the furnace and the
floor. Thus, additional sealing is not required.
Refer to the National Electrical Code, Canadian Electrical Code and
local codes for wiring material requirements.
FIGURE 10: Hanger Angle Attachment
Hanger Angle
Screw x 2
Casing
FIGURE 11: Blower Bracket and Duct Flange Attachment
NOTICE
The furnaces are equipped with either one or two 60 amp circuit
breakers. These circuit breakers protect the wiring inside of the fur-
nace in the event of a short circuit. Additionally, these breakers pro-
vide a means of disconnecting the power to the unit. The circuit
breakers in the furnace are not meant to protect the branch circuit
wiring between the furnace and the home's breaker panel. General
wire and breaker sizes are shown in Table 2. If sheathed cable is
used, refer to National Electrical Code, Canadian Electrical Code
and local codes for additional requirements concerning supply cir-
cuit wiring. Electrical Data can be found in Table 4.
Flange Plate
(Mounted with screws
EB Series
(Upflow Furnace)
Blend Air
Start Collar
Lineset
Knockout
Use Blunt
Screws Here

5165699-BIM-C-0516
Johnson Controls Unitary Products 7
Models for EB15F, EB17F, EB20F, and EB23F may be connected to a
single or dual branch circuit.
These units are shipped from the factory set up for dual power supply
connections. For single power supply connections, jumper bars (P/N
3500-378P*) are required and are available from the factory. See Figure
12.
Casing or cabinet must be permanently grounded in accordance with National Electrical Code or other applicable codes.
IMPORTANT
All installation on field wiring must be rated at 60ºC or higher.
TABLE 2: Wiring Requirements
MODELS EB10F1
1. Does Not require a Jumper.
EB12F2
2. Jumper provided for Single Branch Circuit Only.
EB15F1EB17F1EB20F1EB23F3
3. Requires Jumper Bars (P/N 3500-378P) - Dual Supply for U.S. Only.
Single Branch Circuit Service 2 Leads + 1 Ground CKT #1
Nominal Circuit Load - Amps 44.0 50.7 64.0 70.7 84.0 94.0
Minimum Wire Size (90ºC) #8 #6 #4 #4 #3 #2
Minimum Wire Size (75ºC) #6 #6 #4 #3 #2 #1
Minimum Wire Size (60ºC) #6 #4 #3 #2 #1 #0
Ground Wire Size + #10 #8 #8 #8 #6 #6
Max. Fuse (or C.B.) - Amps 60 70 80 90 110 125
Dual Branch Circuit Service
NOT
APPROVED
CKT #1 CKT #2 CKT #1 CKT #2 CKT #1 CKT #2 CKT #1 CKT #2
Branch Circuit Load - Amps 44.0 20.1 47.3 23.4 44.0 40.0 47.3 46.7
Branch Circuit Min. - Amps 55.0 25.2 59.2 29.3 55.0 50.0 59.2 58.4
Minimum Wire Size (90ºC) #8 #10 #6 #10 #8 #8 #6 #6
Minimum Wire Size (75ºC) #6 #10 #6 #10 #6 #8 #6 #6
Minimum Wire Size (60ºC) #6 #10 #4 #10 #6 #6 #4 #4
Ground Wire Size 4
4. Refer to National Electrical Code. Table 250-122 for Non-Sheathed Conductor Ground Wire.
#10 #10 #10 #10 #10 #10 #10 #10
Max. Fuse (or C.B.) - Amps 60 30 60 30 60 50 60 60
TABLE 3: EB Series Blower Performance
Static Pressure (inches of w.c.) 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
Low Speed - Heating Speed
Models EB10, 12, 15 CFM (STD. Air) 945 936 936 924 915 889 870 813 705
Medium Speed - Heating Speed
Models EB17, 20, 23 CFM (STD. Air) 1160 1145 1145 1140 1129 1109 1073 1027 935
Medium High - with A-Coil in place CFM (STD. Air) 1340 1317 1290 1252 1208 1158 1095 1021 876
High - with A-Coil in place CFM (STD. Air) 1573 1534 1490 1435 1369 1309 1237 1135 1019
TABLE 4: Electrical Data
MODEL NUMBER EB10F EB12F EB15F EB17F EB20F EB23F
D.O.E.
Output 240 VAC 60 Hz.,1 Phase BTU 34,000 39,000 51,000 56,000 67,000 77,000
kW 10.0 11.4 15.0 16.4 19.6 22.6
OUTPUT
CAPACITY
230 VAC
60 Hz.,1 Phase BTU 31,000 36,000 47,000 52,000 61,000 71,000
kW 9.1 10.6 13.8 15.2 17.9 20.8
220 VAC
60 Hz.,1 Phase BTU 29,000 33,000 43,000 48,000 57,000 65,000
kW 8.5 9.7 12.6 14.1 16.7 19.1
Element Capacity
@ 240 VAC kW 9.6 11.2 14.4 16.0 19.2 21.6
Amps 40.0 46.7 60.0 66.7 80.0 90.0
Motor Amps @ 240 V. 4.0 Maximum
Circuit Load Amps
@ 240 V. CKT 1 44.0150.7144.0 47.3 44.0 47.3
CKT 2 NA NA 20.0 23.4 40.0 46.7
1. Approved for Single Branch Circuit Service Only.

5165699-BIM-C-0516
8 Johnson Controls Unitary Products
SECTION V: THERMOSTAT
INSTALLATION
The adjustable heat anticipator in the thermostat is pre-set at 0.4Amps.
This setting should be checked at the time of installation.
In some cases the thermostat may be a “self-setting” type in which case
no amp setting will be found on the thermostat, eliminating the need for
any field adjustment.
Thermostat should be located on an inside wall in an open area to more
closely regulate average room air, preferably, where there is air move-
ment back to furnace. Care should be used to locate thermostat away
from hot air discharge openings, lights, etc. Locating height of thermo-
stat is important. Thermostat should be located 52” to 66” (132 - 167.6
cm) above the floor. This is sometimes called the comfort zone.
If a condenser with its own Transformer shares a Heat/Cool Thermostat
with this furnace, use a thermostat with isolating contacts to prevent
interconnection of Class II 24 Volt Systems.
Cycle furnace using the thermostat to make sure it will operate cor-
rectly.
Maintenance and operating instructions are in the customer envelope
accompanying the furnace. Give the customer envelope to the home
owner.
FIGURE 12: Control Box
TRANSFORMER
LIMIT
SWITCHES
GROUND
LUGS
3500-378P* JUMPER
BARS (FOR SINGLE
BRANCH CIRCUIT
SERVICE)
THERMOSTAT
WIRES
CIRCUIT
BREAKERS
SEQUENCERS
NOTE:
As Shipped, the jumper bar assembly
is set up for bottom entry. For side
entry, the top lug can be removed and
re-positioned, as shown, to provide
proper wire bending clearances.
A0345-001
0
6
FFO
NO
N
O
F
FO
06
WARNING
For personal safety be sure to turn the electrical power OFF at the
household service box and at the furnace circuit breakers before
attempting any service or maintenance operations. Homeowners
should never perform any maintenance which requires opening
electric box door.
Furnace is equipped with a protective shield over field wiring con-
nection. When field wiring is completed, shield must be replaced to
prevent hazard of electrical shock when using furnace disconnect.
(See Figure 13.)
FIGURE 13: Field Wiring Shield
!
Circuit
Breakers
Electric
Panel
FieldWiring
Protective
Shield
BLOWER
CAUTION
When using separate thermostats, a thermostat interlock system
must be provided to prevent simultaneous operation of the furnace
and air conditioner. Simultaneous operation can result in coach
overheating, equipment damage and energy waste. (See Figures
14 and 15.)
Do not connect Yellow wire to thermostat until an outdoor unit is
installed.
FIGURE 14: Thermostat Wiring
!
Cooling
Thermostat
Heating
Thermostat
To
Air Conditioner
To
Furnace
DoublePole
Double Throw Switch

5165699-BIM-C-0516
Johnson Controls Unitary Products 9
SECTION VI: OPTIONAL AIR
CONDITIONING ACCESSORIES
This furnace is already equipped with a blower and control system to
add-on air conditioning and heat pump. Insulation and coil shelf kit
(3500-8941/B for downflow up to 4 ton (19-1/2” or less deep coil), 3500-
8961/A for upflow up to 4 ton (19-1/2” or less deep coil), 3500-8601 for
downflow coils 5 ton or any coil with a drain pan longer than 19-1/2”,
and 3500-8602 extension cabinet for any coils taller than 19”. must be
installed when adding on such remote air conditioning systems.
HIGH PERFORMANCE BLOWER
ACCESSORY PACKAGE
All EB furnaces are equipped with a blower and control system to add-
on air conditioning and heat pumps to specified sizes. If the require-
ment is to achieve more air flow or cooling than specified, then the
blower inside the furnace has to be replaced with an accessory blower
package 3500-7901/A. This accessory blower package would deliver
air conditioning up to 5-tons, and heat pump up to 4-tons. Accessory
package (3500-7901/A) includes blower, insulation, coil shelf, trap,
clamps, etc. Please refer to the installation instructions packed with the
accessory package for more information.
FIGURE 15: Thermostat Wiring
DELUXEBLEND AIRII
FRESH
AIR
FRESH
AIR
OFF
AUTO
ALARM
RED
RED
WHITE WHITE
GREEN
GREEN
BLACK
BLACK
BLACK
RED
WHITE
GREEN
YELLOW
WIRES FROM FURNACE
NOT FACTORY
INSTALLED
STANDARD OR DELUXE
BLEND AIR CONTROLBOX
THERMOSTATWIRING SCHEMATIC FOR:BLEND AIR AND FURNACE
The EB Furnaces are A/C ready.
All furnaces installations should include a minimum of four conductor thermostat
wiring to accommodate future air conditioning installations.
Four-conductor wire is required for thermostat connection.
Attach the 4 low voltage wires extending from the control
box as follows:
1.wire from Furnace to thermostat wire.
2. wire from Furnace to thermostat wire.
3.wire from Furnace to thermostat wire.
4.wire from Furnace to condensing unit contactor.
REDRED
WHITE WHITE
GREEN GREEN
BLACK
WARNING
Failure to install this insulation and coil shelf kit could result in dam-
age to equipment and/or personal injury. Liability and warranty from
the manufacturer could also be void.
!CAUTION
All areas around the line sets, drain hoses and other openings in
the coil shelf should be sealed air tight. Use some moldable com-
pound or caulking to seal the area. Failure to do so may result in
loss of performance and premature compressor failure.
!

5165699-BIM-C-0516
10 Johnson Controls Unitary Products
SECTION VII: WIRING DIAGRAMS
FIGURE 16: EB10F Wiring Diagram
IF ANY OF THE ORIGINAL WIRE
SUPPLIED WITH THIS UNIT MUST BE
REPLACED. IT MUST BE REPLACED
WITH TYPE 105 C THERMOPLASTIC
WIRING MUST CONFORM TO LOCAL CODES
BLK
RED
WHT
GRN
BLEND AIR
CONTROL BOX
BLU-MED. HIGH SP.
MOTOR
YEL-MED. LOW SP.
BLK-COOLING SP.
RED-HEATING SP.
2 SPADE (INSUL.)
TERMINALS USED
WHEN
CHANGING
SPEEDS LINE
LOAD
ORG
BRN
CAPACITOR
ORG-COMMON.
TRANSFORMER
BLK
3A
FUSE
RED
RED
BLK
G
W
RH
Y
HEAT/COOL
T'STAT
BLOWER
RELAY
2
4
6
5
1
3
YEL
BLK
M3 M1
M2
H2
SEQUENCER
BLU
YEL
R
R
ELEMENTS
SWITCHES
LIMIT
60 AMP
CIRCUIT #1
BREAKER
ORG
ORG
YEL
ORG
MODEL: EB10F
COND. UNIT
CONTACTOR
A
I
R
F
L
REPLACE
FILTER
WITH SAME
SIZE
240 VAC - 60 Hz - 1 PHASE
NOTE:
4-SPEED BLOWER
EB SERIES FURNACES
GRN
WHT
M4
H1
YEL
L
L
YEL
YEL
SINGLE BRANCH
CIRCUIT SERVICE
240 VAC.
60Hz
1 PHASE
GND. LUG
DO NOT OPEN THIS PANEL UNTIL ELECTRICAL POWER IS SHUT
OFF AT HOUSEHOLD SERVICE BOX. CHECK WITH A VOLTMETER
OR OTHER PROPER INSTRUMENT.
-HAZARD OF ELECTRICAL SHOCK-
SERVICE CONNECTION COVER MUST BE INSTALLED.
IF FILTERS ARE USED, CLEAN/REPLACE EACH SEASON OR
MORE OFTEN IF NEEDED. 5166485-UWD-A-1015
IMPORTANT -
HIGH VOLTAGE
SHOCK HAZARD
THIS FURNACE MAY BE CONNECTED TO MORE THAN ONE POWER SUPPLY.
TURN OFF ALL POWER TO THE FURNACE AT THE WALL BOX, AND LOCK IT OUT.
6
2
48
1
0
RELAY
BRN
ORG
ORG
ORG
BRN
WARNING
CAUTION
D.O.E. OUTPUT CAPACITY - BTU 34,000
MAX. MOTOR-FLA 4.0
SINGLE BRANCH
CIRCUIT SERVICE
2 LEADS +
1 GROUND
NOMINAL CIRCUIT LOAD-AMPS 44.0
WIRE SIZE (75 C) COPPER #6
WIRE SIZE (60 C) COPPER #6
MAX. FUSE SIZE (OR CB) - AMPS 60

5165699-BIM-C-0516
Johnson Controls Unitary Products 11
FIGURE 17: EB12F Wiring Diagram
IF ANY OF THE ORIGINAL WIRE
SUPPLIED WITH THIS UNIT MUST BE
REPLACED. IT MUST BE REPLACED
WITH TYPE 105 C THERMOPLASTIC
WIRING MUST CONFORM TO LOCAL CODES
BLK
RED
WHT
GRN
BLEND AIR
CONTROL BOX
BLU-MED. HIGH SP.
MOTOR
YEL-MED. LOW SP.
BLK-COOLING SP.
RED-HEATING SP.
2 SPADE (INSUL.)
TERMINALS USED
WHEN
CHANGING
SPEEDS LINE
LOAD
ORG
BRN
CAPACITOR
ORG-COMMON.
TRANSFORMER
BLK
3A
FUSE
RED
RED
BLK
G
W
RH
Y
HEAT/COOL
T'STAT
BLOWER
RELAY
2
4
6
5
1
3
RED
BLK
M3 M1
M2
H2
SEQUENCER
BLU
RED
R
R
ELEMENTS SWITCHES
LIMIT
60 AMP
CIRCUIT #1
BREAKER
60 AMP
CIRCUIT #2
BREAKER
BLK
ORG
YEL
ORG
MODEL: EB12F
COND. UNIT
CONTACTOR
A
I
R
F
L
REPLACE
FILTER
WITH SAME
SIZE
240 VAC - 60 Hz - 1 PHASE
NOTE:
4-SPEED BLOWER
EB SERIES FURNACES
GRN
WHT
M4
H1
YEL
L
L
YEL
YEL
SINGLE BRANCH
CIRCUIT SERVICE
240 VAC.
60Hz
1 PHASE
GND. LUG
THIS FURNACE MAY BE CONNECTED TO MORE THAN ONE POWER SUPPLY.
TURN OFF ALL POWER TO THE FURNACE AT THE WALL BOX, AND LOCK IT OUT.
DO NOT OPEN THIS PANEL UNTIL ELECTRICAL POWER IS SHUT
OFF AT HOUSEHOLD SERVICE BOX. CHECK WITH A VOLTMETER
OR OTHER PROPER INSTRUMENT.
-HAZARD OF ELECTRICAL SHOCK-
SERVICE CONNECTION COVER MUST BE INSTALLED.
IF FILTERS ARE USED, CLEAN/REPLACE EACH SEASON OR
MORE OFTEN IF NEEDED.
CAUTION
5166512-UWD-A-1015
IMPORTANT -
HIGH VOLTAGE
SHOCK HAZARD
WARNING
6
2
48
1
0
RELAY
BRN
BRN
BLK
ORG
D.O.E. OUTPUT CAPACITY - BTU 39,000
MAX. MOTOR-FLA 4.0
SINGLE BRANCH
CIRCUIT SERVICE
2 LEADS +
1 GROUND
NOMINAL CIRCUIT LOAD-AMPS 50.7
WIRE SIZE (75 C) COPPER #6
WIRE SIZE (60 C) COPPER #4
MAX. FUSE SIZE (OR CB) - AMPS 70

5165699-BIM-C-0516
12 Johnson Controls Unitary Products
BLK
RED
WHT
GRN
BLEND AIR
CONTROL BOX
BLU-MED. HIGH SP.
MOTOR
RE-HEATING SP.
BLK-COOLING SP.
YEL-MED SP.
2 SPADE (INSUL.)
TERMINALS USED
WHEN
CHANGING
SPEEDS LINE
LOAD
ORG
BRN
CAPACITOR
ORG-COMMON.
TRANSFORMER
BLK
3A
FUSE
RED
RED
BLK
G
W
RH
Y
HEAT/COOL
T'STAT
BLOWER
RELAY
2
4
6
5
1
3
BLK
M3 M1
M2
H2
M5
M6
H4
H3
WHT
BLK
SEQUENCER
BLU
60 AMP
CIRCUIT 1
240 VAC.
60Hz
1 PHASE
CIRCUIT #1
BREAKER
GND. LUG
60 AMP
CIRCUIT 2
240 VAC.
60Hz
1 PHASE
CIRCUIT #2
BREAKER
DUAL BRANCH
CIRCUIT SERVICE
YEL
YEL
60 AMP
CIRCUIT #1
BREAKER
60 AMP
240 VAC.
60Hz
1 PHASE
CIRCUIT #2
BREAKER GND. LUG
SINGLE BRANCH
CIRCUIT SERVICE
GND. LUG
MODEL: EB15F
COND. UNIT
CONTACTOR
A
I
R
F
L
240 VAC - 60 Hz - 1 PHASE
REQUIRES JUMPER BARS (P/N 3500-378/*)
4-SPEED BLOWER
EB SERIES FURNACES
GRN
WHT
M4
H1
RED
SHOCK HAZARD
THIS FURNACE MAY BE CONNECTED TO MORE THAN ONE POWER SUPPLY.
TURN OFF ALL POWER TO THE FURNACE AT THE WALL BOX, AND LOCK IT OUT.
DO NOT OPEN THIS PANEL UNTIL ELECTRICAL POWER IS SHUT
OFF AT HOUSEHOLD SERVICE BOX. CHECK WITH A VOLTMETER
OR OTHER PROPER INSTRUMENT.
-HAZARD OF ELECTRICAL SHOCK-
SERVICE CONNECTION COVER MUST BE INSTALLED.
IF FILTERS ARE USED, CLEAN/REPLACE EACH SEASON.
OR MORE OFTEN IF NEEDED.
CAUTION
IMPORTANT -
HIGH VOLTAGE
WARNING
IF ANY OF THE ORIGINAL WIRE
SUPPLIED WITH THIS UNIT MUST BE
REPLACED. IT MUST BE REPLACED
WITH TYPE 105 C THERMOPLASTIC
WIRING MUST CONFORM TO LOCAL CODES
R
R
R
L
L
L
ELEMENTS LIMIT
SWITCHES
NOTE:
RED
YEL
YEL
ORG
ORG
BLK
REPLACE
FILTER
WITH SAME
SIZE
WHT
BLK
ORG
ORG
BLK
5166513-UWD-A-1015
6
2
48
1
0
RELAY
6
2
48
1
0
RELAY
BRN
BLK
BLK
ORG
YEL
ORG
D.O.E. OUTPUT CAPACITY - BTU 51,000
MAX. MOTOR-FLA 4.0
SINGLE BRANCH
CIRCUIT SERVICE
2 LEADS +
1 GROUND
NOMINAL CIRCUIT LOAD-AMPS 64.0
WIRE SIZE (75 C) COPPER #4
WIRE SIZE (60 C) COPPER #3
MAX. FUSE SIZE
(OR CB) - AMPS 80
DUAL BRANCH
CIRCUIT SERVICE
4 LEADS +
2 GROUNDS
CKT #1-CKT #2
BRANCH CKT. LOAD-AMPS 44 20.1
BRANCH CKT. MIN. AMPACITY 55 25.2
WIRE SIZE (75 C) COPPER #6 #10
WIRE SIZE (60 C) COPPER #6 #10
MAX. FUSE SIZE
(OR CB) - AMPS
60 30
FIGURE 18: EB15F Wiring Diagram

5165699-BIM-C-0516
Johnson Controls Unitary Products 13
FIGURE 19: EB17F Wiring Diagram
BLK
RED
WHT
GRN
BLEND AIR
CONTROL BOX
BLU-MED. HIGH SP.
MOTOR
RE-HEATING SP.
BLK-COOLING SP.
YEL-MED SP.
2 SPADE (INSUL.)
TERMINALS USED
WHEN
CHANGING
SPEEDS LINE
LOAD
ORG
BRN
CAPACITOR
ORG-COMMON.
TRANSFORMER
BLK
3A
FUSE
RED
RED
BLK
G
W
RH
Y
HEAT/COOL
T'STAT
BLOWER
RELAY
2
4
6
5
1
3
RED
BLK
M3 M1
M2
H2
M5
M6
H4
H3
WHT
BLK
SEQUENCER
BLU
60 AMP
CIRCUIT 1
240 VAC.
60Hz
1 PHASE
CIRCUIT #1
BREAKER
GND. LUG
60 AMP
CIRCUIT 2
240 VAC.
60Hz
1 PHASE
CIRCUIT #2
BREAKER
DUAL BRANCH
CIRCUIT SERVICE
YEL
YEL
60 AMP
CIRCUIT #1
BREAKER
60 AMP
240 VAC.
60Hz
1 PHASE
CIRCUIT #2
BREAKER GND. LUG
SINGLE BRANCH
CIRCUIT SERVICE
GND. LUG
MODEL: EB17F
COND. UNIT
CONTACTOR
A
I
R
F
L
240 VAC - 60 Hz - 1 PHASE
REQUIRES JUMPER BARS (P/N 3500-378/*)
4-SPEED BLOWER
EB SERIES FURNACES
GRN
WHT
M4
H1
RED
SHOCK HAZARD
THIS FURNACE MAY BE CONNECTED TO MORE THAN ONE POWER SUPPLY.
TURN OFF ALL POWER TO THE FURNACE AT THE WALL BOX, AND LOCK IT OUT.
DO NOT OPEN THIS PANEL UNTIL ELECTRICAL POWER IS SHUT
OFF AT HOUSEHOLD SERVICE BOX. CHECK WITH A VOLTMETER
OR OTHER PROPER INSTRUMENT.
-HAZARD OF ELECTRICAL SHOCK-
SERVICE CONNECTION COVER MUST BE INSTALLED.
IF FILTERS ARE USED, CLEAN/REPLACE EACH SEASON
OR MORE OFTEN IF NEEDED.
CAUTION
IMPORTANT -
HIGH VOLTAGE
WARNING
IF ANY OF THE ORIGINAL WIRE
SUPPLIED WITH THIS UNIT MUST BE
REPLACED. IT MUST BE REPLACED
WITH TYPE 105 C THERMOPLASTIC
WIRING MUST CONFORM TO LOCAL CODES
R
R
R
L
L
L
ELEMENTS LIMIT
SWITCHES
NOTE:
RED
YEL
YEL
ORG
ORG
BLK
REPLACE
FILTER
WITH SAME
SIZE
WHT
BLK
ORG
ORG
BLK
5166514-UWD-A-1015
6
2
48
1
0
RELAY
6
2
48
1
0
RELAY
BRN
BLK
BLK
ORG
YEL
ORG
D.O.E. OUTPUT CAPACITY - BTU 56,000
MAX. MOTOR-FLA 4.0
SINGLE BRANCH
CIRCUIT SERVICE
2 LEADS +
1 GROUND
NOMINAL CIRCUIT LOAD-AMPS 70.7
WIRE SIZE (75 C) COPPER #3
WIRE SIZE (60 C) COPPER #2
MAX. FUSE SIZE
(OR CB) - AMPS 90
DUAL BRANCH
CIRCUIT SERVICE
4 LEADS +
2 GROUNDS
CKT #1-CKT #2
BRANCH CKT. LOAD-AMPS 47.3 23.4
BRANCH CKT. MIN. AMPACITY 59.2 29.3
WIRE SIZE (75 C) COPPER #6 #10
WIRE SIZE (60 C) COPPER #4 #10
MAX. FUSE SIZE
(OR CB) - AMPS
60 30

5165699-BIM-C-0516
14 Johnson Controls Unitary Products
FIGURE 20: EB20F Wiring Diagram
BLK
RED
WHT
GRN
BLEND AIR
CONTROL BOX
BLU-MED. HIGH SP.
MOTOR
RE-HEATING SP.
BLK-COOLING SP.
YEL-MED SP.
2 SPADE (INSUL.)
TERMINALS USED
WHEN
CHANGING
SPEEDS LINE
LOAD
ORG
BRN
CAPACITOR
ORG-COMMON.
TRANSFORMER
BLK
3A
FUSE
RED
RED
BLK
G
W
RH
Y
HEAT/COOL
T'STAT
BLOWER
RELAY
2
4
6
5
1
3
RED
BLK
M3 M1
M2
H2
M5
M6
H4
H3
WHT
BLK
SEQUENCER
BLU
60 AMP
CIRCUIT 1
240 VAC.
60Hz
1 PHASE
CIRCUIT #1
BREAKER
GND. LUG
60 AMP
CIRCUIT 2
240 VAC.
60Hz
1 PHASE
CIRCUIT #2
BREAKER
DUAL BRANCH
CIRCUIT SERVICE
YEL
YEL
60 AMP
CIRCUIT #1
BREAKER
60 AMP
240 VAC.
60Hz
1 PHASE
CIRCUIT #2
BREAKER GND. LUG
SINGLE BRANCH
CIRCUIT SERVICE
GND. LUG
MODEL: EB20F
COND. UNIT
CONTACTOR
A
I
R
F
L
240 VAC - 60 Hz - 1 PHASE
REQUIRES JUMPER BARS (P/N 3500-378/*)
4-SPEED BLOWER
EB SERIES FURNACES
GRN
WHT
M4
H1
M7
M8
RED
SHOCK HAZARD
THIS FURNACE MAY BE CONNECTED TO MORE THAN ONE POWER SUPPLY.
TURN OFF ALL POWER TO THE FURNACE AT THE WALL BOX, AND LOCK IT OUT.
DO NOT OPEN THIS PANEL UNTIL ELECTRICAL POWER IS SHUT
OFF AT HOUSEHOLD SERVICE BOX. CHECK WITH A VOLTMETER
OR OTHER PROPER INSTRUMENT.
-HAZARD OF ELECTRICAL SHOCK-
SERVICE CONNECTION COVER MUST BE INSTALLED.
IF FILTERS ARE USED, CLEAN/REPLACE EACH SEASON
OR MORE OFTEN IF NEEDED.
CAUTION
IMPORTANT -
HIGH VOLTAGE
WARNING
IF ANY OF THE ORIGINAL WIRE
SUPPLIED WITH THIS UNIT MUST BE
REPLACED. IT MUST BE REPLACED
WITH TYPE 105 C THERMOPLASTIC
WIRING MUST CONFORM TO LOCAL CODES
R
R
R
L
L
L
ELEMENTS LIMIT
SWITCHES
NOTE:
R
L
RED
RED
YEL
YEL
ORG
ORG
BLK
BLK
REPLACE
FILTER
WITH SAME
SIZE
WHT
BLK
ORG
ORG
BLK
5166515-UWD-A-1015
6
2
48
1
0
RELAY
6
2
48
1
0
RELAY
BRN
BLK
BLK
ORG
YEL
ORG
D.O.E. OUTPUT CAPACITY - BTU 67,000
MAX. MOTOR-FLA 4.0
SINGLE BRANCH
CIRCUIT SERVICE
2 LEADS +
1 GROUND
NOMINAL CIRCUIT LOAD-AMPS 84.0
WIRE SIZE (75 C) COPPER #2
WIRE SIZE (60 C) COPPER #1
MAX. FUSE SIZE
(OR CB) - AMPS 110
DUAL BRANCH
CIRCUIT SERVICE
4 LEADS +
2 GROUNDS
CKT #1-CKT #2
BRANCH CKT. LOAD-AMPS 44 40
BRANCH CKT. MIN. AMPACITY 55 50
WIRE SIZE (75 C) COPPER #6 #8
WIRE SIZE (60 C) COPPER #6 #6
MAX. FUSE SIZE
(OR CB) - AMPS
60 50

5165699-BIM-C-0516
Johnson Controls Unitary Products 15
FIGURE 21: EB23F Wiring Diagram
IF ANY OF THE ORIGINAL WIRE
SUPPLIED WITH THIS UNIT MUST BE
REPLACED. IT MUST BE REPLACED
WITH TYPE 105 C THERMOPLASTIC
WIRING MUST CONFORM TO LOCAL CODES
BLK
RED
WHT
GRN
BLEND AIR
CONTROL BOX
BLU-MED. HIGH SP.
MOTOR
RE-HEATING SP.
BLK-COOLING SP.
YEL-MED SP.
2 SPADE (INSUL.)
TERMINALS USED
WHEN
CHANGING
SPEEDS LINE
LOAD
ORG
BRN
CAPACITOR
ORG-COMMON.
TRANSFORMER
BLK
3A
FUSE
RED
RED
BLK
G
W
RH
Y
HEAT/COOL
T'STAT
BLOWER
RELAY
2
4
6
5
1
3
RED
BLK
M3 M1
M2
H2
M5
M6
H4
H3
WHT
BLK
SEQUENCER
BLU
YEL
R
R
R
L
L
L
ELEMENTS LIMIT
SWITCHES
60 AMP
CIRCUIT 1
240 VAC.
60Hz
1 PHASE
CIRCUIT #1
BREAKER
GND. LUG
DUAL BRANCH
CIRCUIT SERVICE
YEL
YEL
ORG
60 AMP
CIRCUIT #1
BREAKER
60 AMP
240 VAC.
60Hz
1 PHASE
CIRCUIT #2
BREAKER GND. LUG
SINGLE BRANCH
CIRCUIT SERVICE
MODEL: EB23F
COND. UNIT
CONTACTOR
A
I
R
F
L
REPLACE
FILTER
WITH SAME
SIZE
240 VAC - 60 Hz - 1 PHASE
REQUIRES JUMPER BARS (P/N 3500-378/*)
NOTE:
4-SPEED BLOWER
EB SERIES FURNACES
GRN
WHT
M4
H1
M7
M8
RED
R
L
SHOCK HAZARD
THIS FURNACE MAY BE CONNECTED TO MORE THAN ONE POWER SUPPLY.
TURN OFF ALL POWER TO THE FURNACE AT THE WALL BOX, AND LOCK IT OUT.
DO NOT OPEN THIS PANEL UNTIL ELECTRICAL POWER IS SHUT
OFF AT HOUSEHOLD SERVICE BOX. CHECK WITH A VOLTMETER
OR OTHER PROPER INSTRUMENT.
-HAZARD OF ELECTRICAL SHOCK-
SERVICE CONNECTION COVER MUST BE INSTALLED.
IF FILTERS ARE USED, CLEAN/REPLACE EACH SEASON
OR MORE OFTEN IF NEEDED.
CAUTION
IMPORTANT -
HIGH VOLTAGE
WARNING
YEL
WHT
RED
RED
YEL
YEL
BLK
5166516-UWD-A-1015
60 AMP
CIRCUIT 2
240 VAC.
60Hz
1 PHASE
CIRCUIT #2
BREAKER GND. LUG
ORG
ORG
BLK
BLK
ORG
ORG
BLK
6
2
48
1
0
RELAY
6
2
48
1
0
RELAY
BRN
BLK
BLK
ORG
D.O.E. OUTPUT CAPACITY - BTU 77,000
MAX. MOTOR-FLA 4.0
SINGLE BRANCH
CIRCUIT SERVICE
2 LEADS +
1 GROUND
NOMINAL CIRCUIT LOAD-AMPS 94.0
WIRE SIZE (75 C) COPPER #1
WIRE SIZE (60 C) COPPER #0
MAX. FUSE SIZE
(OR CB) - AMPS 120
DUAL BRANCH
CIRCUIT SERVICE
4 LEADS +
2 GROUNDS
CKT #1-CKT #2
BRANCH CKT. LOAD-AMPS 47.3 46.7
BRANCH CKT. MIN. AMPACITY 59.2 58.4
WIRE SIZE (75 C) COPPER #6 #6
WIRE SIZE (60 C) COPPER #4 #4
MAX. FUSE SIZE
(OR CB) - AMPS
60 60

Subject to change without notice. Published in U.S.A. 5165699-BIM-C-0516
Copyright © 2016 by Johnson Controls, Inc. All rights reserved. Supersedes: 5165699-BIM-B-0316
York International Corp.
5005 York Drive
Norman, OK 73069
NOTES
