Junt Smart Control 8 Operator's manual

Product documentation
Smart Control 8
Art. no.: SC 0081 U
ALBRECHT JUNG GMBH & CO. KG
Volmestraße 1
58579 Schalksmühle
GERMANY
Tel. [phone]
Fax [phone]
[email protected]
www.jung.de
08/2021

Page 2 of 16SC 0081 U
Table of contents
Table of contents
1 Safety instructions and device components .................................................3
1.1 Safety instructions....................................................................................................... 3
1.2 Device components ..................................................................................................... 3
2 Function ............................................................................................................3
2.1 Intended use................................................................................................................. 3
2.2 Product characteristics ............................................................................................... 4
2.3 Included in delivery ..................................................................................................... 4
3 Mounting and electrical connection ...............................................................4
3.1 Information for electrically skilled persons............................................................... 4
3.2 Mounting in installation box or appliance box.......................................................... 4
3.3 Mounting the adapter .................................................................................................. 5
3.4 Connection ................................................................................................................... 6
3.5 Mounting of Smart Control ......................................................................................... 7
4 Commissioning ................................................................................................7
4.1 Switching on................................................................................................................. 7
4.2 Settings – Overview of the menu structure............................................................... 7
4.3 Opening the settings ................................................................................................... 8
4.4 Selecting the language................................................................................................ 8
4.5 Selecting date and time............................................................................................... 8
4.6 Changing the system password................................................................................. 8
4.7 Updatingthermware ................................................................................................. 8
5 Operation ..........................................................................................................9
5.1 Operating elements ..................................................................................................... 9
5.2 Control elements........................................................................................................10
5.3 Device settings........................................................................................................... 11
5.4 Operation using apps in the main menu .................................................................12
5.5 Apps for building automation...................................................................................12
5.6 Create app link in the main menu.............................................................................13
5.7 App “System Update“ ...............................................................................................14
5.7.1 Restoring default settings ............................................................................................................14
5.7.2 Updatingthermwarewithoutinternetconnection......................................................................15
6 Cleaning ..........................................................................................................16
7 Technical data.................................................................................................16
8 Accessories ....................................................................................................16
9 Warranty ..........................................................................................................16

Page 3 of 16SC 0081 U
Safety instructions and device components
1 Safety instructions and device components
1.1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled persons.
Seriousinjuries,reorpropertydamagepossible.Pleasereadandfollowmanualfully.
Danger of electric shock. During installation and cable routing, comply with the regulations and
standards which apply for SELV circuits.
These instructions are an integral part of the product and must remain with the end customer.
1.2 Device components
Fig. 1: Device components
1 Installation box
2 Adapter
3 Smart Control
2 Function
2.1 Intended use
- Visualising and operating system statuses and information on building automation
- Mounting horizontally (recommended) or vertically
- Mountinginaush-mountedinstallationbox(ref.-no.EBG24orSC7EBG)oronapplianceboxaccording
to EN 60670-1 (recommendation: at a depth of approx. 60 mm)
123

Page 4 of 16SC 0081 U
Mounting and electrical connection
2.2 Product characteristics
- High-resolution HD display
- Proximity sensor
- Capacitive touch screen
- Cleaning mode with touch screen lock
- Fanless, without mechanical moving parts
- KNX visualisation in combination with Visu Pro Server
(ref.-no.: JVP-SERVER-H2, JVP-SENEC-H2)
- KNX visualisation in combination with Smart Visu Server
(ref.-no.: SV-SERVER)
- eNet visualisation in combination with eNet server for rail mounting
(ref.-no.: ENET-SERVER) from software version 2.2
- Door intercom function only in combination with Siedle Smart Gateway SG 650-.. or SG 150-..
- Display of up to six IP camera images
- Image memory integrated in Smart Gateway
2.3 Included in delivery
- Smart Control 8
- Smart Control Adapter for wall installation
- Operating instructions
3 Mounting and electrical connection
3.1 Information for electrically skilled persons
DANGER
Electrical shock on contact with live parts in the installation environment.
Electrical shocks can be fatal.
Before working on the device, disconnect the power and cover live parts in the area!
3.2 Mounting in installation box or appliance box
TheSmartControlisdesignedformountinginaush-mountedinstallationbox(ref.no.EBG24or
SC7EBG).TheSmartControladapterisscrewedontotheinstallationbox.
Installation boxes from other manufacturers must match the overall dimensions and holes of the adapter and
the Smart Control. (See technical data for overall dimensions)
Theinstallationboxmustbepreciselyalignedandmountedushinthewall.
Alternatively, an appliance box according to EN 60670-1 can be used for mounting the Smart Control. The
Smart Control adapter is not mounted directly on the appliance box, but on the wall.
The recommended depth of the appliance box is approx. 60 mm.

Page 5 of 16SC 0081 U
Mounting and electrical connection
3.3 Mounting the adapter
83
58
Fig. 2: Mounting the adapter
1 Adapter locking screw
2 Fixing hooks
• Mounttheadapterontheinstallationboxwithatotaloffourlockingscrews(1).(g.2)
When mounting on an appliance box, the adapter must be mounted on the wall. The adapter must be
placed in such a way that the appliance box is located in the indentation of the adapter. The appliance box
isthusnotlocatedverticallyinthecentreoftheadapter,butwithadownwardo󰀨set.
1
2
2
1
1
1
2
2

Page 6 of 16SC 0081 U
Mounting and electrical connection
3.4 Connection
Fig. 3: Connection
3 Power supply 5 LAN/Ethernet
4USB2.0typeA 6Mini-USBOTG
Requirements:
- Ethernet connection (LAN)
- Power supply via power supply adapter, ref. no.: NT 2415 REG VDC
• Connectthepowersupply(3)andLAN(5).(g.3)
4
6
3
5

Page 7 of 16SC 0081 U
Commissioning
3.5 Mounting of Smart Control
Fig. 4: Mounting of Smart Control
8 Openings for wall mounting
9 Smart Control locking screws
• Placetheopeningsforwallmounting(8)ontheSmartControlonthexinghooks(2)ontheadapter.
(g.2andg.4)
To do this, place the openings for wall mounting above the hooks and engage them downwards.
• FastentheSmartControltotheadapterontheundersidewithatotaloftwolockingscrews(9).(g.4)
4 Commissioning
4.1 Switching on
After connecting, the device is switched on automatically and the operating system is started.
After the start-up process, you must make the settings for commissioning.
4.2 Settings – Overview of the menu structure
- General
- Language
- Date/time
- Design
- Display
- Advanced
- System password
9
8
8
9
8
8

Page 8 of 16SC 0081 U
Commissioning
4.3 Opening the settings
• Select the JUNG logo in the main menu (JUNG Launcher).
Password entry opens.
• Enter the system password.
The default system password is “0000“.
The settings open.
4.4 Selecting the language
• Open the settings.
• Select the menu “General”.
• Select the submenu “Language”.
Available languages are displayed.
• Select the language.
The language is selected.
4.5 Selecting date and time
• Open the settings.
• Select the menu “General”.
• Select the submenu “Date/time”.
• Make the settings:
- autom. date/time: activated
- autom. time zone: deactivated
- select the time zone (e.g. GMT+2)
- 24-hour format: activated
4.6 Changing the system password
iThe system password grants access to all settings. The user password grants only limited access to the
settings.
• Open the settings.
• Select the menu “Advanced”.
• Select the “System password” submenu.
Password entry opens.
• Enter the current and new system password.
• Conrmpasswordswiththe“OK”button.
The system password is changed.
4.7 Updatingthermware
Prerequisite: Internet connection
• Select the app “System update”.
The app is started.
• Select “Search for updates online”.
Thermwareisupdatedautomatically.
iIfthereisnoInternetconnection,aUSBstoragemediumcanbeusedtoupdatethermware.

Page 9 of 16SC 0081 U
Operation
5 Operation
5.1 Operating elements
Fig. 5: Operation
Name Function
1 Proximity and brightness
sensor
For the automatic switch-on of the display and automatic
adjustment of the display brightness
2 Loudspeaker To play signal tones
3 Microphones To record speech
4 HOME button To return to the main menu (JUNG Launcher) and switch the
deviceo󰀨/on
Display main menu
• PresstheHOMEbuttonbriey1x.
The main menu (JUNG Launcher) is displayed.
Switchdeviceo󰀨/on
• KeeptheHOMEButtonpressedfor5seconds.
Theoperatingsystemispowereddownandthedeviceswitchedo󰀨.
• PresstheHOMEbuttonbriey1x.
The device is switched on and the operating system launches.
3
1
22
43

Page 10 of 16SC 0081 U
Operation
5.2 Control elements
Controlelementsareavailablefortheoperationandcongurationofthedevice.
The control elements are not displayed in all the menu areas and apps and can be hidden as necessary.
Fig. 6: Control elements
Name Function
A Status bar Display of the time
Display of status messages of launched apps
BNavigation bar Contains basic control elements
1O󰀨/Restart Torestartorswitcho󰀨thedevice
2 Quieter To reduce the volume
3Back Goes back to the previous menu
4 Main menu Goes directly to the main menu (JUNG Launcher)
5 App overview Opens an overview of all launched apps
6 Louder To increase the volume
7 Context menu Opens the context menu
Opening the status bar
• Perform a swipe movement from the top edge of the touch screen to the centre
Status bar opens.
B
A
12 3 5 6 74

Page 11 of 16SC 0081 U
Operation
5.3 Device settings
Besidesthesettingsforcommissioningthedevice,additionaldevicesettingscanbeperformed.The
device settings can be opened in the main menu using the JUNG Launcher (see “Open settings” in the
Commissioning chapter at page 8).
Overview of the menu structure
- General
- Language
- Date/time
- Network and connectivity
- Shownavigationnotication
- Show navigation bar
- Show virtual power button
- Design
- Orientation
- Theme
- Background
- Dashboard
- App area
- Display
- Display settings
- Display power management
- Display wake-up sensor settings
- Adaptive brightness
- Lockscreen
- Advanced
- System password
- User password
- Welcome message
- Autostart
- Automatic reboot
- App starter
- Cache cleaner
- App guard
- App terminator
- Support access
- Cong-Toolaccess
- App management
- Volume control
- Memory
- Account management

Page 12 of 16SC 0081 U
Operation
5.4 Operation using apps in the main menu
The device is operated via pre-installed apps.
The apps must be started via the main menu.
Fig. 7: Main menu (JUNG Launcher)
5.5 Apps for building automation
Software applications for building automation are already pre-installed on the device as apps.
Depending on the system used, only certain apps can be used.
The apps are used to visualise system states and to control individual components.
Pre-installed apps on the Smart Control 8:
- JUNG Visu Pro
- JUNG Smart Visu Server
- Door communication
- eNet Smart Home
These apps are just working with additional hardware and software.
Formoreinformationaboutappsseetheproductdocumentationofthespecicdevice.Theproduct
documentation can be downloaded from our website.
iThe device is supplied with all the apps required to control the building automation. No apps from
other third parties should be installed. JUNG cannot guarantee that external apps will function on the
device under all circumstances. A third-party app which does not function does represent grounds for a
complaint.

Page 13 of 16SC 0081 U
Operation
5.6 Create app link in the main menu
Fig. 8: Create app link in the main menu
• Touch an area/tile in the main menu for a long period of time.
The app list is displayed.
• Select an app.
A query regarding the icon and name opens.
• Change or keep the icon and name.
• Conrmthesettingsusingthe“Assign”button.
The app link is displayed in the main menu.

Page 14 of 16SC 0081 U
Operation
5.7 App “System Update“
5.7.1 Restoring default settings
Fig. 9: System Update – Restore default settings
• Select app “System Update“ in the main menu.
App starts.
• Select “Reset device to factory settings“.
Request about restoring the default settings opens.
• Conrmrestoringwithbutton“OK“.
Default settings are restored.

Page 15 of 16SC 0081 U
Operation
5.7.2 Updatingthermwarewithoutinternetconnection
Fig. 10: SystemUpdate–Updatermwarewithoutinternetconnection
iCheckrmwareversionin“Settings”menu.
Requirements:
- USBdatastoragewithFAT32lesystem
- DatalesforupdateonUSBdatastoragedevice
- USBdatastoragedeviceinUSBconnection
• Select app “System Update“ in the main menu.
App starts.
• Select“BrowseUSBOTG“or“BrowseUSBdisk“(A).
Datalesareshown.
• Selectupdateleinzipformat.
Pathtotheupdateleisapplied(B).
• Select“Updateusingthespecied‘update.zip‘le“(C).
Firmware is updating.
B
C
A

Page 16 of 16SC 0081 U
Cleaning
6 Cleaning
iThe cleaning mode is started with the “Screencleaner” app.
Suitable cleaning agents:
Water, degreaser, glass cleaner, alcohol and isopropyl alcohol
Not suitable for cleaning:
Abrasive cloths or harsh detergents
• Startthecleaningmodeorswitcho󰀨thedevicetolockthetouchscreen.
• Apply cleaning agent or water to a cloth.
Do not apply directly to the device.
• Clean the front with a cloth.
Cleaning agent must not get into the device.
• Switch the device on again after cleaning or wait for the cleaning mode to end automatically after
30 seconds.
7 Technical data
Screen diagonal 203 mm / 8“
Resolution 1280 x 800 (WXGA)
Aspect ratio 16:10
Overall dimensions
(W x H)
Smart Control
Adapter
225 x 145 mm
216 x 141 mm
Structure height 16 mm
Installation depth 22 mm
Power consumption max. 16 W
Power supply DC 12 ... 32 V SELV
via external power adapter
Operating system Android 6
Processor Cortex-A53
Main memory 2GB
Mass storage 16GBFlash
USB connection 1xUSB2.0typeA
1xMini-USBOTG
LAN connection 1 x 10/100/1000 Mbit/s
Ambient temperature 0 ... +30 °C
Atmospheric humidity 5 ... 80 %
(no moisture condensation)
8 Accessories
Power supply adapter NT 2415 REG VDC
Installation box EBG24
SC7EBG
9 Warranty
The warranty follows about the specialty store in between the legal framework as provided for by law.
