JVC XM-G6 User manual

For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT0378-002A
[B]
INSTRUCTIONS
XM-G6
MINIDISC RECORDER
REC
REC PAUSE
SAMPLING RATE CONVERTER
MINIDISC RECORDER XM-G6
XM_cover[B] 99.11.22, 11:081

CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
G-1
Warnings, Cautions and Others
Front view Side view
1 cm
15 cm
15 cm 15 cm
10 cm
1 cm 15 cm 15 cm
AX-UXG6
TD-UXG6
XT-UXG6R
XM-G6
AX-UXG6
TD-UXG6
XT-UXG6R
XM-G6
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage,
locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No obstructions should be placed in the areas shown by the
dimensions below.
3 Bottom:
Place on the level surface. Maintain an adequate air path for
ventilation by placing on a stand with a height of 10 cm or
more.
XM_safety[B] 99.11.26, 13:351

MPORTANT FOR LASER PRODUCTS
2WARNING LABEL, PLACED INSIDE THE UNIT
REPRODUCTION OF LABELS
1CLASSIFICATION LABEL, PLACED ON REAR
ENCLOSURE
CLASS 1
LASER PRODUCT
1. CLASS 1 LASER PRODUCT
2. DANGER: Invisible laser radiation when open and interlock failed or defeated.Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user serviceable parts inside the Unit; leave all servicing to qualified
service personnel.
G-2
DANGER: Invisible laser
radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE
TO BEAM. (e)
ADVARSEL: Usynlig laser-
stråling ved åbning, når
sikkerhedsafbrydere er ude
af funktion. Undgå udsæt-
telse for stråling (d)
VARNING: Osynlig laser-
strålning när denna del är
öppnad och spärren är
urkopplad. Betrakta ej
strålen. (s)
VARO: Avattaessa ja suo-
jalukitus ohitettaessa olet
alttiina näkymättömälle
lasersäteilylle. Älä katso
säteeseen. (f)
XM_safety[B] 99.11.26, 13:352

1
Precautions
Installation
• Install in a place which is level, dry and neither too hot
nor too cold — between 5˚C (41˚F) and 35˚C (95˚F).
• Install the unit in a location with adequate ventilation to
prevent internal heat built-up in the units.
• Leave sufficient distance between the unit and a TV.
DO NOT install the units in a location near heat
sources, or in a place subject to direct sunlight,
excessive dust or vibration.
Power sources
• The power source of this unit is controlled by UX-G6R’s
system operation. Refer to its Instructions.
• When connecting the unit to the UX-G6R, make sure to
unplug theAC power cord of the UX-G6R from the wall
outlet.
Moisture condensation
Moisture may condense inside the unit in the following
cases:
• After starting heating in the room
• In a damp room
• If the unit is brought directly from a cold to a warm place
Should this occur, the system may malfunction. In this case,
leave the unit turned on for a few hours until the moisture
evaporates, unplug the AC power cord, and then plug it in
again.
DO NOT disassemble the unit since there are
no user serviceable parts inside.
If anything goes wrong, unplug the AC power cord and
consult your dealer.
Welcome to XM-G6
XM-G6is MiniDiscRecorder exclusivelydesigned forUX-
G6Rmicro componentsystem.Althoughyou cannotoperate
this MD recorder without UX-G6R, this integration offers
enhanced features to simple and easy operations
systematized on UX-G6R.
Since the basic settings and common operations are almost
identical to those of UX-G6R, this manual mainly explains
MD related operations. Concerning UX-G6R’s settings and
operations, refer to its Instructions for details.
• The following marks are used in this manual:
Gives you warnings and cautions to prevent
from a damage or risk of fire/electric shock.
Alsogives youinformation whichis not good
for obtaining the best possible performance
from the unit.
Gives you information and hints you had
better know.
We would like to thank you for purchasing one of our JVC products.
Before operating this unit, read this manual carefully and thoroughly
to obtain the best possible performance from your unit,
and retain this manual for future reference.
Introduction
EN01-10.XM-G6[B]/F 99.12.06, 14:401

2
Introduction .......................................................... 1
Welcome to XM-G6 ............................................................. 1
Precautions ........................................................................... 1
Contents................................................................. 2
Location of the Buttons and Controls................. 3
Front Panels .......................................................................... 4
Remote Control (belongs to UX-G6R) ................................ 4
Getting Started...................................................... 5
Unpacking ............................................................................ 5
Connecting the System Control Cable and the External
Wire .................................................................................. 5
Connecting Another Digital Audio Equipment .................... 6
Playing Back an MD............................................. 7
Playing Back the Entire MD — Normal Play ...................... 7
Searching and Skipping Tracks ............................................ 8
Programing the Playing Order of the Tracks
— Program Play ............................................................... 9
Playing at Random — Random Play.................................. 10
Repeating Tracks — Repeat Play ....................................... 10
Recording onto an MD ....................................... 11
Things to Know Before You Start Recording .................... 11
Recording FM/AM (MW/LW) Broadcasts ........................ 12
Recording a CD .................................................................. 14
Recording a Tape ................................................................ 15
Recording onto a Tape ........................................................ 16
Recording the External Equipment .................................... 17
Editing an MD..................................................... 19
Introducing MD Editing Functions .................................... 19
DIVIDE Function ............................................................... 20
JOIN Function .................................................................... 21
MOVE Function ................................................................. 22
ERASE Function ................................................................ 22
ALL ERASE Function ....................................................... 23
Erasing a Portion of a Track ............................................... 23
Assigning Titles to an MD.................................. 24
Assigning a Title................................................................. 24
Changing the Title .............................................................. 26
Contents
Handling MDs ..................................................... 27
MD Handling Precautions .................................................. 27
Additional Information ...................................... 28
MD Disc Types ................................................................... 28
ATRAC (Adaptive TRansformAcoustic Coding).............. 28
UTOC (User Table Of Contents)........................................ 28
Serial Copy Management System (SCMS) ........................ 29
Sound Skip Guard Memory................................................ 29
MD Messages ..................................................................... 30
MD Restrictions ................................................................. 31
Troubleshooting .................................................. 32
Specifications....................................................... 32
EN01-10.XM-G6[B]/F 99.12.06, 14:402

3
REC PAUSE
SAMPLING RATE CONVERTER
1
4
5
6
7
2
3
REC
Location of the Buttons and Controls
XM-G6 MiniDisc Recorder
Buttons behind the Sliding Panel
Become familiar with the buttons and controls on the unit.
DISPLAY
/CHARA. PLAY MODE REC MODE TITLE /EDIT CLOCK /TIMERCANCEL ENTER
SET
8
9pqwer t y
MOS - FET
STANDBY/ON
FM/AM AUX
OPEN/CLOSE
VOLUME
MICRO COMPONENT SYSTEM UX-G6R
4¢
AX-UXG6 Stereo Amplifier (belongs to UX-G6R)
MICRO COMPONENT SYSTEM UX-G6R
MOS - FET
OPEN/CLOSE
AUX
VOLUMEMULTI
FM/AM
STANDBY/ON
JOG
14
5
2
3
6
7
(When pressing OPEN/CLOSE button 4)
EN01-10.XM-G6[B]/F 99.12.06, 14:403

4
• You can also use the buttons on the remote control if they
have the same or similar names (or marks) as those on
the units.
If operation using the remote control is different from
that using each unit, it is then explained.
Concerning with the remote control
Refer to the Instructions supplied with UX-G6R.
Remote Control (belongs to UX-G6R)Front Panels
MiniDisc Recorder XM-G6
1MD IN lamp (7)
2MD loading slot (7)
3REC PAUSE button (12)
4REC indicator (12)
50(eject) button (8)
66(play/pause) button (8)
77(stop) button (8)
Stereo Amplifier AX-UXG6
1button and STANDBY/ON lamp
2MULTI JOG dial
3FM/AM button (12)
4OPEN/CLOSE button (7)
5Display window
6VOLUME dial
7AUX button (17)
Buttons behind the Sliding Panel
8DISPLAY/CHARA. button (13, 25)
94button (8, 9, 25)
p¢button (8, 9, 25)
qSET button (9, 13, 20, 25)
wCANCEL button (9, 21, 25)
eENTER button (21, 25)
rPLAY MODE button (9)
tREC MODE button (13)
yTITLE/EDIT button (20, 24)
* MD related operations are mainly assigned to
the hollow buttons as illustrated bellow.
ACTIVE
BASS EX.
VOLUME
MD
ENTERPTY/EON
AUTOPRESET PLAY MODE
FM MODE
CANCEL
DISPLAY
/CHARA.
BASS
SLEEP
PANEL
OPEN/CLOSE
REMOTE CONTROL RM-SUXG6R
TAPE
FM/AM
DOWN
UP
AUX
TITTLE/EDIT
REPEAT
TREBLE
DIMMER
CLOCK/TIMER
CD


><
SET
EN01-10.XM-G6[B]/F 99.12.06, 14:404

5
When connecting the XM-G6 MD recorder
Make sure to turn off UX-G6R and unplug the AC
power cord. Leave it until all the connections
complete.
DO NOT place XM-G6 unit or any other
equipment onto AX-UXG6 stereo amplifier unit.
Damage or malfunction may result from heat
generating portion of AX-UXG6.
1 Turn off UX-G6R system and unplug theAC power
cord from the wall outlet.
2 Place the UX-G6R’s units onto the XM-G6 unit.
Forexample asfollows, fromtop tobottom:AX-UXG6,
XT-UXG6R, TD-UXG6, finally XM-G6.
3 Using the system control cable-C, connect XM-G6
unit to XT-UXG6R unit.
When connecting the system control cable to the
connecter
Make sure to connect the cable to the terminal having
the same name as “FROM CONNECTOR-C” and
“TO CONNECTOR-C. ”
• To connect the system control cable, press the middle
of the connector body until it clicks into the terminal
on the rear panel.
• To disconnect, pull the connector out pushing both
sides of the connector body. Never pull out the cables
themselves.
4 Using the Optical digital cable, connect between
XM-G6 unit and XT-UXG6R unit.
Now you have finished installation of XM-G6 unit to
UX-G6R system.
Getting Started
Unpacking
After unpacking, check to be sure that you have the
following items.
• Optical digital cable (1)
• External wire (1)
The number in the parentheses indicates the quantity of the
pieces supplied. If any is missing, consult your dealer
immediately.
Connecting the System Control Cable and
the External Wire
Since XM-G6 Mini Disc Recorder is exclusively designed
for UX-G6R micro component system, you can easily
connect this unit using the system control cable and
connector equipped on the rear panel of each unit as
illustrated.
• To prevent malfunction, connect the external wire as
illustrated.
To connect To disconnect
Optical digital cable (supplied)
Protective Plug
Before connecting the unit, remove
the protective plug from the terminal.
FROM CONNECTOR-C
TO CONNECTOR-C
DIGITAL OUT
AUX
XT-UXG6R System control cable-C
External wire (supplied)
XT-UXG6R
AX-UXG6
XM-G6
EN01-10.XM-G6[B]/F 99.12.06, 14:405

6
ConnectingAnotherDigitalAudioEquipment
For digital audio recording onto an MD, XM-G6 unit
connected to UX-G6R system has one more optical digital
terminal (OPTICAL DIGITAL IN for AUX), prepared for
an external digital audio output equipment.
When connecting another digital equipment
Make sure to turn off UX-G6R system with XM-G6
unit and unplug theAC power cord. Leave it until all
the connection completes.
DO NOT place an external equipment onto (or
under) UX-G6R system and XM-G6 unit.
Damage or malfunction may result from heat
generating portion of units.
1 Turn off UX-G6R system and unplug theAC power
cord from the wall outlet.
2 UsingtheOpticaldigitalcable (notsupplied),connect
between XT-UXG6R unit and another digital
equipment.
Now you have finished installation to UX-G6R system.
XT-UXG6R DIGITAL OUT
for XM-G6
DIGITAL IN
for XT-UXG6R
DIGITAL IN
for AUX
Protective Plug
Before connecting the other equipment,
remove the protective plug from the terminal.
XM-G6
EN01-10.XM-G6[B]/F 99.12.06, 14:406

7
• Make sure to insert an MD in the direction of arrow
mark on the MD cartridge.
If you cannot insert an MD
You have inserted an MD incorrectly and taken it off
by force.
MD loading slot rejects MD insertion. If this occurs,
wait for one minute at most with the MD recorder
turned on until a mechanical sound comes out of the
MD mechanism.
The following information appears in the display
window of UX-G6R as follows:
Total track number
Total playback time
Playing Back an MD
MICRO COMPONENT SYSTEM UX-G6R
MOS - FET
OPEN/CLOSE
AUX
VOLUMEMULTI
FM/AM
STANDBY/ON
JOG
MULTI JOG
OPEN/CLOSE
Play mode indicators
VOLUME
MD
ENTERPTY/EON
AUTOPRESET PLAY MODE
FM MODE
CANCEL
DISPLAY
/CHARA.
BASS
SLEEP
PANEL
OPEN/CLOSE
REMOTE CONTROL RM-SUXG6R
TAPE
FM/AM
SET
AUX
TITTLE/EDIT
REPEAT
TREBLE
DIMMER
CLOCK/TIMER
CD

ACTIVE
BASS EX.

UP/DOWN
PLAY MODE
REPEAT
UP
DOWN
SET
CANCEL
MD 6
(play/pause)
4/ ¢
7(stop)
><
</ >
REC
REC PAUSE
SAMPLING RATE CONVERTER
MD IN lamp
MD loading slot
0(eject)
6(play/pause) 7(stop)
You can use Normal, Program, Random, or Repeat Play.
• When using the buttons behind the sliding panel, press
OPEN/CLOSE button on AX-UXG6 unit to open the
sliding panel first.
• When using the remote control, press MD 6(play/
pause) button first and 7(stop) button successively.
Playing Back the Entire MD — Normal Play
1 Insert an MD into the MD loading slot.
The MD is pulled in automatically to light on the MD
IN lamp orange.
DISPLAY
/CHARA. PLAY MODE REC MODE TITLE /EDIT CLOCK /TIMERCANCEL ENTER
SET
4¢
SETCANCELPLAY MODE
DISPLAY
/CHARA.
4¢
EN01-10.XM-G6[B]/F 99.12.06, 14:407

8
If the MD or each track has a title
The disc title and track titles will be shown at the
lowerportion of the display window (Titlelongerthan
11 characters scrolls to show the entire title).
• DO NOT insert any foreign matters.
2 Press 6(play/pause) button on the MD recorder
or MD 6(play/pause) button on the remote
control.
Each track of the MD starts playing back, and playback
information appears in the display window as follows:
Current track number
Elapsed playing time
•To stop playing back for a moment, press 6
(play/pause) button on the MD recorder.
The playback time starts blinking in the display
window.
•To resume playback, press 6(play/pause)
button again.
Playback continues from the point where it was
stopped for a while.
3 Press 7(stop) button to stop playing back the MD.
4 Press0(eject)button onthe MDrecordertoremove
the MD.
• Pressing 0(eject) button during playback directly,
the MD recorder stops playback and ejects the MD.
«
Searching and Skipping Tracks
While playing back an MD, you can do the following
operations.
To search and skip to a particular point in a track
During playback, press and hold 4/ ¢button to meet
the desired passages in a track:
Press and hold ¢button:
Fast forwards in the track.
Press and hold 4button:
Fast reverses in the track.
UP/DOWN button on the remote control is also
available to search and skip operations.
To go to another track
Before or during playback, press 4/ ¢button
repeatedly:
Press ¢button:
Skips to the beginning of the next and succeeding
tracks.
Press 4button:
Goes back to the beginning of the current and
previous tracks.
Rotating MULTI JOG dial clockwise also changes
the tracks forwards quickly, while rotating it
counterclockwise the tracks reverse quickly (< / >
button on the remote control also available).
Continued
EN01-10.XM-G6[B]/F 99.12.06, 14:408

9
• If you try to program a 33rd step
“MEMORY FULL” will appear in the display
window, and your entry is ignored.
• The total playback time of programed tracks
exceeds 99’59”
“– – : – –” will appear in the display window.
6 Press 6(play/pause) button on the MD recorder.
The programed tracks are played back in the order you
have set.
7 Press 7(stop) button to quit Program play.
• When Program play finished, MD recorder auto-
matically stops.
To check the program contents
Before playing back the MD, you can check the program
contents by using 4/ ¢button.
Press ¢button:
Shows the programed tracks in the programed
order.
Press 4button:
Shows them in the reverse order.
To modify the program
Before playing back the MD, you can erase the last
programed track by pressing CANCEL button. Each time
you press the button, the last programed track is erased from
the end of program.
•To add new tracks to the program before you start
playing-back, simply select a track number again you
want to add (repeat steps 3 to 4).
To erase all the programed data
After playing back the MD, you can erase all the programed
track data by pressing 7(stop) button. New program can
be entered again.
To exit from Program play mode
Before or during playback, you can exit from Program play
mode as follows:
• Before playback, press PLAY MODE button twice.
• Duringplayback, press7(stop) buttonthenPLAYMODE
button twice.
Playback mode indicator goes off and the system resumes
Normal play mode.
Pressing 00
00
0(eject)buttontoejecttheMDalso quits
Program play mode.
Continued
PROGRAM
Canceled
(Normal play)
RANDOM
Programing the Playing Order of the Tracks
— Program Play
You can arrange the order in which the tracks play before
you start playing. You can program up to 32 tracks.
1 Insert an MD.
• If the current playing source is not the MD, press
6(play/pause) button on the MD recorder, then
7(stop) button before going to the next step.
2 Press PLAY MODE button repeatedly until “MD
PROGRAM” appears in the display window.
• Each time you press the button, playback mode
indicators also change as follows:
3 Rotate MULTI JOG dial to select a track number to
be programed (< / > button also available).
Track number
Program number
4 Press SET button to enter selected track number to
be program-played.
Track number
Program number
Here the track number 2 of the MD is stored into a
program number 1, and shortly after that the total
playbacktime ofprogramed tracksappearsin thedisplay
window as follows:
Total playback time
5 Repeat steps 3 to 4 to program other tracks you
want up to 32 tracks.
EN01-10.XM-G6[B]/F 99.12.06, 14:409

10
Repeating Tracks — Repeat Play
You can have the entire disc, the programed tracks, or the
individual track repeat as many times as you like.
1 Insert an MD.
If the current playing source is not the MD, press 6
(play/pause) button on the MD recorder, then 7(stop)
button before going to the next step.
2 Press REPEAT button on the remote control
repeatedly to set the repeat play mode.
• Eachtime youpress thebutton, repeatmode indicators
lightin thedisplay window, andrepeat playbackmode
changes as follows:
: Repeats one track on the MD or in a
program.
: Repeats all the tracks on the MD or a
program.
3 Press 7(stop) button to quit Repeat play.
To exit from Repeat play mode
Pressing REPEAT button repeatedly until repeat mode
indicators( and ) goesoff inthe displaywindow.
Combining play modes:
• When combining Program play and Repeat play,
you can repeat whole the programed tracks or
one track among them ( and ).
• When combining Random play and Repeat play,
you can just repeat whole the shuffled tracks
(only ).
Playing at Random — Random Play
The tracks of the loaded MD will play in no special order
(at random) when you select this mode.
1 Insert an MD.
If the current playing source is not the MD, press 6
(play/pause) button on the MD recorder, then 7(stop)
button before going to the next step.
2 Press PLAY MODE button repeatedly until “MD
RANDOM” appears in the display window.
• Each time you press the button, playback mode
indicator also changes as follows:
3 Press 6(play/pause) button on the MD recorder.
The track numbers are shuffled in the display window
for a few seconds, and start playing back at random.
Random play ends when all the tracks are played back
once.
• Other MD operations are the same as Normal play.
4 Press 7(stop) button to quit Random play.
To exit from Random play mode
During playing back the MD, you can exit from Random
play mode as follows:
• Before playback, press PLAY MODE button once.
• During playback, press 7(stop) button then press PLAY
MODE button once.
Play mode indicator goes off and the system resumes
Normal play mode.
Pressing 00
00
0(eject)buttonto eject the MD also quits
Random play mode.
Canceled
(
Normal pla
y)
PROGRAM
Canceled
(Normal play)
RANDOM
EN01-10.XM-G6[B]/F 99.12.06, 14:4010

11
Things to Know Before You Start Recording
• It should be noted that it may be unlawful to pre-recorded tapes, records, or discs without the consent of
the owner of copy right in the sound or video recording,broadcast or cable program and in any literary,
dramatic, or artistic embodied therein.
• The sampling frequency rate converter built in the MD recorder allows you to record a digital source if its
sampling frequency is 32 kHz, 44.1 kHz, or 48 kHz. If no source equipment is connected to theAUX terminal
or if the sampling frequency of the connected equipment is not 32 kHz, 44.1 kHz, or 48 kHz, “DIGITAL
UNLOCK” appears in the display window (no recording is possible).
• When you record onto partially recorded MD, its contents are not erased or overwritten. The recording starts
from the point following the last recorded track of the MD.
If you want to record on such an MD from the beginning, you have to erase its contents first (see “ALL ERASE
Function” on page 23).
• The recording level is automatically set correctly, so it is not affected by the VOLUME dial. Thus, during
recording you can adjust the sound you are actually listening to without affecting the recording level.
Recording/Editing
possible Disc protected:
Recording/Editing
not possible
An erasure protect tab
closed open
Recording onto an MD
To avoid erasing important recordings
Recordable MDs have an erasure protect tab so that
importantrecordings are notaccidentally erased. Whenyou
finish recording or editing, slide open the erasure protect
tab on the cartridge side surface. New recording or editing
is now no longer possible.
To do re-recording or editing, return the tab to the closed
position.
About the track marks
When playing an MD, you can move among the tracks
using MULTI JOG dial or </ >button quickly, and
4/ ¢or UP/DOWN button step by step.
You can do this because there is a mark recorded at
the beginning of each track enabling you to locate the
track. This mark is called a “track mark” and the
portion between two adjacent track marks is called a
“track.”
•When recording from a digital source such as a
CD player, a track mark is recorded automatically
at the beginning of each track.
•When recording from an analog source such as
FM/AM broadcasts, no track mark is recorded on
the MD. This means that, when playing this MD,
the MD recorder will regard the entire recording as
one track (track 1). You will not be able to select
directly a certain portion or navigate through them.
However, ifthere isa blankofthree secondsor more,
theMD recorderwillconsider itas ablankseparating
2 tracks and consequently put a track mark.
To put a track mark manually while recording an
analog source, press SET button where you want to
put a track mark.
To add a track mark after recording is over, you
can use the DIVIDE function (see page 20).
EN11-18.XM-G6[B]/F 99.12.06, 14:4111

12
2 Press FM/AM button.
3 Tune into a desired station using MULTI JOG dial
or 4/ ¢button.
Refer to UX-G6R’s Instructions for details (pages 14
– 15).
4 Press REC PAUSE button on the MD recorder.
The REC indicator on the MD recorder lights red.
Information in the display window changes as follows:
Remaining time for recording
VOLUME
MD
ENTERPTY/EON
AUTOPRESET PLAY MODE
FM MODE
CANCEL
DISPLAY
/CHARA.
BASS
SLEEP
PANEL
OPEN/CLOSE
REMOTE CONTROL RM-SUXG6R
><
TAPE FM/AM
SET
AUX
TITTLE/EDIT
REPEAT
TREBLE
DIMMER
CLOCK/TIMER
CD

ACTIVE
BASS EX.

FM/AM
TAPE `(playback)
AUX
UP
DOWN
SET
MD 6
(play/pause)
7(stop)
CD 6
(play/pause)
DISPLAY/CHARA.
CANCEL
REC
REC PAUSE
SAMPLING RATE CONVERTER
MD IN lamp
REC indicator
0(eject)
6(play/pause) 7(stop)
REC PAUSE
MD loading slot
MICRO COMPONENT SYSTEM UX-G6R
MOS - FET
OPEN/CLOSE
AUX
VOLUMEMULTI
FM/AM
STANDBY/ON
JOG
OPEN/CLOSE
FM/AM
AUX
DISPLAY
/CHARA. PLAY MODE REC MODE TITLE /EDIT CLOCK /TIMERCANCEL ENTER
SET
SET REC MODE
4¢
Continued
XM-G6 allows you to record a variety of audio sources onto
an MD using either manual recording or synchronized
recording.
• When using the buttons behind the sliding panel, press
OPEN/CLOSE button on AX-UXG6 to open the sliding
panel first.
• When using the remote control, press MD 6(play/
pause) button first and 7(stop) button successively.
Recording FM/AM (MW/LW)Broadcasts
1 Insert a recordable MD with the arrow sign facing
toward the MD loading slot.
The MD IN lamp lights orange and MD information
appears in the display window — total track number
and total playback time.
• If you insert a blank MD, “BLANK DISC” appears.
EN11-18.XM-G6[B]/F 99.12.06, 14:4112

13
5 Press 6(play/pause) button on the MD recorder
to start recording.
The REC indicator remains lit, and recording starts.
•To stop recording temporarily, press REC PAUSE
buttonor 6(play/pause)button on theMD recorder
or MD 6(play/pause) button on the remote control.
•To resume recording, press 6(play/pause) button
on the MD recorder or MD 6(play/pause) button
on the remote control again.
6 Press 7(stop) button to stop recording as required.
Information in the display window changes as follows:
You can remove the MD by pressing 0(eject) button.
Using DISPLAY/CHARA. button while recording
Each time you press the button, the display window
switches between the remaining time and the elapsed
time with the current track number alternately.
Recording FM broadcasts, RDS information also
appears(refer to the UX-G6R’s Instructions, page 16).
Monophonic Long Recording
Using the REC MODE settings, you can record FM/AM
broadcasts for twice as long as given recording time of the
MD in monaural reception.
1 Repeat the steps 1, 2 and 3 in previous page.
2 PressRECMODEbuttonto selecta recordingmode
as follows:
3 Press SET button to start recording.
You can double the recording time length, and
information appears in the display window as follows:
Remaining time for recording
•To stop recording temporarily, press REC PAUSE
buttonor 6(play/pause)button on theMD recorder
or MD 6(play/pause) button on the remote control.
•To resume recording, press 6(play/pause) button
on the MD recorder or MD 6(play/pause) button
on the remote control again.
Track marking in Long Recording
Putting track marks manually while recording, you
can easily identify and edit desired portions of the
broadcast program.
To put a track mark, press SET button as required
whilerecording and you can find out the current track
number using DISPLAY/CHARA. button.
4 Press 7(stop) button to stop recording as required.
“WRITING” appears in the display window, and you
can remove the MD by pressing 0(eject) button.
Continued
EN11-18.XM-G6[B]/F 99.12.06, 14:4113

14
Recording a CD — Synchronized Recording
Thisis theeasiestway ofCD recording.Settingthe recording
mode,you canstart playingback anentire CDand recording
it onto an MD simultaneously.
1 Repeat the steps 1 and 2 in previous section.
2 Press REC MODE button behind the sliding panel
to select “SYNC REC >MD.”
Each time you press the button, the recording mode
changes as follows:
3 Press SET button to start recording.
Recording starts automatically, and information change
in the display window as follows:
Each time you press DISPLAY/CHARA. button,
informationswitchesbetween the remaining time and
elapsedtime with the current track number alternately.
While synchronized recording
You cannot use pause function until the recording
finishes.
4 Press 7(stop) button (on either the CD player or
the MD recorder) to quit recording as required.
“WRITING” appears in the display window, and you
can remove the MD by pressing 0(eject) button.
• When all the tracks finished recording, CD player
and MD recorder will automatically stop.
To record a single track during playback
Press REC MODE button to set “SYNC REC>MD”
mode,youcanrecordacurrenttrackduringplayback.
The playback of the current track is stopped, and the
same track starts playing back from the beginning
again. At the same time, the MD recorder starts
recording the current track.
• When the current track is recorded, both CD player
and MD recorder automatically stop.
Recording a CD
Whenrecording a CDonto anMD, youcan recordthe entire
CD or the particular tracks manually and using the
synchronized recording.
Recording a CD Manually
You can start recording an entire CD or any tracks of a CD
while listening.
1 Insert a recordable MD into the MD loading slot.
The MD IN lamp lights orange.
2 Prepare a CD.
• Place a CD on the disc tray, press 6(play/pause)
button on the CD player or CD 6(play/pause) on
the remote control, then press 7(stop) button before
going to the next step.
• You can also record programed tracks if you want
(refer to UX-G6R’s Instructions, pages 21 to 22).
3 Press REC PAUSE button on the MD recorder.
The REC indicator on the MD recorder lights red.
4 Press 6(play/pause) button on the CD player or
CD 6(play/pause) button on the remote control.
Recordingstarts automatically, andinformation changes
in the display window as follows:
•To stop recording temporarily, press REC PAUSE
buttonor 6(play/pause)button on theMD recorder
or MD 6(play/pause) button on the remote control.
•To resume recording, press 6(play/pause) button
on the MD recorder or MD 6(play/pause) button
on the remote control again.
5 Press 7(stop) button to stop recording as required.
“WRITING” appears in the display window, and you
can remove the MD by pressing 0(eject) button.
Continued
Remaining time for recording
Remaining time of each track
CD Track number
SYNC REC
> MD
(
c anceled
)
SYNC REC
> TAPE
Remaining time for recording
Remaining time of each track
CD Track number
EN11-18.XM-G6[B]/F 99.12.06, 14:4114

15
•To stop recording temporarily, press REC PAUSE
buttonor 6(play/pause)button on theMD recorder
or MD 6(play/pause) button on the remote control.
•To resume recording, press 6(play/pause) button
on the MD recorder or MD 6(play/pause) button
on the remote control again.
Each time you press DISPLAY/CHARA. button,
information switches between the remaining time for
the recording and the elapsed time with the track
number of the MD alternately.
6 Press 7(stop) buttons both on the MD recorder and
the cassette deck to quit recording as required.
“WRITING” appears in the display window, and you
can remove the MD and the tape by pressing 0(eject)
buttons.
Using 77
77
7(stop) button on the remote control, you
cannot stop both the MD recorder and the
cassette deck. Make sure to press each button on
both units.
Recording a Tape — Sound Synchronized Recording
Setting the recording mode, you can start playing back a
tape and recording it onto an MD simultaneously.
1 Repeat the steps 1 and 2 in the previous section on
this page.
2 Press REC MODE button behind the sliding panel
to select a recording mode as follows:
3 Press SET button.
REC indicator on the MD recorder lights red, and
information appears in the display window as follows:
Recording a Tape
When recording from TD-UXG6 cassette deck, you can
select one of the two recording methods — Manual
Recording (stereo) and Sound Synchronized Recording.
•Manual Recording — Sound is recorded in stereo (both
on the left and right audio channels).You have to operate
the MD recorder and the cassette deck respectively.
•SoundSynchronized Recording— Withthis method,you
can start recording when the sound signals come into the
MD recorder (sound is recorded in stereo).
Sound Synchronized Recording will stop automatically
if no sound comes in for more than 30 seconds.
If Sound Synchronized Recording will not work
correctly
Use the Manual Recording. Sound Synchronized
Recordingstarts automatically when the MD recorder
detects sound signals come in. If sound signal is too
weak for this unit to detect, Sound Synchronized
Recording will not start (or will stop even while the
source is being played).
Recording a Tape Manually
1 Insert a recordable MD into the MD loading slot.
The MD IN lamp lights orange.
2 Prepare a tape playback.
• Place a tape on the tape tray, press `(playback)
button on the cassette deck or TAPE `(playback)
button on the remote control, then press 7(stop)
button before going to the next step.
3 Press REC PAUSE button on the MD recorder.
The REC indicator on the MD recorder lights red, and
the MD recorder switches to the recording-pause mode.
4 Press 6(play/pause) button on the MD recorder
or MD 6(play/pause) button on the remote
control.
The MD recorder starts recording, and information
changes in the display window and the remaining time
for recording appears as follows:
5 Press `(playback) button on the cassette deck or
TAPE `(playback) button on the remote control
in succession.
Continued
EN11-18.XM-G6[B]/F 99.12.06, 14:4115

16
4 Press `(playback) button on the cassette deck or
TAPE `(playback) button on the remote control.
Once the cassette deck starts playback, the MD recorder
detects the audio signals and starts recording.
Each time you press DISPLAY/CHARA. button,
information switches between the remaining time for
the MD and the elapsed time for the MD alternately.
• If no sound comes in for more than 30 seconds, Sound
Synchronized Recording will stop. “WRITING”
appears in the display window, and you can remove the
MD by pressing 0(eject) button.
Recording onto a Tape
You can record an MD onto a tape manually and using the
recording mode feature.
• For details on recording operation ofTD-UXG6 cassette
deck, refer to UX-G6R’s Instructions (pages 26 – 28).
Recording an MD onto a tape manually
1 InsertanMD tobe played-backinto theloading slot,
and load a recordable tape.
The MD IN lamp lights orange.
2 Press 6(play/pause) button on the MD recorder
or MD 6(play/pause) button on the remote
control, then press 7(stop) button immediately to
prepare playing back the MD.
3 Press REC PAUSE button on TD-UXG6 cassette
deck to prepare for recording.
4 Press 6(play/pause) button on the MD recorder
or MD 6(play/pause) button on the remote
control.
The cassette deck automatically starts recording, and
the information changes as follows:
Track number Elapsed playback time
5 Press 7(stop) button (on either the MD recorder or
the cassette deck) to quit recording as required.
• When all the tracks finished recording, MD recorder
and the cassette deck will automatically stop.
Continued
Synchronized recording an MD onto a tape
1 Insert anMD tobeplayed-backinto theloadingslot,
and load a recordable tape.
The MD IN lamp lights orange.
2 Press 6(play/pause) button on the MD recorder
or MD 6(play/pause) button on the remote
control, then press 7(stop) button immediately to
prepare playing back the MD.
3 Press REC MODE button behind the sliding panel
to select “SYNC REC>TAPE.”
4 Press SET button to start recording.
Recording the MD onto the tape starts, and information
appears in the display window as follows:
Track number Elapsed playback time
5 Press 7(stop) button (on either the MD recorder or
the cassette deck) to quit recording as required.
• When all the tracks finished recording, MD recorder
and the cassette deck will automatically stop.
EN11-18.XM-G6[B]/F 99.12.06, 14:4116

17
Recording the External Equipment
Whenrecording fromthe externalequipment, youcan select
one of the two recording methods — Manual Recording
and Sound Synchronized Recording.
•Manual Recording — Sound is recorded in stereo (both
on the left and right audio channels).You have to operate
the MD recorder and the external equipment respectively.
•SoundSynchronized Recording — Withthis method, you
can start recording when the sound signals come into the
MD recorder (sound is recorded in stereo).
Sound Synchronized Recording will stop automatically
if no sound comes in for more than 30 seconds.
If Sound Synchronized Recording will not work
correctly
Use the Manual Recording. Sound Synchronized
RecordingstartsautomaticallywhentheMDrecorder
detects sound signals come in. If sound signal is too
weak for this unit to detect, Sound Synchronized
Recording will not start (or will stop even while the
source is being played).
Recording the External Equipment Manually
First of all, make sure the proper cable connections between
XM-G6MD recorder andexternal equipment(see alsopage
6 in this manual, and refer to UX-G6R’s Instructions pages
9).
1 Insert a recordable MD.
The MD IN lamp lights orange.
2 Press AUX button to select either analog source or
digital source according to the external equipment.
Each time you press AUX button,AUX mode changes
between “AUX” and “AUX DIGITAL” alternately.
3 Press REC PAUSE button on the MD recorder.
The REC indicator on the MD recorder lights red, and
the MD recorder switches to the recording-pause mode.
4 Press 6(play/pause) button on the MD recorder
or MD 6(play/pause) button on the remote
control.
Selectedsource andremaining timefor recordingappear
in the display window as follows:
or
5 Make the external equipment start playback in
succession.
•To stop recording temporarily, press REC PAUSE
buttonor 6(play/pause)button on theMD recorder
or MD 6(play/pause) button on the remote control.
•To resume recording, press 6(play/pause) button
on the MD recorder or MD 6(play/pause) button
on the remote control again.
Each time you press DISPLAY/CHARA. button,
information switches between the remaining time for
the MD and the elapsed time for the MD alternately.
6 Press 7(stop) button on the MD recorder to stop
recording as required.
“WRITING” appears in the display window, and you
can remove the MD by pressing 0(eject) button.
AUX AUX DIGITAL
Continued
EN11-18.XM-G6[B]/F 99.12.06, 14:4117
