Küppersbusch IWT 1259 User manual

124973811
Instructions for Use
Gebruiksaanwijzing
Notice d’utilisation
Important: Read these instructions carefully and then store them in a safe place.
Belangrijk: Beslist lezen en bewaren.
Important: Lisez soigneusement cette notice et gardez-la.
Integrated Washer-Dryer
Integreerbare was- droogmachine
Lavante-séchante intégrable
Modell: IWT 1259
124973811.qxd 01/02/01 14.02 Pagina 1 (Nero/Process Black pellicola)

2
Dear customer,
Please read these operating instructions carefully
and pay particular attention to the safety notes
indicated in the first pages. We recommend that you
keep this instruction booklet for future reference and
pass it on to any future owners.
The warning triangle and/or the key words
(Warning!, Caution!) emphasize information
that is particularly important for your safety or
correct functioning of the appliance.
The information marked with this symbol
provides additional instructions and practical
tips on the use of the appliance.
Tips and information about economical and
ecological use of the machine are marked
with this symbol.
Should any problems arise, this booklet provides
instructions on how to solve them by yourself; see
section “Something not working?”.
If this information is not sufficient, please contact our
nearest SERVICE CENTRE.
Printed on recycled paper.
People who think ecologically, act accordingly…
Technical data
Height x Width x Depth 82x60x54.5 cm
Depth with door opened 91 cm
Height adjustment ±13 mm approx.
Net weight 76 kg approx.
Load (depending on programme) 4.5 kg max.
Use domestic
Drum speed during washing max. 55 rpm
Drum speed during spinning 1200/900/700/500 rpm
Water pressure 1-10bar
(=10-100N/cm2= 0.1-1.0Mpa)
This appliance complies with the following EC directives:
73/23/EEC of 19.2.1973 “Low voltage directive”, including directive 93 / 68 / EEC;
89/336/EEC of 3.5.1989 “Electromagnetic Compatibility Directive”.
124973811.qxd 01/02/01 14.02 Pagina 2 (Nero/Process Black pellicola)

How to wash 14
Load the laundry 14
Add detergent and additives 14
Switching the machine on 14
Selection of the desired wash programme 14
Selection of the spin speed 14
Selection of the STAIN, PREWASH or QUICK
WASH option 15
Selection of the RINSE PLUS and/or
RINSE HOLD option 15
Selection of the DELAY START option 15
Starting the programme 15
At the end of the programme 15
Automatic washing and drying
(NON-STOP programme) 16
Programme charts 17-19
Wash programmes 17
Special programmes 18
Drying 19
Consumption data for drying 20
Cleaning and maintenance 21
After each wash 21
Periodical cleaning 21
Bodywork 21
Detergent dispenser drawer 21
Drain filter 21
Water inlet filter 21
Emergency emptying out 22
Frost precautions 22
Something not working? 23
Troubleshooting 23
Unsatisfactory washing results 25
Service 26
Instructions for installation and
electrical connection 27
Safety instructions for the installer 27
Dimensions of the appliance 27
Front view and side view 27
Rear view 27
Installation 28
Unpacking 28
Positioning 28
Levelling 29
Water inlet 29
Water drainage 29
Electrical connection 30
Permanent connection 30
Bulding-in 30
Preparation and assembly of the door 30
Safety instructions 4
Discarding 5
Tips for environmental protection 5
Main features of your washer-dryer 6
Description of the appliance 6
Control panel 7
Programme selector dial 7
ON/OFF button 7
Mains-on light 7
START/PAUSE button 7
DELAY START button 8
DRYING TIME button 8
Programme Option buttons 8
STAIN 8
QUICK 8
PREWASH 8
RINSE PLUS 8
RINSE HOLD 8
SPIN SPEED 9
Display 9
Programme progress display 9
Cancelling a programme 9
Modification of a programme which is running 10
Opening the door after the programme has started 10
Detergent dispenser drawer 10
Before the first wash 10
Preparing the wash cycle 11
Sorting out and preparing the laundry 11
Weight of laundry 11
Types of fabric and care labels 11
Detergents and additives 12
Which detergent and additive? 12
How much detergent? 12
Liquid detergent 12
Adding a water softener 12
Information on water hardness 12
Preparing the drying cycle 12
Load 12
Garments not suitable for drying 12
Drying symbols on garment labels 13
Duration of the drying cycle 13
Modification of the drying time 13
Fibre residue 13
Additional drying 13
How to dry 13
Drying only 13
ENGLISH
3
Contents
124973811.qxd 01/02/01 14.02 Pagina 3 (Nero/Process Black pellicola)

The safety of KÜPPERSBUSCH appliances
complies with the industry standards and with legal
requirements on the safety of appliances. However,
as manufacturers, we feel it is our duty to provide the
following safety notes.
General safety
• Repairs to the machine must be carried out only by
qualified personnel. Repairs carried out by
inexperienced persons could cause serious
danger. Contact your local Service Centre.
• Unplug the appliance before carrying out any
cleaning or maintenance operations.
• Never pull the power supply cable to remove the
plug from the socket; always take hold of the plug
itself.
• Never spray the machine with a jet of water.
Danger of electric shock!
• During high temperature wash programmes and
drying the door glass may get hot. Do not touch it!
• Let the water cool down before carrying out
emergency emptying or before opening the door in
an emergency.
Positioning, connection, starting up
• Follow the instructions for positioning and
connection.
• Carry out a first wash without laundry (COTTONS
60, with half the amount of detergent) in order to
remove any manufacturing residue from the tub
and the drum.
• Should the machine be purchased in winter, when
temperatures can be below 0°, leave the appliance
for 24 hours at ambient temperature before starting
it.
Safety instructions
4
Child safety
• Children are often not aware of how dangerous
electrical appliances can be. When the machine is
working, they should be carefully supervised and
not be allowed to play with the appliance - there is
a risk that they could become trapped inside.
• The packaging components (e.g. plastic film,
polystyrene) can be dangerous to children - danger
of suffocation! Keep them out of children’s reach.
• Keep all detergents in a safe place out of children’s
reach.
• Make sure that children or pets do not climb into
the drum.
• When the appliance is to be scrapped, cut off the
electrical supply cable and destroy the plug with
the remaining cable. Disable the door catch in
order to prevent children from becoming trapped
inside while playing.
Proper use
• This appliance is designed for domestic use only. If
the machine is used for any other purposes or is
not used correctly, the manufacturer accepts no
responsibility for any possible damage that might
occur.
• For safety reasons, the appliance must not be
modified.
• Use only detergents suitable for washing machines
and follow the manufacturer’s instructions.
• Garments which have been in contact with
flammable solvents should not be machine
washed.
• Do not use your machine for dry cleaning.
• Dyes and bleaching agents may only be used if
specifically permitted by the manufacturer of these
products. We cannot be held responsible for any
damage.
• Always unplug the appliance and turn off the water
tap after use.
124973811.qxd 01/02/01 14.02 Pagina 4 (Nero/Process Black pellicola)

ENGLISH
5
Discarding
Tips for environmental protection
Packaging materials
The materials marked with the symbol are
recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by disposing of
them properly in appropriate collection containers.
Machine
Use authorised disposal sites for your old appliance.
Help to keep your country tidy!
To save water, energy and to help protect the
environment, we recommend that you follow these
tips:
• Normally soiled laundry may be washed without
prewashing in order to save detergent, water and
time (the environment is protected too!).
• Use the energy saving programme when washing
normally soiled cotton garments.
• The machine works more economically if it is fully
loaded (for both washing and drying cycles).
• When small loads are washed, use only half to two
thirds of the recommended amount of detergent.
• The machine will consume less energy if the
laundry is adequately spun before being dried.
• With adequate pre-treatment, stains and limited
soiling can be removed; the laundry can then be
washed at a lower temperature.
• If the water has a medium or high degree of
hardness (starting from degree of hardness II, see
“Detergents and additives”) water softeners must
be added.
The amount of detergent can then be adjusted to
degree of hardness I (= soft).
