Karassn KS-C8131 User manual

S N :
V 1 . 1
3 5 0 3 1 0 0 0 C 8 1 3 1 0 1 1
Status indicator
Alarm indicator: Red light on means device alarm.
Arm/disarm indicator: Orange means arm, green means
disarm.
Internet indicator: Light means server connect successfully,
blinking means video recording or browsing. PTZ cameras have
no function of internet indicator
The PTZ Cameras with no alarm function, do not have Status
indicator function.
MIC
photoreceptor
state light
Infrared light
SD card slot
alarm indicator
internet indicator
PIR
MIC
power/arm/disarm
indicator,
Wireless IP Camera Operation Guide

.1. .2.
First of all, the cellphone should keep in the state of surfing
the internet (WIFI/3G), support above Ios4.3 / Android2.2.
1.Install the software on cellphone.
Android mobile phone could search and download the “K10” in
Google play. Or use UC browser to scan the QR code outside the
package box, download and install it.
Apple mobile phone could enter the IOS APP Store, search
“K10”, download or scan the QR code and install it. After
download, open the installation program, and then install it.
2.Register Account
K10 support register with email address. Open the software,
click”register”, input the email address and set a password, and
then click “register”.
3.Add and delete the device
The device should be connected with the network line and plug
in. If the cellphone's wifi network is same as the device, pls open
the tools and click “shake”, it will refresh the new device
automatically. Choose one device and enter the interface of
device account setting, set the name of device and a new
administrative password, click “save” in the top right corner.
Add device and set the device password successfully. The device
account can also be added through the local area network or
manually.
choose one device account, long press the icon in the middle,
will pop-up a window, click delete, then delete the device
successfully.
Note: Before delete device, it need to set the alarm push ID,
click it into the alarm push ID interface and delete the device
account, otherwise once trigger the device, it will still push
alarm to the phone.
4. Function operate
1. Browse the video: at the device list interface, click the left icon of
device, into to the interface of video browsing. The device with PTZ
function can turn the direction of video by sliding the screen.
2. Setting the function parameter: at the device list interface, click the
middle blank area of device, into setting the functional parameter
interface.
A. Playback: click it, into the TF card video playback interface. The
interface will show all the TF card video, click one will play it
automatically
Note: the TF card only support the FAT 32 file system, support 64G at
most.
B. Settings, click it, into setting the function parameter interface, can
set the device time, change password, set the wifi, modify the alarm set
and video set.
C. Edit: click it, into the user log in interface, can modify the device
name and password.
5. Reset:
long press reset key ,and release it until hear one sound, the device
reset successfully.
6. Device connecting
Insert the internet line into device and connect to the router, insert
power adapter and power on, power indicator(green light) on, the
motor of PTZ Camera will automatically rotate one circle, then stop at
the place when the power was off last time. When the device has been
activated, the IP will be allotted by router automatically, then confirm
the indicator(yellow light) is on or off, if it is off, please check the
internet line connect successfully or not, setting of router is correct or
not.
DEVICE LIST
10 69738
10 69736
73 8
73 6
Onl ine
arm
disarm
browse video
Function parameter
setting
DEVICE LIST
Onl ine
Play
Playing record
Set up
Edit
5.Learning code with the wireless sensor.
The PTZ camera with alarm function can learn code and work with
wireless sensor (remote control, door sensor, smoke detector, PIR
detector and so on), and make a wireless alarm system. For example,
enroll the door sensor to the hall's first channel, enter the zone setting,
choose “hall”, click “1”, then click “OK”, and trigger the door
sensor, will show “learning successfully”. After arm the camera, if
trigger the door sensor, it will alarm.
WAN
LA N
power line
internet line
router
internet
