Kaysun K03 WIFI USB User manual

K03 WIFI USB USER MANUAL
KAYSUN APLICATIONS
The design and specifications are subject to change without prior notice for product improvement.
Consult with the sales agency or manufacturer for details.
Just a little preventative care on your part can save you a great deal of time and money over the life of
your air conditioner.
Version 1.0

USER MANUAL K03 WIFI USB
3
CONTENTS
1. Declaration of Conformity ................................................................4
2. Specification ....................................................................................4
3. Precaution........................................................................................4
4. Technical Solution ...........................................................................5
5. Operation Instruction........................................................................6
6. How to use app..............................................................................11
7. Special functions............................................................................16
CAUTIONS
This device complies with Part 15 of the FCC Rules and RSS 210 of Industry & Science Canada.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Only operate the device in accordance with the instructions supplied. This device complies with FCC
and IC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the
possibility of exceeding the FCC and IC radio frequency exposure limits, human proximity to the
antenna shall not be less than 20cm (8 inches) during normal operation. Changes or modifications
not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.

USER MANUAL K03 WIFI USB
4
1. Declaration of conformity
Hereby, we declare that this AC is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
2. Specification
3. Precautions
Applicable system: IOS, Android.(Suggest:IOS 7.0 or later Android 4.0 or later)
Please check the service website for more applicable devices.
Disclaimer: Due to the special situation existed during App use, we explicitly claim
as bellow:
Not all of the Android and IOS systems are compatible with the APP.We will not be
responsible for any issue as a result of the incompatibility SMART KIT wireless
safety strategy.
Smart kit only support WPA-PSK/WPA2-PSK encryption and none encryption.
WPA-PSK/WPA2-PSK encryption is recommended.
Smart Phone camera needs to be 5 million pixels or above to make sure scan QR
code well.
Due to different network situation, sometimes, request time-out could be
happened, thus, it is necessary to do network configuration again.
Due to different network sitiuation, sometimes, control process may return time
out. If this situation occurs, do not feel confused, the display on board and APP
may not be the same.
Model
K03 WIFI USB
Standard
IEEE 802.11b/g/n
Antenna Type
External omnidirectional Antenna
Frequency
WIFI：2.4G
Maximum Transmitted Power
15dBm Max
Dimension
55*24*8mm
Operation Temperature
0ºC~45ºC/32ºF~113ºF.
Operation Humidity
10%~85%
Power Input
DC 5V/300mA

USER MANUAL K03 WIFI USB
5
4. Technical Solution
WIFI Router Home Control Mode.
A WIFI router is needed at this mode. Smart phone and connect to the AC
through the WIFI router conditioner.
1）Smart Phone
2）Smart Air conditioner
3）WIFI Router
How to install the smart kit
Remove the protective cap of the smart kit.
Open the front panel and insert the smart kit into the reserved port.
Attach the QR code packed with SMART KIT to the side panel of
the machine, ensure it is convenience to be scanned by the mobile
phone.

USER MANUAL K03 WIFI USB
6
5. Operation Instruction
1. Install App
iPhone Users: scan QR Code or go to App Store and search for
„NetHome Plus‟ app and download it.
Android Phone users: scan QR Code or go to Google Play,
search for „NetHome Plus‟ app and download it.
2. Set Air conditioner to be AP mode
The procedure includes the following steps:
1) Disconnect the power supply of AC
2) Connect the power supply of AC, and continuously press the digital
display button or do not disturb button seven times in 3 minutes.
3) When the AC displays 'AP' , it means that the AC WIFI has already
entered into the WIFI Network Setting Mode
Kindly reminder:
When the AC WIFI entered into WIFI Network Setting Mode, the Air-
conditioning remote control can't open the AC. It needs to wait 3-5
minutes or when the AC finishes the WIFI Network Setting Mode,
then the Air-conditioning remote control can control AC normally
If there is no set operation under WIFI Network setting mode,AC will
quit this mode automatically 8 minutes later ,and then the user can
control the AC normally
3. User Registration and Network Configuration
Please ensure your mobile device is connected to Wifi router. Also,
the Wifi router has already connected to Internet before doing user
registration and network configuration.
1-Click create account
2.-Enter your email address and
password, and then click Registration.

USER MANUAL K03 WIFI USB
7
CAUTION:
It is better to log in your email box and active your registration account by clicking link in
case you forget the password.
It is necessary to forget any other around network and make sure the Android or IOS
device just connect to the WIFI network you want to configure.
Make sure the Android or IOS device WIFI function works well and can be connected
back to your original WIFI network automatically.
Using Android device to do Network configuration
3 Press + Add Device, , 4Scan QR Code
5Select your own WiFi network, for example My Home (the picture is only for reference)
6Enter your own WiFi router password and click OK;
7 Configuration Success, you can see the device on the list.

USER MANUAL K03 WIFI USB
8
Using IOS device to do Network configuration
3 Press + Add Device, , 4Scan QR Code
5Read the instruction above and press the Home button to return to the device
interface.
6. Click settings to enter the setting page, select WLAN/WIFI.

USER MANUAL K03 WIFI USB
9
7Choose net_ac_XXXX
8Type defult password: 12345678 and click "Join”
9Return to APP and click Next
10 Select your WiFi network, for example “My Home”(the picture is only for reference)
11 Enter your own WiFi router password and click OK;

USER MANUAL K03 WIFI USB
10
12 Configuration Success, you can see the device on the list.
NOTE:
When finishing network configuration, APP will display “success”words on the screen.
Due to different Internet environment, it is possible that the device status still display
“offline".
If this situation occurs, user should turn off the AC power and turn on it again. After a few
minutes, it is necessary to do pull-refresh operation to make sure the device status
become "online"

USER MANUAL K03 WIFI USB
11
6. How to use app
Please ensure both your mobile device and air conditioner are connected to the Internet
before using app to control the air conditioner via internet, please follow the next steps:.
1 Type your own account and password, Click "Sign in”
2 Select the target air conditioner to enter into the main control interface.
3 Thus, user can control air conditioners on/off status, operation mode, temperature,
fan speed and so on.

USER MANUAL K03 WIFI USB
12
7. Special functions
Including: Timer on, Timer off, 8ºC Heat, Sleep, Energy, Check.
NOTE: If the air conditioner does not support the above function, the function will
be hided from the function list.
Timer on/ Timer off
Weekly, user can make an appointment to turn on or off AC on specific time. User
also can choose circulation to keep the AC under schedule control every week.

USER MANUAL K03 WIFI USB
13
8ºC Heat
User can let the AC run under 8ºC Heat by one-click.
When people go outside, this function can protect your furniture from frost
damage.
Sleep
Users can customize their own comfortable sleep mode by setting target
temperature.

USER MANUAL K03 WIFI USB
14
Check
User can simply check the AC running status with this function. When
finishing this procedure, it can display the normal items, abnormal items,
and detail information.

USER MANUAL K03 WIFI USB
15
Energy
User can see the electricity curve monthly, and find the Lowest and highest
cost per month.
