Keenox DV1303 User manual

1
Digital Video Camera
User Guide
English

2
Copyright Information:
All rights reserved. No part of this publication may be reproduced, transmitted,
stored in a retrieval system, or translated into any language in any form by any
means, optical, electronic, recording, or otherwise, without the written
permission of our company.
We reserve the right to revise this manual and to make changes to any or all
parts at any time, without obligation to notify any person or entity of such
revisions and changes.

3
Specification:
Image Sensor: 300K Pixels CMOS Sensor
Image Resolution : High:2M , Middle:1.3M
Low:VGA(640*480pixels)
Display: 1.5’’ CSTN LCD
Video: (VGA/QVGA) 640*480/ 320 * 240
Preview Zoom: 4X(only in the camera mode)
Internal Memory: 8*16Mb
External Memory: SD card / MMC Card (not included)
Photo/Audio: JEPG/AVI
Lens: focus 2P
Interface: USB/AV out
Shutter Speed: 1/15 to 1/1000 second
Power: 4AA Alkaline Batteries (not included)
Dimensions: 123*43*70mm
Weight: 125g (excluded battery and SD Card)
Self-timer: 10 seconds delay & 2 seconds delay

4
1.System Requirements: Pentium 166MHz processor or higher Microsoft
Windows 98SE/Me/XP Available USB port
Super VGA card and color monitor CK-ROM or DVD-ROM drive At
least 64MB RAM
200MB available HD space
Mass Storage : Windows Me, 2000, XP
PC Camera Driver: Windows98se,Me, 2000, XP
2.USB device Unplugging Notice:
If you want to unplug the digital Video from your computer, be sure to
stop the device before hand. To stop the Digital Video, follow the steps
below:
Remove from PC (For Windows Me/2000/XP)
1.Click on the device icon “ ” located on the taskbar. Select the
device you want to stop (e.g. Stop USB Mass Storage Device Drive)
2.Follow the on-screen instruction to safely remove the Digital Video.

5
Key instruction
1. Power: Slide the power button on/off
2. Shutter: Start or Stop to take a picture/video
3. Zoom out/zoom in: 4 times digital zoom in camera mode only
4. Preview/Play:Change three mode: Capture, Video, Preview mode.
5. Menu/Ok:Confirm
6. Up/Down: Select setting. Up botton can play video on preview mode.
7. Left: Back/Preview pictures and video one by one/Self-timer
setting(10seconds & 2seconds)
8. Right: Pieview pictures amd video one by one
9. Display: play with icon, without icons or blank(economy mode)

6
Table Of Contents:
Specification
USB device Unplugging Notice
Getting to know your digital video
Strap Install
Power on/off/low
Taking Pictures
Taking Video
Playback Video/ Picture Files
Erase
USB.
Connected to PC
Installing the Drive and Photo-editing Software

7
Getting to Know Your Digital Video

8
1. 1.5” CSTN LCD 2.Power Indicator
3.Power On/Off 4.Zoom out/ Zoom in
5.Shutter/Play 6.AV port
7.USB port 8.Preview/Play
9.Menu/ok 10.Display
11.SD slot 12.Up
13.Left 14.Down
15.Right 16.Lens
17.Microphone 18. Function Incicator
19. Tripord port 20. Battery case

9
Strap Install
Following the instruction steps as below figures to attach the strap to the
camera.

10
Power On/Off
If you leave your Digital Video unused for 1 minute or more, the power will
automatically turn off to save battery.
Power Low
If your battery is about to run out, LCD will show
meantime the will be blinking and turn off itself in 10 seconds.In this
case,replace the batteries.
The status of the batteries are indicated on the top left corner of the display:
-full batteries: -run out 1/3 batteries:
-run out 2/3 batteries: -empty batteries:
To POWER ON -- slide the power button
down for 3 seconds and released to
activate your Digital Video. Slide it again
for 3 seconds to TURN OFF.

11
Remark!
1. Please make sure the focus adjusting button is either like A or B
according to the project distance, or the picture quliaty will be poor.
2. Keep the camera steady when releasing the shutter
3. Make sure you have adequate light when taking still pictures or movies.
4. For best quality video, move the camera slowly during recording.
5. Keep your finger away from the lens.
A. B.

12
Taking pictures/Single shot
1. Power on the camera ,
Press Preview/play to photo mode.A small camera is displayed on the
top right-hand corner of the screen.
2. Zoom-in or Zoom-out by T/W to frame your picture.
3. Press SHUTTER to start and the total number showing on the LCD will
be increase one by one .
4. LCD will say MEMORY FULL when the memory is fully used
5. “” On the lower right of the screen means internal memory, when
SD card was been putted into SD Card Slot, will be changed
by .

13
6. On the shot mode, you can adjust the Resolution , quality ,
EV , BRUST by press menu OK button, press Up or Down
button for selection, then press menu ok again for final confirm. or press
right button to set up mode.( Quality have 3 chose:fine ,
standard , economy: )
7. In the Set up mode , . to adjust format , Auto
off , reset , TV out , and press“YES ”for confirm, or
“NO ” at last, press to back off shot mode.
Taking VIDEO
1. Press Preview/play to select Video Mode
2. Press SHUTTER to start recording and stop
3. Press Menu/ok to switch to VGA(640*480) /
QVGA(320*240) ,then press Menu/ok to setting

14
4. LCD will say when the memory is
fully used.
Playback Videos & Pictures
Playback a Video or Picture
1. Press Preview/play to select playback mode ,
2. The files will be displayed . it mean no image with showed on
screen.

15
3. Move the course by press , to choose the file you want and
press to play.
If you are playback video,you also can press to stop.
Playblack video & audio on TV
Connect the camera to your TV set via AV cable, insert the black end to the
AV port in the camera. There are video and audio port in the TV set, connect
the AV cable with yellow end(for video) and red end(for audio) to the TV
according the instruction on TV.
Refer to below figure. Then open the camera, press preview you will find the
pictures, AVI or audio files you’ve taken. Select the one you desire and press
display key to display it.

16
Caution: If the AVI file cannot be played smoothly, you may need to upgrade
your Windows Media Player or directly play the file enclosed Arcsoft Video
Impression
Erase
1. Press Preview/play to switch to Playback mode
PressMenu/ok,LCD will say:
PressMenu/ok again, LCD will say:1）(delete one only)

17
２） (delete all)，choose at .
2. Then press Menu/ok to confirm.
There are no files,LCD will say:
3. Press Preview/Play to recorder mode.
Notice: If the file is protect and you will not be able to erase file.
USB
MSDC : Mass Storage (for PC Windows2000 and XP)
For Windows98 user need to install Mass storage driver.
DPOF: Set Digital print order Format. Version 1.0 function.
Set up Form:
Item Setting Description
Language English Multi-lingual LCD supports English and
simplified Chinese, You can select any language
that you wish to
Simplified
Chinese

18
AC Power
Frequency
50Hz
Match up with the frequency of the main power supply in your country.
50Hz: Europe, China, Hong Kong etc
60Hz: America, Canada, and Korea
60Hz
Exposure Exposure Value
White Balance White Balance
Sharpness Normal, Sharp or Soft.
TV out. PAL China , UK, Germany, Russia, Africa
NTSC North America and Japan
Auto off 60 sec after no operation (adjustable)
This is disabled when connected on usb.
Data & Time To set date and time
Default Go back to the primary default setting
CONNET TO PC
1. Mass Storage Mode (When in use of external memory card) Power on
your digital camera and Press Preview/play buttom and Connect your
digital Video to a computer, it will turn to mass Storage Mode. In mass
Storage Mode, Your Digital Video acts exactly like a hard disk. That
means you can access it via the Windows user interface. You can copy,
move or delete pictures or movies exactly the way you manipulate files.

19
(Note: For Windows Me 2000 and XP, there is no need to install the mass
storage driver form the CD ROM. Driver installation is only needed for
Windows 98)
2. PC Camera Mode
Power on your digital camera and connect it to your PC via USB cable
provided, press shutter button till you see the screen showed PC camera:
. Then go to [Start] [Programs] [Sunplus Ca533a ] , run Amcap.
Using as a PC/Web Camera
1. The webcam allows you to broadcast moving images over the Internet.
When your camera is connected to the USB port it can be used as a
PC/Web camera.
2.Open the camera first then connect this Digital Video to a computer with its
supplied USB cable and the screen will show PC camera . Go to program-
>Sunplus Ca533a>Amcap, run Amcam

20
You will see it works as a PC cam!
If you have a MSN Messenger or Yahoo account, you can have a video
conference face to face Online.
Installing the driver and photo-editing Software
You must install all software before connecting the Digital Video to your
computer
