Keep Safe Sagl PERSONAL GPS 3 User manual

PERSONAL GPS 3
User Manual

2
1 Inside the Box
Pictures are for indication and illustration purposes only.
2
Overview
2.1 Introduction

3
Thanks for choose our product. This Quick Start guide tells you how to set up your
Personal GPS.

Confirm your SIM card have calling, send SMS,
GPRS function

Remove the pin code of the SIM!

Remove the Combox!

Confirm your SIM card have enough balance (money)

Confirm your SIM card can show caller ID and don't use call forwarding
function

Please charge 12 hours at first use

Insert SIM card in right way

Press ON button for 3 seconds

4
2.2 LED Indication
1.
Power/working status indicator (red)
Status
Indication
Quick flashing (interval 0.3s)
Low battery
Slow flashing (interval 2s)
Fully charged
Slow flashing (flash 0.1s after every 3s )
Normal working
Continuously in bright
Charging
Continuously in dark
No battery/troubleshot
GPS signal indicator (blue)
Status
Indication
Slow flashing (interval 2s)
Searching GPS signal
Slow flashing (flash 0.1s after every 3s )
GPS signal has been acquired
successfully
Continuously in dark
GPS stops working
GSM signal indicator (green)
Status
Indication
Quick flashing (interval 0.3s)
GSM initialization
Flashing (flash 1s after every 3s)
Receive GSM signal normally
Slow flashing (flash 0.1s after every 3s )
GPRS online
Continuously in bright
Monitor function is activated
Continuously in dark
No GSM signal or no SIM card
installed

5
2.
Armed
When red/green/blue 3 LEDs are flashing circularly, it means the terminal is
armed; all LEDs will be off without
other operation on the terminal within 20s.
3.
Buttons instruction
No.
Button
Graphic
Function Introduction
Operation
Function
1
SOS button
Long press
SOS alarm
Short press during calls
Hang off
2
Family Number
button 1
Long press
Call
Short press when calls
coming in
Answer
Short press during calls
Turn on the volume
Long press during calls
Change to speaker mode
3
Family Number
button 1
Long press
Call
Short press when calls
coming in
Answer
Short press during calls
Turn down the volume
Long press during calls
Change to speaker mode
4
Mode button
Short press twice in a row
Arm/disarm the
vibration Alarm
5
ON/OFF
Long press
Power on/off

6
3 Installation
3.1 Install/Remove GSM SIM card
1)
Turn off the terminal
2)
Open the USB rubber plug
3)
Put the GSM SIM card in the SIM card slot until you hear
the “click” sound.
4)
Please turn the terminal off before you remove the SIM card.
WARNING: Must turn off the termina
l before removing the SIM card.
3.2 Power ON/OFF
Long press “ON/OFF” button to turn the terminal on/off.
3.3 Charging battery
When the red LED light is flashing
quickly, it means the battery is low and
needed to be charged in time. And
please charge before using at the first time.
1)
Connect the charger to power;
2)
Open the rubber plug;
3)
Connect the charger into the USB slot;
4)
This process may take 4
-
6 hours.
During this period, it is normal that the terminal,
battery and the charger become hot.
5)
If the red LED is continuously bright, it means it is charging. If the red LED is
flashing slowly, then it means it is fully charged.
WARNING
:
The terminal must be p
laced in a ventilated place in 0
℃
-
4
℃
. Using
not certificated charger might cause danger and will be considered against the
warranty terms

7
4 Parameters setting
4.1 Set APN
Please send SMS command to the number of terminal so as to set up the APN
parameter
. The terminal will reply
“OK” automatically after setting successfully.

Send SMS command:
APN,APN name#
o
e.g: APN,
gprs.swisscom.ch
#
NOTE
:
The APN of some countries have user name and password, you may need
to send SMS command as following:

Send SMS co
mmand: APN,APN name,user name,password#
o
e.g: APN,internet,CLIENTE,AMENA#
4.2 Set SOS Number

Send SMS command: SOS, A,number1,number2,number3#
If set successfully
, the terminal will reply “ok”
o
e.g.
SOS,A, 091****60,091****6,091****8#
(set all 3 SOS numbers)
o
e.g.
SOS,A, 091****60#
(set the first SOS number)
o
e.g.
SOS,A, ,091****6#
(set the second SOS number)
You could set 3 SOS numbers in maximum

8
4.3 Delete SOS Numbers

Send SMS command:
SOS,
D,1,2,3#
o
e.g.
SOS,
D,1
#
(
means delete t
he first number
)
o
e.g.
SOS,
D,3#
(
means delete the third number
)
If you do not know the sequence number, you can also delete the number by SMS
command like this:
SOS,
D,number#
o
e.g.
SOS, D, 13527852360#
4.
4
Add
Family Numbers via SMS command
1)
Add one Family Number

To add the first Family Number, send SMS comman:
FN,A,Phone Number1#
o
e.g.
FN,A,
091
***360#

To add the
second
Family Number, send SMS comman:
FN,A,
,
Phone
Number2#
o
e.g.
FN,A,,
091
***85136#
2)
Add two Family Numbers

Send SMS command:
FN,A,Phone Number1,Phone Number2#
o
e.g.
FN,A,091***360,091***85136#
4.
5
Delete Family Numbers via SMS

Send SMS command:
FN,D,1,2#
(D means delete the number)
1,2 means sequence numbers
or

Send SMS command:
FN,D,Phone Number#
4.
6
Ca
ll Family Numbers
Long press Family Number buttons can call preset numbers. Short press SOS
button can hang off the call.
NOTE
:
When the people you call pick up the phone, the
terminal will vibrate
slightly

9
4.7 Set the time

S
end a SMS with:
GMT,E,number
#
o
Bern example (GMT+1):
GMT
,E,1#
4.
8
Answer phone calls
Short press either one of the Family Number buttons to pick up the call. And
short press SOS button to reject or
end the call. Long press either one of the
Family Number
buttons to turn on the speak
er.
4.
9
Set call reminder mode
There are three ways of call reminder mode: ringtone, vibration, a
nd both
ringtone and vibration.

Send SMS command:
CALLMODE,
code of call reminder mode#
o
e.g.
CALLMODE,
1#
means call reminder mod
e is vibration
Code: 0 = ringtone; 1 = vibration; 2 =
both ringtone and vibration (default)
4.
10
Control volume
During the call, short press Family Number 1 button to turn up the volume and
Family Number 2 button to turn
down the volume. When the volume reaches the
limit
, the button light will be all bright.
4.11 Reboot the terminal

Send SMS command:
FACTORY
#
When terminal gets command, it will reboot after 1 min

10
5 Operation
General information
All of the functions must be performed via SMS from an authorized phone number!
5.1
Check location
1)
Ask for address information

Send SMS command:
POSITION#
or

Send SMS command:
URL
#
After command is sent successfully, SOS number will receive an accur
ate
location information.
2)
Ask for coordinates

Send SMS command:
WHERE#
Also the Family Number can apply for replying longitude and latitude from
the terminal.
o
e.g. Lat:N22.571285,Lon:E1 13.87711
5,Course:42.20,Speed:0.0740,DateTime: 10
-
11
-
23 22:28:51
5.
2
Voice monitor
the device calls the SOS phone numbers authorized and it's possible to listen what's
happening.

Send SMS command:
MONITOR
#
After the call conne
cted, the terminal will enter monitor condition. The SOS
number can hear the
sound around the terminal.
5.3 SOS Alarm
Press SOS button for more than 3s to activate SOS alarm, meanwhile you could
feel the vibration twice, and then
the terminal will send an
address information
message to the SOS number and it contacts the SOS phone numbers authorized.
o
e.g.
Emergy call:
http://maps.google.com/maps?q=N22.577
1 56,E
113,916748
NOTE:
If any SOS number answer the call, it will stop calling. If there’s no response
after all the number been dialed for three cycles, it will stop.

11
5.
3
Vibration Alarm
When the terminal
shakes
for 10 seconds
, it sends a SMS alarm to the SOS phone
numbers authorized
1)
Via calls
Any SOS numbers call the terminal (must be the SOS numbers), and then end up
the call in 10s by the mobile side to arm the terminal. The terminal will reply a
SMS
message “OK”. During arm state, any SOS numbers call the
terminal (must
be the SOS numbers), and then end up the call in 10s to disarm the terminal. If
the call does not
end up, it will enter the monitoring condition.
2)
Via SMS command
Any SOS number can
send SMS command“
111
” to arm the terminal (must be
the SOS number). And it will
automatically reply “OK” if set successfully. Any SOS
number can send SMS command“
000
” to disarm the
terminal (must be the SOS
number). And it will automatically reply “OK”
if set successfully.
3)
Via Mode Button
Short press twice in a row to
activate it
, short pressing twice in a row will disarm
the terminal.
NOTE:
If the GPS is located, the terminal will send accurate address information. If
GPS is not located, the termina
l will
send LBS address information instead. And if
GPS is located in 5 minutes later,
the terminal will send accurate address
information.
o
e.g. GPS address information:
“vibration alarm: Bao’an Road, Bao’
an District, Shenzhen, Guangdong
(N22.57139,E1 13.87710)
NOTE:
When vibration alarm is on and GPS is located successfully but there is no GPS
connection, the terminal will send
longitude and latitude location to pre
-
set SOS
numbers. When the GPS is not loc
ated and there is no GPRS
connection, then
the terminal will not get any location information so it will send “Vibration
alarm! Please notice.” To pre
-
set SOS numbers.
NOTE:
The interval of vibration alarm could not be less than 5 minutes. If could
not sen
d messages, please check your
SIM card balance.
5
.
4
Low battery Alarm
When battery is low, the terminal will send SMS to SOS numbers.

12
6
Appendix
6
.1 Battery security
●
Please use the original battery. The warranty will be invalid by using any other
accessory. The manufacturer will not take any responsibility for any damage
caused by not using the original battery.
●
The new battery can realize the optimal performance af
ter fu
lly charging for 2
or 3 times.
●
Don’t charge the battery for more than one week, since over
charging will reduce
its using time.
●
Do not short
-
circuit the battery with metal stuff (such as the key in your
pocket)
●
Do not bend or open the battery.
●
Do not put the battery into water or fire.
●
The battery should never be charged at temperature below 0 degrees or
above 45 degrees Celsius.

13
6
.2 Trouble shooting
If there is any problem while operating the terminal, please refer to the
following table,
or contact your service provider.
Common problems
Causes
Solution
Bad reception
Near the tall building or in the
basement
Change to a place with good signal
The terminal cannot
switch on
No battery power
Change a new battery
Cannot make voice
monitoring
No preset SOS numbers
Set SOS numbers
SIM card is without Caller ID function
Activate the function
Cannot connect to the
network
SIM card is not inserted correctly
Check the SIM card
The sheet mental of SIM card is Dusty
Wipe it clean
Invalid SIM card
Contact your internet service provider
Out of GSM service area
Move back to the GSM service covered area.
Weak signal
Try again in a strong signal area
cannot charge
Voltage is out of charging range of the
Charger
Change to the proper voltage
Poor contact
Check if the plug is in
Cannot check
address
information
GPRS function is not activated
Please contact the SIM card operator to
activate GPRS
Cannot get the position data
Restart the terminal
It is not a SOS number
Set SOS number
