SPECIFICATIONS
Illust is DPC-395.
* Refer to parts list on page 13.
In compliance with Federal Regulations, following are reproduc-
tions of labels on, or inside the product relating to laser product
safety.
KENWOOD-Corp. certifies this equipment conforms to DHHS
Regulations No. 21 CFR 1040. 10, Chapter 1, Subchapter J.
DANGER : Laser radiation when open and interlock defeated.
AVOID DIRECT EXPOSURE TO BEAM.
PORTABLE CD PLAYER
DPC-193/392/393/395/
DPC-692/792/793/993
SERVICE MANUAL © 1998-7/B51-5451-00 (K/K) 3314
Format
System ............................................................................ Compact disc digital audio system
Laser .......................................................................................................Semiconductor laser
Audio
Frequency response ..........................................................................20 Hz to 20 kHz, ±3 dB
PHONES outpuyt level (16Ω, 1 kHz ) ............................................................ 10 mW + 10 mW
Line output/impedance .....................................................................................0.6 Vrms/1 kΩ
Power supply
External DC supply ........................................................................................... 4.5V to 6 V DC
Rechargeable batteries (NB-88 or NB-130) x 2 or 4 .................................................DC 2.4 V
Commercially-available alkaline batteries (LR6/AA) x 2 or 4 .......................................DC 3 V
Battery life (continuous repeat playback)
(Figures inside parentheses show the performance when the D.A.S.C. is ON.)
Commercially-available alkaline batteries (LR6/AA) x 2 .................................... Approx. 12 (9.5)Hours
Commercially-available alkaline batteries (LR6/AA) x 4 ..................................... Approx. 25 (20)Hours
Rechargeable batteries (NB-88) x 2 ................................................................... Approx. 5.5 (4.5)Hours
Alkaline batteries (LR6/AA) x 2 and rechargeable batteries (NB-88) x 2 ............ Approx. 18 (15)Hours
Dimensions (W x H x D) (DPC-395/792/795) ............................ 132 mm x 32.5 mm x 153 mm
(5 - 3/16"
x 1 - 1/4" x 6")
Dimensions (W x H x D) (DPC-193/392/393/793) .................... 132 mm x 29.5 mm x 153 mm
(5 - 3/16"
x 1 - 3/16" x 6")
Weight (net) (DPC-395/792/795) .......................................................................... 272 g (9.6 oz)
Weight (net) (DPC-193/392/393/793) .................................................................. 260 g (9.2 oz)
VOLUME
PHONES
LINE OUT
DC-IN
Top cabinet *
(A02-)
DC jack
(E03-0356-08)
Line out phone jack
(E11-0354-08)
Phone jack
(E11-0372-08)
Variable resistor
(R31-0086-08)
Knob (DOOR OPEN)
(K27-2322-08)
CD door ASSY *
(A52-)
DPC-193/383(k)COVER(98.12.1410:49 y[W 2

SPECIFICATIONS.........................................Top cover
CONTENTS / ACCESSORIES ....................................2
CIRCUIT DESCRIPTION.............................................3
PC BOARD ..................................................................5
SCHEMATIC DIAGRAM..............................................7
EXPLODED VIEW .....................................................12
PARTS LIST...............................................................13
DPC-193/392/393/395/692/792/793/993
2
CONTENTS / ACCESSORIES
Contents
Model feature list
AC adapter..................................................................(1)
(W08-0657-08) : K5K6K9P5P9P6
(W08-0658-08) : E2E7E3
(W08-0659-08) : T3
(W08-0660-08) : X6
(W08-0675-05) : M2M3M4S3
Innerphone..........................................(1)
(W01-0925-05) : E2E3M1M2M3T3X1X6
(W01-0923-05) : E7M4S3
AC plug..........................................(1)
(E03-0115-05) : M1M2M3M4S3
Rechargeable battery (NB-88) .......(1)
(W09-1240-05) : E7M1M2M4M3S3T3X1X6
Car battery adapter........................(1)
(W01-0921-05) : E2M2K5K6P5P6X6
Car cassette adapter......................(1)
(W01-0922-05) : E2K5K6M2P5P6X6
Remote control...............................(1)
(A70-1190-05) : S3
Remote control...............................(1)
(A70-1111-08) :E7M4
Headphone ....................................(1)
(W01-0924-05) : K5P5
(W01-0943-05) : K6P6
(W01-0947-05) : K9P9
12 3 45 679
DPC-193 DPC-392 DPC-393 DPC-395 DPC-692 DPC-792 DPC-793 DPC-993
MXMEMM2TE M KPKPX E KP
BASE BOOST SW
TACT TACT TACT TACT TACT TACT TACT TACT TACT TACT TACT TACT TACT TACT TACT TACT TACT
DASC<OFF-ON(4M)>IC7 - - YES YES YES YES YES YES YES - - - - - - - -
DASC<ST-OFF-HI(16M)>IC6 -------- -YESYESYESYESYESYESYESYES
DIGITAL OPT OUT(J104) -------- - -----YES--
LINE OUT(J105) YES YES YES YES YES YES YES YES YES YES YES YES YES YES - YES YES
REMOCON JACK(J103) -----YES--YES-----YES--
CAR BATTERY ADP. - - YES YES - - - - - YES YES YES YES YES - - -
CAR CASETTE ADP. - - YES YES - - - - - YES YES YES YES YES - - -
RECHARGEABLE BATT. NB-88 NB-88 NB-88 - NB-88 NB-88 NB-88 - NB-88 - - - - NB-88 NB-88 - -
INNER HEADPHONE(SHORT) -----YES--YES-----YES--
INNER HEADPHONE(LONG) YES YES YES YES YES - YES YES - - - - - YES - - -
OPEN HEADPHONE(LOW) -------- -YESYES---- --
OPEN HEADPHONE(HI/LONG) -------- - --YESYES-- --
NOISE CANCEL HP(LONG) -------- - ----- -YESYES
REMOCON WIRED -----LCD--3KEY - - - - - 3 KEY - -
Accessories
DPC-193/383(k)COVER(98.12.1410:49 y[W 3

DPC-193/392/393/395/692/792/793/993
3
CIRCUIT DESCRIPTION
Pin No. Name I/O Description Remarks
1-4 COM1-4 O LCD common signal
5 VLC3 – GND
6,7 VLC1,2 – LCD driving bias control
8 VDD – Power supply(+2.8V)
9 OSC2 – No use
10 SMCK I External system clock(4.2336MHz)
11 VSS – GND
12 X1 – GND
13 X0 – No use
14,15 MMOD,VREF – GND
16 KEY1 I Key input
17 KEY2 I Remocon key input port
18 RECHARGE OUT O Rechargeable detection port
19 BATT – No use
20 HOLD I Key hold on/off control ON=H
21 DOOR I Door switch detection port OPEN=H
22 DA SCST I/O DASC switch detection port(ST)
23 DA SCHI I DASC switch detection port(HI)
24 VREF+ – Power supply(+2.8V)
25 P00 – No use
26 SUBQ I Sub-Q data input signal port(to MN662746RPK1)
27 SQCK I Sub-Q data read timing clock port(to MN662746RPK1)
28 MDATA O Data signal port(to MN662746RPK1)
29 P04 – No use
30 MCLK O Clock signal port(to MN662746RPK1)
31 P06 – No use
32 RESET I System reset port
33-37 P10-14 – No use
38 BLKCK I Sub-Q signal read require port
39 P21 – No use
40 REM IN I Remocon data input port
41,42 P23,24 – No use
43 YMCLK O Clock signal port(to SM5859AF/5902AF)
44 YMDATA O Audio signal port(to SM5859AF/5902AF)
45 YMLD O Latch signal port(to SM5859AF/5902AF)
46 YD MUTE O Audio signal mute control port ON=H
47 ZSENSE O Sensitive signal port(to SM5859AF/5902AF)
48 NRESET O System reset port(to SM5859AF/5902AF)
49,50 P53,54 – No use
51 POWER O Power supply control port
52 REM DATA O Remocon data output port
53 CONT O DASC control output port(HI/ST) ON=H
54 BBS O BBS control ON=L
55 LMT I Limit switch detection port
56 EMP O Battery level detection port LOW BATT=H
1. Microprocessor : MN101C167
1-1 Pin description
DPC-193/383(k)COVER(98.12.1410:49 y[W 7

IC5
SHOCKPLOOF
SM5859AF
IC6,7
DRAM
AN8889
(KSM-542AAA)
/ / /
/ / /
/ / /
FROM IC4 (Rch)
J105 LINE OUT
J102
J104
Rch
Lch H. P JACK
OPT.OUT
NJM2073M
VOLUME
J103
REMOTE
LMT.
SW
AN8838SB
Lch IC9
MM662746RPK1
DPC-193/392/393/395/692/792/793/993
4
CIRCUIT DESCRIPTION
Pin No. Name I/O Description Remarks
57-59 P66,67,70 – No use
60 RECHARGE I Rechargeable battery detection port
61 LIGHT OUT – No use
62 MLD O Latch signal port(to MN662746RPK1)
63 SENSE I Sensitive signal port
64 FLOCK I Focus servo IN=L
65 TLOCK I Tracking servo IN=L
66 STAT I Status signal port
67 RST O Reset signal port(to MN662746RPK1)
68-71 P83-86 – No use
72 DIGITAL OUT O Digital output control
73 P81 I Memory selector NO=H,4M=H,16M=L
74 P80 I Memory selector NO=L,4M=H,16M=L
75-85 SEG15-25 – LCD segment signal
86-100 SEG0-14 O LCD segment signal
1-2 Microprocessor periphery block diagram
DPC-193/383(k)COVER(98.12.1410:49 y[W 8

4
1
5
IC9
8
22
12
14
1
25
1
51
75
10076
2650
60
41
1
22
12
34
44
111
14 26
13 1
2333
20
4021
6180
15
28
34
44
1
IC2
IC1
IC3
IC4
IC5
IC6
11
33 23
REPEAT
REMOTE VOLUME
LINE OUT
PHONESOPT OUTDC IN
DOOR
SW
P.MODE
B.B
1
19
ON OFF
HOLD
ON OFF
ESP SW
IC7
1
26
13
14
4
1
5
IC9 8
22
12
14
1
25
1
51
75
100 76
26 50
60
41
1
22
12
34
44
11 1
1426
131
23 33
20
40 21
61 80
15
28
34
44
1
IC2
IC1
IC3 IC4
IC5
IC6
11
3323
REPEAT
REMOTEVOLUME
LINE OUT
PHONES OPT OUT DC IN
DOOR
SW
P.MODE
B.B
1
19
ON OFF
HOLD
ON OFF
ESP SW
IC7
1
26
13
14
ACEGIBDFHJ
2
1
3
5
7
4
6
Refer to the schematic diagram for the value of resistors and capacitors.
PC BOARD (Component side view) (Foil side view)
5 6
DPC-193/393(K)PCB/SD(98.12.1410:42 y[W 1

ABDFHJCEGI
2
1
3
5
7
4
6
()
()
28 27 26 25 24 23 22 21 20 19 18 17 16 15
PDF PDE
VREF
TEOUT
TEN
TBAL
FBAL
FEN
FE OUT
ENV
LDON
OFTR
PDW
REDET
1
2 3
4
5 6 7 8
9
10
11
12 13
14
VCC PDA PDC PDB PDD FB RF RFIN LPD LD CSBRT CEA BDO GND
100 99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76
26 27 28
29
30
31
32 33
34
35 36 37 38
39
40
41
42 43
44
45 46 47 48
49
50
SEG0SUBQ
SQCK MDATA PO4 MCLK PO6 RESET PI0 PI1 PI2 PI3 PI4 BLKCK P21 REM IN P23 P24 YMCLK YMDATA YMLD YD MUTE ZSENSE NRESET P53 P54
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
COM4
COM3
COM2
COM1
VLC3
VLC2
VLC1
VDD
OSC2
SMCK
X1
X0
MMODO
VREF-
VSS
KEY1
KEY2
RECHARGE OUT
BATT.
HOLD
DOOR
DASC ST.
DASC HI
VREF+
POD
SEG25
P80
P81
DIGITAL OUT
P83
P84
P85
P86
RST
STAT
TLOCK
FLOCK
SENSE
MLD
LIGHT OUT
RECHARGE
P70
P67
P66
EMP
LMT
BBS
CONT.
REM DATA
POWER
SEG1
SEG2 SEG3
SEG4
SEG5 SEG6 SEG7 SEG8
SEG9
SEG10
SEG11
SEG12 SEG13
SEG14
SEG15 SEG16 SEG17 SEG18
SEG19
SEG20
SEG21
SEG22 SEG23
SEG24
1
2 3
4
5 6 7 8
9
COM1 SEG0
13
11
10 12
14
15 16 17 18
19
COM2 COM3 COM4 SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 SEG13 SEG14
4
3 2
1
100
99
98 97 96 95
94
93 92
91
90
89
88 87 86
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
No. PIN No.
L6
L7
L4
L5
6a
5a
4a
B.BOOST
3a
REPEAT
2a
PGM
1a
COM1
COM1
DASC
L8
L3
6b
6f
5b
5f
4b
4f
3b
3f
2b
2f
1b
1f
COM2
COM2
ST
L9
L2
6c
6g
5c
5g
4c
4g
3c
3g
2c
2g
1c
1g
COM3
COM3
HI
L10
L1
6d
6e
5d
5e
4d
4e
3d
3e
2d
2e
1d
1e
COM4
COM4
PIN u-COM
22 21 20 19 18 17 16 15 14 13 12
34
35 36 37 38
39
40
41
42 43
44
IN TV
PC
IN SP
LDON
IN TR
IN FO
VREF
DRVCC
AVDD
SVCC
EMP VC TB CLK START POWER PVCC2 IOUT SGND PWMG
23
24
25
26
27
28
29
30
31
32
33
11
10
9
8
7
6
5
4
3
2
1
TR-
TR+
FO-
FO+
PGND
SP+
SP-
TV+
TV-
ICONT
CRIP
AREF
CT
SPRO
IN
FB
OUT
DED
RESET
PVCC
VSEN
1
2
3
4
5
6
7
8
9
10
13
15
14
12
11
15
12
14
13
11
10
7
9
8
6
5
2
4
3
1
C140
22u16
+
+
4.7u50
R123A
0.022 4.7K
C139
R119A
C128A
C502A
1
33K
R501A C130
22K
C131
47P
R122A
R502A
33K
C124A C123A
0.1
C121A
C125A 1
47u10
C127
+
100u6.3
C126
+
PD2
PD1
E
PD
LDVR
GND
LD
VCC
VC
F
AL
TRK-
TRK+
FCS-
FCS+
+
F.C T.C
33uH
L102
0.1 0.1
47K
R184A
R125A
20K
22u16
+
SP+
SP-
SL+
SL-
0.1
C122A
47
55
0.01
C136
22K
R124A
100u6.3
C133
+
0.1
C132
1
VCC
VC
C501
+2.8V
+2.8V
+2.8V
+4.8V
+4.8V
+4.8V
+2.8V +2.8V
STOP
TRV
24
25
26
27
MRST
56 22
23 25 27 28
29
NC
C135
0.1
390P
C134
470K
R140A
2.2K
R141A
0.1
C137A
100u6.3
C138
+
R504A
180K
+4.8V
39
4.7K
R505A
0.022
C103A
0.022
C104A
R112A
150K
C115A
150P
R109A
120K
R110A
33K
R8A
47K
R7A
47K
100K
R111A
470P
C116A
R116A
15K
C106A
47P
6.8K
R114A 3.3K R115A
0.1
C111A
4.7K
R113A
2P
C107A
0.022
C112A
0.027
C113A
1
C120A
R97A
10K
R95A
10K
33
31
30 36 38 32
34
TP
24
25
27
26
1
2
3
4
10K
R3A
R1A
10K
R2A
10K
1K
R21A
0.1
C3A
26 27 28 30 38
43
100
99
98 97 96 95
94
93 92
91
90
89
88 87 86
JP12A JP14A
JP11A JP13A
R22A
4.7K
0.1
C2A
100u6.3
C1
+
55
53
56
62
63
64
65
66
67
10
44
45 47 48
+2.6V
+2.6V
+2.6V
+2.6V
40
C114A
0.027
39
47u10
C152
+
R136A
4.7
1
C118A
100u6.3
C117
+
+B
+B
R121A
10K
R189A
10K
R67A
+4.8V
+4.8V
53
17
21
23
22
20
16
+2.8V
+2.8V +2.8V
+2.8V
+2.8V
+2.8V
+2.8V
52
51
+B+B +B
+2.6V +2.6V
+2.6V+2.6V +2.6V
+2.8V
+2.8V
+2.8V
60
+4.8V
+4.8V
+4.8V
33
+2.8V
+2.8V
0.022
C11A
56K
R23A
88
87
86
90
89
91
92
93
94
96
95
99
98
97
1
100
3
2
4
R4A
56K
R5A
15K
+B
AMP
RF
L4 L5
L3
L2 L1
L6 L7
L8
L9
L10
1 2 34 56
a
g
d
b
c
f
e
C
D104
SW
LMT. FEED
MOTOR MOTOR
DISC
LD
PD
BTL DRIVER
CN4
SP1
SL1
Q102 Q6
E
AD
BC
PICKUP
F
D105
Q105
MM
Q116
D122A
u-COM
Q104
LD
CONTROL
D.A.S.C
CONTROL
IC1
IC3
IC2
LC101
(KSM-542A)
MECHA. ASS'Y
PGM REPEAT B.BOOST C D.A.S.C.
ST HI
4.8V
1.1V
0.8V
2.8V
2.5V
0V
1.3V
2.6V
1.3V
1.3V
1.3V
0V
0V
0V
0V
0V
0V
0.2V
0V
2.8V
0V
1.3V
4.8V
4.8V
4.8V
2.8V
0.3V
4.6V
0.6V
2.8V
1.3V
2.5V
0.4V
0.2V
0.7V
2.8V
4.5V
1.0V
1.3V
1.3V
1.4V
0V
2.6V
1.3V
1.3V
1.3V
1.3V
1.3V
1.4V
2.6V
1.3V
0.7V
0.1V
1.9V
1.5V
1.1V
0V
1.9V
4.8V
1.4V
2.8V
1.4V
1.4V
1.4V
0.9V
1.9V
1.3V
2.8V
2.8V
2.8V
2.8V
0V
0V
0V
2.8V
1.4V
0V
0V
2.8V
0V
0V
2.8V
2.8V
0V
0V
0V
2.8V
2.8V
2.8V
0V
2.8V
2.8V
2.8V
0V
2.2V2.8V
1.3V
2.6V
1.9V
1.8V
OFF: 0V
ST/HI: 2.9V
D.A.S.C
2.8V
OFF: 2.7V
0V
ST/HI: 0V
DPC-193/393(K)PCB/SD(98.12.1410:42 y[W 2

TKMOQSLNPR
44 43 42 41 40 39 38 37 36 35 34
12 13
14
15 16 17 18
19
20
21
22
A3 A2
A1
A0
A4
A5 A6 A7 A8
A9
NRAS
YLRCK YSCK ZSCK ZLRCK DATA2 YFLAG YFCLK YBLKCK NRESET ZSENSE VDD
1
2
3
4
5
6
7
8
9
10
11
33
32
31
30
29
28
27
26
25
24
23
VDD
UC1
UC2
UC3
UC4
UC5
DIT
NTEST
CLK
VSS
YSR DATA
NWE
D1
D0
D3
D2
NCAS
A10
YMCLK
YMDATA
YMLD
YDMUTE
20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
41
42 43
44
45 46 47 48
49
50
51
52 53
54
55 56 57 58
59
60
PMCK
SMCK
RST
STAT
D MUTE
SUBQ
SQCK
BLKCK
TLOCK
FLOCK
SENSE
MLD
MDATA
MCLK
TX
DVSS1
DVDD1
SRDATA
LRCK BCLK
TES PLAY WVEL ARF IREF DRF DSLF PLLF DSLF2 AVDD2 AVSS2 EFM PCK CK176 SUBC SBCK VSS X1 X2 VDD
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
TRV
TVD
PC
ECM
ECS
KICK
TRD
FOD
VREF
FBAL
TBAL
FE
TE
RFENV
V DET
OFT
TRCRS
RF DET
BDO
LDON
SSEL
MSEL
PSEL
FSEL
RSEL
OUTR
AVSS1
OUTL
AVDD1
TEST
ARST
FLAG6
RESY
CRC
CLVS
FLAG
IPFLAG
FCLK
CLDCK
TRVSTP
1.2K
R174A
R171A
R170A
R169A
R168A
220u6.3
+
0.022
C162A 1
R182A
R201A
1
100u6.3
+
47K
1K
R166A
R301A
1000P
C161A
C163A
6.8K
C166
10K
33K
5.6K
R175A
1K
1K
C171
C172A
470
100K
R183A
47
3
2
1
27
28
29
23
25
22
36
38
39
31
32
33
34
30
38
63
64
65
30
62
28 26
67
10
66
27
80
79
78
C177A
1
63
69
13
68K
R177A
0.22
C164A
820
R179A
180K
R178A
R180A
MHz
16.9344
C167A
20P 39P
C168A
X1
R47A 10
C169A 1
10
+2.8V +2.8V
0.022
C305A
560K
R307A
R306A
15K
47K
R202A
C202C302
R302A
47K4.7u50
+
C303
C301A C201A
4.7u50
+
C203
15K
R206A
-
+
R204A
-
+
VR101B
50K
300P
R320A 3K
C304
R304A
470
C320
4.7u50
+
+
47u10
8
7
100K
R303A
470
VR101A
300P
R220A 3K
50K
+
4.7u50 6
+
5
C220
47u10
C204
R203A
100K
+
C184
470u10
1C306
+
220u6.3
560K
R207A
C205A
0.022
R309A
10
R322A
4.7K
10
R49A
220u6.3
2
4
3C206
+
R209A
10
+2.8V
4.7u50
+
4.7K
R42AC8
R311A
680
R222A
4.7K
10K
R55A
R41A
4.7K
R211A
680
100K
R69A
100
R310A
0.22
C307A
100
R210A
C207A
0.22
C321
1000P
1000P
C221
R321A
470
470
R221A
L
G
R
R
L
G
C322
4.7u50
+8
9
7
1
2
2
48 47
1
80
79
78 69
63
13
45
27
28
29
30
31
32
33
44
43
3
52
A8
VCC
13
A1
10
12 A3
11 A2
A0
9
A5
15
14
A4
18
A6 17
16
A7
GND
D1
6
7
8
3
NRAS
4
5
NWE
D0
1
2
VCC
D2
21
20
19
24
GND 23
22
NCAS
D3 26
25
44
43 42
41
40
39
38 37 36 35
34
A10
GND
A9NC
NCNC
31 30
27
32
41
42
43
44
29
28
35
36
37
38
39
40
33
34
C180A 1
NC
NCAS
D2
D3
GND
A8
A5
A4
A6
A7
GND
13
31 D0
D1
2
1
32
33
34
42
43
44
41
NC
NC
NRAS
A9
NWE
5
4
3
7
6
VCC
8
9A0
A2
11 A3
12
10 A1
14
30
25
26
36
28
29
22
23
24
20
21
37
38
40
39
19
16
17
18
15
35
NC
NC
NC
22Ou6.3
+
+
1.5K
+
22u16
22Ou6.3
C145
L105
33uH
1
100
3
2
5
4
3
2
L106 95uH
C147A
47P
1
R138A
10
C146
0.01
R134A
C148
C150
100u16
+
3
2
+4.8V
R137A
+4.8V
+2.8V +4.8V
C144
C9
33K
R61A
R59A
33K
220K
R57A
10K
R58A
1.5K
39
60
33
51
22K
R54A 22K R56A
1
1
+4.8V
+4.8V
+4.8V+4.8V
+4.8V
220
R65
1/4W
4.7K
R48A
330
R30A
1.2K
R31A R32A
1.5K R33A 1.8K R34A 2.4K R35A 3.6K
R38A
R76A
3.3K
10K
R75A
47K
R68A
1
3 2
40
10
R46A
+2.6V
+2.6V
+2.6V+2.6V
+2.8V
+2.8V
+2.8V
+2.7V
52
+2.2V
+2.2V
+2.2V +2.2V
+2.2V
+2.2V
+2.2V
+2.2V
+2.2V
+2.2V
+2.2V
+2.2V
C182A
1
R43A
10K
10K
R66A
2700P 2700P
+2.8V
+2.8V+2.8V
+2.7V
+2.7V+2.7V
+2.8V+2.8V
+2.7V
C6A
0.1
+2.8V
+2.8V
16
20
21
17
52
6.8K
R29A
6.8K
R74A
22
23
1
C5A
+2.8V+2.8V +2.8V
+2.8V +2.8V
+2.8V +2.8V
+4.8V +4.8V
R60A
+4.8V +4.8V
Q205,305
R172A
15K
C160A
4700P
1000P
C4A
R40A
+B +B +B
+B
+B
DAD & DSP
SHOCK PROOF
16M D-RAM
J103
REMOTE
REPEAT
OFF
SW107
HOLD
ON
SW109
DOOR SW
ST. ESP SW
OFF
(BOTTOM VIEW)
SW108
G
VOLUME
HEADPHONES
Rch D301 Q301
Q305
D201
DRIVER
Q201
Lch
Q202
Q302
Q4
Q205
Q5
Q203Q303
J102
PHONES
B
LINE OUT
J105
DIGITAL
OUT
OPT OUT
J104
F
D4M D-RAM
(BOTTOM VIEW)
E
Q108
J101
DC-IN
BATTERYBT1
Q106
BATTERYBT
Q110
Q107 Q115
D112
D111
Q111 Q112
D115
D116
SW101 SW102 SW103 SW104 SW105 SW106
P. MODE
B B
D118A
D117
Q113
HIGH ON
OFF
Q304
A
BASS
BOOST
+2.8V
AVR
IC5
IC4
IC6
IC9A
IC9B
IC7
0V
1.2V
0V
0V
0V
1.3V
1.3V
2.8V
2.8V
0V
0V
0V
0V
2.8V
0V
2.8V
0V
0V
0V
0V
1.3V
1.3V
1.3V
1.3V
1.3V
0V
0V
1.5V
2.6V
0V
0V
0V
1.3V
1.3V
1.2V
1.3V
1.1V
1.3V
0V
0V
2.8V
2.8V
0V
0V
0V
2.2V
0V
0V
2.8V
2.7V
1.2V
2.5V
2.7V
2.7V
1.3V
1.4V
1.2V
1.5V
2.7V 0V
0V
0.6V
0V
0.6V
0V
1.1V
0V
0V 2.8V
0V
1.1V
0V
2.7V
ON: 0V
OFF: 2.8V
0.1V
0VB.B.
0.1V
0V
2.8V 2.8V
2.8V
0V
0V
0V
0V
0V
2.7V
0V
0V
2.8V
0V
0V
2.2V
0.1V
0.7V
0.2V
0V
0.8V
0V
1.9V
ON: 2.8V
OFF: 0V
HOLD
2.2V
0V
2.2V
0V
0V
2.6V
2.7V
2.7V
0V
0V
2.8V
4.8V
(DC-IN)
4.8V
4.8V
(DC-IN)
4.1V
4.1V
0V
0V
2.2V
2.2V
0V
0V
0V
0V
0V
0V
0V
0V
0V
0V
0V
0V
0V
0V
2.2V
2.2V
0V
0V
0V
0V
0V
0V
2.2V
2.2V
0V
2.2V
0V
0V
0V
0V
0V
0V
0V
0V
0V
4.8V
DPC-193/393(K)PCB/SD(98.12.1410:42 y[W 3

EUROPE
U.K.
GENERAL MARKET
E3
T3
S3
NO YES
ABB.
DESTINATION
COUNTRY JP11A,12A,
13A,14A SW108 (D.A.S.C.)
OFF ON
GENERAL MARKET M3 NO
A, D
YES
B, E
NO
YES
C, F
NO
R38A
NO
R51A,
52A ST OFF HI
NO
B, D
K6U.S.A.
CANADA
AUSTRALIA X6
P6 NO
DESTINATION
COUNTRY ABB. A, C, E, G
YES
YES NO YES NO NO YES
JP12A,
14A
F R182A SW108 (D.A.S.C.)
ST OFF HIOFF ON
YES
13A
JP11A,
COUNTRY
DESTINATION ABB. NO YESNOYESYES NO 14A
JP12A,
F
C, D 13A
JP11A, ST OFF HI
SW108 (D.A.S.C.)
OFF ON
A, C
YES
B, G
NO
E
NOEUROPE E7
A, C, D, G
NO
DESTINATION
COUNTRY ABB. JP11A,12A,
13A,14A
NOYES YES
NO
B, E F
YES
R182A
NOYES
SW108 (D.A.S.C.)
ST OFF HIOFF ON
GENERAL MARKET
EUROPE E2
M2
A, C, E, G
NO
DESTINATION
COUNTRY ABB.
YESNOYESYES
F
B, D
YES
R182A ST OFF HIOFF ON
SW108 (D.A.S.C.)
CANADA P5
U.S.A. K5 NO YES
13A
NO
14A
JP11A, JP12A,
A, C, E, G
ABB.COUNTRY
U.S.A.
CANADA K9 P9 NO
DESTINATION
NO
JP12A,
14A13A
YES
YES NO YES YES
B, D FJP11A,
R182A OFF ON ST OFF HI
YESNO
SW108 (D.A.S.C.)
NO
B, E
ABB.COUNTRY
YES
DESTINATION
NO
JP11A,12A,
13A,14A
NO NO
A, D F, G R182A OFF ON ST OFF HI
NOYES
SW108 (D.A.S.C.)
M4GENERAL MARKET NO
B
AUSTRALIA
GENERAL MARKET X1 M1 NO
COUNTRY
DESTINATION ABB. A, C, D, E, F, G
YES YES
JP11A
NO NO
ST OFF HI
SW108 (D.A.S.C.)
OFF ON
JP12A,
13A,14A
DIGITAL LINE
GND LINE
+B LINE
SIGNAL LINE
+B
YES 1000P
C116A 5A
YES
R4A, 75A,95A,97A,116A,168A
NO
R7A,8A,38A,48A,51A,52A, 171A
47K
R111A,
100K
R112A 170A
2.2K
R121A,
12K
4.7K
R169A
15K
R172A
160A
NO
C4A, C116A
470P
95A,97A
NO
R4A,5A,75A, 8A
47K
R7A,
100K
R111A R112A
150K
52A,116A,182A
YES
R121A
0/3.9K
R168A
10K
R169A
12K
R170A
5.6K
R171A
68K 0
R172A
160A
YES
C4A, C116A
1000P
470P
R4A,
5A
YES
51A,52A,75A
R7A,8A,38A,
NO NO
R48A,95A,
97A,116A
YES
47K
100K
R111A
100K
150K
R112A
2.2K
0/3.9K
R121A
4.7K
10K
R168A R169A
12K 2.2K
R170A
47K
68K
R171A
0
R172A
0
15K
NO
C4A
1000P
470P
C116A
YES NO
YES
C160A 95A,97A
R4A,5A,
NO
R7A,
YES
8A
YES NO
52A,75A,116A
R38A,48A,51A,
NO 100K
R111A
150K
R112A
2.2K
R121A
12K
R169A
3.9K 10K
4.7K
R168A
5.6K
R170A
2.2K 68K
R171A
0
R172A
15K
YES
160A
C4A,116A, R4A
YES NO
R5A,7A,8A,48A,75A,
95A,97A,116A R111A,
171A
47K 100K
R112A
2.2K
R121A,
4.7K
R168A
12K
R169A
15K
R172A
170A
YES
C4A
470P
C116A
NO
C160A
NO
R4A,5A,48A,
95A,97A,116A
YES
R7A,8A,
182A
YES
R75A
NO 100K
R111A
150K
R112A
3.9K
R121A
10K
R168A
12K
R169A
5.6K
R170A
68K NO
R171A R172A
0
YES
C4A
470P
C116A
NO
C160A 51A,52A,75A,116A
NO
R4A,5A,38A,48A, 95A,97A
YES
R7A,8A,
NO
R111A
100K
R112A
150K
R121A
2.2K
3.9K 5.6K
2.2K
R170A
10K 12K
R168A R169A R172A
68K
R171A
0
15K
C160A
470PYES NO
C116AC4A 52A,75A,116A,182A
NO
R4A,5A,38A,48A,51A, R7A,8A
YES
NO YES
R95A,
97A 2.2K
3.9K
R121A
100K 150K
R111A R112A R170A
10K 12K
R168A R169A
68K
2.2K
5.6K 0
15K
R171A R172A
C4A,
160A
R38A,48A,51A,
1.2KR38A 2
1.5K
R52A 3
R51A 1
JAPAN J 330 YES
G
YES
NO
JAPAN J
C
YES
NO YES YES0
0
52A
R38A
NO
YESNO
100
R51A,
DPC-393
DPC-792
DPC-793
DPC-392
DPC-692
DPC-993
DPC-395
DPC-193
IC1 : AN8838SB
IC2 : AN8789FB
IC3 : MN101C167
IC4 : MN662746RPK1
IC5 : SM5859AF
IC6 : MN41V17400CTT6
IC7 : MN41V4400SJ-08
IC9 : NJM2073M
Q4,6,201,301,304 : 2SC3330
Q5,104,110,113 : 2SA1317
Q102 : 2SB598F
Q105,115 : 2SC4048-AC
Q106 : 2SC4481T
Q107,202,302 : 2SD734F
Q108 : 2SD1805F
Q111,112 : 2SB926T
Q116 : 2SA1564-AC
Q203,205,303,305 : 2SC3860
D104 : SB10-03A3-BT
D105,115-117,201,301 : GMB01-BT
D111,112 : 1N4001
D118,122A : 1SS355
D118A REMOTE
D117 C
J103
DPC-193/DPC-393/DPC-793/
DPC-392/DPC-692/DPC-993/
DPC-792/DPC-395/DPC-795
CAUTION: For continued safety, replace
safety critical components only with manu-
facturer's recommended parts (refer to parts
list). indicates safety critical components.
For continued protection against risk of fire,
replace only with same type and rating
fuse(s). To reduce the risk of electric shock,
leakage-current or resistance measurements
shall be carried out (exposed parts are
acceptably insulated from the supply circuit)
before the appliance is returned to the cus-
tomer.
The DC voltage is an actual reading mea-
sured with a high impedance type voltmeter.
The measurement value may vary depend-
ing on the measuring instruments used or on
the product. Refer to the voltage during
PLAY with DASC OFF(at the normal speed)
unless otherwise specified; The value shown
in ( ) is the voltage measured at the moment
of STOP.
Y22-7800-10
DPC-193/392/393/395/692/792/793/993
UVXWY
NJM2073M
DPC-193/383(k)COVER(98.12.1410:49 y[W 12

VOLUME
OPEN
SW103
VR101
SW108
HOLD
OFF ON
SW107
SW105
B.B./
P.MODE
SW104
DPC-395
SW106 SW102 SW101
SW109
DC IN
J101
LINE OUT
J105
PHONES
J102
REMOTE
J103
D.A.S.C
OFF ON
A ø2X10 (BLK) : N09-3363-08
B ø2X5 (BLK) : N09-3362-08
Ax5
Bx2
REPEAT
659
656
605 604
634
633
601
642
610
641
621
621
622
622
602
645
631
635
635
643
644
603
617
637
632
620
661
660
662
606
657 711
713
707
714
746
747
748
709
712
708
1
2
3
AB
Parts with exploded view numbers larger than 700 are not supplied.
12
DPC-193/392/393/395/692/792/793/993
EXPLODED VIEW(UNIT)
DPC-193/383(k)COVER(98.12.1410:49 y[W 11

DDPC-193/392/393/395/692/792/793/993
13
PARTS LIST
601 2B ✽A02-2872-08 TOP CABINET M2
601 2B ✽A02-2872-08 TOP CABINET M3S3E2
601 2B ✽A02-2872-08 TOP CABINET M4E3T3
601 2B ✽A02-2841-08 TOP CABINET K6P6X6
601 2B ✽A02-2841-08 TOP CABINET K9P9E7
601 2B ✽A02-2841-08 TOP CABINET K5P5
601 2B ✽A02-2874-08 TOP CABINET M1X1
602 3B ✽A02-2840-08 BOTTOM CABINET M4S3
602 3B ✽A02-2842-08 BOTTOM CABINET K5P5
602 3B ✽A02-2842-08 BOTTOM CABINET K6P6X6
602 3B ✽A02-2842-08 BOTTOM CABINET K9P9E7
602 3B ✽A02-2875-08 BOTTOM CABINET M1X1
602 3B ✽A02-2876-08 BOTTOM CABINET E2M2
602 3B ✽A02-2876-08 BOTTOM CABINET E3T3M3
603 3B ✽A09-1110-08 BATTERY DOOR M2M1X1
603 3B ✽A09-1110-08 BATTERY DOOR M3S3E2
603 3B ✽A09-1110-08 BATTERY DOOR M4E3T3
603 3B ✽A09-1111-08 BATTERY DOOR K5P5
603 3B ✽A09-1111-08 BATTERY DOOR K6P6X6
603 3B ✽A09-1111-08 BATTERY DOOR K9P9E7
604 1B ✽A52-0354-08 CD DOOR ASSY M1X1
604 1B ✽A52-0355-08 CD DOOR ASSY E3T3M3
604 1B ✽A52-0355-08 CD DOOR ASSY S3
604 1B ✽A52-0356-08 CD DOOR ASSY E2M2
604 1B ✽A52-0357-08 CD DOOR ASSY E7
604 1B ✽A52-0358-08 CD DOOR ASSY K5P5
604 1B ✽A52-0359-08 CD DOOR ASSY K6P6X6
604 1B ✽A52-0360-08 CD DOOR ASSY K9P9
604 1B ✽A52-0361-08 CD DOOR ASSY M4
605 1A A70-1111-08 REMOTE CONTROL E7M4
606 1A A70-1190-05 REMOTE CONTROL S3
610 2B ✽B10-3454-08 INNER DISPLAY LENS K9P9K6
610 2B ✽B10-3454-08 INNER DISPLAY LENS M1X1
610 2B ✽B10-3454-08 INNER DISPLAY LENS P6X6E3
610 2B ✽B10-3454-08 INNER DISPLAY LENS T3M3S3
- B46-0100-50 WARRANTY CARD E7X6E3
- B46-0100-50 WARRANTY CARD T3E2X1
- B46-0322-03 WARRANTY CARD K5
- B46-0328-03 WARRANTY CARD K9K6
- B46-0336-03 WARRANTY CARD P9P6P5
-✽B60-3946-08 INST MANUAL(EN) K5P5
-✽B60-3946-08 INST MANUAL(EN) K6P6
-✽B60-3946-08 INST MANUAL(EN) K9P9
-✽B60-3947-08 INST MANUAL(FR) P5E3E2
-✽B60-3947-08 INST MANUAL(FR) P9E7P6
-✽B60-3948-08 INST MANUAL(EN) M1X1
-✽B60-3948-08 INST MANUAL(EN) M3S3M2
-✽B60-3948-08 INST MANUAL(EN) X6M4T3
-✽B60-3949-08 INST MANUAL(SP) E2M2M1
-✽B60-3949-08 INST MANUAL(SP) E7E3M3
-✽B60-3949-08 INST MANUAL(SP) M4
-✽B60-3950-08 INST MANUAL(TA) M2M1
L : Scandinavia K : USA P : Canada R:Mexico C:China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V:China(Shanghai)
Y : AAFES(Europe) X : Australia Q:Russia H:Korea M:Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q:Russia H:Korea M : Other Areas indicates safety critical components.
-✽B60-3950-08 INST MANUAL(TA) M4M3S3
-✽B60-3951-08 INST MANUAL(CH) S3
-✽B60-3952-08 INST MANUAL(HO) E7E3E2
-✽B60-3953-08 INST MANUAL(IT) E7E3E2
-✽B60-3954-08 INST MANUAL(GR) E7E3E2
- 155-00000-2266 CAUTION SHEET X6
- 155-01911-0266 CAUTION SHEET(HOLD) E7M4S3
617 2A D40-1547-08 CD MECHANISM KSM-542AAA
620 1A E03-0115-05 AC PLAG ADAPTER M2M1
620 1A E03-0115-05 AC PLAG ADAPTER M4M3S3
621 3B E23-1757-08 BATTERY CONTACT PLATE(-)
622 3B E23-1758-08 BATTERY CONTACT PLATE(+)
631 3A ✽G01-4075-08 OPEN KNOB SPRING(FOR HOOK)
632 2B ✽G01-4097-08 RECHARGE CONTACT SPRING
633 1B ✽G01-4077-08 CD DOOR SPRING (L) K5P5M4
633 1B ✽G01-4077-08 CD DOOR SPRING (L) K6P6X6
633 1B ✽G01-4098-08 CD DOOR SPRING (L) E3T3M3
633 1B ✽G01-4098-08 CD DOOR SPRING (L) K9P9E7
633 1B ✽G01-4098-08 CD DOOR SPRING (L) M1X1
633 1B ✽G01-4098-08 CD DOOR SPRING (L) S3E2M2
634 1B ✽G01-4076-08 CD DOOR SPRING (R) K5P5M4
634 1B ✽G01-4076-08 CD DOOR SPRING (R) K6P6X6
634 1B ✽G01-4099-08 CD DOOR SPRING (R) E3T3M3
634 1B ✽G01-4099-08 CD DOOR SPRING (R) K9P9E7
634 1B ✽G01-4099-08 CD DOOR SPRING (R) M1X1
634 1B ✽G01-4099-08 CD DOOR SPRING (R) S3E2M2
635 3A, 3B G13-0562-08 RUBBER FOOT
- H25-1603-08 EPE FOAM BAG
-✽H50-3036-08 ITEM CARTON CASE X6
-✽H50-3038-08 ITEM CARTON CASE M1
-✽H50-3039-08 ITEM CARTON CASE X1
-✽H50-3041-08 ITEM CARTON CASE M3
-✽H50-3042-08 ITEM CARTON CASE S3
-✽H50-3043-08 ITEM CARTON CASE T3
-✽H50-3044-08 ITEM CARTON CASE E3
-✽H50-3045-08 ITEM CARTON CASE M2
-✽H50-3047-08 ITEM CARTON CASE E2
-✽H50-3050-08 ITEM CARTON CASE E7
-✽H50-3051-08 ITEM CARTON CASE K9P9
-✽H50-3053-08 ITEM CARTON CASE M4
-✽H50-3056-08 ITEM CARTON CASE K5P5
-✽H50-3057-08 ITEM CARTON CASE K6P6
637 3A J02-1185-08 CUSHION(MECHA)
641 2B ✽K27-2320-08 KNOB SIDE A
642 2B ✽K27-2321-08 KNOB SIDE B
643 3A ✽K27-2322-08 KNOB DOOR OPEN
644 3A ✽K27-2326-08 KNOB CD BUTTON D K9P9K6
644 3A ✽K27-2326-08 KNOB CD BUTTON D P5M4
644 3A ✽K27-2326-08 KNOB CD BUTTON D P6X6K5
644 3A ✽K27-2341-08 KNOB CD BUTTON D E7E3T3
644 3A ✽K27-2341-08 KNOB CD BUTTON D M2M1X1
644 3A ✽K27-2341-08 KNOB CD BUTTON D M3S3E2
645 3B ✽K27-2327-08 KNOB CD BUTTON E K9P9K6
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 2
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 1
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
DPC-UNIT
DPC-193/383(k)COVER(98.12.1410:49 y[W 9

14
PARTS LIST
DPC-193/392/393/395/692/792/793/993
645 3B ✽K27-2327-08 KNOB CD BUTTON E P5M4
645 3B ✽K27-2327-08 KNOB CD BUTTON E P6X6K5
645 3B ✽K27-2338-08 KNOB CD BUTTON E E7E3T3
645 3B ✽K27-2338-08 KNOB CD BUTTON E M2M1X1
645 3B ✽K27-2338-08 KNOB CD BUTTON E M3S3E2
A N09-3363-08 SCREW 2X10 BLACK 144-62010-112
B N09-3362-08 SCREW 2X5 BLACK
656 1A W01-0923-05 INNER H/P(SHORT) E7M4S3
656 1A W01-0925-05 INNER H/P(LONG) E2M2M3
656 1A W01-0925-05 INNER H/P(LONG) M1X1
656 1A W01-0925-05 INNER H/P(LONG) X6E3T3
657 1A W01-0924-05 HEADPHONE K5P5
657 1A W01-0943-05 HEADPHONE K6P6
657 1A W01-0947-05 HEADPHONE K9P9
659 1A W08-0657-08 AC-DC ADAPTOR K9P9K6
659 1A W08-0657-08 AC-DC ADAPTOR P6K5P5
659 1A W08-0658-08 AC-DC ADAPTOR E7E3E2
659 1A W08-0659-08 AC-DC ADAPTOR T3
659 1A W08-0660-08 AC-DC ADAPTOR X6
659 1A W08-0675-08 AC-DC ADAPTOR M4M3M2
659 1A W08-0675-08 AC-DC ADAPTOR S3
660 1A W09-1240-05 RECHARGEABLE BATTERY E7X6M4
660 1A W09-1240-05 RECHARGEABLE BATTERY M2M1X1
660 1A W09-1240-05 RECHARGEABLE BATTERY T3M3S3
661 2A W01-0921-05 CAR BATTERY ADAPTER E2M2
661 2A W01-0921-05 CAR BATTERY ADAPTER K5P5
661 2A W01-0921-05 CAR BATTERY ADAPTER K6P6X6
662 1A W01-0922-05 CAR CASSETTE ADAPTER K5P5E2
662 1A W01-0922-05 CAR CASSETTE ADAPTER K6P6X6
662 1A W01-0922-05 CAR CASSETTE ADAPTER M2
LC101 ✽B38-0171-08 LCD DISPLAY
C1 CE04CW0J101M ELECTRO 100UF 6.3WV
C2A, 3A CK73FB1E104K CHIP C 0.10UF K
C4A CK73FB1H102K CHIP C 1000PF K E2M2M1
C4A CK73FB1H102K CHIP C 1000PF K K9P9K6
C4A CK73FB1H102K CHIP C 1000PF K P5M4E3
C4A CK73FB1H102K CHIP C 1000PF K P6X6K5
C4A CK73FB1H102K CHIP C 1000PF K T3M3S3
C4A CK73FB1H102K CHIP C 1000PF K X1
C5A CK73FB1H105Z CHIP C 1.0UF Z
C6A CK73FB1E104K CHIP C 0.10UF K
C8 CE04CW1H4R7M ELECTRO 4.7UF 50WV
C9 CE04CW1C220M ELECTRO 22UF 16WV
C11A CK73FB1E223K CHIP C 0.022UF K
C103A, 104A CK73FB1E223K CHIP C 0.022UF K
C106A CC73FSL1H470J CHIP C 47PF J
C107A CC73FSL1H020C CHIP C 2.0PF C
C111A CK73FB1E104K CHIP C 0.10UF K
C112A CK73FB1E223K CHIP C 0.022UF K
C113A, 114A CK73FB1E273K CHIP C 0.027UF K
C115A CC73FSL1H151J CHIP C 150PF J
L : Scandinavia K : USA P : Canada R:Mexico C:China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V:China(Shanghai)
Y : AAFES(Europe) X : Australia Q:Russia H : Korea M:Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H:Korea M : Other Areas indicates safety critical components.
C116A CK73FB1H102K CHIP C 1000PF K K9P9K6
C116A CK73FB1H102K CHIP C 1000PF K P6K5M4
C116A CK73FB1H471K CHIP C 470PF K E3T3M3
C116A CK73FB1H471K CHIP C 470PF K E7X6P5
C116A CK73FB1H471K CHIP C 470PF K M1X1
C116A CK73FB1H471K CHIP C 470PF K S3E2M2
C117 CE04CW0J101M ELECTRO 100UF 6.3WV
C118A CK73FB1H105Z CHIP C 1.0UF Z
C120A CK73FB1H105Z CHIP C 1.0UF Z
C121A-124A CK73FB1E104K CHIP C 0.10UF K
C125A CK73FB1H105Z CHIP C 1.0UF Z
C126 CE04CW0J101M ELECTRO 100UF 6.3WV
C127 CE04CW1A470M ELECTRO 47UF 10WV
C128A CK73FB1H105Z CHIP C 1.0UF Z
C130 CC45FSL1H470J CERAMIC 47PF J
C131 CK45FB1H103Z CERAMIC 0.010UF Z
C132 CK45FB1C104K CERAMIC 0.10UF K
C133 CE04CW0J101M ELECTRO 100UF 6.3WV
C134 CC45FSL1H391J CERAMIC 390PF J
C135 CK45FB1C104K CERAMIC 0.10UF K
C136 CE04CW1H4R7M ELECTRO 4.7UF 50WV
C137A CK73FB1E104K CHIP C 0.10UF K
C138 CE04CW0J101M ELECTRO 100UF 6.3WV
C139 CE04CW1C220M ELECTRO 22UF 16WV
C140 CK45FB1H223Z CERAMIC 0.022UF Z
C144, 145 CE04CW0J221M ELECTRO 220UF 6.3WV
C146 CK45FB1H103Z CERAMIC 0.010UF Z
C147A CK73FB1H105Z CHIP C 1.0UF Z
C148 CC45FSL1H470J CERAMIC 47PF J
C150 CE04CW1C101M ELECTRO 100UF 16WV
C152 CE04CW1A470M ELECTRO 47UF 10WV
C160A CK73FB1H472K CHIP C 4700PF K K9P9K6
C160A CK73FB1H472K CHIP C 4700PF K M4
C160A CK73FB1H472K CHIP C 4700PF K P6X6K5
C161A CK73FB1H102K CHIP C 1000PF K
C162A CK73FB1H105Z CHIP C 1.0UF Z
C163A CK73FB1E223K CHIP C 0.022UF K
C164A CK73FB1H224Z CHIP C 0.22UF Z
C166 CE04CW0J221M ELECTRO 220UF 6.3WV
C167A CC73FSL1H200J CHIP C 20PF J
C168A CC73FSL1H390J CHIP C 39PF J
C169A CK73FB1H105Z CHIP C 1.0UF Z
C171 CE04CW0J101M ELECTRO 100UF 6.3WV
C172A CK73FB1H105Z CHIP C 1.0UF Z
C177A CK73FB1H105Z CHIP C 1.0UF Z
C180A CK73FB1H105Z CHIP C 1.0UF Z
C182A CK73FB1H105Z CHIP C 1.0UF Z
C184 CE04CW1A471M ELECTRO 470UF 10WV
C201A CK73FB1H272K CHIP C 2700PF K
C202 CK45FB1H301J CERAMIC 300PF J
C203, 204 CE04CW1H4R7M ELECTRO 4.7UF 50WV
C205A CK73FB1E223K CHIP C 0.022UF K
C206 CE04CW0J221M ELECTRO 220UF 6.3WV
C207A CK73FB1H224Z CHIP C 0.22UF Z
C220 CE04CW1A470M ELECTRO 47UF 10WV
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 4
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 3
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
ELECTRONICS PARTS
DPC-193/383(k)COVER(98.12.1410:49 y[W 10

15
PARTS LIST
DPC-193/392/393/395/692/792/793/993 D
C221 CK45FB1H102K CERAMIC 1000PF K K6P6X6
C221 CK45FB1H102K CERAMIC 1000PF K K9P9
C221 CK45FB1H102K CERAMIC 1000PF K M1X1M2
C221 CK45FB1H102K CERAMIC 1000PF K M4K5P5
C221 CK45FB1H102K CERAMIC 1000PF K S3T3E3
C221 CK45FB1H102K CERAMIC 1000PF K T2E2M3
C301A CK73FB1H272K CHIP C 2700PF K
C302 CK45FB1H301J CERAMIC 300PF J
C303, 304 CE04CW1H4R7M ELECTRO 4.7UF 50WV
C305A CK73FB1E223K CHIP C 0.022UF K
C306 CE04CW0J221M ELECTRO 220UF 6.3WV
C307A CK73FB1H224Z CHIP C 0.22UF Z
C320 CE04CW1A470M ELECTRO 47UF 10WV
C321 CK45FB1H102K CERAMIC 1000PF K K6P6X6
C321 CK45FB1H102K CERAMIC 1000PF K K9P9
C321 CK45FB1H102K CERAMIC 1000PF K M1X1M2
C321 CK45FB1H102K CERAMIC 1000PF K M4K5P5
C321 CK45FB1H102K CERAMIC 1000PF K S3T3E3
C321 CK45FB1H102K CERAMIC 1000PF K T2E2M3
C322 CE04KW1H4R7M ELECTRO 4.7UF 50WV E7
C501 CE04CW1C220M ELECTRO 22UF 16WV
C502A CK73FB1H105Z CHIP C 1.0UF Z
BT E35-1995-08 2P J.WIRE(BLACK/GREY)
BT1 E35-1994-08 2P J.WIRE(ORANGE/BLUE)
CN4 E60-0005-08 FILM CONNECTOR, 15P
J101 2B E03-0356-08 DC JACK
J102 2B E11-0372-08 PHONE JACK 3.6MM GREEN
J103 3B E11-0355-08 STEREO PHONE JACK S3E7M4
J105 2B E11-0354-08 LINE OUT(PHONE JACK) K6P6X6
J105 2B E11-0354-08 LINE OUT(PHONE JACK) K9P9
J105 2B E11-0354-08 LINE OUT(PHONE JACK) M1X1M2
J105 2B E11-0354-08 LINE OUT(PHONE JACK) M4K5P5
J105 2B E11-0354-08 LINE OUT(PHONE JACK) S3E2M3
L102 L33-0564-08 CHOKE COIL 33UH
L105 L33-0564-08 CHOKE COIL 33UH
L106 L33-0565-08 CHOKE COIL 95UH
X1 L77-2240-08 CRYSTAL RESONATOR 16.9344MHZ
JP15A RK73FB2A000J CHIP R 0 J 1/10W S3
JP173A RK73FB2A000J CHIP R 0 J 1/10W
R1A~3A RK73FB2A103J CHIP R 10K J 1/10W
R4A RK73FB2A563J CHIP R 56K J 1/10W K9P9K6
R4A RK73FB2A563J CHIP R 56K J 1/10W M4
R4A RK73FB2A563J CHIP R 56K J 1/10W P6X6K5
R5A RK73FB2A153J CHIP R 15K J 1/10W K9P9K6
R5A RK73FB2A153J CHIP R 15K J 1/10W P6X6K5
R7, 8 RK73FB2A473J CHIP R 47K J 1/10W E2X1
R7, 8 RK73FB2A473J CHIP R 47K J 1/10W E7P5E3
R7, 8 RK73FB2A473J CHIP R 47K J 1/10W T3M3S3
R21A RK73FB2A102J CHIP R 1.0K J 1/10W
R22A RK73FB2A472J CHIP R 4.7K J 1/10W
R23A RK73FB2A563J CHIP R 56K J 1/10W
R29A RK73FB2A682J CHIP R 6.8K J 1/10W
R30A RK73FB2A331J CHIP R 330 J 1/10W
L : Scandinavia K : USA P : Canada R:Mexico C:China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V:China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H:Korea M : Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q:Russia H:Korea M : Other Areas indicates safety critical components.
R31A RK73FB2A122J CHIP R 1.2K J 1/10W
R32A RK73FB2A152J CHIP R 1.5K J 1/10W
R33A RK73FB2A182J CHIP R 1.8K J 1/10W
R34A RK73FB2A242J CHIP R 2.4K J 1/10W
R35A RK73FB2A362J CHIP R 3.6K J 1/10W
R38A RK73FB2A101J CHIP R 100 J 1/10W S3
R38A RK73FB2A331J CHIP R 330 J 1/10W E7M4
R40A RK73FB2A100J CHIP R 10 J 1/10W
R41A, 42A RK73FB2A472J CHIP R 4.7K J 1/10W
R43A RK73FB2A103J CHIP R 10K J 1/10W
R46A RK73FB2A100J CHIP R 10 J 1/10W
R47A RK73FB2A100J CHIP R 10 J 1/10W
R48A RK73FB2A472J CHIP R 4.7K J 1/10W E7X6
R49A RK73FB2A100J CHIP R 10 J 1/10W
R51A RK73FB2A122J CHIP R 1.2K J 1/10W E7M4
R52A RK73FB2A152J CHIP R 1.5K J 1/10W E7M4
R54A RK73FB2A223J CHIP R 22K J 1/10W
R55A RK73FB2A103J CHIP R 10K J 1/10W
R56A RK73FB2A223J CHIP R 22K J 1/10W
R57A RK73FB2A224J CHIP R 220K J 1/10W
R58A RK73FB2A103J CHIP R 10K J 1/10W
R59A RK73FB2A333J CHIP R 33K J 1/10W
R60A RK73FB2A122J CHIP R 1.2K J 1/10W
R61A RK73FB2A333J CHIP R 33K J 1/10W
R66A, 67A RK73FB2A103J CHIP R 10K J 1/10W
R68A RK73FB2A473J CHIP R 47K J 1/10W E7
R69A RK73FB2A104J CHIP R 100K J 1/10W
R74A RK73FB2A682J CHIP R 6.8K J 1/10W
R75A RK73FB2A103J CHIP R 10K J 1/10W S3
R76A RK73FB2A332J CHIP R 3.3K J 1/10W S3
R95A RK73FB2A103J CHIP R 10K J 1/10W E2M1X1
R95A RK73FB2A103J CHIP R 10K J 1/10W T3M3S3
R95A RK73FB2A103J CHIP R 10K J 1/10W X6P5E3
R97A RK73FB2A222J CHIP R 2.2K J 1/10W E2M1X1
R97A RK73FB2A222J CHIP R 2.2K J 1/10W T3M3S3
R97A RK73FB2A222J CHIP R 2.2K J 1/10W X6P5E3
R109A RK73FB2A124J CHIP R 120K J 1/10W
R110A RK73FB2A333J CHIP R 33K J 1/10W
R111A RK73FB2A104J CHIP R 100K J 1/10W E7X6K5
R111A RK73FB2A104J CHIP R 100K J 1/10W M2M1X1
R111A RK73FB2A104J CHIP R 100K J 1/10W M3S3E2
R111A RK73FB2A104J CHIP R 100K J 1/10W P5E3T3
R111A RK73FB2A473J CHIP R 47K J 1/10W K9P9K6
R111A RK73FB2A473J CHIP R 47K J 1/10W P6M4
R112A RK73FB2A104J CHIP R 100K J 1/10W K9P9K6
R112A RK73FB2A104J CHIP R 100K J 1/10W P6M4
R112A RK73FB2A154J CHIP R 150K J 1/10W E7X6K5
R112A RK73FB2A154J CHIP R 150K J 1/10W M2M1X1
R112A RK73FB2A154J CHIP R 150K J 1/10W M3S3E2
R112A RK73FB2A154J CHIP R 150K J 1/10W P5E3T3
R113A RK73FB2A472J CHIP R 4.7K J 1/10W
R114A RK73FB2A682J CHIP R 6.8K J 1/10W
R115A RK73FB2A332J CHIP R 3.3K J 1/10W
R116 RK73FB2A153J CHIP R 15K J 1/10W E7X6
R119A RK73FB2A470J CHIP R 47 J 1/10W
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 6
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 5
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
DPC-193/383(k)COVER(98.12.1410:49 y[W 5

DPC-193/392/393/395/692/792/793/993
16
PARTS LIST
Y : AAFES(Europe) X : Australia Q : Russia H:Korea M : Other Areas indicates sa ety critical components.
Y : AAFES(Europe) X : Australia Q:Russia H:Korea M : Other Areas indicates sa ety critical components.
R121A RK73FB2A222J CHIP R 2.2K J 1/10W
R122A RK73FB2A223J CHIP R 22K J 1/10W
R123A RK73FB2A472J CHIP R 4.7K J 1/10W
R124A RK73FB2A223J CHIP R 22K J 1/10W
R125A RK73FB2A203J CHIP R 20K J 1/10W
R134A RK73FB2A101J CHIP R 100 J 1/10W
R136A RK73FB2A4R7J CHIP R 4.7 J 1/10W
R137A RK73FB2A152J CHIP R 1.5K J 1/10W
R138A RK73FB2A100J CHIP R 10 J 1/10W
R140A RK73FB2A474J CHIP R 470K J 1/10W
R166A RK73FB2A102J CHIP R 1.0K J 1/10W
R168A RK73FB2A103J CHIP R 10K J 1/10W E2M2X1
R168A RK73FB2A103J CHIP R 10K J 1/10W E3T3M3
R168A RK73FB2A103J CHIP R 10K J 1/10W E7X6P5
R168A RK73FB2A103J CHIP R 10K J 1/10W M1X1
R168A RK73FB2A103J CHIP R 10K J 1/10W S3E2M2
R168A RK73FB2A472J CHIP R 4.7K J 1/10W K6P6K5
R168A RK73FB2A472J CHIP R 4.7K J 1/10W M4
R169A RK73FB2A123J CHIP R 12K J 1/10W M2M1X1
R169A RK73FB2A123J CHIP R 12K J 1/10W M3S3E2
R169A RK73FB2A123J CHIP R 12K J 1/10W P5M4E3
R169A RK73FB2A123J CHIP R 12K J 1/10W P6X6K5
R169A RK73FB2A123J CHIP R 12K J 1/10W P9E7K6
R169A RK73FB2A472J CHIP R 4.7K J 1/10W K9
R170A RK73FB2A222J CHIP R 2.2K J 1/10W K9P9K6
R170A RK73FB2A222J CHIP R 2.2K J 1/10W M4M2M1
R170A RK73FB2A222J CHIP R 2.2K J 1/10W P6X6K5
R170A RK73FB2A562J CHIP R 5.6K J 1/10W E2M2X1
R170A RK73FB2A562J CHIP R 5.6K J 1/10W E7P5E3
R170A RK73FB2A562J CHIP R 5.6K J 1/10W T3M3S3
R171A RK73FB2A473J CHIP R 47K J 1/10W K9P9K6
R171A RK73FB2A473J CHIP R 47K J 1/10W P6M4
R171A RK73FB2A683J CHIP R 68K J 1/10W E7X6K5
R171A RK73FB2A683J CHIP R 68K J 1/10W M2M1X1
R171A RK73FB2A683J CHIP R 68K J 1/10W M3S3E2
R171A RK73FB2A683J CHIP R 68K J 1/10W P5E3T3
R172A RK73FB2A153J CHIP R 15K J 1/10W K5M4M2
R172A RK73FB2A153J CHIP R 15K J 1/10W K9P9P6
R172A RK73FB2A153J CHIP R 15K J 1/10W M1
R174A RK73FB2A682J CHIP R 6.8K J 1/10W
R175A RK73FB2A122J CHIP R 1.2K J 1/10W
R177A RK73FB2A683J CHIP R 68K J 1/10W
R178A RK73FB2A184J CHIP R 180K J 1/10W
R179A RK73FB2A821J CHIP R 820 J 1/10W
R180A RK73FB2A473J CHIP R 47K J 1/10W
R182A RK73FB2A471J CHIP R 470 J 1/10W E3E7M2
R182A RK73FB2A471J CHIP R 470 J 1/10W M3S3T3
R182A RK73FB2A471J CHIP R 470 J 1/10W P5K9K6
R182A RK73FB2A471J CHIP R 470 J 1/10W P6X6
R182A RK73FB2A471J CHIP R 470 J 1/10W T2E2K5
R183A RK73FB2A470J CHIP R 47 J 1/10W
R184A RK73FB2A473J CHIP R 47K J 1/10W
R189A RK73FB2A103J CHIP R 10K J 1/10W
R201A RK73FB2A102J CHIP R 1.0K J 1/10W
R202A RK73FB2A473J CHIP R 47K J 1/10W
L : Scandinavia K : USA P : Canada R:Mexico C:China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V:China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H:Korea M : Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q:Russia H:Korea M : Other Areas indicates safety critical components.
R203A RK73FB2A104J CHIP R 100K J 1/10W
R204A RK73FB2A471J CHIP R 470 J 1/10W
R206A RK73FB2A153J CHIP R 15K J 1/10W
R207A RK73FB2A564J CHIP R 560K J 1/10W
R209A RK73FB2A100J CHIP R 10 J 1/10W
R210A RK73FB2A101J CHIP R 100 J 1/10W
R211A RK73FB2A681J CHIP R 680 J 1/10W
R220A RK73FB2A302J CHIP R 3.0K J 1/10W
R221A RK73FB2A471J CHIP R 470 J 1/10W K6P6X6
R221A RK73FB2A471J CHIP R 470 J 1/10W K9P9
R221A RK73FB2A471J CHIP R 470 J 1/10W M1X1M2
R221A RK73FB2A471J CHIP R 470 J 1/10W M4K5P5
R221A RK73FB2A471J CHIP R 470 J 1/10W S3T3E3
R221A RK73FB2A471J CHIP R 470 J 1/10W T2E2M3
R222A RK73FB2A472J CHIP R 4.7K J 1/10W
R301A RK73FB2A102J CHIP R 1.0K J 1/10W
R302A RK73FB2A473J CHIP R 47K J 1/10W
R303A RK73FB2A104J CHIP R 100K J 1/10W
R304A RK73FB2A471J CHIP R 470 J 1/10W
R306A RK73FB2A153J CHIP R 15K J 1/10W
R307A RK73FB2A564J CHIP R 560K J 1/10W
R309A RK73FB2A100J CHIP R 10 J 1/10W
R310A RK73FB2A101J CHIP R 100 J 1/10W
R311A RK73FB2A681J CHIP R 680 J 1/10W
R320A RK73FB2A302J CHIP R 3.0K J 1/10W
R321A RK73FB2A471J CHIP R 470 J 1/10W
R322A RK73FB2A472J CHIP R 4.7K J 1/10W
R501A RK73FB2A333J CHIP R 33K J 1/10W
R502A RK73FB2A333J CHIP R 33K J 1/10W
R504A RK73FB2A184J CHIP R 180K J 1/10W
R505A RK73FB2A472J CHIP R 4.7K J 1/10W
VR101 R31-0086-08 VARIABLE RESISTOR
SW101~103 ✽S70-0066-08 TACT SWITCH
SW104 ✽S70-0062-08 TACT SWITCH
SW105 ✽S70-0066-08 TACT SWITCH
SW106 ✽S70-0062-08 TACT SWITCH
SW107 ✽S62-0081-08 SLIDE SWITCH
SW108 ✽S62-0064-08 SWITCH E2
SW108 ✽S62-0064-08 SWITCH S3M4T2
SW108 ✽S62-0064-08 SWITCH T3E3M3
SW108 ✽S62-0084-08 SWITCH E7K5P5
SW108 ✽S62-0084-08 SWITCH K9P9K6
SW108 ✽S62-0084-08 SWITCH P6X6M6
SW109 ✽S74-0084-08 MICRO SWITCH
D104 SB10-03A3-BT DIODE
D105 GMB01-BT DIODE
D111, 112 IN-4001 DIODE
D115, 116 GMB01-BT DIODE
D117 GMB01-BT DIODE S3E7M4
D118 1SS355 DIODE S3E7M4
D122A 1SS355 DIODE
D201 GMB01-BT DIODE
D301 GMB01-BT DIODE
IC1 ✽AN8838SB IC(CD DIGITAL SERVO)
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 8
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 7
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
DPC-193/383(k)COVER(98.12.1410:49 y[W 6

DPC-193/392/393/395/692/792/793/993
17
PARTS LIST
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q:Russia H:Korea M : Other Areas indicates safety critical components.
IC2 ✽AN8789FB IC
IC3 ✽MN101C167 IC
IC4 ✽MN662746RPK1 IC
IC5 SM5859AF IC
IC6 MN41V17400CTT6 IC E7K5P5
IC6 MN41V17400CTT6 IC K9P9K6
IC6 MN41V17400CTT6 IC P6X6
IC7 MN41V4400SJ-08 IC M2E2M3
IC7 MN41V4400SJ-08 IC S3T3E3
IC7 MN41V4400SJ-08 IC M4
IC8 MN41V4400SJ-09 IC M2E2M4
IC9 NJM2073M IC(AF POWER AMP)
Q4 2SC3330 TRANSISTOR
Q5 2SA1317 TRANSISTOR
Q6 2SC3330 TRANSISTOR
Q102 2SB598F TRANSISTOR
Q104 2SA1317 TRANSISTOR
Q105 2SC4048-AC TRANSISTOR
Q106 2SC4481T TRANSISTOR
Q107 2SD734F TRANSISTOR
Q108 2SD1805F TRANSISTOR
Q108 2SD1805G TRANSISTOR
Q110 2SA1317 TRANSISTOR
Q111, 112 2SB926T TRANSISTOR
Q113 2SA1317 TRANSISTOR S3
Q115 2SC4048-AC TRANSISTOR
Q116 ✽2SA1564-AC TRANSISTOR
Q201 2SC3330 TRANSISTOR
Q202 2SD734F TRANSISTOR
Q203 2SC3860 TRANSISTOR K6P6X6
Q203 2SC3860 TRANSISTOR K9P9
Q203 2SC3860 TRANSISTOR M1X1M2
Q203 2SC3860 TRANSISTOR M4K5P5
Q203 2SC3860 TRANSISTOR S3T3E3
Q203 2SC3860 TRANSISTOR T2E2M3
Q205 2SC3860 TRANSISTOR
Q301 2SC3330 TRANSISTOR
Q302 2SD734F TRANSISTOR
Q303 2SC3860 TRANSISTOR K6P6X6
Q303 2SC3860 TRANSISTOR K9P9
Q303 2SC3860 TRANSISTOR M1X1M2
Q303 2SC3860 TRANSISTOR M4K5P5
Q303 2SC3860 TRANSISTOR S3T3E3
Q303 2SC3860 TRANSISTOR T2E2M3
Q304 2SC3330 TRANSISTOR E7
Q305 2SC3860 TRANSISTOR
J104 W02-2630-08 OPTICAL OUT 3.6MM GREEN E7
✽New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. 9
Ref. No Add-
ress
New
Parts
Parts No. Description Desti-
nation Re-
marks
MODEL ABB. Australia Canada China England Europe Germany Korea Malaysia
DPC-193 - X1 -------
DPC-392 - ----E2---
DPC-393 - - - - T3 E3 - - -
DPC-395 - --------
DPC-692 - - P5 ------
DPC-792 - X6 P6 ------
DPC-793 - ----E7---
DPC-795 - --------
DPC-993 - - P9 ------
MODEL ABB. Mexico PX/AAFES Russia Scandinavia Shanghai USA Other area Other area(M2)
DPC-193 - ------M1-
DPC-392 - ------M2-
DPC-393 - ------M3S3
DPC-395 - ------M4-
DPC-692 - -----K5--
DPC-792 - -----K6--
DPC-793 - --------
DPC-795 - --------
DPC-993 - -----K9--
HOW TO READ THE PARTS LIST
ABBREVIATION OF MODEL AND MASS PRODUCTION'S DESTINATIONS
DPC-193/383(k)COVER(98.12.1410:49 y[W 4

DPC-193/392/393/395/692/792/793/993
14-6,Dogenzaka 1-chome, Shibuya-ku, Tokyo, 150-8501 Japan
KENWOOD SERVICE CORPORATION
P.O BOX 22745, 2201 East Dominguez St., Long Beach, CA 90801-5745, U.S.A.
KENWOOD ELECTRONICS CANADA INC.
6070 Kestrel Road, Mississauga, Ontario, Canada L5T 1S8
KENWOOD ELECTRONICS LATIN AMERICA S.A.
P.OBOX 55-2791,Piso6 plazaChase, Cl.47y Aquilinodela GuardiaPanama,Republic dePanama
KENWOOD ELECTRONICS BRASIL LTDA.
Av Indianópolis, 628, 04062-001 Planalto Paullsta São Paulo-SP-Brasil
KENWOOD ELECTRONICS U.K. LIMITED
KENWOOD House, Dwight Road, Watford, Herts., WD1 8EB., United Kingdom
KENWOOD ELECTRONICS BELGUM N.V.
Meachelsesteenweg 418, B-1930 Zaventem, Belgium
KENWOOD ELECTRONICS DEUTSCHLAND GMBH
Rembrücker Str. 15, 63150 Heusenstamm, Germany
KENWOOD ELECTRONICS FRANCE S.A.
13 Boulevard Ney, 75018 Paris, France
KENWOOD ELECTRONICS ITALIA S.p.A.
Via G. Sirtori, 7/9 20129, Milano, ltaly
KENWOOD IBÉRICA S.A.
Bolivia, 239-08020 Barcelona, Spain
KENWOOD ELECTRONICS AUSTRALIA PTY. LTD.
(A.C.N. 001499 074)
P.O Box 504, 8 Figtree Drive, Australia Centre, Homebush, N.S.W. 2140, Australia
KENWOOD & LEE ELECTRONICS, LTD.
Unit 3712-3724, Level 37, Tower 1, Metroplaza, 223 Hing Fong Road, Kwai Fong N.T., Hong Kong
KENWOOD ELECTRONICS GULF FZE
P.O.Box 61318, Jebel Ali, Dubai, U.A.E.
KENWOOD ELECTRONICS SINGAPORE PTE LTD.
No. 1 Genting Lane #02-02, KENWOOD Building, Singapore, 349544
KENWOOD ELECTRONICS (MALAYSIA) SDN BHD.
#4.01 Level 4, Wisma Academy Lot 4A, Jalan 19/1 46300 Petaling Jaya Selangor Darul Ehsan
Malaysia
KENWOOD ELECTRONICS (THAILAND) CO., LTD.
573/111 Soi Ramkhamhaeng 39, Ramkhamhaeng Road, Wangthonglang, Bangkapi, Bankok
10301 Thailand
Note:
Component and circuit are subject to modification to insure best
operation under differing local conditions. This manual is based on
Europe (E) standard, and provides information on regional circuit
modification through use of alternate schematic diagrams, and infor-
mation on regional component variations through use of parts list.
DPC-193/383(k)COVER(98.12.1410:49 y[W 1
