CD RECEIVER
KDC-MP5033U
KDC-MP532U
KDC-W534UA/UAY/UG/UGY
KDC-W5534U/UY
SERVICE MANUAL
* Depends on the model. Refer to the parts list.
Panel assy
KDC-MP5033U (A64-3765-11) Panel assy
KDC-MP532U (A64-3764-11)
Mounting hardware assy
(J22-0011-03)
Lever
(D10-4589-04) x2
* DC cord
(E30-6414-05)
* Screw set
(N99-1757-05)
* Escutcheon
(B07-xxxx-xx) SPARE TDF PANEL
MAIN UNIT NAME TDF PARTS No. TDF NAME
KDC-MP5033U Y33-2540-65 TDF-MP5033U
KDC-MP532U Y33-2540-64 TDF-MP65D
KDC-W534UA/UAY Y33-2540-67 TDF-W534UA
KDC-W534UG/UGY Y33-2540-68 TDF-W534UG
* Carrying case
(W01-1661-05)
* DC cord
(E30-6413-05)
* Antenna adaptor
(T90-0523-05) * Plastic cabinet assy
(A02-2743-03)
* Remote controller assy (RC-517)
(A70-2069-15)
Battery
(Not supplied)
Panel assy
KDC-W534Uxxx (A64-3757-11) Panel assy
KDC-W5534U/UY (A64-3766-11)
Mounting hardware (R)
(J22-0259-04)
Mounting hardware (L)
(J22-0258-04)
Screw set
(N99-1780-05)
KDC-W5534U/UY Y33-2540-66 TDF-W5534U
CD MECHANISM EXTENSION CORD (30P) : E39-0812-05
VOL
AUD
SET UP
SCAN REP
Q MENU
M.RDMF.SEL
KDC-MP532U
FF
AM
FM
SCRL
AUTO
AME
A.RDM
RDM
/ C.S.
DISP
USB
VOL
AUD
SET UP
SCAN
USB
A.RDM
RDM REP
Q MENU
F.SEL
KDC-W534U
FF
AM
FM
SCRL
TI
AME
/ PTY
DISP
M.RDM
AUTO
AME
VOL
AUD
SET UP
SCAN
USB
A.RDM
RDM REP
Q MENU
F.SEL
KDC-MP5033U
FF
AM
FM
SCRL
M.RDMA.RDM
RDM
TI
AME
VOL
AUD
SET UP
SCAN REP
Q MENU
F.SEL
KDC-W5534U
FF
AM
FM
SCRL
/ PTY
DISP
USB
This product uses Lead Free solder.

2
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
BLOCK DIAGRAM
(X16- )
SWITCH UNIT
ELECTRIC UNIT (X34- )
DIMMER
Q53
Q501
AGC
AM
Q502
FM
AGC E-VOL
TUNER & MPX
IC10
DECODER
RDS
IC400
CURRENT
PROTECT
IC3 E2P
ROM
IC103
EJECT
KEY
S102
S3
SW
RESET
ROTARY
ENCODER
S1
KEY MATRIX
KEY KEY
ILLUMI
IC2
REMOTE
VFD
ED1
FLIP DET
S101 D111
DSI
Q101
5V
PANEL
Q4,5
SERVO
+B
Q1,2
CD 5V
IC2
IC102
IC
RESET
Q54
ACC DET
Q52
D58,C58,R68
TEL MUTE
B.U. DET
SURGE DET
Q51
Q105
DRIVER
MUTE DC OFFSET
DETECTOR
Q205
POWER
IC
IC201
Q251,252
MUTE
PRE
CD
&
USB
BU5V
SW5
A8V
BU5V
A8V
SERVO
CD5V
LX BUS
DME1
J4
BU
BU5V
u-COM
ANT
J2 AM+B
IC101
SERVO
CD5V
CD
IC1
A8V
AM+B
VFD REG
BU5V
BACK UP
USB (D+,D-)
USB (5V,GND)
PREOUT (NF/REAR)
PREOUT (FRONT)
SP OUT (FR)
BACK UP
LINE MUTE
ACC
DIMMER
WIRED REMOTE
ANT CON
P CON
SP OUT (FL)
SP OUT (RL)
SP OUT (RR)
(E-TYPE ONLY)
CN2
J1
PANEL
MPX OUT MPX IN
USB
S.OUT
CD CH I2C
I2C
CNT
CD5V
S.OUT
FRONT/
NF
REAR
MUTE
DC ERR
ACC
DIMMER
TEL MUTE
DET
B.U.
RST
STBY
I2C
RST
P-CON
P-ANT
ILLUMI
AM+B
AUDIO+B
BU5V VCC

3
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
BLOCK DIAGRAM
CD PLAYER UNIT (X32-5830-00)
TR COIL
FO COIL
C
F
AB
E
PD
LD
SERVO DSP
MOTOR
DRIVER
SP MOTOR
LOADING &
MOTOR
SLED
IC4
IC2
u-COM
IC1
IC15
IC5
SW3.3V
3V REG
IC21
1.8V REG
IC20
IC19
BU3.3V REG
IC14
A5V REG
DAC
3.3 5V
LPF
IC18
IC13
64Mbit
SDRAM
IC16
MEMORY
FLASH
IC17
8Mbit
D5V (D4V)
S7.5V
A8V
BU5V
AUDIO DSP
DM2
DM1
DPU1 Q7
(SW3.3V)
S4
ONLY
0-01
S2
S1
S3
(BU5V)
3.3
Q6 5V
RESISTOR
3.3
R6,8 5V
(BU5V)
Q3
3.3 5V
3-STATE
BUFFER
IC28
GATE
NAND
IC26
DRIVER
USB
IC25
to X34-
16.893MHz
SW3.3V
S7.5V
RESET
SCK
SI
STB
A0
SO
INTQ
POWER ON 11.500MHz BU3.3V
D5V CKO
SW3.3V
CS3.3V
CS1.8V
POWER
BU3.3V
SW A5V
BU5V
A8V
SER2 (3/4WIRE)
LOE/LIM-
8EJE-SW
LOS-SW
12EJE-SW
AUDIO Lch
CS3.3V
CONTROLLER
MEMORY
CS3.3V CS3.3V
SW A5V
I2S
CD I/F
CS3.3V
CS1.8V
&
CS POWER
CS POWER
X1
DA EMPH
I2CDATA
I2CCLK
MRESET
MSTOP
AUDIO MUTE
EMPH
INFINITY 0 DET.
CSRST
S DATA DATA MUTE B DATA CLK SREQ BREQ CS EMPH
DAC RST
DAC MUTE
PCM XCK
PCM DATA
PCM LRCK
PCM BCLK AUDIO Rch
SW A8V
CS3.3V
DATA
LRCK
BCLK
C16 PLL
CS, A20 CS3.3V
CS3.3V USB CS
X2
6.00MHz
X3
USB D+
USB D-
OC
PO
CSRST UHC124
BU3.3V
IC19
u-COM
IC1
MECHA-
(CS1.8V)
CS3.3V
IC20,21
CONNECTOR
USB HOST
IC25
LFP
IC13
DAC
IC18
IC15
DSP
CN1 CN1
BU5V
Q1,2
u-COM
SESTEM
IC101
IC3
SWITCH
HIGH-SIDE
E-VOL
IC10
IC2
SW-REG.
5V
CONTROLLER
CONNECTOR
CN2
CONNECTOR
USB
AUDIO LINE
USB LINE
CSRST
RESET
INT
BU14V
MSTOP
BU5V
D5V
POWER ON SW
OVER CURRENT
USB D-
USB D+
Rch
Lch
P-ON P-ON
(V-BUS 5V)
USB 5V
USB D+
USB D-
USB GND
CABLE
CD PLAYER UNIT (X32-) ELECTRIC UNIT (X34-)

4
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
COMPONENTS DESCRIPTION
●ELECTRIC UNIT (X34-412x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 Power Supply IC DC5V x 1, 7.9V x 1, 8.1V x 2, 10.2V x 1, P-CON, P-ANT output.
IC2 Power Supply IC DC5V for CD mechanism unit and USB.
IC3 Hi-side SW USB5V on when the pin 1 goes “Hi”.
IC10 E-VOL & Tuner E-VOL, Tuner, Stereo decoder.
IC101 System µ-COM Controls system.
IC102 Reset IC “Lo” when detection voltage is below 3.6V.
IC103 E2PROM Saves and loads for tuner adjustment data.
IC201 Power IC Amplifies signal.
IC400 RDS Decoder Decodes RDS.
Q1 SERVO+B AVR Darlington connection with Q2. (Current buffer)
Q2 SERVO+B AVR Outputs 7.5V.
Q3 14V SW “ON” when the base goes “Hi”.
Q4 VFD+B & LED AVR Darlington connection with Q5. (Current buffer)
Q5 VFD+B & LED AVR Outputs 11V.
Q6 VFD+B & LED SW “ON” when the base goes “Hi”.
Q7 Non Back Up 5V SW “ON” when the base goes “Lo”.
Q8 Control SW for IC1
Q9 Serge Protect for IC2 Darlington connection with Q5.(Current buffer)
Q10 Serge Protect for IC2 Outputs 15V when back up voltage is over 16V.
Q11 Control SW for IC2 IC2 turns on when the base goes “Lo”.
Q12 FL FIL Voltage SW FL FIL voltage ON/OFF SW.
Q13 Control SW for Q12 Q12 turn on when the base goes “Hi”.
Q51 Serge DET “ON” when the base goes “Hi”.
Q52 BU DET “ON” when the base goes “Hi” during BU is applied.
Q53 ILLUMI SW “ON” when the base goes “Hi”.
Q54 ACC DET “ON” when the base goes “Hi” during ACC is applied.
Q101 PANEL5V SW “ON” when the base goes “Lo”.
Q102 Control SW for D111 D111 is ON when the base goes “Hi”.
Q103,104 Mute Control “ON” when the base goes “Hi”.
Q105 Mute Driver for Preout “ON” when the base goes “Lo”.
Q201,202 DC Offset DET SW “ON” when the base goes “Lo”.(At that time, IC201’s SP-OUT DC is
separated)
Q203 DC Offset DET “ON”when the base goes “Hi”. (At that time, Q201 and Q202’s outputs
are separated)
Q204 SVR Discharge IC201’s pin 10 discharges when the base goes “Hi”.
Q251 Mute SW for Lch Preout Pre-output is muted when the base goes “Hi”.
Q252 Mute SW for Rch Preout Pre-output is muted when the base goes “Hi”.
Q400 Buffer IC10 QUAL output buffer.
Q501 AM RF Amplifier Adjusts for gain.
Q502 FM RF Amplifier Amplifies RF.
Q503,504 AFS Control Controls AFS time.

5
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
● SWITCH UNIT (X16-373x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC2 Remote Control IC
Q4,5 SW5V The power supply of IC2 is turned on when Q5’s base level goes “Hi”.
Q10 GREEN SW When the base goes “Hi”, LED lights.
Q12~14 Grid Driver Each grid is ON when each transistor’s base is “Lo”.
Q15 RED SW When the base goes “Hi”, LED lights.
Q20 Key Scan Start SW Key scan starts when the base goes “Hi”.
●DAUGHTER UNIT (X89-2902-70): KDC-MP5033U/MP532U/W5534U/W5534UY only
Ref. No. Application / Function Operation / Condition / Compatibility
Q221,222 2-PREOUT MUTE “ON” when the base goes “H”.
Q225 2-PREOUT MUTE “ON” when the base goes “H”.
● CD PLAYER UNIT (X32-5830-00)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 Mechanism µ-COM
IC2 Signal Processor
IC4 BTL Driver Spindel motor, sled (including loading & eject) motor and pick-up actuator
IC5 SW3.3V Regulator 3.3V power supply for IC2, pick-up, IC18 digital part
IC13 Audio Active Filter 2nd LPF
IC14 A5V Regulator 3.3V power supply for DAC
IC15 DSP for Compression Audio Decoder ACDrive decoder, MP3/WMA/AAC decoder
IC16 Compression Audio Codec SDRAM
IC17 Decoder Software & Unique ID Strage Flash ROM
IC18 Audio D-A Converter (24-bit external) External 24-bit for audio
IC19 BU3.3V Regulator 3.3V power supply for µ-com
IC20 1.8V Regulator 1.8V power supply for IC15 core part
IC21 Decoder/SDRAM/Flash ROM/USB Driver 3.3V Power supply for decoder, SDRAM, flash ROM and USB driver.
Regulator 3.3V power supply for IC15 port parts, IC16, IC17, IC25, IC26 and IC28.
IC25 USB Host Controller
IC26 Switching among IC15 & Flash ROM & SDRAM & USB For DSP for Compression Audio Decoder, Flash ROM, SDRAM and USB
IC28 Clock SW To SDRAM
Q3 Level Shift 3.3V→5V
Q6,7 Level Shift 3.3V←5V
Q8 APC (Auto Power Control)
Q9,10 Anticipation Sub-beam Delay During non-searching
Q16 Logic Inverter µ-com “ZERO” terminal
Q17 USB Hi-side SW
D2 Static Electricity Countermeasure For IC2 built-in reset terminal
D3 Laser Diode Protection
D9 Static Electricity Countermeasure
COMPONENTS DESCRIPTION

6
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
●SYSTEM µ-COM: IC101 on X34- (ELECTRIC UNIT)
Pin No. Pin Name I/O Application Truth Processing / Operation / Description
ValueTable
1ACC DET I ACC power supply detection L: ACC found, H: No ACC
2BU DET I Momentary power down detection L: BU found, H:No BU or momentary power down
3ILLUMI DET I Dimmer illumination detection L: ON, H: OFF
4 REMO I Remote control signal input Detects pulse width
5NC-Not used Output L fixed
6BYTE -
7CNVSS -
8 XCIN I 32.768kHz
9XCOUT I 32.768kHz
10 RESET -
11 XOUT - 12.0MHz
12 VSS -
13 XIN - 12.0MHz
14 VCC1 -
15 NMI - Not used
16 CN DET I Panel communication detection H: Panel opened, L:Panel closed
17 RDS CLK I RDS decoder clock input
18 LX REQ S I Communication request from slave unit
19 AUD MUTE O Mute control for IC10 and preout
20 PWIC STBY O Power IC standby control H: POWER ON, L: POWER OFF
21 PWIC SVR O SVR discharge circuit SVR discharge circuit
22 PWIC MUTE O Power IC mute STANDBY source or momentary power down: L
TEL mute: L
23 LX REQ M O Communication request to slave unit
24 LX CON O Start-up request to slave unit H: Slave unit starts up, L: Slave unit stops
25 LX RST O Fouced reset to slave unit H: Reset, L: Normal
26 PWIC BEEP O Beep output
27 TUN SCL I/O Front-end I2C clock input and output MAX400kHz
28 TUN SDA I/O Front-end I2C data input and output
29 VFD DATA I/O VFD data input and output Data input and output
30 VFD INT I VFD INT input INT input
31 VFD CLK O VFD clock output 125kHz
H: Reset cancelled, L: Reset
32 VFD RST O VFD driver reset L: Momentary power down, panel detached or 11
minutes after ACC OFF
33 LX DATA M I/O Data to slave unit
34 LX DATA S I Data from slave unit
35 LX CLK I/O LX-BUS clock
36 VFD KEY REQ I Communication request from VFD driver Connects to INT
H: Normal, L: FM/AM seek or AF search
37 RDS AFS L 2 O RDS mute output q(L:Tuner SRC or Auto Zero)
*Same process as RDS AFS L (Pin 38)
38 RDS AFS L O RDS mute output qH: Normal, L: FM/AM seek or AF search
(L:Tuner SRC or Auto Zero)
MICROCOMPUTER’STERMINAL DESCRIPTION

7
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
Pin No. Pin Name I/O Application Truth Processing / Operation / Description
Value Table
39 EPM I Flash EPM input
40 TUN SD I Search stop input H: Station found, L:No station
41 TUN FANC OUT O Tuner block (in µ-com) check H: E2P OK in test mode, L: E2P NG in test mode
L: Normal
42 TUN ADJ I E2PROM writing request and IC10 adjustment E2PROM writing at ADJ=H
43 NC - Not used Output L fixed
44 VFD CE O VFD chip select control
45 RDS QUAL I RDS decoder QUAL input
46 RDS DATA I RDS decoder data input
47,48 NC - Not used Output L fixed
49 DSI I/O DSI/EJECT LED control OFF: Hi-z, Pulse drive: Panel detached
H: Illumination ON or panel opened (POWER ON)
50 EJECT I Eject key input L: Eject
51 ENC CCW I Encoder input (Counterclockwise) Detects pulse width
52 ENC CW I Encoder input (Clockwise) Detects pulse width
53 PON PANEL I/O Panel 5V control L: ON, Hi-Z: Momentary power down, panel detached
or 11 minutes after ACC OFF
54~59 NC - Not used Output L fixed
60 VCC2 -
61 PON 5V O SW5V control L: POWER ON, H: POWER OFF
62 VSS -
63 CD DISC12 SW I 12cm CD detection
64 CD LOS SW I CD loading detection
65 CD SCL I/O CD mechanism I2C clock output
66 CD SDA I/O CD mechanism I2C data input and output
67 CD MUTE I CD mute request H: Normal, L: Mute request
(CD playing time only)
68 CD MRST O CD mechanism µ-com reset H: Normal, L: Reset
69 CD MSTOP O CD mechanism µ-com stop H: Mechanism µ-com operates
L: Mechanism µ-com stops
70 CD DISC8 SW I 8cm CD detection (Not used)
71 CD LOE LIM SW I CD detection (Chucking SW) H: Loading completes, L:No disc
72 CD LOEJ I/O CD motor control wRefer to the truth value table
73 CD MOTOR O CD motor control wRefer to the truth value table
74 PANEL DET I Panel detection L: No panel, H: Panel attached
75~77 NC - Not used Output L fixed
78 TUN TYPE2 I Destination setting eRefer to the truth value table
79 TUN TYPE1 I Destination setting eRefer to the truth value table
80 RDS NOISE I FM noise detection
81 TUN SMETER I S-meter input
82 TYPE 3 I Destination SW rRefer to the truth value table
83 TYPE 2 I Destination SW rRefer to the truth value table
84 TYPE 1 I Destination SW rRefer to the truth value table
85 LINE MUTE I Line mute detection TEL mute: Below 1V , NAVI mute: Over 2.5V
MICROCOMPUTER’STERMINAL DESCRIPTION

8
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
Pin No. Pin Name I/O Application Truth Processing / Operation / Description
ValueTable
If DC offset is found 10 times in 100m seconds with
86 PWIC DC DET I DC offset detection condition of over 1.0V, it will be judged as DC offset
detected.
87 PON CD O Power supply for CD mechanism and USB L: POWER ON, H: POWER OFF
88 NC - Not used Output L fixed
89 PON FL O FL+B control H: FL+B ON, L: FL+B OFF
90 PS1 3 O Power supply IC (IC1) control 1-3 tRefer to the truth value table
91 PS1 2 O Power supply IC (IC1) control 1-2 tRefer to the truth value table
92 PS1 1 O Power supply IC (IC1) control 1-1 tRefer to the truth value table
93 PS2 2 O Power supply IC (IC1) control 2-2 tRefer to the truth value table
94 AVSS -
95 REF CON O VREF control Connects to VREF
96 VREF -
97 AVCC - Connects to VCC
98 PS2 1 O Power supply IC (IC1) control 2-1 tRefer to the truth value table
99,100 NC - Not used Output L fixed
tPOWER SUPPLY IC (IC1) CONTROL
SW1 (Pin 10)
PS1-1 PS1-2 PS1-3 AUDIO P-CON P-ANT
LLLOFF OFF OFF
HLLONOFF OFF
LHLONOFF OFF
HHHONONON
Truth value table
qAFS CONTROL
RDS AFS L Condition
AFS LOW L No sound output with AF search
AFS MID Hi-Z Sound output with AF search
AFS HIGH Hi-Z Normal reception
wCD MOTOR CONTROL
CD MOTOR CD LOADING/EJECT
Stop L L
Load H L
Eject H H
Brake H Hi-z
eTUNER TYPE
TUN TYPE1 TUN TYPE2
(Pin 79) (Pin 78)
Kenwood brand model L L
OEM model 1 L H
OEM model 2 H L
OEM model 3 H H
rDESTINATION SW
TYPE 1 TYPE 2 TYPE 3 DESTI-
MODEL
(Pin 84) (Pin 83) (Pin 82) NATION
LHLEKDC-W5534U/UY
HHLEKDC-W534UA/UAY/UG/UGY
LLLKKDC-MP532U
HLHMKDC-MP5033U
HHHJU515
SW2 (Pin 11)
PS2-1 PS2-2 ILLUMI FM AM
LLOFF OFF OFF
HLONON OFF
HHONON ON
MICROCOMPUTER’STERMINAL DESCRIPTION

9
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
MICROCOMPUTER’STERMINAL DESCRIPTION
●MECHANISM µ-COM: IC1 (X32-: CD PLAYER UNIT)
Pin No. Pin Name I/O Application Processing / Operation / Description
1~5 NC - Not used Opened output L fixed
6BYTE I External data bus SW input Connects to GND
7CNVSS I Processor mode SW L: Single chip mode
H: Microprocessor mode or flash ROM writing
8MUTE O Audio mute control L: Mute ON, H: Mute OFF
9NC-Not used Opened output L fixed
10 RESET I Reset detection L: Reset (Flash ROM writing), H: Normal
11 XOUT O Main clock output Connects to resonator
12 VSS - Power supply input Connects to GND
13 XIN I Main clock input Connects to resonator
14 VCC1 - Power supply input Connects to BU3.3V
15 NMI I NMI interruption input Input Hi (Pull-up) fixed
16 MSTOP I STANDBY comeback interrupption L: Stop, H: Stop cancelled (Hi edge)
17 NC - Not used Opened output L fixed
18 DSP INT I DSP interruption signal input H: Interruption (Hi edge)
19~22 NC - Not used Opened output L fixed
23 E2P SCL I/O E2P I2C clock output Series resistors and E2PROM are not built when
ROM collection is not used.
24 E2P SDA I/O E2P I2C data input and output Series resistors and E2PROM are not built when
ROM collection is not used.
25,26 NC - Not used Opened output L fixed
27 SCL I System µ-com I2C clock input
28 SDA I/O System µ-com I2C data input and output
29 DSP TXD O Data output for DSP serial data Flash ROM writing:TXD (Pull-up)
30 DSP RXD I Data input for DSP serial data Flash ROM writing: RXD
31 DSP CLK O Clock output for DSP serial data Flash ROM writing: SCLK (Pull-up)
32 DSP STB (BUSY) ODSP data strove signal output Flash ROM writing: BUSY
33 CS SDATA O Data output for decoder serial data
34 CS BDATA I Data input for decoder serial data
35 CS CLK O Clock output for decoder serial data
36~38 NC - Not used Opened output L fixed
39 EPM - Not used (Flash ROM: EPM) Opened output L fixed
40 PON D3.3 O D3.3V POWER ON control H: POWER ON, L: POWER OFF
41 PON A5 O A5.0V POWER ON control H: POWER ON, L: POWER OFF
42 PON CS1 O IC15 series 3.3V POWER ON control H:POWER ON, L: POWER OFF
43 PON CS2 O IC15 series 1.8V POWER ON control H:POWER ON, L: POWER OFF
44 CE - Not used (Flash ROM: CE) Opened output L fixed
45 DRV MUTE O Driver mute L: Stop, H:Mute OFF
46,47 NC - Not used Opened output L fixed
48 ZERO M I 0-bit mute detection H: Mute ON, L: Mute OFF
(No distinction of Lch/Rch)
49 DE-EMPHASIS O DAC de-emphasis control H: De-emphasis ON, L: De-emphasis OFF
50,51 NC - Not used Opened output L fixed
52 LIM SW I Laser pick-up inner circumference detection H: Inner circumference
SW signal input

10
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
Pin No. Pin Name I/O Application Processing / Operation / Description
53 DISC NORMAL O Media discrimination result output (Not used) H: Normal disc, L: Other disc
54 DISC H RW O Media discrimination result output (Not used) H: High reflecting RW disc, L: Other disc
55 DISC RW O Media discrimination result output (Not used) H: Normal RW disc, L: Other disc
56 TEST OUT4 O Output for test Opened output L fixed
57 TEST OUT3 O Output for test Opened output L fixed
58 TEST OUT2 O Output for test Opened output L fixed
59 TEST OUT1 O Output for test Opened output L fixed
60 VCC2 - Power supply input Connects to BU3.3V
61 TEST OUT0 O Output for test Opened output L fixed
62 VSS - Power supply input Connects to GND
63~66 NC - Not used Opened output L fixed
67 TEST IN3 I TEST IN3 Pull-down connection (L: Normal/H: During test)
68 MODEL SEL I Model determination L: DXM-6810W (X32-583), H: DXM-6820W (X32-587)
69 E2P WRITE I TEST IN1: E2P writing permission Pull-down connection (L: Normal/H: During writing)
70 UNIQ ID I TEST IN0: Uniqe ID writing permission Pull-down connection (L: Normal/H: During writing)
71~73 NC - Not used Opened output L fixed
74 SEARCH O Searching situation output H: During seaching, L: Normal
75,76 NC - Not used Opened output L fixed
77 DSP RST O DSP reset control L: Reset, H:Normal
78 DSP A0 O DSP command/parameter discrimination signal H: During parameter transmitting
output L: During command transmitting
79 DA EMPHASIS I DSP DA emphasis input H: emphasis ON, L: emphasis OFF
80 ROM EMPHASIS IDecoder ROM emphasis input H: emphasis ON, L: emphasis OFF
81 DATA MUTE O Data output status L: During data output muting, H:During data output
82 CS RST O Decoder reset control L: Reset, H: Nornal
83 NC - Not used Opened output L fixed
84 SREQ O Decoder SREQ signal output
85 BREQ I Decoder BREQ signal input
86~93 NC - Not used Opened output L fixed
94 AVSS - Analog power supply input Connects to GND
95 NC - Not used Opened output L fixed
96 VREF - Reference voltage input Not used: Connects to GND
97 AVCC - Analog power supply input Connects to BU3.3V
98~100 NC - Not used Opened output L fixed
MICROCOMPUTER’STERMINAL DESCRIPTION

11
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
●How to enter the test mode
Press and hold the [1] and [3] keys and reset.
(While “– – – –” is being displayed, power can be ON for 30
minutes.)
●How to clear the test mode
Reset, momentary power down, Acc OFF, Power OFF, detach
the panel.
●Test mode default condition
• Source is STANDBY.
• Display lights are all turned on.
• The volume is at -10dB (The display is 30).
• LOUD is OFF.
• CRSC is off regardless of the availability of switching func-
tion.
• SYSTEM Q is NATURAL (=FLAT).
• BEEP should always function when the key is pressed.
• TUNER mode [4] key frequency shall be 98.3MHz.
●RDS automatic measurement
Conventionally, the PS display has been visually checked on
the production line. This will be replaced by a new processing.
The PS data will be received and the PS contents is to be
verified as “RDS_TEST”. When this is verified, the P-CON
terminal is forced to go OFF.(In this case, “ _ ”means blank.)
→This will be a dedicated test mode processing.
On the P-CON, when power is turned off once and, then,
turned on again, (Power OFF →ON) the unit will be re-
started.
●CD receiver test mode specification
• Display mode default setting shall be P-TIME.
• Jumps to the following tracks by pressing the [ ] key.
No. 9 →No. 15 →No. 10 →No. 11 →No. 12 →No. 13 →
No. 22 →No. 14 →No. 9 (recursive)
Note that when playing an MP3 / WMA / AAC disc with 8
files or less, the disc is played from the 1st track in the
normal order.
• Pressing the [ ] key goes back by 1 track from the track
being played.
• When playing an MP3 / WMA / AAC disc, display the file
format before starting to play each file. (“MP3”, “WMA”,
“AAC”)
• While in CD source, press the [1] key to jump to No. 28.
• While in CD source, press the [2] key to jump to No. 14.
• While in CD source, press the [3] key to display the CD
mechanism model name and the version. Press the [3] key
again to go back to the normal screen.(Time code display)
• When CD is the source, press the [6] key to jump to No.15.
At this time, the volume value is set to 25 (2V PRE).
●USB source test mode specification
•While in USB source, press the [6] key to set volume value
to 15.
●AUDIO adjust mode
• Press the [AUD] key and enter the audio adjustment mode.
• Press the remote control [∗] key and [AUD] key to go into
the audio adjustment mode.
• Both AUDIO FUNCTION MODE and SETUP MODE ad-
justment items are included.
• By pressing [AUD] key and then [FM] key, switch the item
to be adjusted in the following order. (Only in forward rota-
tion)
The default item shall be Fader, and then the item is for-
warded in the following order: Balance →Bass Level →
Middle Level →Treble Level (thereafter arbitrary).
• Continuous forwarding by remote control is prohibited.
• Fader is adjusted by theVOL knob and [ ] / [ ] keys in
3 steps: R15 ↔0 ↔F15. (Default value: 0)
• Balance is adjusted by theVOL knob and [ ] / [ ] keys
in 3 steps: L15 ↔0 ↔R15. (Default value: 0)
• Bass/Middle/Treble Level are adjusted by theVOL knob and
[] / [ ] keys in 3 steps:-8 ↔0 ↔+8. (Default value:0)
•Volume Offset is adjusted by theVOL knob and [ ] / [ ]
keys in 2 steps: -8 ↔0. (Default value: 0)
• Loudness ON/OFF is adjusted by theVOL knob and [ ] /
[ ] keys in 2 steps:OFF ↔ON. (Default value: OFF)
●MENU
• Press the [Q] key to enter the MENU.
• Press the remote control [DNPP/SBF] key or the [DIRECT]
key to enter the MENU.
• Continuous forwarding by remote control is prohibited.
• Initial item in CD/USB source is “F/WVersion”.
●Backup current measurement
If reset while in Acc OFF (Back Up ON) condition, MUTE ter-
minal goes off 2 seconds later, rather than 15 seconds. (Dur-
ing this time, the CD mechanism does not function.)
TEST MODE
6680:0123
Model name Version

12
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
●Initializing AUDIO-related setting value
Press the [ ] key in the STANDBY source and reset the AU-
DIO setting value to the test mode default value.
●Other
• When Power ON, do not display “CODE_OFF” and
“CODE_ON”.
• When the source is STANDBY, press [AUTO] or [TI] key to
switch key illumination GREEN/RED. (in the model with
ILLUMI switching function)
• When started in Test Mode, duration of prohibiting LINE
MUTE shall be changed from 10 seconds to 1 second.
• When in test mode, do not write security code by security
jig.
• While in Test Mode, serial number is not written with a se-
rial-number-writing jig.
• When in Test Mode, when DC offset error detection is run,
the detection information is not written into the E2PROM.
• DEMO mode shall not be operated while in Test Mode, CD
Mechanism Error Log Data Clearing Mode, or DC Offset
Error Detection Data Clearing Mode.
Also, do not display DEMO ON/OFF option items in the
MENU in STANDBY source in the above modes.
●Special displays while all lights are on
When all lights are on with STANDBY source, if the following
keys are pressed, the following messages are displayed.
[1] key Version is displayed (forwarding)
(Display) TYPE : x_ _ _ (“x” is displayed in hexadecimals)
→519K – 2.02 (“development ID” – “version”)
→all lights on →
∗TYPE indicates µ-com destination, and shows real-time
condition of the destination terminal.
[2] key Serial No.is displayed (8 digits)
(Display) xxxxxxxx
[3] key Key pressed: Power ON time is displayed.
While Power ON time is displayed, press and hold for 2
seconds or longer to clear the Power ON time.
(Display)
PON_0Hxx (00~50 is displayed for “xx”.When less
than 1 hour, display by increment of 10
minutes.)
xxxxx (00001~10922 is displayed for “xxxxx”)
MAX 10922 (hours)
[4] key Key pressed: CD operation time is displayed.
Press the key for more than 2 seconds while the CD
operation time is displayed to clear CD operation time.
(Display)
CDT_0Hxx (00~50 is displayed for “xx”.When less
than 1 hour, display by increment of 10
minutes.)
xxxxx (00001~10922 is displayed for “xxxxx”)
MAX 10922 (hours)
[5] key Key pressed: Number of CD EJECT time is displayed.
While the CD EJECT times is displayed, press and hold
for 2 seconds or longer to clear the number of CD EJECT
times.
(Display) EJCxxxxx MAX 65535 (times)
[6] key Key pressed: Number of times PANEL is opened/closed
is displayed.
Press the key for more than 2 seconds while the PANEL
open/close count is displayed to clear the PANEL open/
close count.
(Display) PC_xxxxx MAX 65535 (times)
[FM] ROM correction version is displayed
key (Display) ROM_R123
ROM_ERR_ (When E2PROM is not installed)
ROM_R – – – (When not written in)
ROM_R ∗ ∗ ∗ (When data not matching)
[AM] IC10 adjustment status
key “E2P_OK”: Adjustment completed
“E2P_ER”: E2PROM values are still default (not determined)
“I2C_ER” : Cannot communication with IC10/E2PROM
∗If “E2P_OK”, Pin 41 (TUN FANC OUT) should be
output as “H”.
[]AUDIO data initialization
key (Display) AUD_INIT
[]Key pressed: Forced Power OFF data displayed.
key While the forced power OFF data is displayed, press and
hold for 2 seconds or longer to clear the data.
(Display) POFF_ – – – (No Forced Power OFF)
SEC (Forced Power OFF because of
missing Security Code)
PNL (Forced Power OFF because of
system µ-com and panel communication error)
TEST MODE

13
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
[]Key pressed: CD information display mode ON/OFF
key While in CD information display mode, press and hold for
2 seconds or longer to clear all CD information.
∗Please refer to the next table.
CD information display mode
I2C communication condition display
(Display) I2C_OK_ _
NG
[AM] CD mechanism error log display
key(switched by [ ] / [ ] keys)
↑(Display) MCERR1: x x ↔MCERR2: x x ↔
MCERR3: x x ↔MCERR1: x x ↔
(“– –” or the error code is displayed for “xx”)
CD loading error log display (switched by [ ] / [ ] keys)
(Display) LDERR1: x x ↔LDERR2: x x ↔
LDERR1: x x ↔
(Number of times is displayed for “xx”)
MAX 99 (times)
CD ejection error log display (switched by [ ] / [ ] keys)
(Display) EJERR1: x x ↔EJERR2: x x ↔
EJERR3: x x ↔EJERR4: x x ↔
EJERR1: x x ↔
(Number of times is displayed for “xx”)
MAX 99 (times)
CD time code error count data display (missing counts)
(switched by [ ] / [ ] keys)
(Display) CNT_LOSE ↔CDDA_ _: xx ↔CDROM_: xx ↔
CNT_LOSE ↔
(Number of times is displayed for “xx”)
MAX 99 (times)
↓ CD time code error count data display (count not updated)
[FM] (switched by [ ] / [ ] keys)
key (Display) CNT_STAY ↔CDDA_ _: xx ↔CDROM_: xx ↔
CNT_STAY ↔
(Number of times is displayed for “xx”)
MAX 99 (times)
●Clearing CD mechanism information and service
information (E2PROM data clearing)
1. While pressing the [Q] key and [ATT] key, reset-start to start
CD mechanism and service information initialization.
(While “– – – –“ is being displayed, power can be ON for 30
minutes.)
[CD mechanism information]
• Displays I2C communication condition
• Displays CD mechanism error log
• Displays CD loading error data.
• Displays CD ejection error data
• Displays CD time code error count data (missing count)
•
Displays CD time code error count data (count not updated)
[Service information]
• Displays power ON time is displayed
• Displays CD operation time
• Displays number of CD EJECT times
• Displays number of times panel was opened/closed
• Displays forced Power OFF data
2. After the initialization process is completed, the following is
displayed.
When successfully completed : “CD_O_ _ _”
When finished but unsuccessful:“CD_X_ _ _”
∗CD mechanism information clearing is no good.
3. This mode is cancelled by resetting. (The last screen will
not be retained.)
●Clearing DC offset error detection data
(E2PROM data clearing)
If DC voltage difference (DC offset error) is detected between
audio power amplifier (power IC) ±outputs, “DC_ERR_” is dis-
played on the display.When this occurs, the audio is forced-
mute and the display displays only “DC_ERR_”.
Once this product detected a DC offset error, even if it is re-
started (or reset), its display displays “DC_ERR_”.
However, if the error is detected while in Test Mode, it is not
saved in E2PROM.
1. Press and hold [3] and [6] keys and reset-start to go into
the DC offset error display mode.
(While “– – – –“ is being displayed, power can be ON for 30
minutes.)
2. While in STANDBY source, the current DC offset error con-
dition is displayed.
When detected : “DC_ERR_ _”
When not detected: “DC_OK_ _ _”
3. While error condition is being displayed, press [AUTO] key
to clear the detection data. (Clear E2PROM)
4. DC offset error display mode is cancelled by resetting.(The
last screen will not be retained.)
TEST MODE

14
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
TEST MODE
●FM/AM channel space switching
(KDC-MP5033U/MP532U only)
While power is OFF, press and hold [1] and [5] keys, and press
[SRC] key to power ON.
●IC10 (X34-) Stereo adjustment (VCO adjustment)
While in test mode and all lights are lit (STANDBY), press and
hold [1] key and press [6] key for 3 seconds or longer.
“VCO ADJ” will be displayed for a second.
(Adjusted data will be written on E2PROM.)
●Security
1) How to enter the forced POWER ON mode
While “– – – –” is being displayed, while simultaneously
pressing [Q] key and [4] key, press [RESET] button, With
this, it is possible to turn the power on for 30 minutes only.
2) How to register the security code on the“Car
Audio Passport” sheet after replacing E2PROM
(IC103) (For models of destination“E”or“M”)
1. Enter the test mode.(Refer to“How to enter the test mode”.)
2. In the test mode, press [Q] key to enter the MENU mode.
When “CODE_SET” is displayed, press [ ] key for 1 sec-
ond or longer to enter the security registration mode.
3. Input the security code, using [FM] / [AM] / [ ] / [ ] keys.
[FM] key: number up / [AM] key: number down
[ ] key:cursor to right / [ ] key:cursor to left
4. After inputting the code, press [ ] key for 3 seconds or
longer which causes “RE-ENTER” to be displayed.This is
for “confirming” the code. Use the method in the step 3 to
re-enter the code.
5. Then, press [ ] key for 3 seconds or longer, which will
display“APPROVED”.This completes the security code reg-
istration.
6. Release the test mode. (Refer to “How to clear the test
mode”.)
∗All clear cannot be used to clear the security code.
3) How to clear the programmable security code
(KDC-MP532U only)
1. While “– – – –” is being displayed, press [ ] key for 3
seconds or longer while pressing the [AUTO] key. This
makes the “– – – –” display disappear.
2. Input “KCAR”, using the remote controller.
Press [5] key of the remote controller twice (Input for “K”)
and press [ ] key.
Press [2] key of the remote controller 3 times (Input for “C”)
and press [ ] key.
Press [2] key of the remote controller once (Input for “A”)
and press [ ] key.
Press [7] key of the remote controller twice (Input for “R”)
and press [ ] key.
3. The security is cleared and the unit enters STANDBY
source.
4. If wrong codes are input, “– – – –” will be displayed again.

15
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
ADJUSTMENT
1. IC10 (X34-) -TheTuner adjustment method
• When IC10 and its circumference are repaired, according
to the following order, it readjusts if needed.
• The adjustment item changes with parts to exchange.Please
refer to "Parts vs Adjustment item table".
1-1. VCO coil adjustment - adjustment of tunning voltage
Voltage Check Point :Vt-Check Land
(PWB Side B, around D506)
Adjustment Coil :L507 (VCO Coil)
The adjustment method :VCO coil is turned and adjusted
according to the following tables.
Type Mode freq. Voltage Fig.
E/M AM 1611kHz 5.5 ±0.1(V) 2, 3 (C)
KAM1700kHz 5.8 ±0.1(V) 2, 3 (C)
JFM90.0MHz 5.6 ±0.1(V) 2, 3 (C)
M : AM Adjustment
ForYour Information :The frequency of this unit is only set
up by preset key in case this adjustment
1-2. Adjustment of 1st & 2nd-MIX coil
Voltage Check Point : S-METER-Check Land
(PWB Side B, around R216)
Adjustment Coil : 1
st IFT=L508 / 2nd IFT=L509
Setting of Signal Generator : Refer to the following tables
Type Mode freq. Mod. ANT Input Fig.
KAM1000kHz OFF 35dBµEMF 1~3 (B),(C)
E/M/J AM 999kHz OFF 35dBµEMF 1~3 (B),(C)
qThe appearance and the coil with which S-METER DC volt-
age serves as the maximum are turned and adjusted in the
above-mentioned SG input.
wBy the above-mentioned adjustment method, same adjust-
ment is performed to both sides (1st & 2nd MIX Coil).
1-3. Adjustment of FM ANT & RF coil
Voltage Check Point : S-METER-Check Land
(PWB Side B, around R216)
Adjustment Coil : ANT Coil = L505
RF Coil = L506
Setting of Signal Generator : Refer to the following tables
Type Mode freq. Mod. ANT Input Fig.
E/M FM 87.5MHz OFF 5dBµV or 11dBµEMF 1~3 (A),(C)
KFM87.9MHz OFF 5dBµV or 11dBµEMF 1~3 (A),(C)
JFM76.0MHz OFF 5dBµV or 11dBµEMF 1~3 (A),(C)
qThe appearance and the coil with which S-METER DC volt-
age serves as the maximum are turned and adjusted in the
above-mentioned SG input.
wBy the above-mentioned adjustment method, same adjust-
ment is performed to both sides (ANT & RF Coil).
1-4. Adjustment of STEREO (adjustment of 456k-VCO)
Adjust in TEST MODE
• How to enter the test mode
Refer to “TEST MODE”.
• Adjustment method
While in test mode and all lights are lit (STANDBY), press
and hold [1] key and press [6] key for 3 seconds or longer.
(Adjusted data will be written on E2PROM.)
Effect of adjustment is in cofirmation of adjustment status
at Preset [AM] key.
• Display of Preset [AM]
Adjustment OK:“E2P OK” (14-segment display model)
Adjustment NG:“E2P ER” (14-segment display model)
• How to clear the test mode
Refer to “TEST MODE”.
[Fig.3]
(UNDER VIEW)
[Fig.2]
[Fig.1]
(OVER VIEW)
(REAR VIEW)
(TUNER ANT)
(A)
(B)
S-METER
Check Land
IC10
Vt
Check Land
FM-SG
AM-SG
(C)DC Voltmeter
L509
L508
L507
L506
L505

16
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
2. IC10 (X34-) Replacement - Parts vs Adjustment ItemTable
• When the parts in the following tables are exchanged, please readjust according to a table.
• When other parts are exchanged, please perform only a check of operation.There is no necessity for readjustment.
Replacement parts Adjustment Item
Ref. Number Parts Name VCOVt 1st MIX 2nd MIX ANT Coil RF Coil Stereo
IC10 E-VOL & Tuner YES YES YES YES YES YES
IC103 E2PROM YES YES YES YES YES YES
L505 Antenna Coil YES
L506 RF Coil YES
L507 VCO Coil YES YES YES YES YES
L508 1st MIX Coil YES
L509 2nd MIX Coil YES
D504 Variable Capacitance Diode YES YES YES YES YES
D505 Variable Capacitance Diode YES YES YES YES YES
D506 Variable Capacitance Diode YES YES YES YES YES
X501 X’tal
• The “ YES ” mark shows that the adjustment is need.
ADJUSTMENT

17
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
EDCBA
1
2
3
4
5
6
7
SWITCH UNIT X16-373x-xx
(J76-0239-02)
ED1
S1
S2
S27
S10
D4
D1
D2
D3
D7
D8
D9
D13
D14
D15
D5
D6
D10
D11
D12
D16
D17
D18
D25
D26
D21
D23
D19
D20
D22
D116
IC2
1
FM AM
AUTO
SRC
654321
Q
VOL
ATT
AUD
G
VO
VCC
J1
D102
D110
Q5
Q10
Q15
Q18
Q19
D115
Q4
Q12
Q13
Q14
Q20
SWITCH UNIT X16-373x-xx
(J76-0239-02)
214
C8
R59
R60
R20
C10
C19 C20
C27
C28
C29
C31
C32
CP14
R55
R56
R58 R63
R80
R101
R106
R110
W6
W7
W8
C14
C16
C13 C15
CP10
CP11
CP12
CP13
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R13
R14
R15
R23
R26
R112
R29 CP15
R51
R52
R53
R54
R66 R67
R73
R74
R75
R81
R107
R108
R109
R111
W4
W5
EB
BE
EB
EBBEBE
EB
BE
BEBE
115
KS1 KI6
KI1-2
KI4
KI5
KI3
KS2
KS3
PAN5V
D GND
RTRY-CW
FL+B
ILL+B
RST
CN DET
ESD
RTRY CCW
FL+B
KS4
Refer to the sche-
matic diagram for
the values of resis-
torsand capacitors.
PC BOARD
(COMPONENT SIDE VIEW) (FOIL SIDEVIEW)
X16-373x-xx
Ref. No. Address
IC2 6A
X16-373x-xx
Ref. No. Address
Q4 6D
Q5 6D
Q10 3C
Q12 3D
Q13 3D
Q14 3D
Q15 3C
Q20 3D

18
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
FGHIJ
1
2
3
4
5
6
7
1
1
13
9106 75 1
224
1
5
1
1
5
15
214
8
9
25
11 12 8 4 3 2 P-MUTE
W7
L513
W8
C512
C400
L400
C560
L515
R582
L512
C548
L509
L510
L514
C210
C402
C505
C507
C508
C533
C547
C558
C566
C575
CF51
L500
L507
R59
R60
R
R253
R254
L505
L506
CF52
CF53
C209
CF54
C201
C202
C203
C204
C205 C206
C207
C208
C251
C252
C300
C301
C302
C303
C304
C563
L501
L502
L503
L504
L511
R255
R256
R300
R301
R302
R528
X400
X501
W64
W6
W11 W10 W9
L508
W4
W553
W560
W561
W12
W554
W555
W550
W559
W556
W557
W552
W551
W558
C401
R51
R164
R165
R166
R167
R168
R169
R162
R163
R170
R549
TH1
R108
R109
R120
R126
R134 R13
6
R13
8
C51
C57
C58
C105
C106
C404
C405
R52
R54
R56
R65
R68
R105
R106
R117
R119
R121
R124
R131
R133
R13
5
R13
7
R139
R161
R224
R402
R405
R219
C54
C55
C108C109
C110
C403
R53
R55
R58
R61
R67
R107
R110
R113
R115
R116
R122
R123
R125
R127
R128
R129
R143
R150
R151
R152
R153
R154
R155 R156
R157
R158
R159
R160
R201
R202
R203
R204 R205
R206
R207
R208
R209
R210
R211
R212
R213
R214
R215
R216
R221
R222
R223
R401
R406
R407
R408
X102
W210
W402
X101
L3
R146
R147
R71
R70
25
100
7650
26
51 75
8
169
30 1
BE
BEBE
BE
BE
BE
BE
BE
BE
BE
BE
J2
J4
D111
J5
J6
P1
WH1
C
N
S101
S102
WH2
CN1
Q400
D51
D58
D303
D304
D305 D306
D307
D308 D309 D310
Q51
Q52
Q
5
D52
D57
D201
D202
D510
Q53
Q201
Q202
Q203
Q204
Q12
Q13
IC201
IC400
IC101
ELECTRIC UNIT
X34-412x-xx (J76-0170-02)
CNVSS
VREF
2-2
2-1
1-1
1-
2
B.U.
CN
A-MUTE
STBY
SVR
BEEP
CLK
DT
38
C
DATA
C
E
OE
DI
RST ADJ
MSTOP
SDA
CON
T
VCC
G
P-5
37
SCL
PC BOARD (COMPONENT SIDEVIEW)

19
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
ONMLK
1
2
3
4
5
6
7
Refer to the schematic diagram for the values of resistors and capacitors.
X34-412x-xx
Ref. No. Address
IC1 4L
IC2 5K
IC101 4J
IC201 2I
IC400 6G
Q1 2L
Q2 3L
Q3 2L
Q4 6L
Q8 4K
Q9 4L
Q12 6J
Q13 6J
Q51 3J
Q52 3J
Q53 2J
Q54 3K
Q201 2I
Q202 3I
Q203 3J
Q204 3H
Q400 6G
1
1
2
4
1
51
5
12
16
8
9
C1
C3
L1
C6
C14
C8
C9
L101
C101
C2
C4
C5
C7
C10
C11
C12
C13
R59
R60
R63
R64
W63
W3
W1
W52
W2
W57
L2
C17
W56
W55
W5
W60
W51
W54 W53
W58
W59
W61
W62
3
4R136
R138
C
51
C
57
R
56
R
65
3
1
3
3
R135
R137
R139
R1
R11
R12
R31R32
R33
R34
R35
R36
R37
R
53
R101
R102
R103
R104
2
7
2
8
2
9
R38
R81
1
00
76
BEE
BE
BE
BE
CC
EEB
CC
BE
BE
D1 Q1
Q4
Q9
J1
CN2
S101
D
51
Q3
D2
Q8
Q54
D4
D
57
Q2
IC1
IC2
CNVSS
VREF
2-2
2-1
1-1
1-21-3
U
.
CLK
DATA
CE
OEM
DISPLAY
P-FL
CD5V
P-CD
PON
CON
T1
T3 T2
VCC
GND
SW1
SW2

20
KDC-MP5033U/MP532U
KDC-W534UA/UAY/UG/UGY/W5534U/UY
PQRST
1
2
3
4
5
6
7
Q6
D8
Q7
Q101
Q105
D3
D5
D6
D53
D54
D300
D301
D302
Q10
Q11
D103
D10
D9
D55
D56
D102
D112
D113
D114
D508
D509
Q5
Q103
Q104
IC3
I
C
IC102
ELECTRIC UNIT
X34-412x-xx (J76-0170-02)
1
1
43
2
C559
R7
C16
C549
C
C555
C561
C111
R4
R57
R62
R66
R185
R69
R114
R181
R182
C102
R100
R118
C52
C53
C56
C103
C107
C112
C541
C551
C557
C567
R3
R9
R10
R142
R144
R220
R54
6
C552
C5
6
R2
R5
R140
R141
R171
R172
R173
R174
R175 R176
R177
R178 R179 R180
R186
R187
R190
R217
R218
R303
R304
R305
R306
R544
R545
R561
W50
C260
C261
C115
C114
C262
C80
R80
C584
C263
R311
4
58
CC
EBE
BE
BEBE
BE
EB
BEBE
BE
TUNOUT
A-DATA
A-CLK
SW2
SW1
FANC OUT
ADJ
TP66
TP50
TP100
TP112
TP1
TP2
TP3
TP4
TP5
TP6
TP7
TP8
TP9
TP10
TP11
TP12
TP13
TP510
TP48
TP49
TP70
TP69
TP47
TP46 TP45
TP44
TP43
TP40
TP105
TP106
TP39
TP51
TP41
TP42
TP14
TP36
TP38
TP37
TP15
TP17
TP25
TP20
TP23
TP33
TP29
TP28
TP21
TP107
TP24
TP26
TP16
TP18
TP19
TP35
TP30
TP27
TP111
TP22
TP34
TP101
T
P
TP514
TP515
TP520
TP521
TP518
TP517
TP519
TP516
TP55
TP60 TP59
TP57
TP56
TP103
TP102
PC BOARD (FOIL SIDEVIEW)
