KERBEDANZ Maximus Series Installation guide

www.kerbedanz.com
Crafting your singularity
Maximus collection
CARE AND
INSTRUCTION MANUAL

The Maximus collection
Maximus, a technical feat
Using your watch
Precautions for use
Your KRB-08 hand-wound movement
Welcome to Kerbedanz
The Kerbedanz international guarantee
03
04
05-06
07
08-09
10-12
Table of contents
13-14

03
WELCOME TO
KERBEDANZ !
We thank you for your trust and hope you are satisfied
with your purchase!
We are happy to count you among our customers.
To ensure that your Kerbedanz watch is in perfect
working order, please carefully follow the instructions
in this manual and in the international warranty.

The Maximus wristwatch contains the world’s largest
tourbillon ever designed. This timepiece, whose name means
“the largest”, is a genuine technical feat acknowledged by two
patents as well as an aesthetic achievement: housed in a
cage measuring 27 mm in diameter, the majestic tourbillon,
the focus of everyone’s attention, presents a unique show.
This exceptionally portable model features optimal
chronometric performance that will not disappoint.
MAXIMUS
COLLECTION
04

05
A REAL TECHNICAL
FEAT
A 54-hour power reserve
The "gauge" indicating the power reserve of more than 54
hours is also displayed on the case back rather than on the
dial - which is logical, given that the winding of the
movement by the 4 barrels is carried out from the case back
by means of a very special winder, independent of the crown
- the latter, shifted to 2 o'clock, being used only to set the
time.
An exceptional movement
The movement was designed, manufactured and decorated
by Kerbedanz. It is a hand-wound mechanical movement with
a total of 415 components. Of these components, 73 make up
the tourbillon and its cage, entirely in titanium, weighing 1.35
grams. The height of the movement itself is 8.35 mm and
13.2 mm with the tourbillon cage. The design and
manufacture of the balance wheel and balance spring also
had to be mastered.

06
A unique winding system
The force required to wind the four barrels is so great that it
necessitated the design of a manual winding system from the
bottom of the case, activating the central ball-bearing gear
wheel, which itself meshes with the barrel wheels. The
winding "key" is designed like a kind of chicken or spider, not
with 8 legs but with 6 "arms" that are hooked with the fingers
to make them turn clockwise. The winding is done by a
system of pawls, which is designed with a disengagement to
avoid the breakage of a pawl or a tooth in case of error in the
direction of rotation.
A REAL TECHNICAL
FEAT

Giant central tourbillon
with a cage diameter
of 27 mm
Power reserve of
approximately
54 h
Holder of 2 patents for
its innovative systems
of 4 barrels and
raquetterie
415 components and
34 jewels
07
THE MANUAL
WINDING MOVEMENT
KRB-08

Winding is only done through the case back.
Turn the winding key on the back of the watch clockwise until
the power reserve indicator is full (+ position).
Wind the watch regularly for optimal performance.
08
USING YOUR WATCH
Starting up

Pull the crown out to position 2.
Turn the crown clockwise to the desired time. Finally, push
the crown back in to position 1.
09
12
USING YOUR WATCH
Time setting

10
PRECAUTIONS FOR
USE
To ensure the longevity of your timepiece, it is important to have
it serviced periodically, exclusively by an authorized service
center.
The frequency of periodic service depends on the use of the
watch and the environment in which it is worn.
We recommend that you have a water-resistance test performed
every 2 years and a full service every 5 years.
Read this manual carefully and follow the
maintenance instructions.
Make sure the bracelet is properly adjusted to
your wrist size at the time of purchase.
