Ketra S30 PAR 30 Lamp User manual

Lamp
TUNABLE WIRELESS LAMPS
Instlltion Guide
Models
S30 PAR 30 Lamp
S38 PAR 38 Lamp
A20 Lamp

Shock Hzrd. May result in serious injury or deth.
Turn power OFF at circuit breker or remove fuse. Dmge to this product cused by wiring with power
on voids the wrrnty.
Due to the risk of electric shock, a licensed electricin should instll this power supply unit in strict
complince with the Ntional Electricl Code nd ny stte or locl code which my pply.
Maintain at least 6 ft (1.8 m) of spacing between any KetraNet Mesh product and Wi-Fi routers and
access points.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following
two conditions:
• This device may not cause interference.
• This device must accept any interference, including interference that may cause undesired operation
of the device.
!WARNING
2|LAMP INSTALLATION GUIDE
770-0000XX-01 r11
© 2019 Ketra, Inc. All rights reserved

Contents
Product Overview 4
Dimension Drawings 5
Installation 6
Fixture Placement 6
Power 6
After Installation 7
Warranty  Tech Support 8
3|LAMP INSTALLATION GUIDE
770-0000XX-01 r11
© 2019 Ketra, Inc. All rights reserved

Product Overview
Ketra’s Family of lamps are an all-encompassing LED solution with the
ability to render 90+ CRI white light, saturated colors and pastels from a
fully mixed, single point source.
Ketra’s custom driver chip and optics incorporate closed-loop thermal and optical
feedback, maintaining a factory-calibrated color point to one MacAdam ellipse over
the product’s lifetime. Each lamp is wirelessly controlled and individually addressable
through Ketra’s accompanying software.
S38 PAR 38 Longneck Lamp A20 Lamp S30 PAR 30 Longneck Lamp
continued on next page
4|LAMP INSTALLATION GUIDE
770-0000XX-01 r11
© 2019 Ketra, Inc. All rights reserved

Dimension Drawings
fig. 1
S38 PAR 38 Longneck Lamp
A20 Lamp
S30 PAR 30 Longneck Lamp
fig. 2
fig. 3
4.80 in, 122 mm
3.7 in, 95 mm
2.52 in, 64 mm
4.95 in, 126 mm
4.7 in, 118.6 mm
1 in, 25.4 mm
2.4 in, 60.1 mm
1.8 in, 44.7 mm
4.95 in, 126 mm
E 26 Base
E 26 Base
E 26 Base
5|LAMP INSTALLATION GUIDE
770-0000XX-01 r11
© 2019 Ketra, Inc. All rights reserved

Installation
* Ketra’s lighting products should only be controlled via our digital control architecture. Please refer to our controls products installation guides for
more information.
Fixture Placement
For ideal KetraNet Mesh wireless performance, position the Lamp according to these guidelines:
• Keep within range: Place the Lamp within 50 ft (15.24 m) of at least one or more KetraNet Mesh
enabled device in its network.
• Avoid obstructions: Avoid having metal obstructions or walls between the Lamp and the
nearest device.
• Avoid metal enclosures.
• Separate from Wi-Fi devices: Maintain at least 6 ft (1.8 m) of spacing between any KetraNet Mesh
product and Wi-Fi routers and access points.
Note: Ketra lighting products should not be connected to, or directly controlled by, AC mains
line voltage dimmers.* Ketra’s lighting products should only be controlled via our digital control
architecture. Please refer to our controls products installation guides for more information.
Power
The S30, S38, and A20 all require 120 V 60 Hz.
NODE NODENODE
50 nodes max per N4
50 FT MAX 50 FT MAX
6|LAMP INSTALLATION GUIDE
770-0000XX-01 r11
© 2019 Ketra, Inc. All rights reserved

INSTALLATION
After Installation
Ketra lamps power on to a warm white color. They are not controllable until being commissioned in Ketra’s
Design Studio software. Commissioning requires at least one Ketra N4 Hub connected to a DHCP-enabled
router. For manuals and installation guides, see the Design Studio product page and the N4 Hub product
page on our website.
Design Studio product page
N4 Hub product page
7|LAMP INSTALLATION GUIDE
770-0000XX-01 r11
© 2019 Ketra, Inc. All rights reserved

Warranty  Tech Support
Limited warranty terms can be found at:
www.ketra.com/warranty
For questions and technical support please contact:
[phone]
[e-mail]
Ketra and KetraNET are trademarks or registered trademarks of Lutron Ketra LLC, in the US and/ or
other countries.
