Keytrak INS-831DV-UH-W User manual

ITEM №: INS-831DV-UH-W
Caution for Installation
1. In order to prevent electronic shock, don’t loosen any screws or covers.
2. Do not directly touch the front glass. If necessary, use a soft cloth
moistened with alcohol to wipe off the dust.
3. Avoid places where there are frequent vibrations or shocks.
4. Don’t operate the camera beyond its temperature, power source ratings.
5. When any abnormalities happen, make sure to unplug the camera and
contact your local dealer.
Packing
1. Camera X1
2. User Manual X1
3. Screw X4
4. Plastic-Conical-Anchor X4
5. Hexagonal Wrench X1
6. ScrewDriver X1
7. Mounting drawing paper X1
8. DC Connector X1
9. Zoom&Focus Rubber X2
Specification
ITEM
INS-831DV-UH-W
IP Rating
IP65
Type
Colour/Monochrome（Removable IR Cut Filter）
Signal System
NTSC/PAL
Pick Up Device
1/3" 960H Double Scan CCD
Picture Elements
NTSC:1020H×508V PAL:1020H×596V
Resolution
700 TVL
Min Illumination
0Lux（36 Pieces IR LED ON）
Vertical Frequency
NTSC:60Hz PAL:50Hz
Horizontal Frequency
NTSC:15.734KHz PAL:15.625KHz
Clock Frequency
NTSC/PAL:36MHz
Scanning System
2:1 Interlace
S/N Ratio
≥52dB
Electronic Shutter
NTSC:1/63-1/10000S PAL:1/53-1/10000S
Lens
2.8-11mm Varifocal IR Lens
White Balance
ATW
Back Light Compensation
ON
Auto Gain Control
ON
IR OPTIMIZER
ON
GAMMA
0.45
Video Out-put
1V p-p,75Ω
Power Supply
DC12V ±10%
Current Consumption
500mA(MAX)
IR Effect Distance
15-20m （49.2-65.6ft）(indoor)
Dimension
Φ120×100mm（Φ4.72”×3.93”）
Weight
790g (27.86oz)
Storage Temperature
-30～+60℃(-22～+140℉)
Operating Temperature
-30～+40℃(-22～+104℉)
Remark:Non-regulativeadaptormaycause camera damaged.
Digital IR Colour CCD Camera
All manuals and user guides at all-guides.com
all-guides.com

Major control key and function
1. How to Setup Functions
1) Press” ” to display OSD menu or confirm
2) Press “▲” for screen choice
3) Press ”▼” for screen choice
4) Press ” ” for screen choice
5) Press ” ” for screen choice
2. Main Menu Setup
Press MENU button first, then there is 10main items on the screen, and the
category which is selected will be in flash.
Adjustable parameters by OSD menu Packing
OSD Menu Item
Adjustable Parameters
LANGUAGE
ENGLISH/JAPANSE/ESPANOL/PYCCKNN/DEUTSCH/
FRANCAIS/中文
LENS
MANUAL / AUTO（TYPE/MODE/SPEED）
SHUTTER/AGC
AUTO(HIGH LUMINANCE / MODE/BRIGHTNESS/
LOW LUMINANCE / MODE/BRIGHTNESS)
MANUAL(MODE / SHUTTER /AGC)
WHITE BAL
ATW / PUSH / USER1 / USER2 / ANTI CR / PUSH
LOCK / MANUAL
PICT ADJUST
MIRROR / CONTRACT / SHARPNESS
NR
MID/MIDHIGH/HIGH/LOW/MIDLOW/OFF
DAY NIGHT
AUTO /COLOR
BACK LIGHT
OFF / BLC / HLC
WDR
NORMAL / LIGHT/FULL
(MID/MIDHIGH/HIGH/LOW/MIDLOW
PRIVACY
OFF / ON(AREA SEL/COLOUR / TRANSP / MOSIAC)
MOTION DET
OFF / ON(DETECT SENSE / BLOCK DISP / DETECT
AREA/MONITOR AREA / AREA SELECT /TOP /
BOTTOM / LEFT / RIGHT)
CAMERA ID
OFF / ON(OPENS VIRTUAL KEYBOARD)
CAMERA RESET
