KICE KF Series User manual

07182022 FAN-M01-0000
FAN-M01-0000
II 3 D c
KICE INDUSTRIES, INC.
KF Fan
Operators Manual

23
Kice Industries, Inc. Kice Industries, Inc.
07182022 FAN-M01-0000 07182022 FAN-M01-0000
1. INTRODUCTION
When you purchased your Kice heavy duty industrial fan, you bought an air mover that has proven to be the
best design based on thousands of installations and years of proven reliability and operation.
We’re proud of our products, and the people at Kice Industries who craft them. At Kice, we use high
manufacturing standards and processes to produce the highest quality products, which have been a
trademark of our organization for over 75 years.
Our product development work, driven by the requirements of our customers, has resulted in the present
designs of the Kice Fans.
This owner’s manual is intended as a guide for proper installation, operation and maintenance to keep your
Kice fan operating safely and eciently on the job. Service and spare parts information are also included for
your benefit.
Sincerely,
Drew Kice, President
Kice Industries, Inc.
W
The Company warrants the equipment manufactured by the Company to be free of defects in material
and workmanship for a period of one year from the date of shipment. Kice agrees to repair or replace, at
its option, any parts found to be defective in the opinion of the Company. Kice is not liable for any costs
in connection with the removal, shipment or reinstallation of said parts. This warranty does not apply
to abrasion, corrosion, erosion, misuse or abuse of the product. Assistance by Kice in system layout or
selecting equipment does not imply Kice’s responsibility.
Buyer agrees to look to the warranty, if any, of the manufacturer or supplier of equipment manufactured
by others and supplied by Kice for any alleged defects in such equipment and for any damages or injuries
caused thereby or as a result thereof. Where work is made to measurements or specifications furnished by
the Buyer, Kice does not assume any responsibility for the accuracy of Buyer’s specifications. Kice will not
assume responsibility for alteration or repairs unless the same are made with written consent and approval
of Kice Industries, Inc.
PURCHASER SHALL BE RESPONSIBLE FOR COMPLIANCE WITH ELECTRICAL MANUFACTURER’S
RECOMMENDATIONS, UNDERWRITERS CODE AND ALL SAFETY PRECAUTIONS.
Kice extends no other warranty for any of its products other than the above express warranty and there
are no other warranties, express or implied, including warranties of merchantability, fitness for a particular
purpose, or otherwise which extend beyond the above limited express warranty. Kice and its dealers shall
not in any event be liable for consequential or incidental damages, and the terms and conditions stated
herein provide Buyer’s sole and exclusive remedy. Any actions for breach of this agreement or warranty
must be commenced within one year after the cause of action has occurred.
TABLE OF CONTENTS
1. I 2
2. G I 4
3. S P 7
4. R, H  I 9
5. F M 13
6. T G 14
7. T V  M  I 15
8. I P L 16
I
Write down the MODEL and SERIAL NUMBER of the Kice Industrial Fan, along with the same information for
the auxiliary equipment.
For additional information, application assistance or special service, you should contact the factory. We’ll
need to know the MODEL and SERIAL NUMBER of your Kice Industrial Fan. For ready reference, please
record this information and the date of delivery or installation and the date of delivery or installations on the
lines below. See the General information section for the location of model and serial number.
MODEL
SERIAL NUMBER
Date of delivery or installation / /

45
Kice Industries, Inc. Kice Industries, Inc.
07182022 FAN-M01-0000 07182022 FAN-M01-0000
2. GENERAL INFORMATION
T  N O
The purpose of this manual is to assist owners and operators in maintaining and operating the Kice
Industrial Fans. Please read it carefully; information and instructions furnished can help you achieve years
of dependable performance. Separate manuals are included for auxiliary equipment that makes up an air
system, such as airlock valves, cyclones and fans. They contain additional information that may not be
repeated in this manual. You are urged to read all manuals before attempting any operation or repair of the
equipment in the system. If these manuals are not included in your owner’s packet, contact our customer
service department.
U T M
General operation, adjustment and maintenance guidelines are outlined for owners and operators of
the Kice Industrial Fan. Operating conditions vary considerably and cannot be addressed individually.
Through experience, however, operators should have no diculty in developing good operating, safety and
monitoring skills.
The term “disconnect and lockout” as used in this manual means that power to the equipment has been
completely disconnected through the use of a “Lockout and Tagout Procedures”.
Directions used in this manual, for example RIGHT or LEFT, CLOCKWISE or COUNTERCLOCKWISE, refer to
directions when facing the drive side of the fan.
Photographs and illustrations were current at the time of printing, but subsequent production changes may
cause your Kice fan to vary slightly in detail. Kice Industries, Inc., reserves the right to redesign and change
the equipment as deemed necessary, without notification. If a change has been made to your Kice Industrial
Fan that is not reflected in this owner’s manual or the Illustrated Parts List, write or call Kice Industries, Inc.,
for current information and parts.
G I C
M  S N
The model of the Kice Industrial Fan, serial number and date of manufacture can be found stamped on the
metal identification plate located on the housing on the opposite side of the inlet.
K I F P  S
Use original Kice Industrial Fan replacement parts only. These parts are available from Kice Industries, Inc.
To obtain prompt, ecient service, always provide the following information when ordering parts:
1. Correct part description and number, as given in the Illustrated Parts Lists section of this manual.
2. Correct model number.
3. Correct serial number.
For assistance in service or ordering parts, contact the customer service department:
Kice Industries, Inc.
5500 Mill Heights Drive
Park City, KS 67219-2358
Phone: [phone]; Fax: [phone]
IMPORTANT: Any unauthorized modification, alteration, or use of non-approved attachments or drive units
voids the warranty and releases Kice Industries, Inc., from any liability arising from subsequent use of this
equipment. Each type of Industrial Fan is designed to be used in a specific type of system. Using the Kice
Industrial Fan for a purpose other than that for which it was designed could result in personal injury, as well
as product or property damage.
Kice equipment is designed and built to provide years of operation. As with any equipment, the following
rules are essential for trouble-free operation:
• Proper installation
• Regular maintenance
• Correct operation within original design parameters
• Proper application within a process
Model Motor (HP) Air Volume (CFM) Static Pressure (in WC)
KF7W4 1.5 200-400 6
KF7W8 3 400-800 6
KF7W16 5 600-1200 6
KF9W8 7.5 600-1200 10
KF9W16 10 1200-2200 10

67
Kice Industries, Inc. Kice Industries, Inc.
07182022 FAN-M01-0000 07182022 FAN-M01-0000
G I C
Failure to properly install, maintain or operate Kice equipment can result in a variety of problems, including
but not limited to: poor equipment performance, decreased equipment life, equipment failure or dangerous
operating conditions.
The Kice Industries product line includes a variety of equipment, all of which can be custom-made to suit
your application. Your Kice equipment was chosen based on your specification of process, product, and
your application requirements for capacity, operating conditions, operating parameters, etc. It is essential
that your Kice equipment be installed, maintained and operated under the conditions for which it was
originally designed and specified. Should your process needs change, please consult with Kice Industries
prior to utilizing the equipment under dierent conditions.
M  D P  S
The motor and drive components are covered by the manufacturer’s warranty. If there is a problem, check
with the local supplier or service representative.
3. SAFETY PRECAUTIONS
This safety alert symbol is used on equipment, safety decals and in manuals to call
your attention to an important safety message warning you of possible danger to your
personal safety. When you see this symbol, be alert; your personal safety or the safety
of other persons involved. Follow the instructions in the safety message.
H L
The following definitions for identifying hazard levels are:
DANGER (RED) – Danger is used to indicate the presence of a hazard that WILL
cause SEVERE personal injury, death, or substantial property damage if the
warning is ignored.
WARNING (ORANGE) – Warning is used to indicate the presence of a hazard that
CAN cause SEVERE personal injury, death, or substantial property damage if the
warning is ignored.
CAUTION (YELLOW) – Caution is used to indicate the presence of a hazard that
WILL or CAN cause MINOR personal injury or property damage if the warning is
ignored.
WARNING: All owners and operators should read this manual, or be instructed in
safe operating and maintenance procedures, before attempting to uncrate, install,
operate, adjust, or service this equipment.
S D
The safety decals on the Industrial Fan should not be removed, covered over, painted, or otherwise
become illegible. If this occurs, the decals should be replaced immediately. Contact our customer service
department for replacements.

89
Kice Industries, Inc. Kice Industries, Inc.
07182022 FAN-M01-0000 07182022 FAN-M01-0000
S P C
A S P
1. Do not attempt to install, connect power to, operate or service your new fan without proper instruction and until you have been thoroughly
trained in its use by your employer.
2. Do not attempt to work on, clean or service the fan, or open or remove any protective cover, guard, grate or maintenance panel until the POWER
has been turned o and LOCKED OUT, and the fan rotor has come to a complete stop.
3. Do not manually override or electrically bypass any protective device.
4. Do not connect power to or operate the fan unless all moving parts are covered and all covers, guards, grates and maintenance panels are in
place and securely fastened.
5. Do not abuse, overload, mistreat or misuse the fan or attempt to operate the fan if it is in need of service, lubrication, maintenance or repair.
6. Never place any part of your body near rotating members or moving parts of the fan.
7. If the fan is not equipped with factory supplied drive and guard, then all rotating members and moving parts must be completely enclosed
before connecting power and before operation.
8. Free outlet of the product must be guaranteed at all times. Otherwise, blockage and severe damage may result, or a dangerous situation may
occur.
9. If the fan is equipped with a maintenance panel or access door incorporating a Protective Interlocking Limit Switch (PLS), the PLS must be
interlocked with all electrical controls. This is to prevent all motors or powered devices on the unit from being energized if any protective cover,
guard, grate or maintenance panel is open or removed. Never attempt to manually override or electrically bypass a safety device. The interlock
function of the PLS must be tested and logged daily by supervisory personnel.
10. The fan housing may have an inspection port which is fastened with captive hardware. In addition, the port has a device that keeps it open as
long as it is not fastened down. The port may only be opened when the fan wheel is motionless and the repair switch is turned o.
11. Many fans are installed and wired to start automatically or be controlled from remote locations. Keep clear of all moving parts on industrial
equipment at all times.
12. The fan must be equipped with a properly functioning Protective Interlocking Electrical Control Switch (PCS), a Padlockable Manual Power
Lockout Switch, and with the other basic safety equipment listed above. On-O, interlock and padlock functions of the PCS must be tested and
logged daily by supervisory personnel.
13. It is the owner’s and the employer’s responsibility to adequately train the employee-operator in the proper and safe use of the equipment.
Written safety programs and formal instruction are essential. All new employees must be made aware of company policies and operating rules,
especially the established safety and health procedures. Refresher training of experienced employees in the potential hazards of the job is
important. Up-to-date training records must be maintained at the job site.
14. Special attention must be devoted to outside contractors engaged to enter and perform work on equipment or in the workplace. Special care
must be exercised to insure all such personnel are fully informed of the potential hazards and follow plant rules – with special emphasis on
explosion proof electrical tools and cutting or welding in unsafe environments.
15. Keep the workplace cleaned up and free of dirt and dust at all times. Do not attempt to work on slippery or unsafe ladders or work platforms
when maintenance or repair work is being performed on the fan.
16. The operator must ensure that adequate lighting conditions are provided at the location of equipment operation.
17. Do not climb on ladders or work on platforms unless maximum load rating is posted. Do not exceed maximum load ratings when installing or
servicing the fan.
18. Never allow any kind of metal or other foreign objects to enter a fan while in operation. Examined raw materials (cleaned air) should be used
through the machine to ensure proper and consistent operation.
19. To prevent human access while the equipment is operating, all fan inlet and discharge openings must be completely enclosed and remain
enclosed until POWER IS TURNED OFF AND LOCKED OUT. Keep away from the moving parts of the fan during operation.
20. Kice fans must be operated at the airflow rates determined for the customer specific application(s). This is to insure that the fan will operate
normally and under its maximum surface temperature rating.
21. Unless otherwise specified or designed per customer requirement, Kice fans are designed not to exceed a light dust load through the internal
airstream.
22. Operate safely at all times. Use personal protective equipment when and where appropriate, such as hard hats, helmets, gloves, earplugs, dust
masks, and eye protection devices. Keep personal protective equipment in good repair and convenient to the operator.
23. Drive components must be inspected and adjusted after transportation and periodically as required by operating conditions. Check sheaves
and coupling alignment and spacing, V-belt tension, set screws, keys, fasteners, bearings, shafts and motor, as appropriate to job conditions.
24. High voltage and rotating parts can cause serious or fatal injury. Only qualified, trained, and experienced personnel should perform installation,
operation and maintenance of electrical machinery. During installation and operation, make sure that the motor and the frame of the fan is
eectively grounded in accordance with OSHA safety and health standards, the National Electric Code, local codes and EN ISO 60204-1 as
required for the classified area.
25. Never stand under any kind of hoist or lifting mechanism, whether or not it is loaded or in operation. Never stand under or near a fan or
component when it is being lifted.
26. Qualified personnel, before each use, must carefully inspect all lifting devices. Never use a lifting device to transport equipment. Never use a
lifting device that is damaged, deteriorated, or in any way in need of repair.
27. All protective covers, guards, grates, maintenance panels, switches and warning decals must be kept in place and in good repair. Any
equipment with a damaged, malfunctioning, defective, or missing protective device must be taken out of service until the protective device can
be repaired or replaced.
28. Any device powered by air or hydraulic pressure must be equipped with a properly functioning Padlockable Manual Pressure Lockout and
Internal Pressure Relief Valve (PRV).
29. Any equipment that is used in the processing of explosive materials in hazardous environments requires an evaluation on the part of the user
and operator of proper and adequate monitoring equipment, dust control, explosion relief venting, and electrical equipment enclosures. Do not
use your equipment in hazardous environments unless it has been properly equipped for the hazard.
30. It is ultimately the operator’s responsibility to implement the above listed precautions and insure proper equipment use, maintenance and
lubrication. Keep these instructions and list of warnings with your machine at all times.
31. It cannot be assumed that every acceptable safety procedure is contained herein or that abnormal or unusual circumstances may not warrant or
require future or additional procedures.
WORK SAFELY AT ALL TIMES
4. RECEIVING, HANDLING AND INSTALLATION
R  I
Kice Industries, Inc., has prepared your new fan for shipment in accordance with the Uniform Freight
Classification. It has been thoroughly inspected at the factory and, barring damage in transit, should be in
excellent condition upon arrival.
The fan and accessories should be inspected upon receipt for any shipping damage or fan case
deformation. Turn the fan wheel by hand to see that it rotates freely and does not bind. If dampers or
shutters are provided, check these accessories for free operation of all moving parts, following all safety
protocols.
When a carrier signs the Kice Industries, Inc., bill of lading, the carrier accepts the responsibility for any
subsequent shortages or damage, evident or concealed, and the purchaser must make any claim against
the carrier. Evident shortage or damage should be noted on the carrier’s delivery document before
signature of acceptance. Inspection by the carrier of damage, evident or concealed, must be requested.
After inspection, issue a purchase order for necessary parts or arrange for return of the equipment to Kice
Industries, Inc., for repair.
H  S
Kice fans are shipped completely assembled and skidded when size permits. These units may be handled
and moved using good rigging techniques, being careful to avoid concentrated stresses that will distort any
of the parts. Items or parts of the fan that are shipped knocked down will be clearly labeled for reassembly.
If the fan is not to be installed promptly, store it in a clean, dry location to prevent rust and corrosion of steel
components. If outdoor storage is necessary, protection should be provided. Cover the inlet and outlet to
prevent the accumulation of dirt and moisture inside the housing. Cover the motor with waterproof material.
Refer to the Fan Maintenance section of this manual regarding bearings (Section 5) for further storage
instructions.
Check dampers for free operation and lubricate moving parts prior to storage. Inspect the stored unit
periodically. Rotate the wheel by hand every two weeks to redistribute the grease on internal bearing parts.
Caution: Use proper equipment when lifting or moving the fan. Make sure all persons and obstructions are
clear from path and installation area.

10 11
Kice Industries, Inc. Kice Industries, Inc.
07182022 FAN-M01-0000 07182022 FAN-M01-0000
R, H  I C
F I
To insure proper operation, the unit must be adequately supported and properly installed. It is important that
the fan is properly installed and maintained per the information in this manual so that material clearances are
maintained and potential ignition sources are minimized.
After the receiving and inspection has been completed, install the unit with the following guidelines:
1. Installation of the fan (which may include the motor) is completed by the operator. When installing the
equipment, please make sure that the moving parts on the inside of the equipment are not accessible.
2. Move the Kice Fan to the installation area using proper equipment with sucient lifting capacity. The
fan has locations where the equipment necessary for lifting the device can be attached. These will
be the lifting lugs on the fan assembly frame. Lifting the fan at any other point is hazardous and may
compromise human safety as well as the structural integrity of the fan itself. Note: Motor lifting lugs
are not suitable lifting points.
3. Tighten all fasteners securely. Refer to the table of recommended hardware torque values in this
manual (Section 7) when performing Kice Fan installation.
4. The fan, as well as any other parts and equipment, must be separately grounded when assembled to
mitigate the risk of an electrostatic charge. If necessary, shaft grounding systems may be used.
5. To insure proper operation, all ductwork or stacks should be independently supported as excess
weight may distort the fan housing and cause contact between moving parts. Ductwork should also
be placed away from access routes and steps.
6. For proper operation, Kice fans should also be installed in such a manner as to provide normalized
inlet airflow to minimize noise and resulting vibration which results from inlet air turbulence.
7. The unit should only be operated once it is properly connected and fully encapsulated. The fan wheel
is built into the case and the case has two connections for the air inlet and air outlet.
8. If there is danger of vibration transfer to adjoining plant components, suitable compensators can be
installed on the air outlet transition. Where vibration isolators are used, consult Kice Industries, Inc.,
for proper location and adjustment.
9. The motor controls and starter can be mounted in any convenient location. Distance or location of the
controller does not aect its performance.
10. Electrical conduit, junction tees, safety switches, motor starters and sometimes motors, are not
furnished by Kice Industries, Inc. A local electrician familiar with industrial equipment and local codes
should install the electrical items. Wiring from the controls to the motor and switches should be sized
for the amperage rating on the electrical device. All electrical components must be in accordance
with current guidelines and codes.
11. Some systems will have additional equipment to wire and check. All items must be checked to insure
proper direction of rotation.
12. Test-run the fan. If any unusual noises or vibration occurs, disconnect and lock-out the power. Open
the equipment, manually rotate the rotor and inspect for touching or rubbing. The fan outlet must
remain free and clean at all times; otherwise dangerous operating conditions may occur, causing
damage to equipment and/or personnel.
13. Reassemble items removed during inspection and remove lock-out for operation.
R, H  I C
F B  O I
Kice Industrial Fans are tested and adjusted before commissioning to validate design and operational
requirements as a final quality assessment. Each rotor has been dynamically balanced during fabrication to
conform to Kice vibration standards. Kice fan wheels are unique in that the wheel utilizes a hub with a split
taper bushing to insure concentric placement on the shaft and to insure that the wheel will retain its balance
(See the Fan Maintenance section for installation instructions).
It is not always practical for the manufacturer to perform a final assembly test run for vibration levels.
Therefore, though the impeller may have been balanced by the manufacturer, the customer is not assured of
a smooth-running assembled fan until the drive and/or driver are connected to the fan shaft and the unit is
tested for start-up vibration. Kice also cannot be responsible for the eects of vibration of drive components
added after factory test run and shipment.
S-U
Safe operation and maintenance includes the selection and use of appropriate safety accessories for the
specific installation. This is the responsibility of the system designer and requires consideration of the
equipment location and accessibility, as well as adjacent components. All safety accessories must be
installed properly prior to start-up.
Safe operating speed is a function of air temperature and wheel design. Do not, under any circumstances,
exceed the maximum safe fan speed published in the Kice Fan Performance bulletin, which is available from
Kice Industries, Inc. Kice fan performance characteristic curves and fan speed guidelines can also be found
on our website at http://www.kice.com/Product-CentrifugalFans.html .
P
1. Inspect the installation prior to starting the fan. Check for any loose items or debris that could be
drawn into the fan or dislodged by the fan discharge.
2. Check the tightness of all setscrews, nuts and bolts. When furnished, tighten hub setscrews or bolts
to the proper torque.
3. Install all remaining safety devices and guards. Verify that the supply voltage is correct and wire the
motor. “BUMP” the starter to check for proper wheel rotation, following all safetly protocols.
4. Test the unit for start-up vibration levels.
5. Use extreme caution when testing the fan with the ductwork disconnected. Apply power and check
for unusual sounds or excessive vibration. If either exists, see the Troubleshooting section of this
manual. To avoid motor overload, do not run the fan for more than a few seconds if the ductwork is
not fully installed. Check for correct fan speed and complete the installation. Ductwork and guards
must be fully installed for safety.
If a problem is detected, SHUT THE FAN DOWN IMMEDIATELY. Lock out the electrical supply. Check
carefully for the cause of the trouble and correct as necessary.
After a brief period of operation (even if the fan appears to be operating satisfactorily), shut down the
fan, lock out the electrical supply and recheck the following items:
1. Check and tighten all fasteners.
2. Check all setscrews tighten as necessary.
3. Properly secure all safety guards.

12 13
Kice Industries, Inc. Kice Industries, Inc.
07182022 FAN-M01-0000 07182022 FAN-M01-0000
R, H  I C
4. Secure all access doors to the fan housing and the ductwork.
The fan may now be put into operation. However, during the first eight hours of operation, it should be
periodically observed and checked for excessive vibration and noise. At this time, checks should also be
performed on the motor input current and the motor temperatures to insure that they do not exceed the
manufacturer’s recommendations.
After eight hours of satisfactory operation, the fan should be shut down and the power locked out in order to
check the following items and adjust if necessary:
1. Check and tighten all fasteners.
2. Check all setscrews and tighten as necessary.
3. Properly secure all safety guards.
After twenty-four hours of satisfactory operation, the fan should be shut down, observed and checked for
excessive vibration and noise again.
5. FAN MAINTENANCE
Kice fans are manufactured to high standards with quality materials and components. Proper maintenance
will ensure a long and trouble free service life.
Do not attempt any maintenance on a fan unless the electrical supply
has been completely disconnected and locked out. In many cases,
a fan wheel can windmill despite the removal of all electrical power.
The rotating assembly should be blocked securely before attempting
maintenance of any kind.
The key to good fan maintenance is regular and systematic inspection of all fan parts. Inspection frequency
is determined by the severity of the application and local conditions. Strict adherence to an inspection
schedule is essential. Regular fan maintenance should include the following:
1. Regularly check all components that can corrode, and as a consequence result in contact between
rotating parts and fixed parts.
2. Check the fan wheel for any wear or corrosion, as this can cause catastrophic failures. Check also for
the buildup of material that can cause the wheel to be unbalanced, resulting in vibration, bearing wear
and serious safety hazards. Clean or replace the wheel as required.
NOTE: Shut the fan down immediately if there is any sudden increase in fan vibration, fan noise or visible
deformation in the fan housing.
3. Hot surfaces and gaps between rotating parts must be regularly cleaned with a vacuum cleaner and/
or an antistatic cloth so that dust cannot deposit on the housing and create a potential ignition source.
4. When performing any fan maintenance, please refer to the table of recommended hardware
torque specifications (Section 7) when re-assembling equipment. For wheel hub bolt torque
recommendations, see the wheel hub bolt torque table in this section. All setscrews and bolts should
be checked for tightness during maintenance activity.
5. When installing a new wheel or inlet section, the proper wheel to inlet clearance must be maintained.
6. Any monitoring devices supplied with the fan (such as automated temperature and vibration
monitoring systems), need to be regularly inspected.
7. See the Illustrated Parts List (Section 8) in this manual for a detailed replacement part listing.
8. Maintenance intervals for Kice Fans vary depending on the fan application. Please contact Kice
Industries, Inc. for any further information regarding fan maintenance interval requirements.
Installation of a Kice fan wheel is dierent than most other fans because of the hub design. The Kice fan
wheel uses a hub with a split taper bushing to insure accurate placement on the shaft. Using a taper hub
and bushing insures that the fan wheel will be centered and the balance is the same as when it left the
factory.
Check the hub and bushing and remove all foreign material. Inspect the surfaces and edges to insure that
there are no burrs. Clean the machined surfaces of any grit or dirt and coat with a light film of oil. Place the
fan wheel onto the shaft inside the housing. Slide the bushing onto the shaft and into the hub. Slide the
wheel forward on the bushing and insert the bolts through the bushing flange into the three tapped holes in
the hub. Check the wheel clearances inside the housing.
Tighten each bolt in turn and then use a torque wrench to set each bolt to the proper torque (see page 15).
To insure that the bushing and hub are properly seated, tap the fan wheel hub with a hammer and then
retighten the bolts with a torque wench. In most instances, the bolts will tighten another few degrees.
Rotate the wheel and listen for any rubbing sound between the wheel and housing.

14 15
Kice Industries, Inc. Kice Industries, Inc.
07182022 FAN-M01-0000 07182022 FAN-M01-0000
6. TROUBLESHOOTING GUIDE
Problem Probable Cause/Suggested Remedies
Excessive Vibration
A common complaint regarding
industrial fans is “excessive vibration”.
Kice Industries, Inc., is careful to
ensure that each fan is precisely
balanced prior to shipment; however,
there are many other causes for fan
vibration, including:
1. Loose mounting bolts or setscrews
2. Misaligned or unbalanced motor
3. Bent shaft due to mishandling or material impact
4. Accumulation of foreign material on wheel
5. Excessive wear or erosion of the wheel
6. Excessive system pressure or restriction of airflow due to
closed dampers
7. Externally transmitted vibration
Inadequate Performance
1. Fan wheel rotating in the wrong direction or installed
backwards on the shaft
2. Wheel not properly centered relative to the fan inlet
3. Damaged or incorrectly installed cuto sheet or diverter
4. Poor system design, closed dampers, air leaks, clogged filters
or coils
5. Obstructions or sharp elbows near the fan inlet
6. Sharp deflection of air stream at the fan outlet
Excessive Noise
1. Vibration originating elsewhere in the system
2. System resonance or pulsation (type of cavitation)
3. Improper location or orientation of fan discharge
4. Nearby sound reflecting o surfaces
5. Loose accessories or components
Premature component Failure
1. Prolonged or major vibration
2. Inadequate or improper maintenance
3. Abrasive or corrosive elements in the air stream or
surrounding environment
4. Misalignment or physical damage to rotating components
5. Excessive fan speed
6. Extreme ambient or air stream temperatures
7. TORQUE VALUES FOR MAINTENANCE
AND INSTALLATION
*Values above are approximations; consult with the manufacturer for torque data.
Significant variation may exist within the same grade and size between manufacturers.
Recommended U.S. BOLT TORQUE*
Coarse thread only


SAE
Grade
5
SAE
Grade
5
SAE
Grade
8
SAE
Grade
8
Socket
head
Socket
head
cap
screw
cap
screw
Bolt
Thread
Dia.
Size
1/4 20 8.4 11 12 16 11 15
5/16
18
17
24
25
33
23
31
3/8 16 31 42 44 59 41 55
7/16
14
49
67
70
95
65
59
1/2 13 74 100 110 140 100 140
9/16
12
100
140
150
210
140
200
5/8 11 140 190 210 290 200 270
3/4
10
240
330
380
510
350
480
7/8 9 390 520 610 820 570 770
1
8
570
780
910
1100
850
1200
1-1/8 7 790 1100 1300 1700
1-1/4
7
1100
1500
1800
2500
1-3/8 6 1500 2000 2400 3200
1-1/2
6
1900
2600
3200
4300
1-5/8 5.5 2400 3300 4300 5900
1-3/4
5
3000
4100
5000
6800
2 4.5 4500 6100 7500 10000
W H B T R
Model Bushing Size Bolt Size Torque (in-lbs)
KF7W4
P1 3 ea. 5/16 x 1 192
KF7W8
KF7W16
KF9W8
Q1 3 ea. 3/8 x 1 1/4 348
KF9W16

16
Kice Industries, Inc. 07182022 FAN-M01-0000
8. ILLUSTRATED PARTS LISTS
R P
It is recommended that only Kice manufactured and/or supplied replacement parts be used. Kice fan parts
are built to be fully compatible with the original fan, using specific alloys and tolerances. These parts carry a
standard Kice warranty.
When ordering replacement parts, specify the part name, Kice fan serial number, fan model, fan size, type,
configuration (viewed from the drive side), and bearing size or shaft size. Most of this information is on the
metal nameplate attached to the fan housing or cheek plate.
Example:
Part required: wheel
Kice serial number: 100515
Fan model: KF7W16 Arr.5
Suggested replacement parts include:
Wheel, Motor
1
2
3
5
6
4
Item Description
1 Motor
2 Fan Housing
3 Fan Wheel
4 Bushing
5 Eye Plate
6 Damper
COMPONENT PARTS:

18
Kice Industries, Inc. 07182022 FAN-M01-0000
© 2023 Kice Industries, Inc.
KICE INDUSTRIES, INC.
5500 N. Mill Heights Dr.
Park City, KS 67219-2358
(P) 316.744.7151
(F) 316.744.7355
[email protected]
kice.com
