Kicker AMPHITHEATER 41iK5BT2V2 User manual

AMPHITHEATER
Models: 41iK5BT2V2
Owner’s Manual | English Manual del Propietario | Español
Manuel d’utilisation | Française
TM
High Performance Audio System
Compatible with most Bluetooth devices
iK5BT2 User Manual Translations Rev 9.indd 1iK5BT2 User Manual Translations Rev 9.indd 1 3/12/2014 10:20:30 AM3/12/2014 10:20:30 AM

2ENGLISH
Setup
In the Box
power switch
reset button
Note: Press the reset button to perform a factory reset and clear Bluetooth
paired devices.
Status LED
LED color displays audio source:
• Blue - connected bluetooth device
• Purple - 1/8” (3.5mm) auxiliary input
• Orange - USB audio input
LED status indicators:
• illuminated when the AMPHITHEATER is powered
• flashes blue when in Bluetooth pairing mode
• flashes white while initializing connection
• flashes when receiving commands from the remote
• breathes slowly when your speaker is muted
Status LED
iK5BT2 User Manual Translations Rev 9.indd 2iK5BT2 User Manual Translations Rev 9.indd 2 3/12/2014 10:20:37 AM3/12/2014 10:20:37 AM

3
ENGLISH
•8-band EQ
•customizable presets
•spatialization control
•autoplay
•device firmware updates
•prioritize devices for auto-connect
•enable bluetooth auto-connect
•disconnect
For advanced DSP control and access to even more features, download the
KICKSTART app from your device’s app store.
For more information on the KICKSTART app, visit www.kicker.com/KICKSTART
Before you play your device, make sure that the input is set to the correct
source. Touch the SOURCE button to select your audio source. When the
status LED is blue, your audio source is Bluetooth.
decrease / increase volume.
mute
SOURCE | PAIR
audio source select /
press and hold to pair
Pair and Connect Bluetooth® Devices
1. Press and Hold SOURCE | PAIR button on the dock or the remote control to
enter pairing mode (status LED flashes blue).
2. From your bluetooth device menu, make sure bluetooth is enabled. Scan for
devices and pair with IK5BT2 Amphitheater.
If a code is required by your device, use [ 0000 ]
3. When your bluetooth device is paired and connected, the status LED will be
solid blue.
iK5BT2 User Manual Translations Rev 9.indd 3iK5BT2 User Manual Translations Rev 9.indd 3 3/12/2014 10:20:38 AM3/12/2014 10:20:38 AM

4ENGLISH
Play Auxiliary Devices
Touch SOURCE to listen to music
from your external device. The aux-
input is activated when the status
LED is purple.
iK5BT2 User Manual Translations Rev 9.indd 4iK5BT2 User Manual Translations Rev 9.indd 4 3/12/2014 10:20:39 AM3/12/2014 10:20:39 AM

5
ENGLISH
Using the Remote
source
trebbass
iK5BT2/IK5BTL
play / pause
mute
volume up/down
skip backward
(hold down to REW) skip forward
(hold down to FF)
bass up/down treble up/down
source select /
(hold to pair)
USB Charging
and Playback
Connect your device to the IK5BT2 via USB using only the appropriate cable
intended from the manufacturer. Press the source key until the status LED
is orange. Press play on your device and make sure the volume is turned up,
then increase the volume of the IK5BT2.
iK5BT2 User Manual Translations Rev 9.indd 5iK5BT2 User Manual Translations Rev 9.indd 5 3/12/2014 10:20:39 AM3/12/2014 10:20:39 AM

6ENGLISH
Specifications
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all the instructions listed in this manual. Keep these instructions and heed all warnings. Follow all safety and
procedural recommendations to prevent damage to your self, your KICKER product, or your portable media device.
The AMPHITHEATER should not be used near water or in an environment where exposure to liquids is possible. This
includes but is not exclusive to areas where splashing, dripping, leaks, spills, and exposure to rain can occur. Liquid
containers should not be placed on or near the AMPHITHEATER. The AMPHITHEATER should not be cleaned with liquid
cleaners. Use only a dry cloth to clean the AMPHITHEATER.
Only use the AMPHITHEATER in areas with adequate open ventilation allowing at least 4” of space on all sides of the
AMPHITHEATER. Do not set the AMPHITHEATER on any surface or cover the AMPHITHEATER with any object that could
impede the airflow to and from the AMPHITHEATER. The AMPHITHEATER should not be placed near any source of heat.
The battery pack or batteries installed shall not be exposed to excessive heat. This includes but is not limited to stoves,
radiators, heating elements, electronic heat sources, and areas where excessive solar heat can be generated. Do not place
the AMPHITHEATER near any flame or place any flammable objects near the device.
The power outlet used to provide power to the AMPHITHEATER should be accessible at all times. The power cord
should be situated in a way that protects it from being pinched, walked on, tripped over, or accidentally pulled from the
electrical outlet or the electrical input on the AMPHITHEATER. Where the MAIN plug or an appliance coupler is used
as the disconnect device, the disconnect device shall remain readily operable. Do not run the cable through doorways
or underneath objects that could damage the wire or tear the insulating material surrounding the wire. Only use the
manufacturer supplied power supply with the AMPHITHEATER. We recommend using a surge protector/power conditioner
and unplugging the AMPHITHEATER during any electrical storms or situations that could cause voltage fluctuations in the
electrical system.
DISCLAIMER: Bluetooth wireless audio compatible with most Bluetooth enabled phones, tablets and computers
•50W Stereo Amplifier with DSP
•5”[127mm] Mid-bass Woofers
•3/4”[20mm] Silk-Dome Tweeters
•6”[152mm] Square Reflex Subwoofer
24V-2.9A Power Supply
Freq. Response
40Hz—20kHz ±3dB
Weight
9.7 lbs [4.4kg]
19” [483mm]
9.14”
[232mm]
8.87”
[225mm]
USB Playback Bluetooth
iPhone (3gs, 4, 4s, 5, 5c, 5s) iPhone (3gs, 4, 4s, 5, 5c, 5s)
iPad (1st, 2nd, 3rd, and 4th Gen, Air, Mini, Mini w/ Retina) iPad (1st, 2nd, 3rd, and 4th Gen, Air, Mini, Mini w/ Retina)
iPod Nano (3rd, 4th, 5th, 6th, and 7th Gen) iPod Nano 7th Gen
iPod Touch (1st, 2nd, 3rd, 4th, and 5th Gen) iPod Touch (2nd, 3rd, 4th, and 5th Gen)
iPod Classic (120 Gb)
Compatibility List
iK5BT2 User Manual Translations Rev 9.indd 6iK5BT2 User Manual Translations Rev 9.indd 6 3/12/2014 10:20:39 AM3/12/2014 10:20:39 AM

7
ESPAÑOL
El color del LED muestra la entrada:
• Púrpura - entrada auxiliar de 1/8” (3,5 mm)
• Azul - Bluetooth del dispositivo conectado
• Naranja - entrada de audio USB
Indicadores de estado por LED:
• se ilumina cuando el AMPHITHEATER está encendido
• destella en azul cuando en modo de emparejamiento Bluetooth
• parpadea en blanco mientras realiza inicialización de conexión
• destella al recibir instrucciones desde el control remoto
• parpadea muy lentamente cuando su AMPHITHEATER está en el modo de silencio
En la Caja
interruptor de encendido
botón reiniciar
LED de Estado
LED de Estado
Nota: Presione el botón reiniciar para restablecer la configuración de fábrica y
eliminar todos los dispositivos sincronizados con Bluetooth.
iK5BT2 User Manual Translations Rev 9.indd 7iK5BT2 User Manual Translations Rev 9.indd 7 3/12/2014 10:20:39 AM3/12/2014 10:20:39 AM

8ESPAÑOL
Para un control avanzado del Procesador Digital de Señal (DSP) e incluso
tener acceso a más funciones, descargue la aplicación KICKSTART desde la
tienda de aplicaciones de su dispositivo.
• ecualización de 8 bandas
• configuraciones personalizables
• espacialización
• permite la autoconexión de bluetooth
• desconectar
• organiza los dispositivos por
autoconexión.
• actualizaciones al firmware del dispositivo
• autoplay
Descargue la aplicación KICKSTART
Antes de usar su iPod/iPhone/iPad, cerciórese de que la entrada auxiliar esté
apagada. Toque el botón SOURCE para cambiar entre su iPod/iPhone/iPad y
la entrada auxiliar. Cuando el LED de estado está blanco, la entrada auxiliar
está apagada.
reducir / aumentar volumen.
modo de silencio
FUENTE | SINCRONIZACIÓN
Selección de fuente de audio
/ presione y sostenga para
sincronizar
Sincronización y conexión de dispositivos Bluetooth®
1. Presione y sostenga el botón SOURCE | PAIR para ingresar al modo de
sincronización (la luz LED de estado parpadea en azul)
2. Desde el menú de su dispositivo bluetooth, asegúrese de que el bluetooth se
encuentra habilitado. Busque dispositivos y sincronícelos con el IK5BT2 anfiteatro.
3. Cuando su dispositivo bluetooth esté sincronizado y conectado, la luz de
estado LED se mostrará fija en azul.
iK5BT2 User Manual Translations Rev 9.indd 8iK5BT2 User Manual Translations Rev 9.indd 8 3/12/2014 10:20:40 AM3/12/2014 10:20:40 AM

9
ESPAÑOL
Conexión de Dispositivos de Audio
Toque SOURCE | PAIR
para escuchar música de su
dispositivo externo. La entrada
AUX está activa cuando el LED
de estado está púrpura.
iK5BT2 User Manual Translations Rev 9.indd 9iK5BT2 User Manual Translations Rev 9.indd 9 3/12/2014 10:20:40 AM3/12/2014 10:20:40 AM

10 ESPAÑOL
Uso del Control Remoto
source
trebbass
iK5BT2/IK5BTL
modo de silencio
reproducción / pausa
selección de fuente
(mantener al par)
subir/bajar volumen
salto hacia atrás
(sostener para REW)
salto hacia adelante
(sostener para FF)
navegación del
menú del iPod
subir/bajar graves subir/bajar agudos
Carga de dispositivos USB
Conecte su dispositivo al IK5BT2 a través del cable USB utilizando solo el
cable apropiado del fabricante. Presione la tecla fuente hasta que la LED de
estado sea naranja. Presione Reproducir en su dispositivo y asegúrese de
que el volumen esté alto, luego suba el volumen del IK5BT2.
iK5BT2 User Manual Translations Rev 9.indd 10iK5BT2 User Manual Translations Rev 9.indd 10 3/12/2014 10:20:41 AM3/12/2014 10:20:41 AM

11
ESPAÑOL
Especificaciones
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Lea y siga todas las instrucciones que figuran en este manual. Guarde estas instrucciones y siga todas las advertencias.
Siga todas las recomendaciones y procedimientos para evitar daño a usted mismo, a su producto KICKER o a su
dispositivo de medios portátil.
El AMPHITHEATER no debe usarse cerca del agua o en un entorno en donde sea posible su exposición a líquidos. Esto
incluye a, pero no es exclusivo de, áreas en donde puedan ocurrir salpicaduras, goteo, derrames y exposición a lluvia.
No deben clocarse recipientes con líquido sobre o cerca del AMPHITHEATER. El AMPHITHEATER no debe limpiarse con
limpiadores líquidos. Use sólo un trapo seco para limpiar el AMPHITHEATER.
Use el AMPHITHEATER únicamente en áreas con ventilación abierta adecuada, permitiendo al menos un espacio de 4"
(10 cm) en todos los lados del AMPHITHEATER. No coloque el AMPHITHEATER sobre cualquier superficie ni cubra el
AMPHITHEATER con objeto alguno que pueda impedir el flujo de aire hacia y desde el AMPHITHEATER. El AMPHITHEATER
no debe colocarse cerca de cualquier tipo de fuente de calor. Esto incluye a, pero no es exclusivo a estufas, radiadores,
elementos de calefacción, fuentes de calor electrónicas y áreas en donde pueda generarse calor solar excesivo. No
coloque el AMPHITHEATER cerca de llama alguna ni coloque objetos inflamables cerca del dispositivo.
Se deberá tener acceso al tomacorrientes usado para alimentar el AMPHITHEATER en todo momento. El cable de
alimentación debe colocarse de forma que esté protegido de ser pellizcado, pisado, tropiezos o ser jalado accidentalmente
del tomacorrientes eléctrico o de la entrada eléctrica del AMPHITHEATER. No tienda el cable a través de pórticos o debajo
de objetos que puedan dañar el conductor o jalar el material aislante que rodea al conductor. Use únicamente la fuente de
potencia suministrada por el fabricante con el AMPHITHEATER. Recomendamos usar un protector contra sobretensiones/
acondicionador de energía y desconectar el AMPHITHEATER durante tormentas eléctricas o situaciones que pudieran
causar fluctuaciones de voltaje en el sistema eléctrico.
• Amplificador Estéreo de 50W con DSP
• Altavoces de Medio Bajos de 5” [127 mm]
• Altavoces de Agudos de Domo 3/4” [20 mm]
• Altavoz Ultrabajo de Reflexión Cuadrado 6” [152 mm]
Fuente de Energía de 24V-2.9A
Respuesta de Frecuencia
40Hz—20kHz ±3dB
Peso
9.7 lbs [4.4kg]
19” [483 mm]
9.14”
[232 mm]
8.87”
[225 mm]
EXENCIÓN DE RESPONSABILIDAD: El audio inalámbrico de Bluetooth es compatible con la mayoría de los teléfonos,
tabletas y computadoras con capacidad Bluetooth.
Lista de Compatibilidad
Reproducción USB Bluetooth
iPhone (3gs, 4, 4s, 5, 5c, 5s) iPhone (3gs, 4, 4s, 5, 5c, 5s)
iPad (1ra, 2da, 3ra, 4ta Gen, Air, Mini, Mini con Retina) iPad (1ra, 2da, 3ra, 4ta Gen, Air, Mini, Mini con Retina)
iPod Nano (3ra, 4ta, 5ta, 6ta, y 7ma Gen) iPod Nano 7ma Gen
iPod Touch (1ra, 2da, 3ra, 4ta, y 5ta Gen) iPod Touch (1ra, 2da, 3ra, 4ta, y 5ta Gen)
iPod Classic (120 Gb)
iK5BT2 User Manual Translations Rev 9.indd 11iK5BT2 User Manual Translations Rev 9.indd 11 3/12/2014 10:20:41 AM3/12/2014 10:20:41 AM

12 FRANÇAISE
La couleur du voyant indique le type d'entrée:
• Pourpre: entrée auxiliaire 1/8” (3,5mm)
• Bleu : Bluetooth
• Orange : entrée audio USB
Indicateurs d'état du voyant:
• Allumé lorsque l'ENCEINTE est activée
• Clignote bleu brièvement lorsqu’il est en mode d’appairage Bluetooth
• Clignote en blanc lors de initialisation de la connexion
• Clignote lorsqu'une commande est envoyée par la télécommande
• Murmure doucement lorsque l'ENCEINTE est en mode muet
Installation
Contenu de la boîte
Bouton marche/arrêt
bouton réinitialiser
Voyant d'état
Voyant d'état
Remarque: Appuyez sur le bouton « Réinitialiser » pour rétablir les paramètres
d’usine et supprimer les appareils Bluetooth appairés
iK5BT2 User Manual Translations Rev 9.indd 12iK5BT2 User Manual Translations Rev 9.indd 12 3/12/2014 10:20:41 AM3/12/2014 10:20:41 AM

13
FRANÇAISE
Avant d'utiliser votre iPod/iPhone/iPad, assurez-vous que l'entrée auxiliaire est
désactivée. Appuyez sur la touche SOURCE | PAIR pour basculer entre votre
iPod/iPhone/iPad et l'entrée auxiliaire. Lorsque le voyant d'état est blanc,
l'entrée auxiliaire est désactivée.
diminution ou
augmentation du volume
mode muet
SOURCE | APPAIRAGE
sélectionnez la source
audio / pressez et
maintenez pour appairer
Pour un contrôle avancé DSP et l’accès à encore plus de fonctionnalités,
téléchargez le KICKSTART l’application sur l’App Store de votre appareil.
• un égaliseur à 8 canaux
• des préréglages personnalisables
• la spatialisation
• activez la connexion automatique
Bluetooth
• couper
• des mises à jour du micrologiciel de
l'appareil
• établissez l’ordre de priorité des
périphériques pour la connexion
automatique
• autoplay
Téléchargez l'application KICKSTART.
Appairer et connecter des périphériques
Bluetooth®
1 Appuyez et maintenez appuyé le bouton SOURCE | APPAIRAGE pour entrer
en mode appairage (le voyant d’état DEL clignote en bleu)
2 À partir du menu de votre périphérique Bluetooth, assurez-vous que le
Bluetooth est activé. Recherchez des périphériques et appariez-les avec
IK5BT2 l’amphithéâtre.
3 Lorsque votre périphérique Bluetooth est apparié et connecté, le voyant
d’état DEL devient bleu uni.
iK5BT2 User Manual Translations Rev 9.indd 13iK5BT2 User Manual Translations Rev 9.indd 13 3/12/2014 10:20:42 AM3/12/2014 10:20:42 AM

14 FRANÇAISE
Connexion des appareils audio
Appuyez sur SOURCE | PAIR pour
écouter de la musique de votre
dispositif externe. L'entrée auxiliaire
est activée lorsque le voyant de
statut est pourpre.
iK5BT2 User Manual Translations Rev 9.indd 14iK5BT2 User Manual Translations Rev 9.indd 14 3/12/2014 10:20:42 AM3/12/2014 10:20:42 AM

15
FRANÇAISE
Utilisation de la télécommande
source
trebbass
iK5BT2/IK5BTL
mode muet
lecture/pause
augmentation/
diminution du volume
retour en arrière
(garder appuyé pour
rembobiner)
Avance rapide
(garder appuyé pour
faire défiler)
augmentation/
diminution des
graves
augmentation/
diminution des aigus
sélection de la source
Chargement de vos appareils USB
Connecter le périphérique à l’IK5BT2 via le port USB en utilisant exclusivement
le câble préconisé par le fabricant. Appuyer sur le bouton SOURCE jusqu’à ce
que le voyant d’état devienne orange. Appuyer sur le bouton de lecture
du périphérique, vérifier que le volume est activé, puis augmenter le volume
sur l’IK5BT2.
iK5BT2 User Manual Translations Rev 9.indd 15iK5BT2 User Manual Translations Rev 9.indd 15 3/12/2014 10:20:42 AM3/12/2014 10:20:42 AM

16 FRANÇAISE
Spécifications
CONSIGNES DE SÉCURITÉ IMPORTANTES
Lisez et suivez toutes les consignes de ce manuel. Conservez ces instructions et observez tous les avertissements. Suivez
toutes les recommandations et procédures de sécurité pour éviter de vous blesser ou d'endommager votre appareil
KICKER ou votre appareil multimédia portable.
N'utilisez jamais l'ENCEINTE à proximité d'eau ou dans un environnement potentiellement exposé à des liquides. Ceci inclut,
sans s'y limiter, les endroits exposés à des éclaboussures, des égouttements, des fuites, des déversements de liquides
et à la pluie. Ne placez jamais l'ENCEINTE à proximité d'un récipient de liquides. Ne nettoyez jamais l'ENCEINTE avec des
produits liquides. Utilisez seulement des tissus secs pour nettoyer l'ENCEINTE.
Utilisez uniquement l'ENCEINTE dans des endroits bien ventilés avec au moins 10 cm d'espace de chaque côté de
l'ENCEINTE. Ne placez pas l'ENCEINTE sur une surface qui pourrait empêcher l'air de circuler autour et ne la recouvrez pas.
Ne positionnez pas l'ENCEINTE à proximité d'une source de chaleur. Ceci inclut, sans s'y limiter, les poêles, les radiateurs,
les éléments de chauffage, les sources de chauffage électroniques ou les endroits trop exposés au soleil. Ne placez pas
l'ENCEINTE à proximité d'une flamme ou d'un objet inflammable.
La prise d'alimentation qui se connecte à l'ENCEINTE devrait être accessible à tout moment. Le câble d'alimentation devrait
être positionné de manière à ne jamais pouvoir être coincé, à ce qu'on ne puisse pas marcher dessus ou se prendre
les pieds dedans, et à ce qu'il ne puisse pas être arraché accidentellement de la prise à laquelle il est branché ou de
l'entrée de connexion de l'ENCEINTE. Ne faites pas passer les câbles sous les portes ou sous des objets qui pourraient
endommager les fils ou arracher le matériau isolant qui protège le câble. Utilisez uniquement l'alimentation fournie par
le fabricant de l'ENCEINTE. Il est recommandé d'utiliser un dispositif antisurtension ou un onduleur et de débrancher
l'ENCEINTE en cas d'orage ou de situation qui pourrait causer des variations de tension dans le système électrique.
• Amplificateur stéréo 50W avec DSP
• Haut-parleurs medium bass 5” [127mm]
• Tweeters à dômes en soie 3/4” [20mm]
• Caisson de basse reflex carré 6” [152mm]
Alimentation 24V-2,9A
Réponse en fréquence
40Hz—20kHz ±3dB
Poids
4,4 kg
19” [483mm]
9,14”
[232mm]
8,87”
[225mm]
Compatible avec
CLAUSE DE NON-RESPONSABILITÉ: Bluetooth wireless audio est compatible avec la plupart des ordinateurs, tablettes et
téléphones équipés de la technologie Bluetooth
Lecture USB Bluetooth
iPhone (3gs, 4, 4s, 5, 5c, 5s) iPhone (3gs, 4, 4s, 5, 5c, 5s)
iPad (1ère, 2ème, 3ème, et 4ème génération, Air, Mini, Mini avec Retina) iPad (1ère, 2ème, 3ème, et 4ème génération, Air, Mini, Mini avec Retina)
iPod Nano (3ème, 4ème, 5ème, 6ème, et 7ème génération) iPod Nano 7ma génération
iPod Touch (1ère, 2ème, 3ème, 4ème, et 5ème génération) iPod Touch (1ère, 2ème, 3ème, 4ème, et 5ème génération)
iPod Classic (120 Go)
iK5BT2 User Manual Translations Rev 9.indd 16iK5BT2 User Manual Translations Rev 9.indd 16 3/12/2014 10:20:42 AM3/12/2014 10:20:42 AM

Warranty
KICKER warrants this product to be free from defects in material and workmanship under normal use for a period of ONE
(1) YEAR from date of original purchase with the original receipt from an Authorized KICKER Dealer. Should service be
necessary under this warranty for any reason due to manufacturing defect or malfunction during the warranty period,
KICKER will repair or replace (at its discretion) the defective merchandise with equivalent merchandise at no charge.
Warranty replacements may have cosmetic scratches and blemishes. Discontinued products may be replaced with more
current equivalent products.
This warranty is valid only for the original purchaser and is not extended to owners of the product subsequent to
the original purchaser. Any applicable implied warranties are limited in duration to a period of the express warranty
as provided herein beginning with the date of the original purchase at retail, and no warranties, whether express or
implied, shall apply to this product thereafter. Some states do not allow limitations on implied warranties; therefore these
exclusions may not apply to you. This warranty gives you specific legal rights; however you may have other rights that
vary from state to state.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
WHAT TO DO IF YOU NEED WARRANTY OR SERVICE:
Defective merchandise should be returned to your local Authorized KICKER Dealer for warranty service. Assistance in
locating an Authorized Dealer can be found at www.kicker.com or by contacting KICKER directly.
If it becomes necessary for you to return defective merchandise directly to Stillwater Designs (KICKER), call the KICKER
Customer Service Department at [phone] for a Return Merchandise Authorization (RMA) number. Package all
defective items in the original container or in a package that will prevent shipping damage, and return to:
Stillwater Designs, 3100 North Husband, Stillwater, OK 74075
The RMA number must be clearly marked on the outside of the package. Include a copy of the original receipt with the
purchase date clearly visible, and a “proof-of-purchase” statement listing your name and return shipping address, the
Dealer’s name and invoice number, and product purchased. Warranty expiration on items without proof-of-purchase will
be determined from the type of sale and manufacturing date code. Freight must be prepaid; items sent freight-collect, or
COD, will be refused.
WHAT IS NOT COVERED?
This warranty is valid only if the product is used for the purpose for which it was designed.
It does not cover:
o Damage due to improper use.
o Damage due to improper installation of components or audio/video devices.
o Subsequent damage to other components or audio/video devices.
o Damage caused by exposure to moisture, excessive heat, chemical cleaners, and/or UV radiation.
o Damage through negligence, misuse, flood, fire, earthquake, accident, or abuse. Repeated returns for the same
damage may be considered abuse.
o Items previously repaired or modified by any unauthorized repair facility or person.
o Return shipping on non-defective items.
o Products with tampered or missing barcode labels.
o Products returned without a Return Merchandise Authorization (RMA) number.
o Freight Damage.
o The cost of shipping product to KICKER.
o Service performed by anyone other than KICKER.
HOW LONG WILL IT TAKE?
KICKER strives to maintain a goal of 1 week service for all electronics (speakers, crossovers, speaker docks, etc.)
returns. Delays may be incurred if lack of replacement inventory or parts is encountered. Failure to follow these steps
may void your warranty. Any questions can be directed to the KICKER Customer Service Department at [phone].
Contact your International KICKER dealer or distributor concerning specific procedures for your country’s warranty
policies.
Note: All specifications and performance figures are subject to change. Please visit www.kicker.com for the most
current information. Please allow two weeks of break-in time for the speakers to reach optimum performance.
iK5BT2 User Manual Translations Rev 9.indd 17iK5BT2 User Manual Translations Rev 9.indd 17 3/12/2014 10:20:43 AM3/12/2014 10:20:43 AM

Garantía Internacional
Versión Español
Comuníquese con su concesionario o distribuidor KICKER internacional para obtener infor ación sobre procedimientos específicos relacionados con las normas de
garantía de su país.
Garantie Internationale
Version Française
Pour connaître les procédures propres à la politique de garantie de votre pays, contactez votre revendeur ou distributeur International KICKER.
The AMPHITHEATER was not tested on animals (other than humans) nor put through OTA testing.
El AMPHITHEATER no fue probado en animales (sólo en seres humanos) ni fue sometido a pruebas OTA.
Der AMPHITHEATER wurde nicht an Tieren (außer Menschen) getestet und auch keinen Over-the-Air-Tests unterzogen.
L’AMPHITHEATER n’a fait l’objet d’aucun test sur des animaux (autres qu’humains) ni autres tests OTA (« over the air »).
iPhone, iPod, iPod classic, iPod nano, iPod Touch and iPad are trademarks of Apple Inc., registered in the U.S. and other countries.
iPhone, iPod, iPod classic, iPod nano, iPod touch e iPad son marcas registradas de Apple Inc., registradas en los EE. UU. y en otros países.
iPhone, iPod, iPod classic, iPod nano, iPod touch und iPad sind Handelsmarken von Apple Inc. und in den USA und anderen Ländern eingetragen.
iPhone, iPod, iPod classic, iPod nano, iPod touch et iPad constituent des marques déposées d’Apple Inc., enregistrées aux États-Unis et dans d’autres pays.
© 2014 Stillwater Designs 41IK5BT2V2-AMPHITHEATER-20140310
C22.2No.60065
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between
the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced
radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This
device complies with Part 15 of the FCC Rules. Operation is subjectto the following two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
Radiation Exposure Statement:
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IC Statement:
IC Regulations:This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil numerique de classe B est conforme aux normes canadiennes ICES-003 et RSS-210. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet
appareil ne doit pas causer d’interference et (2) cet appareil doit accepter toute interference, notamment les interferences qui peuvent affecter son fonctionnement.
“This Class B digital apparatus complies with Canadian ICES-003.
Cetappareilnumériquede la classeB estconformeàla normeNMB-003 du Canada.
This Category II radiocommunicationdevice complies with Industry Canada Standard RSS-310. Cedispositifde radiocommunicationde catégorieII respectela normeCNR-310
d’IndustrieCanada.
IMPORTANT NOTE:
IC Radiation Exposure Statement
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.
REMARQUE IMPORTANTE :
Déclaration relative à l’exposition aux radiations IO
Cet appareil et son/ses antenne(s) ne doivent pas être colocalisés ni fonctionner en conjonction avec une autre antenne ou un autre émetteur.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
WARNING:
1. The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like.
2. Do not ingest battery, chemical burn hazard.
3. This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
4. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children.
5. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
6. Use only power supplies listed in the user manual (Golden Profit Electronics Ltd, Model: GPE060D240290D)
7. Unplug the apparatus during lightning storms or when unused for long periods of time.
8. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid
has
been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
9. Please refer to the information on exterior bottom enclosure for electrical and safety Information before installing or operating the apparatus.
FCC ID: TQYBS41IK5BTL00
IC: 6233A-41IK5BTV
iK5BT2 User Manual Translations Rev 9.indd 18iK5BT2 User Manual Translations Rev 9.indd 18 3/12/2014 10:20:43 AM3/12/2014 10:20:43 AM
