King-Pigeon security W12 User manual


HD Camera
WIFI Network
Wireless Sensors
Movement Detection
Email Notification
App Push Notification
SMS & Phone Call Notification
User Manual
Ver 1.2
GSMWIFICAMERAALARMSYSTEM
HDWIFICamerawithSMS&PhoneCallNotification



Table of Content
1. The Introduction.........................................................................................................3
2. The Specification.......................................................................................................3
3. The Diagram. .............................................................................................................4
4. The Settings of WIFI camera...................................................................................5
4.1 The User Registration...................................................................................5
4.2 The Mobile APP Settings..............................................................................5
4.3 Add Wireless Sensors...................................................................................6
4.4 The PC CMS Settings...................................................................................8
5. The Settings of GSM Alarms...................................................................................9
6. The Warranty............................................................................................................12
Safe Startup
Do not use GSM unit when using GSM equipment is prohibited or might bring disturbance or danger.
Interference
All wireless equipment might interfere network signals of GSM unit and influence its performance.

GSM3GWIFICameraAlarmSystem
3
1. The Introduction.
The GSM WIFI Camera is specially designed for home security.It could be used as a HD WIFI
Camera Alarm System and a GSM SMS Alarm System.
The WIFI Camera had included most functions of the WIFI camera in the present market, and
meanwhile its GSM alarm system can support 64 wireless zones, and support App push notification,
SMS & Phone call notification, Email Notification.
2. The Specification.
GSM Alarm
SIM Card Frequency Quad-band: 850/900/1800/1900 Mhz 3G WCDMA : 900/2100MHz UMTS ;
3G: 850/1900MHz UMTS. 3G: 850/2100MHz UMTS.
Wireless Zones (433.92Mhz) 64 wireless zones for wireless sensors.
8 zones for remote controls.
Phone Numbers 9 , SMS notification or phone call notification.
WIFI Camera
Alarm Notification Speaker Alarm, Alarm Recording, Screen shot,
Email Alert, SMSAlert, Phone call Alert.
Main Processor Embedded Hi3518E
Operating System LINUX
Image Sensor 1.3MP CMOS
Image Coding Standard H.264
Video Standard PAL
Image Quality 720P: 1280*720
Replay Image Quality 720P @ 25 fps
Motion Detect Yes
LUX 0.1 LUX/F1.2
Infrared Yes
2 way Voice Communication Yes
Screen Shot Yes
Coding Standard G.711A
Audio 45dB Microphone, Inbuilt 8Ω， 1W Speaker
Functions Manually Recording, Dynamically Motion Recording, Timing
Recording, Alarm Recording
Memory Extra one TF card, Max. 32G
Network RJ45 Interface, 10/100 self-adaption
WIFI 802.11 b/g/n
Power Supply DC 5V 2A
PTZ Control Inbuilt horizontal and vertical control motor
Consumption 1.5W
Humidity & Temperature 10％-90％0℃- + 55℃
Size and Weight 103*110*112mm 300g

GSM3GWIFICameraAlarmSystem
4
3. The Diagram.
Network Interface When using a network cable connected to the Internet use.
GSM antenna GSM signal reception.
WIFI antenna WIFI signal reception.
TF Card Max. 32G
Power Adapter DC 5V, 2A.
Micro Speaker
WIFI Antenna
GSM Antenna PPower Adapter
TF Card
SIM Card
Network Interface
Used to connect with the LAN port of the Router.

GSM3GWIFICameraAlarmSystem
5
4. The Settings of WIFI camera.
Please scan the QR code to download the mobile app:
Or visit: http://yoosee.co/
4.1 The User Registration.
Use your mobile phone number or email to register a user ID according to your country code.
4.2 The Mobile APP Settings.
There are 2 different ways for camera connection.
4.2.1 Wired Connection via RJ45 port.
Use a network cable to connect the camera network interface to the router LAN interface
(make sure the router is turned on DHCP function), the network indicator will be activated after
connection successfully.
4.2.2 WIFI Connection via the Mobile APP.
Open your mobile APP with your user ID, then follow the step as below:

GSM3GWIFICameraAlarmSystem
6
4.2.2.1 add the device by ‘Smartlink’
Make sure your mobile and your camera are using the same WIFI network in your first programming.
Please click 【Smartlink】and follow the step as below, the app will add all the cameras automatically.
4.2.2.2 Add device manually:
Make sure the camera’s power is on, and connect with the WIFI network already, then Click
【Manual】, it will be like the picture as below:
4.3 Add Wireless Sensors.
Video settings
The max memory is 32G with the TF card, if need record video, please insert the memory card at first.
【Device】→【 Device name】→【 settings】→【 video settings】
Playback: 【Device】→【 Device name】→【Playback】
Please find the device name and device ID
and default password on the label of the
camera.

GSM3GWIFICameraAlarmSystem
7
Zone Settings.
Note: This function is optional, please make sure your device has this function.
The device supports 8 pcs remote controls, 64 wireless zones (433 frequency), supports 8 groups.
Learning the code as follows
Click【Device】→【Device name】→【Settings】→【Defense Area settings】
.
E.g.. : Add door sensor in the hall, the serial number is 1.
1. Click 【hall】→【number 1】→pop-up.
2. Click【confirm】, then trigger the door sensor, you will learn into the camera successfully. if match
code successfully, the words will be turn blue from gray, and Pop-up: ‘’learn successfully.’’
3. Back to device list interface, click the right lock key of the device【Arming】, wait for 15s, then
trigger the sensor, the camera will get alarm.
【Remote control】,
This is for the remote control to arm/disarm the camera.
Alarm Settings.
Click【Device】→【Device name】→【Settings】→【Alarm settings】
add receiving alert APP ID in binding account, alarm write the receiving alarm email address.
Motion detection:
When the camera detect the movement in the video, it will send a notification in the APP.
Buzzer:
Open the Buzzer, when there is alert, the inbuilt buzzer will work until disarming.
Equipment Upgrade:
Click【Device】→【Device name】→ 【Settings】→【Check for Device Update】

GSM3GWIFICameraAlarmSystem
8
4.4 The PC CMS Settings.
Please download the PC CMS software at http://yoosee.co/
Log Account in PC.
Two different ways to log in as below:
1. 【Remote Log In】: Use the ID of your mobile app to log in.
2. 【log on locally】: The account is:admin, password:00000000
When the PC software choose ” log on locally”.
the account is:admin,password: 00000000
Add the device to PC.
On the left side of the “CMS” software interface, click the button 【+】, fill the 【device name】and
【device ID】and 【password】, then click 【OK】
Device monitoring in PC. 【device name】→【start monitor】

GSM3GWIFICameraAlarmSystem
9
The video setting in PC.
Click on the monitor screen, select【start video】(Notice: the video will save the local on your PC)
Playback: this device can playback the video from computer, open the CMS software, choose
“playback”, user can find the playback files according to the data, the play it directly.
(Note: the video in computer hard disk only can be played in PC, does not support playing in mobile)
Restore factory settings
Reset will delete all user settings: including WIFI information, access password, alarm information,
arming zones information.
The steps: find the reset hole at the button of the device, and then use needle to insert it, press it
more than three seconds after hearing “di” sound, when hearing the sound like” drawing the sword”
reset successfully.
5. The Settings of GSM Alarms.
The SMS commands below are send to the SIM card of WIFI Camera for remote configuration.
Notice:
1) All the letters in SMS commands must be CAPITALIZED under the English format.
2) The Examples below are only for reference, please send the SMS commands according to your actual situations.
3) The default password (1234), please use the new password when the default password was changed.
1）Enable / Disable the GSM Alert.
SMS Commands Return SMS Message
Password + SAX# Set OK!
For Example:1234SA0#
Notice : X：0 or 1
1234SA0#：Only when the WIFI network failed, the SMS or phone call notification will be activated.
1234SA1#：The SMS and Phone Call notification is always working. (The Factory Default)

GSM3GWIFICameraAlarmSystem
10
2）Set the phone number to receive the alert. (Max. 9 phone numbers)
SMS Commands Return SMS Message
Password + Serial Number +A + Function Code + # + Phone Number + # Tel1: Empty
Tel2: Empty
Tel3: 18676734714 - 1
Tel4: Empty
Tel5: Empty
Tel6: Empty
Tel7: Empty
Tel8: Empty
Tel9: Empty
For Example:
12343A1#18676734714#
Serial Number: 1 - 9
Function Code: 1 - 3
Phone number: Max. 21 digits
3）Check the list of the phone number .
SMS Commands Return SMS Message
Password + A# Tel1: Empty
Tel2: Empty
Tel3: 18676734714 - 1
Tel4: Empty
Tel5: Empty
Tel6: Empty
Tel7: Empty
Tel8: Empty
Tel9: Empty
For Example:
1234A#
4）Delete the phone number in the List.
SMS Commands Return SMS Message
Password + Serial Number + A# Tel1: Empty
Tel2: Empty
Tel3: Empty.
Tel4: Empty
Tel5: Empty
Tel6: Empty
Tel7: Empty
Tel8: Empty
Tel9: Empty
For Example:
12343A#
Serial Number: 1 - 9
5）Change the password (The default password is 1234, with 4 digits):
SMS Commands Return SMS Message
Old Password＋P＋New Password 【New Password】,This is the New Password, please remember it carefully.
For Examples: 1234P4321
Notice: When the password was forgot, please reset the camera.
Function Code Description
1 SMS & Phone Call
2 Only SMS Notification
3 Only Phone Call
