Kirby Morgan PIONEER Installation guide

PIONEER
INSTRUCTIONS AND WARRANTY
THE INNOVATION CONTINUES

OVERVIEW
1Hour hand
2Minute hand
3Seconds hand
4Date window
5Unidirectional rotatable
graduated bezel in ceramic
6Winding crown
7Automatic helium release
S
W
I
S
S
M
O
V
T
DIVER’S 1000 m
PIONEER
THE INNOVATION CONTINUES
1 2
43
5
6
7
2

It may be necessary to manually
wind your automatic watch, on
occasion, including right out of
the box, or if it rests for more
than 40 hours without wear.
Unscrew the crown counter-
clockwise until it spins freely.
Advance the crown clockwise
20–30 times.
Push the crown back into the
case, turning it clockwise while
applying pressure towards the
case, until snug.
S
W
I
S
S
M
O
V
T
DIVER’S 1000 m
PIONEER
THE INNOVATION CONTINUES
WEARING THE WATCH FOR THE FIRST TIME
3

Unscrew the crown counter-
clockwise until it spins freely
(position 0), then pull the
crown out to the first click
(position 1).
Turn the crown clockwise to
advance the date (position 1).
Push the crown back into
the case. Turn the crown
clockwise while applying
pressure towards the case,
until snug (position 0).
SETTING THE DATE
S
W
I
S
S
M
O
V
T
DIVER’S 1000 m
PIONEER
0 1
THE INNOVATION CONTINUES
4

Unscrew the crown
counter-clockwise until it
spins freely (position 0),
then pull the crown out to
the second click (position
2).
Turn the crown clockwise
(or counter-clockwise)
to the appropriate time
(position 2).
Push the crown back into
the case. Turn the crown
clockwise while applying
pressure towards the case,
until snug (position 0).
SETTING THE TIME
S
W
I
S
S
M
O
V
T
DIVER’S 1000 m
PIONEER
0 1 2
THE INNOVATION CONTINUES
5

HOW TO REMOVE THE LINKS
1There are arrows on the inside links of
the metal bracelet. These are the links
that are removable.
2Notice the small holes on the edge of
the metal bracelet. To remove a link you
will need to push out the small “hairpin”
style pins using a pin pusher or similar
tool—be careful not to scratch the metal.
Press the “hairpin” style pins out in the
direction of the arrow.
3Reinstall the “hairpin” style pins in the
reverse order.
2
1
2
6

HOW TO CHANGE THE BANDS
1Locate the small holes and set screws at
the end of the watch lugs on the crown
side, this is where the band attaches to
the watch.
2The set screw is 22.5mm long and goes
from one side of the watch lugs to the
other. Use the provided screwdriver to
unscrew the set screw until the threads
fully release—you should feel less tension
on the set screw. The set screw will not
be fully removed, at this point pull the
screw all of the way out.
3To install a new strap, reverse the order of
the strap removal procedures. DO NOT
OVER TIGHTEN THE SET SCREWS, the
screws only need to be snug.
1
2
7

WETSUIT EXTENDER
S
W
I
S
S
M
O
V
T
Your watch is equipped with a ratchet style
wetsuit extension. This will allow you to
determine the amount of extension needed
with the push of a button.
1Locate the larger buttons—one on each
side of the buckle across from each
other. Simultaneously push the buttons.
While the buttons are held down, you
can adjust the extension in and out
freely.
2Adjust the extension to the desired size
and release the buttons to lock the
extension in place. Keep the extension
free of dirt, sand, or debris. If exposed to
these simply rinse with fresh water.
1
2
8

Your KIRBY MORGAN watch is a
precision device, thus it requires
appropriate care, both to protect
your investment and to maintain
good working order.
Daily activities, as well as normal
sports activities, will not affect the
integrity of the watch. A violent
shock, such as a drop or impact
may upset the movement, and the
watch’s ability to keep correct time,
however.
Your watch should only be cleaned
with water and a soft cloth.
Metal bracelets should be cleaned
with a soft brush or cloth, warm
soapy water, rinsed clean and dried
with a soft cloth.
If your watch is immersed in water
on a regular basis, it should be
inspected annually to verify water
resistance.
If wearing your watch in salt
water, thoroughly rinse the case
and bracelet in fresh water when
finished.
The maximum water resistance
depth is engraved on the case back,
or can be found on the dial. Never
wind or pull out the crown when the
watch is wet or underwater.
The water resistance indicated is
CARING FOR YOUR WATCH
9

tested at a static level of pressure.
Underwater activities create
additional pressures on the watch,
which are greater than the normal or
actual depth.
Guidelines for water resistance
50 Meters / 5 ATM / 165 Feet
suitable for swimming
100 Meters / 10 ATM / 330 Feet
suitable for swimming and snorkeling
200 Meters / 20 ATM / 660 Feet
suitable for recreational scuba diving
300 Meters / 30 ATM / 1000 Feet
suitable for professional diving
Avoid wearing your watch in
saunas and hot tubs, as the high
temperatures can affect the watch’s
water resistance.
Avoid bathing or showering with
your watch, as prolonged exposure
to soap can reduce the watch’s
water resistance, over time.
10

KIRBY MORGAN backs our watches
with a one year conditional warranty.
This warranty covers defects in the
build quality of the watch, including
movement. This excludes the strap,
and normal wear and tear.
Further, the warranty does not cover
damage to the watch from water
leaking into the case due to an
unsecured crown.
KIRBY MORGAN reserves the sole
right to determine whether a watch
is covered under the conditional
warranty.
WARRANTY AND REFUNDS
11
