INSTALLATION INSTRUCTIONS
27" (68.6 CM) AND 30" (76.2 CM) ELECTRIC BUILT-IN
CONVECTION MICROWAVE OVEN
INSTRUCTIONS D’INSTALLATION
FOUR À MICRO-ONDES ENCASTRÉ ÉLECTRIQUE
À CONVECTION DE 27" (68,6 CM) ET 30" (76,2 CM)
Table of Contents/Table des matières
BUILT-IN MICROWAVE OVEN SAFETY.......................................2
INSTALLATION REQUIREMENTS................................................3
Tools and Parts ............................................................................3
Location Requirements................................................................3
Electrical Requirements ...............................................................4
INSTALLATION INSTRUCTIONS..................................................5
Prepare Built-In Microwave Oven................................................5
Make Electrical Connection .........................................................5
Install Microwave Oven................................................................7
Complete Installation ...................................................................7
SÉCURITÉ DU FOUR À MICRO-ONDES ENCASTRÉ................9
EXIGENCES D'INSTALLATION...................................................10
Outillage et pièces......................................................................10
Exigences d'emplacement.........................................................10
Spécifications électriques ..........................................................11
INSTRUCTIONS D’INSTALLATION.............................................12
Préparation du four à micro-ondes encastré.............................12
Raccordement électrique...........................................................12
Installation du four à micro-ondes .............................................14
Achever l'installation ......................................................................14
8304424B

2
BUILT-IN MICROWAVE OVEN SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING

3
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
Parts needed
■A UL listed or CSA approved conduit connector
■UL listed wire connectors
Parts supplied
■2 screws
Check local codes. Check existing electrical supply. See
“Electrical Requirements.”
It is recommended that all electrical connections be made by a
licensed, qualified electrical installer.
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
■Cabinet opening dimensions that are shown must be used.
Given dimensions provide minimum clearance with
microwave oven.
■Recessed installation area must provide complete enclosure
around the recessed portion of the microwave oven.
■Grounded electrical supply is required. See “Electrical
Requirements” section.
■Electrical supply junction box should be located 3" (7.6 cm)
maximum below the support surface when the microwave
oven is installed in a wall cabinet. A 1" (2.5 cm) minimum
diameter hole should have been drilled in the right rear or left
rear corner of the support surface to pass the appliance cable
through to the junction box.
NOTE: For undercounter installation, it is recommended that
the junction box be located in the adjacent right or left
cabinet. If you are installing the junction box on rear wall
behind the microwave oven, the junction box must be
recessed and located in the upper or lower right or left corner
of the cabinet; otherwise, the microwave oven will not fit into
the cabinet opening.
■Microwave oven support surface must be solid, level and
flush with bottom of cabinet cutout. Floor must be able to
support a weight of 110 lbs (50.0 kg).
Product Dimensions
27" (68.6 cm) and 30" (76.2 cm) Microwave Ovens
Cabinet Requirements
27" (68.6 cm) and 30" (76.2 cm) Microwave Ovens
■Philips screwdriver
■Measuring tape
■Level
■Drill (for wall cabinet installations)
■1" (25 mm) drill bit (for wall
cabinet installations)
27" (68.6 cm) models
A. 25
⁵⁄₁₆ " (64.3 cm) recessed
width
B. 20
⁵⁄₁₆ " (51.6 cm) overall height
C. 26
³⁄₄ " (67.9 cm) overall width
D. 23" (58.3 cm) max. recessed
depth
E. 18
³⁄₄ " (47.6 cm) recessed
height
30" (76.2 cm) models
A. 28
⁵⁄₁₆ " (71.9 cm) recessed
width
B. 20
⁵⁄₁₆ " (51.6 cm) overall height
C. 29
³⁄₄ " (75.6 cm) overall width
D. 23" (58.3 cm) max. recessed
depth
E. 18
³⁄₄ " (47.6 cm) recessed
height
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C.
40 " (101.2 cm) bottom of
cutout to floor (recommended)
D. 25
¹⁄₂ " (64.8 cm) cutout width
E. 1
¹⁄₂ " (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 19
⁷⁄₁₆ " (49.4 cm) cutout height
30" (76.2 cm) models
A.
30 " (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C.
40 " (101.2 cm) bottom of
cutout to floor (recommended)
D. 28
¹⁄₂ " (72.4 cm) cutout width
E. 1
¹⁄₂ " (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 19
⁷⁄₁₆ " (49.4 cm) cutout height
A
B
E
DC
A
B
D
E
F
C

4
Cabinet Side View
Electrical Requirements
If codes permit and a separate ground wire is used, it is
recommended that a qualified electrical installer determine that
the ground path and wire gauge are in accordance with local
codes.
Check with a qualified electrical installer if you are not sure the
microwave oven is properly grounded.
This microwave oven must be connected to a grounded metal,
permanent wiring system.
Be sure that the electrical connection and wire size are adequate
and in conformance with the National Electrical Code, ANSI/
NFPA 70-latest edition or CSA Standards C22.1-94, Canadian
Electrical Code, Part 1 and C22.2 No. O-M91-latest edition, and
all local codes and ordinances.
A copy of the above code standards can be obtained from:
National Fire Protection Association
One Batterymarch Park
Quincy, MA 02269
CSA International
8501 East Pleasant Valley Road
Cleveland, OH 44131-5575
Electrical Connection
To properly install your microwave oven, you must determine the
type of electrical connection you will be using and follow the
instructions provided for it here.
■Microwave oven must be connected to the proper electrical
voltage and frequency as specified on the model/serial
number rating plate. The model/serial number rating plate is
located on the right-hand microwave oven frame.
■When a 4-wire, single phase 208/220 volt, 60 Hz, AC only
electrical supply is required, a 20-amp maximum circuit
protection is required, fused on both sides of the line.
■A time-delay fuse or circuit breaker is recommended.
■Connect directly to the fused disconnect (or circuit breaker
box) through flexible, nonmetallic sheathed, copper cable
(with grounding wire). See “Make Electrical Connection”
section.
■Flexible cable from the microwave oven should be connected
directly to the junction box.
■Do not cut the conduit. The length of conduit provided is for
serviceability of the microwave oven.
■A UL listed or CSA approved conduit connector must be
provided.
■If the house has aluminum wiring, follow the procedure
below:
1. Connect a section of solid copper wire to the pigtail
leads.
2. Connect the aluminum wiring to the added section of
copper wire using special connectors and/or tools
designed and UL listed for joining copper to aluminum.
Follow the electrical connector manufacturer's recommended
procedure. Aluminum/copper connection must conform with
local codes and industry accepted wiring practices.
A. 23 ¹⁄₄ " (59.1 cm) min. cutout depth
B. 23" (58.4 cm) recessed oven depth
C. Oven front
D. Recessed oven
E. Cabinet
A
B
C
D
E
For a permanently connected microwave oven:
The microwave oven must be connected to a grounded,
metallic, permanent wiring system, or an equipment
grounding conductor should be run with the circuit
conductors and connected to the equipment grounding
terminal or lead on the microwave oven.
GROUNDING INSTRUCTIONS
SAVE THESE INSTRUCTIONS
A. Model/serial number plate
A

5
INSTALLATION INSTRUCTIONS
Prepare Built-In Microwave Oven
1. Locate existing wiring to avoid drilling into or severing wiring
during installation.
2. To avoid floor damage, set the microwave oven onto
cardboard prior to installation. Do not use handle or any
portion of the front frame for lifting.
3. Remove the shipping materials and tape from the microwave
oven.
4. Remove and set aside racks and other items from inside the
microwave oven.
5. Remove the hardware package from inside the bag
containing literature.
6. Move the microwave oven and cardboard close to the
microwave oven’s final location.
Make Electrical Connection
This microwave oven is manufactured with a neutral (white)
power supply wire and a cabinet-connected green (or bare)
ground wire twisted together.
1. Disconnect power.
2. Feed the flexible cable conduit from the microwave oven
through the opening in the cabinet.
3. Remove junction box cover if it is present.
4. Install a UL listed or CSA approved conduit connector to the
junction box.
5. Route the flexible cable conduit from the microwave oven to
the junction box through a UL listed or CSA approved conduit
connector.
6. Tighten screws on conduit connector.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
microwave oven.
Failure to do so can result in back or other injury.
A. UL listed or CSA approved conduit connector
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Use 12 gauge solid copper wire.
Electrically ground oven.
Failure to follow these instructions can result in death,
fire, or electrical shock.
A

6
4-Wire Cable from Home Power Supply
IMPORTANT: Use the 4-wire cable from home power supply in
the U.S. where local codes do not allow grounding through
neutral, New Branch circuit installations (1996 NEC), mobile
homes and recreational vehicles, new construction and in
Canada.
1. Connect the 2 black wires (B) together using a UL listed wire
connector.
2. Connect the 2 red wires (C) together using a UL listed wire
connector.
3. Untwist white wire from green (or bare) ground wire coming
from the microwave oven.
4. Connect the 2 white wires (F) together using a UL listed wire
connector.
5. Connect the green (or bare) ground wire (H) from the oven
cable to the green (or bare) ground wire (in the junction box)
using a UL listed wire connector.
6. Install junction box cover.
Install Microwave Oven
1. Using 2 or more people, lift microwave oven partially into
cabinet cutout.
NOTE: Push against seal area of microwave oven front frame
when pushing microwave oven into cabinet. Do not push
against outside edges.
2. Push against the front of the microwave oven to push oven
into cabinet. Push microwave oven completely into cabinet
and center in cabinet cutout.
3. Securely fasten microwave oven to cabinet using the 2
screws provided. Insert the screws through holes in mounting
rails. Do not overtighten screws.
4. Replace oven racks, turntable and support hub.
5. Reconnect power.
6. Display panel will light briefly, and “PF” should appear in the
display.
7. If display panel does not light, please reference the
“Assistance or Service” section of the Use and Care Guide or
contact the dealer from whom you purchased your
microwave oven.
A. Cable from home power supply
B. Black wires
C. Red wires
D. 4-wire flexible cable from
microwave oven
E. Junction box
F. W h i t e w i r e s
G. UL listed wire connectors
H. Green (or bare) ground wires
I. UL listed or CSA approved
conduit connector
A
B
C
D
E
F
G
H
I
A. Two screws

7
Complete Installation
1. Check that all parts are now installed. If there is an extra part,
go back through the steps to see which step was skipped.
2. Check that you have all of your tools.
3. Dispose of/recycle all packaging materials.
4. For microwave oven use and cleaning, read the Use and Care
Guide.
Check Operation of Microwave Oven
1. Turn power on.
2. When “CLOCK ENTER TIME” appears in the display, press
START/ADD A MINUTE.
3. Fill a microwave-safe container with 1 cup (250 mL) of water
and place container inside microwave oven on the turntable.
Close door firmly.
4. Touch START/ADD A MINUTE twice to set cooking time to
“2:00” minutes. Microwave should begin cooking, interior
light should be on, and the display should count down the
remaining time.
If microwave does not operate, check the following:
■Household fuse is intact and tight; or circuit breaker has
not tripped.
■Electrical supply is connected;
■See “Troubleshooting” section in the Use and Care Guide.
■If an error code (“F” followed by a number plus “E”
followed by a number) appears in the display, turn off the
microwave oven and contact a qualified technician.
5. When the display reads “1:00” minute, open the microwave
oven door. The microwave should stop cooking. Close door
firmly. The interior microwave oven light should turn off.
6. Press START/ADD A MINUTE to resume preset cycle.
Microwave should begin cooking, and the microwave oven
interior light should be on.
Let microwave oven complete cooking time. A tone will
sound 3 times at the end of the cooking time.
7. Open microwave oven door and slowly remove container.
Water in container should be hot.
If you need Assistance or Service:
Please reference the “Assistance or Service” section of the Use
and Care Guide or contact the dealer from whom you purchased
your built-in microwave oven.

8
Notes

9
SÉCURITÉ DU FOUR À MICRO-ONDES ENCASTRÉ
Risque possible de décès ou de blessure grave si vous ne
suivez pas immédiatement les instructions.
Risque possible de décès ou de blessure grave si vous
ne suivez pas les instructions.
Tous les messages de sécurité vous diront quel est le danger potentiel et vous disent comment réduire le risque de blessure et
ce qui peut se produire en cas de non-respect des instructions.
Votre sécurité et celle des autres est très importante.
Nous donnons de nombreux messages de sécurité importants dans ce manuel et sur votre appareil ménager. Assurez-vous de
toujours lire tous les messages de sécurité et de vous y conformer.
AVERTISSEMENT
DANGER
Voici le symbole d’alerte de sécurité.
Ce symbole d’alerte de sécurité vous signale les dangers potentiels de décès et de blessures graves à vous
et à d’autres.
Tous les messages de sécurité suivront le symbole d’alerte de sécurité et le mot “DANGER” ou
“AVERTISSEMENT”. Ces mots signifient :

10
EXIGENCES D'INSTALLATION
Outillage et pièces
Rassembler les outils et pièces nécessaires avant de commencer
l'installation. Lire et suivre les instructions fournies avec les outils
indiqués ici.
Outils nécessaires
Pièces nécessaires
■Un connecteur de conduit homologué UL ou CSA
■Des connecteurs de fils (homologation UL)
Pièces fournies
■2 vis
Consulter les codes locaux. Vérifier l'alimentation électrique
existante. Voir “Spécifications électriques”.
Toutes les connexions électriques doivent être effectuées par un
électricien qualifié et certifié.
Exigences d'emplacement
IMPORTANT : Observer les dispositions de tous les codes et
règlements en vigueur.
■Respecter les dimensions indiquées pour les ouvertures à
découper dans les placards. Ces dimensions prennent en
compte les dégagements de séparation nécessaires
nécessaires pour le four à micro-ondes.
■L'emplacement d'installation doit permettre la formation
d'une enceinte complète autour de la partie encastrée du four
à micro-ondes.
■Une source d'électricité avec liaison à la terre est nécessaire.
Voir la section “Spécifications électriques”.
■Le boîtier de raccordement doit être situé à moins de
3" (7,6 cm) au-dessous de la surface de support lorsque le
four à micro-ondes est installé dans un placard mural. Percer
un trou de diamètre 1" (2,5 cm) ou plus dans l'angle arrière
gauche ou droit de la surface de support pour le passage du
câble d'alimentation jusqu'au boîtier de connexion.
REMARQUE : Pour l'installation sous un plan de travail, on
recommande que le boîtier de connexion soit situé dans le
placard adjacent, à droite ou à gauche. Dans le cas de
l'installation du boîtier de connexion sur le mur arrière,
derrière le four à micro-ondes, le boîtier de connexion doit
être encastré et placé dans l'angle inférieur ou supérieur du
placard, à gauche ou à droite; sinon le four ne pourra pas
passer dans l'ouverture destinée à le recevoir.
■La surface de support du four à micro-ondes doit être
robuste, horizontale et en affleurement avec le bas de
l'ouverture découpée dans le placard. Le plancher doit
pouvoir supporter un poids de 110 lb (50,0 kg).
Dimensions du produit
Fours à micro-ondes de 27" (68,6 cm) et 30" (76,2 cm)
■Tournevis Phillips
■Mètre ruban
■Niveau
■Perceuse (pour l'installation
dans un placard mural)
■Foret de 1" (25 mm) (pour
l'installation dans un placard
mural)
Modèles de 27" (68,6 cm)
A. Largeur de l'encastrement
25
⁵⁄₁₆ " (64,3 cm)
B. Hauteur hors-tout
20
⁵⁄₁₆ " (51,6 cm)
C. Largeur hors-tout
26
³⁄₄ " (67,9 cm)
D. Profondeur de l'encastrement
23" (58,3 cm) max.
E. Hauteur de l'encastrement
18
³⁄₄ " (47,6 cm)
Modèles de 30" (76,2 cm)
A. Largeur de l'encastrement
28
⁵⁄₁₆ " (71,9 cm)
B. Hauteur hors-tout
20
⁵⁄₁₆ " (51,6 cm)
C. Largeur hors-tout
29
³⁄₄ " (75,6 cm)
D. Profondeur de
l'encastrement 23" (58,3 cm)
max.
E. Hauteur de l'encastrement
18
³⁄₄ " (47,6 cm)
A
B
E
DC
