KitchenAid KMCS522PP User manual

MICROWAVE OVEN WITH CONVECTION
Use & Care Guide
For questions about features, operation/performance, parts, accessories or service, call: 1-800-422-1230,
or visit our website at www.kitchenaid.com.
In Canada, for assistance, installation and service, call: 1-800-807-6777,
or visit our website at www.kitchenaid.ca.
FOUR À MICRO-ONDES À CONVECTION
Guide d’utilisation et d’entretien
Pour des questions à propos des caractéristiques, du fonctionnement/rendement, des pièces, accessoires ou service,
composer le 1-800-422-1230,
ou visiter notre site internet sur www.kitchenaid.com..
Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777,
ou visiter notre site Internet sur www.kitchenaid.ca.
HORNO MICROONDAS CON CONVECCIÓN
Manual de uso y cuidado
Si tiene preguntas sobre funciones, funcionamiento, rendimiento, piezas, accesorios o servicio técnico, llame al: 1-800-422-1230,
o bien, visite nuestro sitio web en www.kitchenaid.com.
En Canadá, para obtener asistencia, instalación y servicio, llame al: 1-800-807-6777,
o bien, visite nuestro sitio web en www.kitchenaid.ca.
W11659086A Model/Modèle/Modelo KMCS522PP

2
TABLE OF CONTENTS TABLE DES MATIÈRES
MICROWAVE OVEN SAFETY........................................................4
INSTALLATION INSTRUCTIONS...................................................6
Unpacking ....................................................................................6
Location Requirements................................................................6
Electrical Requirements ...............................................................6
PARTS AND FEATURES ................................................................7
Turntable.......................................................................................7
Grill Element .................................................................................7
Convection Element and Fan.......................................................7
MICROWAVE OVEN CONTROL....................................................8
Display..........................................................................................8
Standby mode..............................................................................8
Start..............................................................................................8
Quick start/Add 30 seconds ........................................................8
Cancel ..........................................................................................8
To use Non - Sensor Menu ..........................................................8
Clock ............................................................................................9
Tones ON/OFF..............................................................................9
To use Sensor Menu ....................................................................9
Timer.............................................................................................9
Cooking End................................................................................9
Control Lock.................................................................................9
Keypad Instructions ...................................................................10
MICROWAVE OVEN USE.............................................................13
Food Characteristics..................................................................13
Cooking Guidelines....................................................................13
Cookware and Dinnerware.........................................................14
Aluminum Foil and Metal ...........................................................14
Cook...........................................................................................14
Popcorn......................................................................................15
Reheat ........................................................................................15
Soften/Melt.................................................................................15
Steam Clean...............................................................................16
Keep Warm.................................................................................16
Grill .............................................................................................16
Auto Defrost ...............................................................................16
Convection Bake/Roast .............................................................17
Air fryer .......................................................................................17
MICROWAVE OVEN CARE..........................................................18
General Cleaning........................................................................18
TROUBLESHOOTING ..................................................................19
ASSISTANCE OR SERVICE .........................................................20
In the U.S.A. ...............................................................................20
In Canada ...................................................................................20
Replacement Parts.....................................................................20
Built-In Kits.................................................................................20
SÉCURITÉ DU FOUR À MICRO-ONDES ...................................21
INSTRUCTIONS D’INSTALLATION.............................................23
Déballage ...................................................................................23
Exigences d’emplacement.........................................................23
Spécicationsélectriques..........................................................23
PIÈCES ET CARACTÉRISTIQUES..............................................24
Plateau rotatif .............................................................................24
Élément du gril ...........................................................................24
Élément de cuisson par convection et ventilateur.....................24
COMMANDES DU FOUR À MICRO-ONDES.............................25
Afchage ....................................................................................25
Standby mode (Mode veille) ......................................................25
Start (mise en marche) ...............................................................25
Quick start/Add 30 seconds (démarrage rapide/ajouter 30
secondes)...................................................................................25
Cancel (annulation).....................................................................25
Utilisation du menu sans détection ...........................................26
Clock (Horloge)...........................................................................26
Tones ON/OFF (Signaux sonores de marche/arrêt) .................26
Utilisation du menu avec détection ...........................................26
Timer (minuterie).........................................................................26
Fin de cuisson ...........................................................................26
Control Lock (verrouillage des commandes).............................26
Instructions du clavier................................................................27
UTILISATION DU FOUR À MICRO-ONDES ...............................31
Caractéristiques des aliments....................................................31
Guide de cuisson .......................................................................31
Ustensiles de cuisson et vaisselle .............................................32
Papier d’aluminium et métal ......................................................32
Cook (cuisson)............................................................................33
Popcorn (maïs éclaté) ................................................................33
Reheat (réchauffage) ..................................................................33
Soften/Melt (ramollir/faire fondre) ..............................................34
Auto Defrost (décongélation automatique)................................34
Steam Clean (nettoyage à la vapeur).........................................34
Keep Warm (Maintien au chaud)................................................35
Grill (gril)......................................................................................35
Convection Bake/Roast (Cuisson au four/rôtissage par
convection) ................................................................................35
Air fryer (Friture à air)..................................................................36
ENTRETIEN DU FOUR À MICRO-ONDES .................................37
Nettoyage général......................................................................37
DÉPANNAGE.................................................................................38
ASSISTANCE OU DÉPANNAGE..................................................39
Aux É.-U. ....................................................................................39
Au Canada..................................................................................39
Pièces de rechange....................................................................40
Trousses pour fours encastrés...................................................40

3
SEGURIDAD DEL HORNO MICROONDAS................................41
INSTRUCCIONES DE INSTALACIÓN .........................................43
Desempaque..............................................................................43
Requisitos de ubicación.............................................................43
Requisitos eléctricos..................................................................43
PIEZAS Y FUNCIONES ................................................................44
Bandeja giratoria ........................................................................44
Elemento de asado ....................................................................44
Elemento de convección y ventilador........................................44
CONTROL DEL HORNO MICROONDAS ...................................45
Pantalla.......................................................................................45
Modo Standby (En espera) ........................................................45
Start (Inicio).................................................................................45
Quick start/Add 30 seconds (Inicio rápido/Agregar 30
segundos)...................................................................................45
Cancel (Cancelar).......................................................................45
Para utilizar el menú sin sensor .................................................45
Clock (Reloj) ...............................................................................46
Tones ON/OFF (Encendido/Apagado delos tonos)..................46
Para utilizar el menú del sensor.................................................46
Timer (Temporizador) .................................................................46
Fin de la cocción.......................................................................46
Control Lock (Bloqueo de controles).........................................46
Instrucciones del teclado...........................................................47
USO DEL HORNO MICROONDAS..............................................51
Características de los alimentos................................................51
Pautas para cocinar ...................................................................51
Utensilios de cocina y vajilla ......................................................52
Papel de aluminio y metal..........................................................52
Cook (Cocinar) ...........................................................................53
Popcorn (Palomitas de maíz) .....................................................53
Reheat (Recalentar)....................................................................53
Soften/Melt (Ablandar/Derretir)..................................................54
Auto Defrost (Descongelado automático)..................................54
Steam Clean (Limpieza con vapor)............................................54
Keep Warm (Mantener caliente).................................................55
Grill (Asar) ...................................................................................55
Convection Bake/Roast (Hornear/Rostizar por convección) ...55
Freidora de aire ..........................................................................56
CUIDADO DEL HORNO MICROONDAS ....................................57
Limpieza general ........................................................................57
SOLUCIÓN DE PROBLEMAS......................................................58
ASISTENCIA O SERVICIO TÉCNICO .........................................59
En Estados Unidos.....................................................................59
En Canadá..................................................................................59
Piezas de repuesto.....................................................................60
Juegos para empotrar................................................................60
TABLA DE CONTENIDOS

4
MICROWAVE OVEN SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
When using electrical appliances basic safety precautions should be followed, including the following:
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: To reduce the risk of burns, electric shock,
fire, injury to persons, or exposure to excessive microwave
energy:
■ Read all instructions before using the microwave oven.
■ Read and follow the specific “PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY” found in this section.
■ The microwave oven must be grounded. Connect only to
properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found in the “INSTALLATION
INSTRUCTIONS” section.
■ Install or locate the microwave oven only in accordance
with the provided Installation Instructions.
■ Some products such as whole eggs in the shell and
sealed containers - for example, closed glass jars - are
able to explode and should not be heated in the
microwave oven.
■ Use the microwave oven only for its intended use as
described in the manual. Do not use corrosive chemicals
or vapors in the microwave oven. This type of oven is
specifically designed to heat, cook, or dry food. It is not
designed for industrial or laboratory use.
■ As with any appliance, close supervision is necessary
when used by children.
■ Do not operate the microwave oven if it has a damaged
cord or plug, if it is not working properly, or if it has been
damaged or dropped.
■ The microwave oven should be serviced only by qualified
service personnel. Call an authorized service company for
examination, repair, or adjustment.
■ Do not cover or block any openings on the microwave oven.
■ Do not store this microwave oven outdoors. Do not use the
microwave oven near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or similar
locations.
■ Do not immerse cord or plug in water.
■ Keep cord away from heated surfaces.
■ Do not let cord hang over edge of table or counter.
■ See door surface cleaning instructions in the “Microwave
Oven Care” section.
■ To reduce the risk of fire in the oven cavity:
– Do not overcook food. Carefully attend the microwave
oven when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
– Remove wire twist-ties from paper or plastic bags before
placing bags in oven.
– If materials inside the oven ignite, keep oven door closed,
turn oven off, and disconnect the power cord, or shut off
power at the fuse or circuit breaker panel.
– Do not use the cavity for storage purposes. Do not leave
paper products, cooking utensils, or food in the cavity when
not in use.

5
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
■ Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing to be
boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A SPOON OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
– Do not overheat the liquid.
– Stir the liquid both before and halfway through heating it.
– Do not use straight-sided containers with narrow necks.
– After heating, allow the container to stand in the microwave
oven for a short time before removing the container.
– Use extreme care when inserting a spoon or other utensil
into the container.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure
to microwave energy. It is important not to defeat or
tamper with the safety interlocks.
(b) Do not place any object between the oven front face and
the door or allow soil or cleaner residue to accumulate on
sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there
is no damage to the:
(1) Door (bent),
(2) Hinges and latches (broken or loosened),
(3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
This device complies with Part 18 of the FCC Rules.
This device complies with Industry Canada ICES-001.

6
INSTALLATION INSTRUCTIONS
Unpacking
1. Empty the microwave oven of any packing materials.
2. Clean the inside with a soft, damp cloth.
3. Check for damage, such as:
nA door that is not lined up correctly,
nDamage around the door, or
nDents on the interior or exterior of the microwave oven.
If there is any damage, do not operate the microwave
oven until a designated service technician has checked
itandmade any needed repairs.
NOTE: To avoid damage to the microwave oven, do not remove
microwave inlet cover. See the “Parts and Features” section.
Location Requirements
IMPORTANT: The control side of the microwave oven is the
heavy side. Handle the microwave oven gently. The weight of the
microwave oven is over 35 lbs (15.9 kg).
nPlace the microwave oven on a cart, counter, table, or shelf
that is strong enough to hold the microwave oven and the
food and utensils you place inside it.
nThe microwave oven should be at a temperature above
50°F (10°C) for proper operation.
NOTE: Some models can be built into a wall or cabinet by using
one of the trim kits listed in the “Assistance or Service” section.
nInstall the microwave at a height of minimum 36" (91.4 cm)
from oor.
nDo not block the exhaust vents or air intake openings. Allow
a few inches of space at the back and side of the microwave
oven where the exhaust vents are located. Blocking the
exhaust vents could cause damage to the microwave oven
as well as poor cooking results.
nMake sure the microwave oven legs are in place to ensure
proper airow. If vents are blocked, a sensitive thermal
device may automatically turn the microwave oven off. The
microwave oven should work properly once it has cooled.
Electrical Requirements
Observe all governing codes and ordinances.
Required:
nA 120 V, 60 Hz AC only, 15 A or 20 A electrical supply with a
fuse or circuit breaker.
Recommended:
nA time-delay fuse or time-delay circuit breaker
nA separate circuit serving only this microwave oven
WARNING
Excessive Weight Hazard
Use two or more people to move and install
microwave oven.
Failure to do so can result in back or other injury.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
GROUNDING INSTRUCTIONS
SAVETHESE INSTRUCTIONS
■ For all cord connected appliances:
The microwave oven must be grounded. In the event of
an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric
current. The microwave oven is equipped with a cord
having a grounding wire with a grounding plug. The plug
must be plugged into an outlet that is properly installed
and grounded.
WARNING: Improper use of the grounding plug can
result in a risk of electric shock. Consult a qualified
electrician or serviceman if the grounding instructions are
not completely understood, or if doubt exists as to whether
the microwave oven is properly grounded.
Do not use an extension cord. If the power supply cord is
too short, have a qualified electrician or serviceman install
an outlet near the microwave oven. A short power supply
cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.

7
PARTS AND FEATURES
This manual may cover several different models. The model you
have purchased may have some or all of the features shown
here. The appearance of your particular model may differ slightly
from the illustrations in this manual.
*NOTE: To avoid damage to the microwave oven,do not remove
microwave inlet cover. See the “Parts and Features” section.
Turntable
The turntable can rotate in either direction to help cook food
more evenly. For best cooking results, do not operate the
microwave oven without having the turntable in place. See the
“Assistance or Service” section to reorder any of the parts.
To Install:
1. Place the support on the microwave oven cavity bottom.
2. Place the turntable on the support.
Fit the raised, curved wedges in the center of the turntable
bottom between the three spokes of the hub. The rollers on
the support should t inside the turntable bottom ridge.
Grill Element
The microwave oven uses a cal rod thermal element for grilling.
The microwave oven cavity and door will become hot. The use of
oven mitts is recommended.
Convection Element and Fan
The microwave oven’s convection system is composed of
a convection element which heats in conjunction with the
convection fan for true convection cooking. The convection
system is embedded in the wall of the microwave oven cavity,
behind the screen. See the “Parts and Features” section. The
microwave oven cavity and door will become hot. The use of
oven mitts is recommended.
Accessory Congurations
A. Door lock system
B. Window
C. Cooking guide label
D. Convection element and fan
E. Microwave oven light
F. Display
G. Control panel
H. Door open push button
I. Microwave inlet cover*
J. Removable turntable support
K. Glass turntable
L. Model and serial number plate
Parts and Features
Not Shown: Grill element (on
cavity ceiling)
A
B
C
D
A. Turntable
B. Hub
C. Support
D. Shaft
DA EC FB
IKL HJ
G
Grilling Airfrying
Baking Roasting
Grill and Convection Accessories
A. Turntable
B. Baking Tray
C. Air Fryer (without ipping out the legs)
and put on the top of baking tray

8
MICROWAVE OVEN CONTROL
Display
When power is rst supplied to the microwave oven, “12Hr” will
appear in the display. User can press Timer/Clock button or
+/- button to toggle between 12Hr or 24Hr within 10 seconds.
Press Start button to conrm. If the “12:00” appears in the
display at any other time, a power failure has occurred. Reset
the clock if needed. See the “Clock” section.
Standby mode
When no functions are being used, the microwave oven will
switch to Standby mode.
Start
The Start button begins any function. If non-sensor cooking
isinterrupted by opening the door, pressing Start button will
resume the cycle.
NOTE: To avoid unintentional operation of the microwave oven,
a cooking function cannot be started if the microwave oven door
has been closed for about 1 minute. The word “door” willappear
in the display until the door is opened and closed.
Quick start/Add 30 seconds
In standby mode, pressing Start automatically starts the
microwave oven at 100% power for 30 seconds and adds
30 seconds of cook time, with each additional touch of the
control. Time may be added to any manual cooking cycle in
30 second increments, at the moment power level, by pressing
Start button during cooking.
Cancel
The Cancel button clears any incorrect command and Cancels
any program during cooking. Press the Cancel button to Cancel
the cycle. It will not erase the time of day.
The microwave oven will also turn off when the door is opened.
Close the door and press Start to resume the cycle. The Cancel
button is also used to lock and unlock the control panel. See the
“Control Lock” section.
To use Non - Sensor Menu
(Popcorn, Potato)
1. Place food on the turntable and close the door.
2. Touch desired menu control. The rst programmed amount
will appear in the display. Touch control keypad repeatedly or
touch number keypads to change quantity.
3. Touch Start. When the cycle ends, “End” will appear in the
display and the end-of-cycle tone will sound.
4. Touch Cancel or open the door to clear the display.

9
Clock
To Set:
The microwave oven must be in standby.
1. Press Timer/Clock button for 3 seconds to enter clock
setting. It will also appear every time the product is plugged
into the power source, or power is back after a power fail.
2. Press +/- button to set the hour.
3. Press Start button to conrm.
4. Press +/- button to set the minute.
5. Press Start button to conrm the setting.
Tones ON/OFF
This function allows the user to activate/deactivate all the
sounds played by the appliances, includes button press,
warnings, alarm, even end audio feedback.
Press Steam Clean button and hold for 5 seconds to put into
mute, hold the button again for 5 seconds to turn on the sound.
“This function can operate at any time” in Tones on/off function.
To use Sensor Menu
(Reheat, Cook Menu)
1. Place food on the turn table and close the door.
2. Touch the desired menu control.
3. Touch Start, the running segment animation will appear
in the display. The microwave oven will start and sensor
cooking will begin.
The running segment will remain in the display until the
sensor has determined the remaining cook time.
4. When the cycle end, “End” will appear in the display and the
end-of-cycle tones will sound.
5. Touch Cancel or open the door to clear the display.
(NOTE: Sauce,Soup and Beverage in Reheat Menu, Potato in
Cook Menu without using Sensor cooking).
Timer
To Set:
1. Press Timer/Clock button
2. Press +/- button to enter desired time.
3. Press Start button. When the set time ends, the
end-of-timer
4. When the Timer countdown is achieve in the display, tone
will sound. Press Cancel to Cancel the timer.
NOTE: The Timer does not start or stop the microwave oven.
The function can be set only in Standby mode.
Cooking End
When the cooking is nished, the display will show the text
“End”. A reminder acoustic beep will signal.
NOTE: If the cooking time is more than 2 minutes, after cooking
end, the cooling fan and Forced Convection fan are ON for
3 minutes, cavity lamp is OFF, which is helping to cool down the
component to have better quality.
Control Lock
The Control Lock disables the control panel keypads to avoid
unintended use of the microwave oven.
To Lock/Unlock Control: The microwave oven must be OFF.
Touch and hold Cancel button for about 3 seconds, until the
tone sounds and the LOCK icon appears in the display. Repeat
to unlock and clear the display.
If any cook function control is touched while the Control Lock is
active, a tone will sound.

10
Keypad Feature Instructions
Timer
(Clock Hold
3 Seconds)
Hold to Set the Clock To set the clock, follow the instructions below:
1. Press Timer for 3 seconds to enter clock setting.
2. Press the +/- button to set the hour, press Start button to conrm.
3. Press the +/- button to set the minute.
4. Press Start button.
NOTE: The microwave oven must be in standby. It will also appear
every time the product is plugged into the power source, or power is
back after a power fail.
NOTE: When plug in, the screen shows“12Hr” (“12” ashing), use
+/- to change 12 or 24 hour format, press Start to conrm; then the
screen shows “12:00”.
Timer
(Clock Hold
3 Seconds)
Set Kitchen Timer The kitchen timer functions like a stop watch. To set the kitchen
timer, following the instructions below:
1. Press Timer button.
2. Press +/- button to enter desired time.
3. Press Start button.
NOTE: While the Timer countdown is active in the display, touch
Cancel to Cancel the Timer. The timer does not start or stop the
microwave oven.
Start
Add 30 seconds
Add 30 Seconds The button Start can be used in two ways:
1. To start the microwave by cooking for 30 seconds with full power
in standby mode.
2. To increase a cooking time using increments of 30 seconds. Each
press adds 30 seconds.
Start
Add 30 seconds
Start Function Press the Start button to start any cooking function. If cooking is
interrupted by opening the door, touch the Start button after the door
is closed again to resume the cycle.
Cancel Microwave Oven Cancel The Cancel button stops any microwave oven function except for the
clock and control lock.
The microwave oven will also turn off when the door is opened. When
the door is opened, the element(s) will turn off, but the microwave
oven light will remain on. Close the door and touch the Start button
to resume the preset cycle.
Control Lock
(Cancel Hold 3 Sec)
Activate Control Lock Activate Control Lock to avoid an unintended start.
To activate, press and hold the Cancel button for 3 seconds until the
CONTROL LOCKED icon appears on the display. Repeat to unlock
control.
1 min-6 min Quick Start Default power is full in this function (P100).
Press 1 min, 2 min.. or 6 min to start with the time mentioned on the
button.
Cook Time Set Manual Cooking Press “Cook Time” button to set manual cooking time. The default
power level is 100%. Press +/- button/1 min-6 min to set the cooking
time, follow the instruction below:
1. Press “Cook Time” button, “0:15” will show on the display.
2. Press +/- button/1 min-6 min to adjust the cooking time.
3. Press Start button to start.
NOTE: Press the “Power” button to increase /decrease power levels
in cyclic way P10 P20 P30………..P100.
Keypad Instructions
