Kitsound SWING User manual

kitsound.co.uk
JB. 3471 / Made in China. © KitSound™ 2014. Christchurch, Dorset. BH23 4FL
USER MANUAL
SWING
ALARM CLOCK
FM RADIO

We are craftspeople. We are musicians. We are KitSound™
And we all commit ourselves to achieving one shared goal: Bringing
people closer to their music. By truly understanding music we stay true
to its craft. Pure, rich, incredible sound. We’ll settle for nothing less.

At KS we believe your music deserves to be showcased on great
quality products that don’t cost the earth. We might not all share
the same taste in music (the ferocious disputes on music forums
prove that), but whether it’s Irish folk, death metal or any number
of obscure genres which seem to be multiplying by the minute, the
artists responsible for connecting with you through their craft have
bared their souls to do so. And we think that’s worth celebrating.

6 7
Please read this manual carefully before use.
Box contents
• KS Swing alarm clock FM radio
• Mains adaptor
• User manual
Functions
On the front:
1. Power
2. Speaker
3. Screen
On the top:
4. Set
5. Previous
6. Scan
7. Next
8. Mode
9. Volume–
10. Snooze
11. Alarm
12. Volume+
On the rear:
13. FM aerial
14. Aux input
15. DC input
16. Battery cover
10 1211 15 161413
567
5
1
2
4
9
8
3

8 9
Instructions for use
Getting started
Mains power
1. Plug the power adaptor into a convenient mains wall outlet and switch it on
2. The screen (3) will turn on
3. The Swing is now in ‘STANDBY’ mode
4. Press the Power button (1) to turn the Swing on
5. Press the Power button (1) again to put the Swing in standby mode
6. Disconnect from the mains to eliminate standby
Battery power:
1. Remove the battery cover (16) and insert 4 x AA batteries observing the correct polarity
2. Replace the battery cover (16)
3. The screen (3) will turn on
4. The Swing is now in ‘STANDBY’ mode
5. Press the Power button (1) to turn the Swing on
6. Press the Power button (1) again to put the Swing in standby mode
7. Remove the batteries to eliminate standby
Note: Please use only standard non rechargeable batteries. Rechargeable batteries may not provide
enough power for the Swing to operate correctly.
Time/Date
To set the time
• Press and hold the Set button (4)
• Press Previous (5) or Next (7) to change the year followed by Set (4) to confirm
• Press Previous (5) or Next (7) to change the month followed by Set (4) to confirm
• Press Previous (5) or Next (7) to change the day followed by Set (4) to confirm
• Press Previous (5) or Next (7) to change between 12/24 hour clock mode followed
by Set (4) to confirm
• Press Previous (5) or Next (7) to change the hours followed by Set (4) to confirm
• Press Previous (5) or Next (7) to change the minutes followed by Set (4) to confirm
• The time is now set

10 11
Temperature
You can change the temperature reading between Celsius and Fahrenheit. To do this, press the Next
button (7) whilst in standby mode.
FM Radio
Whilst in standby mode, press the Power button (1) to turn the Swing on. Please ensure the aerial is
fully extended and adjusted to the best position.
To tune into a station, you can
1. Press Scan (6) to automatically scan to the next channel
2. Press and hold Scan (6) to automatically scan to the previous channel
3. Press or press and hold Previous (5) or Next (7) to manually scan
To change the volume
1. Press the Volume– button (9) to decrease the volume
2. Press the Volume+ button (12) to increase the volume
Alarm
To set the alarm
• Press and hold the Alarm button (11)
• Press Previous (5) or Next (7) to change the hours followed by Alarm (11) to confirm
• Press Previous (5) or Next (7) to change the minutes followed by Alarm (11) to confirm
• Press Previous (5) or Next (7) to change between FM or buzzer followed by Alarm (11) to confirm
• Press Previous (5) or Next (7) to change the alarm volume followed by Alarm (11) to confirm
• The alarm is now set and active
Note: If using FM as an alarm, it will use the last station listened to for the alarm.
• To enable/disable the alarm, simply press (not hold) the Alarm button (11) when in standby mode.
The alarm icon will turn on/off respectively
• When the alarm is sounding, press either the Snooze button (10) to enter snooze mode or press the
Alarm button (11) to stop the alarm
[continued...]

12 13
Aux audio input
Using the Aux audio input
With the Swing in FM mode, press the Mode button (8) to enable aux mode. Connect one end of an aux
cable (not supplied) into the aux port (14) on the Swing and insert the other end into the headphone
socket on your device. Sound will now be heard through the Swing. Whilst in aux mode, you can:
1. Press the Volume– (9) or Volume+ button (12) to decrease or increase the volume
2. Use sleep mode (same setup as in FM mode)
Note: Volume is controlled on both your device and the Swing. Track control functions can only be done
on the device.
PLEASE NOTE:
Your device will have an internal amplifier and if it is playing digital files like MP3s it will also have an
integrated DAC (Digital Audio Converter). If you turn up the volume to 100%, your device will be sending
distorted signals to the Swing. To avoid this and to get the best sound quality from the speaker, we
recommend that you do not run your device any higher than 95% volume.
To set presets
1. Tune into a station you wish to store as a preset
2. Press and hold the Set button (4) and a number between 01 – 20 will flash on the screen
3. Press Previous (5) or Next (7) to change the preset number followed by Set (4) to confirm
To recall presets
1. Press (don’t hold) the Set button (4)
2. Press Previous (5) or Next (7) to change the preset number and the Swing will automatically
tune into the stored channel
To enable sleep mode
1. Press and hold the Alarm button (11)
2. Press Previous (5) or Next (7) to change the sleep timer followed by pressing Alarm (11) to confirm
3. The sleep icon will flash and a timer will countdown on the screen until the Swing enters
standby mode
[...continued] FM Radio

14
Specifications
Troubleshooting
We hope you’ve now got all the information you need to get started, but if you’re having problems
with anything, please feel free to contact us at: [e-mail]
We apologise for any inconvenience caused by minor inconsistencies in these instructions, which may occur as a result of
product improvement and development.
Care for your Swing
Please DON’T
• Get the Swing wet
• Drop the Swing as this will invalidate your warranty
• Open up the Swing as there are no user serviceable parts inside
• Expose the Swing to extreme temperatures or rapid changes of hot to cold or vice versa
Please DO
• Clean the Swing with a soft dry cloth and no detergents
Power supply DC 6 V
AC 100 – 240 V adaptor
Battery 4 x 1.5 V AA
Output RMS 2 W
Frequency response 100 Hz – 20 kHz
FM frequency range 87.5 – 108 mHz
Aux-in 3.5 mm
Weight 630 g
