Klein 5000 V2 Series User manual

SERIES 5000 V2 SONAR
SYSTEM
Operations and Maintenance Manual
P/N 11214512, Rev. 04
11 Klein Drive
Salem, NH 03079-1249
U.S.A.
Tel: [phone]
Fax: [phone]
www.KleinMarineSystems.com

ii
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
This document contains proprietary information, and such information may not be
disclosed to others for any purpose or used for any manufacturing purpose without
expressed written permission from Klein Marine Systems, Inc. (KMS). The
information provided is for informational purposes only and is subject to change
without notice. KMS assumes no responsibility or liability for any errors,
inaccuracies or omissions that may be present in this document.
The SonarPro software program may be used or copied only in accordance with
the terms of the Software License Agreement.
©Copyright 2008–2019 by Klein Marine Systems, Inc. All rights reserved.
SonarPro®is a registered trademark of Klein Marine Systems, Inc.
K-Wing®and K-Wing II®are a registered trademarks of Klein Marine Systems,
Inc.
Intel®and Pentium®are registered trademarks of Intel Corporation.
Windows®and Wordpad®are registered trademarks of Microsoft Corporation.
Kevlar®is a registered trademark of the DuPont Company.

iii
WARNING
Klein Marine Systems, Inc. recommends all troubleshooting be
done by a trained technician. Some circuits in the Sonar
Transceiver and Processing Unit have voltages as high as 240 volts,
and some circuits in the sonar towfish have 1500 volts. You should
familiarize yourself with the location of these voltages before you
attempt any troubleshooting. Failure to observe these warnings
could result in injuries to personnel.
CAUTION
Serious damage to the sonar electronics may occur if the sonar
towfish is operated out of the water for periods longer than 15
minutes. Let the sonar cool 15 minutes or longer between
operations. Protect the sonar towfish from direct exposure to the
sun prior to and during operation in high temperature climates.
CAUTION
The depth rating on the transducers for the Series 5000 V2 Sonar
System is 500 meters (1640 feet). Operations at depths greater than
500 meters may damage the transducers. For a Series 5000 V2
Sonar System with bathymetry option, the depth rating is
200 meters (656 feet). Operations at depths greater than 200 meters
may damage the transducers.
STANDARDS
SAFETY: EN 60950
EMC: EN 60945

iv
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
Table of Contents
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
List of Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Sonar System Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
What Is Covered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Conditions Of Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Changes, Errors And Omissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Software License Agreement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
What’s in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
Note, Warning, Caution, and Shock Hazard Notices . . . . . . . . . . . . . xvii
Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii
CHAPTER 1: Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1 Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2.1 Towfish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2.2 TPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2.3 SonarPro Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
CHAPTER 2: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1 Sonar System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Topside System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.1 System Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.2 TPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.3 SonarPro Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.3 Towfish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.3.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.3.2 Transducers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.3.3 Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.3.4 Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.3.5 A/D Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

v
2.3.6 Multiplexer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3.7 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3.8 Heading Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3.9 Pitch and Roll Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3.10 Pressure Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.4 Tow Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.4.1 Lightweight Coaxial Deck Cable . . . . . . . . . . . . . . . . . . . . . . 2-5
2.4.2 Armored Coaxial Tow Cable (0.40) . . . . . . . . . . . . . . . . . . . . 2-5
2.4.3 Armored Coaxial Tow Cable (0.68) . . . . . . . . . . . . . . . . . . . . 2-5
2.5 Towfish Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.6 Tow Cable Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
CHAPTER 3: Preparation for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1 Unpacking and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 Locating the Topside System Components . . . . . . . . . . . . . . . . 3-1
3.3 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.3.1 Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.3.2 TPU and SonarPro Workstation Circuit Breakers . . . . . . . . . 3-2
3.4 Towfish Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.4.1 Connecting the Tow Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.4.2 Connecting the Tow Cable with the Optional K-Wing
Depressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3.4.3 Disconnecting the Tow Cable from the Towfish . . . . . . . . . . 3-5
3.5 Topside System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
3.5.1 TPU Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
3.5.2 SonarPro Workstation Connections . . . . . . . . . . . . . . . . . . . . 3-8
3.6 Connecting the Topside System Components . . . . . . . . . . . . . 3-10
3.7 Topside System Controls and Indicators . . . . . . . . . . . . . . . . . 3-11
3.7.1 TPU Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . 3-11
3.7.2 SonarPro Workstation Controls and Indicators . . . . . . . . . . 3-13
3.8 System Activation and Test . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.8.1 Activating and Testing the System on Deck . . . . . . . . . . . . 3-15
3.8.2 Activating and Testing the System at Sea . . . . . . . . . . . . . . 3-16

vi
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
CHAPTER 4: Maintenance and Troubleshooting . . . . . . . . . . . . . . 4-1
4.1 General Maintenance Recommendations . . . . . . . . . . . . . . . . . . 4-1
4.2 Maintenance Checklists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.1 Daily Maintenance Checklist . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.2 Weekly Maintenance Checklist . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.3 Long Term Maintenance Checklist . . . . . . . . . . . . . . . . . . . . 4-2
4.3 Replacing the Fixed Tail Cone Assembly . . . . . . . . . . . . . . . . . 4-3
4.4 Removing the Fixed Tail Cone Assembly . . . . . . . . . . . . . . . . . 4-6
4.5 Removing the Towfish Electronics . . . . . . . . . . . . . . . . . . . . . . 4-7
4.6 Installing the Towfish Electronics . . . . . . . . . . . . . . . . . . . . . . . 4-8
4.7 Testing the Towfish Electronics . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4.7.1 Checking the Multiplexer Board . . . . . . . . . . . . . . . . . . . . . 4-10
4.7.2 Checking the Transmitter Board . . . . . . . . . . . . . . . . . . . . . 4-10
4.7.3 Checking the Receiver Boards . . . . . . . . . . . . . . . . . . . . . . . 4-10
4.7.4 Checking the Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
4.7.5 Calibrating the Optional Temperature Probe . . . . . . . . . . . . 4-12
4.7.6 Calibrating the Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
CHAPTER 5: Technical Description . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.1 Towfish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.1.1 Sonar Electronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.1.2 Transducer Arrays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
5.2 TPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
APPENDIX A: Sample Towing Characteristics . . . . . . . . . . . . . . . . A-1
APPENDIX B: Notes on Handling Tow Cables . . . . . . . . . . . . . . . . . B-1
B.1 Unreeling Tow Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.2 Uncoiling Tow Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
B.3 Cable Kinking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
B.3.1 Cause of Cable Kinking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
B.3.2 Effect of Cable Kinking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.3.3 Result of Cable Kinking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

vii
APPENDIX C: Configuring and Updating the TPU . . . . . . . . . . . . . C-1
C.1 Starting Linux TPU Updater . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
C.2 Querying or Changing the TPU IP Address . . . . . . . . . . . . . . . . C-2
C.3 Editing the TPU Startup File . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
C.4 Updating the TPU Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
APPENDIX D: Different Tow Cable Lengths and the Startup.ini
File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
D.1 Measuring Cable Insertion Loss . . . . . . . . . . . . . . . . . . . . . . . D-2
D.2 Spare Tow Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-3
APPENDIX E: Drawings and Parts Lists . . . . . . . . . . . . . . . . . . . . . E-1

viii
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
List of Figures
Figure 1-1: Series 5000 Towfish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Figure 1-2: Series 5000 V2 Sonar System Topside System Main Components . . . . . . . . 1-4
Figure 3-1: TPU Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Figure 3-2: SonarPro Workstation Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Figure 3-3: TPU Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Figure 3-4: SonarPro Workstation Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Figure 4-1: Towfish Tail with Rear Center Pin in Place . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Figure 4-2: Tail Cone being Aligned and Attached to Towfish . . . . . . . . . . . . . . . . . . . . 4-4
Figure 4-3: Tail Cone Being Tightened with Hex Key . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Figure 4-4: Crossbar Used to Secure Tail Cone Parts . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Figure 4-5: Tail Cone Being Tightened With Screwdriver and Key . . . . . . . . . . . . . . . . 4-5
Figure 4-6: Tail Fins being Inserted into Tail Cone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Figure 4-7: Tail Fins being Secured to Tail Cone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Figure 4-8: Push/Pull Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Figure 4-9: Jacking Screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Figure 4-10: Electronics Housing End Cap Bulkhead Connectors . . . . . . . . . . . . . . . . . . 4-8
Figure 4-11: Altimeter Cable Identified with Colored Shrink Tubing . . . . . . . . . . . . . . . . 4-8
Figure 4-12: Towfish Electronics Ready for Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Figure 4-13: Multiplexer Board Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Figure 4-14: Sample Transmit Waveform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Figure 4-15: The Sensor Interface Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
Figure 5-1: Towfish Block Diagram—12 Sidescan Channels and 3 Bathymetery
Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Figure 5-2: The Series 5000 V2 Sonar System TPU Electronics Chassis . . . . . . . . . . . . 5-3
Figure 5-3: The Series 5000 V2 Sonar System TPU Electronics Block Diagram . . . . . . 5-6
Figure 5-4: The Series 5000 V2 Sonar System TPU Electronics Chassis . . . . . . . . . . . . 5-7
Figure A-1: Cable Length vs. Towfish Depth Graph 1 . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

ix
Figure A-2: Cable Length vs. Towfish Depth Graph 2 . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
Figure A-3: Cable Length vs. Towfish Depth Graph 3 . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
Figure A-4: Cable Length vs. Towfish Depth Graph 4 . . . . . . . . . . . . . . . . . . . . . . . . . . A-6
Figure A-5: Cable Length vs. Towfish Depth Graph 5 . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
Figure B-1: Correct Methods to Unreel Tow Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Figure B-2: Spooling Real to Drum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
Figure B-3: Cable Loop and Kink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
Figure B-4: Damaged Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
Figure C-1: The Klein Linux TPU Updater Dialog Box . . . . . . . . . . . . . . . . . . . . . . . . . C-1
Figure C-2: The Select RS-232 Port Dialog Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
Figure C-3: The Klein Linux TPU Updater Dialog Box with Current TPU IP
Address Displayed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
Figure D-1: Sample Plot of Tow Cable Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . D-2
Figure D-2: Setup for Measuring Tow Cable Characteristics using a Function
Generator, Terminator and Oscilloscope . . . . . . . . . . . . . . . . . . . . . . . . . . . D-3

x
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
List of Tables
Table 3-1: TPU Power Cable Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Table E-1: List of Drawings and Parts Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

xi
Sonar System Warranty
What Is Covered
LIMITED WARRANTY Subject to the conditions set forth below, equipment
sold by Seller is warranted against defects in materials and workmanship, and
Seller will repair or exchange any parts proven to be malfunctioning under normal
use for one year (12 months) from the date of Delivery as follows:
a) SONAR and other associated manufactured products, with the following
exceptions:
b) All third party accessories, winches, magnetometers, Sonar Laptops or PCs, and
peripherals/accessories and third party software packages related to the Sonar
Product Line are limited to the warranty provided by original manufacturer.
c) This warranty does not apply to tow cables. If applicable, the manufacturer’s
warranty will be forwarded with the equipment.
EQUIPMENT NOT MANUFACTURED BY SELLER Carries only its
vendor’s warranty, which is hereby incorporated by reference.
SERVICE WORK BY SELLER Warrants that ALL service work performed by
Seller’s technical and engineering employees will be performed in a good and
workmanlike manner, but its liability under this warranty is limited to the
obligation to remedy at Seller’s expense any such service work not performed
satisfactorily, upon receipt of written notice within ninety (90) days of the date of
performance of the work.
For authorized onsite service (excluding Side Scan Sonar category referenced as a.
SONAR) in which Seller has to travel to the installed equipment, travel costs (auto
mileage and tolls) up to 100 round trip highway miles and travel time of 2 hours,
will be allowed by Seller. The Overtime premium labor portion of service of
normal working hours is not covered by this Warranty. On-site warranty service is
capped at (4) hours per failure. Travel costs other than auto mileage, tolls and two
(2) hours travel time are specifically excluded on all products and services.
Travel costs which are excluded from coverage of this warranty include, but are
not limited to: taxi, launch fees, aircraft rental, airfare, subsistence, customs,
shipping, communication charges, etc.
During the warranty period, Seller will repair or, at its option, replace any
equipment that proves to be defective. Such repair or replacement is Buyer’s
exclusive right and remedy, and our only obligation, with respect to any defective
equipment.

xii
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
Conditions Of Warranty
a) Seller’s warranty policy does not apply to equipment which has been subjected to
accident, abuse, or misuse, shipping damage, alterations, incorrect and/or non-
authorized service or equipment on which the serial number plate has been
altered, mutilated or removed.
b) A suitable proof of purchase, such as, a paid commercial invoice, an installation
certificate signed by Seller or an authorized agent must be made available to
Seller or Seller’s authorized servicing agent at the time of the Warranty Service.
c) The warranties stated herein are in lieu of all other warranties, expressed or
implied, and of all other obligations or liabilities on the part of Seller. Seller
neither assumes nor authorizes any other person to assume for it any other
liability. The Buyer expressly waives any right, claim or cause of action that
might otherwise arise out of the purchase and use of Seller’s products or service.
d) Warranty is not transferable and only applies to the original Buyer.
e) Warranty does not cover equipment that has been repaired or modified other than
by Seller, or equipment that has been subjected to misuse or to negligent or
accidental mishandling.
f) Except where Seller has performed the installation of specific equipment, Seller
assumes no responsibility for damage incurred during installation of equipment or
by damage caused by no fault of the Seller.
g) This warranty does not cover routine system checkouts or alignment/calibration,
unless required by replacement of part(s) in the area being aligned.
h) Consumable items are specifically excluded from this Warranty.
i) Buyer is responsible for the prepayment of all freight charges, insurance,
customs, imposts, duties, etc., to return defective equipment to Seller and for
Seller to return the repaired or replaced equipment to buyer.
j) Equipment returned for warranty service must be packed to best commercial
standards to prevent shipping damage.
k) Warranty shall be void and Seller shall be released from all obligations under this
warranty if the equipment is operated with components other than those sold or
authorized by Seller.
l) This warranty is strictly limited to the terms and indicated herein, and no other
warranties or remedies shall be binding on Seller including, without limitation,
any warranties of merchantability or fitness for a particular purpose.
m) Repairs and replacements under warranty have the same warranty as the original
product for the remaining balance of the warranty period for the original product
existing prior to notice of the warranty claim.

xiii
Any failure to meet the foregoing conditions of warranty will automatically void
this limited warranty. This warranty gives Buyer specific legal rights, and Buyer
may also have other rights, which vary from State to State, Province to Province or
Country to Country.
DISPUTES Seller and Buyer agree that all disputes in any way relating to, arising
under, connected with, or incident to this agreement, and over which the federal
courts have subject matter jurisdiction, shall be litigated, if at all, exclusively in the
United States District Court for the State of Delaware, and if necessary, the
corresponding appellate courts. Seller and Buyer further agree that all disputes in
any way relating to, arising under, connected with or incident to this contract, and
over which the federal courts do not have subject matter jurisdiction, shall be
litigated, if at all, exclusively in the Courts of the State of Delaware, and if
necessary, the corresponding appellate courts. Seller and Buyers expressly submit
themselves to the personal jurisdiction of the State of Delaware. Before resorting
to litigation, Seller and Buyer agree to enter into negotiations to resolve the
dispute. If Seller and Buyer are unable to resolve the dispute by good faith
negotiation, either Seller or Buyer may refer the matter to litigation.
LIMITATION OF LIABILITY TO THE MAXIMUM EXTENT PERMITTED
BYAPPLICABLE LAW, SELLER SHALL NOT BE LIABLE UNDERANY
THEORYAT LAW, IN EQUITY OR OTHERWISE FOR ANY SPECIAL,
EXEMPLARY, PUNITIVE, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES (EVEN IF SELLER HAS BEEN ADVISED OF SAME)
INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR REVENUES,
THE ENTIRE LIABILITY OF SELLER FOR ANY CLAIM, LOSS, OR
DAMAGES UNDER ANY THEORYAT LAW, IN EQUITY, OR OTHERWISE,
INCLUDING, BUT NOT LIMITED TO CONTRACT, TORT, (INCLUDING
INTELLECTUAL PROPERTY INFRINGEMENT, AND NEGLIGENCE), AND
STRICT LIABILITY, ARISING OUT OF THIS AGREEMENT OR ANY
INDEMNIFICATION OBLIGATION THEREOF, THE PERFORMANCE OR
BREACH THEREOF, OR THE SUBJECT MATTER SHALL NOT IN ANY
EVENT EXCEED THE SUM OF PAYMENTS ACTUALLY MADE BY BUYER
TO SELLER PURSUANT TO THIS AGREEMENT, ANYACTION AGAINST
SELLER MUST BE BROUGHT WITHIN ONE (1) YEARAFTER THE CLAIM
AROSE.
Changes, Errors And Omissions
Klein Marine Systems, Inc. reserves the right to make changes to the design or
specifications at any time without incurring any obligation to modify previously
delivered sonar systems. In addition, while considerable effort has been made to
ensure that the information in this manual is accurate and complete, Klein Marine
Systems, Inc. assumes no liability for any errors or omissions.

xiv
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
Software License Agreement
This Software License Agreement is provided by Klein Marine Systems, Inc.
(KMS) for end users of SonarPro©software for the KMS Series 3000, UUV-3500,
3900, 4900, 5000, 5000 V2, 5900, HydroChart 3500, HydroChart 5000, and
D3500TF Sonar Systems.
YOU SHOULD CAREFULLY READ THE FOLLOWING TERMS AND
CONDITIONS BEFORE USING THIS PRODUCT. IT CONTAINS
SOFTWARE, THE USE OF WHICH IS LICENSED BY KMS, TO ITS
CUSTOMERS FOR THEIR USE ONLY, AS SET FORTH BELOW. IF YOU DO
NOTAGREE TO THE TERMS AND CONDITIONS OF THIS AGREEMENT,
DO NOT USE THE SOFTWARE. USING ANY PART OF THE SOFTWARE
INDICATES THAT YOU ACCEPT THESE TERMS.
LICENSE: KMS grants you a nonexclusive license to use the accompanying
software programs(s) (the "Software") subject to the terms and restrictions set
forth in this License Agreement. You are not permitted to lease, rent, distribute or
sublicense the Software or to use the Software in a time-sharing arrangement or in
any other unauthorized manner. Further, no license is granted to you in the human
readable code of the Software (source code). Except as provided below, this
License Agreement does not grant you any rights to patents, copyrights, trade
secrets, trademarks, or any other rights in respect to the Software.
The Software is licensed to be used on any workstation or any network server
owned by or leased to you, provided that the Software is used only in connection
with one KMS Series 3000, UUV-3500, 3900, 4900, 5000, 5000 V2, 5900,
HydroChart 3500, HydroChart 5000, or D3500TF Sonar System. You may
reproduce and provide authorized copies only of the Software and supporting
documentation for each such workstation or network server for this equipment on
which the Software is used as permitted hereunder. Otherwise, the Software and
supporting documentation may be copied only as essential for backup or archive
purposes in support of your use of the Software as permitted hereunder. You must
reproduce and include all copyright notices and any other proprietary rights
notices appearing on the Software and the supporting documentation on any copies
that you make.
NO ASSIGNMENT; NO REVERSE ENGINEERING: You may not transfer
or assign the Software and/or this License Agreement to another party without the
prior written consent of KMS. If such consent is given and you transfer or assign
the Software and/or this LicenseAgreement, then you must at the same time either
transfer all copies of the Software as well as the supporting documentation to the
same party or destroy any such materials not transferred. Except as set forth above,
you may not transfer or assign the Software or your rights under this License
Agreement.
Modification, reverse engineering, reverse compiling, or disassembly of the
Software is expressly prohibited. You may not translate or create derivative works
of the software or the supporting documentation.

xv
BATHYMETRIC PROCESSING ATTRIBUTION: Bathymetric processing
derived from DGA/GESMA publication in IEEE OCEAN'S 05 Europe
Conference Proceedings: "Bathymetric Sidescan Sonar: a System Dedicated to
Rapid Environment assessment, ref: 10.1109/OCEANSE.2005.1511695.
EXPORT RESTRICTIONS: You agree that you will not export or re-export the
Software or accompanying documentation (or any copies thereof) or any products
utilizing the Software or such documentation in violation of any applicable laws or
regulations of the United States or the country in which you obtained them.
TRADE SECRETS; TITLE: You acknowledge and agree that the structure,
sequence and organization of the Software are the valuable trade secrets of KMS.
You agree to hold such trade secrets in confidence. You further acknowledge and
agree that ownership of, and title to, the Software and all subsequent copies thereof
regardless of the form or media are held by KMS.
UNITED STATES GOVERNMENT LEGEND: All technical data and
Software are commercial in nature and developed solely at private expense. The
Software is delivered as Commercial Computer Software as defined in DFARS
252.227-7014 (June 1995) or as a commercial item as defined in FAR 2.101(a) and
as such is provided with only such rights as are provided in this License
Agreement, which is KMS's standard commercial license for Software. Technical
data is provided with limited rights only, as provided in DFAR 252.227-7015
(Nov. 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree
not to remove or deface any portion of any legend provided on any licensed
program or documentation delivered to you under this License Agreement.
TERM AND TERMINATION: This license will terminate immediately if you
fail to comply with any term or condition of this License Agreement. Upon such
termination you agree to destroy the Software and documentation, together with all
copies and merged portions in any form. You may terminate it at any time by
destroying the Software and documentation together with all copies and merged
portions in any form.
GOVERNING LAW: This License Agreement shall be governed by the laws of
the State of New Hampshire, USA. You agree that the United Nations Convention
on Contracts for the International Sales of Goods (1980) is hereby excluded in its
entirety from application to this LicenseAgreement.
LIMITED WARRANTY; LIMITATION OF LIABILITY: All warranties and
limitations of liability applicable to the Software are as stated in the product
manual accompanying the Software. Such warranties and limitations of liability
are incorporated herein in their entirety by this reference.
SEVERABILITY: In the event any provision of this License Agreement is found
to be invalid, illegal or unenforceable, the validity, legality and enforceability of
any of the remaining provisions shall not in any way be affected or impaired and a
valid, legal and enforceable provision of similar intent and economic impact shall
be substituted therefore.

xvi
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
ENTIRE AGREEMENT: This LicenseAgreement sets forth the entire
understanding and agreement between you and KMS supersedes all prior
agreements, whether written or oral, with respect to the Software, and may be
amended only in a writing signed by both parties.
Preface
The Series 5000 V2 Sonar System is a towed multibeam sonar comprising a towed
underwater platform and a topside system.
What’s in This Manual
This operations and maintenance manual provides information pertaining to the
setup and deployment, operation, general maintenance, and troubleshooting of the
Series 5000 V2 Sonar System. The manual is divided into the following four main
chapters and four appendices:
Chapter 1: Overview. Presents an overview of the Series 5000 V2 Sonar
System components, including both functional and physical descriptions of the
system.
Chapter 2: Specifications. Provides detailed physical and performance
specifications for the main components of the system, including the acoustic
transducers, the environmental and navigation sensors, and the available tow
cables.
Chapter 3: Preparation for Use. Provides instructions for unpacking and
setting up the Series 5000 V2 Sonar System components. It also includes a
pre-survey checkout procedure.
Chapter 4: Maintenance and Troubleshooting. Provides instructions on
how to perform maintenance and troubleshooting of the Series 5000 V2 Sonar
System and how to replace the fixed tail cone assembly and remove, install and
test the towfish electronics.
Chapter 5: Technical Description. Provides an overall technical
description of the Series 5000 V2 Sonar System towfish and TPU electronics,
including block diagrams, printed circuit board descriptions and chassis photos
with call outs.
Appendix A: Sample Towing Characteristics. Provides towing
characteristics charts which are helpful when planning survey equipment
requirements.
Appendix B: Notes on Handling Tow Cables. Contains information on
tow cable handling.

xvii
Appendix C: Configuring and Updating the TPU. Provides instructions
on how to configure and update the Series 5000 V2 Sonar System TPU.
Appendix D: Different Tow Cable Lengths and the Startup.ini File.
Provides instructions on how to tune the Series 5000 V2 Sonar system for
optimum performance versus various cable lengths and how to measure cable
insertion loss.
Appendix E: Drawings and Parts Lists. Provides drawings and parts lists
for reference and troubleshooting purposes.
Note, Warning, Caution, and Shock Hazard Notices
Where applicable, note, warning, caution, and shock hazard notices are included
throughout this manual as follows:
NOTE Recommendations or general information that is particular to the
material being presented or a referral to another part of this manual or to
another manual.
WARNING Identifies a potential hazard that could cause personal injury
or death to yourself or to others.
CAUTION Identifies a potential hazard that could be damaging to
equipment or could result in the loss of data.
SHOCK HAZARD Identifies a potential electrical shock hazard that could
cause personal injury or death to yourself or to others.

xviii
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
Customer Service
KMS technical support can be contacted using any of the following means:
Mail
Klein Marine Systems, Inc.
11 Klein Drive
Salem, NH 03079
Email
T[email protected]
Telephone
[phone]
Facsimile
[phone]
For more information about KMS and our products, please go to our Web site at
www.KleinMarineSystems.com.

1-1
CHAPTER 1: OVERVIEW
The Series 5000 V2 Sonar System is a very high resolution, multibeam long range
sonar system that is ideally suited for surface mine counter measure applications
and hydrographic, geophysical, pipeline, and offshore surveys. The two primary
drawbacks of conventional side-looking sonars, along-track resolution and towing
speed limitation, have been addressed by simultaneously forming multiple
dynamically focused beams per side, per ping. This allows greater towing speeds
without the usual loss of bottom coverage while maintaining high resolution. The
system employs operator selectable chirp and continuous wave (CW) technologies
which, when coupled with KMS proprietary display algorithms, provides
extraordinary sea floor images. In addition, rugged construction, low weight and
simple setup enables operation from large or small vessels.
1.1 Main Features
The Series 5000 V2 Sonar System provides the following main features:
• High speed, high resolution, multibeam side scan sonar.
• 14-bit digital multiplexer for transmission of sonar and control
data over a single coaxial cable.
• PC based operation using SonarPro and the Windows operating
system.
• Operation at 455 kHz for ranges up to 150 meters.
• Flexible and expandable system configurations.
• Chirp and CW operating modes.
• 500-meter operating depth (200-meter with bathymetry option).
• Operation with up to 800 meters of coaxial 0.680-inch diameter
armored tow cable.
• Heading, pitch, roll and pressure sensors.
• Optional interfaces for a responder, acoustic positioning system
yaw rate sensor, and altimeter.
• Small, lightweight and simple to operate and maintain.

1-2 CHAPTER 1 Overview
Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
1.2 System Components
The main components of the Series 5000 V2 Sonar System are the towfish and the
topside system. The towfish is the underwater component and is towed with an
armored coaxial tow cable up to 800 meters in length. The topside system provides
the power source for the towfish and receives, stores and processes data acquired
by the towfish. The towfish connects to the topside system using an optionally
supplied winch with slip rings and an armored coaxial tow cable. A terminated,
light weight deck cable is optionally supplied for connecting to the winch or for
connecting directly to the towfish for testing. The topside system is composed of
two separate main components:
• Transceiver and Processing Unit (TPU)
• SonarPro Workstation
In addition, a K-Wing I or K-Wing II Depressor can be installed on the towfish
which enables a greater towing depth with less cable deployed.
1.2.1 Towfish
The towfish, which is shown in Figure 1-1, consists of a negatively buoyant
stainless steel towfish housing with attached port and starboard sonar transducer
arrays, an altimeter, a nose cone, and a tail cone with stabilizing fins. Inside the
towfish housing is a pressure housing containing the sonar electronics, a downlink
demultiplexer for control signals, an uplink multiplexer for sonar and sensor data,
a transmitter board for transmit pulses, receiver boards for receiving signals, and
the compass, pitch/roll and pressure sensors. The downlink control signals and the
uplink sonar and sensor data are multiplexed onto a single conductor coaxial tow
cable.An electro-mechanical termination is provided on the towfish end of the tow
cable, where a shackle provides a strong, reliable mechanical termination to the
towfish tow bracket, and an underwater connector connects to a jumper cable on
the towfish. Four carrying handles, two forward and two aft, are included for
lifting and transporting the towfish. The installed safety cable minimizes the
chances of losing the towfish should it collide with an obstruction.
1.2.2 TPU
The TPU is housed in a 19-inch rack mountable 2U chassis and connects to the
towfish directly using an optional coaxial tow cable, or to an optionally supplied
winch using an optionally supplied deck cable, where the winch connects to the
towfish using a tow cable. The deck cable can also be used to connect the TPU
directly to the towfish for testing. The TPU receives and demultiplexes the sonar
and sensor data from the towfish and transfers the data to the SonarPro
Workstation over an Ethernet connection. The TPU provides power and downlink
