Simrad SH80 - REV C User manual

Simrad SH80
High frequency fishery sonar
Operator manual
M A X I M I Z I N G Y O U R P E R F O R M A N C E A T S E A
www.simrad.com

850-164385 / Rev.C
SH80
High frequency fishery sonar
Operator manual
WARNING
The sonar must never be powered up when the ship is
in dry dock. The transducer will be damaged if it
transmits in open air. To prevent inadvertent use of the
sonar, pull out the mains plug on the Sonar Processor
Unit whenever the vessel is in dry dock.

About this document
Rev Date Written by Checked by Approved by
Rev.C 11.02.05 RBr SØJ OBG
Updated for software version 1.2.X
© 2005 Simrad AS
ISBN 82-8066-007-0
All rights reserved. No part of this work covered by the copyright hereon may be
reproduced or otherwise copied without prior permission from Simrad AS.
The information contained in this document is subject to change without prior notice.
Simrad AS shall not be liable for errors contained herein, or for incidental or
consequential damages in connection with the furnishing, performance, or use of this
document.
Simrad AS
Strandpromenaden 50
Box 111
N-3191 Horten
Telephone: [phone]
Facsimile: [phone]
M A X I M I Z I N G Y O U R P E R F O R M A N C E A T S E A

Operator manual
I
850-164385 / Rev.C
Sections
1. System description
This chapter provides a brief introduction to the SH80, and defines the main
units. Refer to page 1.
2. Display modes
This chapter defines the available operational display modes. Refer to page
13.
3. Sonar Operating Panel
The main functions of the SH80 is controlled by a dedicated keyboard; the
operating panel. The controls and functions of this unit is described. Refer
to page 23.
4. Operation
This chapter provides the basic knowledge on how to operate the SH80
sonar. Refer to page 36.
5. Menu description
Operation of the SH80 sonar is also menu based. and the menus will
automatically adjust to your current operational modes. This chapter
explains all the menus, and referes directly to the relevant parameters. Refer
to page 56.
6. Parameters
All the operational functions of the SH80 sonar are controlled by the
parameters accessed from the menu system. In this chapter, all the
parameters are described and explaind. They are listed in alphabetical
order. Refer to page 83.
7. Maintenance
This chapter explains how to perform the on-board maintenance on the
SH80 sonar. Refer to page 150.

Simrad SH80
II 850-164385 / Rev.C
SYSTEM DESCRIPTION 1......................................
Introduction 1..................................................
System overview 2..............................................
Main units 2..............................................
Wheelhouse units 2........................................
Sonar room units 3.........................................
System diagram 4...............................................
Options 6......................................................
General 6................................................
Multiple-frequency 6.......................................
Scientific output 6.........................................
Functional description 7..........................................
Introduction 7.............................................
Functional principles 7......................................
Stabilization system 9......................................
Reception 9...............................................
Transmission 10............................................
Peripheral equipment 12...........................................
DISPLAY MODES 13.............................................
Introduction 13..................................................
Bow Up 14......................................................
North Up 15.....................................................
True Motion 16..................................................
180°/Audio 17...................................................
270°/Vertical 18..................................................
Bow Up / Vertical 19..............................................
True Motion/Vertical 20...........................................
Dual 1 21.......................................................
Dual 2 22.......................................................
SONAR OPERATING PANEL 23..................................
Introduction 23.............................................
Main switch 24.............................................
Symbol 25................................................
Mode 27..................................................
Gain 28...................................................
Range 29..................................................
Cursor 30.................................................
Train 32..................................................

Operator manual
III
850-164385 / Rev.C
Tilt 34....................................................
Various 35.................................................
OPERATION 36..................................................
Introduction 36..................................................
Maintaining the sonar 37...........................................
Maintenance procedures 37...................................
Important when docking the vessel 37...........................
Start and stop procedures 38........................................
Start procedure 38..........................................
Stop procedure 39...........................................
Dry-docking safety measures 40...............................
Menu operation 41................................................
Introduction 41.............................................
Screen presentations 42......................................
Menu structure 44..........................................
Menu buttons 45............................................
Selecting a new parameter value 46.............................
Stored parameters 48........................................
Visual aids 49...................................................
Common information on the display 49.........................
Moving the boundary lines 49.................................
Cosmetics 50....................................................
Installation of options 53...........................................
On-line help 55..................................................
MENU DESCRIPTIONS 56.......................................
Introduction 56..................................................
Active menus 57.................................................
Overview 57...............................................
Horizontal 58..............................................
Vertical 59................................................
Display 60................................................
Setup 61..................................................
Objects 62.................................................
Temporary menus 63..............................................
Cosmetics 64..............................................
Store/Recall 65.............................................
System test 66.............................................
Sort Modes 68.............................................

Simrad SH80
IV 850-164385 / Rev.C
Pop-up menus 69.................................................
View pop-up 70............................................
Object pop-up 72...........................................
View menus 74..................................................
GeoView 75...............................................
VerticalView 76............................................
CatchView 77..............................................
Messages 78.....................................................
Message categories 78.......................................
Warnings 79...............................................
Operator alarms 80..........................................
System alarms 81...........................................
Errors 82..................................................
PARAMETERS 83.................................................
About parameter dialogues and help 83...............................
Alphabetical list 84...............................................
About 85..................................................
Beam 86..................................................
Bearing (Horizontal) 88......................................
Bearing (Display) 90........................................
Bearing (Vertical) 91........................................
Colour Threshold 92........................................
Colours 93................................................
Data Source 94.............................................
Dead Reckoning 95.........................................
Default Setting 96..........................................
Direction Indicator 97.......................................
Edit Gear (Purse) 98.........................................
Edit Gear (Trawl) 99........................................
Edit School 101.............................................
External Synchronization 102..................................
Fish Alarm 103..............................................
Frequency 104..............................................
Gain 105...................................................
Gear 106...................................................
Heading 107................................................
Inspect Object 108...........................................
Language 109...............................................
Menu 110..................................................

Operator manual
V
850-164385 / Rev.C
Message Bar 111............................................
Mode 112..................................................
Mode Buttons 113...........................................
Movements 114.............................................
Noise Level 115.............................................
Palette 116.................................................
Panel Backlight 117..........................................
PP Filter 118...............................................
Pulse Form 119.............................................
Range 121..................................................
Range (Catch View) 122......................................
RCG (Reverberation Controlled Gain) 123........................
Recall 124..................................................
Recall Mode 124............................................
Ruler 125..................................................
Scale 126..................................................
School 127.................................................
Scientific Output (Option) 128.................................
Search Sector 129............................................
Search Step 130.............................................
Slant Range/True Range 131...................................
Speed 132..................................................
Stabilizer 133...............................................
Status 134..................................................
Store 135..................................................
Store Mode 135.............................................
Target Track 136.............................................
Tilt 137....................................................
Time and Date 138...........................................
Track History 139............................................
Track Window 140...........................................
Transducer 141..............................................
TVG (Time Variable Gain) 142.................................
Tx Power 143...............................................
Units 144..................................................
User Setting 145.............................................
Wind Direction 146..........................................
Wind Speed 147.............................................
Zoom 148..................................................
Zoom Scale 149.............................................

Simrad SH80
VI 850-164385 / Rev.C
ON-BOARD MAINTENANCE 150..................................
Introduction 150..................................................
Preventive maintenance schedule 151..................................
Wheelhouse units 152..............................................
Cleaning 152...............................................
Dust filter 152..............................................
Transceiver Unit 154...............................................
Dust filter 154..............................................
Replacing fuses 154..........................................
Hull unit 156.....................................................
General 156................................................
Hull unit familiarization 157...................................
Docking the vessel 158.......................................
Cleaning the transducer 160....................................
Hoist motor overload protection 161.............................
Emergency hoisting and lowering 162............................
Lubrication of the Hull Unit 163................................

System description
1
850-164385 / Rev.C
SYSTEM DESCRIPTION
Introduction
The Simrad SH80 sonar is an omnidirectional high frequency
sonar, designed for all sized fishing vessels, both purse seiners
and trawlers. The standard frequency is 116 kHz (multiple
frequencies as option), and the beam can be electronically tilted
from +10 to –60 degrees.
Great emphasis has been placed on giving the best possible
presentations on a high resolution colour display. The processor
unit is controlled by Microsoft’s Windows XPoperating
system, which result in a flexible choice of display modes for a
large range of user applications.
The signal processing and beamforming is performed in a fast
digital signal processing system using the full dynamic range of
the signals. In addition to the traditional single frequency
transceiver system, the SH80 sonar contains an advanced
frequency modulated filter system (FM).
The cylindrical multi-element transducer allows the
omni-directional sonar beam to be tilted electronically down to
-60 degrees. This allows you to automatically track schools of
fish, and to observe the whole water volume around the vessel.
A stabilization system is included for electronic pitch and roll
compensation.
Topics
System overview, page 2
System diagram, page 4
Options, page 6
Functional description, page 7
Peripheral equipment, page 12
Important notice
Windows, Windows NT and Windows XPare either registered
trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.

Simrad SH80
2850-164385 / Rev.C
System overview
Main units
The Simrad SH80 sonar consists of the following units:
Wheelhouse units:
- Display monitor
- Sonar Operating Panel
- Sonar Processor Unit
- Sonar Interface Unit
Sonar room units:
- Transceiver Unit
- Hull Unit
Wheelhouse units
The Display Monitor is a high-resolution colour LCD (Liquid
Crystal Display). In addition to the sonar picture, the monitor
can also display the user menu for the interactive operation. In
order to ease the situation comprehension, certain colours have
been chosen to better the distinction between the various
elements in the scene.
The Operating Panel contains all necessary control functions
for operating the sonar. The controls are arranged in function
groups, which gives a clear and easy operation. Note that all
sonar operation also may be made from the trackball, or from an
optional standard mouse.
The Sonar Processor Unit contains a ruggedized computer,
which runs the Microsoft Windows XPoperating system.
The software has been modified by Simrad to suit the SH80
sonar requirements. The unit holds a CD R/WR unit to be used
for future software upgrades.
The Sonar Interface Unit provides interface for all auxiliary
equipment; log, gyro, GPS, echo sounder, trawl systems, purse
seine systems etc. One signal cable is used for the
communication with the Transceiver Unit in the sonar room.
Note that SH80 sonars shipped before August 2003 use a
different Sonar Processor Unit; the APC10. These sonars do not
have the Sonar Interface Unit fitted. All interfaces to peripheral
equipment are then handled by the APC10.

System description
3
850-164385 / Rev.C
Sonar room units
The Transceiver Unit is located in the sonar room, close to the
Hull Unit. One signal cable is used for communication with the
Sonar Interface Unit in the wheelhouse. The transceiver
performs the signal processing and the digital beamforming of
the 240 transmitters and 480 receiver channels, which are
located on the eight identical transceiver boards.
The Hull Unit is designed to be lowered 1.0 meters below the
ship’s hull. The transducer can also be lowered to any selectable
middle position. Note that in case of voltage failure, the Hull
Unit can be manually raised or lowered by means of a hand
crank.
The cylindrical 480-elements transducer allows the sonar beam
to give full 360 degrees coverage of the water volume down to
-60 degrees.
The sensor for the electronic stabilization of the sonar beams is
housed in the Motor Control Unit, which is mounted on the Hull
Unit.
Warning: If the transducer hits larger objects or bottom,
the transducer shaft may be bent, or in worst
caseitcanbebrokenoff.Abrokentransducer
shaft will cause water leakage in the top of the
shaft. To prevent larger leakages in such a case,
do not raise the transducer shaft to the upper
position. To prevent serious damages it is
therefore of great importance to have a good
pump and warning system in the sonar room.
Related topics
System diagram, page 4

Simrad SH80
4850-164385 / Rev.C
System diagram
A simplified SH80 system diagram is shown.
(A) = Colour display
(B) = Operating Panel
(C) = Sonar Processor Unit
(D) = Sonar Interface Unit
(E) = Multiple interface lines to peripheral equipment
(F) = Transceiver Unit
(G) = Hull Unit
(1) = Wheelhouse
(2) = Sonar room

System description
5
850-164385 / Rev.C

Simrad SH80
6850-164385 / Rev.C
Options
General
The standard SH80 sonar is a single 116 kHz version with beam
stabilization.
The beam stabilization was an optional function until 1 January
2003. After that date, the function was included with the
standard sonar delivery.
The options described below are pre-programmed into the
standard software version, and a code word is required to make
the actual option available. Simrad offers a 1 month free test
period for certain options. Note that the Scientific Output
function is not available for such a test period.
For a permanent installation of a chosen option, a new code
word will be released from Simrad when the option is ordered.
Multiple-frequency
In addition to the standard 116 kHz frequency, a multiple
frequency option is available. In this multiple frequency version
you can select between 13 frequencies from 110 to 122 kHz in 1
kHz steps.
Scientific output
The Scientific Output is designed for research purposes. When
activated, the following data are available on an Ethernet (LAN)
output:
Beam data
Target data
Own ship data
Gear data
The scientific output option may also include software for a
Scientific Data Logger.
Note that this option is not available for a free test period.
Related topics
Code words, procedure, page 53

System description
7
850-164385 / Rev.C
Functional description
Introduction
The basic principles of the SH80 sonar are unique because of
the 240 transmitter and 480 receiver channels with their
transducer elements spread around on the cylindrical transducer
array.
The transmission, reception and data processing are under
computer control, and the powerful capabilities of the sonar are
the results of sophisticated digital signal processing software
and state of the art hardware.
Functional principles
When the Omni beam is tilted, the total beam picture can be
compared with folding an umbrella, which means that all beams
in 360 degrees around the vessel have the same tilt angle.
Omni beam
principle
The beam can be tilted from +10 up to -60 degrees down.
In addition to seeing the target from above, it is also possible to
see the target from the side, by using the vertical slice
presentation. In this case the beam covers a continuous vertical
beam from 0 to -60 degrees in one transmission.
This vertical slice, which is presented by the white audio line in
the horizontal picture, can be selected to any bearing by the
manual training control. The combination of the Omni mode
and the vertical slice will give an optimal visualization of the
catch situation.

Simrad SH80
8850-164385 / Rev.C
60 degrees vertical
slice
Omni/Vertical
combination
In addition to the Omni picture, the vertical slice is especially
useful for visualizing the vertical distribution of a school of fish.
In that way, it is not necessary to go over the target to see the
distribution on the echo sounder, which often results in a
spreading of the school.

System description
9
850-164385 / Rev.C
Stabilization system
When the beam stabilizer is activated, both horizontal and
vertical beams will be stabilized electronically for roll and pitch
movements up to 20 degrees. The beam direction will then
change continuously according to the vessel’s movements, and
secure an optimal contact with the targets even in rough seas.
Stabilization
system
Reception
A great effort has been made to reduce unwanted noise to get a
clean and stable echo presentation. To achieve this goal the
sonar receiver has the following filtering possibilities:
FM Correlation filter
In addition to the traditional single frequency transmitting
method, the SH80 sonar is equipped with an FM correlation
mode.
In FM mode each transmission pulse contains up to four
different frequencies, and the receiver makes a spectrum
analysis and compares the received echoes with the transmitted
frequency code. This provides a filtering effect, which
efficiently reduces interference, noise and reverberation. In
addition to giving a clean and stable echo presentation, this will
normally also increases the sonar’s detection range
Frequency selection (Option)
The optional multiple frequency selection can be used for
suppression of interference from other sonars.

Simrad SH80
10 850-164385 / Rev.C
However, the sound absorption in salt water increases with the
frequency, thus giving the lower frequencies a longer detection
range.
RCG (Reverberation Controlled Gain)
The RCG filter senses the noise level (reverberation, propeller
noise, etc.), and adjusts the gain individually for each of the 64
receiver beams in order to eliminate noise on the display. The
strength of the filter can be selected in the menu. With
maximum strenght is selected, the RCG will effectively reduce
the bottom in shallow water, while variations on the bottom will
be displayed.
Note that scattered fish can be perceived as reverberation. The
RCG filter must therefore be used with care if scattered schools
are to be detected.
PP Filter
The SH80 sonar is equipped with a ping-to-ping filter to give a
clean and steady presentation by reducing the interference and
noise. This filter compares the echoes from a selected amount of
transmissions (pings), and an echo has to be present in the
selected amount of pings in order to be presented on the display.
Note that in rough seas, when the beam easily can miss the
target in several pings, the PP filter must be used with care.
TVG (Time Variable Gain)
The TVG function controls the gain of the receiver so that a
school with a given size and density is presented with
approximately the same strength on the display, inside the
regulated TVG range. This can also be seen as a filter, because it
reduces the noise close to the vessel.
The regulated strength of the TVG can be selected in the menu.
Transmission
The transmitting is controlled by the signal processor in the
Transceiver Unit. The parameters you have chosen are used.
There are 240 separate transmitters in the unit distributed on
eight transceiver circuit boards. Each transmitter is individually
addressed and controlled from the signal processor. The
controlled parameters include power output and time delay for
each transducer element in order to form a beam with the
selected tilt angle.
