KOBE WPS760 User manual

760W SUBMERSIBLE
WATER PUMP
ORDER CODE KBE-279-4500K WPS760
OPER ATOR’S MANUAL
Please retain this information for future reference.
WARNING: THE SAFETY INFORMATION
GIVEN INSIDE MUST BE READ AND
UNDERSTOOD BY ANY PERSON
USING, INSTALLING, REPAIRING
OR MAINTAINING THIS PRODUCT.
ALWAYS WEAR
APPROPRIATE
PERSONAL
PROTECTIVE
EQUIPMENT.
Suitable for the effective drainage of cellars,
cisterns and the general transfer of water.
Can handle solids up to 4mm diameter.
230 litres per minute flow rate.
760 watt motor.
Max delivery height 10m.
10m cable.
Easy to remove filters for cleaning and access
to the impeller.
Automatic float switch.
Capable of continuous and reliable running.
Strong double insulated case.
No metal parts in contact with water.
Overload protection.
Multi-hose adaptor.
© The Kennedy Group Ltd. 06/09
Kobe Tools continually strives to improve its products. Specifications may change without prior notice.
AVAILABLE FROM YOUR DISTRIBUTOR
QUALITY GUARANTEE & WARRANTY
KOBE PRODUCTS carry a one years manufacturers warranty.
KOBE PRODUCTS are designed & produced to the highest standards &
specifications
KOBE PRODUCTS are fully guaranteed against faulty materials & workmanship
Should they be found to be defective, they will either be repaired or replaced
free of charge (fair wear and tear and/or misuse excepted).
This does not affect your legal rights.
Please retain supplier invoice as proof of purchase.
KOBE TOOLS Official Agents:
JAPAN: MIKI TOOL TRADING CO. MIKI CITY, JAPAN.
EUROPE, MIDDLE EAST, AMERICA & AFRICA: THE KENNEDY GROUP LTD, WIGSTON, ENGLAND.
THE ENVIRONMENT
Always dispose of unwanted tools, accessories and packaging materials in an environmentally
friendly manner.
SERVICE & REPAIR
A comprehensive repair and
service facility is available through
your local Kobe agent for all your
electric and pneumatic tools.
KOBE
INDUSTRIAL
POWER TOOLS
KOBE
INDUSTRIAL
POWER TOOLS
760W SUBMERSIBLE
WATER PUMP
KBE-279-4500K_Instructions.qxd 19/08/2009 09:16 Page 1

Please ensure that the pump is in a stationary
position with a fixed pipeline or with a flexible
hose pipe.
The pump should not be installed by suspending it
unsupported from the delivery pipe or power cable and
should therefore be submerged via a rope fixed to the
pumps carry handle for it to be placed on the bottom
of the shaft. The pump shaft should have minimum
dimensions of 40 x 40 x 50cm, so that the floating
switch can move freely. Please note: The pump is
automatically switched off on overheating by the
built-in thermal cut-out. After having cooled down,
the motor automatically switches on again.
2 3
You have purchased a quality industrial product that is designed for high
performance and long service life. If correct use, safety and maintenance
procedures are observed this tool will last for many years.
SAFETY INSTRUCTIONS
KOBE INDUSTRIAL TOOLS have been specifically designed to help you work SAFELY
and EFFICIENTLY. Your care and good judgement are the best protection against injury, but
always ensure that the appropriate safety equipment is worn. All possible hazards cannot be
covered here, but the most important ones have been highlighted. The Kobe submersible pump
is designed for private use around the house and garden. It is predominantly used for drainage
after flooding, transport of liquids, draining containers and taking water from wells and shafts.
SPECIFICATIONS
INSTALLATION
KOBE
INDUSTRIAL
POWER TOOLS
AREAS OF USE
KOBE
INDUSTRIAL
POWER TOOLS
MAINTENANCE
KOBE
INDUSTRIAL
POWER TOOLS
MAINS SUPPLY
KOBE
INDUSTRIAL
POWER TOOLS
KOBE
INDUSTRIAL
POWER TOOLS
Model: WPS760
Nominal voltage: 230V
Nominal frequency: 50Hz
Power consumption: 760 Watt
Delivery rate max.: 14,000 L/H
Delivery height max.: 10m
Submersion depth max.: 8m
Water temperature max.: 35°C
Hose connection: 1”, 11/4” and 11/2”
Foreign bodies up to: dia. 4mm
Switching point ON: approx. 50cm
Switching point OFF: approx. 5cm
Suitable hose sizes: 1”, 11/4and 11/2
PERFORMANCE DATA
1m - max.: 14,000l/h max.
2.5m - max.: 12,200l/h max.
5m - max.: 10,500l/h max.
7.5m - max.: 8,000l/h max.
Max
delivery
height
10m
4mm
1400L/h - 230L/m
25-38mm
This submersible pump is an approved, maintenance-free high quality product, it is recommended
that regular inspection and maintenance is carried out to ensure long life of the submersible pump
and uninterrupted use.
Whilst the pump is in use it is essential to check that the level of water does not sink too far.
Any sludge in the shaft may dry out quickly and stop the pump from starting up. It is necessary,
therefore, to check the submersible pump regularly (by carrying out start-up tests). The floater is
adjusted in a way that the pump can immediately be started.
After having pumped chlorinated swimming pool water, pond water or other liquids leaving
residues, the pump should be rinsed with clear water. The bottom of the shaft must be kept
free of sludge and debris of all kinds in order to guarantee that the pump works properly.
Your new submersible pump is equipped with a shock-proof plug according to the regulations.
The pump is designed to be connected to a 13 Amp 3 pin socket which has been installed
according to regulations. The plug must have a supply voltage of 230V - 50Hz. Make sure that
the socket is sufficiently secured (min.6 Amp) and is in excellent condition before use.
Always ensure the electrical supply is fitted
with a R.C.D. ground fault circuit interrupter
with a nominal trip current of max. 30mA
(according to VDE 0100, part 702 and 738).
When it is being used in swimming pools or
garden ponds the pump must not be operated
while people are in the swimming pool or in
the garden pond!
Always protect the pump from frost.
Always fix a rope to the pump’s carrying handle
to submerge or lift it.
Always keep children away from the work area.
Always check if the pump rests firmly on
the ground.
Always check that the delivering hose is
fixed securely
Always check if electrical connection is
230V - 50Hz
Always check if socket is in good condition.
Always ensure that water and humidity are
kept away from the mains supply.
Never use a damaged pump.
Never let the pump run dry.
Never use continuously in a pond.
ON
50cm
OFF
GENERAL OPERATING HAZARDS
It is important that the following points are checked before you use your pump:
Designed for private use around the house and
garden.
It is predominantly used for drainage after flooding,
transport of liquids, draining containers and taking
water from wells and shafts.
Liquids which can be handled are: Clean and
contaminated water, swimming pool water and
soapy water. The pump is fully submersible and can
be immersed in the liquid to a depth of 5m.
Please note: Corrosive, easily combustible or
explosive substances (e.g. gasoline, petroleum,
nitro thinner), fats oils, salt-water and waste water
must not be pumped. The submersible pump is not
to be operated out of the water.
