KOCOM KCC-D51 User manual

KCC-D51 07.04
This user's manual may be changed for the enhancement of product quality without notice.
KCC-D51 User's Manual
High Resolution Day& Night Color Camera
5
4
0
T
V
l
i
n
e
s
O
n
S
c
r
e
e
n
D
i
s
p
l
a
y
M
e
n
u
S
u
p
e
r
D
i
g
i
t
a
l
N
o
i
s
e
R
e
d
u
c
t
i
o
n
【
S
D
N
R
】
▶Please read User's Manual carefully before installing or using the product.

Contents
1
Product Features
Warnings & Attentions
Product Components
Names of Product Parts
- Front Side
- Back Side
Installation
- Lens
- Installation Using Automatic Iris
- Installation Using C/CS Mount Lens
Monitor Connection
Power Connection
Camera Operation
3
5
7
8
8
9
10
10
10
12
13
14
15
2
Functions of OSD MENU Buttons
How to Set OSD MENU SET UP Functions
- Lens Selection (LENS)
- Shutter Selection (SHUTTER)
- White Balance Selection (WHITE BALANCE)
- Backlight Compensation Selection (BACKLIGHT)
- AGC Selection (AUTO GAIN CONTROL)
- DNR Selection (DIGITAL NOISE REDUCTION)
- SENS-UP (Automatic adjustment at night or under dim light)
- SPECIAL Functions (Functions peculiar to camera)
Troubleshooting
Product Specifications
17
19
19
20
21
22
23
24
25
26
33
35

Product Features
3
▶ High Sensitivity
- Clear image even under the illuminance of 0.002 by adopting 1/3 INCH SONY SUPER HAD CCD.
▶ 540 TV Lines
- Clear image quality of 540 TV lines in its horizontal resolution by adopting COLOR CCD
with 410,000 pixels.
▶DNR (Digital Noise Reduction)
- Applies DNR DSP CHIP for the effective reduction of noise under low illuminance, the increase of horizontal
resolution the clear image even at dim places by improved S/N ratio.
▶Electronic Day & Night Function
- Automatically discerns day and night settings and electronically switches into the mode appropriate to
such settings. (While the product is switched into COLOR mode to secure and maintain optimal color under
the day settings, it is switched into B/W mode for more improved discernability of dim settings under
the night settings).
▶Electronic IRIS Function
- Provides automatic shutter control in a continuous way from 1/60(1/50) to 1/120,000 seconds by adopting
electronic IRIS.
4
▶ PRIVACY Function
- Able to hide a part of screen not to be shown by supporting PRIVACY Function.
▶ OSD MENU (On Screen Display Menu)
- Able to select or deselect major functions of camera with comfortable OSD MENU.
▶VIDEO/DC Drive Lens
- Able to select VIDEO or DC drive lens only by simple operation of switch.
▶Additional Functions
- Provides additional functions such as CAMERA ID, MOTION DETECTION, SHARPNESS, MIRROR,
LINE LOCK and RESET.
▶Fine Exterior Design
- Provide the finest product image with a small, robust, differentiated and refined design.
▶Please Use Regulated DC 12V / 300mA Power Supply
※OPTION : Dual Input Voltage (DC12V and AC24V).

Warnings & Attentions
This section contains important instructions for the correct use of the
product to avoid possible dangers or material damages.
Please read carefully for the right and correct installation and use of the product.
Do not disassemble the product to avoid the danger of electric shock.
This symbol represents the dangers which may cause personal injuries or
material damages if neglectfully handled.
This symbol represents the dangers which may cause death or serious injury
if neglectfully handled.
5
Warnings:
6
※ Warnings
- Please contact your local seller or service center if the product does not work normally.
- Do neither disassemble the product at user's discretion nor insert any alien material into it.
- Do not personal installation by a user.
- Do not touch a plug with a wet hand.
- Stop to use the product if smoke comes out from camera or abnormal high heat is emitted.
- Do not install the product at humid place or the places exposed to oils or gases.
- Do not install the product at the ceilings or walls which do not provide tight fixing.
(It may cause the accidents due to drop).
※ Attentions
- Do not install the product at the places with unstable lighting.
- Do not install the product at excessively hot or cold places.
- Avoid drop, strong impact or tremor.
- Prevent camera lens from directing to the strong ray of the sun.
- Do not install the product at the places infused by rain, water or gas.
(Water infused into camera may cause mechanical troubles of it).

Product Components
● KCC-D51 Camera (Main Body) ● User's Manual
● Automatic Iris Lens
Connection Plug
● L-Wrench ● C-Mount Adaptor
7
Names of Product Parts
■ Front Side
8
● A groove for fixing the C/CS mount
Fix C/CS mount here using L-Wrench.
● A groove for fixing the support
Please use the screws complying with the following standards to fix the product.
※1/4" - 20 UNC (20 TREAD)
L : 4.5mm ±0.2mm (ISO Standard) or 0.197" (ASA Standard)
●Lens Protection Cap
Whenever the lens is not mounted, be sure to put the lens protection cap.

Installation
■ Lens
■ Installation Using Automatic Iris
● Lens is optional. (Automatic iris lens, CS-mount lens, C-mount lens or other lenses may be used).
※ Note : For effective realization of the product's major performances, it is recommended to use DC type iris lens.
[Alien substances or fingerprints on the lens surface may cause poor image quality under low illuminance, so always keep clean].
10
1. Please peel off about 8mm of the outer skin of the automatic iris lens cable.
2. Please peel off about 2mm of the outer skin of the insulated conductor inside the lens cable.
About 8mm
About 2mm
Names of Product Parts
■ Back Side
● VIDEO OUT Terminal
Outputs video signal and connects to video input terminal of monitor.
● Automatic Iris Lens Connector
A connection terminal for automatic iris lens.
● Switch for Automatic Iris Lens Selection
Change to DC or VIDEO mode according to the type of
automatic iris lens used.
● Power Input
DC 12V / 300mA.
Power Lamp ●
● OSD Function SET UP Button
- SET UP Button: displays menu screen. (Use when confirming a changed
value of a selected item or a change in the present condition).
- UP/DOWN Button : Used to move cursor up and down at menu screen
to select a desired menu item.
9

Installation
■ Installation Using C-mount Lens
■ Installation Using CS-mount Lens
- After removing the lens protection cap in the front side of the product, combine C-mount lens by turning it clockwise.
1. After removing the lens protection cap in the front side of the product,
combine CS-mount by turning it clockwise.
2. Combine CS-mount lens by
turning it clockwise.
12
Lens Protection Cap
Lens Protection Cap
C-mount Adaptor
CS-mount Adaptor
Installation
3. After removing connection plug cap from automatic iris lens, connect and solder lens cable to connector pins of connection plug.
4. After removing the lens protection cap in the
front side of the product, combine automatic
iris lens by turning it clockwise.
5. Insert the connection plug connected to
automatic iris lens cable into AUTO IRIS
connector in the back side of the product.
6. According to the automatic
iris lens used, select VIDEO or
DC mode using lens selection switch.
11
PIN VIDEO DC
PIN 1
PIN 2
PIN 3
PIN 4
Damping(-)
N.C
White (Video Signal)
Black (Grounding)
Red (Power)
Damping(+)
Drive(+)
Drive(-)
Lens Protection Cap
Cap
PIN 1
PIN 3
PIN 4
PIN 2
Lens Cable
Connector

Monitor Connection
■ For intermediate video equipment, select 75 Ω or Hi-Z as follows.
■ Connect the video output terminal of camera to the input terminal of monitor.
13
Connection methods vary according to the equipment used,
so please refer to the user's manual of such equipment.
Be sure to connect when the equipment is turned off.
Camera
Camera
Monitor
Intermediate Video Equipment End Monitor
Power Connection
■ Be sure to check the power standard of the product before power connection.
- Connect the constant voltage adaptor for DC (DC 12V/300mA) only.
※ ( Note) Connect adaptor after checking its polarity.
14
GND GND
※OPTION (DC 12V or AC 24V)
DC 12V
DC 12V / AC 24V

Camera Operation
15
■ Contents of OSD MENU
SET UP Menu
●MANUAL ●DC/VIDEO
●ESC ●MANUAL ●FLK
●ATW ●AWC ●MANUAL
●OFF ●LOW ●MIDDLE ●HIGH
●OFF ●LOW ●MIDDLE ●HIGH
●OFF ●LOW ●MIDDLE ●HIGH
●OFF ●AUTO
●CAMERA ID ●COLOR
●SYNC ●MOTION DETECTION
●PRIVACY ●MIRROR
●SHARPNESS ●RESET
●RETURN
LENS (selects lens)
SHUTTER (adjusts shutter mode and speed)
WHITE BALANCE (adjusts white balance)
BACK LIGHT (provides backlight compensation)
AGC (AUTO GAIN CONTROL)
DNR (Digital noise reduction)
SENS-UP (Low illuminance)
SPECIAL Menu
EXIT
■ How to Set OSD MENU Functions
- Use 5 buttons in the Back side of the product to set up OSD MENU functions.
16
◉ UP
◉ RIGHT
◉ LEFT
◉ DOWN
◉ SET UP
+

3. Change the present mode using LEFT or RIGHT button.
- Pressing LEFT or RIGHT button, selectable values or states are displayed in order.
(Press button until the desired mode or state are displayed).
4. To finish set up mode, select EXIT in OSD MENU and then press SET UP button of camera.
[Note]
For the modes displaying symbol, press SET UP button to go to sub menus.
For the modes displaying - - - symbol, such mode cannot be used according to the present set up states.
18
Using LEFT or RIGHT button
to change the present modes.
SETUP
DC▶LENS
SHUTTER - - -
WHITE BAL. ATW
BACKLIGHT OFF
AGC MIDDLE
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
Using UP or DOWN button
to select a desired menu item.
Functions of OSD MENU Buttons
1. Press SET UP button
- Product goes to the functional set up state.
(SET UP menu is displayed in the monitor screen connected to camera).
2. Select a desired menu item using UP and DOWN buttons.
- Pressing UP or DOWN button, an arrow moves up or down, respectively.
(Make the arrow point the desired menu item).
17
◉ SET UP
SETUP
DC▶LENS
SHUTTER - - -
WHITE BAL. ATW
BACKLIGHT OFF
AGC MIDDLE
DNR LOW
SENS-UP OFF
SPECIAL
EXIT

How to Set OSD MENU SET UP Functions
■ Lens Selection
Functions showing the brightness of screen.
1. If SET UP screen is displayed, make an arrow point to "LENS" item using UP or DOWN button.
2. Press LEFT or RIGHT button to select the type of lens to be used.
◎ MANUAL : Manually Lens Selection
3. Press SETUP menu to return to the previous menu.
19
◎ DC / VIDEO : Automatic Iris Lens Selection
SETUP
DC▶LENS
SHUTTER - - -
WHITE BAL . ATW
BACKLIGHT OFF
AGC MIDDLE
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
LENS
▶BRIGHTNESS l - - I - - I 25
If automatic iris lens is attached, the lens selection switch
in the back side of the product should be set at DC or VIDEO.
If DC lens is selected, the brightness of screen can be adjusted
within the range from 1 to 70. (Make a proper adjustment for
optimal screen brightness).
20
◎ FLK : When FLICKER occurs due to the influence of lightings around the product or the discordance
in frequency, select "FLK" mode.
◎ ESC : Can automatically control shutter speed. Selecting "ESC" automatically controls shutter speed
according to the brightness of screen.
◎ MANUAL : Can manually control shutter speed.
SETUP
MANUALLENS
▶SHUTTER ESC
WHITE BAL. ATW
BACKLIGHT OFF
AGC MIDDLE
DNR LOW
[Notes]
If DC/VIDEO lens is selected, shutter speed is fixed at 1/60(1/50) second.
If shutter is set as "ESC" in internal synchronization method and camera directly faces fluorescent lamp,
image may become unstable. Select installation place carefully.
If SHUTTER menu is on MANUAL mode, SENS UP function does not work.
■ Adjustment of Shutter Mode and Speed
Selects automatic or manual control of shutter.
1. If SET UP menu is displayed, make an arrow point to "SHUTTER" item using UP or DOWN button.
2. Press LEFT or RIGHT button to select the type of lens to be used.
3. Set "SHUTTER" as "MANUAL" and press SETUP button
to manually control shutter. (Shutter speed can be adjusted
within the range from 1/60(1/50) to 1/120,000 second).
4. Press SETUP button after finishing setup.

How to Set OSD MENU SET UP Functions
■ Adjustment of WHITE BALANCE
Use this function if the color adjustment in screen is necessary.
1. If SET UP menu is displayed, make an arrow point to "WHITE BAL" item using UP or DOWN button.
2. Press LEFT or RIGHT button to select a desired mode.
21
◎ ATW : Used in color temperature from 1,800˚K to 10,500˚K.
◎ AWC : To get the most appropriate state under the present conditions,
aim camera to white paper and press SETUP button.
If environment is changed, it should be readjusted.
◎ MANUAL : If selected, fine tuning is available. After selecting ATW or
AWC and switching to MANUAL mode, press SETUP button. After setting
proper color temperature, increase or decrease the values of RED or BLUE
while observing the color changes of the subject shown in the screen.
[Notes]
In the following conditions, WHITE BALANCE may not function well.
1) If surroundings of the subject have extremely high color temperature (e.g. : clear sky, at dusk).
2) If surroundings of the subject is dark.
3) If camera directly faces fluorescence lamp or is installed at the places where lights is considerably changed.
SETUP
MANUALLENS
SHUTTER ESC
▶WHITE BAL. ATW
BACKLIGHT OFF
AGC MIDDLE
DNR LOW
22
■ BACKLIGHT (Backlight Compensation)
If BLC is selected for the subject under the strong backlight, both the subject and its background
can be clearly seen.
1. If SET UP menu is displayed, make an arrow point to "BACKLIGHT" item using UP or DOWN button.
2. Press LEFT or RIGHT button to select a desired mode.
SETUP
MANUALLENS
SHUTTER ESC
WHITE BAL. ATW
▶BACKLIGHT OFF
AGC MIDDLE
DNR LOW
■ BACKLIGHT ON ■ BACKLIGHT OFF
◎ HIGH : increases GAIN by 6dB up to 34dB.
◎ MIDDLE : increases GAIN by 6dB up to 30dB.
◎ LOW : increases GAIN by 6dB up to 18dB.
◎ OFF : turns off BACKLIGHT function.

How to Set OSD MENU SET UP Functions
■ AGC Function (AUTO GAIN CONTROL)
1. If SET UP screen is displayed, make an arrow point to "AGC" item using UP or DOWN button.
2. Press LEFT or RIGHT button to select a desired mode.
(The higher GAIN level is, the brighter the screen becomes but the more NOISE increases).
23
SETUP
MANUALLENS
SHUTTER ESC
WHITE BAL. ATW
BACKLIGHT OFF
▶AGC MIDDLE
DNR LOW
Brightness
Press SET to Return
▶BRIGHTNESS l - - I - - I 25
◎ HIGH : increases GAIN by 6dB up to 34dB.
◎ MIDDLE : increases GAIN by 6dB up to 30dB.
◎ LOW : increases GAIN by 6dB up to 18dB.
◎ OFF : fixes GAIN level at 6dB.
3. Press SETUP button. BRIGHTNESS can be adjusted
within the range from 1 to 70.
4. After finishing setup, press SET UP button.
24
SETUP
MANUALLENS
SHUTTER ESC
WHITE BAL. ATW
BACKLIGHT OFF
AGC MIDDLE
▶DNR LOW
■ DNR Function (DIGITAL NOISE REDUCTION)
As GAIN increases or decreases, DNR function automatically reduces background noise of low illuminance.
1. If SET UP menu is displayed, make an arrow point to "DNR" item using UP or DOWN button.
2. Press LEFT or RIGHT button to select a desired mode.
◎
OFF : has no noise reduction effect.
◎ LOW : has a low noise reduction effect but nearly no
residual images.
◎ MIDDLE : has the most general effect in noise reduction
with considerable decrease in noise and smaller
residual image effect.
◎ HIGH : has the greatest effect in noise reduction,
but also has the severest residual image effect.

How to Set OSD MENU SET UP Functions
3. After finishing setup, press SET UP button.
25
■ SENS UP
Automatically detects darkness at night or under dim light and keeps clear images.
1. If SET UP screen is displayed, make an arrow point to "SENS UP" item using UP or DOWN button.
2. Press LEFT or RIGHT button to select a desired mode.
SETUP
MANUALLENS
SHUTTER ESC
WHITE BAL. ATW
BACKLIGHT OFF
AGC MIDDLE
DNR LOW
▶SENS-UP OFF
SPECIAL
[Notes]
Press SET UP button in AUTO menu to adjust magnification (12 steps).
As magnification becomes higher, the screen becomes brighter but the residual image of moving object grows more.
If magnification is increased when SEN UP works, noise or spots may occur. But such phenomenon is normal.
[Notes]
If AGC is set as OFF mode, SENS UP function doesn't work.
If SHUTTER is set as MANUAL mode, SENS UP function
doesn't work.
◎ AUTO : Automatic mode
◎ OFF : De-selection mode
26
■ SPECIAL Functions
1. If SET UP screen is displayed, make an arrow point to "SPECIAL" item using UP or DOWN button.
2. Press LEFT or RIGHT button to select a desired mode.
SPECIAL
OFF▶CAMERA ID
COLOR ON
INT
SYNC
MOTION DET OFF
PRIVACY OFF
MIRROR OFF
SHARPNESS ON
RESET
RETURN
SPECIAL
ON▶CAMERA ID
CAMERA ID : If a user inputs an ID of installed CAMERA,
such CAMERA ID is displayed in monitor.
1) Using UP or DOWN button, make an arrow point to
"CAMERA ID" item.
2) By pressing LEFT or RIGHT button, set the present
state as "ON."
[Notes]
If CAMERA ID is set as "OFF" mode, even if input by a user, it is not displayed in the monitor screen.
If CAMERA ID is set as "ON" mode, it is displayed in the screen of installed monitor.

How to Set OSD MENU SET UP Functions
27
3) After setting CAMERA ID as "ON," press SET UP button.
Camera ID
A B C D E F G H I J K L M
N O P Q R S T U V W X Y Z
a b c d e f g h i j k l m n o
p q r s t u v w x y z
- . 0 1 2 3 4 5 6 7 8 9
<- -> CLR POS END
- - - - - - - - - - - - - - -
4) Up to 15 letters are available for CAMERA ID.
Camera ID
- - - - - - - - - - - - - - -
(1) Using LEFT or RIGHT button, move cursor to a desired letter.
(2) Using UP,DOWN or LEFT, RIGHT button, select letters out of
A to Z, a to z, or 0 to 9.
(3) Press SET UP, fix a selected letter.
※ If pressing SET UP button to fix a selected letter,
cursor moves the next space.
(4) After completing to input a desired CAMERA ID, place cursor at "END"
and press SET UP button to finish.
[Notes]
If a wrong ID is input, move cursor to CLR and press SET UP to clear all letters input. To modify a letter,
move cursor to the arrow at the bottom left corner and press SET UP. Move and place cursor to a letter
that a user wants to input, and press SET UP button.
Camera ID
A B C D E F G H I J K L M
N O P Q R S T U V W X Y Z
a b c d e f g h i j k l m n o
p q r s t u v w x y z
- . 0 1 2 3 4 5 6 7 8 9
<- -> CLR POS END
- - - - - - - - - - - - - - -
28
5) If CAMERA ID is created, select the location where created CAMERA ID is displayed.
(1) After moving cursor to "POS," press SET UP.
(2) A created CAMERA ID is displayed at the upper
left corner of screen.
KCC-D51
to Locate, then SET
(3) If CAMERA ID is displayed as shown in the picture above, select the location of CAMERA ID
in the screen using UP, DOWN or LEFT, RIGHT button, and press SET UP.
(4) After the location is fixed, select "END" and press SET UP to finish ID input.

How to Set OSD MENU SET UP Functions
29
■ COLOR (Electronic Day & Night)
◎ AUTO : Automatically discern day or night settings and switches to the appropriate mode for the surrounding conditions.
While mode is switched to COLOR during the day, it is switched to B/W at night.
◎ ON : Mode isn't automatically switched and fixed at COLOR.
■ SYNC : In the area of 60Hz(50Hz), a user can put output phases of several units in tune using Line Lock
function without a synchronizing signal generator.
SYNC
▶PHASE l - - - - - I 225
[Notes] If AFC is set as OFF, COLOR function are not available.
※ Camera is more liable to be out of focus under an infrared lighting than general ones.
INT : Internal Synchronization Method.
LL : Line Lock Method (AC 24V).
Press SET UP button.
A user can select a desired phase among 0 to 359.
[Note]
In a product using DC 12V, SYNC is fixed at "INT" mode.
30
■ MOTION DETECTION
MOTION DETECTION
Press SET to Return
AREA 1▶AREA SEL
AREA STATE ON
I- - I - - I 10
I- I - - - I 25
I- - I - - I 20
I- - I - - I 40
TOP
DOWN
LIGHT
RIGHT
- This product can detect motions of subject in the 4 areas on screen. During the motion detection,
a message "MOTION DETECTION" is displayed, which enables a person to do his job effectively.
The motions of subject are detected by the differences in its
contour, brightness, and color.
(1) Press SET UP button
- OFF : deselects the function.
- ON : detects a MOTION occurred in a selected area.
(2) In AREA SEL, select one among 4 areas where a user does
motion detection.
(3) Change the state of a selected area to ON.
(4) Using UP, DOWN or LEFT, RIGHT button,
adjust the size of detection area.
(5) Press SET UP button to save the changed value and finish.

How to Set OSD MENU SET UP Functions
31
■ PRIVACY
PRIVACY
Press SET to Return
AREA 1▶AREA SEL
AREA STATE ON
AREA TONE
I- - I - - I 10
I- - - I - I 80
I- I - - - I 25
I- - I - - I 20
I- - I - - I 40
TOP
DOWN
LIGHT
RIGHT
MIRROR OFF MIRROR ON
(1) Able to hide an area that a user doesn't want to display
in the screen.
- OFF : deselects the function.
- ON : turns on PRIVACY function.
(2) In AREA SEL, select one among 4 areas that a user wants
to hide.
(3) Change the state of a selected area to ON.
(4) Using UP, DOWN or LEFT, RIGHT button, adjust the
size of an area to be hidden.
(5) Using AREA TONE, adjust the TONE
of an area to be hidden.
■ MIRROR
- OFF : sets the reversal of a horizontal image.
- ON : deselects the reversal.
32
SHARPNESS
Press SET to Return
I- - I - - I 8
LEVEL
■ SHARPNESS
- If a user increases its level, the contour of image becomes sharpened and clear.
Please adjust appropriately according to the image values.
If set too higher, images may be seen as unnatural or noise may occur.
(1) Press SET UP button
- A user can select a desired SHARPNESS level from 0 to 31.
■ RESET : Returns to ex-factory default setup values.
■ RETURN : Goes back to SETUP menu after saving SPECIAL menu.
■ EXIT : Exits from SET UP menu after saving setups.

Troubleshooting
33
■ If a trouble or disorder occurred in the product, please check the following points.
Trouble Check Points
- Is noting displayed in the screen?
- Isn't the screen clear?
- Is the screen dim?
- Isn't the color matched?
- Are black lines shown in the camera
image screen?
- Check that the power is normally connected to the constant voltage
adaptor (DC12V/500mA).
- Check that the video signal is normally connected.
- In case VIDEO (DC) lens is used, check that the selection switch for
automatic lens are properly set at DC/VIDEO.
- Check that lens is stained with alien substances or dusts.
- Check the monitor state.
- If too much bright lays are infused into the camera under the present
installation angle, please adjust such angle.
- Readjust the back focus of camera.
- Adjust the monitor state.
- If automatic iris lens is used, properly adjust the brightness of the lens.
- Check whether "WHITE BAL." is properly set in functional setup.
- Check the adaptor connected to the camera.
(Check that there is no problem in rated voltage).
34
Trouble
Check Points
- Does not the motion detection work?
- Is there a flicker on the screen?
- Is Line Lock mode setup unavailable?
- Doesn't COLOR (day & night) work?
- Doesn't SENS UP work?
- Check whether MOTION DETECTION function is set as "OFF"?
If so, set the function as "ON."
- Is MD LEVEL set too low?
- Is MD AREA set appropriately?
- Is camera lens directed to the sun or fluorescent lamp?
- Check the installation angle of camera.
- If DC12V/300mA is used, Line Lock function doesn't work.
- Check whether "AGC" is set as "OFF." If so, change the state of
AGC to "ON."
- Check whether "AGC" is set as "OFF."
If so, change the state of AGC to "ON."
- Check whether SHUTTER is set as "MANUAL."
If so, change such mode to ESC.

Product Specifications
35
■ Product specifications are as presented in the following table.
Description/Model KCC-D51
Input Power
Image Sensor Device
Total Pixels
Effective Pixels
Scanning System
Scanning Frequency
Sync System
Resolution
Video Output
S/N ratio
Minimum lllumination
Color Day & Night
White Balance
540 TV Lines
1.0Vp-p/75Ω(Video 0.714Vp-p Sync 0.286Vp-p)
more than 50dB (AGC OFF)
0.002 Lux @ F1.2
ON / AUTO
ATW/AWC/MANUAL(1,800˚K󰾝10,500˚K)
DC12V/300mA
1/3 INCH SONY SUPER HAD COLOR CCD
795 (H) x 596 (V)
752 (H) x 582 (V)
811 (H) x 508 (V)
768 (H) x 494 (V)
2 : 1 Interlace
15,625KHz (H) x 5OHz (V)15,734KHz (H) x 59,94Hz (V)
Internal
36
Description/Model KCC-D51
IRIS Control
Electronic Shutter Speed
Sens-Up
OSD Menu
Motion Detection
DNR
Mirror
Privacy
Sharpness
Lens Mount
Operation Temperature
Weight
Size
Changeable Mount for C or CS type Lens
-10˚C 󰾝 50˚C (Within 90% RH)
Approx : 250 g
54 (W) x 52 (H) x 100 (D) mm
DC / VIDEO
AUTO / MANUAL (1/60,1/50 󰾝 120,000 sec)
OFF / AUTO
OFF / ON
OFF / ON (4 Programmable Zone)
OFF / ON (4 Programmable Zone)
OFF / ON
OFF / LOW / MIDDLE / HIGH
OFF / ON
