KONDATOR 436-T50G User manual

Caution
PRODUCT SPECIFICATION
PART NUMBER
Color Temp (Kelvin)
CRI
Brightness (50 cm distance)
Lumen
Eco-timer
Expected life time
AC / DC adapter
Power Consumption
Weight
Operating temperature
436-T50G (Gray) : 436-T50W (White)
4000 ± 200 K
RA ≥ 93
560 / 450 / 340 / 224 / 112 / Lux ± 10%
400 lm ± 10
4 Hours
50 000 Hours
AC 220~240V, DC 12V 420 mA
7 W ± 10%
540g
-10 40 °C
ADVANTAGES OF CONCEPTUM LED
CAUTION
Use ONLY the supplied AC
power adaptor.
Do not place near any heat
sources or in direct sunlight.
ONLY Supplied adaptor
Do not repair, disassemble, or
modify under any
circumstances.
Do not use appliances with
frayed or damaged electrical
cords.
Please keep the light and all
appliances dry and clean.
Clean only with a soft dry
cloth and do not use solvents
or cleaning solutions.
Do not touch electrical
appliances with wet hands or
when liquids are present.
Never overload electrical
circuits as it may cause
electrical shock or fire.
Thank you for purchasing the Conceptum Lamp.
Please read the instructions before use to operate Conceptum LED Lamp safely .
We recommend that you keep these instructions.
ECO-firendly light
It provides a safe, comfortable, consistent light that
stimulates concentration without eye strain.
It contains no mercury or environmentally harmful
substances.
Extraordinary Long lifetime
Lasts up to 40 times longer than a typical
incandescent bulb.
(Used 5 hours per day it will last up to 22 years)
Low power consumption
It consumes 80% less power than a typical flourescent
light.
Flicker Free Light
Reduce eye strain without the flickering present in both
incandescent and flourescent lights.
Conceptum Lamp
Flicker-Free
www.kondator.se

DISPOSAL / RECYCLING
IMPORTANT SAFEGUARDS
To ensure that your lamp lasts, please see the below recomendations.
1. Make sure that the rating label of the adapter corresponds to the power output of the usage environment.
2. See the user manual for the correct cleaning procedures.
3. Indoor use only.
4. The light source in this luminaire shall only be replaced by the manufacturer, manufacturers service agent
or similarly qualified person.
WARRANTY
- Warranty ensures that this product will operate for the period of 2 years based on an avarage usage of up
to 8 hours per day when used in accordance with the directions and specifications stated in this manual.
- If this product fails to conform to the warranty a replacement product is guaranteed upon presentation of
a valid sales receipt.
ASSEMBLY AND INSTALLATION
x2
Decide on nut variant 1A or 1B .
Place it into the aluminum profile
track.
The sliding nut 1B has to be
inserted from the side.
Remove the bracket’s 2 cover.
(See instruction below).
Once off, hook the bracket
flange into the upper track.
Fully align the brackets screw holes with the nuts.
Use screws 3to fixate the bracket to the aluminum profile.
Insert cover
Slide the
cover into place.
Remove cover
Grip the upper ends
firmly and pull
outwards while
maintaining the grip.
Connect the power adapter 4to an outlet.
Insert the power cord through the
bracket 3from below
and plug it to the bottom of the lamp 5
The lamp is now fully assembled and can
be used as intended. Adjust neck for optimal
position.
Cycle through brightness setting
by pressing , and hold to
turn the lamp off.
PRODUCT DESCRIPTION
- Eco-timer 4 h
- 5 step touch button
- Hold button to turn off
- Adjustable
goose neck - AC / DC
adapter
- DC port
PRODUCT COMPOSITION
2 x1
3 x2
1B
1A
x1
x2 4 x1
5 x1
NATURAL LIGHT
Conceptum Lamp’s CRI is 93. It reproduces a natural type of light source.
CRI = Color Rendering Index
Color Rendering Index (CRI) is the index which shows how close a light source is to natural sunlight.
The CRI of natural sunlight is 100%. The higher the CRI value is, the closer it is to natural sunlight.
