Konig KN-SCOPE60 User manual

KN-SCOPE60
REFLECTOR TELESCOPE
MANUAL
MODE D’EMPLOI
MANUALE
HASZNÁLATI ÚTMUTATÓ
BRUKSANVISNING
ANLEITUNG
GEBRUIKSAANWIJZING
MANUAL DE USO
KÄYTTÖOHJE
NÁVOD K POUŽITÍ

Česky Svenska Suomi Magyar Español Italiano Nederlands Français Deutsch English
2
CAUTION!
Under NO circumstances should be looked directly into the sun.
Direct observation of the sun is very dangerous for the eyes.
Description:
Figure 1

English Deutsch Français Nederlands Italiano Español Magyar Suomi Svenska Česky
3
1. Open End of Tube 12. Right Ascension Clamp Screw
2. Diagonal Mirror (inside) 13. Clock Drive Gear
3. Nuts for Sight Scope Bracket 14. Horizontal Axis Clamp Screw
4. Sight scope 15. Clamp Screw for Tripod Leg
5. Sight Scope Bracket 16. Rubber Tips
6. Sight Scope Eyepiece 17. Declination Flexible Cable Control
7. Main Tube 18. Polar Axis (Not Parts)
8. Focusing Knob 19. Accessory Tray
9. Focusing Tube 20. Accessory Tray Brackets
10. Eyepiece Adapter 21. Tripod Leg
11. Declination Clamp Screw
Figure 2

Česky Svenska Suomi Magyar Español Italiano Nederlands Français Deutsch English
4
22. Main Mirror
23. Polar Axis Auxiliary Screw
24. Polar Axis Clamp Screw
25. Aligning Screw for Sight Scope
26. Clamp Handle
27. Declination Attachment
28. Hour Circle
29. Declination Circle
30. Right Ascension Flexible Cable Control
31. Right Ascension Attachment
32. Latitude Scale
33. Balance Shaft
34. Balance Weight
35. Eyepiece (Not Shown in the Figure)
36. Moon Filter (Not Shown in the Figure)
Assembling:
Take before assembling all parts out of the packaging. Study below figures to see how the telescope
is put together.
Note: a telescope is an optical and mechanical instrument, handle with care.
Figure 3
Base mount
Tripod leg

English Deutsch Français Nederlands Italiano Español Magyar Suomi Svenska Česky
5
Figure 4
Internal hexagonal bolt
Body belt
Equatorial mount
Umbrella screw
Base mount

Česky Svenska Suomi Magyar Español Italiano Nederlands Français Deutsch English
6
Purpose:
A telescope is an optical system designed to magnify from a distant. A reflector telescope
consists of an open tube with a curved mirror at the bottom. The open end of the tube is pointed at
the object in the sky and the entering light rays strike the mirror at bottom. The rays, reflected from
this mirror, strike a second diagonal mirror. As a result of the curvature of the main mirror, the light
rays are bent to meet at a point.
The mirror in a reflector telescope must be painstakingly ground to the proper curvature to achieve
the correct focal point. The purpose of the diagonal mirror, which is located a short distance before
the focal point, is to reflect the light rays towards the side of the tube where an eyepiece magnifies
the image.
The telescope has an equatorial mount. It is extremely versatile because it allows the telescope to
move in all directions. Therefore, it is possible to track a star’s movement across the sky in the same
path the star seems to take.
Focusing the telescope:
Figure 5
1. Leave the telescope in the same position as assembled.
2. Remove the two screws attached to the eyepiece adaptor (10). Put the eyepiece with lowest
value (H20) on the eyepiece adaptor.
3. Aim the telescope during daytime at an object in the distance (e.g. building, etc.)
4. Adjust the focusing knob (8) back and forth until the object is sharp focused.
Eyepiece

English Deutsch Français Nederlands Italiano Español Magyar Suomi Svenska Česky
7
Aligning the sighting scope
1. Look through the sighting scope after focusing the telescope (4). If the sighting scope is not in
focus, turn the eyepiece (6) around on until the view is sharp and clear.
2. If the object you see in the telescope is not in the center of the sighting scope crosshairs, do
the following: tighten and loose the four screws (25, figure 2) of the bracket and move sighting
scope up or down, side to side or diagonally. When the object is in the center of the crosshairs
your sighting scope is adjusted.
3. Repeat this process by replacing the lower power eyepiece with another higher eyepiece.
Once the image is centered under highest magnification, the telescope is also centered in the
sighting scope. It may now be used for rapid location of objects in the sky. On rare occasions,
the sighting scope might have to be readjusted.
Note 1: Whenever locating an object, always use the finder scope first in finder scope
position. Because it has a wide field of view and will speed up the search.
Note 2: Always start with the lowest power eyepiece in the telescope tube and work up to
the required value. Make the necessary focusing adjustments by changing eyepieces.
Eyepieces and magnification
This telescope is supplied with two different eyepieces (H6 mm and H20 mm). The power
of each particular eyepiece is directly related to the focal length of the telescope which
is 1000 mm.
However, generally the power of each eyepiece is related to the focal length of the objective mirror
of the telescope.
The formula is as follows:
Focal length of telescope
---------------------------------- = Magnification
Focal length of eyepiece
As an example, the H6mm eyepiece will show a magnification of:
1000mm
------------ = 167X Magnification
6mm
Note: focal length of the telescope is synthesized by the correcting lens.

Česky Svenska Suomi Magyar Español Italiano Nederlands Français Deutsch English
8
Using the telescope
Before learning the technical details of this telescope, the telescope is ready for observing stars,
planets and the moon. Turn the declination axis clamp screw (11), the right ascension clamp screw
(12) and the polar axis clamp screw (24) to adjust the position of the telescope. Turn the horizontal
axis clamp screw (14) so the telescope can swing in a circle.
The Moon and the Stars
When viewing at night, it’s possible to look at the moon and it’s surface. Aim the Finder scope so
the moon is in the center of the crosshairs. The main telescope is now directly aimed at the moon.
Focus the telescope as previously described.
For optimal use of a telescope and everything about astronomy it’s recommended to purchase
specific books and literature for amateur astronomers.
Specifications
Objective mirror: Concave mirror, hard coated
Lens aperture: 114mm
Focal length: 1000mm (synthesized)
Resolving power: 1”
Light collection power: 265X
Faintest discernible stars: 12M
Magnification: 50X, 167X
Eyepiece Magnification Exit Pupil
Aperture
Brightness Visual Field
Actual Apparent
H20mm 50X 2.28ram 5.2 42’ 35°
H6mm 167X 0.68mm 0.46 12‘ 30°
Warranty:
No guarantee or liability can be accepted for any changes and modifications of the product or
damage caused due to incorrect use of this product.
General:
Designs and specifications are subject to change without notice.
