Koolatron TOTAL Chef TCM07 User manual

H1S291
Please Read These Instructions Carefully Before Use!
User Manual
TCM07
7/2019 - v2
Warranty
This product is warranted to the retail customer for 90 days from date of retail purchase, against
defects in material and workmanship.
WHAT IS COVERED
• Replacement parts and labour.
• Transportation charges to customer for the repaired product.
WHAT IS NOT COVERED
• Damage caused by abuse, accident, misuse, or neglect.
• Transportation of the unit or component from the customer to Koolatron.
IMPLIED WARRANTIES
Any implied warranties, including the implied warranty of merchantability are also limited
to the duration of 90 days from the date of retail purchase.
WARRANTY
Keep the original, dated, sales receipt with this manual.
WARRANTY AND SERVICE PROCEDURE
If you have a problem with your unit, or require replacement parts, please telephone the following
numbers for assistance:
North America 1-800-265-8456
Koolatron has Master Service Centres at these locations:
U.S.A. - 4330 Commerce Dr., Batavia, NY 14020-4102
Canada - 139 Copernicus Blvd., Brantford, ON N3P1N4
A Koolatron Master Service Centre must perform all warranty work.
www.koolatron.com
©2019 Koolatron, Inc. All rights reserved.
All specification are subject to change without notice.
Microwave Oven

2
PRECAUTIONS
3
TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
1. Do not attempt to operate this oven with the door open since open-door operation can result in
harmful exposure to microwave energy. It is important not to defeat or tamper with the safety
interlocks.
2. Do not place any object between the oven front face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is very important that the oven door close properly and
that there is no damage to the
a) Door (including any bents),
b) Hinges and latches (broken or loosened),
c) Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except qualified service personnel.
WARNING! To reduce the risk of burns, electric shock, fire, injury to persons or exposure to exces-
sive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific "TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY" above.
3. This appliance must be grounded. Connect only to properly grounded outlet. See "GROUNDING
INSTRUCTIONS" on page 4.
4. Install or locate this appliance only in accordance with the provided installation instructions.
5. Do not operate the oven when empty.
6. Some products such as whole eggs and sealed containers -for example, closed glass jars- are able
to explode and should not be heated in this oven.
7. Use this appliance only for its intended use as described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory use.
8. As with any appliance, close supervision is necessary when used by children.
9. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible materi-
als are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c) If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the
power cord or shut off power at the fuse or circuit breaker panel.
d) Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or food
in the cavity when not in use.
10. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without
appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the
container is removed from the microwave oven is not always present.
PRECAUTIONS (cont.)
THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER
UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of injury to person:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating it.
c) Do not use straight-sided containers with narrow necks.
d) After heating, allow the container to stand in the microwave oven for a short time before removing
the container.
e) Use extreme care when inserting a spoon or other utensil into the container.
11. Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil in microwave
oven.
12. Do not cover or block any openings on the appliance.
13. Do not store or use this appliance outdoors. Do not use this product near water, for example, near
a kitchen sink, in a wet basement, near a swimming pool, or similar locations.
14. Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly or if
it has been damaged or dropped.
15. Do not immerse cord or plug in water. Keep cord away from heated surface. Do not let cord hang
over edge of table or counter.
16. This appliance should be serviced only by qualified service personnel, contact nearest authorized
service facility for examination, repair, or adjustment.
17. When cleaning surfaces of door and oven that comes together on closing the door, use only mild,
nonabrasive soaps, or detergents applied with a sponge or soft cloth.
18. This equipment has been tested and found to comply with Part 18 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired
operation.
CAUTION Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the product.
19. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

4 5
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the electric current. This appliance is equipped with a
cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is
properly installed and grounded.
WARNING! Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely under-
stood, or if doubt exists as to whether the appliance is properly grounded, and if it is necessary to use
an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot
receptacle that will accept the plug on the appliance. The marked rating of the extension cord shall be
equal to or greater than the electrical rating of the appliance.
ELECTRICAL REQUIREMENTS
The electrical requirements are a 120 V 60 Hz, AC only, 15 amp. It is recommended that a separate
circuit serving only the oven be provided. The oven is equipped with a 3-prong grounding plug. It
must be plugged into a wall outlet properly installed and grounded.
POWER CORD
1. A short power supply cord is provided to reduce the risks resulting from becoming entangled in or
tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in their use.
3. If long cord or extension cord is used：
a) The marked electrical rating of the cord set or extension cord should be at least as great as the
electrical rating of the appliance.
b) The extension cord must be a grounding-type 3-wire cord, and the longer cord should be arranged
so that it will not drape over the counter top or table top where it can be pulled on by children or
tripped over unintentionally.
SPECIFICATIONS
Power Consumption 120V / 60Hz, 1100W
Output 700W
Operation Frequency 2450MHz
Outside Dimensions(H x W x D) 9-9/16 ×17-9/16 × 12-11/16 in.
Oven Capacity 0.7cu.ft.
Net Weight approx. 20.7 lbs
1. Make sure that all the packing materials are removed from the inside of the door.
2. This microwave oven must be placed on a flat.
3. For correct operation, the oven must have sufficient air flow. Allow 8” / 20 cm of space above the
oven, 4” / 10 cm at back and sides. Do not cover or block any openings on the appliance. Do not
remove feet on which oven stands.
4. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
5. Make sure that the power cord is undamaged and does not run under the oven or over any hot or
sharp surface.
6. The socket must be readily accessible so the microwave oven can be easily unplugged in an
emergency.
COOKING UTENSILS GUIDE
This section lists which utensils can be used in this microwave, which have limited use for short
periods, and which should not be used in this microwave.
RECOMMENDED
MICROWAVE BROWNING DISH - Use to brown the exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with your browning dish.
MICROWAVEABLE PLASTIC WRAP - Use to retain steam. Leave a small opening for some steam to
escape and avoid placing it directly on the food.
PAPER TOWELS AND NAPKINS - Use for short-term heating and covering; these absorb excess
moisture and prevent spattering. Do not use recycled paper towels, which may contain metal and
could ignite.
GLASS AND GLASS-CERAMIC BOWLS AND DISHES - Use for heating or cooking.
Paper plates and cups - Use for short-term heating at low temperatures. Do not use recycled paper,
which may contain metal and could ignite.
WAX PAPER - Use as a cover to prevent spattering.
THERMOMETERS - Use only those labeled "Microwave Safe" and follow all directions. Check the food
in several places. Conventional thermometers may be used on microwave food once the food has
been removed from the oven.
LIMITED USE
Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas. Using too much
foil can damage your oven, so be careful. You should keep distance of 1 inch (2.54 cm) between
aluminum foil and cavity.
Ceramic, porcelain, and stoneware— Use these if they are labeled "Microwave Safe". If they are not
labeled, test them to make sure they can be used safely.
Plastic — Use only if labeled "Microwave Safe". Other plastics can melt.
INSTALLATION

6 7
INSTALLATION (cont.)
PARTS & FEATURES
NOT RECOMMENDED
Glass jars and bottles — Regular glass is too thin to be used in a microwave. It can shatter and cause
damage and injury.
Paper bags — These are a fire hazard, except for popcorn bags that are designed for microwave use.
Styrofoam plates and cups — These can melt and leave an unhealthy residue on food.
Plastic storage and food containers — Containers such as margarine tubs can melt in the microwave.
Metal utensils — These can damage your oven. Remove all metal before cooking.
NOTE Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. A dish which becomes very hot should not be used.
OPERATION
• When the oven first plugged in, a beep will sound and the display will show "1:01".
• In the process of cooking setting, broke about 25 seconds the oven will return to standby mode.
• During cooking, if STOP/CANCEL pad is pressed once, the program will be paused, press START pad
to resume, but if STOP/CANCEL pad is pressed twice, the program will be canceled.
• After cooking is done, the screen will display End with sound every two minutes until the STOP/CAN-
CEL pad is pressed or the door is opened.
• In the process of operation, pressing a valid pad, the buzzer will ring once, but if pressing an invalid
pad, the buzzer will ring twice.
• In standby mode, press STOP/CANCEL and START pads at the same time to check the version date
and the model of PCB.
FUNCTION BUTTONS
• DISPLAY
Cooking time, power, indicators and clock time
are displayed.
• AUTO COOK MENUS
There are 6 kinds of auto cook menus. Use to
set auto cook program.
• NUMBER PADS (0-9)
Use to adjust power level, set time or enter food
weight.
• CLOCK
Use to set the clock time.
• TIME COOK
Use to set microwave cooking.
• KITCHEN TIMER
Kitchen timer functions independently, even
while a cooking program is in process
• TIME DEFROST
Use to set defrost program based on time.
• WEIGHT DEFROST
Use to set defrost program by weight.
• POWER LEVEL
Use to set microwave power level.
• STOP/CANCEL
Press to reset the oven before setting a cooking program. Press once to temporarily stop cooking, or
twice to cancel cooking altogether. It is also used for setting child lock.
•START/+30 SEC
Press to start a cooking program. It is also used to increase cooking time during cooking.
1. Door Safety Lock System
2. Oven Window
3. Shaft
4. Roller Ring
5. Door Release Button
6. Control Panel
7. Wave Guide (Please do not remove the mica plate covering the wave guide)
8. Glass Tray

8 9
OPERATION (cont.)
SETTING THE CLOCK
This is a 12 or 24 hour clock, and you can select it by pressing CLOCK pad.
1. In standby mode, press CLOCK pad once or twice to select 12 or 24 hour clock.
2. Use the number pads to enter the correct time.
3. Press CLOCK pad to confirm.
NOTE During cooking, the current time can be seen by pressing CLOCK pad.
EXPRESS COOK
Directly in standby mode, when you touch a number button (1, 2, 3, 4, 5 or 6) once, the correspond-
ing system direct start cooking time starts respectively 1 minute, 2 minutes, 3 minutes, 4 minutes, 5
minutes and 6 minutes. The microwave oven will start to cook at full power level.
SETTING THE +30 SEC FUNCTION
In standby mode, touch START/+30 SEC button repeatedly to enter cooking time, the microwave oven
will auto start cooking at full power level. The longest cooking time you can enter is 99 minutes and
99 seconds.
NOTE: During cooking (microwave cooking and express cook), you can add cooking time by touching
START/+30 SEC button.
SETTING KITCHEN TIMER
1. In standby mode or during cooking, press KITCHEN TIMER pad once.
2. Press the number pads to enter the amount of time. The longest time is 99 minutes 99 seconds.
3. Press START pad to confirm.
NOTE When the countdown ends, the buzzer will beep to remind you. You can check the countdown
time by pressing KITCHEN TIMER pad, but if STOP/CANCEL pad is pressed when the display shows
the time, the function can be canceled.
MICROWAVE COOKING
1. In standby mode, press TIME COOK pad once.
2. Use the number pads to enter cooking time. The longest time is 99 minutes 99 seconds.
3. If you want to set a power level other than 100% power, touch POWER LEVEL pad, and then use
the number pads to enter the power level.
4. Press START pad to confirm.
Use single digit to set a cooking power level:
NOTE During cooking, the current power level can be seen by pressing POWER LEVEL pad.
TIME DEFROST
The defrosting power is adjusted automatically once the cooking time is programmed.
1. In standby mode, press TIME DEFROST pad once.
2. Use the number pads to enter defrosting time. The longest time is 99 minutes 99 seconds.
3. Press START pad to confirm.
NOTE During defrosting program, the system will pause and sound beeps to remind user to turn food
over, and then press START pad to resume.
WEIGHT DEFROST
The defrosting time and power level are automatically set once the weight is programmed.
1. Press WEIGHT DEFROST pad once.
2. Use the number pads to select food weight. The maximum weight is 6 lbs.
3. Press START pad to confirm.
NOTE
• During defrosting program, the system will pause and sound beeps to remind user to turn food over,
and then press START pad to resume.
• Weight must be in pounds and ounces. If label gives weight in pounds only, change the fraction of
a pound to ounces using the following chart.
Converting fractions of a pound to ounces
MULTISTAGE COOKING
Your oven can be programmed up to 3 automatic cooking sequences. It can be composed of time
defrost with one or two microwave cooking program, or composed of two microwave cooking
program.
A. Time defrost with one or two-stage microwave cooking:
1. Open the door and place the food into the oven, close it.
2. Press TIME DEFROST pad once.
3. Enter desired defrosting time by pressing correct number pads.
4. Input the first stage of microwave cooking program.
5. Input the second stage of microwave cooking program.
6. Press START to confirm.
NOTE Step 5 is not necessary if you have one microwave cooking program. Time defrost can only be
set in the first stage.
B. Two-stage microwave cooking:
Some recipes require different stages of cooking at different temperatures.
1. Input the first stage of microwave cooking program.
2. Press TIME DEFROST pad once.
3. Input the second stage of microwave cooking program.
4. Press START to start.
CHILD LOCK
The lock prevents unsupervised operation by children.
• To set the child proof lock: In standby mode, press and hold STOP/CANCEL pad for 3 seconds, then
a beep will sound, the oven will auto enter child lock mode and lock indication appears on the display
for 3 seconds. In the lock state, all pads are invalid.
• To cancel the child proof lock: Press and hold STOP/CANCEL pad for 3 seconds, then a beep will
sound and all pads are valid.
OPERATION (cont.)
Fractions of a pound Ounces
Less than .03 0
.03 to .09 1
.10 to .15 2
.16 to .21 3
.22 to .27 4
.28 to .34 5
.35 to .40 6
.41 to .46 7
.47 to .53 8
Fractions of a pound Ounces
.54 to .59 9
.60 to .65 10
.66 to .71 11
.72 to .78 12
.79 to .84 13
.85 to .90 14
.91 to .97 15
above .97 go to next even
Number pad Cooking power (Display)
1,0 100% (P100)
9 90% (P-90)
8 80% (P-80)
7 70% (P-70)
6 60% (P-60)
5 50% (P-50)
Number pad Cooking power (Display)
4 40% (P-40)
3 30% (P-30)
2 20% (P-20)
1 10% (P-10)
0 0% (P-00)

10 11
AUTO COOK MENUS
The auto cook settings allow you to cook or reheat food automatically without entering power level or
time. For smaller portions, simply press the applicable pad and start. For larger portions, push the pad
twice. Enter the amount of shares and start.
POPCORN
1. Press POPCORN pad once.
popcorn automatically sets the cooking time for a 3.5 oz bag of microwave popcorn.
2. Press START pad to confirm.
NOTE: To change the preset POPCORN time: Press POPCORN pad twice. Press number pads to enter
minutes and seconds, the longest time is 99 minutes 99 seconds. Press START pad. This new
cooking time will be set as the default one until next power on.
POTATO
For small potatoes (4~6 oz/share):
1. Press POTATO once.
2. Enter number of potatoes by pressing number pads from 1 to 4.
3. Press START pad to confirm.
For larger potatoes (8~10 oz/share):
1. Press POTATO twice.
2. Enter number of potatoes by pressing number pads from 1 to 4.
3. Press START pad to confirm.
PIZZA
Reheating a slice of pizza (about 5oz):
1. Press PIZZA pad once.
2. Press START pad to confirm.
Heating a whole ice pizza (about 16oz):
1. Press PIZZA pad twice.
2. Press START pad to confirm.
FROZEN DINNER
For small frozen dinners (7~9 oz/share):
1. Press FROZEN DINNER pad once.
2. For 1 entree or 2 entrees, press the number pad “1” or “2”.
3. Press START pad to confirm.
For larger frozen dinners (10~12 oz/share):
1. Press FROZEN DINNER pad twice.
2. For 1 entree or 2 entrees, press the number pad “1” or “2”.
3. Press START pad to confirm.
BEVERAGE
For cups (5~7 oz/share):
1. Press BEVERAGE pad once.
2. Enter number of cups by pressing number pads from 1 to 4.
3. Press START pad to confirm
OPERATION (cont.)
For larger coffee cups (9~11 oz/share):
1. Press BEVERAGE pad twice.
2. Enter number of mugs by pressing number pads from 1 to 4.
3. Press START pad to confirm.
REHEAT
For reheating medium-sized food (12~18oz):
1. Press REHEAT pad.
2. Press START pad to confirm.
OPERATION (cont.)
1. Turn off the oven and unplug the power cord from the wall when cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using spray or other
harsh cleaners. They may stain, streak or dull the door surface.
3. The outside of the oven should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp
cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the
control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity condition. And it is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the
bottom surface of the oven with mild detergent. The roller ring may be washed in mild, soapy water
or in a dishwasher. When removing the roller ring, be sure to replace it in the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in
a microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
10. If the light bulb burns out, please contact customer service to have it replaced.
11. The oven should be cleaned regularly and any food deposits should be removed. Failure to
maintain the oven in a clean condition could lead to deterioration of surface that could adversely affect
the life of the unit and could possibly result in a hazardous situation.
12. Please do not dispose of this appliance into the domestic rubbish bin; it should be disposed to the
specific disposal center provided by the municipalities.
CLEANING AND MAINTENANCE
