KoolMore SCF-9C User manual

CHEST FREEZER
USER’S MANUAL
Please read this user’s manual thoroughly before using.
Keep this manual handy for further reference.
MODEL: SCF-9C
SCF-16C

1
Dear Consumers:
Thank you very much for purchasing our products. In order to ensure your
safety and achieve the best out of this freezer, pls read this instruction carefully.
Details of Product
1. It uses quality, effective and hermetic compressor with broad range of
starting voltage, suitable ambient temperature: not higher than 38℃,
reasonable matching of the freezer system guarantees its powerful
refrigerant ability and energy saving.
2. A good choice for stoarge of your variety of frozen food product. It is
easy to lift up the lid to get your frozen food and close the lid to seal the
freezer in.
Caution for Using
1. Unpack all packages before using the freezer. Don’t bend it over more than
60° while moving it.
2. The freezer should be installed in the environment of good ventilation, Cool
and dry and without corrosive gas. It should not be installed close to heat
sources or directly under the sunlight. The space more than 10cm between
the wall of the front and the back of the freezer should be allowed. When
installing, the wheels should be padded well so as to make the freezer be
level and stable, or it will cause vibration and too much noise.
3. When initial operation, the freezer should run emptily about one hour before
storing food in it.
4. Before placing food into the freezer, adjust the temperature control to the
lowest point (highest number) and let it run until the temperature of inner
cabinet decreases to 0°Fahrenheit. Put the food in, and after 12 hours
adjust the temperature control to the normal point.
5. The thermostat could adjust the temperature inside the freezer. When you
turn the knob in clockwise. The bigger the figure, the lower the temperature.
Generally, the position of ‘4’ is suitable.’0’ position stand for stopping
operation.’Max’ position will be operating not continually as compressor
won’t stop (no cycle). Turn the temperature control to the “4” or “5” when
temperature inside is stable for ice cream and similar products.
6. Never store flammable, explosive or corrosive products in the freezer, and
keep the freezer away from such materials.
7. If power is cut off, wait at least 5 minutes before turning on again to avoid
damage to the compressor.
8. To save energy, the door should not be frequently opened for a long time.
9. The surface and the inside of the freezer should be dry and clean. Long term
moisture with cause the freezer rust slowly. (There will be some stains on
the surface.)
10.Periodical cleaning is suggested for your reference. Generally, 30-45 days
once is best. When cleaning, it is best to wipe the inside and the surface of
the showcase with the soft cloth with neutral soap or detergent.
Attention: To ensure safety, the power plug must be pulled out before
cleaning. All safety precautions must be followed. Dispose of properly in

2
accordance with Federal or local regulations. Risk of fire or explosion due
to puncture of refrigerant tubing. Follow handling instrucitons carefully.
DANGER: Risk of fire or explosion. Flammable refrigerant R290/R600a
used. To be repaired only by trained service personnel. Do not use
mechanical devices to defrost refrigerator. Do not puncture refrigerant
tubing.
ATTENTION: pour assurer la sécurité, la fiche d'alimentation doit être
retirée avant le nettoyage. Toutes les précautions de sécurité doivent être
respectées. Disposer correctement conformément aux réglementations
fédérales ou locales. Risque d'incendie ou d'explosion dû à la perforation
du tube réfrigérant. Suivre la manutention instrucitons soigneusement.
Danger: risque d'incendie ou d'explosion. Réfrigérant inFlammable
R290/R600a utilisé. Être réparé uniquement par un technicien qualifié.
N'utilisez pas de dispositifs mécaniques pour dégivrer le réfrigérateur. Ne
pas perforer le tube réfrigérant.
Food Storage
Do not fill the freezer full of products. You should leave space between items and
the inner surface of the cabinet, so as to keep good ventilation of cold air and
freeze evenly. Do not put in any bottled or canned beverage with freezing point
above the temperature in the cabinet when it is below zero.
For foods that should be moisture-free or lose water easily, wrap them up with
hermetical food bags or fresh films before putting in the cabinet for the sake of
avoiding smell-mixing and reducing frosting.
Storage of volatile and combustible gases, liquids such as strong alkalies, strong
acids, petrol ,etc. is forbidden.
Never put hot food directly in the freezer. Food should be cold or frozen before
placing it inside.
The cabinet is intended exclusively for the storage and/or display of packaged
foods only.
Maintenance
The freezer should be cleaned regularly. When cleaning, turn off the power, take
out the foods in the cabinet, clean the inside using water or a little neutral
detergent.
Do not use boiling water, acid, chemical diluents, petrol and oil, or dirt- removing
powder.
Dry it after cleaning.
Use light soap water when cleaning the door seal, apply a little of talcum powder
on it after natural drying to extend its service life.
Use soft cloth with water or a little detergent to clean the out surface. Note,
keeping the power supply and lower part of connect wires away from water to
avoid electricity leakage.
Except common breakdowns, those who are not service technician should not take
apart and repair the freezer on their own so as to avoid worsening the trouble.
Unauthorized repair of electrical part such as compressor, temperature controller is
forbidden.

3
Defrosting
Defrost for better freezing efficiency when the frost film in the cabinet is 4-5mm
thick.
When defrosting, turn off the power, take out the frozen foods, open the door for
warming and melting. Use soft cloth to absorb water and clean it up.
Do not use sharp metal tools such as steel brush to clean the frost film when
defrosting so as to avoid evaporator damage.
Trouble Shooting
Breakdown
Case
Removal method
The indicator is not on.
The compressor doses not
start.
The plug isn’t connected to
the
socket really.
Replug it.
no power
Connect the socket with
power.
The indicator is on ,but the
com- pressor doesn’t work
and buzzes only
The power voltage is＜98V.
Put a power-regulater more
than
1000W power together.
The compressor stops a
minute after start, and
restart after a few minutes,
and so repeatedly.
The power voltage is＞
132V.
The compressor works
normally,
but the temperature in the
cabinet
lowers too slowly.
The door is opened too
frequently.
Reduce open times.
The food in the cabinet is
too
much, and placed
improperly.
Place foods properly keep
place
between them for
ventilation of
cold air.
The frost film is too thick.
Take out foods and defrost.
The surface of the
condenser is
too dirty.
Stop and clean the
condenser.
The door seals badly.
Adjust the door seal.
The noise is too loud
The freezer is placed
unstably.
Place it stably.
The fixing of the freezer is
loose.
Tighten the fixing.
there’s contact between
pipes.
Separate them.
The following are not faults:
When the freezer is working or after stopping for a while, the refrigerant in
the pipes is cycling and gives out＂running water＂sounds.
The surface temperature of the compressor may be up 70℃~80℃when it
is working.
The back side of step freezer gives out heat.
In rainy season, the outer surface of the cabinet may have dew, which
makes no defects on normal use. Just dry it with a piece of cloth.
