Koryo KMC 2522IAM User manual

Please read these instructions carefully before installing and operating the oven.
USER'S MANUAL

2
CONTENT
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY.................................3
IMPORTANT SAFETY INSTRUCTIONS.......................................................................................................................4
SPECIFICATIONS* .......................................................................................................................................................5
INSTALLATION .............................................................................................................................................................5
RADIO INTERFERENCE ..............................................................................................................................................5
GROUNDING INSTRUCTIONS ....................................................................................................................................6
MICROWAVE COOKING PRINCIPLES........................................................................................................................6
BEFORE YOU CALL FOR SERVICE............................................................................................................................6
UTENSILS GUIDE.........................................................................................................................................................7
PART NAMES................................................................................................................................................................8
CONTROL PANEL.........................................................................................................................................................9
HOW TO SET THE OVEN CONTROLS......................................................................................................................10
SETTING DIGITAL CLOCK.........................................................................................................................................10
MICROWAVE COOKING ............................................................................................................................................10
GRILL COOKING ........................................................................................................................................................11
COMBINATION COOKING .........................................................................................................................................11
MULTI-STAGE COOKING...........................................................................................................................................11
CONVECTION.............................................................................................................................................................12
MICROWAVE+CONVECTION ....................................................................................................................................12
DEFROST ...................................................................................................................................................................13
QUICK START.............................................................................................................................................................13
AUTO COOK ...............................................................................................................................................................13
STEAM CLEAN ...........................................................................................................................................................15
DEODORIZE ...............................................................................................................................................................15
KEEP WARM...............................................................................................................................................................15
CHILD LOCK...............................................................................................................................................................15
CLEANING AND CARE...............................................................................................................................................16
E-WASTE DISPOSAL .................................................................................................................................................17
WARRANTY ................................................................................................................................................................18

3
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
1. Do not attempt to operate this oven with the door open since open door operation can result
in harmful exposure to microwave energy. It is important not to defeat or tamper with the
safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the
a. Door (bent),
b. Hinges and latches (broken or loosened),
c. Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except company authorised
service personnel.

When using electrical appliance basic safety
precautions should be followed, including the
following:
WARNING: To reduce the risk of burns, electric
shock, re, injury to persons or exposure to
excessive microwave energy:
1. Read all instructions before using the appliance.
2. Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type
of oven is specically designed to heat, cook
or dry food. It is not designed for industrial or
laboratory use.
3. Do not operate the oven when empty.
4. Do not operate this appliance if it has a
damaged cord or plug, if it is not working
properly or if it has been damaged or dropped.
If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualied person in order to
avoid a hazard.
5. WARNING: Only allow children to use the oven
without supervision when adequate instructions
have been given so that the child is able to use
the oven in a safe way and understands the
hazards of improper use.
6. WARNING: When the appliance is operated
in the combination mode, children should only
use the oven under adult supervision due to the
temperatures generated.
7. To reduce the risk of re in the oven cavity:
a. When heating food in plastic or paper
container, keep an eye on the oven due to
the possibility of ignition.
b. Remove wire twist-ties from paper or plastic
bags before placing bag in oven.
c. If smoke is observed, switch off or unplug the
appliance and keep the door closed in order
to stie any ames.
d. Do not use the cavity for storage purposes.
Do not leave paper products, cooking
utensils or food in the cavity when not in use.
8. WARNING: Liquid or other food must not be
heated in sealed containers since they are
liable to explode.
9. Microwave heating of beverage can result in
delayed eruptive boiling, therefore care has to
be taken when handle the container.
IMPORTANT SAFETY INSTRUCTIONS
10. Do not fry food in the oven. Hot oil can damage
oven parts and utensils and even result in skin
burns.
11. Eggs in their shell and whole hard-boiled eggs
should not be heated in microwave ovens since
they may explode even after microwave heating
has ended.
12. Pierce foods with heavy skins such as potatoes,
whole squashes, apples and chestnuts before
cooking.
13. The contents of feeding bottles and baby
jars should be stirred or shaken and the
temperature should be checked before serving
in order to avoid burns.
14. Cooking utensils may become hot because
of heat transferred from the heated food.
Potholders may be needed to handle the
utensil.
15. Utensils should be checked to ensure that they
are suitable for use in microwave oven.
16. WARNING: It is hazardous for anyone other
than a trained person to carry out any service
or repair operation which involves the removal
of any cover which gives protection against
exposure to microwave energy.
17. This product is a Group 2 Class B ISM
equipment. The denition of Group 2 which
contains all ISM (Industrial, Scientic and
Medical) equipment in which radio-frequency
energy is intentionally generated and/or
used in the form of electromagnetic radiation
for the treatment of material, and spark
erosion equipment. For Class B equipment
is equipment suitable for use in domestic
establishments and in establishments directly
connected to a low voltage power supply
network which supplies buildings used for
domestic purpose.
18. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
19. Children should be supervised to ensure that
they do not play with the appliance.
4

1. Make sure that all the packing materials
are removed from the inside of the door.
2. WARNING: Check the oven for any
damage, such as misaligned or bent door,
damaged door seals and sealing surface,
broken or loose door hinges and latches
and dents inside the cavity or on the door.
If there is any damage, do not operate the
oven and contact company authorised
service personnel.
3. This microwave oven must be placed on
a at, stable surface to hold its weight and
the heaviest food likely to be cooked in the
oven.
4. Do not place the oven where heat,
moisture, or high humidity are generated,
or near combustible materials.
Operation of the microwave oven can cause
interference to your radio, TV, or similar
equipment.
When there is interference, it may be
reduced or eliminated by taking the following
measures:
1. Clean door and sealing surface of the
oven.
SPECIFICATIONS
INSTALLATION
RADIO INTERFERENCE
5. For correct operation, the oven must have
sufcient airow. Allow 20cm of space
above the oven, 10cm at back and 5cm
at both sides. Do not cover or block any
openings on the appliance. Do not remove
feet.
6. Do not operate the oven without glass
tray, roller support, and shaft in their
proper positions.
7. Make sure that the power supply cord is
undamaged and does not run under the
oven or over any hot or sharp surface.
8. The socket must be readily accessible
so that it can be easily unplugged in an
emergency.
9. Do not use the oven outdoors.
2. Reorient the receiving antenna of radio or
television.
3. Relocate the microwave oven with respect
to the receiver.
4. Move the microwave oven away from the
receiver.
5. Plug the microwave oven into a different
outlet so that microwave oven and
receiver are on different branch circuits.
Power Consumption 230V~50Hz, 1400W (Microwave),
1950W (Convection), 1000W (Grill)
Rated Microwave Power Output 900W
Operation Frequency 2450MHz
Outside Dimensions 281mm(H)×483mm(W)×415mm(D)
Oven Cavity Dimensions 220mm(H)×340mm(W)×344mm(D)
Oven Capacity 25Litres
Cooking Uniformity Turntable System
Net Weight Approx.16kg
5

This appliance must be grounded. This oven
is equipped with a cord having a grounding
wire with a grounding plug. It must be plugged
into a wall receptacle that is properly installed
and grounded. In the event of an electrical
short circuit, grounding reduces risk of electric
shock by providing an escape wire for the
electric current. It is recommended that a
separate circuit serving only the oven be
provided. Using a high voltage is dangerous
and may result in a re or other accident
causing oven damage.
WARNING Improper use of the grounding
plug can result in a risk of electric shock.
1. Arrange food carefully. Place thickest areas
towards outside of dish.
2. Watch cooking time. Cook for the shortest
amount of time indicated and add more as
needed. Food severely overcooked can
smoke or ignite.
3. Cover foods while cooking. Covers prevent
spattering and help foods to cook evenly.
If the oven fails to operate:
1. Check to ensure that the oven is plugged in
securely. If it is not, remove the plug from
the outlet, wait 10 seconds, and plug it in
again securely.
2. Check for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be
operating properly, test the outlet with
another appliance.
3. Check to ensure that the control panel is
programmed correctly and the timer is set.
GROUNDING INSTRUCTIONS
MICROWAVE COOKING PRINCIPLES
BEFORE YOU CALL FOR SERVICE
Note
1. If you have any questions about the
grounding or electrical instructions, consult
a qualied electrician or service person.
2. Neither the manufacturer nor the dealer
can accept any liability for damage to
the oven or personal injury resulting from
failure to observe the electrical connection
procedures.
The wires in this cable main are colored in
accordance with the following code:
Green and Yellow = EARTH
Blue = NEUTRAL
Brown = LIVE
4. Turn foods over once during microwaving
to speed cooking of such foods as chicken
and hamburgers. Large items like roasts
must be turned over at least once.
5. Rearrange foods such as meatballs
halfway through cooking both from top to
bottom and from the center of the dish to
the outside.
4. Check to ensure that the door is securely
closed engaging the door safety lock
system. Otherwise, the microwave energy
will not ow into the oven.
IF NONE OF THE ABOVE RECTIFIES
THE SITUATION, THEN CONTACT A
COMPANY AUTHORISED TECHNICIAN.
DO NOT TRY TO ADJUST OR REPAIR
THE OVEN YOURSELF.
6

1. The ideal material for a microwave utensil
is transparent to microwave, it allows
energy to pass through the container and
heat the food.
2. Microwave can not penetrate metal, so
metal utensils or dishes with metallic trim
should not be used.
3. Do not use recycled paper products when
microwave cooking, as they may contain
small metal fragments which may cause
sparks and/or res.
* Combination: applicable for both “microwave + grill”, and “microwave + convection” cooking.
UTENSILS GUIDE
4. Round /oval dishes rather than square/
oblong ones are recommend, as food in
corners tends to overcook.
5. Narrow strips of aluminum foil may be
used to prevent overcooking of exposed
areas. But be careful don’t use too much
and keep a distance of 1 inch (2.54cm)
between foil and cavity.
The list below is a general guide to help you
select the correct utensils.
Cookware Microwave Grill Convection Combination*
Heat–Resistant Glass Yes Yes Yes Yes
Non Heat–Resistant Glass No No No No
Heat–Resistant Ceramics Yes Yes Yes Yes
Microwave–Safe Plastic Dish Yes No No No
Kitchen Paper Yes No No No
Metal Tray No Yes Yes No
Metal Rack No Yes Yes No
Aluminum Foil & Foil Container No Yes Yes No
7

PART NAMES
1. Door Safety Lock System
2. Oven Window
3. Shaft
4. Roller Ring
5. Control Panel
6. Wave Guide
(Please do not remove the mica plate covering the wave guide)
7. Glass Tray
8. Grill Heater
9. Baking Plate
8

CONTROL PANEL
MENU ACTION SCREEN
• Cooking time, power, action indicators, and
clock time are displayed.
POWER LEVEL
• Touch this button a number of times to set
microwave cooking power level.
GRILL/ MICRO.+GRILL
• Use to set a grill cooking program.
• Use to set a microwave and grill
combination cooking program.
CONVECTION
• Used to set a convection cooking program.
• Deodorize
MICRO.+CONVECTION
• Used to set a microwave and convection
combination cooking program.
CLOCK / WEIGHT
• Press a number of times to specify weight or
number of serving.
• Press and hold to set the clock.
KEEP WARM
• Press to set keep warm function.
STOP/CANCEL
• Press to cancel setting or reset the oven
before Stop setting a cooking program.
• Press once to temporarily stop cooking, or
twice to cancel cooking altogether.
• It is also used for setting child lock.
START/QUICK START (THE DIAL)
• Touch to start a cooking program.
• Simply touch it a number of times to
set cooking time and the oven will cook
immediately at full power level.
MENU/TIME
• Turn the dial to input cooking time,
• Select the kind of food you want to cook.
9

SETTING DIGITAL CLOCK
It is a 12-hour or 24-hour clock. With the oven ready for input, touch the CLOCK/ WEIGHT
button once to set the digital clock.
FOR EXAMPLE: Suppose you want to set the oven clock time to 8:30.
1. In waiting mode, press CLOCK / WEIGHT button to choose the cycle.
2. Turn MENU/TIME to indicate the hour digit 8.
3. Press CLOCK / WEIGHT button.
4. Turn MENU/TIME dial to indicate the minute digits until the screen shows 8: 30.
5. Press CLOCK / WEIGHT to conrm the setting.
Note: During cooking, press CLOCK / WEIGHT button to check the clock time.
MICROWAVE COOKING
To cook with microwave, time and power level should be set. The longest cooking time to be
set is 95 minutes
Suppose you want to cook for 5 minutes at 60% of microwave power.
1. In waiting mode, place food into oven and close it.
2. Touch POWER LEVEL button 5 times.
3. Use the MENU/TIME to set cooking time (5 minute).
4. Touch START/QUICK START button.
Note: during cooking, press POWER LEVEL to show power level.
HOW TO SET THE OVEN CONTROLS
Each time a button is touched, a beep will sound to acknowledge the touch.
During cooking program, press STOP/CANCEL to pause the program, then press START/
QUICK START to resume. Press STOP/CANCEL twice to cancel the program.
End will display with beeps to remind the program is over, and it will sound every two minutes
until you press any pad or open the door.
Press POWER LEVEL button to select cooking power
Press Power Description
Once 100% High
Twice 90%
3 times 80%
4 times 70% Medium High
5 times 60%
6 times 50% Medium
7 times 40%
8 times 30% Med. Low
9 times 20%
10 times 10% Low
11 times 00%
10

GRILL COOKING
The longest cooking time is 95 minutes. The grill cooking is particularly useful for thin slices
of meat, steaks, chops, kebabs, sausages of piece of chicken. It is also suitable for hot
sandwiches and au gratin dishes.
For example, suppose you want to grill for 12 minutes.
1. In waiting mode, place food into oven and close it.
2. Press GRILL/MICRO.+GRILL button once.
3. Turn the MENU/TIME to 12:00.
4. Press START/QUICK START button.
COMBINATION COOKING
Combination1:
The longest cooking time is 95 minutes. Use for sh or au gratin.
FOR EXAMPLE: Suppose you want to set combination 1 cooking for 25 minutes.
1. In waiting mode, place food into oven and close it.
2. Press GRILL/MICRO.+GRILL button twice.
3. Turn Menu/Time to 25:00.
4. Press START/QUICK START button.
Combination2:
The longest cooking time is 95 minutes.
Use for puddings omelettes, baked potatoes and poultry.
FOR EXAMPLE: Suppose you want to set combination 2 cooking for 12 minutes.
1. In waiting mode, place food into oven and close it.
2. Press GRILL/MICRO.+GRILL button 3 times.
3. Turn MENU/TIME to 12:00.
4. Press START/QUICK START button.
MULTI-STAGE COOKING
Your oven can be programmed for up to 3 automatic cooking sequences.
Suppose you want to set the following cooking program.
Microwave cooking
↓
Convection cooking (without preheat function)
1. In waiting mode, place food into oven and close it.
2. Press POWER LEVEL button to set power level.
3. Rotate the MENU/TIME dial to program cooking time.
4. Press CONVECTION button to set convection temperature.
5. Rotate the MENU/TIME dial to program cooking time.
6. Press START/QUICK START button.
Note: The digital tube will display 1S, 2S or 3S according to different stage setting. Quick start,
auto cook, steam clean, deodorize, keep warm, preheat and cook with convection, defrost and
auto menu cannot be set in multi-stage cooking program.
11

CONVECTION
During convection cooking, hot air is circulated throughout the oven cavity to brown and
make crisp foods quickly and evenly. This oven can be programmed for ten different cooking
temperatures.
To Cook with Convection
Press Convection button to set convection temperature. (200°C --- 110°C)
Suppose you want to cook at 170°C for 40 minutes.
1. In waiting mode, place food into oven and close it.
2. Press CONVECTION button to select cooking temperature.
3. Rotate the MENU/TIME dial until the correct cooking time is displayed.
4. Press START/QUICK START button.
NOTE:
1. The maximum convection cooking time is 95 minutes.
2. You can check the convection temperature while cooking is in progress by pressing the
CONVECTION button.
To Preheat and Cook with Convection
Your oven can be programmed to combine preheating and convection cooking operations.
Suppose you want to preheat to 150°C and then cook 30 minutes.
1. In waiting mode, press CONVECTION button to select cooking temperature.
2. Press START/QUICK START. When the oven reaches the programmed temperature, one
beep will sound every 5 seconds.
3. Open the door and place container of food at the center of the turntable.
4. Rotate the MENU/TIME dial to program cooking time (30 minutes).
5. Press START/QUICK START button.
Note: The longest preheat time is 30 minutes. When the temperature reaches the preheat
temperature, the countdown stop with sound DE- and keep the state for 30 minutes. If don’t
open the oven door within the 30 minutes, the system will stop automatically with END in
display.
MICROWAVE+CONVECTION
This oven has four pre-programmed settings that make it easy to cook with both convection
heat and microwave automatically.
Press Micro+Convection button to select convection temperature (110°C~200°C).
Suppose you want to bake a cake for 24 minutes on 140°C.
1. In waiting mode, place food into oven and close it.
2. Press MICRO. + CONVECTION button to select cooking temperature.
3. Rotate the MENU/TIME dial to program cooking time.
4. Press START/QUICK START button to start.
Note: The maximum cooking time is 95 minutes. You can check the convection temperature
while cooking is in progress by pressing the MICRO. +CONVECTION button.
12

Code Display Food (wt/qty)
AC1 A1 Gajar Ka Halwa (g)
AC2 A 2 Nariyal Bur (g)
AC3 A 3 Desert- Kheer (g)
AC4 A 4 Desert Choco pudding (g)
AC5 A5 Coconut Kheer (g)
AC6 A6 Suji Halwa (g)
AC7 b 1 Makai Ka Soup(g)
AC8 b 2 Tomato Soup (share)
AC9 b 3 Vegetable Soup(share)
AC10 b 4 Aam Panna (share)
AC11 SN1 Tikki Aloo (g)
AC12 SN2 French Fries (g)
AC13 SN3 Khandvi (g)
WEIGHT & DEFROST
FOR EXAMPLE: Suppose you want to defrost shrimp.
1. In waiting mode, place the shrimp to be defrosted into the oven.
2. Rotate MENU/TIME anti-clockwise to select cooking code 8 for defrost.
3. Press CLOCK / WEIGHT to enter food weight (100g~1800g).
4. Rotate the MENU/TIME dial to program defrosting time.
5. Press START/ QUICK START button.
Note: The maximum defrosting time you can enter is 95 minutes. During defrosting program,
the system will pause and sound beeps to remind user to turn food over, and then press
START/ QUICK START to resume the defrosting.
QUICK START
This feature allows you to start the oven quickly with full power level.
In waiting mode, press the START/QUICK START button a number of times to set the cooking
time (maximum 10 min.), the oven starts work at full power level immediately. During cooking
program, you can press START/QUICK START to add cooking time.
AUTO COOK
For food or the following cooking mode, it is not necessary to program the duration and the
cooking power. It is sufcient to indicate the type of food that you wish to cook as well as the
weight of this food.
You may need to turn food over at the middle of cooking time to obtain uniform cooking.
For example, to cook 3 units of potato.
1. In standby mode, turn MENU/TIME anti-clockwise once and then continue turn the dial to
select cooking code of potato.
2. Press CLOCK / WEIGHT to indicate potato’s numbers you want to cook.
3. Press START/QUICK START button.
Auto Cook Menu
Note :
As you press CLOCK / WEIGHT
button once or repeatedly, number
of servings or weight parameters
will appear on screen, select the
one equal to the weight of food
you have placed in the oven.
The result of auto cooking
depends on factors such as
voltage uctuation, the shape
and size of food, your personal
preference as to the doneness of
certain foods and even how well
you happen to place food in the
oven. If you nd the result at any
rate not quite satisfactory, please
adjust the cooking time a little bit
accordingly.
13

Code Display Food (wt/qty)
AC14 SN4 Dhokla (g)
AC15 SN5 Idlis (4 nos / 8 nos.)
AC16 SN6 Sprouts (g)
AC17 SN7 Spicy mutton curry (g)
AC18 SN8 Fish-steamed (g)
AC19 C1 Noodles (g)
AC20 C2 Pasta (g)
AC21 C3 Fish-Steamed (g)
AC22 C4 Macaroni-Baked (g)
AC23 C5 Baked fruit salad (g)
AC24 C6 Fruit Jam (g)
AC25 C7 Cheese Balls(g)
AC26 C8 Nan Khatai(g)
AC27 CA Desert Trufe Cake(g)
AC28 E1 Pav Bhajji(g)
AC29 E2 Chinese Chicken(g)
AC30 E3 Dal ke Kabab(g)
AC31 E4 Grilled Veg(g)
AC32 E5 Baked fruit salad(g)
AC33 E6 Poha(g)
AC34 E7 Pizza(g)
AC35 G1 Garlic Chicken(g)
AC36 G2 Tasty Chicken(g)
AC37 G3 Tandoori Chicken Masala (g)
AC38 G4 Paneer Tikka-Tandoor (g)
AC39 G5 Grill Sandwich (share)
AC40 G6 Tandoori Fish (g)
AC41 G7 Aaloo Tandoor Se (g)
AC42 G8 Grilled Chicken (g)
AC43 L1 Masala Aloo (g)
AC44 L2 Kadi (g)
AC45 L3 Masala Bhindi (g)
AC46 L4 Prawn Curry Masala (g)
AC47 L5 Spicy Mutton curry (g)
AC48 L6 Pyaj Chawal (g)
AC49 L7 Spicy chicken Masala (g)
AC50 L8 Mutton Biryani (g)
14

STEAM CLEAN
In waiting mode, press DEODORIZE/STEAM CLEAN once. The default time is 5 minutes, then
press START/QUICK START to start the setting. The system will work by 100% power.
DEODORIZE
In waiting mode, press DEODORIZE/STEAM CLEAN once. The default time is 5 minutes, then
press START/QUICK START to start the setting. The system will work by 100% power in rst
minute and 0% power in last 4 minutes.
KEEP WARM
In waiting mode, press KEEP WARM once. You can turn the MENU/TIME dial to set the keep
warm time. The maximum is 95 minutes. The system will work by 50% power.
CHILD LOCK
Use to prevent unsupervised operation of the oven by little children. The CHILD LOCK indicator
will show up on display screen, and the oven cannot be operated while the CHILD LOCK is set.
To set the CHILD LOCK: Press and hold the STOP/CANCEL button for 3 seconds, a beep
sounds and LOCK indicator lights.
To cancel the CHILD LOCK: Press and hold the STOP/CANCEL button for 3 seconds until lock
indicator on display goes off.
AUTOMATIC PROTECTION MECHANISM
Digital tube has been shows “E -1” and had been “DE-DE” alarm when the system into the
super high temperature protection status. The system into normal standby mode when faults
remove and press Stop/Cancel button.
Digital tube has been shows “E -2” and had been “DE-DE” alarm when the system enters into
the super low temperature protection status. The system enters into normal standby mode
when faults remove and press STOP/CANCEL button.
Error may also occur to the system sensor, which will make the oven enter into protection
mode with the screen displaying E03, and beeps can be heard. As soon as this malfunction
disappears by pressing Stop/Cancel, the oven will back to normal.
COOLING FEATURE——The controlling system of the microwave oven has the feature of
cooling. As for any cooking mode which cooking time above 2 minutes, after nishing cooking,
the oven fan will work about 3 minutes automatically to cool the oven for prolonging the life of
the oven.
15

CLEANING AND CARE
1. Turn off the oven and remove the power plug from the wall socket before cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven
walls, wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty. Avoid
the use of spray and other harsh cleaners as they may stain, streak or dull the door surface.
3. The outside surfaces should be cleaned with a damp cloth. To prevent damage to the
operating parts inside the oven, water should not be allowed to seep into the ventilation
openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with
a damp cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning
the control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth.
This may occur when the microwave oven is operated under high humidity condition. And it
is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm
sudsy water or in a dishwasher.
8. The roller ring and oven oor should be cleaned regularly to avoid excessive noise. Simply
wipe the bottom surface of the oven with mild detergent. The roller ring may be washed in
mild sudsy water or dishwasher. When removing the roller ring from cavity oor for cleaning,
be sure to replace in the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one
lemon in a deep microwaveable bowl, microwave for 5 minutes. Wipe thoroughly and dry
with a soft cloth.
10. When it becomes necessary to replace the oven light, please consult a dealer to have it
replaced.
11. The oven should be cleaned regularly and any food deposits removed. Failure to maintain
the oven in a clean condition could lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a hazardous situation.
12. Please do not dispose this appliance into the domestic rubbish bin; it should be disposed to
the particular disposal center provided by the municipalities.
13. When the microwave oven with grill function is rst used, it may produce slight smoke and
smell. This is a normal phenomenon because the oven is made of a steel plate coated with
lubricating oil, and the new oven will produce fumes and odor generated by burning the
lubricating oil. This phenomenon will disappear after a period of using.
16

E-WASTE DISPOSAL
This symbol on the product or on the container indicates that this product cannot be
eliminated with the general waste. The user is responsible for eliminating this kind of
waste by throwing them away at a “recycling point” specically for electrical and electronic
waste. Selective collection and electrical equipment recycling contribute to preserve
natural resources and warrant waste recycling to protect environment and health.
In order to receive further information about electrical and electronic waste collecting and
recycling, contact your Local Council, the service of household waste or the establishment where
the product was acquired.
17

WARRANTY
18
This product comes with a warranty of 12 months from the date of purchase as specied on the
warranty card. This is against all defective material or workmanship. In the event of a defect,
Future Retail Limited or Koryo Authorized Service Centre undertakes to repair the set, free of charge,
during the warranty period.
In the event of a defect developing in the product, contact KORYO Customer Care or Koryo
Authorized Service Centre and provide information about the defect, the model number and serial
number of the product.
THIS WARRANTY IS VOID IF
1. The completely lled warranty card is not presented to the authorised personnel at the time of
servicing of the product.
2. The product is not operated according to the instructions given in the user manual.
3. Defects are caused by improper or reckless use.
4. Modications or alterations have been made to the product or if the product has been
tampered with, in any manner whatsoever.
5. Repairs to the product are carried out by anyone other than an authorised company representative.
6. For defects other than faulty parts or workmanship such as damage due to lightning, abnormal
voltage, spillages, dust, accidental damage, etc.
7. The serial number is deleted or altered.
8. Used for any non–domestic purpose.
OTHER TERMS AND CONDITIONS
1. Repairs or replacement will be carried out either by a Future Retail Limited authorised customer
care centre or by a representative.
2. All expenses incurred in collecting the unit(s) or part(s) thereof from the Customer Service Centre,
as well as any other expenses and incidentals will be borne by the customer.
3. Whilst the company will make every effort to carry out repairs at the earliest, it is made expressly
clear that the company is under no obligation to do so in a specied period of time.
4. The company or its authorised customer centre reserves the right to retain any part(s) or
component(s) replaced at its discretion, in the event of a defect being noticed in the equipment
during the warranty

19
MODEL NO : SERIAL NO :
CUSTOMER NAME :
ADDRESS :
PHONE NO : RESIDENCE : OFFICE :
INVOICE/CASH BILL NO :
DATE OF PURCHASE :
CUSTOMER SIGNATURE :
WARRANTY CARD
THIS CARD IS VALID ONLY IF IT IS FILLED IN COMPLETELY, SIGNED AND STAMPED BY THE DEALER ON DATE OF
PURCHASE
DEALER’S STAMP
WARRANTY CARD
* For service request kindly contact Customer Care Centre at : 1800-425-7722, 080-26577722
* Please mail in queries to [email protected]

Imported by:
Future Retail Limited
Tower C, 9th Floor, 247 Park, L.B.S. Marg, Vikhroli (West),
Mumbai - 400 083, Maharashtra, India.
Also Available
Convection MW Ovens Slow Juicer Split Air Conditioner
Grill MW Ovens Juicer Mixer Grinder Window Air Conditioner
Oven Toaster Grill Mixer Grinder Storage Water Heater
Pop up Toasters Juice Extractor Instant Water Heater
Sandwich Maker Food Steamer Immersion Heater
Induction cooker Chopper Room Heaters
Electric cooker Steam Iron Vaccum Cleaner
Electric Kettle Dry Iron Washing Machine
Coffee/Tea Makers Ceiling Fans Emergency Light
Hand Blender Hair Dryer Stabilizer
