KTI KE-ISA User manual

KE-ISA
ISA PnP Ethernet Card
NE2000 Compatible
Full Duplex
Plug and Play
User’s Guide

FCC Warning
This equipment has been tested and found
to comply with the regulations for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with this user’s
guide, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference, in which case
the user will be required to correct the
interference at his own expense.
CE Mark Warning
This is a Class B product. In a domestic
environment, this product may cause radio
interference, in which case the user may be
required to take adequate measures.
P/N: 6012-1050301

iii
Table of Contents
ISA PNP ETHERNET CARD............................1
INTRODUCTION..................................................1
ISA PNP ETHERNET CARD ..............................1
PRODUCT FEATURES .........................................2
PACKING LIST.....................................................3
INSTALLATION....................................................4
HARDWARE INSTALLATION..............................4
CONFIGURATION AND DIAGNOSTICS .............4
Running Plug and Play mode......................4
Running Jumperless (NE2000) mode ........5
Running Diagnostics.....................................5
DRIVER INSTALLATION.....................................5
BOOT ROM INSTALLATION ............................6
PRODUCT SPECIFICATIONS.........................7

1
Introduction
Congratulations on your purchase of a PnP
Ethernet adapter. This adapter was designed
and manufactured to give you years of
trouble-free and reliable service.
ISA PnP Ethernet Card
This ISA PnP Ethernet adapter is high
performance NE2000 compatible Ethernet
adapter with Plug-and-Play and full-duplex
function
The Plug-and-Play function can relieve the
users from pains of taking care the adapter’s
resource configurations such as IRQ, I/O,
and memory address, etc.
The full-duplex function enables
simultaneously transmission and reception
on Twisted-Pair (10BASE-T) link to full-
duplex Ethernet switching hub. This feature
not only increases the channel bandwidth
from 10 to 200Mbps but also avoids the
performance degrading problem due to the
channel contention characteristics of the
10BASE-T transceiver can automatically
correct the polarity error on its receiving pair.
The Ethernet adapter includes complete
NE2000 compatible drivers that are
compatible with a wide range of Network
operating systems. The optional BOOT ROM
device allows the diskless workstation to be
connected to the network.

2
Product Features
lCompliant to IEEE 802.3 10BASE-2 and
10BASE-T standards.
lSupports Microsoft’s Plug and Play
configuration for jumperless mode.
lSupports Full-Duplex Ethernet function to
double channel bandwidth.
lAutomatic port selection between
10BASE-2 interface(BNC) and 10BASE-T
interface(RJ-45)
lOn-board socket for remote Boot ROM.
lOn-board switch socket Plug and Play
(PnP) or Jumperless (NE2000) mode.
lLED Indicators
One LED on the bracket provides LINK
indicators.
State Description
On Normal data packet are received
or Link integrity pulse is detected
Off * When no twisted-pair connected
* No power source into hub
* Twisted-pair is faulty
* Non-10BASE-T device
connected at the other end of the
twisted pair
* A twisted-pair wire that exceeds
recommended length

3
Packing List
The adapter package should contain the
following items:
lOne 16-bit PnP Ethernet adapter
lThis User’s guide
lOne 3.5”driver diskette
lOne T-connector (for BNC port only)
If any of these items are missing contact your
reseller.

4
Installation
Hardware Installation
1. Turn OFF the computer, unplug the
power cord and open the computer
case.
2. Pick a free ISA expansion slot and
remove the expansion slot cover. Insert
the adapter into the slot until it is fully
seated. Secure the adapter.
3. Replace the computer cover and
connect the network adapter.
Reconnect the computer’s power cord
and plug it into the power outlet.
Configuration and Diagnostics
Before you configure this adapter, make sure
you finished hardware installation.
Running Plug and Play mode
It does not require the configuration
operation to install the Ethernet adapter in a
computer that is compatible with Plug and
Play specification or is running Microsoft
Windows 95/98 system.
The adapter default is NE2000 mode. For
Plug and Play environment, please switch to
PnP mode or execute RSET8019.EXE
choose the operating mode is PnP mode.
Attach the cable and connector, it will
automatic detect the medium type to use.

5
Running Jumperless (NE2000) mode
Please switch to NE2000 mode and execute
RSET8019.EXE. A screen will guide you to
configure the adapter to fit your computer
system’s environment.
Running Diagnostics
You can select “Run Diagnostics”in
RSET8019.EXE menu to do the diagnostic
to check your Ethernet adapter. The
diagnostic will check the adapter. Then
report the results. It can help you to isolate
and problem to a specific adapter and to
figure out whether adapter or cable causes
the problem.
If the diagnostic succeeds, “PASS COUNT”
or “OK”message is displayed at the bottom
of the screen.
If the diagnostic fails, afterward, an error
message is displayed at the bottom of
screen. To press ESC to exit from the
problem and power OFF, check hardware
installation make the necessary changes,
and then try again.
If the diagnostic test still fails, contact your
reseller for assistance.
Driver Installation
Before you connect adapter to the network,
you have to install the network driver first.
The adapter can work with all network

6
drivers for Novell NE2000 adapter. You can
also use the drivers supplied by the driver
diskette that is compatible with your
Networking Operating System is under a
separate directory. A HELP8019.EXE file
under root directory lists the information and
detailed installation procedure of all the
available driver.
Boot ROM Installation
The optional Boot ROM device allows you to
connect a diskless workstation to the
network. Perform the following steps to
install your Boot ROM device:
1. Insert the Boot ROM into the socket on
the adapter.
2. Execute the RSET8019.EXE file to
enable the Boot ROM function by
selecting the appropriate Boot ROM
address from the setup menu.
3. Refer to the installation procedure
provided by Networking Operating
System, Here lists the reference
subjects under two commonly used
Networking Operating Systems.
Microsoft LAN Manager: Starting remote
booting service
Novell Netware: DOSGEN

7
Product Specifications
IEEE 802.3 Standard
Wiring connector
Bus Interface
I/O address
IRQ Line
Boot ROM address
Operating Temperature
Humidity
Emissions
10BASE-2, 10BASE-T
BNC and RJ-45
16-bit ISA bus
200H, 220H, 240H
260H, 280H, 2A0H,
2C0H,2E0H, 300H,
320H, 340H, 360H,
380H, 3A0H, 3C0H,
3E0H
2(9), 3, 4, 5, 10, 11,
12, 15
C0000H, C4000H,
C8000H, CC000H,
D0000H, D4000H,
D8000H, DC000H
0 °C –40 °C
(32 °F –104 °F)
10% to 90%
non-condensing
FCC Class A
CE Mark
