KUHN MAXIMA 2 User manual

KN188BGB B
OPERATOR'S MANUAL
Precision Seed Drills
MAXIMA 2
Foldable telescopic frame
KN188BGB B
- English - 09-2008

Dear Owner
Precision Seed Drills
MAXIMA 2
1
$DEAR OWNER
In buying a Kuhn machine you have chosen wisely. Into it have gone years of thought, research and
improvement. You will find, as have thousands of owners all over the world, that you have the best that
engineering skill and actual field testing can produce. You have purchased a dependable machine, but only
through proper care and operation can you expect to receive the performance and long service built into it.
This manual contains all the necessary information for you to receive full efficiency from your machine. The
performance you get from this machine is largely dependent on how well you read and understand this manual
and apply this knowledge. Please DO NOT ASSUME YOU KNOW HOW TO OPERATE AND MAINTAIN YOUR
MACHINE before reading this manual carefully. KEEP THIS MANUAL AVAILABLE FOR REFERENCE. Pass
it on to the next owner if you re-sell the machine.
Your KUHN dealer can offer a complete line of genuine KUHN service parts. These parts are manufactured and
carefully inspected in the same factory that builds the machine to assure high quality and accurate fitting of any
necessary replacements.
About improvements
We are continually striving to improve our products. It therefore reserves the right to make improvements or
changes when it becomes practical to do so, without incurring any obligations to make changes or additions to
the equipment sold previously.
Designated use of the machine
The MAXIMA 2 precision seed drill must only be used for work for which it has been designed:
- Precision drilling.
- Mineral fertilizer placement (depending upon equipment).
- Application of microgranules in combination with drilling (depending upon equipment).
Document illustrations
The illustrations in this manual may be based on one type of machine only. However, all instructions apply to all
machines covered in this manual.

Precision Seed Drills
2
MAXIMA 2
Contents
$CONTENTS
Dear Owner.....................................................................................................................1
Contents .........................................................................................................................2
Identification of the machine ........................................................................................5
Front view (Basic machine) ............................................................................................................ 5
Rear view (Basic machine).............................................................................................................. 5
Model identification plate................................................................................................................ 6
Optional equipment......................................................................................................................... 7
Safety............................................................................................................................12
Description of symbols used in this document.......................................................................... 12
Safety instructions......................................................................................................................... 13
Location and description of safety decals on the machine....................................................... 23
Road safety equipment and recommendations.......................................................................... 26
Machine specifications................................................................................................27
Description and glossary.............................................................................................................. 27
General technical specifications.................................................................................................. 28
Technical specifications per model ............................................................................................. 29
Sound levels................................................................................................................................... 31
Putting into service......................................................................................................32
Description of control elements................................................................................................... 32
Control box description ................................................................................................................ 32
Coupling and uncoupling.............................................................................................................. 36
Instructions for transport............................................................................................51
Putting the machine into transport position............................................................................... 51
Conformity with the road regulations.......................................................................................... 53

Contents
Precision Seed Drills
MAXIMA 2
3
Instructions for work....................................................................................................54
Putting the machine into work position ...................................................................................... 54
Adjustments in working position.................................................................................................56
Machine use................................................................................................................................... 85
Optional equipment......................................................................................................94
Clod clearer.................................................................................................................................... 98
Spring assisted clod clearer......................................................................................................... 99
Star shaped trash remover ......................................................................................................... 101
Furrow opening disk ................................................................................................................... 103
Covering scraper......................................................................................................................... 104
Composite intermediate axial press wheel............................................................................... 105
Stainless steel intermediate axial press wheel......................................................................... 107
Furrow closing disks....................................................................................................................110
Standard V-shaped roller .............................................................................................................111
HD V roller.....................................................................................................................................115
"OTIFLEX" 370 x 165 roller......................................................................................................... 120
"OTIFLEX" 500 x 175 roller......................................................................................................... 122
Microgranulator ........................................................................................................................... 124
Fertilizer unit................................................................................................................................ 139
Low flow kit for the fertilizer unit ............................................................................................... 154
Filling auger ................................................................................................................................. 155
Distribution disks ........................................................................................................................ 157
Belt and pulley units.................................................................................................................... 158
Rear PTO output stub.................................................................................................................. 158
Hydraulic blower drive................................................................................................................ 159
Vacuometer .................................................................................................................................. 161
HECTOR 3000 electronic control box........................................................................................ 161

Precision Seed Drills
4
MAXIMA 2
Contents
Passage control box kit KMS208................................................................................................ 161
Sowing control box kit KMS412 ................................................................................................. 162
Electronic disengagement kit..................................................................................................... 162
65 x 400 depth control wheels.................................................................................................... 162
45 mm (1.8 ’’) spacer and 5 mm (0.2’’) levelling pad................................................................. 163
82 mm (3.2’’) spacer and 5 mm (0.2’’) levelling pad.................................................................. 163
Mechanical hectare counter........................................................................................................ 163
Maintenance and storage..........................................................................................165
Frequency chart........................................................................................................................... 165
Cleaning the machine.................................................................................................................. 167
Lubrication ................................................................................................................................... 168
Maintenance................................................................................................................................. 171
Storage.......................................................................................................................................... 179
Trouble shooting guide .............................................................................................181
Limited warranty ........................................................................................................184

Identification of the machine
Precision Seed Drills
MAXIMA 2
5
$IDENTIFICATION OF THE MACHINE
1. Front view (Basic machine)
2. Rear view (Basic machine)

Precision Seed Drills
6
MAXIMA 2
Identification of the machine
3. Model identification plate
Please write below the type and serial number of the
machine. This information is to be indicated to the dealer
for all spare parts orders.
Type: MAXIMA 2
Serial no.:

Identification of the machine
Precision Seed Drills
MAXIMA 2
7
4. Optional equipment
Tick box corresponding to the equipment fitted on your
machine:
Sowing component
 Kit no. 1676801: Clod clearer with disk coulter for * 1 gauge wheels.
 Kit no. 1676802: Clod clearer with disk coulter for * 1 gauge wheels.
 Kit no. 1676803: Spring assisted clod clearer.
 Kit no. 1676783: Star shaped trash remover.
 Kit no. 1676775: Opener disc solo.
 Kit no. 1676761: Covering scraper.
 Kit no. 1676762: Composite intermediate axial press wheel.
 Kit no. 1676766: Stainless steel intermediate axial press wheel.
 Kit no. 1676790: Furrow closing disks.
 Kit no. 1677235: Standard Rubber V roller 25 mm (1’’).
 Kit no. 1677234: Standard Rubber V roller 50 mm (2’’).
 Kit no. 1677237: Standard smooth steel V roller.
 Kit no. 1677236: Standard notched steel V roller.
 Kit no. 1677241: HD Rubber V roller 25 mm (1’’).
 Kit no. 1677240: HD Rubber V roller 50 mm (2’’).
 Kit no. 1677239: HD smooth steel V roller.
 Kit no. 1677238: HD notched steel V roller.
 Kit no. 1676757: ø370 x 165 mm (1’2’’ x 6.4’’) OTIFLEX roller and covering scrapers.
 Kit no. 1676859: ø370 x 165 mm (1’2’’ x 6.4’’) OTIFLEX roller and furrow closing disks.
 Kit no. 1676758: ø500 x 175 mm (1’7’’ x 6.9’’) OTIFLEX roller and covering scrapers.
 Kit no. 1676863: ø500 x 175 mm (1’7’’ x 6.9’’) OTIFLEX roller and furrow closing disks.

Precision Seed Drills
8
MAXIMA 2
Identification of the machine
Microgranulator
Fertilizer unit
For the following models:
- M2M08RT000A003
First equipment microgranulator
 Kit no. 1677163:Insecticide microgranulator 8 rows, 100 L (26 US gal) hopper with front blower and fitting on air
duct.
 Kit no. 1677164: Slug pellet microgranulator 8 rows, 100 L (26 US gal) hopper with front blower and fitting on air
duct.
 Kit no. 1677165: Herbicide microgranulator 8rows, 190 (50 US gal) hopper with front blower and fitting on air duct.
Second equipment microgranulator
 Kit no. 1677139: Insecticide microgranulator 8 rows with 100 L (26 US gal) hopper and fitting on air duct.
 Kit no. 1677140: Slug pellet microgranulator 8 rows with 100 L (26 US gal) hopper and fitting on air duct.
 Kit no. 1677292: Herbicide microgranulator 8 rows with 190 L (50 US gal) hopper and fitting on air duct.
For the following models:
- M2M08RT000AG03
First equipment microgranulator
 Kit no. 1677145: Insecticide microgranulator 8 rows with 100 L (26 US gal) hopper and fitting in high position.
 Kit no. 1677146: Anti-slug pellet microgranulator 8 rows with 100 L (26 US gal) hopper and fitting in high position.
 Kit no. 1677147: Herbicide microgranulator 8 rows with 190 L (50 US gal) hopper and fitting in high position.
Second equipment microgranulator
 Kit no. 1677145: Insecticide microgranulator 8 rows with 100 L (26 US gal) hopper and fitting in high position.
 Kit no. 1677146: Anti-slug pellet microgranulator 8 rows with 100 L (26 US gal) hopper and fitting in high position.
 Kit no. 1677147: Herbicide microgranulator 8 rows with 190 L (50 US gal) hopper and fitting in high position.
 Kit no. 1677228: Low flow kit for the fertilizer unit.
 Kit no. 1677227: Loading screw for fertilizer unit fitted with a 1350 L (356 US gal) hopper.
For the following models:
- M2M08RT000AG03
 Kit no. 1677058: Fertilizer 8 rows with 1350 L (356 US gal) hopper and applicators with standard Suffolk coulters.
 Kit no. 1677059: Fertilizer 8 rows with 1350 L (356 US gal) hopper and applicators with non-stop Suffolk coulters.
 Kit no. 1677060: Fertilizer 8 rows with 1350 L (356 US gal) hopper and applicators with non-top disk coulters.

Identification of the machine
Precision Seed Drills
MAXIMA 2
9
Distribution disks
SP = Disk without agitator blades.
AP = Disk with agitator blades.
 Kit no. 1677227: Loading screw for fertilizer equiped with 1350 L (356 US gal) hoppers.
 Kit no. N1503620: Distribution disk 12 holes of diameter 1.5 mm (0.06’’) AP.
 Kit no. N04343B0: Distribution disk 12 holes of diameter 2.5 mm (0.1’’) AP.
 Kit no. N1502090: Distribution disk 12 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N04286B0: Distribution disk 18 holes of diameter 1.5 mm (0.06’’) SP.
 Kit no. N00846B0: Distribution disk 18 holes of diameter 2.5 mm (0.1’’) AP.
 Kit no. N04318B0: Distribution disk 18 holes of diameter 3 mm (0.12’’) AP.
 Kit no. N00847B0: Distribution disk 18 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N00856B0: Distribution disk 22 holes of diameter 2.1 mm (0.08’’) SP.
 Kit no. N1503810: Distribution disk 22 holes of diameter 2.1 mm (0.08’’) AP.
 Kit no. N04341B0: Distribution disk 22 holes of diameter 2.5 mm (0.1’’) AP.
 Kit no. N03840B0: Distribution disk 22 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N00851B0: Distribution disk 22 holes of diameter 4.5 mm (0.18’’) AP.
 Kit no. N02511B0: Distribution disk 22 holes of diameter 5 mm (0.2’’) AP.
 Kit no. N00852B0: Distribution disk 22 holes of diameter 5.5 mm (0.22’’) AP.
 Kit no. N1503140: Distribution disk 27 holes of diameter 2.5 mm (0.1’’) AP.
 Kit no. N1500670: Distribution disk 27 holes of diameter 3 mm (0.12’’) SP.
 Kit no. N03823B0: Distribution disk 27 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N00843B0: Distribution disk 27 holes of diameter 4.5 mm (0.18’’) AP.
 Kit no. N00905B0: Distribution disk 27 holes of diameter 5 mm (0.2’’) AP.
 Kit no. N00844B0: Distribution disk 27 holes of diameter 5.5 mm (0.22’’) AP.
 Kit no. N1500340: Distribution disk 30 holes of diameter 7 mm (0.28’’) AP.
 Kit no. N00845B0: Distribution disk 31 holes of diameter 2.1 mm (0.08’’) SP.
 Kit no. N00855B0: Distribution disk 33 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N04107B0: Distribution disk 33 holes of diameter 4.5 mm (0.18’’) AP.
 Kit no. N04282B0: Distribution disk 33 holes of diameter 5.5 mm (0.22’’) AP.

Precision Seed Drills
10
MAXIMA 2
Identification of the machine
Blower
 Kit no. N1503380: Distribution disk 35 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N1503390: Distribution disk 35 holes of diameter 4.5 mm (0.18’’) AP.
 Kit no. N1503400: Distribution disk 35 holes of diameter 5 mm (0.2’’) AP.
 Kit no. N1503410: Distribution disk 35 holes of diameter 5.5 mm (0.22’’) AP.
 Kit no. K3601440: Distribution disk 48 holes of diameter 1.25 mm (0.05’’) SP.
 Kit no. N02951B0: Distribution disk 48 holes of diameter 2.5 mm (0.1’’) AP.
 Kit no. N00848B0: Distribution disk 48 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N04305B0: Distribution disk 48 holes of diameter 4.5 mm (0.18’’) AP.
 Kit no. N1503130: Distribution disk 48 holes of diameter 5.5 mm (0.22’’) AP.
 Kit no. N1500061: Distribution disk 54 holes of diameter 3 mm (0.12’’) SP.
 Kit no. N1500681: Distribution disk 54 holes of diameter 4.5 mm (0.18’’) AP.
 Kit no. N1500691: Distribution disk 54 holes of diameter 5.5 mm (0.22’’) AP.
 Kit no. N1500431: Distribution disk 70 holes of diameter 1.25 mm (0.05’’) SP.
 Kit no. N02851B0: Distribution disk 70 holes of diameter 2.5 mm (0.1’’) AP.
 Kit no. N04342B0: Distribution disk 70 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N00850B0: Distribution disk 70 holes of diameter 4.5 mm (0.18’’) AP.
 Kit no. N1502170: Distribution disk 80 holes of diameter 2.5 mm (0.1’’) AP.
 Kit no. N1501591: Distribution disk 80 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. N1501051: Distribution disk 100 holes of diameter 0.8 mm (0.03’’) SP.
 Kit no. N00849B0: Distribution disk 100 holes of diameter 1.25 mm (0.05’’) SP.
 Kit no. N1500701: Distribution disk 100 holes of diameter 1.75 mm (0.07’’) AP.
 Kit no. N04293B0: Distribution disk 100 holes of diameter 3.5 mm (0.14’’) AP.
 Kit no. 1677287: 470 min-1 pulley and belt unit
 Kit no. 1676731: 870 min-1 pulley and belt unit
 Kit no. 1676738: 1000 min-1 pulley and belt unit
 Kit no. 1676730: Rear PTO output stub.
 Kit no. 1676545: Hydraulic blower drive.

Identification of the machine
Precision Seed Drills
MAXIMA 2
11
Control units
Sundry
 Kit no. 1676546: Hydraulic hose extension.
 Kit no. 1677223: Vacuometer.
 Kit no. 1676822: HECTOR 3000 electronic unit.
 Kit no. 1676659: Passage control box kit KMS208.
 Kit no. 1676428B: Sowing control box kit KMS412.
 Kit no. 1677299: Electronic disengagement kit.
 Kit no. 1676520: 65 x 400 depth control wheels.
 Kit no. 1677293: 45 mm (1.8’’) spacer and 5 mm (0.2 ’’) levelling pad.
 Kit no. 1676792: 82 mm (3.2’’) spacer and 5 mm (0.2 ’’) levelling pad.
 Kit no. 1676821: Mechanical hectare counter.

Precision Seed Drills
12
MAXIMA 2
Safety
$SAFETY
1. Description of symbols used in this
document
This symbol indicates a potentially hazardous situation
that if not avoided, could result in serious bodily injury.
This symbol is used to identify special instructions or
procedures which, if not followed strictly, could result in
machinery damage.
This symbol is used to communicate technical
information of particular interest.

Safety
Precision Seed Drills
MAXIMA 2
13
2. Safety instructions
Read and follow the safety instructions
Before using the machine, carefully read all the safety
instructions in this manual and the warnings placed on
the machine.
Before starting work, the operator must be familiar with
all machine controls, handling devices and their
functions. It is too late to learn once work has been
started!
Never let anyone operate the machine who is not trained
to do so.
Should you have any difficulties in understanding certain
parts in this manual, please contact your KUHN dealer.
Precautions to be taken before carrying out
any operations on the machine
Before leaving the tractor or before adjusting,
maintaining or repairing the machine, disengage the
PTO drive, turn off the engine, remove ignition key and
wait until all moving parts have come to a complete stop
and apply park brake.
Introduction
The machine must only be operated, maintained and repaired by competent persons who are familiar with
machines' specifications and operation and aware of safety regulations for preventing accidents.
The operator must imperatively respect safety instructions in this manual and in the warnings posted on the
machine. The operator is also obliged to respect current legislation concerning accident prevention, work safety
and public traffic circulation.
Designated use of the machine also means following operation, maintenance and repair recommendations
given by the manufacturer, and using only genuine spare parts, equipment and accessories, as recommended
by the manufacturer.
The manufacturer is not held liable for any damage resulting from machine applications other than those
specified by the manufacturer. Any use other than the designated operation is at the risk and responsibility of
the operator.
The manufacturer is not held liable for any damage or accident resulting from machine modifications carriedout
by the operator himself or by a third party without previous written agreement from the manufacturer.

Precision Seed Drills
14
MAXIMA 2
Safety
Precautions to take before using the
machine
Do not wear loose clothing which could become caught
up in moving parts.
Wear the appropriate protective clothing for the work in
hand (gloves, shoes, goggles, helmet, ear-protectors,
etc.).
Ensure that all operating controls (ropes, cables, rods,
etc) are placed so as they cannot be operated
unintentionally and cause damage or injury.
Before operating the machine, check tightness of nuts
and bolts, particularly on fixing elements (tines, forks,
blades, knives, etc). Retighten if necessary.
Before operating the machine, ensure that all the safety
guards are firmly in place and in good condition.
Immediately replace any worn or damaged guard.
Precautions when driving
Tractor handling, stability, performance and braking
efficiency are all affected by weight distribution, trailed or
mounted implements, additional ballast and driving
conditions. It is therefore ofthe great importance that the
operator exercises caution in every given situation.
Groundspeed must be adapted to ground conditions as
well as to roads and paths. Always avoid abrupt changes
of direction.
Be particularly cautious when turning corners, paying
attention to machine overhang, length, height and
weight.
Never use a narrow track tractor on very uneven or
steeply sloping ground.
Never leave the tractor seat while the machine is
operating.
Carrying people or animals on the machine when
working or in transport is strictly forbidden.

Safety
Precision Seed Drills
MAXIMA 2
15
Precautions when driving on public roads
Dimensions
Depending on the dimensions of the machine, contact
the relevant authorities to ensure that it can be legally
transported on public roads.
If the machine is over the maximum legal size, follow the
local regulations for special transportation of oversize
equipment.
Gross weight and weight per axle
Check that the tractor's authorized gross weight as well
as its lift capacity and maximum weight per axle are not
exceeded.
The front axle load (1) must never, under any
circumstances, be less than 20% of the tractor's unladen
weight. If necessary, add ballast weights to the front or
to the rear to preserve the steering and braking
efficiency.
Transport position
Before transporting the machine on public roads, place
the machine into its transport position, according to the
instructions in this manual.
Lightings and signallings
Before transporting the machine on public roads, ensure
that all legally required lightings and signallings are in
place.
Ensure that lightings and signallings are clean and in
good working order. Replace any missing or broken
equipment.
Maximum speed
Always keep to the legal speed limit for driving a tractor-
machine assembly on public roads.
Always obey current regulations for driving
on roads.

Precision Seed Drills
16
MAXIMA 2
Safety
Precautions when coupling
Before attaching the machine, make sure that it cannot
accidentally start moving (chock the wheels) andthat the
parking stand is in the right position.
The machine must only be attached to the hitch points
provided for this purpose.
Never stand between the tractor and the machine when
operating the three point linkage.
Do not stand between the tractor and the machine
without ensuring that the parking brake is applied.
Hydraulic circuit
Beware : The hydraulic circuit is under pressure.
Maximum pressure at work: 200 bar (2857 psi).
Before connecting hoses to the tractor hydraulics,
ensure that tractor and machine circuits are not under
pressure.Beforedisconnectinga hose, depressurize the
hydraulic circuit.
To avoid making incorrect connections, mark hydraulic
couplers and corresponding hoses with colors.
WARNING! Functions could be reversed (for example:
lift/lower) and cause accidents.
Regularly check the hydraulic hoses. In case of normal
wear, replace the hydraulic hoses every 5 years.
Damaged or worn hoses must immediately be replaced.
When replacing the hydraulic hoses, make sure to use
hoses with the specifications and quality recommended
by the manufacturer of the machine.
To locate a leak, use appropriate means.
Protect body and hands from liquid under pressure.
Any liquid under pressure (particularly oil from
hydraulics) can penetrate the skin and cause severe
injury. If injured, see a doctor immediately, there could
be danger of infection.
Before any adjustments, maintenance or repairs are
carried out, lower the machine on the ground,
depressurize the hydraulics, turn off the engine, remove
ignition key and wait until all moving parts have come to
a complete stop.

Safety
Precision Seed Drills
MAXIMA 2
17
PTO shaft
Use only PTO shafts supplied with the machine or
recommended by the manufacturer.
The protective shield of the tractor PTO stub, the PTO
shaft guards and the protective covering of the machine
input shaft must always be in place and in good
condition.
Make sure that the PTO shaft guards are secured with
the safety chains provided.
Any worn or damaged guards must be replaced
immediately. A worn guard or an unprotected PTO shaft
can cause a serious or even a lethal accident.
Do not wear loose clothing that could be caught in the
rotating PTO shaft.
Before attaching or removing a PTO shaft, or before
doing any work on the machine, disengage the PTO
drive, turn off the engine, remove ignition key and wait
for all moving parts have come to a complete stop.
If the primary PTO shaft is equipped with a slip clutch or
a free wheel, these must be fitted on the machine side.
Ensure that the PTO shaft is always correctly fitted and
locked into place.
Before connecting the PTO shaft, ensure that the PTO
speed (rotational frequency) and directions of rotation
are in line with manufacturer's recommendations.
Before engaging the PTO drive, make sure all people
and animals are clear from the machine. Never engage
the PTO drive when the tractor engine is stopped.
When uncoupling the machine, rest the PTO shaft on the
support specially provided, and replace protective cover
on the PTO stub of the tractor.
Read and follow the instructions in the operator's manual
provided with the PTO shaft.

Precision Seed Drills
18
MAXIMA 2
Safety
Precautions during manoeuvres
When moving the machine from the transport position to
the working position and vice versa, make sure that
nobody is within the machine pivoting area.
Remote controlled components
Danger of crushing and shearing can exist when
components are operated by hydraulic or pneumatic
controls. Keep away from these danger zones.
Safety decals
Safety warning decals to respect, are placed in pictorial
form on various parts of the machine. They are there to
warn you of potential dangers and to tell you how to
avoid accidents.
Always keep the safety decals clean and readable, and
replace them when they are worn, damaged, missing or
illegible.
Waste disposal
Respect the environment! Never spill pollutants (oil,
grease, filters etc.) on the ground neither pour them
down the drain or discard them in any other place where
they could pollute the environment. Never throw away or
burn a tire. Always take waste to specialized recycling or
waste disposal centers.
