Kustom KPM7200 User manual

Congratulations,you nowownKustom'sKPM7200 Powered Mixer,
a24-bitdigital,portableand powerful200 Watt PAmixer/amplifier.
The KustomKPM7200 iseasy tooperateand easy tounderstand.Beforeoperating your
KPM7200,pleaseread and understand all setup and safetyinstructions.

1
IMPORTANT
1.Read all safetyand operating instructionsbeforeusing thisproduct.
2.All safetyand operating instructionsshouldbe keptforfuturereference.
3.Thisproductshouldnotbe used nearwateri.e.bathtub,sink,swimming
pool,wetbasement, etc.
4.Thisproductshouldbe located sothatitsposition doesnotinterferewith
properventilation.It shouldnotbe placed flatagainstawall orplaced
inabuilt-inenclosurethatwill impede the flowofcooling air.
5.Thisproductshouldnotbe placed nearasourceofheat, suchasa
stove,radiator,oranotherheatproducing amplifier.
6.Connectonlytoapowersupplyofthe type indicated on the back ofthe
amplifiernearthe powersupplycord.
7.Donotbreakoff the ground pinofthe powersupplycord.
8.Powersupplycordsshouldalways handled carefully.Neverwalkorplace
equipmenton powersupplycords.
9.The powersupplycordshouldbe unplugged when the unitisunused
forlong periodsoftime.
10.Careshouldbe taken sothatobjectsdo notfall and liquidsarenotspilled
intothe unitthrough the ventilation portsoranyotheropenings.
Danger
Exposuretoextremelyhigh noiselevelsmaycauseapermanenthearing loss.
Individualsvaryconsiderablytonoiseinduced hearing loss butnearlyeveryone will
losesomehearing ifexposed tosufficientlyintensenoiseforasufficienttime.
The U.S.Government'sOccupationalSafetyand HealthAdministration (OSHA)has
specified the following permissiblenoiselevelexposures:
According toOSHA,anyexposureinthe abovepermissiblelimitscouldresultin
somehearing loss.Earplugsorprotectorsinthe earcanaloroverthe earsmust
be wornwhen operating thisamplification systeminordertopreventapermanent
hearing loss.If exposureinexcess ofthe limitsasputforthabove,toinsureagainst
potentiallyharmfulexposuretohigh sound pressurelevels,itisrecommended that
all personsexposed toequipmentcapableofinducing high sound pressurelevels,
suchasthisamplification system,be protected byhearing protectorswhilethisunit
isinoperation.
DURATIONPERDAY (HOURS)8 6 4 3 2 1
SOUND LEVEL(dB)90 93 95 97 100 103
CAUTIO
RISKOFELECTRIC
SHOCK
CAUTION: TOREDUCETHERISKOFELECTRICSHOCK,
DONOTREMOVE CHASSIS.NOUSER-
SERVICEABLEPARTSINSIDE.REFER
SERVICINGTOQUALIFIEDSERVICE
AVIS:RISQUEDECHOCELECTRIQUE-NEPAS
IMPORTANT
1.Liseztouteslesinstructionsd’utilisation etde sécuritéavantd’utiliser
ceproduit.
2.Touteslesinstructionsd’utilisation etde sécuritédoiventêtreconservées
afinde pouvoirs’yréféreràtoutmoment.
3.Cetappareil ne doitpasêtreutiliséàproximitéd’eau ou baignoire,évier,
piscine,sous-solhumide,etc.
4.Cetappareil doitêtreplacéde tellesorteque saposition ne l’empêche
pasd’êtreventilé.Ilne doitpasêtreplacéàplatcontreun murou dans
un espaceencastréquiempêcheraitlaventilation.
5.Cetappareil ne doitpasêtreplaceprèsd’une sourcede chaleurtelun
forneau,radiateurou toutautreappareil produisantde lachaleur.
6.Branchezuniquementune alimentation électrique du type indiqué sur
l’arrièrede l’amplificateur,prèsdu cordon d’alimentation électrique.
7.Necoupezpaslaborne de terredu cordon d’alimentation électrique.
8.Lescordonsd’alimention électrique doiventtoujoursêtremanipulésavec
précaution.Nejamaismarcherniposerun équipementsurdescordons
d’alimentation électrique.
9.Le cordon d’alimentation électrique doitêtredébranché en casde période
de non-utilisation prolongée.
10. Ilfautprendrelesprécautionsnécessairesafinde ne pasfairetomberd’objet
nirenverserdu liquide dansl’appareil parlestrousd’aération ou toute
autreouvertune.
Danger
L’exposition adesniveauxelevesde bruitpeutprovoquerune pertepermanente
de l’audition.Chaque organismehumainreagitdifferemmentquantalapertede
l’audition,maisquasimenttoutlemonde subitune diminution de l’acuiteauditive
lorsd’une exposition suffisammentlongue au bruitintense.Lesautorites
competentesen reglementation de bruitontdefinilesexpositionstolereesaux
niveauxde bruits:
Selon lesautorites,touteexposition dansleslimitesciteesci-dessus,peuvent
provoquercertainespertesd’audition.Desbouchonsou protectionsdans
l’appareil auditifou surl’oreilledoiventetreporteslorsde l’utilisation de ce
systemed’amplification afinde prevenirlerisque de pertepermanentede
l’audition.Danslecasd’expositionssuperieuresauxlimitespreciteesil est
recommande,afinde sepremunircontrelesexpositionsauxpressions
acoustiqueseleveespotentiellementdangeureuses,auxpersonnesexposees
auxequipementscapablesde delivrerde tellespuissances,telscesysteme
d’amplification en fonctionnement, de protegerl’appareil auditif.
ATTENTI
RISQUEDECHOC
ELECTRIQUE
ATTENTI
AFINDELIMITERLERISQUEDECHOCELECTRIQUE,
NEPASENLEVERLECHASSIS.NECONTIENTPAS
DEPIECESPOUVANTETREREPAREEPAR
L’UTILISATEUR.CONFIERLESERVICEAPRES-
VENTEAUXREPARATEURSAGREES.
DUREENHEURES PARJOUR 8 6 4 3 2 1
NIVEAUSONORECONTINU ENdB90 93 95 97 100 103
ENGLISHFRENCH
THISSYMBOLISINTENDEDTOALERTTHEUSERTOTHEPRESENCE
OFIMPORTANTOPERATINGAND MAINTENANCE(SERVICING)
INSTRUCTIONSINTHELITERATUREACCOMPANYINGTHEUNIT.
THISSYMBOLISINTENDEDTOALERTTHEUSERTOTHEPRESENCEOFNON-
INSULATED“DANGEROUSVOLTAGE”WITHINTHEPRODUCT’SENCLOSURETHAT
MAYBEOFSUFFICIENTMAGNITUDETOCONSTITUTEARISK OFELECTRIC
SHOCKTOPERSONS.
CESYMBOLEAPOURBUTD’AVERTIRL’UTILISATEUR DELA
PRESENCED’INSTRUCTIONSD’UTILISATIONETDEMAINTENANCE
DANSLESDOCUMENTSFOURNISAVECCEPRODUIT.
CESYMBOLEAPOUR BUTD’AVERTIRL’UTILISATEUR DELA
PRESENCEDEVOLTAGEDANGEREUXNON-ISOLEAL’INTERIEUR
DECEPRODUITQUIPEUTETREDEPUISSANCESUFFISAMMENT
IMPORTANTEPOUR PROVOQUERUNCHOCELECTRIQUEAUX
PERSONNES.

SETUPDIAGRAMA
MIXERFRONT
SETUPDIAGRAMB
MIXERREAR
2
1
2
3
4
5
6
7 8 10 12 14139 11
26
25
15 16 17 18 19
24
23
22
21
20
29
30
28
27

EXPLANATIONOFCONTROLS
FRONTPANEL
1)EffectsControls:Adjuststhe amountofsignalthatissenttothe digitaleffectsprocessor.
2)MonitorControls:Adjuststhe amountofsignalthatissenttothe MasterMonitorcontrol.
3)ToneControls:Adjuststhe balanceofbass and treblefromthe individualchannels.
4)MainControls:Adjuststhe volumeofthe individualchannel.
5)LineInput: Inputconnection for1/4"line levelsources(Keyboards,drummachines,etc.)
6)MicrophoneInput: Inputconnection forbalanced Low-Zsignals(Microphones,etc.)
7-8)InstrumentInputs:Inputconnection forinstruments(AcousticGuitars,ElectricGuitars,etc.)
9)EffectsSend:Outputconnectorused tosend aline levelsignalfromthe KPM7200 toan
outboardeffect. Thisconnectortakesasignalfeed fromthe individualchannel'sEffectscontrols.
10)AuxReturn:Inputconnectorused toreceiveasignalfroman outboardeffectorsignalsource.The signalfrom
thisconnectorisfed totheeffectMaster(16)control.The EffectMastercontrol(16)will adjustthevolumeofthissignal
source.
11)PreampOutput: Line leveloutputforthe preamp.Thiscontroltakesasignalfeed fromthe MainMastercontrol.
12)PowerAmpInput: Inputconnectorforthe PowerAmp.NOTE:When aline levelsignalsourceisinserted into
thisconnector,thesignalfromthe KustomKPM7200'sindividualchannelsaredisconnectedandwill notfunction.Only
the outboardsignalsourcewill be amplified.
13)MonitorOutput: Outputconnectortosend aline levelsignaltoamonitoramplifierorpowered monitor.
14)Footswitch:StandardTip-Ring-Sleevewired footswitchtoturndigitaleffectson and mutethe channelsofthe
KPM7200.Tipconnection turnsthe Effectson and off. The Ring connection will mutethe individualchannels.
15)DigitalEffectsIndicators:TheseLED'sshowwhatdigitaleffectshavebeen chose.NOTE:NoLED'sarelit
when the Effectsaremuted viafootswitch.
16)EffectsMaster:Controlsthe volumeofdigitaleffectsignaltothe MainMastercontrol.
17-18)EffectSelect: Thesetwopushbuttonswill scroll through the digitaleffectoptions.Pressing the UPbutton will
advancethe digitaleffectselection tothe nextselection higherthan the presentselection.Pressing the DOWN
button will advancethe digitaleffectselection tothe nextselection lowerthan the presentselection.NOTE:When
scrolling pastthe top orbottomofthe effectsselection,the effectsselection will automaticallygo tothe oppositeend
ofthe selections.
19)Equalizer:Thesecontrolsadjustoverall tone ofthe mixer.Eachslide controladjuststhe amountofspecific
frequencies+or–12dB.
20)MainMaster:Controlsthe totalvolumeon the individualchannels.NOTE:The playback volumeisnotaffected
bythe MainMastercontrol.
21)PowerOnIndicator:Powerison when LEDislit.
22)MonitorMaster:Controlsthe totalvolumeofthe individualchannel'smonitorsends.
NOTE:The Monitoroutputisstill activewhen Mainchannelsaremuted viafootswitch.
3

23)ChannelsOnIndicator:Channelsareactivewhen LEDislit.
24)Playback Volume:Controlsthe volumefromthe Playback RCAinputjacks(25).
NOTE:The Playback featureisnotaffected bythe MainMastercontroland will remain
activeeven when the mutefunction isactiveviathe footswitch.
25)Playback RCA Jacks:InputconnectorCD,Tape oranyline levelstereo signalsource.
Allowsyou toplayrecorded musicthrough the mixer.
26)RecordRCA Jacks:Outputconnectorstosend line levelsignaltoarecorddevicesuchasatape recorderor
computer.
REAR PANEL
27)AC CordConnector:InserttheACcord(supplied)firmlyintotheACconnector.NOTE:ReplacetheACpower
cordifprotectivejacketisdamaged orround ground pinisdamaged orremoved.
28)PowerSwitch:The KPM7200 isturned ONwhen the switchisinthe UPposition.
Press the switchtothe DOWNposition when notinuse.
29-30)Speaker:Connectorsfor8Ohmspeakercabinetseach.
NOTES:#1 do notconnectmorethan two8Ohmspeakercabinetstothe outputofthe KPM7200 mixer/amplifier.
Totalload mustnotgo below4Ohms.
#2.It isnotnecessarytousebothA&Boutputjacks.
The KPM7200 will operateat8-16 Ohms.
QUICK-STARTSETUPINSTRUCTIONS
Making Connections:
•Connect1/4"non-shielded speakercablestothe speakeroutjacks on the rearofthe KPM7200 (29 &30),
then connectthe oppositeend ofeachspeakercabletothe speakerenclosures.
•Connectinstrumentsand microphonesintothe appropriateinputconnectorslocatedon thefrontofthemixer.
LowImpedanceMicrophones(6),Line Level(5),High ImpedanceInstruments(7&8),tape/CD (25).
•Makesurethe powerswitchisturned tothe off position and attachtheACpowercableintothe fusedAC
input(27)located on the rearofthe mixer.
MasterSection:
•Turnthe MainMastercontrol(20),and Playback Master(24)counterclockwise.
• Adjustthe masterequalizerslide controls(19)tothe center0dBposition.
InputSection:
•Turnall channelvolumecontrols(4)counterclockwise.
•Turnall tone controls(3)tothe 12 O'clock position.
4

PLAYING
• Press the Powerswitch(28)tothe ONposition.
•Turnthe MainMastercontrol(20)tothe 12 O'clock position.
•Turnthe Maincontrol(4)clockwiseon eachchanneltoachievethe desired volume.(One channelatatime)
• Afteryou aresatisfied withthebasicmixofthe individualchannels,usethe MainMastercontrol(20)toadjust
the overall volumeofthe mixer.
•Usethe GraphicEqualizerslide controls(19)tocontrolfeedbackand contourthe audiototheoverall desired
sound.
• Selectadigitaleffect(ifdesired).The KPM7200 offersachoiceofeight24-bit
digitaleffects.
STAGEEFFECTS STUDIOEFFECTS
Large RoomChorus
Small RoomChorus/Reverb
Small Hall Slap-backEcho
Large Hall Delay
• Adjustthe effectscontrolson the individualchannels(1)todesired volume.
Adjustthe effectsMastercontroltoachievethe totaldesired amountofeffects
inthe mix.
•Resetthe Mainmastercontrol(20)todesired volume.
That'sit. Enjoy...
Servicing:TheACFuseisaccessibleunderneaththeACcableconnector.Nouserserviceablepartsinside.Pleasecontact
yournearestAuthorized KustomServiceCenterorKustomInc.directlyforservice.
KustomInc.CustomerServicecan be reached at(513)451-5000 ext. 504,[e-mail]
ServiceCenterfromthe WorldWide Web atwww.kustom.com.
5

6

ModelKPM7200 KPM7200 Powered Mixer
OutputPower200W4ohms@5%THD
160W4ohms@0.4%THD
Frequency Response 20Hz-20kHzActualresponseistailored tospeakercabinetfor
accurateacousticalresponse.
TotalHarmonicDistortion less than 0.4%Measured at1VRMS(0dBv)atrecordoutput,
effectssend,orinsertoutput
Hum&Noise-115dBMicInput, Rs=150 ohm,20-20kHz
-60dBResidualNoise,all levelcontrols0%(minimum)
-50dBNominalSystemNoise,all levelcontrolsat50%
SystemGainAll measurementsmade at1kHz
77dBMictoPowerAmpOut(Ch1-Ch5)
60dBLine toPowerAmpOut(Ch1-Ch7)
70dBInstrumenttoPowerAmp(Ch6-Ch7)
36dB Playback toPowerAmp
50dBMictoRecordOutput
44dBMictoEffectsSend
50dBMictoPreampOutput
50dBMictoMonitorOutput
Crosstalk80dBChanneltochannel,1kHz
InputChannelEqualization Specialcurvethatadjustsbass,mid,and treblefrequencies
MasterEqualization 100 to10Khz,7Band,1OctaveGraphic,all ±12dB
DigitalEffects24 bitDSP,8effects;small room,large room,small hall,large hall,
chorus,chorusreverb,slap back (delay),echo
PhantomPower+15V Applied toall MicInputsthru3.3Kresistors
FootswitchDigitaleffectsON/OFF and ChannelON/OFF (playback remainsactive)
PowerRequirementsUSA/Canada 120VAC/60Hz,160Wnominal
Europe 230VAC/50Hz,160Wnominal
UK230VAC/50Hz,160Wnominal
Australia 240VAC/50Hz,160Wnominal
Japan 100VAC/50-60Hz,160Wnominal
Dimensionsmm/kg 210 (Height)x480 (Width)x270 (Depth),11 kg
inches/pounds81/4(Height)x19 (Width)x10 5/8(Depth),24 lbs
7
KPM7200
Specifications

We:KustomMusicalAmplification Inc.
4940 DelhiPike
Cincinnati,OH 45238
Tel: [phone] Fax:[phone]
www.kustom.com
Declarethattheproduct
Productname:Kustom
Productmodelnumber:KPM7200,ContainsoneKPM7200
towhichthisdeclaration relatesisinconformitywiththefollowing standards;
EN55013 (A12):1995 Limitsand methodsofmeasurementofradiodisturbance characteristicsofbroadcastreceiversand
associatedequipment.
EN55020:1995 Electromagneticimmunityofbroadcastreceiversand associatedequipment.
EN61000-3-2:1995 Limitsforharmoniccurrentemissions(equipmentinputcurrent<16Aperphase).
EN61000-3-3:1995 Limitation ofvoltagefluctuationsand flickerinlowvoltagesupplysystemsforequipmentwithrated
currents<16A.
EN55103-1:1995 ElectromagneticCompatibility-ProductfamilystandardforAudio,VideoAudio-visualand
entertainmentLighting ControlApparatus.
EN60065:1994 Safetyrequirementsformainoperatedelectronicand relatedapparatusforhouseholdand similar
generaluse.
Following theprovisionsofEUCouncil Directive(s):72/73 EECand 89/336/EEC.
Wetheundersigned,hereby declarethattheequipmentspecifiedaboveconformstotheaforementioneddirective(s).
Nameofauthorizedperson:RickKukulies,VPEngineering
Signature:______________________ Date:05 June2001
ECDeclaration ofConformity
8

KustomInc., 4940 DelhiPike,Cincinnati,OH •USA
[phone] Fax:[phone] /www.kustom.com
