L.A. West Sprinter Shuttle User manual

Shuttle Owner’s Manual
L.A. West, Inc.
196 Crawford Road
Statesville, NC 28625
www.lawestcoaches.com

i
Contents
..........................................................................................................................................................1
Limited Warranty Policy................................................................................................................1
Delivery ...........................................................................................................................................3
Dealer Responsibilities..............................................................................................................3
Customer Responsibilities........................................................................................................3
L.A. West Limited Warranty..........................................................................................................4
Chassis Warranty.......................................................................................................................4
Other Warranties........................................................................................................................4
Vehicle Identification Number (VIN).........................................................................................4
Safety Warnings and Precautions ...............................................................................................5
Caution Symbol..........................................................................................................................5
We Care About Our Customers....................................................................................................5
Safety Alert .................................................................................................................................5
Be Prepared for Emergencies ......................................................................................................6
Escape Routes............................................................................................................................6
Optional Emergency Escape Windows................................................................................6
Emergency Escape Hatch .....................................................................................................6
Emergency Doors...................................................................................................................6
Optional Fire Extinguisher(s)................................................................................................6
Park Safely..................................................................................................................................6
Vehicle Safety Standard Certification Labels.............................................................................7
Vehicle Weight and Loading Restrictions Label ....................................................................7
Electrical Features.........................................................................................................................8
12 Volt DC (VDC) Receptacles USB Receptacles...................................................................8
Optional Converter/Inverter ......................................................................................................8
120 Volt (VAC) AC Receptacles................................................................................................8
Circuit Breakers..........................................................................................................................8
Pre-Travel Instructions..................................................................................................................9
Review this Operations/Service Manual..................................................................................9
Read the Chassis Owner’s Manual ..........................................................................................9
Before You Drive Away..............................................................................................................9

ii
Driving Tips.................................................................................................................................9
Exterior Components, Operations and Care ............................................................................10
Roof Area ..................................................................................................................................10
Fiberglass or ABS Areas.........................................................................................................10
Seams and Moldings ...............................................................................................................10
Emergency Escape Routes ........................................................................................................11
Escape Hatch............................................................................................................................11
Optional Emergency Exit Egress window.............................................................................11
Passenger Windows....................................................................................................................12
Full View Curb Window ...........................................................................................................12
Window Maintenance...............................................................................................................12
Doors.............................................................................................................................................12
Door Emergency Release Handle ..........................................................................................12
Optional Remote Control ........................................................................................................12
Rear Luggage Compartment ......................................................................................................12
Auxiliary Battery ..........................................................................................................................12
Maintaining the Doors.................................................................................................................13
Door Components........................................................................................................................14
Mirrors...........................................................................................................................................15
Lower A/C Condenser Unit.........................................................................................................15
Batteries/Battery Box ..................................................................................................................15
Underbody Area...........................................................................................................................15
Wheels and Rims.........................................................................................................................16
Tires...............................................................................................................................................16
Optional Custom Paint Graphics...............................................................................................17
Optional Vinyl Graphics..............................................................................................................17
Destination Signs (if equipped)..................................................................................................17
Walls and Ceilings ...................................................................................................................18
Optional Stanchion/Modesty Panel or Grab Rails................................................................18
Flooring.....................................................................................................................................18
Interior Luggage Racks (if equipped)....................................................................................19
Electrical Systems.......................................................................................................................20
Factory Installed Lights, Signals and Equipment................................................................20

iii
Switch Panel.............................................................................................................................20
Switches....................................................................................................................................20
Air Conditioning Control.........................................................................................................20
Switch Panel Maintenance and Care .....................................................................................20
Electronic Audio/Video Systems ...............................................................................................21
Air Conditioning System.............................................................................................................21
Factory Air Conditioning System...........................................................................................21
Fast Idle.....................................................................................................................................21
Seating ..........................................................................................................................................21
Passenger Rear Seats .............................................................................................................21
Armrest......................................................................................................................................21
Flip Style................................................................................................................................21
Fold-down Style....................................................................................................................22
Seat Recline/Side Release Handle .........................................................................................22
Other Types of Seating and Seating Operations..................................................................22
Side Slide Seat to slide the seats out for more room..........................................................22
Flips Seats.................................................................................................................................22
Seating Care.................................................................................................................................22
Driver Seat and Passenger Seat Areas .................................................................................22
Seat Fabrics..............................................................................................................................22
Wheel Chair Lifts......................................................................................................................23
Wheel Chair Restraints and Securement..................................................................................23
Reporting Safety Defects............................................................................................................23

1
Limited Warranty Policy
COMPLETE ASSURANCE LIMITED WARRANTY: L.A. West, Inc. (hereafter referred to as Warrantor)
warrants to the original purchaser (hereafter referred to as Owner) that its workmanship and its materials
shall be free of substantial or material defects with regards to any and all parts or assembly labor
attributabletoWarrantor, under normal use and service. The warranty period shall beas follows: (3)three
years or (36,000) thirty-six thousand miles from the date of original purchase, whichever shall happen
first.
WARRANTY PERFORMANCE: Warrantor will repair or replace, at its sole election, any defective part
covered under this warranty, at no expense to the Owner. Unless otherwise approved in writing and signed
by all parties, Owner shall be responsible for expenses arising out of or relating to transporting the product
and / or vehicle to the appropriate Warranty Service location. Every reasonable effort shall be made to
select and provide a suitable Warranty Service location in close relative proximity to Owner for necessary
inspection and / or repair of vehicle. In the event that a specified part is deemed non-reparable and exact
replacement is no longer available, all reasonable effort shall be made to obtain suitable replacement of
equivalent value and function for substitution in place of original. Notwithstanding, Warrantor reserves the
right to change the parts and designs of its products without notice with no obligation to make corresponding
changes to previously manufactured products.
WARRANTY EXCLUSIONS: This warranty shall NOT cover the following:
1) Damage or deterioration to the physical appearance of the unit if such damage is the result of normal use, wear and
tear, or exposure to the elements.
2) Damage caused by misuse, abuse, negligence, accident or acts of God. Usage of this product in a manner
inconsistent with its design intentions or inconsistent with the manufacturer’s instructions and recommendations will
void this warranty with respect to damage caused by or relating to such inconsistent usage.
3) Products, which have been repaired, altered or modified by any party other than Warrantor.
4) Accessories or parts not installed by Warrantor, including but not limited to; chassis and its component parts.
5) Expenses arising out of, or related to, the transporting of the product to an appropriate Warranty Service Location
for service.
6) Expenses arising out of, or related to, normal maintenance, such as: cleaning interior/exterior, lubrication and/or
minor adjustments of moving parts, etc.
The following actions or events will result in the automatic termination of this warranty and will relieve
Warrantor from any and all obligations under this warranty:
1) Misuse or neglect of the product, failure to provide reasonable and necessary maintenance, unauthorized alteration
or modification, accident or improper loading.
2) Sale of this vehicle to third party. This warranty is non-transferable.
3) The expiration of the warranty period set out herein.
WARRANTY CLAIM PROCEDURES: All warranty claims must be reported within the warranty period.
Warrantor must authorize all warranty service requiring repair or replacement prior to such repair or
replacement being performed. Warranty service may be reported directly to the Warrantor or to one of their
authorized dealer or sales representatives. If warranty personnel approve warranty service, you must leave
the unit at the appropriate Warranty Service location for a sufficient time to effect service.
Formatted: Left, Tab stops: 0.38", Left

2
LIMITATIONS: THIS WRITTEN WARRANTY IS MADE IN LIEU OF ANY AND ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED. NO IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE IS MADE.
RECOVERY LIMITATIONS: NO PERSON SHALL BE ENTITLED TO RECOVER FROM WARRANTOR
FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING OUT OF OR RELATING TO ANY
DEFECT IN THE PRODUCT. These limitations include, but are not limited to, loss of time; loss of use; loss
of revenues, salaries or commissions; towing charges; bus fares; car rentals; gasoline expenses; telephone
charges; lodging, inconvenience or other incidental damages.
LEGAL RIGHTS: This written warranty constitutes the entirety of the agreement between Warrantor and
Owner. Warrantor does not authorize any person to expand, amend or alter this liability in connection with
this product. No alteration of this agreement shall be deemed valid unless and until it has been agreed to
in writing and signed by all parties. Disputes arising from any repair, replacement parts or any other aspect
of repair and/or warranty shall be resolved in accordance with the accepted practices and procedures of
the American Arbitration Association relating to commercial transactions in the State of North Carolina.
Arbitration results shall be binding by both parties. Both parties’ arbitration related expenses shall be paid
by losing party.
THE TERMS OF THE WARRANTOR’S UNDERTAKING EXPRESSED IN THIS LIMITED WARRANTY
ARE DRAFTED TO COMPLY WITH THE MAGNUSEN MOSS WARRANTY LEGISLATION, P.L. 93-637
of 1974, AND OTHER APPLICABLE LAW. ANY WARRANTY PROVISION PROMULGATED BY THE
FEDERAL TRADE COMMISSION PURSUANT TO RULES OR ANY OTHER LAW RELATIVE THERETO
ARE EXPRESSLY INCORPORATED HEREIN. TO THE EXTENT ANY PROVISIONS OF THIS LIMITED
WARRANTY ARE INCONSISTENT WITH STATE OR PROVINCIAL LAWS, ONLY THOSE PARTS
INCONSISTENT ARE VOID.
L.A. West, Inc.
Customer Care and Aftersales Service
196 Crawford Rd.
Statesville, NC 28625
www.lawestcoaches.com

3
Delivery
Throughout the entire manufacturing process, your L.A. West vehicle has been regularly
inspected by our qualified personnel to assure you of the finest product of the highest quality,
without exception. However, the final inspection at our factory is not to be the last one. The
pre-delivery inspection and system check that your dealer performs are the final inspections
done to your particular vehicle prior to you actually receiving your new Z Coach. Your dealer is
also available to assist you in understanding the warranties and completing the necessary
forms to activate the warranties for the various accessories installed in your vehicle.
Dealer Responsibilities
1. A pre-delivery inspection and systems check is performed to assure a thorough
inspection of the vehicle and to assure the proper operation of all factory-installed
components.
2. A customer walk-through is performed to familiarize the new customer with the
vehicle, its systems and components, and their proper and safe operation.
3. Delivery of the Owner’s Information Package which contains warranty cards and
registrations for the vehicle and all factory-installed components from other vendors and
suppliers to L.A. West. The detailed operation instructions and maintenance instructions
on these components are also included in this package.
4. Assisting the customer in completing the registration forms to avoid loss of warranty
coverage. The dealer should review the limited-warranty provisions with the customer to
stress the importance of completing the warranty cards and registration forms for the
components in the vehicle to enable the manufacturers to receive them within the
prescribed time limits.
5. Providing the customer with information regarding warranty and non-warranty work on
the vehicle and its separately warranted components.
Customer Responsibilities
The customer is responsible for regular and proper maintenance of the vehicle. Properly
maintaining your vehicle will prevent conditions arising from neglect that are not covered
by your L.A. West limited warranty. The maintenance guidelines in this manual and any
other, applicable manual(s) should be followed It is your responsibility to return the
vehicle to an authorized dealer for repairs and service. To assist you in avoiding
problems with your vehicle, it is recommended that you do the following:
1. Read the warranty. Go over it thoroughly with your dealer to make sure you
understand all the terms and conditions of the warranty.
2. Please ask questions about anything you do not fully understand about your vehicle.
L.A. West is here to serve you and assure that you have all the information necessary
for your safe and enjoyable use of your new vehicle.
3. When you are taking delivery, set an appointment for adjustments. This appointment
should be within two weeks after you accept delivery.

4
4. You are responsible for and are expected to use your vehicle in a responsible, safe
manner. Please take the time to familiarize yourself with the proper operation of the
vehicle and all its features before you attempt to use your vehicle.
Contact your authorized dealer for service and warranty of your L.A. West vehicle.
L.A. West Limited Warranty
The terms and conditions of the limited warranty are set forth in the L.A. West Limited
Warranty. Please read your L.A. West Limited Warranty carefully and familiarize yourself
with what it covers. If you haven’t received a copy of the complete Limited Warranty
statement, request a copy from your dealer.
The chassis and certain other components in a L.A. West build are under warranty by the
chassis manufacturer and/or component manufacturers.
This owner’s manual is NOT a warranty.
Chassis Warranty
Your vehicle chassis is warranted by the manufacturer. The information packet included
in your bus will contain the chassis owner’s manual and warranty information for the
chassis.
Other Warranties
Some of the components in or on your bus have their own warranties. In some cases,
separate warranty cards may need to be completed and mailed to activate these
warranties.
If, after reviewing the warranties, you have questions about coverage included in the
L.A. West Limited Warranty, coverage by the chassis manufacturer or warranty
coverage by others, please ask your dealer.
Vehicle Identification Number (VIN)
This number is the identification number for the chassis manufacturer. The VIN number
is located on the Vehicle Safety Certification Label and stamped on a tag located in the
upper left-hand corner of the dash at the windshield area.

5
Safety Warnings and Precautions
Your L.A. West vehicle is designed and manufactured to provide you with various custom
features as well as provide you with comfortable and safe transportation. We have indicated
throughout this owner’s manual how to safely operate and use the variety of features on
your bus. Please take time to read this owner’s manual, as well as the chassis owner’s
manual to become familiar with the features of your vehicle and please pay special attention
to the notes and instructions that explain important safety precautions.
Caution Symbol
Whenever you see this “ CAUTION”, exercise caution and follow the instruction
provided throughout this manual. Failure to do so could cause you or other people to be
seriously injured or killed.
Notice: This indicates there is something that could damage your vehicle.
We Care About Our Customers
Because we care about you and your passengers, we urge you to review and follow the safety
warnings and precautions listed on below.
Safety Alert
1. Read your vehicle chassis owner’s manual. It covers many important safety points in
addition to operating instructions.
2. Make sure the seating is properly secured before the vehicle is put into motion.
3. Never disconnect safety devices installed on your L.A. West unit. These devices are
for your protection and should not be tampered with.
4. All seat release, slide and recline mechanisms must be fully engaged and locked
when the bus is in motion.
5. Have passengers keep fingers and hands away from any pivot points or moving
components to avoid personal injury.
6. Entry steps, bumper steps and running boards may become slippery during wet,
snowy or icy conditions and caution needs to be used during these conditions.
7. Don’t overload the bus. Refer to weight and loading restrictions.
8. Check clearances for any overhead obstructions like bridges, branches, overhead
doors, low hanging wires, etc.

6
Be Prepared for Emergencies
To provide the maximum safety for you and your passengers, it is important that everyone
using and riding in the vehicle is familiar with emergency features such as the location of exits.
It is the driver’s responsibility to make sure everyone is familiar with and understands the
escape routes of the bus.
Escape Routes
Optional Emergency Escape Windows
Are marked with a red sticker that states “EMERGENCY EXIT”
and has bright red release latches. Instructions are listed on
the window.
Emergency Escape Hatch
Located in the ceiling with release handles to help open. Instructions are listed on the
hatch.
Emergency Doors
Can be located in the rear, side or front and with a red “EMERGENCY EXIT” sticker
above them. They are opened by pulling the handle and pushing outward.
Optional Fire Extinguisher(s)
Fire extinguishers are recommended for small fires only.
Read the label for basic instructions and the owner’s guide supplied with the fire
extinguisher for complete details on proper use and operations before using the bus.
Fire Prevention Suggestions:
• DO NOT overload electrical wiring.
• DO NOT replace a fuse with one of a higher amp rating.
•DO NOT store flammable liquids inside the vehicle.
• DO NOT park over papers, leaves, dry grass or other things that can be ignited if
touched by hot exhaust parts under your vehicle.
Park Safely
In heavy snow or blizzard conditions make sure you clear away any snow around the
base of your vehicle, especially anything blocking the exhaust pipe. Keep checking to
make sure snow has not collected there.
CAUTION: Engine exhaust can kill you and others in the vehicle. It contains the gas
carbon monoxide (CO) which you cannot see or smell. It will cause unconsciousness
and/or death. If you ever suspect exhaust coming into the vehicle have it checked and
repaired immediately.

7
Vehicle Safety Standard Certification Labels
Vehicle Weight and Loading Restrictions Label
Provides the following information:
•Name of the body manufacturer (MFG BY)
•The month and year the body was manufactured (DATE OF MFG.)
•Weight and Loading Restrictions: (GVWR, GAWR-FRONT, GAWR-REAR)
•Certification Statement (MO and YR)
•Vehicle Identification Number
•Vehicle Type
The weight and loading restrictions are specified by the chassis manufacturer.
These loads are defined by the Gross Axle Weight Rating (GAWR). The GAWR is the
value of the load carrying capacity of a single axle system. It is measured by the
tire/ground interface, plus the Gross Vehicle Weight Rating (GVWR), which is the
maximum permissible load/weight of the bus.
Weighing the Unit
The weight of the empty vehicle will vary based on the equipment and options which are
installed on your particular bus. Properly loaded vehicles will perform better, handle
more safely and give you peak performance from your tires.
It is your responsibility to weigh the vehicle while empty and again when fully loaded
including fuels and other fluids, to ensure it stays within weight limitations. Weigh the unit
from time to time to make sure the bus stays within its gross vehicle weight limitations.
CAUTION: Do not exceed the GVWR. Overloading can cause a potential safety
hazard. The driving ability and the handling of the unit could be greatly altered or
affected if your unit is overloaded.
CAUTION: Overloading can cause your tires to overheat resulting in too much
friction and you could have an air-out which could result in a serious accident. Be sure
that the overall weight, including passengers, equipment and supplies etc., does not
cause your bus to exceed axle loads as well as the overall vehicle loads specified for
your particular bus.
Notice: Overloading can cause parts to break and/or shorten the life of your vehicle.
Your warranty does not cover parts or components that have failed due to overloading.

8
Electrical Features
Your vehicle may feature a 12 VDC system. This system allows the ability to control circuits
from multiple locations in the coach. Each switch allows you to turn a circuit on or off with
individual button presses and provides an indicator light to tell you the status of the circuit (i.e.
whether it is on or off).
12 Volt DC (VDC) Receptacles USB Receptacles
Your L.A. West vehicle may be equipped with a 12 VDC receptacles conveniently
located at various locations. This 12 VDC receptacle can be used for providing power to
various items, such as cellular phones, personal computers, or portable communications
equipment. This receptacle is usually found on the sidewall next to the passenger’s seat
so that it is conveniently available to be used by the passengers. This receptacle
accommodates the “cigarette-lighter” type of connector. Your Z Coach may be equipped
with USB ports conveniently located on the front dashboard. These ports allow for easy
access when charging cell phones, laptop computers, iPods, iPads or other tablets.
Optional Converter/Inverter
Your L.A. West vehicle may be equipped with a 2000 watt inverter. The control panel for
the inverter/charger is located under the rear passenger seat. Please refer to the
Invertor’s Owner’s Manual in your owner’s package for more detailed operating
instructions.
120 Volt (VAC) AC Receptacles
Your L.A. West vehicle maybe equipped with several 120 VAC receptacles located
throughout the interior of the vehicle. These 120 VAC receptacles are of the “three-
prong” variety. The third prong being a grounding pin which provides adequate
grounding to protect one from any electrical shock. For these
receptacles to work properly, do not use an adapter, cheater, or
extension cord which defeats the function of the grounding pin.
For the same reason, never remove or bend away the ground
prong or pin from any three prong AC plug so that it would fit a
two-prong AC receptacle (i.e., an ungrounded AC receptacle).
Never operate the Z Coach if there is an electrical short present,
as an electrical short may deliver an electrical shock to anyone coming in contact with
the exterior of the unit. Do not reconnect the 120 VAC power until after that electrical
fault is fixed—the grounding circuit must be continuous from the frame to the distribution
panel, to the power cord, and to the earth ground so that electrical-shock protection is
realized.
Circuit Breakers
The 12 VDC circuit breakers are located under the driver’s seat. When the circuit
breakers are shut down or electrically tripped, they must be manually reset. These
breakers protect the 12-volt rear lighting and the 12 VDC components in your vehicle.
As needed, manually reset the circuit breaker or breakers. Be careful when working
around these connections as an accidental electrical short to ground (i.e., momentarily
connecting the “positive” or “hot” terminal to any part of the chassis) can be hazardous
and harmful.

9
Pre-Travel Instructions
It is the driver’s responsibility to understand the complete operation of the bus. Failure to
follow the proper procedures could affect the performance of the bus and/or affect the safety
of the passengers.
Review this Operations/Service Manual
It is important for you as well as your passengers to understand and be familiar with the
operations, procedures, preparations and check lists that are recommended throughout
this manual. Knowing the vehicle is the key to gaining maximum efficiency.
Read the Chassis Owner’s Manual
The chassis owner’s manual will explain all the features of the factory instrument panel
as well as the warning systems that let you know everything is working properly and
what to check if not. It will also have driving tips and other useful tips such as information
on starting, shifting, braking and roadside emergency information.
Before You Drive Away
Plan your trip and prepare as much as you can before you leave. Chart your route by
consulting maps and guidebooks as to the condition of the roads and other
circumstances such as low bridges or tunnels. Listed below are recommendations
concerning some of the things you may want to do before you set out on your trip.
• Check your tires, wheels and lug nuts for proper tightness or excessive wear.
•Check all fluid levels and hoses for damage or wear.
• Check mechanical functions such as proper brake operations etc.
• Check battery(s) for proper charge and proper cable connections or physical damage.
• Check for the proper amount of antifreeze/coolant in your radiator.
• Test lights inside and out including clearance, stop, turn signals, flashers and backup,
etc.
• Close and secure all doors.
Driving Tips
• Allow for the length and width of the vehicle.
• Always allow extra room when turning a corner or changing lanes.
• Check the side mirrors often. Learn to use the view of the roadway behind, as seen
through the side mirrors, as a reference to keep a good lane position.
• Avoid sudden maneuvers when passing another vehicle. Check rear view mirrors and
signal lane change before passing.
• Drive with consideration on the highway, observing speed and safety regulations.
• Allow a safe distance in which to stop your vehicle, never follow another vehicle too
close.

10
• Observe proper vehicle speeds when ascending or descending hills and always
operate in the proper transmission range.
• Allow for the extra height of your vehicle and avoid areas having low overhead
clearance.
Exterior Components, Operations and Care
This section explains the basic features of the exterior components and will help you become
familiar with operations, procedures and recommended care and maintenance.
•Daily washing will not only enhance the look of the bus, but help maintain the exterior
components.
• Using a hose to wet it down and wiping the surface with a sponge or cloth can easily
clean the exterior.
• Never use harsh abrasives or strong solvents on the exterior.
Roof Area
•The sealants and adhesives used on the roof area are formulated to remain waterproof
under the sustained effects of the weather and road vibrations.
•Periodically inspect the roof paying special attention to possible scrapes or cuts caused
by tree limbs or other overhanging obstructions.
Note: If there is evidence of cuts or scrapes in the sealants or adhesives please
contact your dealer for repair or to provide the correct materials to make a repair
yourself.
Fiberglass or ABS Areas
The components such as the front cap area are made either with fiberglass or ABS
materials. Exposure to sunlight, water, dust and chemicals can cause caulking,
discoloration or yellowing.
•Proper maintenance of these areas will minimize these problems:
• Wash often with a mild detergent.
• Wax at least once a year with a wax that is specifically produced for fiberglass or ABS
plastics.
Seams and Moldings
The sealants and adhesives used on the seams are formulated to remain waterproof
under the sustained effects of the weather and road vibrations.
• At least every 90 days check all seams and moldings for missing areas, damages,
scrapes, cuts or cracking.
• If there is evidence of missing areas damage, cuts or scrapes in either the sealant or
adhesive please contact your dealer for repair or for the correct materials to make a
repair yourself.

11
Emergency Escape Routes
Escape Hatch
It is located in the roof area to be used only in the event of an emergency and is
equipped with release handles that open the hatch.
Note: Instructions are listed on the hatch. For everyone’s safety frequently check for
proper operations.
Optional Emergency Exit Egress window
•Can be identified by the “Emergency Exit” label on the glass and has two (2) red
release handles.
• In an emergency release red handles, rotate them away from the window and push out
to swing window up.
• To close reverse the operation make sure the window is tight against the frame.
Note: Instructions are on each window. For everyone’s safety frequently check the
operations.
•Daily inspect operations and mechanisms to ensure they are all in good working order.
If any problems are found, have repaired immediately to help ensure the safety of your
passengers.
•Latches and Mechanisms- Inspect for damage, worn or loose parts. Replace as
necessary. Lubricate hard to move latches with white lithium grease.
•Emergency Decal- Check to see that the decals are in place and the instructions are
legible. If decals are missing or cannot be clearly read call your dealer to order new.
• Seals- Inspect for damages and worn or loose areas and replace as necessary. Using
a silicone based spray will clean and condition the seals
• Glass and Shrouding - Inspect for cracks and chips. Clean window with all-purpose
glass cleaner and use a mild soap on the ABS shrouding.
CAUTION: Emergency windows and escape hatch must be checked for proper
operations before each trip. Someone could be serious injured and or/killed if the
window or hatch operations failed and they were unable to escape the bus during an
emergency.
CAUTION: Never allow an emergency egress window or hatch to be open or opened
when the unit is in motion. This could result in someone being seriously injured and/or
killed.

12
Passenger Windows
Full View Curb Window
This window is located in front of the entry door curbside, which allows the driver to see
the curb and any passengers in that area while in a seated position.
Window Maintenance
Daily check all moving parts on and around the window and latch areas. Daily inspect
glass for damages, cracks or chips that could result from road debris, such as stones.
Repair or replace the glass as necessary. Clean by using a standard glass cleaner or an
ammonia based solution and a soft cloth to remove the road film and dirt.
Doors
The original factory driver’s door is utilized on all models and the passenger door is also used
on some models. All other entry doors are installed by L.A. West.
Door Emergency Release Handle
This release handle is used to disengage the electric door mechanism allowing the door
to be manually opened in the event of a loss of power. It is located above the door and is
marked by an “Emergency Exit” label with instruction on releasing. To release pull as
directed on the label
CAUTION: Do not move the bus if the Emergency Release Handle is not in the
secured locked position. The door could open while driving and injure someone.
CAUTION: Make sure the outer door area is clear. Doors open outwards which could
cause anyone in that area to be struck by the doors causing injury.
Notice: Do not move the bus if the Emergency Release Handle is not in the secured
locked position. The door could open while driving and damage to the door area.
Optional Remote Control
Your bus may be equipped with remote controls on your key fob to open and close your
passenger entry door.
Rear Luggage Compartment
Your luggage compartment will have two courtesy lights.
Auxiliary Battery
The auxiliary battery location is typically on the driver side of the vehicle under the hood.

13
Maintaining the Doors
Before each trip inspect the door operations to ensure they are working properly. The
following are items that need to be frequently inspected to ensure the doors remain in good
working order.
• Manual Door Operations- Inspect daily the door mechanism for loose or damaged
parts. Open and close to see that the door is moving smoothly closes properly and the
door mechanism (handle) latches properly when closed. Repair, replace or adjust as
necessary.
• Electric Door Operations- Inspect daily to ensure the door power mechanisms are
working properly. Open and close the door using the console switch and then again
using the remote control. If door is not operating properly have adjusted or repaired as
necessary.
• Emergency Door Release: (Red handle)- Inspect daily to ensure that the door opens
manually when the red handle is released. Then secure the handle and check interior
and exterior switch operation.
Note: A daily inspection should be made to ensure the Emergency Door decal is in
place. If missing or unreadable contact your dealer.
• Door Alignment- Check daily to ensure the door is closing properly and the seals are in
proper alignment when closed. Check all nuts and bolts for tightness and have realigned
as necessary.
• Door Handle Operation- Check daily, adjust or replace as necessary.
• Lock Sets, Latches and Hardware- Check daily for damage or worn areas, replace as
necessary. Apply lubricants at least every 6 months. If vehicle is exposed to salt air
lubricate more often.
• Key Holes- Lubricate with powdered graphite squirted directly in the keyhole.
• Latches- Lubricate with a white lithium grease applied on all attaching mechanisms
• Hinges- Lubricate with a silicone-based product directly applied to the hinges.
• Door Pins- Lubricate with a light machine oil.
• Glass Panels/Windows- Inspect daily for damage or looseness. Clean daily or as
needed. Use a standard ammonia based solution or glass cleaner and a soft cloth to
remove road film and dirt.
• Brushes and Pivot Points- Inspect daily for damaged, worn or loose parts. Tighten any
loose areas such as bolts, hinges, pins, nuts etc. or replace parts as necessary.
• Aluminum Components- Clean as needed. Use a mild all-purpose cleaner and wipe
dry.
• Door Seals- Check daily and replace if damaged or worn. Use a silicone based spray
weekly to lightly coat the door seal surfaces.

14
• Rubber or Neoprene Extrusions- Check daily for cracks and worn areas replace as
necessary. Clean regularly using a nonabrasive, noncorrosive all-purpose cleaner,
followed by a vinyl protector.
CAUTION: Before each trip inspect the latches, handles, and mechanical operations of
the Emergency Doors. If these items are not in proper working order and an accident
occurred, someone could be trapped inside the bus resulting in serious injuries and/or
death.
Door Components
Entry Door
Door Seal
Door Glass
Step Tread
Edge Seal

15
Mirrors
•Mirrors should be properly adjusted so you can get the maximum view around and
behind the vehicle.
•Manual mirrors need to be adjusted manually at the mirror head.
•Power and/or heated mirrors can be adjusted by pushing the switch on the interior
console.
•Inspect daily to ensure that the mirrors heads brackets and support arms are secure
and the bolts and mounting brackets are not damaged or loose. Secure or replace items
as necessary.
• Adjust daily to ensure there is a clear view for the driver.
•Check power operations mechanisms where applicable. Adjust as necessary.
• Clean the glass with standard glass cleaner and the mirror head and brackets can be
cleaned with a nonabrasive detergent.
Note: Using the heated portion of the mirror during warm weather can cause the convex
mirror to become unglued and fall off.
Lower A/C Condenser Unit
This unit is located in the lower portion of the bus. Dirt leaves and debris can build up on the
condenser which would restrict the efficiency of the unit.
• Inspect the unit daily for items that may be trapped in this area.
• By using a high-pressure air or water hose you should remove most items that may be
trapped in this area.
Notice: To avoid damage to the unit be sure the engine is off and no power is supplied
to the unit before attempting to clean.
Batteries/Battery Box
Read the information provided by the battery manufacturer as to the care maintenance and
check point. This information is in your owner’s information packet.
Underbody Area
Road debris, dirt and salt on the underbody can accelerate corrosion of the components under
the vehicle such as the frame, suspension, exhaust parts, etc.
• Daily inspection for road debris, dirt and salt on the underbody should be performed. If
necessary spray wash the underside of the bus with warm soapy water to remove the
dirt, etc.
