L.L.Bean 0KSV1 User manual

INTRODUCTION
Thank you for selecting this Weather Station.
NOTE Please keep this manual handy as you use
your new product. It contains practical step-by-step
instructions, as well as technical specifications and
warnings you should know about.
OVERVIEW
FRONT VIEW
2
1
6
8
9
7
3
4
5
1. Solar panel
2. Remote sensor reception indicator
3. Indoor temperature
4. MODE: Change settings / display
5. / : Increase / decrease value; activate /
deactivate clock reception signal; : toggle
between outdoor channels (1-3)
6. Outdoor temperature
7. Time zone
8. Clock with weekday
9. MEM: View current, maximum and minimum
temperature
BACK VIEW
1
2
Solar First Watch Weather Station
with Indoor / Outdoor Temperature
Model:0KSV1
USER MANUAL
1. RESET: Reset unit to default settings
2. °C / °F: Select temperature
REMOTE SENSOR
1
2
34
5
1. LED status indicator
2. Wall mount hole
3. Battery compartment
4. RESET hole
5. CHANNEL switch
GETTING STARTED
IMPORTANT Set up the remote outdoor sensor
first before setting the main unit.
REMOTE SENSOR – INSERT BATTERIES
The main unit can collect data from up to 3 sensors.
To set up the sensor:
1. Open the battery compartment.
2. Insert the battery, matching the polarities.
3. Select a channel then press RESET.
4. Close the battery door.
5. Place the sensor within 30 m (98 ft) of the main
unit using the table stand or wall mount.
TIP Ideal placements for the sensor would be in
any location on the exterior of the home at a height
of not more than 1.5 m (5 ft) and which can shield it
from direct sunlight or wet conditions for an accurate
reading.
1.5 m (5 ft)
NOTE
• Press RESET after each battery change or channel
selection.
• Use alkaline batteries for longer usage and
consumer grade lithium batteries in temperatures
below freezing.
MAIN UNIT – INSERT BATTERIES
1. Remove the battery compartment.
2. Insert the batteries, matching the polarities.
3. Press RESET after each battery change.
LOCATION MEANING
Clock / alarm Main unit batteries
low
Outdoor temperature Sensor battery low
EN
MAIN UNIT - SOLAR PANEL
The solar panel is an energy saving feature, which is
an environmentally friendly way to provide additional
power to the main unit and prolongs battery life. How-
ever, it cannot replace battery power entirely.
SENSOR DATA TRANSMISSION
To search for a sensor:
Press and hold + MODE.
The sensor reception icon in the remote sensor
area shows the status:
ICON DESCRIPTION
Main unit is searching for
sensor(s).
A channel has been found.
The sensor cannot be
found.
TIP The transmission range may vary depending
on many factors. You may need to experiment with
various locations to get the best results.
MANUALLY SET CLOCK
To set the clock manually:
1. Press and hold MODE.
2. Press or to change the settings.
3. Press MODE to confirm.
4. The settings order is: time zone,12/24 hr format,
hour, minute, year, calendar mode (day – month /
month – day), month, day and language.
Time zone offset sets the clock +/- 23 hours from the
received clock signal time.
Select the time zone: (P) Pacific, (E) Eastern, (C)
Central or (M) Mountain.
NOTE The language options are English (E), Ger-
man (D), French (F), Italian (I), Spanish (S) and
Russian (R).
To select display mode:
Press MODE to choose between clock with seconds,
clock with weekday or calendar.
TEMPERATURE
To toggle temperature unit:
Press °C / °F.
To toggle between each outdoor sensor’s readings:
Press repeatedly.
OR
Press and hold + MEM for 2 seconds to initiate auto
toggle of outdoor channels.
To end press .
To toggle between current, minimum and maxi-
mum records:
Press MEM repeatedly.
To clear the records:
Press and hold MEM.
RESET
Press RESET to return to the default settings.
PRECAUTIONS
• Do not subject the unit to excessive force, shock,
dust, temperature or humidity.
• Do not cover the ventilation holes with any items
such as newspapers, curtains etc.
• Do not immerse the unit in water. If you spill liquid
over it, dry it immediately with a soft, lint-free
cloth.
• Do not clean the unit with abrasive or corrosive
materials.
• Do not tamper with the unit’s internal components.
This invalidates the warranty.
• Only use fresh batteries. Do not mix new and old
batteries.
• Images shown in this manual may differ from the
actual display.
• When disposing of this product, ensure it is
RAR802_MANUAL R3.indd 1 1/6/12 11:40:37

P/N:300102858-00003-10
collected separately for special treatment and not
as normal household waste.
• Placement of this product on certain types of
wood may result in damage to its finish for which
Oregon Scientific will not be responsible. Consult
the furniture manufacturer’s care instructions for
information.
• The contents of this manual may not be reproduced
without the permission of the manufacturer.
• Do not dispose old batteries as unsorted municipal
waste. Collection of such waste separately for
special treatment is necessary.
• Please note that some units are equipped with
a battery safety strip. Remove the strip from the
battery compartment before first use.
NOTE The technical specifications for this product
and the contents of the user manual are subject to
change without notice.
NOTE Features and accessories will not be available
in all countries. For more information, please contact
your local retailer.
SPECIFICATIONS
TYPE DESCRIPTION
MAIN UNIT
L x W x H 75 x 33 x 120 mm
(2.95 x 1.30 x 4.72 in)
Weight 112 g (3.95 oz)
without battery
Temperature range -5°C/23°F to 50°C/122°F
Signal frequency 433 MHz
Power 2 x UM-4 (AAA) 1.5 V
batteries
REMOTE UNIT (THN132N)
L x W x H 96 x 50 x 22 mm
(3.78 x 1.97 x 0.87 in)
Weight 62g (2.22 ounces)
Transmission range 30m (98 ft) unobstructed
Temperature range
-20°C/-4°F to 60°C/140°F
(Alkaline batteries)
-30°C/-22°F to 60°C/140°F
(Lithium batteries)
Power 1 x UM-3 (AA) 1.5 V
batteries
L.L.BEAN GUARANTEE
Our products are guaranteed to give 100% satisfaction
in every way. Return anything purchased from us at
anytime if it proves otherwise. We do not want you to
have anything from L.L. Bean that is not completely
satisfactory.
The L.L. Bean 24hr customer service number is:
1-800-341-4341.
