L2 LT52N1BWWC User manual

Before using your new product, please read these instructions to prevent any damage.
Top-Load Washer
MODEL:
LT52N1BWWC

Troubleshooting...........................................................................................
Appendix......................................................................................................
Technical specifications.............................................. .........
................... ..................
23
26
27
*** If your user manual lost or broken,you could get it from dealers.
Cleaning the exterior...............................................................................
................................................................................Cleaning the interior
.........................Cleaning the detergent, bleach, softener compartmens
Storing your washer................................................................................
Tub clean................................................................................................
22
22
22
22
22
Check these solutions if your washer..................................................... 23
Fabric Care Chart................................................................................... 26
Contents
Contents
Installation.....................................................................................................
Removing from the package....................................................................
Package list.............................................................................................
Tools and parts needed in installation......................................................
Parts identification....................................................................................
Location requirements.............................................................................
Installation steps......................................................................................
Operation......................................................................................................
Control Panel...........................................................................................
Washing a load of laundry........................................................................
Program Function....................................................................................
Maintenance.................................................................................................
9
9
9
9
10
11
14
17
17
19
21
22
12
Safety Instructions ........................................................................................
Safety Instructions
....................................................................
................................................................................... 2
2
3
4
5
5
Explanation of the symbols
The electric shock
Risk to children
Installing the product
Risk of explosion
Risk of damaging appliance
Operating the appliance
Packaging/Old appliance
...................................................................................
...................................................................................
...................................................................................
...............................................................................
....................................................................
.........................................................................
........................................................................
6
6
7
8
For your safety, the information in this manual must be followed
to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, personal injury or loss of life.
• This appliance is not intended for use by persons(including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge unless they have
been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
•
•
•
• The openings must not be obstructed by a carpet.
• This appliance is intended to be used in household and similar
applications such as:
− staff kitchen areas in shops, offices and other working environments;
− farm houses;
− by clients in hotels, motels and other residential type environments;
− bed and breakfast type environments;
− areas for communal use in blocks of flats or in launderettes.
Children should be supervised to ensure that they do not
play with the appliance.
The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS

34
Warning!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
death or serious injuries unless it’s avoided.
Explanation of the symbols
Caution!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries or damage to property and the
environment.
Note!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries.
The electric shock
•
•
• Hands shall not be inserted into running spin-dry tub .
• If the spin-dry tub does not stop within 15 seconds after
opening the cover, please stop using the machine and
have it repaired.
• Before any maintenance the device, unplug the appliance
from the mains.
• Always unplug the machine and turn off the water supply
after use. The max. inlet water pressure, in pascals. The
min. inlet water pressure, in pascals.
• To ensure your safety, power plug must be inserted into
an earthed three-pole socket. Check carefully and make sure
that your socket is properly and reliably earthed.
• Make sure that the water and electrical devices must be
connected by a qualified technician in accordance with the
manufacturer's instructions and local safety regulations.
Do not put washing machine at humid place.
This appliance is for indoor use only.
Warning!
SAFETY INSTRUCTIONSSAFETY INSTRUCTIONS
This graphic represents CAUSE ATTENTION, and detailed cautions will
be displayed in side the graphic .
This graphic represents OPERATION PROHIBITED, and detailed
prohibitive items will be displayed in side the graphic .
This graphic represents FORBIDDEN EXECUTION, and detailed
forbidden execution items will be displayed inside the graphic .
Model
120V~ /60Hz
680W 58kg
Rated power supply
Rated power
Overall dimensions(mm)
Weight of whole machine
Current draw
Pulsator type Drum grain
Display type Display color
Motor
LT52N1BWWC
1114 x 686 x 726
Agitator
LED
Ellipse
Red
Series
10A

56
• EN countries: the appliance can be used by children aged
from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• Animals and children may climb into the machine. Check
the machine before every operation.
• Young children should be supervised that they do not play
with the appliance.
• Machine may be very hot during the operation. Keep kids
and pets far away from the machine during the operation
• Plug must be accessible after installation.
very wet rooms as well as in the rooms with explosive or
caustic gas.
•
• The washing machine with single inlet valve only can be
connected to the cold water supply. The product
inlet valves should be correctly connected to the hot water
and cold water supply.
with double
Remove all packages before using the appliance. Otherwise,
serious damage may result.
Risk of explosion
•
•
Do not wash or dry articles that have been cleaned in, washed
in, soaked in, or dabbed with combustible or explosive
substances( such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents, kerosene, etc.) This may result in
fire or explosion.
Before hand thoroughly rinse items of washing by hand.
Risk to children
• This washing machine is for indoor use only.
• It isn't intended to be built-in using.
• The openings must not be obstructed by a carpet.
• Washing machine shall not be installed in bath room or
very wet rooms as well as in the rooms with explosive
or caustic gases.
• Remove all packages and transport bolts before using
the appliance. Otherwise, serious damage may result.
• The washing machine with single inlet valve only can be
connected to the cold water supply. The product with
double inlet valves should be correctly connected to the
hot water and cold water supply.
• Plug must be accessible after installation.
Risk of damaging appliance
Caution
Installing the product
• Your product is only for home use and is only designed
for the textiles suitable for machine washing.
• Do not climb up and sit on top cover of the machine.
• Do not lean against machine door.
• Cautions during Handling Machine:
1.Transport bolts shall be reinstalled to the machine by
a specialized person.
2.The accumulated water shall be drained out of the
machine.
3.Handle the machine carefully. Never hold each protruded
part on the machine while lifting. Machine door can
not be used as the handle during the conveyance.
4.This appliance is heavy. Transport with care.
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS

78
Operating the appliance
• Before washing the clothes at first time, the product
shall be operated in one round of the whole procedures
without the clothes inside.
• Flammable and explosive or toxic solvents are forbidden.
Gasoline and alcohol etc.Shall not be used as detergents.
Please only select the detergents suitable for machine
washing, especially for drum.
• Make sure that all pockets are emptied. Sharp and rigid
items such as coin, brooch, nail, screw or stone etc. may
cause serious damages to this machine.
• Please check whether the water inside the drum has
been drained before opening its door.Please do not open
the door if there is any water visible.
• Be careful of burning when the product drains hot
washing water.
• Never refill the water by hand during washing.
• After the program is completed, Please wait for two
minutes to open the door.
This marking indicates that this product should not be
disposed
with other household wastes throughout the
EU.To prevent possible harm to the environment or
human health from uncontrolled waste disposal,recycle
it responsibly to promote the sustainable reuse of
material resources.To return your used device, please use
the collection systems or contact the retailer where the
product was purchased. They return and can take this
product for environmental safe recycling.
• Please do not close the door with excessive forces.
• It is forbidden to wash carpets.
Packaging/Old appliance
SAFETY INSTRUCTIONS
Risk of damaging appliance
SAFETY INSTRUCTIONS

InstallationInstallation
Removing from the package
Remove the package and take out the machine from the carton box and foam cushion.
Open the lid of washer to take out all accessories including a protection foam.
Packaging materials can be dangerous to children;
Keep all packaging material (plastic bags, polystyrene, etc.) well out of children’s
reach.
Do not operate this appliance on the foam cushion.
- Failing to do so will result in serious vibration.
Package list
TOOLS and PARTS needed in installation
WARNING
Parts identification
Base foam cushion Protection foam
Hose holder Owner’s manual
Pliers level Water inlet hoses
Faucet and Water inlet hose
(Not supplied)
Power cord
water inlet valve
Drainage hole
Drainage hose and holder
Control panel
Top lid
Cabinet
Adjustable leg
Look through window
Bleach
compartment Detergent compartment
Powder
Softener compartment
Drain hose
910
Door locker
flat screwdriver Phillips screwdriver
Hose clamp+Screw
(x2)
Clamp

InstallationInstallation
Location Requirements
Flooring
For best performance, you must install your washer on a solidly constructed floor. Wood
floors may need to be reinforced to minimize vibration and/or unbalanced load situations.
- Carpeting and soft tile surfaces are contributing factors to vibration which can cause
your washer to move slightly during the spin cycle.
NEVER INSTALL ON A PLATFORM OR WEAKLY SUPPORTED STRUCTURE.
CAUTION
Drain facility
The recommended height of the standpipe is 48in. / 120cm.
The suitable drainage is available in various up to 96in. / 240cm.
The drain hose must be routed through the drain hose clip to the standpipe.
The standpipe must be large enough to accept the outside diameter of the drain hose.
The drain hose is attached to the washer at the factory.
height
Room for washer
Required dimensions for installation
Closet or Door
48 in.² *
( )310 cm²
24 in² . *
( )155 cm² 3 in.
( . )76 cm
* Required spacing
Location Requirements
Electric
- Individual branch circuit serving only for your washer is recommended.
- Your washer is equipped with a power cord.
NEVER USE AN EXTENSION CORD.
CAUTION
Grounding
ELECTRICAL GROUNDING IS REQUIRED FOR THIS APPLIANCE.
- This appliance must be grounded. In the event of malfunction or breakdown, grounding
will reduce the risk of electric shock by providing a path of least resistance for electric
current.
- This appliance is equipped with a power cord having a three-prong grounding plug for
use in a properly installed and grounded outlet.
- The plug must be plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
An improperly connected equipment-grounding conductor can increase the risk of
electrical shock. Check with a qualified electrician or serviceman if you are not
sure whether the appliance is properly grounded. Do not modify the plug provided
with the appliance.
- If it does not fit the outlet, have a proper outlet installed by a qualified electrician.
To prevent unnecessary risk of fire, electrical shock or personal injury, all wiring
and grounding must be done in accordance with the National Electrical Code
ANSI/FNPA, No.70 Latest Revision and local codes and ordinances. It is the
personal responsibility of the appliance owner to provide adequate electrical
service for this appliance.
WARNING
NEVER CONNECT THE GROUND WIRE TO PLASTIC PLUMBING LINES, GAS
LINES, OR HOT WATER PIPES.
CAUTION
Water
To correctly fill your washer in the proper amount of time, water pressure of 14 to 116psi
(100 to 800kPa) is required.
- Water pressure less than 14psi may cause water valve failure, or may not allow the
water valve to shot off completely, or may extend the fill time beyond what your washer
controls allow, causing your washer to turn off and set off an error alarm. A time limit is
built into the controls to prevent flooding in your home if a hose becomes loose.
The water faucet must be within 4 feet / 122cm of the back of your washer to match the
inlet hoses.
Inlet hoses are available in various lengths up to 8 feet / 240cm for faucets that are
further away from the back of your washer.
To avoid the possibility of water damage:
- Have water faucets easily accessible
- Turn off faucets when the washer is not in use.
- Periodically check that there is no leakage from the water inlet hose fittings.
CHECK ALL CONNECTIONS AT THE WATER VALVE AND FAUCET FOR LEAKS.
WARNING
WARNING
Do not install your washer in areas where water may freeze, since your
washer will always retain some water in its water valve, pump, and hose
areas. Frozen water can damage the belts, the pump, hoses, and other
components.
3 in.
( . )76 cm
11
12
The electrical valve, retractor, motor and drain pump of this appliance are
intentionally not grounded and may present a risk of electric shock during serving.
Do not contact these electronic devices while the appliance is energized. 270 in. .
68.6 cm
43.9 in.
111.4cm
40.1 in.
101.8 cm
28.6 in.
72.6 cm
59.5 in.
151.2cm

InstallationInstallation
Installation Steps
STEP 1: Select a location
Before you install the washer, make sure the location:
- Has a hard, level surface without carpeting or flooring that may obstruct ventilation.
- Is away from direct sunlight.
- Has adequate ventilation.
- Is not exposed to freezing temperatures (temperature under 32 F or 0 C).
- Is away from heat sources such as oil or gas.
- Has enough space so that the washer doesn’t rest on its power cord.
These instructions should be retained for future reference.
Follow the followings STEP by STEP to ensure a successful installation.
CAUTION
o o
STEP 2: Connect the water hose
1. Connect the ends of the water supply hoses to the HOT and
COLD faucets.
2. Tighten the fittings by hand until they are snug, and then tighten
them an additional two-thirds of a turn with a wrench.
The water supply hoses are not supplied with your washer
and must be purchased separately. Before installing the
water supply hoses, make sure there are rubber gaskets
inside the fittings at both ends of each new water hose.
Installing the water supply hoses without rubber gaskets
can cause water leakage.
When you initially install the washer, be sure to use new
hoses. Failing to do so may result in a water leakage or
overflow and may damage your property.
Do not connect multiple water supply hoses together to
increase the length of the supply hose. Hoses connected
this way can leak and the leakage can cause electrical shock.
If a hose is too short, replace the hose with a longer, high
pressure hose.
CAUTION
Coupling Rubber
gasket
Cold Hot
When you fasten the fittings, do not fasten them too tightly
or apply tape or sealant to the faucets or water supply
intakes. This can damage the fittings.
After you have connected the water supply hoses to the
faucets, ensure that they are connected correctly by pulling
the water supply hoses downwards.
CAUTION
3. Place the unconnected ends of the hoses into a bucket and open
the faucets connected to the two water supply hoses for 10 or 15
seconds to remove any foreign substances from the hoses.
Close the faucets before continuing.
4. Connect the ends of the water supply hoses to the water supply
intake connections at the back of the washer.
The water supply hose connected to the HOT faucet must be
connected to the hot water supply intake and the water hose
connected to the COLD faucet must be connected to the cold
water supply intake.
CAUTION
5. Tighten the fittings by hand until they are snug, and then tighten
them an additional two-thirds of a turn with a wrench.
Confirm that the water supply hoses are not twisted or bent.
If the hoses are twisted or bent, the hoses can leak and
cause electric shock due to the water leakage.
CAUTION
Location Requirements
Minimum clearances for closet and alcove installations
Sides - 1 in. / 2.5cm Closet Front - 2 in. / 5.1cm
Rear - 6 in. / 15.2cm Top - 24 in. / 61cm
Gap between end of water valve and the wall.
- Case 1. Assemble supply hose after installing: Over 3.9 in. (10cm)
- Case 2. Assemble supply hose before installing: Over 2.8 in. (7cm)
If the washer and dryer are installed together, the closet front must have at least a 72 in
(465 cm ) unobstructed air opening. Your washer alone does not require a specific air
opening.
2
2
13
14
A Recessed area.
B. Side view - closet or confned area
24 in.
AB
1 in.
2.5cm
27 in.
68.6cm
1 in.
2.5cm
61cm
2 in.
5.1cm
28.6 in.
72.6cm
6 in.
15.2cm

Installation
Installation Steps
STEP 4: Leveling your washer
See if the washer is level by checking the position of the tub or
using a leveling gauge.
1. Slide the washer into position.
2. Open the lid of the washer, and pour the water into the tub to just
below the agitator level.
3. If the washer is level, the pulsator is positioned at the center of
the washer as shown in the figure right. If not, level your washer
by turning the front leveling feet clockwise or counterclockwise
as necessary.
Agitator
loosen lock
Adjustable legs
Your washer is grounded through the third prong of the power cord
when plugged into a 3-prong grounded electrical outlet.
STEP 5: Powering your washer
Run a test cycle as following to check if your washer is properly installed.
1. Load about 6 pounds of laundry into the tub.
2. Select the Cycles to turn on your washer.
3. Select the cycle by turning the .
4. Press the button to start the test cycle.
5. The washer should not rock or vibrate excessively when water is supplied or when
washing or spinning, and should drain well during the spin cycle.
Rinse&Spin Cycle Selector
Start/Pause
STEP 6: Running a test cycle
If water leaks while water is being supplied or drained, check the water connections.
Refer to the “ ” and “ ” section for
instructions.
If the washer rocks and vibrates excessively, level your washer again. Refer to the
“ ” section for instructions.
Connect the water hose Connect the drain hose
Leveling your washer
CAUTION
Installation
Installation Steps
To ensure the correct water usage, connect both the HOT
and COLD water faucets. If either or both are not connected,
an error code can occur.
If you do not want to use the HOT water supply hose, insert
the water intake cap into the HOT water supply intake hole.
In this case, you must select the Tap Cold option for the water
temperature.
CAUTION
6. Turn on the HOT and COLD water supplies and check all the
water supply intake connections and the faucets for water leaks.
STEP 3: Connect the drain hose
1. Connect the drain pipe onto your washer.
The drain pipe is attached as accessory with your washer.
Fail to slide the drain hose over the sewer completely
may result in water leakage.
Fail to move the hoop back will result in water leakage.
CAUTION
A. Find the clamp on one end of the drain hose. Move the
clamp forward as shown in right figure.
B. Insert the drain hose onto the washer until it contact the
pump outlet. Then move the clamp near the pump outlet.
C. Screw the clamp tightly with a flat screwdriver clockwise.
2. Position the other end of the drain hose.
It can be positioned in three ways.
A. Over the edge of a wash basin
Secure the guide to the side of the basin wall
with a hook or to the tap with a piece of string
to prevent the drain hose from moving.
B. In a standpipe
The standpipe must be no shorter than 39 in.
(99cm) and no longer than 96 in. (245cm).
C. in a laundry tub.
The laundry tub must be no shorter than 39 in.
(99cm) and no higher than 96 in. (245cm).
Standpipe
Hose
Retainer
Tie
strap
96 in. Max
39 in. Min
Laundry tub
Hose
Retainer
Tie
strap
96 in. Max
39 in. Min
Make sure that the connection between the
drain hose and the wash basin, or standpipe,
or laundry tub is not airtight.
CAUTION
15
16
DO NOT use the washing machine without leveling. It may
result in malfunction caused by the production of excess
vibration and noise.
Use the leveling feet only when you level the washing
machine. If you raise the leveling feet unnecessarily, it
may cause abnormal vibration of the washing machine.
CAUTION
Slide to here.
Fasten the Hose
clamp to the frame
with a screw.
(A)
(B)
(C)
(D)
D. Find the hose clamp, and Fasten the drain hose to the
washer frame at the indicated locations with the hose
clamps (2) provided, using a Phillips screwdriver.
Clamp

Operation
Control Panel
Operation
Control Panel
Temp.
Select the washing water temperature.
The rinsing water temperature will
always keep in Cold. There is always
one option selected for temperature,
except when the selected programs
are Tub clean, Drain&Spin.
Hot - Hot water with no cold water
added.
Warm - Mixture of hot and cold water.
Cold - Cold water with no warm water
added.
Tab Cold - Automatically selects the
water temperature according to the
selected program.
2
Start/Pause button
Press once to start the program.
Press again to pause the program. You
can Cycles and
Water Level could be changed.
Once again to restart the program.
add a garment. And only
6
17
18
Model: MAV180-A2804PS/01FM-US
Program selector
Select the appropriate program for the
type of loading.
1
Cycle status lights
The relative light will be lighted when
the washer is in its washing program,
as the soak will light when the washer
is operating in soak process.
When the whole program is finished,
the light will flash 6 times.
The door can’t be opened When the
lock light is on.
When the light was be lighted,
it means the program will be quickly
finished than normal.
8
Water level
Select the washing water level. The
rinsing water level is the same as the
washing water level. There is always
one option selected for water level,
except when the selected programs are
Tub clean, Drain&Spin.
High - Select for the large loading level.
Medium - Select for the medium loading
level.
Low - Select for the low loading level.
Auto - Automatically selects the
water level according to the loading
level.
3
7
Options selector
Select one additional program before
the machine runs. If the selector is
adjusted while the program is running,
the position of the selector will take
effect after the program has finished
running.
5
Power
Press to turn on your washer. Press again
to turn off your washer. If you leave your
washer and do not press button
within 10 minutes, your washer automatically
turns off.
1
Soil level
Select the soil level.Different soil level
settings.There is always one option selected
for Soil level,except when the selected
programs are Tub clean, Drain&Spin.
4
2 3 4 5 6 7
8

Operation Operation
Washing a load of laundry
- Loading the Bleach compartment (Liquid chlorine bleach only)
1. Add chlorine bleach to the bleach compartment.
2. DO NOT exceed the bleach compartment.
3. As no water inlet to bleach dispenser, the bleach will directly load
into the tub when you pour in.
- Avoid splashing or over-filling the compartment.
Never pour undiluted liquid chlorine bleach directly onto the
load or into the tub. It is a powerful chemical and can cause
fabric damage, such as weakening of the fibers or color loss, if
not used properly.
If you prefer to use color-safe, non-chlorine bleach, add it to the
DO NOT pour color-safe bleach into the Bleach compartment.
CAUTION
- Loading the Fabric softener compartment
1. Pour the recommended amount of liquid fabric softener into the
softener compartment.
2. The dispenser automatically releases liquid fabric softener at
the proper time during the rinse cycle.
3. If using fabric softener on NORMAL cycles, please make sure to
press the FABRIC SOFTENER button on.
CAUTION
STEP 3: Add liquid detergent and Powder to the dispenser
- Loading the liquid detergent compartmentor powder
1. Pour the recommended amount of laundry detergent directly
into the detergent compartment before starting your washer.
2. If you are using color-safe bleach, add it with the detergent
to the detergent compartment.
When adding color-safe bleach with detergent, it is best if both
laundry products are in the same form - liquid.
Detergent
compartment
Bleach
compartment
Softener
compartment
19
20
- You can fill the tub with dry, unfolded clothes. Load the tub no more
than 3/4 full.
- Overloading may reduce washing efficiency, cause excess wear,
and possibly cause creasing or wrinkling of the load.
- When washing big bulky items or a few smaller items that don’t fill
the tub completely, for example, a rug, a pillow, stuffed toys, or one
or two sweaters, add a few towels to improve spin performance.
- Do not insert bulky items except for Heavy Duty cycle.
- When washing heavily soiled loads, do not overload your washer to
ensure good cleaning results.
- To add a garment:
1. Press the button to pause the washer.
2. Wait for the door to unlock automatically, and then open the
door.
3. Add the item, close the door, and then press the
button. The cycle will resume.
Start/Pause
Start/Pause STEP 4: Select the appropriate cycle and options for the load
Use the softener compartment ONLY for liquid fabric softeners.
DO NOT use the Downy Ball in the fabric softener compartment
with this washer. It will not add fabric softener at the appropriate
time. Use the detergent compartment.
Do not use liquid fabric softener that is too sticky as it may not
mix with the water sufficiently.
●
Washing a load of laundry
To reduce the risk of fire, electric shock, or injury to persons when using your
washer, follow important safety instructions, including the following:
WARNING
STEP 1: Power on your washer
Before loading your laundry, be sure to take out coins, keys
and other hard objects, and close the zip to prevent clothes
from damage.
CAUTION
STEP 2: Load your washer
- Select any program ( ) except blank to power your washer on.
- Your washer will start up with initial setting according to user’s
choose.
- The lights will display different combination according to
different program.
Start/Pause
Powder
compartment
- Select appropriate cycle by Cycle Selector according to cycle chart on next page.
- Select appropriate option function according to cycle chart.
Delay the start of any cycle for up to 24hours in one-hour increments.
Displayed hour indicates the time the wash will be started.
Press once to get the highest water level.
Press again to cancel selection.
Note: when the machine start , the function can not be cancled.
There will be no change if the water level has been the highest.
Press once to add an extra rinse into the washing program.
Press again to cancel selection.

Operation
21
Program function
Cleaning the exterior
Turn off the water faucets after final use.
This will shut off the water supply to your washer and prevent the unlikely possibility of
damage from escaping water. Leave the lid open to allow the inside of your washer to dry
out.
Use a soft cloth to wipe up all detergent, bleach or other spills as they occur.
Clean the following as recommended:
Control Panel - Clean with a soft, damp cloth. Do not use abrasive powders or
pads. Do not spray cleaners directly on the panel.cleaning
Cleaning the detergent, bleach, softener compartments
You may find laundry product residue leftover in your compartments. To remove residue,
wipe with a damp cloth and towel dry. Do not attempt to remove the compartments or
trims for cleaning. The compartments and trims are not removable.
Storing your washer
Washers can be damaged if water is not removed from hoses and internal components
before storage.
Preparing your washer for storage as follows:
- Select the Quick wash cycle and add bleach to the washer. Run your washer through
the cycle without a load.
- Turn the water faucets off and disconnect the inlet hoses.
- Unplug your washer from the electrical outlet and leave your washer lid open to let air
circulate inside the drum.
- If your washer has been stored in below-freezing temperatures, allow time for any
leftover water in your washer to thaw out before use.
Cleaning the interior
Clean the interior of your washer periodically to remove any dirt, soil, odor, mold, mildew,
or bacterial residue that may remain in your washer as a result of washing clothes.
Failure to follow these instructions may result in unpleasant conditions, including odors
and/or permanent stains on your washer or laundry.
Hard water deposits may be removed, if needed. Use cleaners labeled “Washer safe”.
Tub clean
Tub clean is a self-cleaning cycle that removes mold that may occur
inside the washer.
1. Select the on Cycle selector.
- Once the is selected, the other
.
2. Press the button.
- If you press the button, Tub clean begins.
Using Tub clean, you can clean the tub and drum without using a
cleansing agent.
Tub clean
Tub clean function will be
automatically cancelled
Start/Pause
Start/Pause
Never use Tub clean cycle when laundry is in the washer.
This may cause damage to the laundry or a problem with the
washer.
CAUTION
Maintenance
22
Cycle Water Level Temp. Soil Level Delay (h) Fill up Extra Rinse
Auto Hot Extra Heavy
High Warm Heavy
Medium Cold Medium
Low Tap Cold Light
Drain & Spin
Heavy duty
Normal 0-24
Whites
Tub Clean
Bulky
Towels
Casual
Quick 28'
Delicates
Auto
Auto
Auto
Auto
Hot
Hot
Hot
Hot
Extra Heavy
Extra Heavy
Extra Heavy
High
High
High
High
Warm
Warm
Warm
Warm
Heavy
Heavy
Heavy
Heavy
Medium
Medium
Medium
Medium
Cold
Cold
Cold
Cold
Medium
Medium
Medium
Medium
Low
Low
Low
Low
Tap Cold
Tap Cold
Tap Cold
Tap Cold
Light
Light
Light
Light
Auto
High Warm Heavy
Medium Cold Medium
Low Tap Cold Light
Hot
Hot
Warm
Warm
Heavy
Medium
Medium
Cold
Cold
Medium
Medium
Low
Low
Tap Cold
Tap Cold
Light
Light
Means defult ○ Means optional — Means no selection
1:When you turn to one option which there is no beep notice. It means the function
can not be selected with this program.
–
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
High
●
●
–
–
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
–
Hot ●
–
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
–
Extra Heavy●
–
●
●
●
●
●
●
–
–
–
●
●
0-24
0-24
0-24
0-24
0-24
0-24
0-24
0-24
0-24
● ●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
– –
–
Express
●
●
●
●
●
●
–
–
–
–
–
–
–

23
24
Check these solutions if your washer...
Troubleshooting
Troubleshooting
Problem Solution
Fills with wrong
temperature
water.
- Turn both faucets fully.
- Make sure the temperature selection is correct.
- Make sure the hoses are connected to the correct faucets.
Flush water lines.
- Disconnect the hoses and clean the screens. The hose filter
screens may be clogged.
Load is too wet
at the end of the
cycle.
- Use high efficiency detergent to reduce over-sudsing.
- The load is too small. Very small loads (one or two items) may
become unbalanced and not spin out completely.
Leaks water. - Make sure all hose connections are tight.
- Make sure the end of the drain hose is correctly inserted and
secured to the drainage system.
- Avoid overloading.
- Use high efficiency detergent to prevent over-sudsing.
Has excessive
suds.
- Use high efficiency detergent to prevent over-sudsing.
- Reduce the detergent amount for soft water, small or lightly soiled
loads.
- Non-HE detergent is NOT recommended.
Has an odor. - Run a Tub Clean cycle to clean the tub and basket periodically.
See page 13.
- Check your detergent. Excessive suds collect in nooks and
crannies and cause mold.
- Dry the interior of your washer after the total cycle has finished.
Check these solutions if your washer...
Problem Solution
The unit doesn’t
start
- Check the fuse or reset the circuit breaker.
- Make sure your washer is plugged in.
- Make sure the lid is closed.
- Make sure the water source faucets are open.
- Make sure to press the Start/Pause button to start your washer.
- Before your washer starts to fill, it will make a series of clicking
noises to check the lid lock and go a quick drain.
No water or not
enough water.
Detergent /
Softener remains
in its box after
the wash cycle is
completed.
- Turn both faucets on fully.
- Check if the water pressure is in the normal range.
- Straighten the water inlet hoses.
- Disconnect hoses and clean the screens. Hose filter screens
may be clogged.
If your washer has any following problems, you can check from the
solutions listed below before making a service call. This will help you
save time and money.
Vibrates or is too
noisy.
- Make sure your washer is set on a level surface. If the surface is
not level, adjust your washer’s feet to level the appliance.
- Make sure your washer is not touching any other object.
- Make sure the laundry load is balanced.
During the spin process, if clothes are piled at one side of
basket, it will stop due to imbalance. The unit will try to
solve the problem automatically. If the washer can’t solve the
problem in three trials, you should replace the clothes and
make it as even as possible manually.
Stops - Plug the power cord into a live electrical outlet.
- Check the fuse or reset the circuit breaker.
- Close the lid and press the Start/Pause button to start your
washer. For your safety, your washer will not spin unless the lid
is closed.
- Before your washer starts to fill, it will make s series of clicking
noises to check the lid lock and do a quick drain.
- There may be a pause or sock period in the cycle. Wait and it
may start.
- Check the screens on the inlet hoses at the faucets for
obstructions. Clean the screens periodically.
Lid locked or will
not open.
- Press the Start/Pause button to stop your washer.
- It may take a few moments for the lid lock to disengage.
Does not drain or
spin.
- Check the fuse or reset the circuit breaker.
- Straighten the drain hoses. Eliminate kinked hoses. If there is a
drain restriction, call for service.
- close the lid and press the Start/Pause button. For your safety,
your washer will not spin unless the lid is closed.
- Check the height of drain hose end.

25
26
Wash Cycle Special Instructions Warning Symbols for
laundering
Normal Line Dry/ Hang to Dry Do Not Wash
Permanent Press /
Wrinkle Resistant /
Wrinkle Control
Drip Dry Do Not Wring
Gentle Delicates/Dry Flat Do Not Bleach
Hand Wash heat Setting Do Not Tumble Dry
Water Temperature** High No Steam (added to
iron)
Hot Medium Do Not Iron
Warm Low Dryclean
Cold Any Heat Dry Clean
bleach No Heat Air / Do Not Dry Clean
Any Bleach when (
needed)
iron-Dry or Steam
Temperatures Line Dry/ Hang to Dry
Only Non Chlorine -
(color-safe)
Bleach when needed( )
High Drip Dry
Tumble Dry Cycle Medium Dry Flat
normal Low
For machine-washable
wool Loads should be .
under 8 pounds.
Permanent Press/
Wrinkle Resistant/
Wrinkle Control
Gentle Delicates/
** The dot symbols represent appropriate wash water temperatures for various items. The temperature range for
Hot is 105 125 F 41 52 C for Warm 85 105 F 29 41 C and for Cold 60 85 F 16 29 C°- ° / °- ° , °- ° / °- ° °- ° / °- ° .
( ° / °.)Wash water temperature must be a minimum of 60 F 16 C for detergent activation and effective cleaning
The clothes washer can not ensure these temperatures because the actual temperature of the water entering
your washer depends on water heater settings and regional water supply temperatures. For example, cold
water entering the home in the northern states during winter may be 40 F 4C which is too cold for effective° / °
cleaning In this situation you will need to adjust the water temperature by selecting a warm setting, adding . ,
some hot water to the MAX FILL line, or using your Washer’s heating option, if available.
Fabric Care Chart
Appendix
The following symbols provide garment care direction. The Clothing care
labels include symbols for washing, bleaching, drying and ironing, or dry
cleaning when necessary. The use of symbols ensures consistency
among garment manufacturers of domestic and imported items. Follow
care label directions to maximize garment life and reduce laundering
problems.
Troubleshooting
Close the lid.
The door lock or PCB
is failed. Call service
center.
Check if the lid is open.
Check as “No water or
not enough water”
Check for water leakage.
Check these solutions if your washer...
SolutionsError Code Possible Cause
The washer takes more than
30 minutes to fill with water. After
water finishes entering your
washer, the water level has not
changed in 5 minutes.
The unit takes more than 10
minutes to drain.
Check as “Does not
drain or spin”
The lid is open.
Error Codes
The unit is out of balance in
spin operation.
Check as “Vibrates
or is too noisy”
Call service center.
Load sensing failed
Call service center.
Water leveling sensor failed
Door lock failed
Call service center.
Call service center.
Washer is not level.
Impact switch failed.
Adjust the washer level
refer to installation. If
situation continues, call
service center.

28
Technical specifications
TYPE
58kg
Agitator
111.4cm x 68.6cm x 72.6cm
120V~/60Hz 680W
Dimensions
(H x W x D)
Weight
Power
Current draw
Pulsator type
Drum grain
Display type
Display color
Motor
LT52N1BWWC
Red

Avant d'utiliser votre nouvel appareil, veuillez lire ces instructions afin d'éviter tout dommage.
Laveuse à chargement par le haut
MODÈLE :
LT52N1BWWCFR
GUIDE DE L'UTILISATEUR

Dépannage.................. ......................................................................... ........
Annexe........... ..............................................................................................
Caractéristiques techniques.......................................................
................... ..................
23
26
27
*** Si votre manuel d'utilisation est perdu ou abîmé, vous pouvez l'obtenir auprès des revendeurs.
Nettoyage de l'extérieur...........................................................................
............................................................................Nettoyage de l'intérieur
..........Nettoyage des compartiments (détergent, eau de Javel et assouplisseur)
Entreposage de votre laveuse.................................................................
Nettoyage de la cuve................................................................................
22
22
22
22
22
Codes d'erreur Vérifiez ces solutions si votre laveuse............................ 23
Tableau d'entretien des tissus................................................................ 26
Table des matières
Table des matières
Installation.....................................................................................................
Retrait de l'emballage... ...........................................................................
Liste du contenu de l'emballage.............................................................
Outils et pièces nécessaires à l'installation..............................................
Désignation des pièces............................................................................
Exigences en matière d'emplacement.....................................................
Étapes de l'installation..............................................................................
Fonctionnement.............................................................................................
Panneau de commande...........................................................................
Lavage d'une brassée de linge.................................................................
Fonction des cycles..................................................................................
Entretien........................................................ ................................................
9
9
9
9
10
11
14
17
17
19
21
22
12
Consignes de sécurité ..................................................................................
Consignes de sécurité
.. ......................................................................
............................................................................. 2
2
3
4
5
5
Explication des symboles
La décharge électrique
Risque pour les enfants
Risque d'explosion
Installation de l'appareil
Risque de dommages à l'appareil
Fonctionnement de l'appareil
Emballage/ancien appareil
............................................................................
..........................................................................
..........................................................................
...............................................................................
...........................................................
................................................................
.....................................................................
6
6
7
8
CONSIGNES DE SÉCURITÉ
CONSIGNES DE SÉCURITÉ
Pour votre sécurité, les informations contenues dans ce manuel
doivent être respectées afin de minimiser les risques d'incendie
ou d'explosion, de décharge électrique, ou pour d'éviter des
dommages matériels, des blessures corporelles ou des décès.
- Cet appareil n'est pas destiné à être utilisé par des
personnes (y compris des enfants) dont les capacités
physiques, sensorielles ou intellectuelles sont réduite ou
manquant d'expérience et de connaissances, à moins
qu'elles n'aient été surveillées ou instruites sur l'utilisation
de l'appareil par une personne responsable de leur sécurité.
- Les enfants doivent être surveillés afin de s'assurer qu'ils
ne jouent pas avec l'appareil.
Si le cordon d'alimentation est endommagé, il doit être
remplacé par le fabricant, son agent de service ou des
personnes qualifiées afin d'éviter tout danger.
- Les nouveaux tuyaux fournis avec l'appareil doivent être
utilisés et les anciens tuyaux ne doivent pas être réutilisés.
Les ouvertures ne doivent pas être obstruées par un tapis.
- Cet appareil est destiné à être utilisé dans des applications
domestiques et similaires comme :
- les cuisines du personnel dans les magasins, les bureaux
et autres environnements de travail;
- les chalets;
- par les clients dans les hôtels, les motels et autres
environnements de type résidentiel;
- les chambres d'auberges;
- les zones à usage commun dans les immeubles ou les
buanderies.

34
Explication des symboles
La décharge électrique
Avertissement!
CONSIGNES DE SÉCURITÉCONSIGNES DE SÉCURITÉ
Modèle
120V~ /60Hz
680W 58kg
Alimentation électrique nominale
Puissance nominale
Dimensions (mm)
Poids de l'appareil
Consommation de courant
Type de pulsateur Cuve
Affichage Couleur de l'affichage
Moteur
LT52N1BWWC
1114 x 686 x 726
Agitateur
DEL
Elliptique
Rouge
De série
10A
Avertissement!
Cette combinaison de symbole et de mention indique
une situation potentiellement dangereuse qui peut entraîner
la mort ou des blessures graves si elle n'est pas évitée.
Attention!
Cette combinaison de symbole et de mention indique
une situation potentiellement dangereuse qui peut
entraînerblessures légères ou mineures ou des
dommages matériels et à l'environnement.
Remarque!
Cette combinaison de symbole et de mention indique
une situation potentiellement dangereuse pouvant
entraîner des des blessures légères ou mineures.
Ce graphique représente une PRÉCAUTION et des mises en garde
détaillées seront affichées à côté.
Ce graphique représente une FONCTION INTERDITE et des
informations sont affichées à côté.
Ce graphique représente une INTERVENTION INTERDITE et des
informations détaillées sont affichées à l'intérieur du graphique.
-Cet appareil est destiné à un usage intérieur uniquement.
- Ne pas placer l'appareil dans un endroit humide.
- Les mains ne doivent pas être introduites dans la cuve
d'essorage en marche.
- Si la cuve d'essorage ne s'arrête pas dans les 15 secondes
après l'ouverture du couvercle, veuillez cesser d'utiliser
l'appareil et le faire réparer.
- Avant tout entretien de l'appareil, débranchez l'appareil
du réseau électrique.
- Débranchez toujours l'appareil et coupez l'alimentation
en eau après utilisation. La pression maximale de l'eau
à l'entrée est en pascals.
- Pour garantir votre sécurité, la fiche d'alimentation doit
être insérée dans une prise tripolaire reliée à la terre.
Vérifiez soigneusement et assurez-vous que votre prise est
correctement et sûrement reliée à la terre.
- Veillez à ce que l'eau et les appareils électriques soient
raccordés par un technicien qualifié, conformément aux
instructions du fabricant et aux règles de sécurité locales.

56
Risque d'explosion
Risque pour les enfants
Risque de dommages à l'appareil
Attention
Installation de l'appareil
CONSIGNES DE SÉCURITÉ CONSIGNES DE SÉCURITÉ
- Pays EU : l'appareil ne peut pas être utilisé par des enfants
âgés de 8 ans et plus et par des personnes dont les capacités
physiques, sensorielles ou intellectuelles sont réduites ou qui
manquent d'expérience et de connaissances, à condition qu'ils
aient reçu une surveillance ou des instructions concernant
l'utilisation de l'appareil en toute sécurité et qu'ils comprennent
les risques encourus. Les enfants ne doivent pas jouer avec
l'appareil. Le nettoyage et l'entretien ne doivent pas être
effectués par des enfants sans surveillance.
- Les animaux et les enfants ne peuvent pas grimper dans
l'appareil. Vérifiez l'appareil avant chaque utilisation.
- Les jeunes enfants doivent être surveillés afin qu'ils ne jouent
pas avec l'appareil.
- L'appareil peut être très chaud pendant son fonctionnement.
Tenez les enfants et les animaux domestiques éloignés de
l'appareil pendant son fonctionnement dans les pièces très
humides ainsi que dans les pièces contenant des gaz explosifs
ou caustiques.
-Retirez tous les emballages avant d'utiliser l'appareil. Dans le
cas contraire, vous risquez d'endommager gravement l'appareil.
- La laveuse équipée d'un seul robinet d'arrivée peut être
raccordée à l'alimentation en eau froide. Les vannes d'entrée de
l'appareil doivent être correctement raccordées à l'alimentation
en eau chaude et à l'alimentation en eau froide.
- La fiche doit être accessible après l'installation.
- Ne pas laver ou sécher des articles qui ont été nettoyés, lavés,
trempés ou imbibés de substances combustibles ou explosives
(telles que la cire, l'huile, la peinture, l'essence, les dégraissants,
les solvants de nettoyage à sec, le kérosène, etc. Cela pourrait
provoquer un incendie ou une explosion.
- Rincer soigneusement les articles à la main avant de les laver.
- Cet appareil est destiné à un usage intérieur uniquement.
- Il n'est pas destiné à être encastré.
- Les ouvertures ne doivent pas être obstruées par un tapis.
- L'appareil ne doit pas être installé dans les salles de bain
ou les pièces très humides, ainsi que dans les pièces
contenant des gaz explosifs ou caustiques.
- Retirez tous les emballages et les boulons de transport
avant d'utiliser l'appareil. Dans le cas contraire, l'appareil
risque d'être gravement endommagé.
- L'appareil est équipé d'une seule vanne d'entrée peut
être raccordé à l'eau froide. Un appareil à double entrée
doit être correctement raccordé à l'arrivée d'eau chaude
et à l'arrivée d'eau froide.
- La prise doit être accessible après l'installation.
- Votre appareil est destiné à un usage domestique et n'est
conçu que pour les tissus qui peuvent être lavés en machine.
- Ne grimpez pas et ne vous asseyez pas sur le couvercle de
l'appareil.
- Ne vous appuyez pas sur la porte de l'appareil.
- Précautions à prendre lors de la manipulation de l'appareil :
1. Les boulons de transport doivent être réinstallés sur
l'appareil par une personne spécialisée.
2. L'eau accumulée doit être évacuée de l'appareil.
3. Manipulez l'appareil avec précaution. Ne tenez
jamais les parties saillantes de l'appareil lors du
levage. La porte ne peut pas être utilisée comme
poignée pendant le transport.
4. Cet appareil est lourd. Transportez-le avec précaution.

78
Fonctionnement de l'appareil
- Veuillez ne pas fermer la porte avec une force excessive.
- Il est interdit d'y laver des tapis.
Emballage/ancien appareil
CONSIGNES DE SÉCURITÉ
Risque de dommages à l'appareil
CONSIGNES DE SÉCURITÉ
- Avant de faire une première brassée de lavage, l'appareil
doit être utilisé sans vêtements à l'intérieur.
- Les solvants inflammables, explosifs ou toxiques sont
interdits. L'essence et l'alcool, etc. ne doivent pas être
utilisés comme détergents. Ne choisissez que des détergents
adaptés au lavage en machine, en particulier pour la cuve.
- Veillez à ce que toutes les poches soient vidées. Les objets
pointus et rigides tels que les pièces de monnaie, les broches,
les clous, les vis, les pierres, etc. peuvent endommager
gravement l'appareil.
- Vérifiez que l'eau contenue dans la cuve a été vidée avant
d'ouvrir la porte. N'ouvrez pas la porte s'il y a visiblement de l'eau.
- Veillez à ne pas vous brûler lorsque l'appareil évacue de l'eau
de lavage chaude.
- N'ajoutez jamais manuellement de l'eau pendant le lavage.
- Une fois le cycle terminé, attendez deux minutes avant d'ouvrir
le couvercle de l'appareil.
Cette mention indique que cet appareil ne doit pas
être éliminé avec les autres déchets ménagers dans
l'ensemble de l'UE. Afin d'éviter que l'élimination
incontrôlée des déchets nuise à l'environnement ou
à la santé humaine, il convient de recycler l'appareil
de manière responsable afin de promouvoir la
réutilisation durable des ressources matérielles.
Pour retourner votre appareil usagé, utilisez les
systèmes de collecte ou contacter le détaillant où
l'appareil a été acheté afin d'assurer un recyclage
sans danger pour l'environnement.
