L3 Aviation Products GH-3100 User manual

5353 52nd Street, S.E.
TP-559 (Revision K)
Grand Rapids, MI 49512-9704, USA
March 30, 2017
L3aviationproducts.com
Electronic Standby Instrument System
Model: GH-3100
Part Number: 501-1860-(xxx1)
Part Number: 501-1860-(xxx3)
Installation and Operation Manual
This manual contains installation and operating
information for the GH Electronic Standby Instrument
System. Information in this manual includes the following
products: GH-3100 Electronic Standby Indicator (with 1.3,
1.4 or 3.0 software), DCM-3100 Detachable Configuration
Module, and MAG-3000 / MAG-3100 Magnetometer. This
information is supplemented and kept current by
revisions, service letters and service bulletins.

Page A Front Section TP-559
March 30, 2017 Revision K
Foreword
This manual provides information intended for use by persons who, in accordance with current regulatory
requirements, are qualified to install this equipment. Installation requirements may vary, depending on the
particularities of each aircraft, and this manual is intended as a guideline for that purpose. This manual
assumes familiarity with the setup and operation of the aircraft systems that interface with the GH-3100.
Standard installation practices prescribed in FAA Advisory Circular No. 43.13-2B must be followed.
If further information is required, please contact:
L3 Aviation Products
Attn: Field Service Engineering
5353 52PP
nd
PP Street, S.E.
Grand Rapids, MI USA 49512-9704
Telephone: [phone] or [phone]
Fax: [phone]
Email: [e-mail]
Web: www.L3aviationproducts.com
This manual is distributed with permission by:
L3 Aviation Products
5353 52PP
nd
PP Street, S.E.
Grand Rapids, MI USA 49512-9704
Telephone: [phone] or [phone]
Fax: [phone]
Email: [e-mail]
We welcome your comments concerning this manual. Although every effort has been made to keep it free
of errors, some may occur. When reporting a specific problem, please describe it briefly and include the
manual part number, the paragraph/figure/table number, and the page number. Send your comments to the
address or email above:
Disclaimer
This manual contains information that is considered relevant only at the time of distribution with the L3
Aviation Products product for which it is shipped. Information in this manual is subject to change without
notice.
1T21T
WARNING
INFORMATION SUBJECT TO EXPORT CONTROL LAWS
This technology is controlled under the Export Administration Regulations
(EAR) and may not be exported to a Foreign Person, either in the U.S. or
abroad, without proper authorization by the U.S. Department of
Commerce.
Copyright 2017
L3 Aviation Products

GH-3100
Installation & Operation Manual
TP-559 Front Section Page i
Revision K March 30, 2017
About This Manual
SECTION 1 – GENERAL INFORMATION
This section provides the following information: unit configurations, unit functionality, items
required but not supplied with the unit, equipment specifications, installation approval/limitations
and TSO approvals.
SECTION 2 - INSTALLATION
This section contains instructions to locate, assemble and install the GH-3100 Electronic Standby
System as well as information for unpacking equipment, and inspection procedure for in-shipment
damage.
SECTION 3 – INSTALLATION CHECKOUT
This section contains instructions for post installation setup and post installation checkout
procedures.
SECTION 4 – MAINTENANCE
This section contains general flightline maintenance procedures. It includes periodic maintenance,
troubleshooting, return to service procedures and instructions for the return of defective components.
APPENDIX A – SIGNAL AND CABLE CHARACTERISTICS
This appendix defines the electrical characteristics and wiring and label configuration options of all
input and output signals.
APPENDIX B – ENVIRONMENTAL QUALIFICATION FORM
This appendix provides the environmental qualification test data for the GH-3100 Indicator and
DCM-3100 Configuration Module.
Descriptions for Warnings, Cautions, and Notes are used throughout the manual to highlight important
information.
A WARNING is used to give notice to or call one's attention to beforehand especially of danger (such as
a warning to a Flight Crew person or a warning to a mechanic before performing a dangerous task).
A CAUTION is a statement that expresses the need for heightened awareness to conditions that can cause
damage to equipment.
A NOTE is used to point out a procedure, event, or practice that it is desirable to highlight.

GH-3100
Installation & Operation Manual
Page ii Front Section TP-559
March 30, 2017 Revision K
References
To get an up-to-date listing of all L3 Aviation Products technical publications and service literature go to
21T21Twww.L3aviationproducts.com21T21T, click on the Customer Support tab, select Technical Publications, and
select Current Publications on the left side of the screen.
Contact L3 Aviation Products Customer Service [1-800-453-0288] to determine availability of technical
publications and directives.
Service literature and publications can be obtained by either downloading from the L3 Technical
Publications website (may require secure site access) or by receiving a copy via email. Send an email
request to 21T21Tavionics.techpub[email protected]21T21T. Note – Additional request for software and databases may be
required.
PUBLICATION DESCRIPTION
TP-560 Pilot’s Guide, GH-3100
TP-603 Troubleshooting Guide, GH-3100
Letter of Equivalency Letter of equivalency for the GH-3100 software released 3.0.
TP-633 Installation Manual, MAG-3000 Magnetometer.
0040-21200-01 Installation Manual, MAG-3100 Magnetometer.
TP-623 Instruction Manual, JT-147A Calibration Test Set
SL-179 Service Letter - Fan Failures During Power ON Self Test Mode
SL-186 Service Letter - Provide factory generated tolerance settings of altitude
accuracy for certified repair stations.
SL-189 Service Letter –
1. Import / Export control issues.
2. Modification status of models GH-3000, GH-3004, and GH-3100.
SL-244 Service Letter - To inform customers about the replacement of the GH-3100
with software version 1.3 with the new GH-3100 with software version 3.0.
SL-245 Service Letter - During initial or user initiated alignment, attitude error may
be introduced during transition to the external heading source.
SB501-1860-1 Service Bulletin - To ease manufacturing and repair of the keyboard
assembly.
SB501-1860-2 Service Bulletin - To correct startup errors for Level Sensor Self Test.
SB501-1860-3 Service Bulletin - Provide replacement display due to diminishing source.
SB501-1860-4 Service Bulletin - Correct insufficient timing margin for 16-BIT A/D High
Byte-Low Byte Select Line.
SB501-1860-5 Service Bulletin - Provide additional screw depth engagement in sensor
mounting bracket.
SB501-1860-6 Service Bulletin - Manufacturing Change. Produce a universal Lighting
Controller.
SB501-1860-7 Service Bulletin - Manufacturing Change. Provide replacement for Pitch
Rate Sensor Flex.
SB501-1860-8 Service Bulletin - Manufacturing Change. Provide replacement for Roll Rate
Sensor Flex.
SB501-1860-9 Service Bulletin - Manufacturing Change. Provide replacement for Yaw
Sensor Flex.

GH-3100
Installation & Operation Manual
TP-559 Front Section Page iii
Revision K March 30, 2017
PUBLICATION DESCRIPTION
SB501-1860-10 Service Bulletin - Release of 2.1 software in support of Gulfstream G450
program.
SB501-1860-11 Service Bulletin - Release Software 1.1. New features include the capability
to compensate IAS with DCM-3100 loaded constants K1 and K2.
SB501-1860-12 Service Bulletin - To reduce the possibility of the display blanking or failing at
start up.
SB501-1860-13 Service Bulletin - To reduce the possibility of the display blanking or
disruption.
SB501-1860-14 Service Bulletin - To prevent unrecoverable loss of alignment during dynamic
motion with units configured without heading sources.
SB501-1860-15 Service Bulletin - Provide replacement display due to diminishing source.
SB501-1860-16 Service Bulletin - Add SSEC disable to GH SSEC selection and removal of
fan failure warning. (Software load 2.2)
SB501-1860-17 Service Bulletin - Add SSEC disable to GH SSEC selection and removal of
fan failure warning. (Software load 2.2)
SB501-1860-18 Service Bulletin - To improve attitude performance when configured without
heading. Maintenance release to address open action items.
SB501-1860-19 Service Bulletin - Provide replacement display due to diminishing source.
SB501-1860-20 Service Bulletin - Software update to correct alignment error at startup as a
result of power sequencing. This condition only affects units configured for
ARINC 429 heading input source using the following DCM-3100 part
numbers:
SB501-1860-20AWG Service Bulletin – (Agusta Westland only) Software update to correct
alignment error at startup as a result of power sequencing. T
his condition only
affects units configured for ARINC 429 heading input source using the
following DCM-3100 part numbers:
SB501-1860-21 Service Bulletin - This product may have a suspected unapproved part (SUP)
installed. This service bulletin creates an inspection MOD, effective at next
service, which identifies units that have had this condition corrected.
SB501-1860-22 Service Bulletin – (501-1860-2103 only) To incorporate quick disconnect
fittings to Static Pressure Port (MS33649-05) and Total Pressure Port
(MS33649-04).
SB501-1860-23 Service Bulletin - Inspect for suspect unapproved part (SUP).

GH-3100
Installation & Operation Manual
Page iv Front Section TP-559
March 30, 2017 Revision K
List of Effective Pages
Dates of original and changed pages are:
Revision A ................................May 24, 2002
Change 1.......................October 10, 2002
Change 2..........................March 21, 2003
Revision B ............................August 02, 2004
Revision C..................................April 4, 2005
Revision D................................May 22, 2006
Revision E ..........................October 31, 2006
Revision F ..........................January 26, 2009
Revision G................................May 20, 2009
Revision H.........................February 23, 2010
Revision J........................ September 4, 2012
Revision K .............................March 30, 2017
Total number of pages in this publication consists of the following:
Title page
A Page
i thru x
1-1 thru 1-12
2-1 thru 2-12
3-1 thru 3-12
4-1 thru 4-6
5-1 thru 5-34
A-1 thru A-10
B-1 thru B-4
REVISION HIGHLIGHTS
Revision K is a republication. This republication completely replaces the existing manual. New and
revised material for the GH-3100 Installation Manual has been added. These changes include:
•Update company name and email/web site.
•Update frontmatter to current format.
•Pg. 2-1: Change 4 gauss to 5 gausses in caution.
•Pg. 2-3: Insert new step 8 for clamp torque settings.
•Pg. 1-10: Update information concerning the calibration test set and the MAT-3100.
Discard all previous revisions of this manual.

GH-3100
Installation & Operation Manual
TP-559 Front Section Page v
Revision K March 30, 2017
Table of Contents
Paragraph Page
Foreword.......................................................................................................................................................A
About This Manual......................................................................................................................................... i
References..................................................................................................................................................... i
List of Effective Pages...................................................................................................................................iv
Revision Highlights........................................................................................................................................iv
Table of Contents.......................................................................................................................................... v
List of Illustrations .......................................................................................................................................viii
List of Tables.................................................................................................................................................ix
List of Abbreviations...................................................................................................................................... x
SECTION 1
GENERAL INFORMATION
1.1 Introduction ...................................................................................................................................1-1
1.2 Functional description...................................................................................................................1-3
1.2.1 Electronic Standby Indicator (GH-3100).......................................................................................1-4
1.2.2 Detachable Configuration Module (DCM-3100)............................................................................1-5
1.2.3 Magnetometer (MAG-3000)..........................................................................................................1-5
1.2.4 Magnetometer (MAG-3100)..........................................................................................................1-5
1.3 Specifications................................................................................................................................1-6
1.3.1 GH-3100........................................................................................................................................1-6
1.3.2 DCM-3100.....................................................................................................................................1-8
1.4 Modifications and Software Revisions ..........................................................................................1-8
1.4.1 Software Release Summery .........................................................................................................1-8
1.5 Interfaces ......................................................................................................................................1-8
1.6 Equipment Required Not Supplied................................................................................................1-9
1.7 installation approval and Limitations...........................................................................................1-11

GH-3100
Installation & Operation Manual
Page vi Front Section TP-559
March 30, 2017 Revision K
Table of Contents (continued)
Paragraph Page
SECTION 2
INSTALLATION
2.1 Introduction ...................................................................................................................................2-1
2.2 Unpacking and inspecting.............................................................................................................2-1
2.2.1 Transport and Storage Considerations.........................................................................................2-1
2.3 Installation Procedures..................................................................................................................2-2
2.3.1 GH-3100 Electronic Standby Indicator..........................................................................................2-2
2.3.2 DCM-3100 Detachable Configuration Module..............................................................................2-3
2.3.3 Electrical Connections...................................................................................................................2-6
2.3.4 Installation Guidelines for MAG-3000 Magnetometer...................................................................2-7
2.3.5 Installation Guidelines for MAG-3100 Magnetometer...................................................................2-8
SECTION 3
INSTALLATION CHECKOUT
3.1 Introduction ...................................................................................................................................3-1
3.2 Post Installation Checks (Initial System Installation) ....................................................................3-1
3.2.1 Electronic Standby Indicator Check..............................................................................................3-1
3.2.2 Magnetometer Check....................................................................................................................3-2
3.2.3 Post Installation Checks (Remove and Replace Checkout).......................................................3-11
SECTION 4
MAINTENANCE
4.1 Introduction ...................................................................................................................................4-1
4.2 Continued Airworthiness...............................................................................................................4-1
4.2.1 Periodic Maintenance....................................................................................................................4-1
4.2.2 Pneumatic Pressure Checks.........................................................................................................4-1
4.3 Fault Isolation................................................................................................................................4-3
4.4 Return to Service ..........................................................................................................................4-5
4.5 Disposition of Failed Items............................................................................................................4-5
4.5.1 GH-3100 Electronic Standby Indicator..........................................................................................4-5
4.5.2 DCM-3100 Data Configuration Module.........................................................................................4-6
4.5.3 Magnetometer (MAG-3100 and MAG-3000).................................................................................4-6

GH-3100
Installation & Operation Manual
TP-559 Front Section Page vii
Revision K March 30, 2017
Table of Contents (continued)
Paragraph Page
SECTION 5
OPERATION
5.1 Introduction ...................................................................................................................................5-1
5.2 Functional Description...................................................................................................................5-1
5.2.1 Front Panel Controls.....................................................................................................................5-1
5.2.2 Menu Interface ..............................................................................................................................5-2
5.2.3 Operational Formats .....................................................................................................................5-7
5.2.4 Air Data Presentation..................................................................................................................5-12
5.2.5 Navigation Data...........................................................................................................................5-19
5.2.6 Heading Data..............................................................................................................................5-23
5.3 Operational Functions.................................................................................................................5-25
5.3.1 Power ON Sequence ..................................................................................................................5-25
5.3.2 Pitch and Roll Attitude Display....................................................................................................5-26
5.3.3 Slip / Skid Indicator .....................................................................................................................5-27
5.3.4 Air Data Display ..........................................................................................................................5-27
5.3.5 NAV Displays ..............................................................................................................................5-28
5.3.6 Magnetic Heading Display Data..................................................................................................5-34
APPENDIX A
GH-3100 INTERFACE SIGNAL NAME & CABLE CHARACTERISTICS
A.1 Introduction ...................................................................................................................................A-1
A.2 Digital Interface .............................................................................................................................A-1
A.2.1 ARINC 429 Input BUS...................................................................................................................A-1
A.2.2 CSDB Input BUS...........................................................................................................................A-2
A.2.3 RS-422 Input BUS.........................................................................................................................A-3
A.2.4 BUS Configuration Options...........................................................................................................A-3
A.3 Electronic Standby Indicator, [J1 connector] ................................................................................A-4
APPENDIX B
ENVIRONMENTAL QUALIFICATION FORM
B.1 GH-3100 & DCM-3100 Environmental Qualification Form...........................................................B-1

GH-3100
Installation & Operation Manual
Page viii Front Section TP-559
March 30, 2017 Revision K
List of Illustrations
Figure Page
1-1: GH-3100 Electronic Standby Instrument System...........................................................................1-2
1-2: JT-147A Calibration Test Set........................................................................................................1-11
2-1: DCM-3100 Outline Dimensions......................................................................................................2-3
2-2: GH-3100 Outline Dimensions and J1 Pin Assignments.................................................................2-4
2-3: GH-3100 Cable Assembly (J1).......................................................................................................2-6
2-4: System Electrical Interface Diagram with MAG-3000.....................................................................2-9
2-5: System Electrical Interface Diagram with MAG-3100...................................................................2-10
3-1: Example of Plane on Compass Rose.............................................................................................3-4
3-2: ILS Display......................................................................................................................................3-5
3-3: VOR Display ...................................................................................................................................3-6
3-4: DME Display ...................................................................................................................................3-6
3-5: FMS Display....................................................................................................................................3-7
3-6: TACAN Display...............................................................................................................................3-8
5-1: Indicator Front Panel.......................................................................................................................5-1
5-2: Attitude Display with Callouts .........................................................................................................5-7
5-3: Chevrons in Excessive Pitch Attitude Display ................................................................................5-8
5-4: Full Screen Attitude Failure Display..............................................................................................5-10
5-5: Processor Error Screens ..............................................................................................................5-11
5-6: Attitude Display with Airspeed and Altitude..................................................................................5-12
5-7: Altitude Displays ...........................................................................................................................5-13
5-8: Invalid Air Data Displays...............................................................................................................5-15
5-9: IAS Tape Displays ........................................................................................................................5-16
5-10: IAS Invalidity Displays ................................................................................................................5-18
5-11: VOR Mode with DME..................................................................................................................5-19
5-12: ILS Mode with DME....................................................................................................................5-20
5-13: FMS Mode ..................................................................................................................................5-20
5-14: TACAN Mode..............................................................................................................................5-21
5-15: Heading Tape, VOR Mode .........................................................................................................5-23
5-16: Heading Tape, FMS Mode..........................................................................................................5-23
5-17: Heading Invalidity with X.............................................................................................................5-24
5-18: Heading Invalidity with Box.........................................................................................................5-24
5-19: Example of ARINC 429 NAV & CSDB NAV Interconnect ..........................................................5-29

GH-3100
Installation & Operation Manual
TP-559 Front Section Page ix
Revision K March 30, 2017
List of Tables
Table Page
1-1: GH-3100 System Components.......................................................................................................1-1
1-2: GH-3100 Configuration...................................................................................................................1-3
2-1: GH-3100 Installation Kit P/N 504-1895-07 .....................................................................................2-2
2-2: Magnetometer Installation Kit, P/N 504-1895-05............................................................................2-7
2-3: Magnetometer Installation Kit, P/N 504-1895-18............................................................................2-7
3-1: Installation Data Record ...............................................................................................................3-10
4-1: Indicated Airspeed..........................................................................................................................4-2
4-2: Fault List .........................................................................................................................................4-3
5-1: Menu Item Display Summary..........................................................................................................5-4
5-2: NAV Annunciator Colors...............................................................................................................5-19
A-1: External Systems BUS Input Options............................................................................................ A-3

GH-3100
Installation & Operation Manual
Page x Front Section TP-559
March 30, 2017 Revision K
List of Abbreviations
Symbol or
Acronym
Definition
Symbol or
Acronym
Definition
3ATI
3” Air Transport Instrument
IM
Inner Marker
A/C
Aircraft
IN
Inch
A/C EFF
Aircraft Effectivity
InHg
Inches of Mercury
ac or AC
Alternating Current
Kg
Kilogram
ADC
Air Data Computer
KIAS
Knots Indicated Airspeed
AMLCD
Active Matrix Liquid Crystal Display
KTS
Knots
AOA
Angle of Attack
Lbs.
Pounds
APR
Approach
LCD
Liquid Crystal Display
ARINC
Aeronautical Radio, Inc.
LOC
Localizer
ASCII
American Standard Code for
Information Interchange
LRN
Long Range Navigation
BARO
Barometric Pressure Setting
M
Unit Menu Command
BC
Backcourse (ILS)
MAG
Magnetic
BIT
Built In Test
MB
Millibars
BRG
Bearing
MHz
Megahertz
CCW
Counter-Clockwise
MIN
Minute
CDI
Course Deviation Indicator
MM
Middle Marker
CPU
Central Processing Unit
MMO
Maximum Operating Mach
CRS
Course
MSB
Most Significant Bit
CSDB
Commercial Standard Digital Bus
NAV
Navigation
CW
Clockwise
NM
Nautical Mile
dc or DC
Direct Current
Non_Std
Non Standard
DCM
Detachable Configuration Module
NVIS
Night Vision Imaging System
°
Degree
N/A
Not Applicable
DEG
Degree
OBS
Omni-Bearing Selector
DG
Directional Gyro
OM
Outer Marker
DME
Distance Measuring Equipment
PFD
Primary Flight Display
DTK
Desired Track
P/N
Part Number
EASA European Aviation Safety Agency
PVOR
Pseudo VHF Omnidirectional
Range
EFIS
Electronic Flight Instrument System
REF
Reference
ETI
Elapsed Time Indicator
RNAV
Area or Random Navigation
ETSO
European Technical Standard Order
SDI
Source / Destination Identifier
E.M.I
Electromagnetic Interference
SI
Source Identifier
FL
Foot-Lambert
SSM
Sign-Status Matrix
FMC
Flight Management Computer
STD
Standard
FMS
Flight Management System
TACAN
Tactical Air Navigation
FREQ
Frequency
TCN
TACAN
FT
Feet
TSO
Technical Standard Order
GPS
Global Positioning System
TTS
Time To Station
GS
Glideslope
UUT
Unit Under Test
HMI
Hazardously Misleading Information
Vdc
Volts - Direct Current
HPa, HPA
Hecto Pascal
VMO
Maximum Operating Velocity
IAS
Indicated AirSpeed
VNE
Not to Exceed Velocity
IAW
In Accordance With
VNO
Normal Operating Velocity
I/O
Input / Output
VOR
VHF Omnidirectional Range
ID
Identification
WPT
Waypoint
ILS
Instrument Landing System
XTK
Crosstrack
ILS BC
Instrument Landing System Back
Course

GH-3100
Installation & Operation Manual
TP-559 General Information Page 1-1
Revision K March 30, 2017
Section
1
General Information
1.1 INTRODUCTION
This section includes functional descriptions and equipment specifications for the GH-3100 Electronic
Standby Instrument System. Included at the end of this section is a list of equipment required but not
supplied with the system. A list of system components is provided in Table 1-1. Installation kits are called
out in paragraph 1.6 and described in the installation section.
Table 1-1: GH-3100 System Components
NAME MODEL PART NUMBER
Electronic Standby Indicator GH-3100 501-1860-() (see Table 1-2)
Detachable Configuration Module DCM-3100 501-1870-()
Magnetometer MAG-3000 501-1826-() (optional)
Magnetometer MAG-3100 9200-21200-01 (optional)

GH-3100
Installation & Operation Manual
Page 1-2 General Information TP-559
March 30, 2017 Revision K
GH-3100
DCM-3100
MAG-3000 MAG-3100
Figure 1-1: GH-3100 Electronic Standby Instrument System

GH-3100
Installation & Operation Manual
TP-559 General Information Page 1-3
Revision K March 30, 2017
1.2 FUNCTIONAL DESCRIPTION
The GH-3100 Electronic Standby Instrument System provides a backup system for the following
information: attitude, air data, heading, and navigation. Table 1-2 provides a list of currently available
GH-3100 Electronic Standby Indicator's, for software versions 1.3, 1.4 and 3.0.
Table 1-2: GH-3100 Configuration
Part No.
Bezel Lighting
Night Vision
Bezel Color
Rate Sensor
Air Data Card, P/N
501-1860-0101
5.0 V
No
Gray
100
°
/Sec
542-2851-02
501-1860-0201
5.0 V
No
Black
100
°
/Sec
542-2851-02
501-1860-0301
28 V
No
Gray
100
°
/Sec
542-2851-02
501-1860-0401
28 V
No
Black
100
°
/Sec
542-2851-02
501-1860-0501 5.0 V Yes Gray
100
°
/Sec
542-2851-02
501-1860-0601 5.0 V Yes Black
100
°
/Sec
542-2851-02
501-1860-0701 28 V Yes Gray
100
°
/Sec
542-2851-02
501-1860-0801 28 V Yes Black
100
°
/Sec
542-2851-02
501-1860-1101 5.0 V No Gray
200
°
/Sec
542-2851-02
501-1860-1201
5.0 V
No
Black
200
°
/Sec
542-2851-02
501-1860-1301
28 V
No
Gray
200
°
/Sec
542-2851-02
501-1860-1401
28 V
No
Black
200
°
/Sec
542-2851-02
501-1860-1501
5.0 V
Yes
Gray
200
°
/Sec
542-2851-02
501-1860-1601
5.0 V
Yes
Black
200
°
/Sec
542-2851-02
501-1860-1701
28 V
Yes
Gray
200
°
/Sec
542-2851-02
501-1860-1801
28 V
Yes
Black
200
°
/Sec
542-2851-02
501-1860-2101
5.0 V
No
Brown
100
°
/Sec
542-2851-02
501-1860-2201
28 V
No
Brown
100
°
/Sec
542-2851-02
501-1860-0103
5.0 V
No
Gray
100
°
/Sec
9230-10000-01
501-1860-0203
5.0 V
No
Black
100
°
/Sec
9230-10000-01
501-1860-0303
28 V
No
Gray
100
°
/Sec
9230-10000-01
501-1860-0403
28 V
No
Black
100
°
/Sec
9230-10000-01
501-1860-0503 5.0 V Yes Gray
100
°
/Sec
9230-10000-01
501-1860-0603 5.0 V Yes Black
100
°
/Sec
9230-10000-01
501-1860-0703 28 V Yes Gray
100
°
/Sec
9230-10000-01
501-1860-0803 28 V Yes Black
100
°
/Sec
9230-10000-01
501-1860-1103
5.0 V
No
Gray
200
°
/Sec
9230-10000-01
501-1860-1203
5.0 V
No
Black
200
°
/Sec
9230-10000-01
501-1860-1303 28 V No Gray
200
°
/Sec
9230-10000-01
501-1860-1403
28 V
No
Black
200
°
/Sec
9230-10000-01
501-1860-1503
5.0 V
Yes
Gray
200
°
/Sec
9230-10000-01
501-1860-1603
5.0 V
Yes
Black
200
°
/Sec
9230-10000-01
501-1860-1703
28 V
Yes
Gray
200
°
/Sec
9230-10000-01
501-1860-1803
28 V
Yes
Black
200
°
/Sec
9230-10000-01
501-1860-2103
5.0 V
No
Brown
100
°
/Sec
9230-10000-01
501-1860-2203
28 V
No
Brown
100
°
/Sec
9230-10000-01

GH-3100
Installation & Operation Manual
Page 1-4 General Information TP-559
March 30, 2017 Revision K
1.2.1 Electronic Standby Indicator (GH-3100)
NOTE
The GH-3100 product Software Release 3.0 is a direct replacement for
the GH-3100 Software Release 1.3 and 1.4 with regard to form, fit and
function as long as the appropriate Detachable Configuration Module
(DCM-3100) is used for the aircraft type. There is no aircraft wiring
changes required for the new part numbers.
The Electronic Standby Indicator is a 3 ATI, self-contained solid state instrument that uses a color active
matrix liquid crystal display to provide a visual display of attitude (pitch and roll), and slip/skid
information computed from an internal three-axis inertial sensor cluster. Air data information for baro
corrected altitude, air speed, mach number, and vertical speed are provided by pitot and static inputs.
Built-in interfaces provide additional navigation information. A bezel mounted light sensor provides
automatic display dimming capability, with manual offset control achieved through the menu mode.
The GH-3100 contains the following built-in interfaces.
•ARINC 710 / 711 (VHF) NAV Receivers (ARINC 429, CSDB)
•ARINC 709 (VHF) DME (ARINC 429, CSDB)
•TACAN (ARINC 429)
•Flight Management System Interface (ARINC 429)
•Three axis solid state Magnetometer input for Magnetic Heading (RS-422)
•ARINC 705 Heading Reference (ARINC 429)
When equipment is connected to and configured for the above interfaces, the GH-3100 provides the
following functions:
INTERFACE DESCRIPTION INTERFACE STANDARD FUNCTION
ARINC 710 / 711 (VHF) NAV Receivers ARINC 429, CSDB Precision approach Instrument Landing System
(ILS) and/or Very High Frequency Omnirange (VOR)
navigation information.
TACAN ARINC 429 Bearing, Range, Time to Station, and Groundspeed
ARINC 709 (VHF) DME ARINC 429, CSDB Range, Time to Station, Groundspeed.
Flight Management System Interface ARINC 429 Flight Management System (FMS) navigational aids
Three axis solid state Magnetometer input
for Magnetic Heading RS-422 Magnetic Heading
ARINC 705 Heading Reference ARINC 429 Magnetic Heading

GH-3100
Installation & Operation Manual
TP-559 General Information Page 1-5
Revision K March 30, 2017
1.2.2 Detachable Configuration Module (DCM-3100)
The Detachable Configuration Module is a solid-state device that retains software and hardware
configuration information for specific aircraft.
NOTE
The DCM-3100 is electrostatic sensitive device when not connected to
the GH-3100 Indicator.
1.2.3 Magnetometer (MAG-3000)
The Magnetometer uses a three-axis magnetic sensor to sense magnetic fields. The field data is transmitted
via an RS-422 bus to the Standby Attitude Indicator (GH-3100). The field data is used with the pitch and
roll attitude of the Standby Attitude Indicator to compute the magnetic heading of the aircraft.
NOTE
Refer to the MAG-3000 Install manual, TP-633, for complete installation
information.
1.2.4 Magnetometer (MAG-3100)
The Magnetometer uses a three-axis magnetic sensor to sense magnetic fields. The field data is transmitted
via an RS-422 bus to the Standby Attitude Indicator (GH-3100). The field data is used with the pitch and
roll attitude of the Standby Attitude Indicator to compute the magnetic heading of the aircraft.
NOTE
Refer to the MAG-3100 Install manual, 0040-21200-01, for complete
installation information.

GH-3100
Installation & Operation Manual
Page 1-6 General Information TP-559
March 30, 2017 Revision K
1.3 SPECIFICATIONS
1.3.1 GH-3100
PART NUMBER 501-1860-() (GH-3100)
CERTIFICATION: USA (FAA) and Europe (EASA)
See paragraph 1.3.1.1 and 1.3.1.2 for information.
RTCA COMPLIANCE:
see environmental qualification
form in Appendix B.
Environmental Category: DO-160D
Software Category: DO-178B, criticality Level B & C
Other: DO-187, DO-189, DO-192, DO-195, DO-196, And DO-208.
EUROCAE COMPLIANCE:
see environmental qualification
form in Appendix B.
ED-14E, ED-22B, ED-46B, ED-47B, ED-54
SIZE: Case shall be 3 ATI in accordance with ARINC Specification 408A.
Length (with knob): 12.29 inches [31.22 cm]
Bezel Width and Height: 3.30 inches [8.38 cm]
WEIGHT: 4.0 Lbs. (1.81 Kg) maximum.
POWER REQUIREMENTS: Starting: (warm up) 50.0 watts at +28.0 Vdc, continues for first five minutes of
operation.
Running: (with heaters, fan, and thermal electrical cooler off) shall not exceed 23.5
watts at 28 Vdc input.
Lighting Power: 0.708 watts at 5.0 Vac or Vdc or 0.9 watts at 28.0 Vac or Vdc.
CIRCUIT BREAKER: 3.0A recommended.
CONFIGURATION: See Table 1-2.
OPERATING TEMPERATURE: -40°to +70°C (-40°to +158°F)
STORAGE TEMPERATURE: -55°to +85°C (-67°to +185°F)
MAXIMUM ALTITUDE: 25,000 ft.
AIR SPEED AND ALTITUDE
MAXIMUM DISPLAY LIMITS:
Mach Range 0.41 to 0.99
Altitude Range –1,000 to +55,000 feet
Indicated Airspeed Range 0 to 450 knots
OPERATION REQUIREMENTS: DCM-3100 installed at J2 is required to operate.
CONNECTOR TYPE: J1 (p/n 563-1113-01)
mates with MS3116F18-32S (solder contacts)
or MS3126F18-32S (front release crimp contacts)
or MS3476L18-32S (rear release crimp contact).
with M85049/52S18W strain relief.
J2 (p/n 563-1013-21)
Interface port to the DCM-3100 and diagnostic port.
Static Pressure Port : IAW MS33649-05
Total Pressure Port: IAW MS33649-04
SCHEDULED MAINTENANCE
No scheduled maintenance interval applicable. Subject to bi-annual requirements of
FAA document
CFR FAR Part 91.411
.
REPAIRABILITY: Repairs will be performed at the factory
SERVICE LIFE: The indicator has unlimited service life
CAUTION
Do not use this information for acceptance verification for the GH
indicator. Verification tests are located in the Installation Checkout
section of this manual.

GH-3100
Installation & Operation Manual
TP-559 General Information Page 1-7
Revision K March 30, 2017
1.3.1.1 TSO Authorizations
TSO NO.
TSO ADDITIONAL MARKING
TSO TITLE
TSO-C2d (Type B) Airspeed Instruments
TSO-C4c Bank and Pitch Instruments
TSO-C6d Directional Instruments, Magnetic
TSO-C8d (Type B) Vertical Speed Instruments (Rate-of-Climb)
TSO-C10b (-1000 to 55,000 Ft) Aircraft Altimeter, Pressure Actuated, Sensitive
TSO-C34e Airborne ILS Glide Slope Receiving Equipment
Operating Within the Radio Frequency Range of
328.6-335.5 Megahertz (MHz)
TSO-C36e Airborne ILS Localizer Receiving Equipment
Operating Within the Radio Frequency Range of
108-112 Megahertz (MHz)
TSO-C40c VOR Receiving Equipment
TSO-C46a (0 to 450 Knots) Maximum Allowable Airspeed Indicator Systems
TSO-C66c Distance Measuring Equipment (DME)
TSO-C106 (-1000 to 55,000 Ft, 50 to 450
Knots, 0.41 to 0.99 Mach) Air Data Computer
TSO-C113 Airborne Multipurpose Electronic Display
TSO-C115b Airborne Navigation Equipment Using Multi-Sensor
Inputs
1.3.1.2 ETSO Authorizations
ETSO NO. ETSO ADDITIONAL MARKING ETSO TITLE
ETSO-C2d Airspeed Instruments
ETSO-C4c (28 V dc, 50W max) Bank and Pitch Instruments
ETSO-C6d Directional Instruments, Magnetic
ETSO-C8d Vertical Speed Instruments (Rate-of-Climb)
ETSO-C10b (-1000 to 55,000 Ft) Aircraft Altimeter, Pressure Actuated, Sensitive
ETSO-2C34f Airborne ILS Glide Slope Receiving Equipment
Operating Within the Radio Frequency Range of
328.6-335.5 Megahertz (MHz)
ETSO-2C36f Airborne ILS Localizer Receiving Equipment
Operating Within the Radio Frequency Range of
108-112 Megahertz (MHz)
ETSO-2C40c VOR Receiving Equipment
ETSO-C46a (0 to 450 Knots) Maximum Allowable Airspeed Indicator Systems
ETSO-2C66b Distance Measuring Equipment (DME)
ETSO-C106 Air Data Computer
ETSO-C113 Airborne Multipurpose Electronic Display
ETSO-C115b Airborne Navigation Equipment Using Multi-Sensor
Inputs

GH-3100
Installation & Operation Manual
Page 1-8 General Information TP-559
March 30, 2017 Revision K
1.3.2 DCM-3100
PART NUMBER 501-1870-( ) (DCM-3100)
CERTIFICATION: USA (FAA) and Europe (EASA)
See paragraph 1.3.1.1 and 1.3.1.2 for information.
WEIGHT: 0.05 Lbs. (0.023 Kg) maximum.
POWER REQUIREMENTS: 5.0 Vdc Regulated from GH-3100 Electronic Standby Indicator via J2 Connector.
OPERATING TEMPERATURE: -40°to +70°C (-40°to +158°F)
STORAGE TEMPERATURE: -55°to +85°C (-67°to +185°F)
MAXIMUM ALTITUDE: 25,000 ft.
OPERATION REQUIREMENTS:
Must be connected to J2 connector of GH-3100 Electronic Standby Indicator.
SCHEDULED MAINTENANCE No scheduled maintenance interval applicable.
REPAIRABILITY:
Repairs will be performed at the factory
SERVICE LIFE: The Module has unlimited service life.
1.4 MODIFICATIONS AND SOFTWARE REVISIONS
Modification (MOD) for the LRU components of the GH-3100 Electronic Standby Instrument System is
identified by an entry on the S/N & I.D. on individual units. Software revision is shown on the display
during the startup phase of the Electronic Standby Indicator.
1.4.1 Software Release Summery
1. Software release 1.1 (see Service Bulletin SB501-1860-11) added the capability of compensating the
IAS with DCM-3100 loaded constants K1 and K2. [Superseded by SB501-1860-14].
2. Software release 1.2 (see Service Bulletin SB501-1860-14) released to improve attitude accuracy
when configured without heading and removes fan failure warning message.
[Superseded by SB501-1860-18].
3. Software release 1.3 (see Service Bulletin SB501-1860-18) released to improve attitude performance
when configured without heading.
4. Software release 3.0 (New models) released to incorporate new air data card and add new
functionality of ARINC 710 and ILS/VOR.
5. Software release 1.4 (see Service Bulletin SB501-1860-20) released to correct alignment error at
startup as a result of power sequencing. This condition only affects units configured for ARINC 429
heading input source using specific DCM-3100 part numbers:
1.5 INTERFACES
The electrical characteristics of all input and output signals are detailed in Appendix A
