Larsen & Toubro Star 55 User manual

Star 55
8 channel multiparameter color monitor
Star 55
Operating Manual
LARSEN &LARSEN &
LARSEN &LARSEN &
LARSEN & TT
TT
TOUBROUBR
OUBROUBR
OUBRO LIMITEDO LIMITED
O LIMITEDO LIMITED
O LIMITED

Star 55
CAT NO. : 3-86-020-0013-71 ISSUED : April 2010 Rev. :06
Larsen & Toubro Limited
Medical Equipment & Systems
Gate #5, Mysore Campus,
Plot #358-360,
KIADB Industrial Area, Hebbal,
Mysore - 570018.
Karnataka, India.
All rights reserved
L&T medical reserves the right to make changes in specifications and features shown
herein or discontinue the product described at any time without notice or obligation. The
contents in this manual are strictly not to be reproduced in any form, by any method, for
any purpose.
© 2010 Larsen & Toubro Limited
0843

Introduction
Congratulations on becoming one of the proud
customers of L&T Medical’s multiparameter color
monitor Star 55.
Star 55 offers continuous monitoring for ECG - 3/5
lead, Respiration, Temperature, Non-Invasive Blood
Pressure, Pulse Oximetry, Invasive Blood Pressure
(two standard and two optional channels),
Microstream Capnography (optional) and it has
external connection facility for Gas monitoring module.
Star 55 has an optional Inbuilt two channel thermal
array recorder which can record online data (any two
waveforms out of ECG waveform, plethysmograph,
respiration/capnogrpahy, O2, AA and Invasive blood
pressure w/f along with numerical values of all
parameters). Star 55 also has a feature of Drug
calculator and an Oxygen Cardio Respirograph.
Star 55 is a multi channel monitor with selectable
waveform display facility for ECG (Lead I / II / III /
aVR / aVL / aVF / V1-V6 ), Plethysmograph,
Respiration, Invasive Blood Pressure (IBP1, IBP2, IBP3
and IBP4), O2, AA and Capnography (CO2). It also
displays the digital values of HR/PR, SpO2,
Respiration Rate, Non-Invasive and Invasive Blood
Pressure (Systolic, Diastolic and Mean), Temperature,
N2O, O2, EtAA ,FiAA and CO2(EtCO2and FiCO2)
readings. Star 55 has graded and colour coded
alarms. It has 72 hours tabular and graphical trend
for 200 patients of all parameters except NIBP. Star 55
has special tabular trend for NIBP to store last 240
readings. Recall feature offers storage of last 24 critical
alarm conditions and ECG trend.
Star 55 also has a feature of SD Card (Optional).
Star 55 has different communication modules for various
external connectivity and software upgrade options.
Star 55 also has a connectivity to external printer
through USB port (Optional). Star 55 allows the user
to print the trend data and last 24 patient related alarm
conditions in tabular format.

Star 55
Exemptions .................i
Copyright..................i
Standards .................i
Regulatory Requirements ............i
Disposal Instructions . .............i
Caution ..................ii
WARNING .................iii
Unpacking .................iv
Indication For Use . . .............v
Handling Precautions . .............vi
Symbols ..................viii
Acronyms and Abbreviations............x
1. Display, Controls And Connections ..........1
• Front Panel. .................1.1
• Rear Panel .................1.5
• Left Side Panel . . . .............1.7
• Right Side Panel . .............1.9
• Procedure To Connect And Disconnect The Connectors . . . . 1.11
• Recorder (Optional). . .............1.15
• Remote. ..................1.17
2. Application Guide . . . .............2
•ECG...................2.1
• Respiration .................2.6
• Temperature.................2.7
• Pulse Oximetry . . . .............2.8
• Non Invasive Blood Pressure ...........2.11
• Invasive Blood Pressure (Optional)..........2.13
• Capnography (Optional) .............2.16
3. Operations And Main Screen.............3
• Operation . . . .............3.1
• Main screen.................3.2
4. Parameter Setting . . . .............4
•ECG...................4.1
• Respiration . . . . .............4.4
• Temperature . . . .............4.5
•SpO
2...................4.6
Table Of Contents

•NIBP...................4.7
• Capnography (Optional) . . ...........4.9
• IBP (Optional) ................4.11
• Drug cal ..................4.15
5. System Functions ................5
• System Functions ...............5.2
• Menu ...................5.3
• Trend ...................5.10
• Display ..................5.18
• Volume ..................5.20
• Recall ..................5.21
• Autoset ..................5.22
6. Maintenance Schedule . . ...........6
7. Accessories ..................7
•ECG...................7.1
• Respiration . .................7.1
• Temperature ................7.2
• Pulse Oximetry ................7.3
• Non Invasive Blood Pressure ...........7.4
• Capnography (Optional) . . ...........7.5
• Invasive Blood Presure (Optional) .........7.7
• Grounding cable ...............7.7
8. Trouble Shooting And Waveforms ..........8
• Troubleshooting Chart . ...........8.1
• Error Messages . . . ...........8.3
• Problems Observed During ECG Monitoring .......8.9
• Problems Observed During CO2Monitoring .......8.15
9. Technical Specifications . . . ...........9
• Technical Specifications . . ...........9.1
• Electro Magnetic Capability Information And Manufacturer's Declaration 9.16
10.Warranty And Warranty Service . ...........10

Star 55
Exemptions
L&T's liability under this warranty does not include any transportation damage or
other charges or liability for direct, indirect or consequential damages or delay
resulting from improper use or application of the product or the substitution upon it
of parts or accessories not approved by L&T.
Copyright
L&T owns all rights to the manual and intends to maintain this manual as confidential.
L&T also seeks to maintain this manual as a copyright. This manual is to be used
solely for the purpose of reference, operation and maintenance of L&T equipment.
The contents of this manual are proprietary. Reproduction or distribution of any part
of this manual in any form is prohibited.
Due to continuous updating of technology, the specifications, as well as information
in this manual, are subject to change without prior notice.
All information in this manual is believed to be correct. L&T shall not be liable for
errors contained herein with the performance or use of this manual.
Standards
This equipment has been designed to meet the following International standards:
Class 1 equipment requirement of IEC 60601-1.
EMI/EMCrequirementsasper IEC 60601-1-2.
IEC60601-2-27 requirements for ECG.
IEC60601-2-30requirementsforNIBP.
IEC60601-2-34 requirementsforIBP.
IEC 60601-1-8 requirements for alarm systems.
IEC 60601-2-49 requirements for multifunction patient monitor systems.
ISO 9919 requirements for SpO2.
ISO 21647 requirements for CO2.
AAMIEC13forECG.
AAMISP10forNIBP.
Regulatory Requirement
"United States law restricts this device to sale or use by or on the order of a physician"
Disposal Instructions
• Follow the local regulations and procedures for the disposal of unit and battery.
i

ii
Caution
Cautions are intended to alert you to the importance of following correct operating
procedures to prevent the risk of damage to the system.
zElectrical installation of the room or the building in which the equipment is to be used,
should comply with regulations specified by the country in which the equipment is to be
used.
zIf earthing arrangements are suspected, the monitor must be connected to a mains line
withproperearthconnectiontoensurecorrectreadings.
zThe equipment should be used in accordance with the "instruction for use" provided by
L&Tandasspecifiedonthe rear panelofthe monitor.
zIfanyfunctionofthemonitorfails,then consult L&TMedicalauthorizedservice engineer.
zFailureto meetventilation requirementmaycauseequipmentfailure andinternjeopardise
thefunctionsofautomatedmonitoring.Donotplaceequipment in an enclosed area that
couldrestrict heat dissipation from the front or rear oftheunit.
zKeep pacemaker patients under close observation. Rate meters may continue to count
thepacemakerrateduringcardiacarrestandsome arrhythmia.
zThisequipmentismeantfor use by qualified medical personnel only.
zForthedisposalofbatteryafter its life, follow the local regulations and procedures.
Readall the Cautions,Warnings and Notesprovided throughout the Operating Manual
before using the monitor.

Star 55
WARNING
WARNINGs are intended to alert you to the importance of following correct operating
procedures where risk of injury to the patient or system user exists.
zAll modifications and repairs should be carried out by authorized L&T personnel or
authorized agents.
zAlarms:
Adjusting the alarm volume to a low level or switching OFF alarms during patient
monitoring may result in alarm conditions going unnoticed. Hence do not rely
fully on audible alarm.
The most reliable method of patient monitoring combines close personal surveillance
with correct operation of monitoring equipment.
zAfterAC power is resumed keep the monitor ON for 16 hours to charge the battery, if
low battery indicator is displayed.
zWhen'lowbattery'indicationcomesonscreen,connecttheunittomainsupplyandkeep the
unitfor charging.
zUse only L&T approved accessories and battery.
zDo not use damaged cables/sensors, cuffs and contaminated accessories.
zWhenseveralequipmentof different companies/makes are interconnected through the
same mains power distribution line, the summation of the resulting leakage
currents may exceed the maximum limits.
zExplosionhazardsarepossible if used in the presence of flammable anesthetics.
zForcontinuedprotectionagainstfirehazard,usefusesofonlyspecifiedtypeandrating.
z'Electricalshockhazard'.Donotremovecover.Refertoqualifiedpersonnelforservicing.
zPatientsafetyand performance of this unit when connected to patients undergoing magnetic
resonance diagnostic procedures is unknown. It is advice that all sensors and cables
usedwiththisunitshouldberemovedfrompatientduringsuch procedures.
zL&T medical does not assume responsibility for damage to the equipment caused by
improperlyventilatedcabinets,improper orfaulty powerorinsufficient wallstrength incase
ofwallmountedunits.
zDonotusethemachinewithnuclearspintomography(MRT,NMR,NMT)asthefunction of the
machinemaybedisturbed.
zPayextraattentionifthepartsoftheequipmentareprovidedwithprotectionsagainstburning the
patientwhen used with High Frequency (HF) surgicalequipment.
zObserveextremecautionwhenadefibrillator is used on a patient. Do not touch any part
ofpatient,tableormonitorwhen a defibrillator is in use.
iii

iv
Unpacking
Check for any signs of transportation damage after removing the Patient Monitor from
the packing carton. Verify the material in the packing carton as per the packing list
sent along with the monitor.
Preserve the packing carton as it may required/useful for future use.

Star 55
Indication For Use
The Star 55 multiparameter patient monitoring system is intended to monitor a single
adult, pediatric or neonatal patient's vital signs at the bedside or during intra-hospital
transport along with the appropriate accessories mentioned / supplied with the unit.
Vital signs parameter include ECG (3/5 lead), SpO2, Respiration, Temperature ,
Capnography (CO2) and can be connected to an optional External Gas module unit.
It can also display the digital values of HR/PR, SpO2, RR, Invasive and Non-invasive
Blood Pressure (Systolic, Diastolic and Mean), EtCO2, FiCO2and temperature.
Parameters like N2O, O2, EtAA and FiAA can be displayed when connected to the
optional External Gas module unit.
The user, responsible to interpret the monitored data made available, will be a
professional health care provider. The device permits patient monitoring with
adjustable alarm limits as well as visible and audible alarm signals. The monitor is
not intended for home use.
v

Handling Precautions
Thismonitoris intended for use by only qualified medical personnel.
Pleaseread these precautions thoroughly before attempting to operatethismonitor.
1. For effective use of monitor , operation of the unit must be fully understood.
2. While installing or storing the monitor, take the following precautions.
zAvoid moisture or contact with water, extreme atmospheric pressure,
excessivehumidity and temperatures, poorly ventilated areas and dustyair.
zThemonitorshouldbe placedon aneven, levelfloor. Vibrationandmechanical
shockshould be avoided even duringmoving.
zAvoidplacing in an area wherechemicalsarestored or where there is danger
ofgas leakage.
zThe power line source to be applied to the monitor should correspond in
frequencyandvoltage to specifications, and haveallowablecurrentcapacity.
3. Before Operation
zCheckthatthemonitorisinperfectoperatingorder.
zCheckthatthe monitor is grounded properly.
zCheckthatallaccessoriesareconnected properly.
zPayextra attention when the monitor is in combinationwithotherinstruments
toavoidmisdiagnosisorotherproblems.
zAllcircuitryusedfordirectpatientconnectionmustbedoublychecked.
zCheckthattheunitis not indicating low battery.
vi

Star 55
4. During Operation
zBoththemonitorand the patient must receive constant, careful attention.
zTurnpower OFF or remove electrodes and cableswhennecessarytoassure
patient'ssafety.
zAvoid direct contact between the monitor and the patient.
zExtra care should be taken when the monitor is in use with the HF Surgical
Equipment.
Note:
The applied parts of NIBP and CO2are protected against HF surgical burns and
theappliedpartsofECG,SpO2,IBPand Temperatureare not protected.
5. To ShutdownAfter Use
zTurn power OFF with all controls returned to their original positions.
zRemove all accessories gently, do not use force to remove them.
vii

viii
Symbols
Logo
Mains 110 / 230 Volts ON indicator
Unit ON indicator
Equipotential ground
Attention, refer to manual
Defibrillation – Proof type-CF of Applied Part
Defibrillation – Proof type-BF of Applied Part
Global Alarm suspended
Alarm Acknowledge
Indicates valid QRS/Pulse detection
Indicates detection of PR from Plethysmograph
Indicates detection of PR from NIBP
$ Indicates detection of PR from IBP
~
!
*
Authorised representative in the european community
Manufacturer

Star 55
Monitor ON/OFF
NIBP measurement Start/Stop
Recorder ON/OFF
Freeze/Defreeze
Goto
Stand By
Home
CO2Pump
NIBP Trend
ECG Lead selection
ECG Gain adjustment
Display Format selection
Beep and Alarm Volume adjustment
PR Source selection
NIBPTimer
LeftNavigator
SelectionKey
RightNavigator
AutoZeroing ofIBP
Drug Calculation window
ix

x
Acronyms andAbbreviations
SpO2OxygenSaturationin%.
HR HeartRate (derived from ECG).
BPM Beats Per Minute (HR/PR).
BPM Breaths Per Minute (RR).
FLT Fault.
SYS SystolicBlood Pressure.
DIA Diastolic Blood Pressure.
MEAN MeanBlood Pressure.
CHECKHR Displayed Heart Rate may not be valid (More than 30 BPM diff).
RECORDING... IndicatesthatRecordingisinprogress.
PR Pulse Rate.
RR RespirationRate.
EtCO2EndTidalCarbondioxide
FiCO2FractionalInspiredCarbon dioxide
CVP CentralVenousPressure
LVP Left Ventricular Pressure
IBP Invasive Blood Pressure
ICP Intracranial Pressure
PAP Pulmonary Artery Pressure
LAP Left Atrial Pressure
RAP Right Atrial Pressure
ART Arterial Blood Pressure
DPI DotPer Inch

Star 55
CNS CentralNursingStation
PA PhysiologicalAlarm
TA TechnicalAlarm
NA NoAlarm
CIC CommunicationInterface Card
xi

Star 55
1
1
DISPLAY, CONTROLS,
CONNECTIONS
AND OUTPUTS

Figure 1.1
23
15 19 16 17 22
18
21
20
1 234 5 6 7 8 9 10 11 12 13 14
Front Panel
1.1

Star 55
Front panel description
1 Monitor ON/OFF switch To switch ON or switch OFF the monitor (Unit should
be connected to the mains supply or to the internal
battery).
2 MainsIndicator AmbercolorLEDturnsONwhen monitor is connected
to Mains.
3 Remote Sensor To sense the remote signals.
4 MonitorON indicator GreenLED ON indicates Monitor ON.
AmberLEDOFFand Green LED ON indicates unit
isONinbattery operation mode.
5 Alarmsuspend/ On pressing this key all audio alarmsaremutedor
Acknowledge suspended.WhenAudio/Visualalarms areindicated
bytheunit, this key actsasalarmackowledge key.
6 NIBPStart/Stop This key is used to start/stop the Auto/Manual NIBP
mesurement.
7 Freeze/Defreeze This key is used to Freeze/Defreeze the screen.
8 Record ThiskeyisusedtoStart/Stop the recording.
9 Goto Thiskeyusedasa short cut key for Menu option.
10 ' IBP Zero' This key is used to make invasive blood pressure
value zero (Ensure that the IBP transducer is
connected to the unit).
11 CO2pump This key is used to ON CO2 pump when in use
and OFF when not in use.
12 Stand By This key is used for the monitor to go to stand by
mode. Press again this key to monitor real time
screen. Stand By mode is a power saving option.
13 Home To go back directly to the Main screen, from any
otherscreen.
14 OpticalEncoder This is a special rotating knob used for multipurpose
applications.Rotatingtheopticalencoderinclockwise
or anti-clockwise direction, moves the cursor
(highlighted rectangular block) right or left in the Menu
area of the screen. Pressing the optical encoder
selectstheparticularfunction.
15 Yellow MessageArea Displays error messages in black text with yellow
background
1.2
