Lawn-Boy Silver Series User manual

Operator’s Manual
Manuel de L’Utilisateur
Manual del Operador
FORM NO. 3319–477 Rev A
Silver Series
Walk-behind Power Mower
Model No. 10200, 10248, 10249, 10313, 10321, 10327, 10328,
10330 — 8900001 & Up
Série Silver
Tondeuse motorisée à guidage arrière
Modèle No. 10200, 10248, 10249, 10313, 10321, 10327, 10328,
10330 — 8900001 et suivants
Serie Silver
Cortadora de césped motorizada empujada por
el usuario
Modelos N. 10200, 10248, 10249, 10313, 10321, 10327, 10328,
10330 — 8900001 y siguientes

The engine exhaust from this product
contains chemicals known to the State of
California to cause cancer, birth defects,
or other reproductive harm.
WARNING:
Les gaz d’échappement du moteur de ce
produit contiennent des produits
chimiques reconnus dans l’état de
Californie comme cancérigènes,
responsables de malformations
congénitales, ou comme nocifs à l’égard
des fonctions de la reproduction.
AVERTISSEMENT:
El escape del motor de esta herramienta
contiene productos químicos que según
la información del Estado de California
producen cáncer, defectos congénitos u
otros riesgos reproductivos.
ADVERTENCIA:

Lawn-Boy Inc. – 1997
Printed in USA All Rights Reserved
i
Figures — Figuras
1064

English
1. Model and serial number decal
Français
1. Décalcomanie de numéros de modèle et de série
Español
1. Calcomanía con los números de modelo y serie
1068
2 1
English
1. Knob 2. Top handle half
Français
1. Bouton 2. Moitié supérieure du
guidon
Español
1. Perilla 2. Mitad superior del manillar
1026
1
2
3
English
1. Low setting
2. High setting 3. Cable anchor –
self-propelled model
Français
1. Position basse
2. Position haute 3. Ancrage de câble -
modèles autopropulsés
Español
1. Ajuste bajo
2. Ajuste alto 3. Anclaje del cable -
modelos autoimpulsados
m-3711
1
English
1. Spark plug wire
Français
1. Fil de bougie
Español
1. Cable de la bujía
1
2
3
4

Figures — Figuras
ii
996
1
2
English
1. Cover plate 2. Wing screw
Français
1. Obturateur 2. Vis à ailettes
Español
1. Placa cobertora 2. Tornillo de mariposa
995
1
English
1. Shoulder bolt
Français
1. Boulon à épaulement
Español
1. Perno con resalte
m-3717

English
1. Dipstick
Français
1. Jauge d’huile
Español
1. Varilla de nivel
m-3713
1
English
1. Fuel tank cap
Français
1. Bouchon du réservoir de carburant
Español
1. Tapa del depósito de combustible
5
6
7
8

Figures — Figuras
iii
1058
1035
1
Models — Modéles — Modelos:
10200, 10249, 10313 & 10321
English
1. Primer
Français
1. Amorceur
Español
1. Cebador
m-3714
1
Models — Modéles — Modelos:
10248, 10327, 10328 & 10330
English
1. Primer
Français
1. Amorceur
Español
1. Cebador
m-3712
1
3
2
English
1. Blade control bail
2. Upper handle 3. Starter handle
Français
1. Barre de commande de la
lame 2. Guidon
3. Poignée du démarreur
Español
1. Palanca de control de la
cuchilla 2. Manillar superior
3. Palanca de arranque
9
10
11
12

Figures — Figuras
iv
1060

English
1. Blade control bail
Français
1. Barre de commande de la lame
Español
1. Palanca de control de la cuchilla
1017
1
English
1. Self-propelled bail
Français
1. Barre de commande d’autopropulsion
Español
1. Palanca autoimpulsada
1016
1
English
1. Self-propelled bail
Français
1. Barre de commande d’autopropulsion
Español
1. Palanca autoimpulsada
1021
1
English
1. Wheel height adjustment lever
Français
1. Levier de réglage de la hauteur de coupe
Español
1. Palanca de ajuste de la altura de la rueda
13
14
15
16

Figures — Figuras
v
1034
2
1
3
4
Models — Modéles — Modelos:
10200, 10249, 10313 & 10321
English
1. Cover
2. Filter 3. Tab 4. Slot
Français
1. Couvercle
2. Filtre 3. Languette 4. Encoche
Español
1. Cubierta
2. Filtro 3. Lengüeta
4. Ranura
ÌÌÌÌÌ
ÌÌÌÌÌ
ÌÌÌÌÌ
ÌÌÌÌÌ
ÏÏ
ÏÏ
ÏÏ
m-3715
2
3
1
Models — Modéles — Modelos:
10248, 10327, 10328 & 10330
English
1. Cover
2. Filter 3. Pre-cleaner
Français
1. Couvercle
2. Filtre 3. Préfiltre
Español
1. Cubierta
2. Filtro 3. Pre-filtro
m-988
m-989
17
18
19
20

Figures — Figuras
vi
1067
1
English
1. Oil fill tube
Français
1. Tube de remplissage d’huile
Español
1. Tubo de llenado del aceite
.030 in.
(.76 mm)
986
1036
1005
21
22
23
24

Figures — Figuras
vii
M–2909
1
2
3
4
Models — Modéles — Modelos:
10200, 10249, 10313 & 10321
English
1. Blade nut
2. Mulching fan 3. Blade 4. Blade driver
Français
1. Écrou de lame
2. Hélice de paillage
3. Lame
4. Plaque d’entraînement de
lame
Español
1. Tuerca de la cuchilla
2. Ventilador de distribución
de fertilizantes orgánicos
3. Cuchilla
4. Accionador de la cuchilla
m-37101
2
3
Models — Modéles — Modelos:
10248, 10327, 10328 & 10330
English
1. Blade nut
2. Blade 3. Blade driver
Français
1. Écrou de lame
2. Lame 3. Plaque d’entraînement de
lame
Español
1. Tuerca de la cuchilla
2. Cuchilla 3. Accionador de la cuchilla
990
2”
(51 mm)
5”
(127 mm)
25 26
27

Figures — Figuras
viii
1007
1024
1018
1
English
1. Grease fitting
Français
1. Graisseur
Español
1. Engrasador
1063
1
2
3
4
5
English
1. 1 to 1!/2in. (25 to 38 mm)
2. Self -propelled bail
3. Cable jacket
4. Cable support
5. Nut
Français
1. 2 à 4 cm (1 à 1 1/2 po.)
2. Barre de commande
d’autopropulsion
3. Gaine du câble
4. Serre–câble
5. Écrou
Español
1. (25 a 38 mm) (1 a 1!/2
pulgadas)
2. Palanca autoimpulsada
3. Envoltura del cable
4. Soporte del cable
5. Tuerca
28
29
30
31

Figures — Figuras
ix
1040
1 2
English
1. Belt cover 2. Tab
Français
1. Garde de la courroie 2. Languette
Español
1. Cubierta de la correa 2. Lengüeta
1073
1
2
3
Rear bag — Sac à herbe arrière — Bolsa trasero
English
1. Chute baffle
2. Deck baffle 3. Toe guard
Français
1. Chicane de la chute
2. Chicane du carter 3. Garde de pieds
Español
1. Deflector de la rampa
2. Deflector de la cubierta 3. Protección del pie
955
2
3
1
Side bag — Sac latéral — Bolsa lateral
English
1. Chute baffle
2. Front deck baffle 3. Toe guard
Français
1. Chicane de la chute
2. Chicane de l’avant du
carter
3. Garde de pieds
Español
1. Separador del conducto
2. Separador del forro
delantero
3. Contrarresguardo
32
33
34

Figures — Figuras
x
1013/1014
3
21
English
1. Chute support rod
2. Chute assembly 3. Wing screw
Français
1. Tige de support de la
chute 2. Ensemble de chute
3. Vis à ailettes
Español
1. Varilla de soporte de la
rampa 2. Conjunto de la rampa
3. Tornillo de mariposa
1072
1
2
3
English
1. Chute baffle
2. Front deck baffle 3. Toe guard
Français
1. Chicane de la chute
2. Chicane de l’avant du
carter
3. Garde de pieds
Español
1. Deflector de la rampa
2. Deflector delantero de la
cubierta
3. Protección del pie
35 36

Figures — Figuras
xi
1011
2
1
3
4
English
1. Knob
2. Bolt 3. Hanger clamp 4. Bag hanger
Français
1. Bouton
2. Boulon 3. Bride du porte-sac 4. Porte-sac
Español
1. Perilla
2. Perno 3. Abrazadera del colgador 4. Colgador del saco
1012
1010
1607
1
English
1. Knob
Français
1. Bouton
Español
1. Perilla
37
38
39
40

Figures — Figuras
xii
1608
1609
1
English
1. Bag rod
Français
1. Tige de sac
Español
1. Varilla de la bolsa
1614
1616
1
English
1. Bag rod
Français
1. Tige de sac
Español
1. Varilla de la bolsa
41
42
43
44

Figures — Figuras
xiii
1008
3
1
2
English
1. Mulch plate
2. Shoulder bolts 3. Wing screw
Français
1. Plaque de paillage
2. Boulons à épaulement 3. Vis à ailettes
Español
1. Placa distribuidora de
fertilizantes orgánicos 2. Pernos con resalte
3. Tornillo de mariposa
1072
1
2
3
English
1. Chute baffle
2. Front deck baffle 3. Toe guard
Français
1. Chicane de la plaque de
paillage 2. Chicane du carter avant
3. Garde de pieds
Español
1. Deflector de la rampa
2. Deflector delantero de la
cubierta
3. Protección del pie
45 46

Figures — Figuras
xiv
1009
1039
1068
47
48
49

EN–1
Contents
Page
Introduction 1. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safe Operating Practices 2. . . . . . . . . . . . . .
Safety and Instruction Decals 4. . . . . . . . . .
Assembly 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Handle 5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cover Plate 5. . . . . . . . . . . . . . . . . . . . . . . . .
Before Starting 5. . . . . . . . . . . . . . . . . . . . . . . . . .
Oil 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gasoline 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Lawn Preparation And Mowing 6. . . . . . . . .
Operation 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Engine 7. . . . . . . . . . . . . . . . . . . . . .
Stopping Engine 7. . . . . . . . . . . . . . . . . . . . .
Self–propelled Drive 7. . . . . . . . . . . . . . . . .
Adjusting Cutting Height 7. . . . . . . . . . . . . .
Mulching Tips 8. . . . . . . . . . . . . . . . . . . . . .
Maintenance 9. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Maintenance Schedule 9. . .
Air Filter 10. . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Filter 10. . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Engine Oil 11. . . . . . . . . . . . . . . . . . .
Spark Plug 11. . . . . . . . . . . . . . . . . . . . . . . . .
Clean Mower Housing 11. . . . . . . . . . . . . . . .
Blade 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication 14. . . . . . . . . . . . . . . . . . . . . . . . .
Self-propelled Cable 14. . . . . . . . . . . . . . . . .
Self-propelled Drive Cleaning 14. . . . . . . . . .
Troubleshooting 15. . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 16. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Grass Catchers 16. . . . . . . . . . . . . . . . . . . . . .
Mulch Plate 17. . . . . . . . . . . . . . . . . . . . . . . .
Storage 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 18. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Folding Handle 19. . . . . . . . . . . . . . . . . . . . . .
Removing From Storage 19. . . . . . . . . . . . . .
Warranty 20. . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction
Thank you for purchasing a Lawn-Boy product.
All of us at Lawn-Boy want you to be completely
satisfied with your new product, so feel free to
contact your local Authorized Service Dealer for help
with service, genuine Lawn-Boy parts, or other
information you may require.
Whenever you contact your Authorized Service
Dealer or the factory, always know the model and
serial numbers of your product. These numbers will
help the Service Dealer or Service Representative
provide exact information about your specific
product. You will find the model and serial number
decal located in a unique place on the product
(Fig. 1).
For your convenience, write the product model and
serial numbers in the space below.
Model No.
Serial No.
Read this manual carefully to learn how to operate
and maintain your product correctly. Reading this
manual will help you and others avoid personal injury
and damage to the product. Although Lawn-Boy
designs, produces and markets safe, state-of-the-art
products, you are responsible for using the product
properly and safely. You are also responsible for
training persons who you allow to use the product
about safe operation.
The Lawn-Boy warning system in this manual
identifies potential hazards and has special safety
messages that help you and others avoid personal
injury, even death. DANGER, WARNING and
CAUTION are signal words used to identify the level
of hazard. However, regardless of the hazard, be
extremely careful.

EN–2
DANGER signals an extreme hazard that will cause
serious injury or death if the recommended
precautions are not followed.
WARNING signals a hazard that may cause serious
injury or death if the recommended precautions are
not followed.
CAUTION signals a hazard that may cause minor or
moderate injury if the recommended precautions are
not followed.
Two other words are also used to highlight
information. “Important” calls attention to special
mechanical information and “Note” emphasizes
general information worthy of special attention.
Safety
This machine meets or exceeds CPSC blade safety
requirements for walk–behind rotary mowers and
the B71.1 specifications of the American National
Standards Institute, in effect at time of
production. However, improper use or
maintenance by the operator or owner can result
in injury. To reduce the potential for injury,
comply with these safety instructions and always
pay attention to the safety alert symbol which
means CAUTION, WARNING or
DANGER—“personal safety instruction.” Failure
to comply with the instruction may result in
personal injury.
Safe Operating Practices
This product is capable of amputating hands and feet
and throwing objects. Always follow all safety
instructions to avoid serious injury or death.
POTENTIAL HAZARD
•Engine exhaust contains carbon monoxide,
which is an odorless, deadly poison.
WHAT CAN HAPPEN
•Carbon monoxide can kill you and is also
known to the State of California to cause
birth defects.
HOW TO AVOID THE HAZARD
•Do not run engine indoors or in an enclosed
area.
This mower is designed for cutting and mulching
grass or, when equipped with a grass bag, for
catching cut grass. Any use for purposes other than
these could prove dangerous to user or bystanders.
Note: This engine is NOT equipped with a
spark arrester muffler. Use or operation
of this mower in the State of California
on any forest-covered, brush-covered
or unimproved grass-covered land,
without an approved spark arrester
muffler, is a violation of the law. Other
states may have similar laws.
General Operation
1. Read this manual carefully before operating the
mower. Become familiar with the controls and
proper use of the mower. Never allow children to
operate the mower or adults to operate it without
proper instructions.
2. Keep everyone, especially children and pets,
away from area of operation. Thoroughly inspect
area where mower will be used and remove
sticks, stones, wire, and debris.
3. Wear long pants and substantial shoes. Do not
operate mower while wearing open-toed shoes,
loose clothing, jewelry or when barefoot.
4. Check fuel level before starting engine. Do not
fill fuel tank indoors, when the engine is
running, or until engine cools for several
minutes after running. Wipe up spilled gasoline
before starting engine.

EN–3
5. Keep all guards, shields (including rear trailing
shield), grass catchers and safety devices in
place. Repair or replace damaged parts,
including decals.
6. Engine, blade and self–propelled drive are
designed to stop when control bails are released.
Ensure control and brake function properly
before each use of mower.
While Operating
1. Do not run engine indoors.
2. Always maintain secure footing. Keep a firm
grip on the handle and walk; never run. Never
operate mower in wet grass. Mow only in
daylight or in good artificial light.
3. Mow across the face of slopes; never up and
down. Use extreme caution when changing
direction on slopes. Do not mow excessively
steep slopes.
4. Always wear safety glasses or eye shields during
operation to protect eyes from foreign objects
that may be thrown from the machine. Keep
face, hands, and feet away from the mower
housing and cutter blade when the engine is
running. Stay behind the handle until the engine
stops.
5. Since the blade rotates for a few seconds after
the blade control bail is released, stay behind the
handle until all movement stops.
6. After striking a foreign object or if mower
vibrates abnormally, stop engine and remove
wire from spark plug. Check mower for damage
and make all repairs before using mower again.
7. Stop the engine before adjusting the
height–of–cut.
8. Stop the blade/engine when crossing a gravel
driveway, road, or sidewalk.
9. Stop engine before leaving the operator’s
position – behind the handle. Disconnect wire
from spark plug if mower will be unattended.
10. Do not touch engine while it is running or
shortly after it is stopped because engine will be
hot enough to cause a burn.
Maintenance
1. Perform only those maintenance instructions
described in this manual. If major repairs are
ever needed or if assistance is desired, contact
your local Authorized Lawn–Boy Service
Dealer.
2. Before mower is cleaned, inspected, serviced, or
adjusted, stop engine and disconnect wire from
spark plug. Keep wire away from plug to prevent
accidental starting.
3. To assure the mower is in safe operating
condition, frequently check and keep all nuts,
bolts, and screws tight. Assure blade nut/screw is
tightened to 63 Nm (47 ft.–lbs.).
4. To reduce fire hazard, keep engine free of
excessive grease, grass, leaves, and
accumulations of dirt.
5. Allow engine to cool before storing mower in
any enclosure. Do not store mower near any
open flame or where gasoline fumes may be
ignited by a spark.
6. Do not overspeed the engine by changing
governor settings.
7. At the time of manufacture, the mower
conformed to the safety standards in effect for
rotary mowers. To ensure best performance and
continued safety certification of the mower, use
genuine Lawn–Boy replacement parts and
accessories.

EN–4
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near
any area of potential danger. Replace any decal that is damaged or lost.
ON MOWER HOUSING
(Part No. 39–5770)
ON MOWER HOUSING
(Part No. 92–1097)
BY FRONT WHEELS
(Part No. 92–2914 Right)
(Part No. 92–2915 Left)
ON MUFFLER GUARD
(Part No. 65–2690)
ON MOWER HOUSING
(Part No. 93–7250)
ON MOWER HOUSING
(Part No. 92–4851)
