USER GUIDE
LC SCS136W
LC SRS149W
LC SRS236W
LC SRS115W
Staff Room Products
Part No: 083664300 Date: 17/07/2017

The installation of this appliance is best carried
out by 2 people.
• Dispose of all packaging carefully and re-
sponsibly.
• The appliance is designed for indoor use
only and must be protected from rain, mois-
ture and extreme temperature variations.
• TheapplianceMUSTbepositionedonarm
level base. Do not splash water on the ap-
pliance. It may cause electrical parts to fail
and result in an electric shock.
• Leave the appliance in its intended place of
installation and in its correct orientation for
at least 4 hours before switching on to allow
thecoolingsystemtosettlebeforerstuse
or after any transportation.
• Your appliance is an environmental friendly
product and it contains non CFC / HFC gas
substances in the cooling system (Called
R600a) and in the insulation (Called cyclo-
pentane)whicharepotentiallyammable
ifexposedtore.Therefore,takecarenot
to damage, the cooling circuit / pipes of the
appliance in transportation and in use. In
case of damage do not expose the appliance
tore,potentialignitionsourceandimmedi-
ately ventilate the room where the appliance
is situated.
• Do not sit, stand or place any other heavy
objects on top of the appliance. This could
result in injury or damage to the appliance.
• Keep ventilation opening, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
BEFORE USE

SAFETY
Disposal of old appliances
Remove any plugs and power leads to ensure
that the appliance is inoperative.
Please note: This symbol means
that products bearing it may not be
disposed of with household waste.
The refrigeration system contains insulat-
ing gases and refrigerant which will require
specialist disposal. Most components can be
recycled. Always contact your local council or
authority for information regarding the cor-
rect disposal/removal of old appliances, do
not dispose of with household waste.
WARNING: When disposing
of an old appliance make sure
that the pipe work does not
become damaged.
Packaging
All of the packaging supplied with your appli-
ance can be recycled, or disposed of without
any harm to the environment.
Cardboard may be crushed, or cut into small-
er pieces if required for recycling or dispos-
al. The polythene and polystyrene included
contain no CFC’s , and are environmentally
friendly.
For further information on recycling, contact
your local council or authority.
• Before installing and using your new
appliance. Read through the instruction s
supplied with your appliance - failure to
install or use this appliance in accordance
with the instruction book may invalidate
any warranty.
• The manufacturer does not accept any
liability for damage caused through im-
proper use, or incorrect installation.
• Do not install this appliance if it has been
damaged during transportation. This in-
cludes the plug and power supply cord.
• Always install this appliance in line with
these instructions.
• Always read these instructions fully before
usingtheapplianceforthersttime.
WARNING:
• Do not allow the refrigerant
circuit to become damaged
while using or installing.
Should it become damaged,
do not use the appliance
until you are instructed to
do so by a service engineer
[Refrigerant can ignite or
cause damage to the eye
when leaking]
• Always remember to unplug
the appliance before clean-
ing. When disconnecting
from the electricity supply,
pull the plug, not the power
cord.
• Do not use any electrical
appliance inside the food
storage area - unless they
are recommended by the
manufacturer.
• All electrical repairs must
be carried out by a quali-
edelectrician.Inadequate
repairs may result in a ma-
jor source of danger for
the user and invalidate any
warranty.
• Never store anything dan-
gerous inside the appliance,
such as combustibles, ex-
plosives, strong acid and
alkali etc.

SAFETY
• Never store alcohol in a
freezer
• Do not store liquids in glass
containers in the freezer
compartment as these may
shatter.
• Always keep any ventilation
openings clear of obstruc-
tion. Should they become
blocked, clear them straight
away.
• Make sure that the plug is
in an accessible place when
installation is complete and
remove all packaging.
• Refrigerating appliances
might not operate consist-
ently when sited for an ex-
tended period of time below
the cold end of the range of
temperatures of the appli-
ance.
• Do not store explosive
substances.
• Do not use mechanical,
electrical or chemical way
to speed up the defrost
process not recommended
by the manufacturer.
• Do not use or place other
electrical products inside
the appliance not recom-
mended by the manufactur-
e r.
• Incasethereisaninam-
mable gas leaking, open
the window for air circula-
tion and do not pull out the
plug or turn the tempera-
ture knob. Do not touch the
appliance until the valve
of gas is turned off. Other-
wise, sparks may happen.
• Do not attempt to repair
the appliance yourself. Con-
tactcontactaqualiedser-
vice engineer.
• When defrosting the appli-
ance, never use sharp or
pointed metal implements.
Always use a plastic scrap-
er. (see Defrosting for more
information)
• Do not damage the refriger-
ant circuit
• When positioning the ap-
pliance ensure the supply
cord is not trapped or dam-
aged.
• Do not locate extension
sockets or charging trans-
formers/power supplies ad-
jacent to the compressor as
they could overheat.

ABOUT YOUR PRODUCT
LC SRS136W LC SRS149W
LC SRS115W LC SRS236W
Top cover
Lightbulb
Glass shelves
Crisper
Fixed foot
Adjustable foot
Freezer shelf
Top Cover
Door shelves
Door Top cover
Light bulb
Glass
shelves
Crisper
Feet
Door
shelves
Big door
shelf
Big door shelf
11
2
3
6
7
5
4
2
8
9
7
6
3
4
5
1
1
3
6
5
9
8
7
4
22
Thermostat &
Lighht housing
Light Bulb
Glass shelf (2)
Glass crisper cover
Mains plug
Salad crisper
Leveling Foot
Bottle shelf
Door shelf (2)
Glass shelves 3
Crisper 4
Door shelves
5
Big door shelf
6

Technical Specicaion
Model Description LC SRS115W LC SRS236W LC SRS136W LC SCS149W
Unit External Width (mm) 501 550 475 600
Unit External Depth (mm) 540 550 573 (w/handle)
550 (w/o handle) 600
Unit External Height (mm) 845 1420 1246 850
Fridge Gross Capacity
(litres) 115 236 100 149
Fridge Net Capacity
(litres) 112 235 97 147
Freezer Gross Capacity
(litres) N/A N/A 36 N/A
Freezer Net Capacity
(litres) N/A N/A 35 N/A
Climate Class
(if applicable) 4 4 4 4
Refrigerant Type R600a R600a R600a R600a
Refrigerant Mass (g) 18 20 27 35
This appliance operates at a voltage of: 220 - 240V ~ 50Hz
ThisapplianceisratedClimateClass4asdenedinBSENISO23953-2:2005
Climate class 4 operates in a climate up to 30oC and 55% humidity
ABOUT YOUR PRODUCT

INSTALLING YOUR APPLIANCE
Before you start
• This appliance must stand vertically on a
at,evensurface,toleveltheappliance,
use the levelling feet by turning them un-
til the appliance is as level as possible. Do
not install onto carpeted surfaces as this
prevents adequate ventilation.
• Install the appliance in a well ventilated
room. The appliance should not be placed
near any heat sources (cookers, heaters
etc.) or in any unheated rooms as the
ambient temperature affects the perfor-
mance of the appliance.
• Do not lift the appliance by the pipes or
the door when moving. Should the ap-
pliance become damaged, contact Lec
Customer Care and do not use the appli-
ance until you are instructed to do so by
a service engineer.
Installation Clearances
• Allow 300 mm clearance at the rear of
the appliance and adequate clearance
on each side of the appliance and over
the top to ensure proper ventilation (see
gures).
Getting Started
Once you have installed your appliance in
an appropriate location, follow the start up
procedure below:
• Before you plug in the appliance, clean
thoroughly the inside, and any accesso-
ries with warm water and bicarbonate of
soda (0.5ml to 0.5 litres) and dry with a
soft cloth.
• Leave the appliance to stand for 2 - 3
hours to allow the refrigerant to settle
following installation and cleaning. If the
appliance has been transported horizon-
tally, it must be left to stand vertically for
12 hours before installation.
• Once dry, plug the appliance into the
socket
• Turn the thermostat to the required set-
ting - a medium setting is usually suita-
ble.
• Leave the appliance for at least 4 hours
before storing any food inside to allow a
sufcienttemperaturetobereached.
LC SRS148W - X: 300mm Y: 100mm
LC SRS236W - X: 100mm Y: 25mm
X
Y
LC SRS115W - X: 25mm Y: 25mm

INSTALLING YOUR APPLIANCE
Caution: 2 people are required to unpack
and handle the appliance, it is recommended
that gloves are worn.
• The appliance should be transported only
in an upright position. Do not tilt the ap-
pliance greater than 45o. The packaging
as supplied must be intact during trans-
portation.
• After transporting the appliance, leave it
for at least 4 hours before switching on to
allow the cooling system to settle. Failure
to comply could result in damage to the
appliance.
• Do not move the appliance by pulling the
door or handle as it may damage your
ooringandwallcoveringsetc.
• Empty any water in the drain tray before
moving.
• Make sure that the defrost water pipe at
thebackoftheproductisxedtothe
plastic evaporating pan on the top of the
compressor, to avoid defrost water spill-
ageontheoor.
• Ensure the supply cable is not caught
under the appliance during and after
moving.
• Carefully remove all packaging materials
including the foam base, dispose of cor-
rectly.
• Makesurethatthesufcientroomispro-
vided around the appliance to ensure free
air circulation
• Screw in the two spacers (where applica-
ble) at the back of the appliance.
• Do not place the appliance near a heat
source or in direct sunlight.
• Do not put any heavy objects on top of
the appliance. It will damage the appli-
ance.
• Do not install the appliance in moist and
wet place.
• Adjust the feet at front to level the appli-
ance. It should be installed on a smooth
surface to avoid excessive vibration and
noise.
• Each appliance has a climate class (shown
on the rating plate) where it indicates the
temperature range of the appliance op-
eration in place. The appliance may not
work properly if it is left for a long period
atatemperatureoutsidethespecied
range.
• Refer to section “Care and Maintenance”
to prepare your appliance for use.

USING YOUR APPLIANCE
About the thermostat
The thermostat is located in the upper right
part of the appliance.
• To reduce the temperature inside the ap-
pliance, turn the thermostat towards the
highest.
• To increase the temperature inside the
appliance, turn the thermostat towards 1
minimum.
• Depending on the ambient temperature
of the room the appliance is in, you may
need to adjust the thermostat according-
ly.
CONDITION /
REASON
SETTING
ADJUSTMENT
Refrigeration too
cold - Not set correctly
for your conditions
Adjust TEMPERATURE
Control one setting
lower
Refrigeration too
warm - Door opened
often, large amount of
food added or room
temperature very warm
Adjust TEMPERATURE
Control one setting
higher
Freezer too cold -
Not set correctly for
your conditions
Adjust TEMPERATURE
Control one setting
lower
Freezer too warm /
too little ice - Door
opened often, large
amount of food added
or room temperature
very cold (can’t cycle
often enough) or heavy
ice usage
Adjust TEMPERATURE
Control one setting
higher
Tips for using this appliance
• Before storing cooked foods in the refrig-
erator, allow them to cool to room tem-
perature.
• To maintain adequate air circulation,do
notoverlltheappliance.Ifthereistoo
much food inside,the compressor does
not work as effectively.
• Do not open the door any more than nec-
essary- this will keep the temperature as
cold as possible inside.
• Ices and water ices should not be con-
sumed straight from the freezer - this can
cause ice burns to the tongue and hands.
• Never touch the inside of the appliance,or
any frozen items with wet hands. This can
cause injury to your hands if they stick to
cold surfaces.
• Wrap or cover foods well before storing.
Always make sure that any packaging
is air tight and suitable for use inside a
fridge or freezer.
• Cooked meats and raw meats should be
stored on separate shelves, and raw meat
should not be allowed to drip onto oth-
er foods. Should not be in direct contact
with already frozen food.
• You may hear gurgling noises or a hum-
ming sound while the appliance is in use
and this is perfectly normal when the
compressor is running and the coolant is
moving through the system.
• A clicking sound may be heard, this is the
thermostat and is normal.
• Effervescent(zzy)drinksshouldnotbe
stored in the freezer or low temperature
compartments.
• Do not exceed the storage times recom-
mended by the food manufacturer and
always check expiry dates.
• Do not wash shelf retention in hot water.
The drainage channel
The drainage channel collects water on the
back wall of the refrigerator and ensures that
it is drained away into a drip tray at the rear
of the appliance.

USING YOUR APPLIANCE
Final checks before operating the appli-
ance
1. Good air circulation around the appliance
positioned.
2. The feet have been adjusted for perfect
levelling.
3. Clean the compartment per recommenda-
tion in section “Care and Maintenance”.
4. Plug in the appliance and interior light will
come on when the door is open.
Important: The compressor starts up and in
operation may produce some background
noise and it is normal, this is not a defect.
Storing fresh food
• Use the fridge compartment to store fresh
food and drinks.
• Do not exceed the food capacity that the
appliance able to handle.
• Do not put warm food to the appliance
immediately as it may cause excessive
cooling of the compartment.
• Set the temperature knob at medium po-
sition for storing fresh food.
• Do not mix already frozen food and fresh
food.
The following guidelines and recommenda-
tions are suggested to obtain the best results
and storage hygiene.
• Frequent door openings can cause inter-
nal temperature rise so the door shall be
closed as soon as possible after use.
• For hygiene reasons, it is always a good
practise to pack, wrap and cover the food
before storing.
• Use a polythene bag to store raw meat
and place on the lowest shelf. Avoid con-
tact with cooked food to prevent contam-
ination. For safety reason, store raw meat
for two to three days only.
• Cooked dishes must be stored in airtight
covered containers.
• Food and beverages shall cool to room
temperature before storing.
• Most vegetables should be blanched and
chilled before freezing.
• Bottles can be placed in the door section.
• Some fruits and vegetables like pineap-
ples, melons, tomatoes, and cucumbers
shall be wrapped in polythene bags.
• Do not leave frozen food at room temper-
ature to thaw. You could defrost the food
by putting it in the fridge to thaw slowly.
Make sure you avoid defrosting food or
food juices drip onto other food.
Energy saving tips
• Cover all food stored, and arrange it so
that cold air can circulate freely.
• Higher cold setting will use more energy.
Do not set to maximum cold if it is not
necessary.
• Cool the hot/warm food to room tempera-
ture before put them into your fridge.
• Frequently open and close door would
cause internal temperature rise and it will
consume more energy.
• Close the door(s) properly, and make sure
the seals and hinges are airtight. Check
the seals by putting a sheet of paper
between the door and the main body of
the fridge. If the paper moves, your seals
need replacing.
We recommend a maximum weight of 10kg
per shelf for storage of goods

CARE & CLEANING
Before cleaning your appliance
You should always unplug this appliance be-
fore cleaning.
To clean your appliance
• Clean the inside of the cabinet with warm
water and a neutral detergent, do not use
harsh abrasives or caustic cleaners.
• Dry the inside of the cabinet with a soft,
dry cloth. Always make sure the inside of
the appliance is dry after cleaning.
• Avoid getting water into the electric com-
ponents of the appliance (i.e. the thermo-
stat), or spilling water on the fridge.
• When cleaning the door seals, use only
warm soapy water. Please use a mild soap
and avoid damaging the door seal as this
will affect the performance of your appli-
ance.
• Clean the outside of the appliance with
warm,soapy water and dry with a soft
cloth. Any accumulation of dirt and dust
should be removed from the back and
bottom of the appliance to maintain ade-
quate ventilation.
• If the appliance is not in use for a long
period of time, you should clean the
appliance as detailed. Make sure that it is
dry,then unplug and leave the door open
to prevent unpleasant smells inside.
Please note: Regular turning off may short-
en the life of this appliance.
Important: Always unplug the appliance
from the power socket during cleaning and
maintenance.
• Never use any sharp instruments or abra-
sive substances, soap, household cleaner,
detergent or wax polish for cleaning.
• Use luke warm water to clean the cabinet
of the appliance and wipe it dry.
• Nevercleantheappliancewithammable
uids.Itcouldcauseadamageandre
hazard.
• Clean the exterior of the appliance and
door seal with a damp cloth and dry it
through.
• Avoid water goes in the temperature con-
trol box. Clean with a dry cloth only.
• Clean the condenser (located at the back
of the appliance) with a vacuum cleaner.
It is suggested to remove the dust every
year.
• Shelves are all removable for cleaning
purpose.
Light bulb replacement
Proceed the following to replace a failure
bulb:
1. Switch off at the socket outlet and pull
out the mains plug.
2. Remove the light diffuser cover by pulling
the recess at the edge.
3. Replace the bulb with a new 10 watt
(max) screw cap (SES) bulb.
4. Assemble the light diffuser cover and
switch on.

TROUBLESHOOTING
Before calling Lec Customer care, please check the table below to see if the problem can be
solved without calling for a Service engineer.
Problem Solution
The fridge / freezer doesn’t work • Check that the appliance is switched on
• Check that the plug is not damaged
• Check that the fuse has not blown
• Check that the voltage is correct for the appli-
ance
• Turn the thermostat up higher
Unusual noises • Checkthattheapplianceisonaat,level
surface and is stable.
• Check that nothing is coming into contact with
the appliance.
The temperature inside the fridge / freezer is
not cold enough.
• Check that there is not too much stored in the
appliance.
• Check the frequency of door openings. If
opened too often this can cause the compres-
sor to run for some time.
• Check that the thermostat is set to a suitable
temperature.
• Check that the appliance is not in direct sun-
light,or near a heating source.
• Check that the ventilation grille has not be-
come blocked.
The temperature inside the appliance is too
cold
• Change the temperature setting to a more
suitable setting.
The outer surfaces of the fridge / freezer are
wet
• Caused by condensation - dry the outer of the
appliance carefully.
The inner surfaces of the fridge / freezer are
wet
• The door is opened frequently, or kept open
too long.
• Caused by condensation - dry the inside of
the appliance thoroughly.
Excess frost and ice has built up inside the
appliance.
• Check that the door has not been left open.
• Check that the door gasket is clean and un-
damaged.
Please note: Any damage caused by not following the instructions within this handbook may lead
to a charge for a service engineer visit and any repairs carried out.

Reversing the door
For the doors on the LC SRS149W
Warning: Remove the main plug before
reversing the door. 2 people may be required
to reverse the door.
1. 1. Remove the screws (6) holding the
top panel (7) to the unit. Remove the top
panel.
2. Remove the two screws (1) holding the
top hinge (5) (right side) to the frame.
Remove the top hinge (5).
3. Lift the door off the bottom hinge pin and
place it on a non-scratching surface.
4. Remove the two screws (8) holding the
bottom hinge (2). Remove the bottom
hinge (2).
5. Remove the left front feet (4) and
transfer it to the right side.
6. Before replacing the bottom hinge (2),
remove the hinge pin (9) and reverse the
direction of the hinge (2). Reassemble the
bottom hinge (2) on the left hand side
using the two screws (8).
7. Retthehingepin(9)intothebottom
hinge (2).
8. Lower the door onto the bottom hinge pin
(9).
9. While holding the door in the closed
position, reassemble the upper hinge
(5) on the left hand side using the two
screws (1). Do not tighten the screws (1)
until the top of the upper door is level
with the counter top.
10.Retthetoppanel(7)usingthescrews
(6)
REVERSING THE DOOR

For the doors on the LC SRS236W
Note: Please unplug the unit before action
1. Remove the right top hingercover.
2. Removethescrewsxedthetop-hingewithcross-slotscrewdriver.
3. Replace the top-hinge and the top-door limit block and the door bearing bush to the other
side. A) Remove the nut with sleeve.Take off the washer then remove the axes to the other
sideandxed.
B) Remove the door limit block
C) Please taking out another door limit block, with screw mounting to the door
REVERSING THE DOOR
Right top hinger cover
Screw (two)

REVERSING THE DOOR
4. Disassemblethescrewsxedthebot-
tom-hinge with cross-slot
Note: The refrigerator-freezer incline angles
less 450
5. Replace the bottom hinge to the other side
thenxitwithscrews.
6. Setthedoorrightposition,xthemid-hinge
7. Replace the top-hinge.
8. Setthetopdoorrightposition,xthetop-
hinge and the cover.
9. Replace the leveler to the other side and
adjust it to make sure the cabinet level.
Thescrewsxed
the bottom-hinge

REVERSING THE DOOR
For the doors on the LC SRS115W
1. Unscrew the top cover and take off it.
2. Unscrew the top hinge.
3. Re-install the top hinge pin, shaft sheath
and block piece on the opposite side. A:
Move the top hinge to opposite side
B: Move the shaft sheath and block piece to
opposite side also
4. Unscrew the three screws on the down
hinge and screw them on the opposite side.
5. Move the adjustable foot to the opposite
side.
6. Alignthedoorproperly,xthetophinge
and top cover.

CHANGING THE PLUG
Any electrical work required to install
this appliance should be carried out by a
qualiedelectricianorcompetentperson.
This appliance must be earthed. The
manufacturer declines any liability should
these safety measures not be observed.
Electrical Requirements
Before switching on, make sure the electricity
supply voltage is the same as that indicated
on the appliance rating plate. The appliance
issuppliedwitha13ampplugtted.Inthe
event of having to change the fuse in the
plug supplied, a 13 amp ASTA approved
(BS 1362) fuse must be used. Should the
plug need to be replaced for any reason.
The wires in the mains lead are coloured in
accordance with the following code:
Green and Yellow: Earth
Blue: Neutral
Brown: Live
The wire coloured green and yellow must
be connected to the terminal marked with
the letter “E” or by the earth symbol or
coloured green and yellow. The wire coloured
blue must be connected to the terminal
marked “N”. The wire coloured brown must
be connected to the terminal marked “L”.
Upon completion there must be no cut, or
stray strands of wire present and the cord
clamp must be secure over the outer sheath.
Important!
The plug must still be accessible after the
appliance has been installed. The appliance
should not be connected to the electrical
supply by means of an extension cable.
In case that the electrical cable has to be
replaced, please contact the Customer Care
Centre and arrange a service engineers visit.
WARNING: A cut off plug inserted into a
13 amp socket is a serious safety (shock)
hazard. Ensure that it is disposed of safely.
This appliance complies with the following
E.E.C Directives: 2006/95/EC (Low Voltage
Directive)andsubsequentmodications,
2004/108/EC (Electromagnetic Compatibility
Directive)andsubsequentmodications.
LC SRS115W model
A cut off plug inserted into a 13 amp socket
is a serious safety (shock) hazard. Ensure
that it is disposed of safely. This appliance
complies with the following E.E.C. Directives:
73/23 EEC of 19.02.73 (Low Voltage
Directive)andsubsequentmodications,
89/336 EEC of 03.05.89 (Electromagnetic
Compatibility Directive) and subsequent
modications.
Note: Figured in the user manual are only
for reference. The actual product may differ
slightly

CUSTOMER CARE
Please record your model number and serial number in the space below. Having these numbers to
handwillhelpustohelpyou,quicklyandmoreefciently.
When contacting us, please use the Customer Care number located in the bottom of this page.
Model Number
Serial Number
Date of purchase Installers stamp / print
name Date of installation
Purchased from
Date Part(s) replaced Engineers stamp /
printed name
In the event of a problem, please call our Customer Care Centre
on: 0344 815 3742

Glen Dimplex Professional Appliances,
Stoney Lane, Prescot, Merseyside, L35 2XW
Customer Care Centre: 0344 815 3742
www.lec-commercial.co.uk
Glen Dimplex Professional Appliances, a division of Glen
Dimplex Home Appliances
This manual suits for next models
3
Table of contents
Other Lec essenChill Refrigerator manuals
Popular Refrigerator manuals by other brands

AEG
AEG SANTO 70338-1KA user manual

True Manufacturing Company
True Manufacturing Company 30 installation manual

GE
GE GTS18ABBRWW Dimensions and installation information

Electrolux
Electrolux FI291/2TS user manual

Frigidaire
Frigidaire FRS26LH5D Factory parts catalog

Master Bilt
Master Bilt MPM-36 Specification sheet
