Leigh Country Welcome TX 94101 User manual

Please keep this instruction manual for future reference
Read the instructions before use of this product
For warranty information, please refer to the back page of
this instruction manual.
Limited one year Finish Warranty
**(non-transferrable)**
This product is covered under United Genreral Supply’s (UGS) one (1) year
limited warranty. To the original purchaser of this furniture, UGS warrants that
this piece of furniture is and will be free from defects in material and
workmanship for up to one year from the date of purchase under normal use
and proper care. Replacement of defective or missing parts will be sent at no
charge to the customer for a period of 15 days from the date of purchase.
UGS will no longer be responsible for missing parts or hardware 15 days after
date of purchase.
Freight, packaging, labor or material charges to and from our customer service
center is not covered under the warranty and is therefore the customer’s
responsibility. The limited warranty does not cover this piece of furniture for
commerical purpose, abusive use, damage by modification, freeze damage,
rust, fading and issues caused by improper care.
Proof of purchase (dated register receipt) will be required for warranty claims.
For any questions or claims, please contact customer service.
Customer Service
1-877-87LEIGH (53444)
[email protected]
Metal Welcome Bench
Item No.: TX 94101
Instruction Manual
Distributed by:
United General Supply Co., Inc.
Houston, TX 77036
©
Copyright U.G.S. Co. 2009
All rights reserved
Made in China
TX 93855
Star Welcome
w/ Barbwire, 29”
TX 93493
Star 23”
w/Ring 3D
TX 93519
Star 23”
TX 93625
Star 23”
w/Barbwire
TX 93853
Star Welcome, 29”

A Back 1
B Seat 1
C Leg &Arm Frame 2
D Screw,M6 x 50mm 4
E Screw,M6 x 68mm 4
F Hex Nut,6mm 8
G FlatWasher,6mm 8
H Plastic Nut Cover 8
I Hex Key 1
1. (SEE FIGURE 1) Attach seat (B) to legs (C) by aligning holes in one
of the legs with corresponding holes in seat frame. Using hex key (I)
secure screws (D), flat washers (G) and hex nuts (F). Repeat for the
second leg.
Do not fully tighten fasteners.
2. Slide back (A) between legs (C) and align holes. Align hex (F) and
washer (G) to the hole on the back before inserting screws (E)
through the holes. Secure using hex key (I) with flat washers (G)
and hex nuts (F).
3. Place bench upright on a flat, level surface and tighten all
fasteners. Slide plastic nut covers (H) over all exposed ends.
C
G
G
F
F
H
H
C
D
D
D
D
E
E
A
B
E
E
Figure 1
ASSEMBLY INSTRUCTIONS
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
B
C
DEGH
FI
Please make sure that every piece of furniture and all hardware are present
before assembling this bench.
CAUTION: Until every part and piece is set and secured in place, do NOT secure the
nuts and bolts tightly together.
G
GF
FH
H
A
Parts Detail
