USER'S INFORMATION MANUAL
MGE Series
Magic-Pak Thru-the-Wall Unit
CAUTION
Congratulations...
...you have one of the most modern gas heating appliances
made. Your unit has been carefully selected to keep you warm
and comfortable during the winter months. It will deliver superb
performance with only minimal help from you. It will also keep
you comfortably cool during hot summer days and nights.
To keep your operating cost low and to eliminate unnecessary
service calls, we have provided a few guidelines. These
guidelines will help you understand how your appliance
operates and how to maintain it so you can get years of safe
and dependable service.
WARNING: If the information in this
manual is not followed exactly, a fire
or explosion may result causing
property damage, personal injury, or
loss of life.
- Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
-What to do if you smell gas:
•Do not try to light any appliance.
•Do not touch any electrical switch; do
not use any phone in your building.
•Immediately call your gas supplier from a
neighbor's phone. Follow the gas
supplier's instructions.
•If you cannot reach the gas supplier, call
the fire department.
- Installation and service must be per-
formed by a qualified installer, service
agency, or the gas supplier.
Certified Efficiency Ratings
EFFICIENCY
RATING
CERTIFIED
area
LISTED LISTED The Gas Appliance Manufacturers Association (GAMA) symbol
verifies that Annual Fuel Utilization Efficiency (AFUE) ratings for
our gas furnaces have been derived from U.S. Government
standard tests.
Certified for
Canada
The E.T.L. Testing Laboratories, Inc. symbol on your appliance
is your assurance that your furnace design meets nationally
recognized standards for safety and performance.
Manufactured By
A.A.C.
A Lennox International Company
421 Monroe Street
Bellevue, OH 44811
IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
# 46978A003 Save these instructions for future reference Page 1

General Information Operating Your Furnace
Your model MGE unit is unique is that it is entirely self-contained
in one compact cabinet. It uses outside air for gas combustion
and the products of combustion are exhausted by a power vent
directly to the outside through the upper right corner of the
exterior grille. If your unit is located at ground level or the exterior
is on a balcony, you will able to observe the flue products
discharge area. On cold mornings during the heating cycle you
may notice a vapor emitting from the discharge area. This is
normal.
Depending on your local or state building codes, you will have a
power disconnect either adjacent to your unit or located at your
main electrical panel. Over-current protection will be provided
at this point. Have your builder, dealer, or maintenance people
show you how to turn the power on and off for your Magic-Pak
unit.
A field-supplied gas cock (valve) is located in the gas line
entering the front of your unit. Manually turn the handle so it is
in a parallel position to the gas line. This is the "OPEN" position.
Your unit is equipped with an energy saving, automatic,
intermittent ignition control. The burners are automatically
ignited at the beginning of each heating cycle and shut off when
each cycle is completed. Your unit does not have a pilot
requiring manual lighting.
For your safety -
Read before operating
AWARNING
Before operating, smell around the appliance area for gas. Be
sure to smell next to the floor because some gas is heavier than
air and will settle to the lowest point. Refer to "What to do if
you smell gas" on page 1 if the odor of gas is present.
Use only your hand to turn the gas control knob; never use
tools. If the knob will not turn by hand, don't try to repair it. Call
a qualified service technician. Force or attempted repair may
result in a fire or explosion.
Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
CAUTION
Lighting Instructions
1. STOP! Read the previous safety information.
2. Turn off electrical power to the appliance.
3. Turn the thermostat to lowest setting.
4. Turn the gas valve knob to "ON" position (see Figure 1).
5. Turn on electrical power to the appliance.
6. Set the room thermostat to the desired temperature. If the
thermostat "set" temperature is above room temperature
after the pre-purge time expires, main burner will light.
Gas Valve
HONEYWELL
GAS
INLET
.REGULATOR
,_...........ADJUSTMENT CAP
/
GAS
CONTROLKNOB
Figure 1
To Shut Down
1. Turn off electrical power to the appliance.
2. Turn the gas valve knob to "OFF" position.
Temperature Control
There are many types and styles of thermostats. Yours may look
different from the one pictured in Figure 2. However, almost all
thermostats perform the same basic functions described in the
following section.
Thermostat
Selector Switch Fan Switch
Coo&ling
Heating
mperature
Room _ ....... Setting
Temperatu re
Figure 2
Page 2 #46978A003

Thermostat Operation Owner/User Maintenance
There are two switches located on the thermostat. One switch
controls the heating and cooling functions. The other switch is
for "FAN" operation, either continuous or automatic. On the
thermostat is the temperature range for the heating temperature
and the cooling temperature desired.
To put the system into operation, push the switch to either
"HEAT" or "COOl" position. After you have chosen the type of
operation you desire, move the thermostat dial or lever to select
the temperature you would like the system to maintain.
Fan Operation
You may wish to increase your comfort by setting your system
for continuous air circulation of the indoor air. The fan switch on
the thermostat permits you to do this.
With the switch in the "ON" position, the fan will operate
continuously. "AUTO" position gives fan operation only when
the unit is in either heating or cooling.
Maintenance Of Your Unit
There are routine maintenance steps you should take to keep
your unit operating efficiently. This will assure longer life, lower
operating costs, and fewer service calls. Certain service and
maintenance procedures require the skill of a trained service
person who utilizes special tools and training. Personal injury
can result if unqualified personnel attempt those procedures.
Your unit should be inspected and serviced at least once
per year by a qualified service technician.
Periodic Inspections
Your Magic-Pak is designed to give many years of efficient,
satisfactory service. However, the varied air pollutants com-
monly found in most areas can affect longevity and safety.
Chemicals contained in everyday household items such as
laundry detergents, cleaning sprays, hair sprays, deodorizers,
and other products which produce airborne residuals may have
an adverse affect upon the metals used to construct your
appliance.
It is important that you periodically inspect your unit. Visually
inspect all flue product carrying areas of the furnace, the vent-
air intake system, main gas burners, and heat exchanger. You
will be able to make this observation by removing the access
panel located on the center portion of the cabinet. A screw-
driver is needed to remove this panel. A flashlight will be useful.
Make one inspection prior to the beginning of the heating
season and another half way through the heating season.
Should you observe unusual amounts of rust, flakes, or
other deposits, coatings, or corrosion, it is important that
you call your authorized dealer at once to obtain a qualified
service inspection.
#46978A003
Should your living area be part of an apartment or condominium
complex, you are likely to have maintenance personnel who
will provide all normal maintenance functions to keep your unit
operating at maximum efficiency. If you are responsible for this
maintenance, there are several key steps you will need to
perform. Your Magic-Pak unit will, in most cases, be located
behind a moveable opening or closet.
1, Filter Remove the access panel on the top of the cabinet.
A screwdriver is needed to remove this panel. The filter is
immediately behind this panel and can easily be slid out of
the side channels which keep it in place in front of the
indoor blower. The filter may be vacuumed or preferably
washed, then dried and replaced. This is a washable filter
that will last many years when properly cared for. When
inserting the filter in the side channels, make sure it does
not touch the fins of the coil. Your filter should be checked
every 4 to 6 weeks.
2, Indoor Coil This coil must be clean at all times, especially
for efficient cooling performance. Should any lint or dirt
collect on the coil fins, you can usually remove this
accumulation using an ordinary vacuum cleaner hose with
a crevice tool or brush attachment. Be careful, the coil fins
are very fragile and are easily damaged.
3, Condensate Drain During cooling, the moisture removed
from indoors collects on the indoor coil, drops to the drain
pan at the bottom of the coil and then drains away through
a plastic hose connected to the stub at the front of the drain
pan. The condensate then drains to the unit base pan.
Make sure this drain connection is kept open to keep
condensate from overflowing the pan.
4, Outdoor Condensing Coil If your unit is located at ground
level where outdoor debris can collect on the outdoor coil,
you will need to periodically inspect and clean this coil
during the cooling season. Use of a vacuum or hose is
recommended. A dirty coil will cause inefficient operation
on cooling and it may also contribute to cooling service
problems. Be careful, the coil fins are very fragile and are
easily damaged.
5, Blower and Fan Motors These are direct drive, sealed
bearing motors and do not require lubrication or owner
maintenance. Access to these motors can be made only
when the entire cooling chassis is removed by your
authorized service person or dealer.
Since the entire cooling section of your unit is a factory-sealed
system, only your authorized service dealer should be called to
make any necessary repairs or adjustments.
A.R.I. Capacity Certified
The Air-conditioning & Refrigeration Institute label assures you
of cooling capacity as shown on the rating plate.
Page 3

Limited Warranty
August 1, 1997
This warranty gives you specific legal rights and you may have other rights
which vary from state/province to state/province.
Warrantor: Armstrong Air Conditioning Inc., 421 Monroe St., Bellevue, OH 44811
Armstrong Air Conditioning Inc. products are available under the following names: Air Ease, Armstrong Air, American Aire, Concord, Magic-Pak
Subject to the limitations stated in this warranty, we warrant to the first buyer for use the residential heating, cooling or heat pump unit, when
installed, operated and maintained as required by this warranty, to be free of defects in workmanship or material for a period of 5 years (1 year for
commercial equipment) from the time of installation. We will replace any defective component without cost or expense to you except for the costs
of delivery and labor for removal and replacement of the defective component.
These MGE Magic-Pak Thru-the-Wall units also carry a limited 10-year warranty on the heat exchanger. Limited 10-year warranty
applies to the original owner in private owner-occupied residences.
Warranty Begins
The warranty period begins when the installation is complete and the product is ready to operate. You must be able to verify this date whenever a
warranty claim is made. Original bill of sale, installer's invoice or other similar document will suffice. If the beginning date cannot be verified, we will
consider warranty coverage to begin 6 months after the date the product was shipped from our factory.
Limitations on Implied Warranties
Implied warranties of merchantability or, to the extent applicable, fitness for a particular purpose are limited to 5 years, the same duration as the
basic limited written warranty provided herein. Some states/provinces do not allow limitations on how long an implied warranty of merchantability or
fitness lasts, so the above limitations or exclusions may not apply to you.
Only Warranty
This written Limited Warranty is the only warranty made by the warrantor; this warranty is in lieu of and excludes all other warranties, express or
implied. The warrantor does not authorize any person to provide any other warranty or to assume for it any further obligation in connection with the
warranted product.
What is NOT Covered
1. Cabinets or cabinet pieces.
2. Normal maintenance items such as filters, fan belts, fuses or other consumable items.
3. Damage caused by misuse, failure to maintain properly, accidents or acts of God.
4. External wiring, piping, venting or attachment of accessory products not integral to our product, including without limitation, humidifier,
air cleaner, vent damper, thermostat or other mechanical devices not manufactured by the warrantor.
5. Products that have been operated in a corrosive atmosphere where a concentration of acids, halogenated hydrocarbons or other
corrosive elements causes deterioration to metal surfaces or integral components. NOTE: Operation in a corrosive atmosphere is
considered abuse and voids this warranty.
6. Products that have NOT been installed in accordance with our published installation instructions, applicable local, state/provincial or
national codes, ACCA published standards.
7. Products that have NOT been installed by competent, qualified installers.
8. Products that have been moved from their original place of installation.
Warranty on Replacement Components
Any replacement component furnished by us will assume the remaining (unused) portion of the Limited Warranty.
Consequential Damages
The warrantor shall not be responsible for any consequential damages caused by any defect in the product. Some state/provinces do not allow the
exclusion or limitations of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
NOTE: After the first year, in the event that a gas or oil heat exchanger is no longer being manufactured by the warrantor, the warrantor will allow a
credit equal to the then current wholesale price of an equivalent heat exchanger towards the purchase of a new Armstrong gas or oil furnace.
This product must be installed, used and cared for in accordance with the instruction manual. You are responsible for required periodic maintenance
or service, such as changing or cleaning of air filters and lubrication or cleaning of components. Failure to properly install, operate or maintain your
unit voids this warranty.
Model #
INSTALLED BY:
Dealer
Address
Telephone #
Owner Record
Serial # Installation Date
License #
Page 4 #46978A003
