Superior Fireplaces VS1824NM User manual

INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.
WARNING: This appliance is for installation only in a solid-fuel burning masonry or UL127 factory-built
fireplace or in a listed ventless firebox enclosure. It is design-certified for these installations in accordance
with ANSI Z21.11.2. Exception: DO NOT install this appliance in a factory-built fireplace that includes
instructions stating it has not been tested or should not be used with unvented gas logs.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation
section on Page 6 of this manual.
Installation and Operation Instructions
Unvented (Vent-Free) Gas Log Heater
Models
PFS
®
US
Report No. F09-129
VS1824NM VS1824PM
P/N 126842-01 REV. B 05/2017
For use with log sets
LVS18VO LVS24VO
P126842-01
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.

SuperiorFireplaces.us.com 126842-01B2
TABLE OF CONTENTS
Safety .................................................................. 2
Product Identification........................................... 5
Local Codes......................................................... 5
Unpacking............................................................ 5
Product Features................................................. 6
Air For Combustion and Ventilation..................... 6
Installation ........................................................... 9
Operation .......................................................... 18
Inspecting Burners............................................. 20
Cleaning and Maintenance................................ 20
Troubleshooting................................................. 22
Parts.................................................................. 26
Specifications .................................................... 29
Replacement Parts............................................ 29
Service Hints ..................................................... 29
Technical Service............................................... 29
Accessories....................................................... 30
Warranty............................................................ 35
SAFETY
WARNING: FIRE, EXPLOSION, AND ASPHYXIATION HAZARD
Improperadjustment,alteration,service,maintenance,orinstallationofthis
heater or its controls can cause death or serious injury.
Read and follow instructions and precautions in User’s Information Manual
provided with this heater.
WARNING:Thisapplianceisfor
installationonlyinasolid-fuelburn-
ing masonry or UL127 factory-built
fireplace or in a listed ventless fire-
boxenclosure.Itisdesign-certified
fortheseinstallationsinaccordance
with ANSI Z21.11.2. Exception:
DO NOT install this appliance in a
factory-built fireplace that includes
instructions stating it has not been
tested or should not be used with
unvented gas logs.
WARNING: This is an unvented
gas-firedheater.Itusesair(oxygen)
fromtheroominwhichitisinstalled.
Provisionsforadequatecombustion
andventilationairmustbeprovided.
Refer to Air for Combustion and
Ventilation section on Page 6 of
this manual.
Thisappliancemaybeinstalledinan
aftermarket,* permanently located,
manufactured(mobile)home,where
not prohibited by local codes.
This appliance is only for use with
the type of gas indicated on the
rating plate. This appliance is not
convertibleforusewithothergases.
* Aftermarket: Completion of sale, not for
purpose of resale, from the manufacturer
WARNING:Thisproductcontains
and/or generates chemicals known
to the state of California to cause
cancer or birth defects or other re-
productive harm.
DANGER: Carbon monoxide
poisoning may lead to death!
WARNING:Vent-freeproductsare
prohibitedforbedroomandbathroom
installation in the Commonwealth of
Massachusetts.

SuperiorFireplaces.us.com
126842-01B 3
SAFETY
Continued
IMPORTANT: Read this owner’s
manual carefully and completely
beforetryingtoassemble,operateor
service this fireplace. Improper use
of this fireplace can cause serious
injury or death from burns, fire, ex-
plosion,electricalshockandcarbon
monoxide poisoning.
WARNING: Any change to this
heater or its controls can be dan-
gerous.
WARNING: Do not use a blower
insert,heatexchangerinsertorother
accessorynotapprovedforusewith
this heater.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning resemble the flu,
with headaches, dizziness or nausea. If you
have these signs, the fireplace may not be
working properly. Get fresh air at once! Have
fireplace serviced. Some people are more af-
fected by carbon monoxide than others. These
include pregnant women, people with heart
or lung disease or anemia, those under the
influenceof alcohol andthoseathighaltitudes.
Natural and Propane/LP gases are odorless.
Anodor-makingagentisaddedtothesegases.
The odor helps you detect a gas leak. How-
ever, the odor added to the gas can fade. Gas
may be present even though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference. It
is your guide to safe and proper operation of
this fireplace.
Due to high temperatures, the ap-
pliance should be located out of
traffic and away from furniture and
draperies.
Do not place clothing or other flam-
mable material on or near the appli-
ance. Never place any objects on
the heater.
Heaterbaseassemblybecomesvery
hot when running heater. Children
and adults should be alerted to the
hazard of high surface temperature
and should stay away to avoid
burns or clothing ignition. Heater
will remain hot for a time after shut-
down. Allow surface to cool before
touching.
Young children should be carefully
supervisedwhentheyareinthesame
room with the appliance.
You must operate this heater with
the fireplace screen and hood in
place. Make sure fireplace screen
andhoodareinplacebeforerunning
heater. The fireplace screen shall
have openings for introduction of
combustion air.
Keep the appliance area clear and
free from combustible materials,
gasolineandotherflammablevapors
and liquids.
WARNING: Do not allow fans
to blow directly into the fireplace.
Avoid any drafts that alter burner
flame patterns. Ceiling fans can
create drafts that alter burner flame
patterns.Alteredburnerpatternscan
cause sooting.
WARNING: Do not place log
scraps or volcanic stone on burner.
Solid-fuels shall not be burned in a
fireplaceinwhichanunventedroom
heater is installed.

SuperiorFireplaces.us.com 126842-01B4
SAFETY
Continued
2. Do not place propane/LP supply tank(s)
inside any structure. Locate propane/LP
supply tank(s) outdoors(propane/LP units
only).
3. Topreventperformanceproblems,theuse
of a propane/LP tank of less than 100 lbs.
capacityis notrecommended(propane/LP
units only).
4. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do nottouch any electrical switch;do not
use any phone in your building
• immediately call your gas supplier from
a neighbor’s phone. Follow the gas sup-
plier’s instructions
• ifyoucannot reachyour gassupplier, call
the fire department
5. This heater shall not be installed in a
bedroom or bathroom unless installed as
aventedappliance (seeInstallingDamper
Clamp Accessory for Vented Operation,
Page 12). This gas log set may not be
installed as a vented appliance in a bed-
room or bathroom in the Commonwealth
of Massachusetts.
6. Do not burn solid-fuel in a fireplace in
whichavent-freeroom heater is installed.
7. WARNING: Before installing in a solid
fuelburningfireplace, the chimney flue
and firebox must be cleaned of soot,
creosote, ashes and loose paint by a
qualified chimney cleaner.Creosote will
igniteifhighlyheated.Adirtychimneyflue
may create and distribute soot within the
house. Inspect chimney flue and firebox
fordamage.If damaged,repairfluebefore
operating heater.
8. If fireplace has glass doors, never oper-
ate this heater with glass doors closed.
Any glass doors shall be fully opened
Installation and repair should be
done by a qualified service person.
The appliance should be inspected
before use and at least annually by
aprofessionalserviceperson.More
frequent cleaning may be required
duetoexcessivelintfromcarpeting,
beddingmaterial,etc.Itisimperative
thatcontrolcompartments,burners,
and circulating air passageways of
the appliance be kept clean.
when the appliance is in operation. If you
operate heater with doors closed, heat
buildupinsidefireplacewill causeglassto
burst.Make surethereare noobstructions
across openings of fireplace.
9. This log heater is designed to be smoke-
less.Iflogseverappeartosmoke,turnoff
heater and call a qualified service person.
NOTE: During initial operation, slight
smokingcouldoccur duetolog curingand
heater burning manufacturing residues.
10. Topreventthecreationofsoot, follow the
instructionsinCleaningandMaintenance,
Page 20.
11. Before using furniture polish, wax, carpet
cleanerorsimilarproducts,turn heateroff.
If heated, the vapors from these products
may create a white powder residue within
burnerboxoronadjacentwallsorfurniture.
12. This heater needs fresh, outside air ven-
tilation to run properly. This heater has an
Oxygen Depletion Sensing (ODS) safety
shutoff system. The ODS shuts down the
heater if not enough fresh air is available.
See Air for Combustion and Ventilation,
Page 6. If heater keeps shutting off, see
Troubleshooting, Page 22.
13. Do not run heater
• where flammable liquids or vapors are
used or stored
• under dusty conditions
14. Donotusethisheater tocookfood orburn
paper or other objects.
15. Do not use this room heater if any part
has been under water. Immediately call a
qualified service technician to inspect the
roomheaterand to replaceanypart of the
control system and any gas control which
has been under water.
16. Donotoperateheaterif any log is broken.
Do not operate heater if a log is chipped
(dime-sized or larger).
17. Turn heater off and let cool before servic-
ing.Only aqualifiedservicepersonshould
service and repair heater.
18. Operating heater above elevations of
4,500 feet could cause pilot outage.
19. Provide adequate clearances around air
openings.
20. Solid fuels shall not be burned in a fire-
place in which an unvented room heater
or decorative appliance is installed.
21.Wheninstalling as a ventedapplianceina
manufacturedhome, theinstallationmust
conform with the Manufactured Home
Construction and Safety Standard, Title
24 CFR, Part 3280 or when standard is
not applicable, with Manufactured Home
Installations Standard, ANSI/NCSBCS
A225.1/NFPZ 501A.
1. WARNING: This appliance is onlyfor
use with the type of gas indicated on
the rating plate.This appliance isnot
convertible for use with other gases.

SuperiorFireplaces.us.com
126842-01B 5
Heater Base
Control Knob
Grate
Left
Side
Right
Side
Front
LOCAL CODES NOTE:Donotpickupappliancebaseas-
semblyby burners.Thiscoulddamagethe
appliance.Alwayshandlebaseassembly
by grate.
2. Remove all protective packaging applied
to logs and appliance for shipment.
3. Check appliance for any shipping dam-
age. If appliance is damaged, promptly
inform dealer where you purchased the
appliance.
Install and use appliance with care. Follow all
localcodes.Intheabsence oflocalcodes, use
the latest edition of The National Fuel Gas
Code, ANSI Z223.1/NFPA 54*.
*Available from:
American National Standards Institute, Inc.
25 West 43rd Street, 4th floor
New York, NY 10036
National Fire Protection Association, Inc.
1 Batterymarch Park
Quincy, MA 02169-7471
UNPACKING
1. Removelogsandappliancebase assem-
bly from carton(s).
CAUTION:Donotremovethe
data plates from the grate as-
sembly. The data plates contain
important warranty and safety
information.
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS
These appliances are approved for installation in the US state of Massachusetts if the fol-
lowing additional requirements are met:
• Un-vented Room Heaters shall be installed in accordance with 527 CMR 30.
• Installation and repair must be done by a plumber or gas fitter licensed in the Common-
wealth of Massachusetts.
• Theflexiblegasline connector used shall not exceed36inches(92centimeters)in length.
• The individual manual shut-off must be a T-handle type valve.
• Unvented appliances may NOT be installed in bedrooms or bathrooms.
• A working smoke detector must be installed in the area where vent-free appliances are
installed.
Seller of unvented propane or natural gas-fired supplemental room heaters shall provide
to each purchaser a copy of 527 CMR 30 upon sale of the unit.
PRODUCT IDENTIFICATION
Figure 1 - Product Identification

SuperiorFireplaces.us.com 126842-01B6
PRODUCT FEATURES
OPERATION
This heater is clean burning. It requires no
outside venting. There is no heat loss out a
vent or up a chimney. Heat is generated by
realistic, dancing yellow flames. This heater
is designed for vent-free operation with flue
damper closed. It has been tested and ap-
proved to ANSI Z21.11.2 standard for un-
ventedheaters.State andlocalcodes insome
areas prohibit the use of vent-free heaters.
Non-thermostatmodelsmay alsobeoperated
asavented decorative(ANSIZ21.60)product
by opening flue damper.
SAFETY PILOT
Thisheaterhasapilotwith an Oxygen Deple-
tionSensing(ODS)safetyshutoffsystem.The
ODS/pilot is a required feature for vent-free
room heaters. The ODS/pilot shuts off the
heater if there is not enough fresh air.
AIR FOR COMBUSTION AND VENTILATION
Today’shomes are built more energy efficient
thanever.New materials,increasedinsulation
and new construction methods help reduce
heat loss in homes. Homeowners apply
weather strip and caulk around windows and
doorstokeep the coldairout and thewarmair
in.Duringheatingmonths,homeowners want
their homes as airtight as possible.
While it is good to make your home energy
efficient, your home needs to breathe. Fresh
air must enter your home.All fuel-burning ap-
pliancesneedfreshairforpropercombustion
and ventilation.
Exhaust fans, some fireplaces, clothes dryers
and some fuel-burning appliances draw air
from the house to operate. You must provide
adequate fresh air for these appliances. This
will ensure proper venting of vented fuel-
burning appliances.
PROVIDING ADEQUATE
VENTILATION
Thefollowingareexcerptsfrom National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation.
All spaces in homes fall into one of the three
following ventilation classifications:
WARNING: This heater shall not
be installed in a room or space un-
less the required volume of indoor
combustion air is provided by the
method described in the National
Fuel Gas Code, ANSI Z223.1/NFPA
54, the International Fuel Gas Code,
or applicable local codes. Read the
following instructions to ensure
properfreshair for this and other fuel-
burning appliances in your home.
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on Pages 6-8 will help you
classify your space and provide adequate
ventilation.
Unusually Tight Construction
The air that leaks around doors and windows
may provide enough fresh air for combustion
and ventilation. However, in buildings of un-
usually tight construction, you must provide
additional fresh air.
Unusually tight construction is defined as
construction where:
a. walls and ceilings exposed to the out-
side atmosphere have a continuous
water vapor retarder with a rating of
one perm (6 x 10-11 kg per pa-sec-m2) or
less with openings gasketed or sealed
and
b. weather stripping has been added on
openable windows and doors and
c. caulking or sealants are applied to
areas such as joints around window
and door frames, between sole plates
and floors, between wall-ceiling joints,
between wall panels, at penetrations
for plumbing, electrical and gas lines
and at other openings.
If your home meets all three criteria above,
you must provide additional fresh air. See
Ventilation Air From Outdoors, Page 8.
If your home does not meet all three
criteria above, proceed to Determining
Fresh-AirFlowFor Heater Location,below.
Confined and Unconfined Space
The National Fuel Gas Code, ANSI Z223.1/
NFPA54 allows two methods for determining
whetherthespace inwhichthe heaterisbeing

SuperiorFireplaces.us.com
126842-01B 7
AIR FOR COMBUSTION AND VENTILATION
Continued
installedisconfined orunconfinedspace.The
standardmethoddefinesa confinedspaceas
a space whose volume is less than 50 cubic
feetper1,000 Btu/hr (4.8m3perkw)of theag-
gregateinputratingofallappliancesinstalled
in that space and an unconfined space as
a space whose volume is not less than 50
cubic feet per 1,000 Btu/hr (4.8 m3per kw) of
the aggregate input rating of all appliances
installedinthat space.Roomscommunicating
directlywiththe spaceinwhichthe appliances
areinstalled*,throughopenings not furnished
with doors, are considered a part of the un-
confined space.
Where the air infiltration rate of a structure is
known,theKnownAirInfiltrationRate Method
may be used. Follow The National Fuel Gas
Code, ANSI Z223.1/NFPA 54 to use this
method to determine if the space is confined
or unconfined.
* Adjoining rooms are communicating only if
therearedoorless passagewaysorventilation
grills between them.
DETERMINING FRESH-AIR FLOW
FOR HEATER LOCATION
Determining if You Have a Confined or
Unconfined Space Using the Standard
Method
Use this work sheet to determine if you have
a confined or unconfined space.
Space: Includesthe roomin whichyou willinstall
fireplace plus any adjoining rooms with door-
less passageways or ventilation grills between
the rooms.
1. Determine the volume of the space (length
x width x height).
Length x Widthx Height =__________cu.ft.
(volume of space)
Example: Space size 20 ft. (length) x 16 ft.
(width) x 8 ft. (ceiling height) = 2,560 cu. ft.
(volume of space)
If additional ventilation to adjoining room
is supplied with grills or openings, add the
volume of these rooms to the total volume
of the space.
2. Multiply the space volume by 20 to determine
the maximum Btu/Hr the space can support.
________ (volume of space) x 20 = (Maxi-
mum Btu/Hr the space can support)
Example:2,560 cu. ft. (volume of space) x
20 = 51,200 (maximum Btu/Hr the space can
support)
3. Add the Btu/Hr of all fuel burning appliances
in the space.
Vent-free fireplace _________Btu/Hr
Gas water heater* _________Btu/Hr
Gas furnace _________Btu/Hr
Vented gas heater _________Btu/Hr
Gas fireplace logs _________Btu/Hr
Other gas appliances*+ _________ Btu/Hr
Total = _________Btu/Hr
* Do not include direct-vent gas appliances.
Direct-vent draws combustion air from the
outdoors and vents to the outdoors.
Example:
Gas water heater __________Btu/Hr
Vent-free fireplace +_________Btu/Hr
Total = _________Btu/Hr
4. Compare the maximum Btu/Hr the space
can support with the actual amount of Btu/
Hr used.
_______ Btu/Hr (maximum the space can
support)
_______ Btu/Hr (actual amount of Btu/Hr
used)
Example:51,200 Btu/Hr (maximum the
space can support)
71,500 Btu/Hr (actual amount of
Btu/Hr used)
The space in the example is a confined space
because the actual Btu/Hr used is more than the
maximum Btu/Hr the space can support. You
must provide additional fresh air. Your options
are as follows:
A. Rework worksheet, adding the space of an
adjoiningroom.If theextraspaceprovides an
unconfined space, remove door to adjoining
room or addventilation grills betweenrooms.
See Ventilation Air From Inside Building,
Page 8.
B. Vent room directly to the outdoors. See
Ventilation Air From Outdoors, Page 8.
C. Install a lower Btu/Hr fireplace, if lower Btu/
Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maxi-
mum Btu/Hr the space can support, thespace is
anunconfined space.You willneed noadditional
fresh air ventilation.
40,000
31,500
71,500

SuperiorFireplaces.us.com 126842-01B8
AIR FOR COMBUSTION AND VENTILATION
Continued
Figure 2 - Ventilation Air from Inside
Building
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills Into
Adjoining
Room,
Option 1
12"
12"
Figure 3 - Ventilation Air from Outdoors
Outlet
Air
Ventilated
Attic
Outlet
A
ir
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two perma-
nent openings: one within 12" of the ceiling
andonewithin12"ofthefloor.Connectthese
items directly to the outdoors or spaces open
to the outdoors. These spaces include attics
and crawl spaces. Follow the National Fuel
Gas Code ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation for required size
of ventilation grills or ducts.
IMPORTANT:Do not provide openings
for inlet or outlet air into attic if attic has a
thermostat-controlled power vent. Heated air
entering the attic will activate the power vent.
WARNING:Iftheareainwhich
theheatermaybeoperateddoes
notmeettherequiredvolumefor
indoorcombustionair,combus-
tion and ventilation air shall be
provided by one of the methods
described in the National Fuel
Gas Code, ANSI Z223.1/NFPA
54, the International Fuel Gas
Code,orapplicablelocalcodes.
VENTILATION AIR
Ventilation Air From Inside Building
This fresh air would come from an adjoining
unconfined space. When ventilating to an
adjoiningunconfinedspace,youmust provide
twopermanentopenings:onewithin12"ofthe
ceiling and one within 12" of the floor on the
wall connecting the two spaces (see options
1and2,Figure 2).You canalsoremovedoor
into adjoining room (see option 3, Figure 2).
Follow the National Fuel Gas Code ANSI
Z223.1/NFPA 54, Air for Combustion and
Ventilation for required size of ventilation
grills or ducts.

SuperiorFireplaces.us.com
126842-01B 9
INSTALLATION
NOTICE:Thisapplianceisintended
for supplemental heating. Use this
heater along with your primary
heating system. Do not install this
heaterasyourprimaryheatsource.
Ifyouhaveacentralheatingsystem,
you may run system’s circulating
blower while using heater. This will
help circulate the heat throughout
the house. In the event of a power
outage, you can use this heater as
your primary heat source.
NOTICE: State or local codes may
only allow operation of this appli-
ance in a vented configuration.
Check your state or local codes.
WARNING: A qualified service
person must install heater. Follow
all local codes.
WARNING: Before installing in
a solid fuel burning fireplace, the
chimney flue and firebox must be
cleanedofsoot,creosote,ashesand
loose paint by a qualified chimney
cleaner.Creosotewilligniteifhighly
heated. A dirty chimney flue may
createanddistributesootwithinthe
house.Inspectchimneyandfirebox
flue for damage. If damaged, repair
flue and firebox before operating
heater.
WARNING:Anyoutsideairducts
and/or ash dumps in the fireplace
shallbepermanentlyclosedat time
of appliance installation.
WARNING: Seal any fresh air
ventsorashclean-outdoorslocated
on floor or wall of fireplace. If not,
drafting may cause pilot outage
or sooting. Use a heat-resistant
sealant. Do not seal chimney flue
damper.
WARNING: Never install the
heater
•
inabedroomorbathroomunless
installed as a vented appliance
(see Page 12)
• in a recreational vehicle
•
wherecurtains,furniture,clothing
orotherflammableobjectsareless
than 36" from front and 42" from
top of heater; for side clearances
see Figure 4, Page 10
• in high traffic areas
• in windy or drafty areas
CAUTION: This heater creates
warm air currents. These currents
move heat to wall surfaces next to
heater.Installingheaternexttovinyl
orclothwallcoveringsoroperating
heater where impurities (such as,
but not limited to, tobacco smoke,
aromatic candles, cleaning fluids,
oil or kerosene lamps, etc.) in the
air exist, may discolor walls or
cause odors.
IMPORTANT:Vent-free heaters add
moisture to the air.Although this is ben-
eficial, installing heater in rooms without
enoughventilation airmay causemildew
to form from too much moisture. See Air
for Combustion and Ventilation, Page 6.
CHECK GAS TYPE
Use only the correct gas type (natural
or propane/LP) for your unit. If your
gas supply is not correct, do not install
heater. Call dealer where you bought
heater for proper type heater.
WARNING: This appliance is
equipped for either natural gas or
propane/LP gas but not both. Gas
typeisindicatedontheratingplate.
Field conversion is not permitted.

SuperiorFireplaces.us.com 126842-01B10
Figure 4 - Minimum Clearance for
Combustible to Wall
*Minimum 16" from Side Wall
*
Example
INSTALLATION
Continued
Minimum Noncombustible Material
Clearances
If Not Using Mantel
NOTE: If using a mantel, proceed to If Using
Mantel, Page 10. If not using a mantel, follow
the information below.
You must have noncombustible material(s)
above the fireplace opening. Noncombustible
materials(suchasslate, marble,tile, etc.)must
beatleast1/2inchthick. Withsheetmetal, you
must have noncombustible material behind
it. Noncombustible material must extend at
least 8" up (for all models). If noncombustible
material is less than 12", you must install the
fireplacehood accessory (forallmodels).See
Figure5on Page11 forminimum clearances.
If Using Mantel
Noncombustible
Material Distance
(A)
Requirements for Safe
Installation
12" or more Noncombustible material
okay.
Between 8" and
12" Install fireplace hood
accessory (GA6050 - see
Accessories, Page 30).
Less than 8" Noncombustible material
must be extended to at
least 8". See Between
8" and 12", above. If you
cannot extend material,
you must operate heater
with flue damper open.
WARNING: Maintain the
minimumclearances.Ifyoucan,
providegreaterclearancesfrom
floor,ceilingandadjoining wall.
Minimum Fireplace Clearance to
Combustible Materials
Side Wall 16", Ceiling 42", Front 36"
Minimum Firebox Size
Height 17", Depth 14", Front Width 24",
Rear Width 20" (measured at 14" depth)
INSTALLATION AND CLEARANCES
(Vent-Free Operation Only)
Carefully follow instructions below. This
will ensure safe installation into a masonry,
UL127-listed manufactured fireplace or certi-
fied vent-free firebox.
Minimum Clearances For Side
Combustible Material, Side Wall and
Ceiling
A. Clearances from side of fireplace cabinet
to any combustible material and wall
should follow diagram in Figure 4.
Example:The faceofa mantel,bookshelf,
etc. is made of combustible material and
protrudes 3-1/2" from the wall. This com-
bustible material must be 4" from the side
of the fireplace cabinet (see Figure 4).
NOTE: When installing your gas logs into
a manufactured firebox, follow firebox
manufacturer’s instructions for minimum
clearances to combustible materials.
B. Clearances from the top of the fireplace
opening to the ceiling should not be less
than 42".
NOTICE: Manual control heaters
may be used as a vented product.
If so, you must always run heater
with chimney flue damper open. If
running heater with damper open,
noncombustible material above
fireplaceopeningisnotneeded.Go
to Installing Damper Clamp Acces-
soryforVentedOperation,Page12.
Minimum clearance requirements include any projections such
as shelves, window sills, mantels, etc. above the appliance.
Maintain adequate clearances for accessibility for purposes
of servicing and proper operation.

SuperiorFireplaces.us.com
126842-01B 11
Minimum
Noncombustible
Material
Minimum
Noncombustible
Material Height
Distances to
Underside of
Mantel
Top of
Fireplace
Opening
Underside of
Mantel Shelf
Mantel Shelf
8"
(A)
8" 14" 17" 20"
All minimum
distances are
in inches
Log Set
All Models
2 1/2"
6"
8"
10"
You must have noncombustible material(s)
above the fireplace opening. Noncombustible
materials(suchasslate, marble,tile, etc.)must
be at least 1/2" thick. With sheet metal, you
must have noncombustible material behind
it. Noncombustible material must extend at
least 8" up. See Figure 5 and 6 for minimum
clearances.
IMPORTANT:If you cannot meet these
minimum clearances, you must operate
heater with chimney flue damper open. Go
to Installing Damper Clamp Accessory for
Vented Operation, Page 12.
INSTALLATION
Continued
Figure 6 - Minimum Mantel Clearances
Without Using Hood
Figure 5 - Heat Resistant Material (Slate,
Marble, Tile, etc.) Above Fireplace
Heat Resistant
Material
(A)
NOTICE: Surface temperatures
of adjacent walls and mantels
become hot during operation.
Walls and mantels above the
firebox may become hot to
the touch. If installed properly,
these temperatures meet the
requirement of the national
product standard. Follow all
minimum clearances shown in
this manual.
Notice: If your installation does
not meet the minimum clear-
ances shown, you must do one
of the following:
• operate the logs only with
the flue damper open
• raise the mantel to an ac-
ceptable height
• remove the mantel
MANTEL CLEARANCES
In addition to meeting noncombustible mate-
rial clearances, you must also meet required
clearances between fireplace opening and
mantelshelf. Ifyoudo notmeettheclearances
listed below, you will need a hood.
You must meet the minimum clearances
between the mantel shelf and the top of the
fireplace opening as shown in Figure 6.
Determining Minimum Mantel Clearance
When Using a Hood
IfminimumclearancesinFigure6,arenotmet,
you must have a hood. When using a hood
there are still certain minimum mantel clear-
ances required. Follow minimum clearances
showninFigure 7, Page12 whenusinghood.
FLOOR CLEARANCES
A. If installing appliance on floor level, you
must maintain the minimum distance of
14" to combustibles (see Figure 8, Page
12).
B. If combustible materials are less than 14"
to fireplace, you must install appliance at
least5"abovethetopsurfaceofcombus-
tibleflooringincludingtileand carpet (see
Figure 9, Page 12).

SuperiorFireplaces.us.com 126842-01B12
INSTALLATION
Continued
14"
Min.
Combustible
Material
Noncombustible Material
Hearth
5"
Min.
Combustible
Material
Figure 9 - Minimum Fireplace Clearances
Above Combustible Flooring
Figure 8 - Minimum Fireplace Clearances
If Installed at Floor Level
Area of Various Standard Round Flues
Diameter Area
5" 20 sq. inches
6" 29 sq. inches
7" 39 sq. inches
8" 51 sq. inches
Chimney
Height Minimum Permanent Flue Opening
6' to 15' 39 sq. inches
15' to 30' 29 sq. inches
INSTALLING DAMPER CLAMP
ACCESSORY FOR VENTED
OPERATION
NOTE: When used as a vented heater, ap-
pliance must be installed only in a solid-fuel
burningfireplacewithaworkingflueandcon-
structed of noncombustible material.
You may use this heater as a vented product.
There are three reasons for operating your
heater in the vented mode.
1. The fireplace does not meet the clear-
ance to combustibles requirements for
vent-free operation.
2. State or local codes do not permit vent-
free operation.
3. You prefer vented operation.
Ifreasonsnumber1or2applytoyou, youmust
permanently open chimney flue damper. You
must install the damper clamp accessory (to
order, see Accessories, Page 30). This will
ensure vented operation (see Figure 10).
The damper clamp will keep damper open.
Installation instructions are included with
clamp accessory.
See chart below for minimum permanent flue
opening you must provide. Attach damper
clamp so the minimum permanent flue open-
ing will be maintained at all times.
Figure 10 - Attaching Damper
Manufactured
Fireplace
Masonry Fireplace
Damper
Damper
Clamp
Damper
Damper
Minimum
Noncombustible
Material
8"
Min.
12" 15" 18" 20"
2½"
6"
8"
10"
12"
Distances to
Underside of
Mantel
Hood
(GA6050)
Top of
Fireplace
Opening
Underside
of Mantel
Shelf
Mantel Shelf
Figure 7 - Minimum Mantel Clearances
When Using Hood

SuperiorFireplaces.us.com
126842-01B 13
INSTALLATION
Continued
gas hose to gas regulator of heater (see
Figure 11).
IMPORTANT:Hold gas regulator with
wrench when connecting flexible gas hose.
2. Locate masonry screws in hardware
package.
3. Position heater base assembly in fireplace.
4. Placelogin properpositiononheaterbase
(see Installing Logs, Page 16).
5. Centerheaterbaseand logs front-to-front
and side-to-side in fireplace.
6. Carefully remove log without moving
heater base.
7. Mark screw locations through holes in
mounting brackets (see Figure 12). If
installinginabrick-bottom fireplace, mark
screw locations in mortar joint of bricks.
8. Remove heater base from fireplace.
9. Drillholesatmarked locations using3/16"
drill bit.
10. Attach base assembly to fireplace floor
using two masonry screws (in hardware
package) (see Figure 12).
Figure 11 - Attaching Base Assembly to
Fireplace Floor
Figure 11 - Attaching Flexible Gas Hose
to Heater Gas Regulator
Heater Gas
Regulator
Flexible Gas Hose
(if allowed by local codes)
Fitting
Masonry
Screw
Mounting
Bracket
WARNING:Youmustsecure
this heater to fireplace floor. If
not, heater will move when you
adjust controls. Moving heater
may cause a gas leak.
CAUTION: Do not pick up
heater base assembly by burn-
ers. This could damage heater.
Only handle base assembly by
grates.
INSTALLING HEATER BASE
ASSEMBLY
WARNING: If installing in a
sunken fireplace, special care
is needed. You must raise the
fireplace floor to allow access
to heater control panel. This
will ensure adequate air flow
and guard against sooting and
controls being damaged. Raise
fireplacefloorwithnoncombus-
tiblematerial.Makesurematerial
is secure.
IMPORTANT:Make sure heater burners are
level. If heater is not level, heater will not
work properly.
Installation Items Needed
• hardware package (provided with heater)
• approved flexible gas hose (if allowed by
local codes)
•
sealant (resistant to propane/LP gas, not
provided)
• electric drill with 3/16" drill bit
• flathead screwdriver
1. Apply pipe joint sealant lightly to male
threads of the fitting to be threaded into
gas regulator. Connect approved flexible
CAUTION:Donotremovethe
data plates from the grate as-
sembly. The data plates contain
important warranty and safety
information.

SuperiorFireplaces.us.com 126842-01B14
INSTALLATION
Continued
Figure 13 - External Regulator With Vent
Pointing Down
Propane/LP
Supply Tank External
Regulator
with Vent
Pointing
Down
WARNING: This appliance
requires a 3/8" NPT (National
PipeThread)inletconnectionto
the pressure regulator.
WARNING: A qualified ser-
vicepersonmustconnectheater
to gas supply. Follow all local
codes.
CAUTION: Never connect
propane/LP fireplace directly
to the propane/LP supply. This
heaterrequiresanexternalregu-
lator (not supplied). Install the
external regulator between the
heater and propane/LP supply.
CONNECTING TO GAS SUPPLY
Installation Items Needed
Before installing heater, make sure you have
the items listed below.
• external regulator (supplied by installer)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve
• test gauge connection
• sediment trap
• tee joint
• pipe wrench
For propane/LP gas, the installer must supply
an external regulator. An external regulator
will reduce incoming gas pressure. You must
reduce incoming gas pressure to between 11"
and 14" of water.
WARNING: Never connect
natural gas fireplace to private
(non-utility) gas wells. This gas
iscommonlyknownaswellhead
gas.
CAUTION: Use only new,
black iron or steel pipe. Inter-
nally-tinned copper tubing may
be used in certain areas. Check
your local codes. Use pipe of
1/2"diameterorgreatertoallow
proper gas volume to heater. If
pipe is too small, undue loss of
volume will occur.
If you do not reduce incoming gas pressure,
heater regulator damage could occur. Install
external regulator with vent pointing down
as shown in Figure 13. Pointing vent down
protects it from freezing rain or sleet.
Installation must include an equipment shutoff
valve,unionandplugged1/8"NPTtap. Locate
NPT tap within reach for test gauge hook up.
NPT tap must be upstream from heater (see
Figure 14, Page 15).
IMPORTANT:Install equipment shutoff valve
in an accessible location. Main gas valve is for
turning on or shutting off gas to the appliance.
Check your building codes for any special
requirements for locating equipment shutoff
valve to fireplaces.
Apply pipe joint sealant lightly to male NPT
threads.This will preventexcesssealantfrom
going into pipe. Excess sealant in pipe could
result in clogged heater valves.
WARNING: Use pipe joint
sealantthatisresistanttoliquid
petroleum (LP) gas.

SuperiorFireplaces.us.com
126842-01B 15
INSTALLATION
Continued
Figure 14 - Gas Connection
** Min. inlet pressure for purpose of input
adjustment.
Tee Cap Pipe
Joint Nipple
3" Min.
Sediment Trap
Gas
Regulator
Approved
Flexible
Gas Hose (if
allowed by
local codes)
Natural
From Gas Meter
(5" W.C.** to
10.5" W.C.
Pressure)
Propane/LP
From External
Regulator
(11" W.C.**
to 14" W.C.
Pressure
PRESSURE TESTING GAS SUPPLY
PIPING SYSTEM
Test Pressures In Excess Of 1/2 PSIG
(3.5 kPa)
1. Disconnect appliance with its appliance
main gas valve (control valve) and equip-
mentshutoffvalve fromgassupplypiping.
Pressures in excess of 1/2 psig (3.5 kPa)
will damage heater regulator.
2. Capoffopenendofgaspipewhereequip-
ment shutoff valve was connected.
3. Pressurizesupplypipingsystem by either
opening propane/LP supply tank valve
for propane/LP gas or opening main gas
valve located on or near gas meter for
natural gas or using compressed air.
4. Checkalljointsofgassupplypipingsystem.
Applya commercialleakdetectionsolution
to all joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Reconnect heater and equipment shutoff
valve to gas supply. Check reconnected
fittings for leaks.
Test Pressures Equal To or Less Than
1/2 PSIG (3.5 kPa)
1. Close equipment shutoff valve (see Fig-
ure 15).
2. Pressurizesupplypipingsystem by either
opening propane/LP supply tank valve
for propane/LP gas or opening main gas
valve located on or near gas meter for
natural gas or using compressed air.
Figure 15 - Equipment Shutoff Valve
Open
Closed
Equipment
Shutoff Valve
CAUTION: Avoid damage to
regulator. Hold gas regulator
with wrench when connecting
it to gas piping and/or fittings.
CAUTION: For propane/LP
units,makesureexternalregula-
tor has been installed between
propane/LP supply and heater.
See guidelines under Connect-
ing to Gas Supply, Page 14.
We recommend that you install sediment
trap in supply line as shown in Figure 14.
Locate sediment trap where it is within reach
for cleaning. Install in piping system between
fuel supply and heater. Locate sediment trap
where trapped matter is not likely to freeze.
A sediment trap traps moisture and contami-
nants. This keeps them from going into heater
controls. If sediment trap is not installed or is
installed wrong, heater may not run properly.
WARNING:Testallgaspiping
and connections, internal and
external to unit, for leaks after
installing or servicing. Correct
all leaks at once.
WARNING: Never use an
open flame to check for a leak.
Applyanoncorrosiveleakdetec-
tion fluid to all joints. Bubbles
forming show a leak. Correct all
leaks at once.
CHECKING GAS CONNECTIONS

SuperiorFireplaces.us.com 126842-01B16
INSTALLATION
Continued
Figure 17 - Checking Gas Joints
(Natural Gas Only)
Gas
Meter
Equipment Shutoff Valve
Control Valve Location
Equipment Shutoff Valve
Propane/LP
Supply Tank
Control Valve
Location
Figure 16 - Checking Gas Joints
(Propane/LP Gas Only)
3. Check all joints from gas meter (natural
gas) or propane/LP supply to equipment
shutoffvalve (see Figure 16 or 17).Apply
acommercialleakdetection solution to all
joints. Bubbles forming show a leak.
4. Correct all leaks at once.
MODELS LVS18-VO AND LVS24-VO
Itisveryimportant to install theselogsexactly
as instructed. Do not modify logs. Only use
logs supplied with heater.
1. Place grate into square holes on heater
base as shown in Figure 18.
2. Place front log on burner so that it sits
between grate fingers and burner (see
Figure 18).
Figure 18 - Installing Grate and Logs
PRESSURE TESTING HEATER GAS
CONNECTIONS
1. Openequipmentshutoffvalve(seeFigure
15, Page 15).
2. Open main gas valve located on or near
gas meter for natural gas or open pro-
pane/LP supply tank valve.
3. Make sure control knob of heater is in the
OFF position.
4. Check all joints from gas meter (natural
gas) or propane/LP supply to equipment
shutoffvalve (seeFigure 16 or 17).Apply
acommercialleakdetection solution to all
joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Light heater (see Operation Page 18).
Check all other internal joints for leaks.
7. Turn off heater (see To Turn Off Gas to
Appliance, Page 19).
Grate
Heater Base
Front Log
The Front Log Should Be
Centered Left To Right.
WARNING:Failuretoposition
thepartsinaccordancewiththese
diagrams or failure to use only
parts specifically approved with
thisheatermayresultinproperty
damage or personal injury.
CAUTION: After installation
andperiodicallythereafter,check
to ensure that no flame comes
in contact with any log. With the
heater set to High, check to see
if flames contact any log. If so,
reposition log according to the
log installation instructions in
this manual. Flames contacting
log will create soot.
INSTALLING LOGS

SuperiorFireplaces.us.com
126842-01B 17
INSTALLATION
Continued
3. Place rear log on heater base behind the
metal burner. The bottom of the rear log
hasrecessareasonthe left and right side
for the base to set into. Pull the rear log
forward until it touches the front log (see
Figure 18, Page 16).
4. Place the left crossover log as shown
in Figure 19. The bottom of the log is
marked with a “L” for left. Match round
peg on left side of top of rear log with
round hole in bottom of left crossover.
Match square peg on left side of top of
front log with square hole in bottom of left
crossover log.
Left Crossover
Log
Figure 19 - Installing Left Crossover Log
Figure 20 - Installing Center Crossover Log
Center
Crossover
Log
Figure 21 - Installing Left Crossover Log
Right
Crossover
Log
5. Place the center crossover log as shown
in Figure 20. The bottom of the log is
marked with a “C” for center. Match
square peg on center of rear log with
square hole in bottom of center cross-
over. Match round peg on center of front
log with round hole in bottom of center
crossover log.
6. Place the right crossover log as shown
in Figure 21. The bottom of the log is
marked with a “R” for right. Match square
peg on right side of rear log with square
hole in bottom of right crossover. Match
round peg on right side of front log with
round hole in bottom of right crossover
log.
7. Addvolcanicstonearound base of heater
ifdesired.Do notplaceanyvolcanic stone
on logs or burner.

SuperiorFireplaces.us.com 126842-01B18
OPERATION LIGHTING
INSTRUCTIONS
WARNING:
• If fireplace has glass doors,
never operate this heater with
glass doors closed. If you op-
erateheaterwithdoorsclosed,
heat buildup inside fireplace
willcauseglasstoburst.Make
suretherearenoobstructions
across openings of fireplace.
• You must operate this heater
with a fireplace screen in
place. Make sure fireplace
screen is closed before run-
ning heater.
NOTICE:Duringinitialoperation
of new heater, burning logs will
give off a paper-burning smell.
Orange flame will also be pres-
ent. Open damper or window to
vent smell. This will only last a
few hours.
NOTE: Homeowners generally prefer to op-
erate their heater with the chimney damper
closed.Thiswillputalltheheatintotheroom.
However, there may be times you will desire
the full flames of the HI heat setting but will
find the heat output excessive. You can open
the chimney damper (if you have one) fully or
partially to release some of the heat.
WARNING: Damper handle
will be hot if heater has been
running.
FOR YOUR SAFETY
READ BEFORE LIGHTING
WARNING: If you do not fol-
low these instructions exactly,
a fire or explosion may result
causing property damage, per-
sonal injury or loss of life.
A. This appliance has a pilot which must
be lighted by hand. When lighting the
pilot, follow these instructions exactly.
B. BEFORE LIGHTING smell all around
the appliance area for gas. Be sure to
smell next to the floor because some
gas is heavier than air and will settle
on the floor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the fire department.
C. Use only your hand to push in or turn
the gas control knob. Never use tools.
If the knob will not push in or turn by
hand, don’t try to repair it, call a quali-
fied service technician or gas supplier.
Force or attempted repair may result in
a fire or explosion.
D.
Do not use this appliance if any part has
been under water. Immediately call a
qualified service technician to inspect
the appliance and to replace any part of
the control system and any gas control
which has been under water.

SuperiorFireplaces.us.com
126842-01B 19
1. STOP! Read the safety information in
column 1.
2. Makesureequipmentshutoffvalveisfully
open.
3. Press in and turn control knob clockwise
to the OFF position.
4. Wait five (5) minutes to clear out any gas.
Then smell for gas, including near the
floor. If you smell gas, STOP! Follow “B”
in the safety information, Page 18. If you
don’t smell gas, go to the next step.
5. Pressincontrolknobandturncounterclock-
wise to the PILOT position. The
igniter will spark once. Keep control knob
pressedinfor5seconds.Ifcontrolknobdoes
notpopupwhenreleased,contactaqualified
service person or gas supplier for repairs.
NOTE: You may be running this heater for
the first time after hooking up to gas sup-
ply. If so, the control knob may need to be
pressed in for 30 seconds or more. This
will allow air to bleed from the gas system.
6. Turn control knob clockwise to
OFF position. Press in control knob and
turn counterclockwise to PILOT
position. This will light pilot. Pilot is at-
tachedtorearofburner.Ifneeded, repeat
this process until pilot lights.
NOTE: If pilot does not stay lit, contact a
qualified service person or gas supplier
for repairs. Until repairs are made, light
pilot with match. To light pilot with match,
see Manual Lighting Procedure.
7. Keep control knob pressed in for 30 sec-
ondsafter lighting pilot.After 30 seconds,
release control knob.
NOTE: If pilot goes out, repeat steps 3
through 7.
• If control knob does not pop out when
released, contact a qualified service
person or gas supplier for repairs.
8. Slightlypressandturncontrolknob coun-
terclockwise to desired heating
level. The burner should light. Set control
knob to HI or LO.
Figure 22 - Control Knob and Igniter
Button Location
PILOT
OFF
LO
HI
Control Knob
Figure 23 - Pilot
VARIABLE CONTROL
OPERATION
The variable control valve can be set to high
or low, by simply turning the control knob
until that setting is attained. Even the low-
est setting provides realistic, dancing yellow
flames. Selecting higher settings produces
greater heat output. This results in increased
heating comfort.
CAUTION: Do not try to ad-
just heating levels by using the
equipment shutoff valve.
TO TURN OFF GAS
TO APPLIANCE
1. Press in and turn control knob clockwise
to the OFF position.
2. Close equipment shutoff valve (see Fig-
ure 15, Page 15).
MANUAL LIGHTING
PROCEDURE
1. Follow steps 1 through 5 under Lighting
Instructions,Page 19.
2. Depress control knob and light pilot
with match.
3. Keep control knob pressed in for 30 sec-
ondsafter lighting pilot.After 30 seconds,
release control knob. Now follow step 8
under Lighting Instructions, Page 19.
OPERATION
Continued
Igniter Electrode
Pilot Burner
Thermocouple
WARNING: Do not operate
heaterbetweenPILOTandHIGH
positions.
9. To leave pilot lit and shut off burners only,
turn control knob clockwise to the
PILOT position.

SuperiorFireplaces.us.com 126842-01B20
INSPECTING BURNERS
Figure 24 - Correct Pilot Flame Pattern
Figure 25 - Incorrect Pilot Flame Pattern
BURNER PRIMARY AIR HOLES
Air is drawn into the burner through the holes
in the fitting at the entrance to the burner.
These holes may become blocked with dust
orlint.Periodicallyinspect these holes forany
blockageandcleanas necessary.Blockedair
holes will create soot.
MAIN BURNER
Periodicallyinspectall burnerflameholeswith
the heater running. All slotted burner flame
holes should be open with yellow flame pres-
ent. All round burner flame holes should be
open with a small blue flame present. Some
burner flame holes may become blocked by
debris or rust, with no flame present. If so,
turn off heaterand let cool. Removeblockage,
blocked burner flame holes will create soot.
Check pilot flame pattern and burner flame
patterns often.
PILOT FLAME PATTERN
Figure 24 showsacorrectpilot flame pattern.
Figure 25 shows an incorrect pilot flame pat-
tern.The incorrectpilotflameisnottouchingthe
thermocouple.Thiswillcausethethermocouple
to cool. When the thermocouple cools, the
heater will shut down.
If pilot flame pattern is incorrect, as shown
in Figure 25
• turn heater off (see To Turn Off Gas to Ap-
pliance, Page 19)
• see Troubleshooting, Page 22
NOTE:Thepilot flameon naturalgasunitswill
have a slight curve, but flame should be blue
and have no yellow or orange color.
Pilot Burner
Thermocouple
Pilot Burner
Thermocouple
CLEANING AND MAINTENANCE
ODS/PILOT AND BURNER
Use a vacuum cleaner or small, soft bristled
brush to clean.
BURNER ORIFICE HOLDER AND
PILOT AIR INLET HOLE
The primary air inlet holes allow the proper
amount of air to mix with the gas. This pro-
videsaclean burningflame.Keep theseholes
clearofdust,dirtandlint.Clean these air inlet
holes prior to each heating season. Blocked
airholeswillcreatesoot. Werecommendthat
you clean the unit every three months during
operation and have heater inspected yearly
by a qualified service person.
WARNING: Turn off heater
and let cool before cleaning.
CAUTION: You must keep
control areas, burner and circu-
latingairpassagewaysofheater
clean. Inspect these areas of
heater before each use. Have
heater inspected yearly by a
qualifiedserviceperson.Heater
may need more frequent clean-
ing due to excessive lint from
carpeting,beddingmaterial,pet
hair, etc.
WARNING: Failure to keep
the primary air opening(s) of
the burner(s) clean may result
insootingandpropertydamage.
