L194 Wide Flat Panel Monitor
Business black
4434-HB6
Tilt stand
LCD Active Matrix TFT (Thin Film Transistor)
19.0" / 481mm (diagonal)
16:10
.285mm
16.1" x 10.0" (horizontal x vertical)
408mm x 255mm (horizontal x vertical)
176° (+/- 88°) vertical, 176° (+/- 88°) horizontal
160° (+/- 80°) vertical, 160° (+/- 80°) horizontal
Digital or analog (two separate connectors)
Dual input (two different PCs attach to two different
connectors; one PC shows image; select via button)
No pivot
None
1440x900 at 60Hz
1440x900 at 75Hz (137MHz maximum pixel rate)
50 to 76Hz
30 to 81kHz
VGA: 640x480 60, 66, 72, 75Hz
640x350 70Hz
720x400 70Hz
SVGA: 800x600 56, 60, 72, 75Hz
832x624 75Hz
XGA: 1024x768 60, 70, 75Hz
1152x864 75Hz
SXGA: 1280x1024 60, 70, 75Hz
WXGA+: 1440x900 60, 75Hz
Standard presets: 20; user settings: 20
300 nits or cd/m2(typical)
1000:1 (typical)
5ms (typical)
On screen display with digital user controls (7 languages)
Direct access (buttons on front) for automatic image setup
Two connectors: (1) analog VGA
15-pin D-shell [blue],
(2) Digital Visual Interface (DVI-D) for digital (not analog) attach [white], HDCP-compliant
Two cables: (1) detachable, VGA 15-pin D-shell at each end (for analog connector), 1.8 meter, matches color of monitor
(2) detachable digital, DVI-D at each end (for digital connector), 1.8 meter, matches color of monitor
Anti-reflective, anti-glare
15.0"H x 17.3"W x 7.0"D / 381mm height x 440mm width x 179mm depth
9.1lb / 4.15kg
Tilt: 30° back, 4° forward / no lift, no swivel, detachable stand
Wall or desk mounting using the Radial Arm9or third-party accessories meeting the VESA FPMPMI®(100mm mount)
Security keyhole for attachment of optional cable lock (Kensington®lock-compatible)
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR®3 4.0
ISO 13406 Part 21
ISO 13406-2 Class II pixel defect standard
MPR-2, MPR-3A, FCC Class B
TCO 03, WEEE, RoHS (EU Directive 2002/95/EC), EPEAT™Gold rating
Monitor, attached stand, Setup Guide, Safety and Warranty Information, CD with multilingual User's Guide and
monitor installation files, analog signal cable, digital signal cable, 1.8m black power cord
90-264Vac (universal), integrated (no external brick-like power supply), 29 watts typical, <2 watts standby/suspend
3 year (includes backlight)
October 2007
Name
Case color
Type-model
Stand
Screen
Viewable image size (diag)
Aspect ratio
Pixel pitch (mm)
Max view area (inches)
Max view area (mm)
Viewing angle at 5:1 CR
Viewing angle at 10:1 CR
Video input
Dual input
Rotating screen
USB Hub
Optimum resolution
Maximum resolution
Vertical frequency
Horizontal frequency
Preset display modes
Presets / user settings
Brightness
Contrast ratio
Pixel response time
On screen display
Control features
Monitor connectors
Signal cables
Anti-reflective
Dimensions
Weight
Viewing adjustments
Mounting features
Security
VESA-compliant2
Power management
Ergonomics
Pixel defect
Emission standards
Environmental
Ship group
Power supply
Limited warranty4
Available date
Flat Panel Monitors - US model
Lenovo®ThinkVision®L194 Wide - withdrawn
©Lenovo
(L194W) February 2009
See footnotes for important warranty information
US model announced October 9, 2007
US model withdrawn effective February 2009
Features
• Widescreen 19-inch flat panel monitor
• EPEAT™Gold rating
•View images in a 16:10 wide aspect ratio
• Resolution of 1440x900 provides crisp screen images
• Slim 14.3mm (0.56") side bezel
• High-bandwidth Digital Content Protection (HDCP)-compliant
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
•Complements the ThinkCentre®and ThinkPad®systems
•Microsoft®Windows®Vista™Premium certified
Personal Systems Reference (PSREF)
Limited Warranty
➫3 year limited warranty4
➫International Warranty Service5
➫Rapid Replacement Service at 1-800-IBM-SERV (426-7378)
➫Replacement normally arrives in two business days, excluding holidays
➫Lenovo pays all shipping costs for valid warranty claims6
➫Service upgrade options:7
•3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™part number 41C9209)
•3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
•4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
•4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9234)
➫24x78day toll-free support for warranty issues during the warranty period4
Accessories
ThinkVision®USB Soundbar 40Y7616
Kensington®MicroSaver®Security Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
ThinkPad Convertible Monitor Stand 40Y7620
ThinkVision TFT Radial Arm919K4464
See details at www.lenovo.com/support/monitoraccessories
