Leviton 47611-WG4 User manual

Note
– 1 – – 2 –
– 3 – – 4 –
1. Package Contents
2. Hardware Installation
– 7 – – 8 –
3. Network Configuration (Windows 7)
4. Enter into the Web Management
5. Wireless Network Connection
– 5 – – 6 –
Wireless Router Quick Guide CD-ROM
Power Adapter Ethernet Cable
STEP 1: Right-Click on the network icon displayed in the
system tray.
STEP 2: Highlight the wireless network (SSID) you want to
connect and click Connect button.
STEP 3: Enter the encryption
key of 47611-WG4 if
necessary.
You have already finished the
configuration of the 47611-WG4.
Now you can use your iPhone,
iPad, laptop, and any other Wi-Fi
devices to connect with it
wirelessly and start surfing the
Internet.
FURTHER INFORMATION:
The above steps introduce simple installations and configura-
tions for 47611-WG4. For further configurations of Wireless
Dual Band, WAN, LAN, Firewall, Virtual Server, DMZ, and
DDNS etc, please refer to the user manual in the CD-ROM. If
you have further questions, please contact Leviton Tech
Support at 800.824.3005.
2011-E50280-010
Thank you for choosing Leviton 47611-WG4. Before
installing the router, please verify the contents inside the
package box.
If there are any items missing, please contact
Leviton immediately.
STEP 1: Connect the Power Adapter provided in the
package to the 47611-WG4. The Power LED on
the front panel shall turn on accordingly.
STEP 2: Follow the figure below to connect the network
devices. It depends on your network environment
to connect the WAN port to a Cable/xDSL modem,
or the Ethernet directly in your place. A computer with a wired Ethernet connection is required for
the first-time configuration of the Wireless Router.
Set your computer to get an IP address from the Wireless
Router:
1. Click “Start” button located at lower-left corner of the
screen.
2. Click “Control Panel”.
3. Double click “Network and Sharing Center” icon.
4. Click “Change adapter settings”.
5. Double click “Local Area Connection” icon.
6. Select “Internet Protocol Version 4 (TCP/IPv4)”
and click “Properties” button.
7. Select “Obtain an IP address automatically” and
“Obtain DNS server address automatically”, then
click “OK” button twice to save the configuration.
Default IP Address: 192.168.0.1
Default User name: admin
Default Password: admin
Default SSID of 2.4G: default_2.4G
Default SSID of 5G: default_5G
Default Wireless Encryption Type: None
STEP 2: When you enter into the Web User Interface,
please enter the User Name and Password in the
login window. The default User name and
Password are both “admin”.
Then click “Login” button to continue.
STEP 1: The Web management allows you to access
and manage the 47611-WG4 easily. Launch the
Web browser and enter the default IP address
http://192.168.0.1
STEP 3: Once the corresponding Internet connection type
is chosen, click OK button to save and make the
changes take effect.
47611-WG4
Quick Installation Guide
300Mbps Dual-Band 802.11n
Wireless Gigabit Router
PC/Laptop
RJ-45
Cable /xDSL
Modem
Phone
Jack
RJ-45
RJ-11
USB Line
RJ-45
A/V
001101010
STB
TV
USB Storage Power Adapter
Power
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encourages to try to correct the interference by one
or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC and IC Statement:
To assure continued compliance, (example-use only shielded
interface cables when connecting to computer or peripheral devices)
any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
Power Adapter
Power
This device complies with Part 15 of the FCC Rules and Industry
Canada licence-exempt RSS standard(s). Operation is subject to the
Following two conditions:
(1) This device may not cause harmful interference
(2) This Device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
Canadian Department of Communications
The device meets the exemption from the routine evaluation limits in
section 2.5 of RSS 102 and compliance with RSS-102 RF exposure,
users can obtain Canadian information on RF exposure and compli-
ance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation
dans la section 2.5 de RSS 102 et la conformité à l'exposition de
RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur
l'exposition et la conformité de rf.
Federal Communication Commission (FCC) Radiation
Exposure Statement
This equipment complies with FCC radiation exposure set forth for an
uncontrolled environment. In order to avoid the possibility of
exceeding the FCC radio frequency exposure limits, human proximity
to the antenna shall not be less than 20 cm (8 inches) during normal
operation.

Note
– 1 – – 2 –
– 3 – – 4 –
1. Package Contents
2. Hardware Installation
– 7 – – 8 –
3. Network Configuration (Windows 7)
4. Enter into the Web Management
5. Wireless Network Connection
– 5 – – 6 –
Wireless Router Quick Guide CD-ROM
Power Adapter Ethernet Cable
STEP 1: Right-Click on the network icon displayed in the
system tray.
STEP 2: Highlight the wireless network (SSID) you want to
connect and click Connect button.
STEP 3: Enter the encryption
key of 47611-WG4 if
necessary.
You have already finished the
configuration of the 47611-WG4.
Now you can use your iPhone,
iPad, laptop, and any other Wi-Fi
devices to connect with it
wirelessly and start surfing the
Internet.
FURTHER INFORMATION:
The above steps introduce simple installations and configura-
tions for 47611-WG4. For further configurations of Wireless
Dual Band, WAN, LAN, Firewall, Virtual Server, DMZ, and
DDNS etc, please refer to the user manual in the CD-ROM. If
you have further questions, please contact Leviton Tech
Support at 800.824.3005.
2011-E50280-010
Thank you for choosing Leviton 47611-WG4. Before
installing the router, please verify the contents inside the
package box.
If there are any items missing, please contact
Leviton immediately.
STEP 1: Connect the Power Adapter provided in the
package to the 47611-WG4. The Power LED on
the front panel shall turn on accordingly.
STEP 2: Follow the figure below to connect the network
devices. It depends on your network environment
to connect the WAN port to a Cable/xDSL modem,
or the Ethernet directly in your place. A computer with a wired Ethernet connection is required for
the first-time configuration of the Wireless Router.
Set your computer to get an IP address from the Wireless
Router:
1. Click “Start” button located at lower-left corner of the
screen.
2. Click “Control Panel”.
3. Double click “Network and Sharing Center” icon.
4. Click “Change adapter settings”.
5. Double click “Local Area Connection” icon.
6. Select “Internet Protocol Version 4 (TCP/IPv4)”
and click “Properties” button.
7. Select “Obtain an IP address automatically” and
“Obtain DNS server address automatically”, then
click “OK” button twice to save the configuration.
Default IP Address: 192.168.0.1
Default User name: admin
Default Password: admin
Default SSID of 2.4G: default_2.4G
Default SSID of 5G: default_5G
Default Wireless Encryption Type: None
STEP 2: When you enter into the Web User Interface,
please enter the User Name and Password in the
login window. The default User name and
Password are both “admin”.
Then click “Login” button to continue.
STEP 1: The Web management allows you to access
and manage the 47611-WG4 easily. Launch the
Web browser and enter the default IP address
http://192.168.0.1
STEP 3: Once the corresponding Internet connection type
is chosen, click OK button to save and make the
changes take effect.
47611-WG4
Quick Installation Guide
300Mbps Dual-Band 802.11n
Wireless Gigabit Router
PC/Laptop
RJ-45
Cable /xDSL
Modem
Phone
Jack
RJ-45
RJ-11
USB Line
RJ-45
A/V
001101010
STB
TV
USB Storage Power Adapter
Power
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encourages to try to correct the interference by one
or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC and IC Statement:
To assure continued compliance, (example-use only shielded
interface cables when connecting to computer or peripheral devices)
any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
Power Adapter
Power
This device complies with Part 15 of the FCC Rules and Industry
Canada licence-exempt RSS standard(s). Operation is subject to the
Following two conditions:
(1) This device may not cause harmful interference
(2) This Device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
Canadian Department of Communications
The device meets the exemption from the routine evaluation limits in
section 2.5 of RSS 102 and compliance with RSS-102 RF exposure,
users can obtain Canadian information on RF exposure and compli-
ance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation
dans la section 2.5 de RSS 102 et la conformité à l'exposition de
RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur
l'exposition et la conformité de rf.
Federal Communication Commission (FCC) Radiation
Exposure Statement
This equipment complies with FCC radiation exposure set forth for an
uncontrolled environment. In order to avoid the possibility of
exceeding the FCC radio frequency exposure limits, human proximity
to the antenna shall not be less than 20 cm (8 inches) during normal
operation.
