LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 1
LEXICON LE45
STAGING & PROVISIONS
MANAGER
USER GUIDE

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 2
TABLE OF CONTENTS
3 OVERVIEW
4 FEATURES SUMMARY
5 STAGING MANAGER: SOURCE DEVICE
OPEN STAGING MANAGER
STEP 1: ADJUST WIFI SETTINGS
STEP 2: INPUT APK DOWNLOAD ADDRESS
STEP 3: INPUT BACKDOORPASSWORD FOR KIOSK MODEIN
STEP 4: INPUT PACKAGE NAME FOR KIOSK MODE
STEP 5: GENERATE QR CODE
TIPS FOR USING QR CODE
PREPARE SCANWEDGE SETTINGS
8 PROVISION MANAGER: TARGET DEVICE
OPEN PROVSION MANAGER
STEP 1: RESTORE WIFI SETTINGS
STEP 2: SCAN QR CODE FOR SETUP
STEP 3: CHECK KEY INFORMATION SETTINGS
STEP 4: DEPLOY
STEP 5: MULTIPLE APPLICATION INSTALLS
STEP 6: START/STOP KIOSK
11 RESTORE SCANWEDGE SETTINGS
STEP 1: SCAN QR CODE FOR SETUP
STEP 2: VERIFY APP INSTALLATION
STEP 3: VERIFY SCANWEDGE CONFIGURATION

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 3
Staging & Provision Manager is a software utility that allows IT administrators to quickly set up
a terminal with pre-defined Wi-Fi & ScanWedge settings and application installation. Instead
of entering in the settings in each device individually, the utility creates the QR code(s) which
contains the settings and application path/URL, and applies them to the target devices by
scanning the QR barcode(s). The below illustration shows the workflow of Staging & Provision
Manager.
OVERVIEW
Staging and Provision Manager work in pairs. The Staging Manager is installed in the source device and the
Provision Manager is installed in the target device(s). All settings must be set up in the source device. The
Staging Manager will create QR code(s) based on the setting in the source device and Provision Manager
will restore the settings in the target device(s).
The QR code(s) generated by Staging Manager embeds the WiFi & ScanWedge settings and path / URL to
download targeted applications. This QR code(s) is distributed via various means like paper, portable devices
such as smartphones or PCs. The QR code(s) is scanned by the target device(s) with Provision Manager
installed, the Provision Manager will decode the settings and apply them to the target device(s).
SOURCE DEVICE
GENERATE READ
STAGING
MANAGER
• Wifi Settings
• ScanWedge
Settings
• App Install
• Kiosk Settings
COPY
DISTRIBUTION MEDIA
Paper
Mobile Device
Laptop/Desktop PC
TARGET DEVICES
PROVISION
MANAGER
• Wifi Settings
• ScanWedge
Settings
• App Install
• Kiosk Settings

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 4
FEATURES SUMMARY
STAGING MANAGER FEATURES
• Creates a QR code for WiFi settings and for applications to be installed in Kiosk mode.
• Creates a QR code for ScanWedge settings.
PROVISIONS MANAGER FEATURES
• Read a QR code (via camera or scan engine) and apply the settings to the device.
• Kick-starts the Kiosk mode.

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 5
STAGING MANAGER: SOURCE DEVICE
OPEN STAGING MANAGER
Start the Staging Manager from the desktop.
STEP 1: ADJUST WIFI SETTINGS
(IF REQUIRED) Input Wi-Fi information (SSID, security type and password).
Note: Wi-Fi password will be encrypted by AES algorithm in the QR code.

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 6
STEP 2: INPUT APK DOWNLOAD ADDRESS
TIPS
• You can put your APK at Google drive and generate the direct
download link if your company doesn’t have any server space
that can provide the link.
• If the target application is available at Google’s Play store, you
can generate the direct download link at many third party sites.
• You can use ScanWedge to scan the download link instead of
typing it in.
EXAMPLE
In this step we are downloading “Candy Crush Saga,” the famous
mobile game from
https://storage.evozi.com/apk/dl/16/09/04/com.king.candycrushsaga_11970011.apk.
(Please note the download link may not work after a while as it is for
demo purposes only.)
STEP 3: INPUT BACKDOOR
PASSWORD FOR KIOSK MODE
Input the backdoor password for Kiosk mode.
The default setting is “12345”.
STEP 4: INPUT PACKAGE
NAME FOR KIOSK MODE
For example, if the device only allows users to
play Candy Crush, the setup should only put
“com.king.cand crush saga” for the Kiosk application.

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 7
STEP 5: GENERATE QR CODE
Click “DEPLOY QR CODE” to generate the code to configure ScanWedge.
You can access the QR Code later by clicking “SCANWEDGE QR CODE”.
TIPS FOR USING QR CODE
• Each QR code points to one (1) URL and therefore only one (1) application can be downloaded
at a time.
• If the administrator needs to deploy 5 applications, for example, to each terminal and these 5
applications are shown in the kiosk mode, the administrator needs to generate the QR code
five (5) times. Each time, the download URL points to different applications.
• For the first four QR codes, only the download URL is needed. In the fifth one, put the
download URL in with 5 application packages in the Kiosk App 1 / 2/ 3/ 4/ 5.
• To apply the settings to the target terminal, the first four QR codes (only APP download URL)
can be applied in any order. The one with download URL and 5 application packages in Kiosk
App settings must be applied in the last place.
PREPARE SCANWEDGE SETTINGS
1. Make sure the parameters in ScanWedge are all set. For details, please refer to the LE45
ScanWedge User Guide.
2. Click the “SCANWEDGE QR CODE.”

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 8
PROVISION MANAGER: TARGET DEVICE
OPEN PROVSION MANAGER
Start the Staging Manager from the desktop.
STEP 1: RESTORE WIFI SETTINGS
STEP 2: SCAN QR CODE FOR SETUP
Make sure the QR code created in the staging manager is ready. You can scan the QR Code either through
the camera or through Scan Engine.
TIP:
When scanning using the camera, make
sure the QR code is placed with the active
scan area as shown.

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 9
STEP 3: CHECK KEY INFORMATION SETTINGS
After the QR code is scanned and is checked valid, the settings will be ap-
plied to the terminal, the key information will be displayed as shown.
STEP 4: DEPLOY
If all of the information in Step 3 is correct, click the DEPLOY button and wait for installation to
complete.

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 10
STEP 5: MULTIPLE APPLICATION INSTALLS
If you have multiple applications to be installed, repeat STEP 1 to STEP 4.
STEP 6: STARTSTOP KIOSK
After all applications are installed, hit the START KIOSK MODE button to start the kiosk application.
To exit kiosk mode, click Stop kiosk mode button and type in the Admin password. If you didn’t
set the password at the QR code, the default password is “12345”.

LexiconLE45.com STAGING & PROVISIONS MANAGER USER GUIDE | 11
RESTORE SCANWEDGE SETTINGS
STEP 1: SCAN QR CODE FOR SETUP
Make sure the QR code created in the staging manager is ready. You can scan the QR Code
either through the camera or through Scan Engine.
STEP 2: VERIFY APP
INSTALLATION
After the QR code is scanned and is checked
valid, you will see the notification shown.
TIP:
When scanning using the camera, make
sure the QR code is placed with the active
scan area as shown.
STEP 3: VERIFY SCANWEDGE
CONFIGURATION
Quit the Provision Manager and go to the ScanWedge
utility. Double check the configuration is applied as set.
