Lexicon Studio Core2 Service Manual
Copyright © 1999 Lexicon, Inc.
All Rights Reserved
Lexicon Inc. ●3 Oak Park ●Bedford, MA 01730-1441 ●Tel (781) 280-0300 ●Customer Service Fax (781) 280-0499
Lexicon Part # 070-14394 Rev 0
Printed in the United States of America
Lexicon
Lexicon Studio Core2 Service Manual
Lexicon
Table of Contents
Chapter 1 Reference Documents, Required Equipment ............................1-1
Reference Documents .............................................................................................................................. 1-1
Required Equipment ................................................................................................................................. 1-1
Tools ...................................................................................................................................................... 1-1
Test Equipment ..................................................................................................................................... 1-1
Chapter 2 General Information...................................................................2-1
Periodic Maintenance................................................................................................................................ 2-1
Ordering Parts ........................................................................................................................................... 2-1
Returning Units to Lexicon for Service...................................................................................................... 2-1
Chapter 3 Specifications............................................................................3-1
Chapter 4 Performance Verification ...........................................................4-1
Test Overview: .......................................................................................................................................... 4-1
User Interface:........................................................................................................................................... 4-1
Punch page:........................................................................................................................................... 4-1
Clock Source Page:............................................................................................................................... 4-2
Core2 Page:........................................................................................................................................... 4-3
I/O Tests:................................................................................................................................................... 4-4
Analog In To Analog Out Audio Listening Test: .................................................................................... 4-4
Analog In To Digital Out Audio Listening Test:...................................................................................... 4-4
Digital In To Digital Out Audio Listening Test:....................................................................................... 4-5
Digital Input To Analog Output Listening Test:...................................................................................... 4-5
Gain Tests:................................................................................................................................................ 4-6
Analog In To Digital Out Gain Test:....................................................................................................... 4-6
Digital In To Analog Out Gain Test:....................................................................................................... 4-6
Frequency Response: ............................................................................................................................... 4-7
Analog In To Digital Out Frequency Test: ............................................................................................. 4-7
Digital In To Analog Out Frequency Test: ............................................................................................. 4-7
THD+N Measurement: .............................................................................................................................. 4-8
Analog In To Digital Out THD+N Test: .................................................................................................. 4-8
Digital In To Analog Out THD+N Test: .................................................................................................. 4-9
Crosstalk Tests: ........................................................................................................................................ 4-9
Analog In To Digital Out Crosstalk Test: ............................................................................................... 4-9
Digital In To Analog Out Crosstalk Test: ............................................................................................. 4-10
Dynamic Range Tests:............................................................................................................................ 4-10
Analog In To Digital Out Dynamic Range Test:................................................................................... 4-10
Digital In To Analog Out Signal to Noise Test:.................................................................................... 4-11
DBX THD+N Tests: ................................................................................................................................. 4-12
Analog In To Digital Out DBX THD+N Test:........................................................................................4-12
DBX Characteristics ............................................................................................................................ 4-12
Lexicon Audio Precision ATE Summary.............................................................................................. 4-13
............................................................................................................................................................. 4-13
Chapter 5 Troubleshooting ........................................................................5-1
Installation ................................................................................................................................................. 5-1
Lexicon Studio Installation Troubleshooting.......................................................................................... 5-1
Lexicon Studio Core2: Complete Uninstall and re-installation directions.............................................. 5-1
Lexicon Studio Core2: sharing IRQ or no resources assigned. Change BIOS ........................................ 5-3
V1.20 Release Notes ................................................................................................................................ 5-3
Addendum #1: NEW USER INTERFACE FEATURES......................................................................... 5-4
Addendum #2: AUXILIARY SENDS AND RETURNS........................................................................... 5-5
Addendum #3: TEXT ENTRY OF FADER VALUES ............................................................................. 5-5
Addendum #4: LEVEL ON EXTERNAL OUTPUT WHEN CLOSING LEXPANEL ............................... 5-5
Addendum #5: ROUTING IN CUBASE ................................................................................................. 5-5
Lexicon Studio Core2 Service Manual
Addendum #6: PUNCH ROUTING IN CUBASE ................................................................................... 5-5
Addendum #7: CLOCK SOURCE CONSISTENCY IN CUBASE ......................................................... 5-6
Addendum #8: THE EFFECT OF ROUTING CHANGES ON WAVE DRIVERS .................................. 5-6
Addendum #9: SELECTION OF WINDOWS SOUNDS........................................................................ 5-7
Addendum #10: CLOCK SOURCE SELECTION IN MMIO .................................................................. 5-7
Addendum #11: MMIO BUS ALIGNMENT IN ACID AND COOL EDIT PRO ....................................... 5-7
Addendum #12: NOISES THAT OCCUR AFTER SHUTDOWN OF SAMPLITUDE ............................ 5-7
Addendum #13: S/PDIF EFFECTS LOOP............................................................................................ 5-7
CORE2 USER'S GUIDE ERRATA ........................................................................................................ 5-8
V1.20-P1 Update....................................................................................................................................... 5-8
Lexicon Studio Core2: Update patch v120-P1 won't unzip properly......................................................... 5-9
C2V120P2.reg - Update............................................................................................................................ 5-9
Lexicon Studio Core2: In Cubase®, the LexPanel does not get properly shut down from the task bar... 5-9
Chapter 6 Theory of Operation .................................................................. 6-1
Architectural Overview .............................................................................................................................. 6-1
Core2 Block Diagram ................................................................................................................................ 6-2
Startup Sequence ..................................................................................................................................... 6-3
DSP56301 (schematic sheet 1.) ............................................................................................................... 6-3
DSP 56301 Expansion Port Memory Map (AA1, AA2 chip selects) ......................................................... 6-3
DSP 56301 Expansion Port Memory Map (AA0 chip select, 48K/44.1K mode)....................................... 6-4
DSP 56301 Expansion Port Memory Map (AA0 chip select, 96K/88.2K mode 1).................................... 6-4
DSP 56301 Expansion Port Memory Map (AA0 chip select, 96K/88.2K mode 2).................................... 6-4
DSP 56301 Expansion Port Memory Map (AA0 chip select, 96K/88.2K mode 3).................................... 6-5
DSP 56301 ESSI Ports ............................................................................................................................. 6-5
DSP 56301 ESSI Port C Register............................................................................................................. 6-5
DSP 56301 ESSI Port D Register............................................................................................................. 6-5
XCS10 FPGA (schematic sheet 2.) .......................................................................................................... 6-5
System Control Register 0 ........................................................................................................................ 6-6
System Control Register 1 ........................................................................................................................ 6-6
Word clock source encoding..................................................................................................................... 6-6
System Status Register............................................................................................................................. 6-7
SPDIF TX Channel Status byte 3 ............................................................................................................. 6-7
SPDIF sample rate encoding .................................................................................................................... 6-7
Sample Clock Phase-Locked Loop (schematic sheet 3.) ......................................................................... 6-7
PCI & Option Connectors (schematic sheet 4.) ........................................................................................ 6-7
Audio I/O & Connectors (schematic sheet 5.)........................................................................................... 6-8
A/D Conversion (schematic sheet 6.) ....................................................................................................... 6-8
D/A Conversion (schematic sheets 8, 9 ).................................................................................................. 6-8
Voltage Regulators (schematic sheet 10.) ................................................................................................ 6-8
Chapter 7 - Parts List................................................................................. 7-1
CORE 2 PC BOARD ASSEMBLY ............................................................................................................ 7-1
CORE2 CONNECTOR BD MECHANICAL ASSEMBLY .......................................................................... 7-3
CORE 2 CONNECTOR BD PC BOARD ASSEMBLY .............................................................................. 7-3
CORE 2 SHIPPING MATERIAL ............................................................................................................... 7-3
Chapter 8 Schematics and Drawings.........................................................8-1
Schematics:............................................................................................................................................... 8-1
Drawings: .................................................................................................................................................. 8-1
Lexicon
1-1
Chapter 1 Reference Documents, Required Equipment
Reference Documents
Lexicon Studio Core2 Owner's Manual - Lexicon P/N 070-13748 or latest revision
Lexicon Studio Core2 Installation Instructions - Lexicon P/N 070-14195 or latest revision
Lexicon Studio Core2 CD - Lexicon P/N 750-13716 or latest revision
Required Equipment
Tools
The following is a minimum suggested technician's tool kit required for performing disassembly, assembly
and repairs:
•Clean, antistatic, well lit work area.
•(1) #1 Phillips tips screwdriver
•(1) 14mm socket nut driver
•PCI Passive Extender, AZ-COM 9900-27-01 (Rev. B) or equivalent.
•PCI Passive Mini Extender, AZ-COM 9900-07-05 (Rev. B) or equivalent.
•Solder: 63/37 - Tin/Lead Alloy composition, low residue, no-clean solder.
•Magnification glasses and lamps
•SMT Soldering / Desoldering bench-top repair station
Test Equipment
The following is a minimum suggested equipment list required to perform the proof of performance tests.
-A personal PC (PC) with an Intel Pentium CPU of at least 200Mhz. 64meg memory,
Windows95®.
-A monitor, keyboard and mouse.
-Lexicon Studio Core2 system consisting of a Core2 PCI card, Connector Box and the
proprietary Lexicon cable to connect the Core2 and Connector Box (provided with the system).
-Amplifier with speakers or headphones.
-At least the following to perform the minimum I/O tests as signal source:
-(1) CD player with both analog and digital (S/PDIF) inputs and outputs. Or,
-(1) DAT machine with both analog and digital (S/PDIF) inputs and outputs. Or,
-(1) Effects box with tone generator (e.g. preset 170 on MPX-1).
-(1) Lexicon M300 (or other device for equivalent A/D and D/A conversion)
-Cables: (dependent on your signal source)
-(2) ¼ unbalanced single conductor to (whatever type connector your amp has) for analog
connections.
-(2) RCA to RCA for digital in to digital out. For digital audio use 75Ωcable.
-(2) Optical to Optical for digital in to digital out.
-(1) low distortion analog oscillator
-(1) analog distortion analyzer and level meter with 20kHz or 30kHz Lo Pass Filter
-(1) 100 MHz oscilloscope
-(1) digital distortion analyzer & digital function generator (e.g. Stanford Research Systems
Model DS360 or Audio Precision System 1 with DSP Option /System 2).
