Sharp XL-HP500W User manual

Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please
read this manual carefully. It will guide you in operating
your SHARP product.
XL-HP500W Micro Component System consisting of XL-
HP500W (main unit) and CP-HP500W (speaker system).
MICRO COMPONENT SYSTEM
MODEL
XL-HP500W
OPERATION MANUAL
XLHP500WA_FRONT 02.8.7, 9:54 AM1

E-1
02/8/6 XL-HP500W(A)1.fm
ENGLISH
XL-HP500W
Important Instruction
Special notes
Warning:
!When the ON/STAND-BY button is set at STAND-BY position,
mains voltage is still present inside the unit. When the ON/
STAND-BY button is set at STAND-BY position, the unit may be
brought into operation by the timer mode or remote control.
!This unit contains no user serviceable parts. Never remove cov-
ers unless qualified to do so. This unit contains dangerous volt-
ages, always remove mains plug from the socket before any
service operation and when not in use for a long period.
!To prevent fire or shock hazard, do not expose this appliance to
dripping or splashing. No objects filled with liquids, such as
vases, should be placed on the apparatus.
Note for users in Australia:
Copyright may exist in material you wish to record. Copying or
broadcasting such material without permission of the relevant lic-
ensees or owners of the copyright is prohibited by law. SHARP is
not in a position to authorise the copying or broadcasting of copy-
right materials and nothing in this OPERATION MANUAL should be
implied as giving that authority.
For other countries:
Audio-visual material may consist of copyrighted works which must
not be recorded without the authority of the owner of the copyright.
Please refer to the relevant laws in your country.
CAUTION
!This product is classified as a CLASS 1 LASER product.
!Use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous radiation ex-
posure.
As the laser beam used in this compact disc player is harmful to
the eyes, do not attempt to disassemble the cabinet. Refer servic-
ing to qualified personnel only.
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW

02/8/6 XL-HP500W(A)1.fm
E-2
ENGLISH
XL-HP500W
General Information
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Contents
Page
"General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
"Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 10
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
"Basic Operation
Sound control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
"CD Playback
Listening to a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 15
Advanced CD playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 17
"Radio
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18, 19
"Tape Playback
Listening to a cassette tape . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
"Karaoke
Playing karaoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21, 22
"Tape Recording
Recording to a cassette tape . . . . . . . . . . . . . . . . . . . . . . . 23, 24
"Advanced Features
Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . .25 - 27
Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 28
"References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29, 30
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31, 32
Remote control 1 "AA" size battery
(UM/SUM-3, R6, HP-
7 or similar) 2
AM loop aerial 1
FM aerial 1 Speaker wire 2

02/8/6 XL-HP500W(A)1.fm
E-3
ENGLISH
XL-HP500W
General Information
Precautions
"General
!Please ensure that the equipment is positioned in a well venti-
lated area and ensure that there is at least 10 cm (4") of free
space along the sides, top and back of the equipment.
!Use the unit on a firm, level surface free from vibration.
!Keep the unit away from direct sunlight, strong magnetic fields,
excessive dust, humidity and electronic/electrical equipment
(home computers, facsimiles, etc.) which generates electrical
noise.
!Do not place anything on top of the unit.
!Do not expose the unit to moisture, to temperatures higher than
60°C (140°F) or to extremely low temperatures.
!If your system does not work properly, disconnect the AC power
lead from the wall socket. Plug the AC power lead back in, and
then turn on your system.
!In case of an electrical storm, unplug the unit for safety.
!Hold the AC power plug by the head when removing it from the
wall socket, as pulling the lead can damage internal wires.
!Do not remove the outer cover, as this may result in electric
shock. Refer internal service to your local SHARP service
facility.
!The ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, tablecloths, curtains,
etc.
!No naked flame sources, such as lighted candles, should be
placed on the apparatus.
!Attention should be drawn to the environmental aspects of bat-
tery disposal.
!This unit should only be used within the range of 5°C - 35°C
(41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is
specified is dangerous and may result in a fire or other type of acci-
dent causing damage. SHARP will not be held responsible for any
damage resulting from use of this unit with a voltage other than that
which is specified.
"Volume control
The sound level at a given volume setting depends on speaker effi-
ciency, location, and various other factors. It is advisable to avoid
exposure to high volume levels. Do not turn the volume on to full at
switch on and listen to music at moderate levels.
"Care of compact discs
Compact discs are fairly resistant to damage, however mistracking
can occur due to an accumulation of dirt on the disc surface. Follow
the guidelines below for maximum enjoyment from your CD collec-
tion and player.
!Do not write on either side of the disc, particularly the non-label
side from which signals are read. Do not mark this surface.
!Keep your discs away from direct sunlight, heat, and excessive
moisture.
!Always hold the CDs by the edges. Fingerprints, dirt, or water on
the CDs can cause noise or mistracking. If a CD is dirty or does
not play properly, clean it with a soft, dry cloth, wiping straight out
from the centre, along the radius.
10 cm (4") 10 cm (4") 10 cm (4")
10 cm (4")
NO YES
Correct

02/8/6 XL-HP500W(A)1.fm
E-4
ENGLISH
XL-HP500W
General Information
Controls and indicators
"Front panel
Reference page
1. Disc Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25, 27
4. Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 25
5. Tuning and Time Down Button . . . . . . . . . . . . . . . . . . . 13, 18
6. Tuning and Time Up Button . . . . . . . . . . . . . . . . . . . . . 13, 18
7. Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8. Microphone Level Control . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9. Microphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
10. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11. CD Eject Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
12. CD Direct Play Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
13. Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . 12
14. Extra Bass/Demo Mode Button . . . . . . . . . . . . . . . . . . 10, 12
15. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
16. Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
17. Tape Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . 20
18. CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . 14, 20
19. CD Play or Repeat, Tape Forward Play Button . . . 14, 16, 20
20. CD Track Down or Fast Reverse, Tape Fast Wind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . 15, 19, 20
21. CD Track Up or Fast Forward, Tape Fast Wind,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . 15, 19, 20
22. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
23. Tape Record Pause Button . . . . . . . . . . . . . . . . . . . . . . 23, 24
24. Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
25. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
26. Tape Reverse Mode Select Button . . . . . . . . . . . . . . . . . . . 20
27. Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . 13, 17, 19
28. Tape Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3
2
1
4
5
6
10
12
11
13
15
14
16
17 19 20 21
24
22
23
25 26 27 28
18
7
8
9

02/8/6 XL-HP500W(A)1.fm
E-5
ENGLISH
XL-HP500W
General Information
Controls and indicators (continued)
"Display
1. Disc Number Indicators
2. CD Play Indicator
3. Tape Reverse Mode Indicator
4. Tape Reverse Play Indicator
5. Tape Forward Play Indicator
6. FM Stereo Mode Indicator
7. FM Stereo Receiving Indicator
8. Memory Indicator
9. Extra Bass Indicator
10. Timer Recording Indicator
11. Timer Play Indicator
12. CD Pause Indicator
13. CD Repeat Play Indicator
14. Tape Record Indicator
15. Sleep Indicator
"Rear panel
Reference page
1. AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. Cooling Fan
3. Subwoofer Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 9
5. FM 75 Ohms Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . 7, 8
6. FM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
7. AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
8. Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . 27
9. Span Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
10. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
Note:
This product is equipped with a cooling fan inside, which begins to
run at a specified volume level for better heat radiation.
"Speaker system
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Terminals
2
3
1
4
5
6
7
8
9
10
21345 6789
10
11
151412 13
3
4
1
2

02/8/6 XL-HP500W(A)1.fm
E-6
ENGLISH
XL-HP500W
General Information
!Remote control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2. CD Direct Play Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3. CD Track Down or Fast Reverse, Tape Fast Wind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . . . 15, 19, 20
4. Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5. Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . 12
6. Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
10. Tape Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
11. Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
12. CD Track Up or Fast Forward, Tape Fast Wind,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . 15, 19, 20
13. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . 12
14. Disc Direct Search Buttons . . . . . . . . . . . . . . . . . . . . . . . . . 16
15. CD Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
16. CD Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
17. CD Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
18. CD Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
19. Tape Reverse Mode Select Button . . . . . . . . . . . . . . . . . . . . 20
20. Tape Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
21. Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
22. CD Play or Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . 14, 16
23. Tape Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . 23, 24
24. CD Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
25. Tape Forward Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1
2
3
4
5
6
7
8
9
10
11
12
14
13
15
16
22
23
24
25
17
18
19
20
21
Buttons with " " mark in the illustration can be operated on the re-
mote control only.

02/8/6 XL-HP500W(A)1.fm
E-7
ENGLISH
XL-HP500W
Preparation for Use
System connections
BlackRed
Black
Red
AM loop aerial
FM aerial
Left speaker
Right speaker
Wall socket
(See page 9.)

02/8/6 XL-HP500W(A)1.fm
E-8
ENGLISH
XL-HP500W
Preparation for Use
!Aerial connection
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS terminal and posi-
tion the FM aerial wire in the direction where the strongest signal
can be received.
Supplied AM loop aerial:
Connect the AM loop aerial to the AM LOOP socket. Position the
AM loop aerial for optimum reception. Place the AM loop aerial on a
shelf, etc., or attach it to a stand or a wall with screws (not supplied).
Note:
Placing the aerial on the unit or near the AC power lead may cause
noise pickup. Place the aerial away from the unit for better recep-
tion.
Installing the AM loop aerial:
External FM aerial:
Use an external FM aerial if you require better reception. Consult
your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM
aerial wire.
!Speaker connection
Connect the black wire to the minus (-) terminal, and the red wire to
the plus (+) terminal.
Caution:
"Connect the speaker wires to the speakers first, then to the
unit.
"Use speakers with an impedance of 6 ohms or more, as lower
impedance speakers can damage the unit.
"Do not mistake the right and the left channels. The right speaker
is the one on the right side when you face the unit.
"Do not let the bare speaker wires touch each other.
"Do not allow any objects to fall into or to be placed in the bass
reflex ducts.
"Do not stand or sit on the speakers. You may be injured.
Speaker grilles are removable:
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
External
FM aerial
75 ohm
coaxial
cable
Incorrect Incorrect
Make sure nothing comes into contact
with the speaker diaphragms when you
remove the speaker grilles.

02/8/6 XL-HP500W(A)1.fm
E-9
ENGLISH
XL-HP500W
Preparation for Use
System connections (continued)
!Setting the AC voltage selector
Check the setting of the AC voltage selector located on the rear
panel before plugging the unit into a wall socket. If necessary, adjust
the selector to correspond to the AC power voltage used in your
area.
Turn the selector with a screwdriver until the appropriate volt-
age number appears in the window (110 V, 127 V, 220 V or 230
V - 240 V AC).
!Connecting the AC power lead
After checking all the connections have been made correctly, plug
the AC power lead of this unit into the wall socket. If you plug the
unit first, the unit will enter the demonstration mode (see page 10).
Notes:
"The unit will start the tape initialisation when plugged in to the AC
socket. During this process, initialising sound will be heard and
the unit cannot be turned on. Wait until the process is finished.
"Unplug the AC power lead from the wall socket if the unit will not
be in use for a prolonged period of time.
(230 - 240 V, 50/60 Hz)
Wall socket
230V
240V

02/8/6 XL-HP500W(A)1.fm
E-10
ENGLISH
XL-HP500W
Preparation for Use
!Setting the FM/AM span selector
The International Telecommunication Union (ITU) has established
that member countries should maintain either a 100 kHz or a 50 kHz
interval between broadcasting frequencies of FM stations and 10
kHz or 9 kHz for AM station. The illustration shows the 50/9 kHz
zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
Before using the unit, set the SPAN SELECTOR switch (on the rear
panel) to the interval (span) of your area.
To change the tuning zone:
Caution:
This operation will erase all data stored in memory including clock,
timer settings, tuner preset, and CD programme.
!Demonstration mode
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode),
press the X-BASS/DEMO button. The demonstration mode will be
cancelled and the display will disappear.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the X-BASS/
DEMO button again.
Note:
When the power is on, the X-BASS/DEMO button can be used to
select the extra bass mode.
!To turn the power on
Press the ON/STAND-BY button to turn the power on.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Set the SPAN SELECTOR switch (on the rear panel) as follows.
"For 50 kHz FM interval (9 kHz in AM) 50/9
"For 100 kHz FM interval (10 kHz in AM) 100/10
3 Whilst pressing down the / button and the X-BASS/DEMO
button, press the ON/STAND-BY button until "CLEAR AL" ap-
pears.
The first time the unit is plugged in, the
unit will enter the demonstration mode.
You will see words scroll.
After use:
Press the ON/STAND-BY button to enter the power stand-by
mode.

02/8/6 XL-HP500W(A)2.fm
E-11
ENGLISH
XL-HP500W
Preparation for Use
Remote control
!Battery installation
Precautions for battery use:
"Replace all old batteries with new ones at the same time.
"Do not mix old and new batteries.
"Remove the batteries if the unit is not to be used for long periods
of time. This will prevent potential damage due to battery leak-
age.
Caution:
"Do not use rechargeable batteries (nickel-cadmium battery, etc.).
"Installing the batteries incorrectly may cause the unit to malfunc-
tion.
Notes concerning use:
"Replace the batteries if the operating distance is reduced or if the
operation becomes erratic. Purchase 2 "AA" size batteries (UM/
SUM-3, R6, HP-7 or similar).
"Periodically clean the transmitter on the remote control and the
sensor on the unit with a soft cloth.
"Exposing the sensor on the unit to strong light may interfere with
operation. Change the lighting or the direction of the unit.
"Keep the remote control away from moisture, heat, shock, and
vibrations.
!Test of the remote control
Check the remote control after checking all connections have been
made correctly. (See pages 7 - 10.)
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now,
you can enjoy music.
1 Remove the battery cover.
2 Insert the batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them towards the
battery terminals.
3 Replace the cover.
0.2 m - 6 m
(8" - 20')
Remote sensor

02/8/6 XL-HP500W(A)2.fm
E-12
ENGLISH
XL-HP500W
Basic Operation
Sound control
!Volume control
Main unit operation:
When the VOLUME control is turned clockwise, the volume will
increase. When it is turned anti-clockwise, the volume will decrease.
Remote control operation:
Press the VOLUME (+ or -) button to increase or decrease the vol-
ume.
!Bass control
When the power is first turned on, the unit will enter the extra bass
mode which emphasises the bass frequencies, and "X-BASS" will
appear. To cancel the extra bass mode, press the X-BASS/DEMO
(X-BASS) button.
!Equaliser
When the EQUALIZER (EQUALIZER MODE) button is pressed, the
current mode setting will be displayed. To change to a different
mode, press the EQUALIZER (EQUALIZER MODE) button repeat-
edly until the desired sound mode appears.
12 29 30 MAXIMUM0.....
X-BASS indicator
ROCK
FLAT
CLASSIC
The sound is not modified.
Bass and treble are emphasised.
POPS Bass and treble are slightly emphasised.
JAZZ Treble is slightly emphasised.
Treble is cut a little.
VOCAL Vocals (midrange tones) are emphasised.

02/8/6 XL-HP500W(A)2.fm
E-13
ENGLISH
XL-HP500W
Basic Operation
Setting the clock
The clock should be set on the main unit.
In this example, the clock is set for the 24-hour (0:00) display.
To confirm the time display:
Note:
The "CLOCK" or time will flash at the push of the CLOCK button
when the AC power supply is restored after a power failure or
unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the clock" from step 1. If the time display is flashing,
step 3 (for selecting the 24-hour or 12-hour display) will be skipped.
To change the 24-hour or 12-hour display:
1Press the ON/STAND-BY button to turn the power on.
2Press the CLOCK button on the main unit and within 5 sec-
onds, press the MEMORY/SET button.
3Press the TUNING/TIME ( or ) button to select 24-hour
or 12-hour display and then press the MEMORY/SET but-
ton.
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"AM 0:00" The 12-hour display will appear.
(AM 0:00 - PM 11:59)
Note that this can only be set when the unit is first installed or it
has been reset. [Refer to "Clearing all the memory (reset)" on
page 30 for details.]
4Press the TUNING/TIME ( or ) button to adjust the hour
and then press the MEMORY/SET button.
"Press the TUNING/TIME ( or ) button once to advance
the time by 1 hour. Hold it down to advance continuously.
"When the 12-hour display is selected, "AM" will change au-
tomatically to "PM".
5Press the TUNING/TIME ( or ) button to adjust the min-
utes and then press the MEMORY/SET button.
"Press the TUNING/TIME ( or ) button once to advance
the time by 1 minute. Hold it down to change the time in 5-
minute intervals.
"The hour will not advance even if minutes advance from "59"
to "00".
Press the CLOCK button on the main
unit or remote control.
The time display will appear for about 5
seconds.
1 Clear all the programmed contents. [Refer to "Clearing all the
memory (reset)" on page 30 for details.]
2 Perform "Setting the clock" from step 1.

02/8/6 XL-HP500W(A)2.fm
E-14
ENGLISH
XL-HP500W
CD Playback
Listening to a CD (CDs)
This system can also play audio CD-R and CD-RW discs, but can-
not record.
Some audio CD-R and CD-RW discs may not be playable due to the
state of disc or the device that was used for recording.
To interrupt playback:
Press the CD button on the remote control.
To resume playback from the same point, press the button.
To stop playback:
Press the (CD ) button.
To exchange other CDs whilst playing a disc:
Press the button for the stopped disc and exchange discs.
To remove the CDs:
Whilst in the stop mode, press the desired button.
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the button to open the disc tray 1.
4Place the CD on the disc tray 1, label side up.
Be sure to place 8 cm (3") CD in the middle of the disc trays.
12 cm (5") 8 cm (3")
5Press the button to close the disc tray 1.
Total number of tracks on
the CD whose number is
flashing
Total playing time of the
CD whose number is
flashing
6You can place discs on the trays 2 - 3 by following steps
3 - 5.
7Press the / button to start playback.
"Playback will begin from track 1 on the DISC 1. After that
disc finishes playing, the next disc will automatically play.
"When the last track on the third disc has finished playing,
the CD player will stop automatically.
"When there is no CD in one of the disc tray 1 - 3 positions,
that position will be skipped and the next CD will be played.

02/8/6 XL-HP500W(A)2.fm
E-15
ENGLISH
XL-HP500W
CD Playback
Listening to a CD (CDs) (continued)
!To locate the beginning of a track
Notes:
"You can locate the beginning of a track on a single disc only.
"You can skip to any track by pressing the or button
repeatedly until the desired track number appears.
!To locate the desired portion
Notes:
!To specify a disc to play
You can play a disc by specifying the disc number.
Note:
If the button of the disc tray with no disc is pressed, playback will not
start and the disc number indicator will go out.
To stop playback:
Press the (CD ) button.
Caution:
"Do not place two CDs in one disc tray.
"Do not play discs with special shapes (heart- or octagon-
shaped). It may cause malfunctions.
"Do not push the disc tray whilst it is moving.
"If the power fails whilst the tray is open, wait until the power is
restored.
"If the disc tray is stopped forcibly, "ER-CD20" will appear on the
display for 3 seconds and the unit will not function. If this occurs,
press the ON/STAND-BY button to enter the power stand-by
mode and then turn the power on again.
"If TV or radio interference occurs during CD operation, move the
unit away from the TV or radio.
"If a disc is damaged, dirty, or loaded upside down, the disc will
skip.
To move to the beginning of the next track:
Press the button for less than 0.5 seconds during playback.
To restart the track being played:
Press the button for less than 0.5 seconds during playback.
For audible fast forward:
Press and hold down the button during playback.
For audible fast reverse:
Press and hold down the button during playback.
"Normal playback will resume when the or button is re-
leased.
"You can locate the desired portion on a single disc only.
"When the end of the last track is reached during fast forward, "
END" will appear on the display and CD operation will be paused.
When the beginning of the first track is reached during fast re-
verse, the unit will enter the playback mode.
( : Last track number)
Press one of the DISC SELECT - ( 1 - 3) buttons to se-
lect the desired disc.
Selected disc number
Only the chosen disc will be played and stopped automatically.

02/8/6 XL-HP500W(A)2.fm
E-16
ENGLISH
XL-HP500W
CD Playback
Advanced CD playback
!Direct search of the track
By using the direct search buttons, the desired tracks on the current
disc can be played.
If the direct search buttons are pressed whilst the disc is stopped,
press the / button to start the desired track on the current disc.
Notes:
"A track number higher than the number of tracks on the disc can-
not be selected.
"During random play, direct search is not possible.
!Repeat play
All tracks on up to 3 discs, all tracks on the chosen disc or a pro-
grammed sequence can be continuously repeated.
To cancel repeat play: Press the / button again. " " will go out.
!Random play
The tracks on the disc(s) can be played in random order automatically.
To cancel random play: Press the / button.
Notes:
"If you press the button during random play, you can move to the track
selected next by the random operation. On the other hand, the button
does not allow you to move to the previous track. The beginning of the
track being played will be located.
"In random play, the CD player will select and play tracks automatically.
(You cannot select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press the (CD ) button.
Otherwise, the disc(s) will play continuously.
Use the direct search buttons on
the remote control to select the de-
sired track whilst playing the se-
lected disc.
Selected track number
"The direct search buttons allow you to select up to number
10.
"When selecting number 11 or more, use the "+10" button.
A. For example, to choose 13
1 Press the "+10" button once.
2 Press the "3" button.
B. For example, to choose 30
1 Press the "+10" button three times.
2 Press the "0" button.
To repeat all tracks on up to 3 discs:
Press the / button twice.
To repeat all tracks on the chosen disc:
1 Press one of the DISC SELECT - ( 1
- 3) buttons.
2 Press the / button.
To repeat desired tracks:
Perform steps 1 - 6 in the "Programmed play" section and then
press the / button twice.
To random play all tracks on up to 3 discs:
1 Press the / button.
2 Press the RANDOM button on the remote
control.
To random play all tracks on the chosen disc:
1 Press one of the DISC SELECT - ( 1
- 3) buttons.
2 Press the RANDOM button on the remote
control.

02/8/6 XL-HP500W(A)2.fm
E-17
ENGLISH
XL-HP500W
CD Playback
Advanced CD playback (continued)
!Programmed play
You can choose up to 32 selections for playback in the order you
like.
To cancel the programmed play mode:
Whilst in the stop mode and the "MEMORY" indicator is lit, press the
CLEAR button on the remote control. The "MEMORY" indicator will
disappear and all the programmed contents will be cleared.
Adding tracks to the programme:
If a programme has been previously stored, the "MEMORY" indica-
tor will be displayed. Then follow steps 1 - 6 to add tracks. The new
tracks will be stored after the last track of the original programme.
To check which tracks are programmed:
Whilst the unit is stopped in the programmed play mode, press the
or button.
Notes:
"Opening the disc tray automatically cancels the programmed
sequence.
"Even if you press the ON/STAND-BY button to enter the stand-by
mode or change the function from CD to another, the pro-
grammed selections will not be cleared.
"During programme operation, random play is not possible.
1Whilst in the stop mode, press
the MEMORY/SET (MEMORY)
button to enter the programming
save mode.
2Press one of the DISC SELECT
- ( 1 - 3) buttons to select
the desired disc.
Selected disc number
3Press the direct search buttons
on the remote control to select
the desired track. Selected track number
You can also select a track by pressing the or button.
4Press the MEMORY/SET (MEMO-
RY) button to save the track
number.
5Repeat steps 2 - 4 for other tracks. Up to 32 tracks can be
programmed.
If you make a mistake, the programmed tracks can be cleared
by pressing the CLEAR button.
6Press the (CD ) button.
The total number of memory will ap-
pear.
7Press the / button to start playback.
During programme play, the DISC SELECT - ( 1 - 3)
buttons will not work.
To clear the programmed selections:
Press the CLEAR button on the remote con-
trol whilst the "MEMORY" indicator is flash-
ing.
Each time the button is pressed, one track will
be cleared, beginning with the last track pro-
grammed.

02/8/6 XL-HP500W(A)2.fm
E-18
ENGLISH
XL-HP500W
Radio
Listening to the radio
!Tuning
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the "ST" indicator.
"" " will appear when an FM broadcast is in stereo.
"If the FM reception is weak, press the TUNER (BAND) button to
extinguish the "ST" indicator. The reception changes to monau-
ral, and the sound becomes clearer.
Note:
This product can receive FM stereo/FM monaural and AM monaural
broadcasts. AM stereo broadcasts will not be played in stereo.
1Press the ON/STAND-BY button to turn the power on.
2Press the TUNER (BAND) button repeatedly to select the
desired frequency band (FM or AM).
3Press the TUNING/TIME ( or ) button to tune in to the de-
sired station.
Manual tuning:
Press the TUNING/TIME button as many times as required to
tune in to the desired station.
Auto tuning:
When the TUNING/TIME button is pressed for more than 0.5
seconds, scanning will start automatically and the tuner will
stop at the first receivable broadcast station.
Notes:
"When radio interference occurs, auto scan tuning may stop
automatically at that point.
"Auto scan tuning will skip weak signal stations.
"To stop the auto tuning, press the TUNING/TIME button
again.
FM stereo mode indicator
FM stereo receiving indicator

02/8/6 XL-HP500W(A)2.fm
E-19
ENGLISH
XL-HP500W
Radio
Listening to the radio (continued)
!Memorising a station
You can store 40 AM and FM stations in memory and recall them at
the push of a button. (Preset tuning)
Note:
The backup function protects the memorised stations for a few
hours should there be a power failure or the AC power lead discon-
nection.
!To recall a memorised station
!To scan the preset stations
The stations saved in memory can be scanned automatically. (Pre-
set memory scan)
!To erase entire preset memory
1Perform steps 1 - 3 in "Tuning" on page 18.
2Press the MEMORY/SET button to enter the preset tuning
saving mode.
3Within 30 seconds, press the PRESET ( or ) button to
select the preset channel number.
Store the stations in memory, in order, starting with preset
channel 1.
4Within 30 seconds, press the MEMORY/SET button to store
that station in memory.
If the "MEMORY" and preset number indicators go out before
the station is memorised, repeat the operation from step 2.
5Repeat steps 1 - 4 to set other stations, or to change a pre-
set station.
When a new station is stored in memory, the station previously
memorised will be erased.
1 Press the PRESET ( or ) button for less than 0.5 seconds to
select the desired station.
1 Press the PRESET ( or ) button for more than 0.5 seconds.
The preset number will flash and the programmed stations will be
tuned in sequentially, for 5 seconds each.
2 Press the PRESET ( or ) button again when the desired sta-
tion is located.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Whilst pressing down the TUNER (BAND) button and the X-
BASS/DEMO button, press the ON/STAND-BY button until
"TUNER CL" appears.
