LG LROFC0605 Series User manual

OWNER'S MANUAL
FREEZER
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
LROFC0605*
MFL67229644
Rev.00_052522
www.lg.com
Copyright © 2022 LG Electronics Inc. All Rights Reserved.

TABLE OF CONTENTS
2
3 IMPORTANT SAFETY
INSTRUCTIONS
3 READ ALL INSTRUCTIONS BEFORE USE
3WARNING
6CAUTION
7 PRODUCT OVERVIEW
7 Product Features
9 INSTALLATION
9 Before Installing
9 Choosing the Proper Location
10 Leveling
11 Turning on the Power
12 OPERATION
12 Before Use
13 Control Panel
13 Defrosting Mode
13 Storing Food
15 MAINTENANCE
15 Cleaning
16 TROUBLESHOOTING
16 Before Calling for Service
20 LIMITED WARRANTY
20 USA
24 Canada

3IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Safety Messages
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
follow all safety messages.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury,
and tell you what may happen if the instructions are not followed.
WARNING
WARNING
• To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this
product, follow basic precautions, including the following:
Installation
• To reduce the risk of injury to persons, adhere to all industry recommended safety procedures including
the use of long-sleeved gloves and safety glasses.
• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has
missing or broken parts, including a damaged cord or plug.
• Only connect this product to a dedicated grounded electrical outlet rated for use with this product (115
V, 60 Hz, AC only). It is the user’s responsibility to replace a standard 2-prong wall outlet with a standard
3-prong wall outlet.
• Do not use an outlet that can be turned off with a switch. Do not use an extension cord.
• The appliance must be positioned for easy access to a power source.
• When moving the appliance, be careful not to roll over or damage the power cord.
• Contact an authorized service center when installing or relocating the appliance.
• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
• Keep packing materials out of the reach of children. Packaging material can be dangerous for children.
There is a risk of suffocation.
• Do not install the appliance in a damp or dusty place where insulation on electrical parts may
deteriorate.
• Do not place the appliance in direct sunlight or expose it to the heat from heating appliances such as
stoves or heaters.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages
will follow the safety alert symbol and either the word WARNING or CAUTION.
These words mean:
WARNING
You may be killed or seriously injured if you do not follow instructions.
CAUTION
You may be injured or cause damage to the product if you do not follow instructions.

4IMPORTANT SAFETY INSTRUCTIONS
• Do not bend or pinch the power cord excessively or place heavy objects on it.
Operation
• This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
• This product is not to be used for special purposes such as the storage of medicine or test materials or
for use on ships, etc.
• DO NOT allow children to climb, stand, or hang on the appliance doors or on the shelves in the freezer.
They could damage the appliance and seriously injure themselves.
• Do not allow children to climb into the appliance. They could be trapped and suffocated.
• Children should be supervised to ensure that they do not play with the appliance.
• Keep fingers out of pinch point areas; clearances between the doors and cabinets are necessarily small.
Be careful closing doors when children are nearby.
• Do not touch frozen food or the metal parts in the freezer compartment with wet or damp hands. Doing
so may cause frostbite.
• Do not refreeze frozen food that has thawed completely. Doing so may result in a serious health hazard.
• Do not use an adapter plug or plug the power plug into a multi-outlet extension cord.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
• Do not operate the appliance or touch the power cord with wet hands.
• Do not modify or extend the power cord.
• Do not use an uncertified power outlet. Do not plug appliance into a damaged wall outlet.
• Do not put hands, feet or other objects into the air vents or bottom of the appliance. Doing so could
result in personal injury or electric shock.
• In the event of a gas leak (propane/LPG), ensure the area is adequately ventilated and contact an
authorized service center before resuming use. Do not touch the appliance or power cord of the
appliance.
• Disconnect the power cord immediately and contact an authorized service center if there is a strange
noise, odor, or smoke coming from the appliance.
• Do not use any fuse (such as copper, steel wire, etc.) other than a standard fuse.
• Do not place or use an electrical appliance inside the freezer, unless it is of a type recommended by the
manufacturer.
• Do not put animals inside the appliance.
• Do not place heavy or fragile objects, liquid filled containers, combustible substances, or flammable
objects (such as candles and lamps) on the appliance.
• If connected to a circuit protected by fuses, use time delay fuse.
• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not use electrical appliances inside the food storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

5IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
Maintenance
• Do not use a hair dryer to dry the inside of the appliance.
• Do not light a candle to remove odors in the appliance.
• In the event of a refrigerant leak, move flammable objects away from the appliance. Ensure the area is
adequately ventilated and contact an authorized service center.
• Keep flammable materials and vapors, such as gasoline, away from the appliance.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Unplug the power plug before cleaning or repairing the appliance.
• The freezer compartment lights are interior LED lighting, and service should be performed by a qualified
technician.
• Unplug the power plug immediately in the event of a blackout or thunderstorm.
• Turn the power off if water or dust penetrates into the appliance. Call a service agent.
• Do not store glass containers or soda in the freezer compartment. Contents may expand when frozen,
break the container and cause injury.
• Do not store, disassemble or repair the appliance yourself or allow unqualified personnel to do so.
Disposal
• Risk of child entrapment. Junked or abandoned appliances are dangerous, even if they are sitting for
only a few days. When disposing of the appliance, remove the packing materials from the door or take
off the doors but leave the shelves in place so that children may not easily climb inside.
• If disposing of an appliance, make sure the refrigerant and insulation foam are removed for proper
disposal by a qualified servicer. If you release the refrigerant or throw away the insulation foam, you
may be fined or imprisoned in accordance with the relevant environmental law. Insulation foam contains
flammable blowing gas.
• When discarding the appliance, remove the door gasket while leaving the shelves and bins in place, and
keep children away from the appliance.
Grounding Instructions
• Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check
with a qualified electrician or service personnel if you are in doubt whether the appliance is properly
grounded. Do not modify the plug provided with the appliance; if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
• Have a certified electrician check the wall outlet and wiring for proper grounding.
• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight
out from the outlet. Failure to do so may damage the power cord, resulting in a risk of fire and electric
shock.

6IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Risk of Fire and Flammable Materials
CAUTION
CAUTION
• To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or
property when using this product, follow basic precautions, including the following:
Installation
• Do not install the appliance where there may be a danger of the unit falling.
• The appliance must be properly installed in accordance with the Installation Instructions.
• Do not connect this appliance to a GFCI (Ground Fault Circuit Interrupter) outlet. If the appliance is
connected to a GFCI outlet, the outlet's circuit breaker could be tripped. If this problem occurs, reset the
GFCI outlet's circuit breaker. If the problem continues, contact a qualified electrician and replace the
GFCI outlet with a non-GFCI outlet.
Operation
• Do not use aerosols near the appliance.
• This appliance is intended to be used only in domestic and similar applications.
• Do not strike or apply excessive force to any glass surface. Do not touch glass surfaces if they are
cracked or broken.
• Do not overfill or pack items too tightly into door bins. Doing so may cause damage to the bin or
personal injury if items are removed with excessive force.
Maintenance
• Do not use strong detergents like wax or thinners for cleaning. Clean with a soft cloth.
• Remove foreign objects (such as dust and water) off the prongs of the power plug and contact areas. Do
not use a wet or damp cloth when cleaning the plug.
• Do not spray water directly on the inside or outside of the appliance.
• Do not clean glass shelves or covers with warm water when they are cold. They may break if exposed to
sudden temperature changes.
This appliance contains a small amount of isobutane refrigerant (R600a), which is combustible.
When transporting and installing the appliance, care should be taken to ensure that no parts
of the refrigerating circuit are damaged. Refrigerant squirting out of the pipes could ignite or
cause an eye injury. If a leak is detected, avoid any naked flames or potential sources of
ignition and air out the room in which the appliance is standing for several minutes.
In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating
circuit occurs, the size of the room in which the appliance may be sited depends on the
amount of refrigerant used. The room must be 10.8 square feet (1 square meter) in size for
every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate inside the appliance. Never start up an
appliance showing any signs of damage. If in doubt, consult your dealer.

7PRODUCT OVERVIEW
ENGLISH
PRODUCT OVERVIEW
Product Features
The images in this guide may be different from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
Interior
aTemperature Control (on back wall of compartment)
Sets the freezer temperature.
bTop Shelf (Soft Freeze Area)
Stores frozen foods such as meat and fish.
Do not place ice cream or frozen dairy products on the top shelf or in door bins.
cMain Shelves (Evaporator)
Stores frozen foods such as meat, fish, and ice cream.
dGlass Shelf
eDrip Tray
Use the drip tray for defrosting (do not use to store food).
• Make sure that the drip tray is properly installed before defrosting.
• The drip tray has a maximum temperature of 21°F (-6°C).
fMagnetic Door Seal

8PRODUCT OVERVIEW
gDoor Bins (Short Term Storage)
Store small packages of frozen food. Do not use these bins to store ice cream or for long-term food
storage.
NOTE
• Store raw meat and fish in suitable containers in the freezer, so that they are not in contact with drip
onto other food.
• Allow hot food to cool prior to storing. Placing hot food in the freezer could spoil other food and lead to
higher energy consumption.
• The temperature inside the freezer will not be affected by power outages lasting only a few hours, as
long as the door is kept closed. For longer power outages, place a block of dry ice in the freezer or
remove food and cook it. When using dry ice, provide adequate ventilation. Dry ice is frozen carbon
dioxide (CO2) When it vaporizes, it can displace oxygen, causing dizziness, light-headedness,
unconsciousness, and death by suffocation. Open a window and do not breathe in the vapor.
• The outside wall of the freezer cabinet may get warm. Don't be alarmed. This is due to the anti-
condensation pipe, which pumps hot refrigerant to prevent sweating on the outer cabinet wall.
Product Specifications
The appearance and specifications listed in this manual may vary due to constant product improvements.
Electrical requirements: 115 V, 60 Hz
Model Description Net weight
LROFC0605* Standard-depth, Freezer 82 lb (37 kg)

9INSTALLATION
ENGLISH
INSTALLATION
Before Installing
Unpacking the Freezer
WARNING
• Use two or more people to move and install the
appliance. Failure to do so can result in back
injury or other injury.
• The appliance is heavy. Protect the floor when
moving the appliance for cleaning or service.
Always pull the appliance straight out when
moving it. Do not wiggle or walk the appliance
when trying to move it, as floor damage could
occur.
• Keep flammable materials and vapors, such as
gasoline, away from the appliance. Failure to do
so can result in fire, explosion, or death.
NOTE
• Remove tape and any temporary labels from
your appliance before using. Do not remove any
warning labels, the model and serial number
label, or the Tech Sheet that is located under the
front of the appliance.
• To remove any remaining tape or glue, rub the
area briskly with your thumb. Tape or glue
residue can also be easily removed by rubbing a
small amount of liquid dish soap over the
adhesive with your fingers. Wipe with warm
water and dry.
• Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove
tape or glue. These products can damage the
surface of your appliance.
• Reinstall or adjust shelves as needed. Freezer
shelves are installed in the shipping position.
Reinstall shelves according to your individual
storage needs.
Choosing the Proper
Location
Electricity
Use an individual, grounded outlet:115 Volts, 60
Hz, AC, 15 amps minimum.
WARNING
• Do not overload house wiring and cause a fire
hazard by plugging in multiple appliances in the
same outlet with the appliance.
• To reduce the risk of electric shock, do not install
the appliance in a wet or damp area.
Flooring
To avoid noise and vibration, the unit must be
installed and leveled on a solidly constructed floor.
If required, adjust the leveling legs to compensate
for the unevenness of the floor.
NOTE
• Installing on carpeting, soft tile surfaces, a
platform or weakly supported structure is not
recommended.
Ambient Temperature
Install this appliance in an area where the
temperature is between 55 °F (13 °C) and 110 °F
(43 °C).
If the temperature around the appliance is too low
or high, cooling ability may be adversely affected.

10 INSTALLATION
Dimensions and Clearances
• Check the dimensions of the appliance and the installation path to ensure there is sufficient room to
move the appliance through doors or narrow openings.
• The installation location chosen for the appliance should allow space behind the unit for connections and
airflow and space in front to open the doors and drawers.
• Too small of a distance from adjacent items may result in lowered freezing capability and increased
electricity consumption charges. Allow at least 2 inches (50 mm) between the back of the appliance and
the wall.
• Remember to allow enough room in front of the appliance to fully open the doors.
Leveling
Leveling the Freezer
If the appliance seems unsteady, or the doors do
not close easily, adjust the appliance’s tilt using the
instructions below.
1 Turn the leveling leg clockwise to raise that
side of the appliance or counterclockwise to
lower it. 2 Open the door and check to make sure that
the door closes easily.
-Dimensions/Clearances LROFC0605*
A Depth without Handle 23 5/8" (600 mm)
B Width 20 7/8" (530 mm)
C Height to Top of Case 51" (1294 mm)
D Height to Top of Hinge 51 1/8" (1300 mm)
E Back Clearance 2" (50 mm)
F Depth without Door 20 1/8" (510 mm)
G Depth (Total with Door Open 90°) 41 1/8" (1045 mm)
G
A
B
CD
E
F

11INSTALLATION
ENGLISH
Turning on the Power
After installing, plug the appliance’s power cord
into a 3-prong grounded outlet and push the
appliance into the final position.
Compressor will start operating 7 to 10 minutes
after connecting the power cord.
CAUTION
• Connect to a rated power outlet.
• Have a certified electrician check the wall outlet
and wiring for proper grounding.
• Do not damage or cut off the ground terminal of
the power plug.
Position the Appliance
• Arrange the coil of tubing so that it does not
vibrate against the back of the appliance or
against the wall. Push the appliance back to the
wall.

12 OPERATION
OPERATION
Before Use
Checklist
Clean the appliance.
Clean the appliance thoroughly and wipe off all dust that accumulated during
shipping.
CAUTION
• Do not scratch the appliance with a sharp object or use a detergent that
contains alcohol, a flammable liquid or an abrasive when removing any
tape or adhesive from the appliance. Remove adhesive residue by wiping it
off with your thumb or dish detergent.
• Do not peel off the model or serial number label or the technical
information on the rear surface of the appliance.
Open doors and drawers to ventilate the interior.
The inside of the appliance may smell like plastic at first. Remove any
adhesive tape from inside the appliance and open the door and the drawers
for ventilation.
Connect the power supply.
Check if the power supply is connected before use.
Wait for the freezer to cool.
Allow the appliance to run for at least two to three hours before putting food
in it. Check the flow of cold air in the freezer compartment to ensure proper
cooling.
CAUTION
• Putting food in the freezer before it has cooled could cause the food to
spoil, or a bad odor to remain inside the freezer.
The appliance makes a loud noise after initial operation.
This is normal. The volume will decrease as the temperature decreases.

13OPERATION
ENGLISH
Control Panel
Depending on the model, some of the following functions may not be available.
The actual control panel may differ from model to model.
Control Panel Features
a0(OFF)
Set the dial to 0to turn the freezer off
bMAX
Set the dial to MAX for coldest temperature
cMID
Set the dial to MID for recommended temperature
dMIN
Set the dial to MIN for warmest temperature
Defrosting Mode
Using the Defrosting Mode
Defrost the freezer regularly to keep it working
efficiently. Once a month, unplug the power cord
and allow the entire freezer to defrost.
CAUTION
• Do not use sharp implements or metal tools to
remove ice or frost from the cabinet or the main
shelves (evaporator). The resulting damage or
punctured evaporators will not be covered
under the warranty.
1 Keep food well wrapped before defrosting. If
food thaws, do not refreeze it. Either store the
food in the freezer or cook and eat it.
2 To defrost the freezer, turn the temperature
control dial to the 0(OFF) setting.
• Make sure that the drip tray is properly
installed so water will collect in the tray.
3 Once finished defrosting, remember to reset
the temperature control dial to its original
setting.
4 Remove and empty the drip tray, dry it off,
and reassemble it.
NOTE
• For faster defrosting, place 1 or 2 pans filled with
warm water inside the freezer.
Storing Food
NOTE
• If you are leaving home for a short period, like a
short vacation, the freezer should be left on.
Refrigerated foods that are able to be frozen will
stay preserved longer if stored in the freezer.

14 OPERATION
• If you are leaving the appliance turned off for an
extended period, remove all food and unplug
the power cord. Clean the interior, and leave the
door open to prevent fungi from growing in the
freezer.
• If doors are opened or closed too often, warm
air may penetrate the freezer and raise its
temperature. This can increase the running costs
of the unit.
Storing Frozen Food
Check a freezer guide or a reliable cookbook for
further information about preparing food for
freezing or food storage times.
Freezing
Your freezer will not quick-freeze a large quantity
of food. Do not put more unfrozen food into the
freezer than will freeze within 24 hours (no more
than 2 to 3 pounds of food per cubic foot of freezer
space). Leave enough space in the freezer for air to
circulate around packages. Be careful to leave
enough room at the front so the door can close
tightly.
Storage times will vary according to the quality
and type of food, the type of packaging or wrap
used (how airtight and moisture-proof) and the
storage temperature. Ice crystals inside a sealed
package are normal. This simply means that
moisture in the food and air inside the package
have condensed, creating ice crystals.
NOTE
• Allow hot foods to cool at room temperature for
30 minutes, and then package and freeze.
Cooling hot foods before freezing saves energy.
• Do not store glass containers in the freezer.
Contents may expand when frozen, break the
container and cause injury.
Packaging
Successful freezing depends on correct packaging.
When you close and seal the package, it must not
allow air or moisture in or out. If it does, you could
have food odor and taste transfer throughout the
freezer and could also dry out frozen food.
Packaging recommendations
• Rigid plastic containers with tight-fitting lids
• Straight-sided canning/freezing jars
• Heavy-duty aluminum foil
• Plastic-coated paper
• Non-permeable plastic wraps
• Specified freezer-grade self-sealing plastic bags
Follow package or container instructions for
proper freezing methods.
Do not use
• Bread wrappers
• Non-polyethylene plastic containers
• Containers without tight lids
• Wax paper or wax-coated freezer wrap
• Thin, semi-permeable wrap
NOTE
• If you are leaving home for a short period, like a
short vacation, the appliance should be left on.
• If you are leaving the appliance turned off for an
extended period, remove all food and unplug
the power cord. Clean the interior, and leave the
door open to prevent fungi from growing in the
appliance.
• If doors are opened or closed too often, warm
air may penetrate the appliance and raise its
temperature. This can increase the running costs
of the unit.

15MAINTENANCE
ENGLISH
MAINTENANCE
Cleaning
WARNING
• Use non-flammable cleaner. Failure to do so can
result in fire, explosion, or death.
CAUTION
• Do not use an abrasive cloth or sponge when
cleaning the interior and exterior of the
appliance.
• Do not place your hand on the bottom surface of
the appliance when opening and closing the
doors.
General Cleaning Tips
• Wipe up spills immediately.
• Unplug the appliance or disconnect power
before cleaning.
• Remove all removable parts, such as shelves.
• Use a clean sponge or soft cloth and a mild
detergent in warm water. Do not use abrasive or
harsh cleaners.
• Hand wash, rinse and dry all surfaces
thoroughly.
Exterior
For products with black stainless steel exterior,
spray glass cleaner on a clean microfiber cloth and
rub in direction of grain. Do not spray glass
cleaner directly at the display panel. Do not use
harsh or abrasive cleaners.
For products with a standard stainless steel
exterior, use a damp microfiber cloth and rub in
the direction of the grain. Dry with a paper towel
to avoid streaks. For stubborn stains and
fingerprints, use a few drops of liquid dish soap in
water, and rinse with hot water before drying. Do
not use abrasive or harsh cleaners.
Inside Walls
• Allow freezer to warm up so the cloth will not
stick.
To help remove odors, wash the inside of the
freezer with a mixture of baking soda and warm
water. Mix 2 tablespoons of baking soda to 1 quart
of water (26 g soda to 1 liter water.) Be sure the
baking soda is completely dissolved so it does not
scratch the surfaces of the freezer.
Door Liners and Gaskets
Use a clean sponge or soft cloth and a mild
detergent in warm water. Do not use cleaning
waxes, concentrated detergents, bleaches, or
cleaners containing petroleum on plastic parts.
Plastic Parts (Covers and Panels)
Use a clean sponge or soft cloth and a mild
detergent in warm water. Do not use glass
cleaners, abrasive cleansers, or flammable fluids.
These can scratch or damage the material.
Condenser Coils
Use a vacuum cleaner with a brush or crevice
attachment to clean the condenser cover and
vents. Do not remove the panel covering the
condenser coil area.

16 TROUBLESHOOTING
TROUBLESHOOTING
Before Calling for Service
Review this section before calling for service; doing so will save you both time and money.
Cooling
Problem Possible Cause & Solution
Appliance is not
cooling or has no
power.
A fuse in your home may be blown or the circuit breaker tripped. Or the appliance is
connected to a GFCI (Ground Fault Circuit Interrupter) outlet, and the outlet's circuit
breaker has tripped.
• Check the main electrical box and replace the fuse or reset the circuit breaker. Do not
increase fuse capacity. If the problem is a circuit overload, have it corrected by a qualified
electrician.
• Reset the circuit breaker on the GFCI. If the problem persists, contact an electrician.
The freezer control is set to OFF (some models).
• Turn the control ON. Refer to the Setting the Controls section for proper temperature
settings.
Freezer is in the defrost cycle.
• During the defrost cycle, the temperature of each compartment may rise slightly. Wait 30
minutes and confirm the proper temperature has been restored once the defrost cycle has
completed.
Appliance was recently installed.
• It may take up to 24 hours for each compartment to reach the desired temperature.
Appliance was recently relocated.
• If the appliance was stored for a long period of time or moved on its side, it is necessary
for the freezer to stand upright for 24 hours before connecting it to power.
Cooling system runs
too much.
Appliance is replacing an older model.
• Modern appliances require more operating time but use less energy due to more efficient
technology.
Appliance was recently plugged in or power restored.
• The appliance will take up to 24 hours to cool completely.
The door is opened often or a large amount of food / hot food was added.
• Adding food and opening the door warms the freezer, requiring the compressor to run
longer in order to cool the freezer back down. In order to conserve energy, try to get
everything you need out of the freezer at once, keep food organized so it is easy to find,
and close the door as soon as the food is removed. (Refer to the Food Storage Guide.)
Doors are not closed completely.
• Firmly push the doors shut. If they will not shut all the way, the "Doors will not close
correctly or pop open" section in Troubleshooting.
Appliance is installed in a hot location.
• The compressor will run longer under warm conditions. At normal room temperatures (70
°F or 21 °C) expect your compressor to run about 40 % to 80 % of the time. Under warmer
conditions, expect it to run even more often. The appliance should not be operated above
110 °F (43 °C).
Condenser / back cover is clogged.
• Use a vacuum cleaner with an attachment to clean the condenser cover and vents. Do not
remove the panel covering the condenser coil area.

17TROUBLESHOOTING
ENGLISH
Interior moisture
buildup.
Doors are opened often or for long periods of time.
• When the doors are opened often or for long periods of time, warm, humid air enters the
compartment. This raises the temperature and moisture level within the compartment. To
lessen the effect, reduce the frequency and duration of door openings.
Doors are not closed correctly.
• See the "Doors will not close correctly or pop open" section.
Weather is humid.
• Humid weather allows additional moisture to enter the compartments when the doors are
opened leading to condensation or frost. Maintaining a reasonable level of humidity in the
home will help to control the amount of moisture that can enter the compartments.
Defrost cycle recently completed.
• During the defrost cycle, the temperature of each compartment may rise slightly and
condensation may form on the back wall. Wait 30 minutes and confirm that the proper
temperature has been restored once the defrost cycle has completed.
Food is not packaged correctly.
• Food stored uncovered or unwrapped, and damp containers can lead to moisture
accumulation within each compartment. Wipe all containers dry and store food in sealed
packaging to prevent condensation and frost.
Freezer section is too
cold.
Incorrect temperature control settings.
• If the temperature is too cold, adjust the control one increment at a time and wait for the
temperature to stabilize. Refer to the Control Panel for more information.
Frost or ice crystals
form on frozen food
(inside of sealed
package).
Condensation from food with a high water content has frozen inside of the food
package.
• This is normal for food items with a high water content.
Food has been left in the freezer for a long period of time.
• Do not store food items with high water content in the freezer for a long period of time.
Frost or ice crystals
form on frozen food
(outside of package).
Door is opened frequently or for long periods of time.
• When the doors are opened often or for long periods of time, warm, humid air enters the
compartment. This raises the temperature and moisture level within the compartment.
Increased moisture will lead to frost and condensation. To lessen the effect, reduce the
frequency and duration of door openings.
Door is not closing properly.
• Refer to the "Doors will not close correctly or pop open" section in the Troubleshooting.
Freezer section is too
warm.
Appliance was recently installed.
• It may take up to 24 hours for each compartment to reach the desired temperature.
The air vents are blocked.
• Locate air vents by using your hand to sense airflow and move all packages that block
vents and restrict airflow. Rearrange items to allow air to flow throughout the
compartment.
Doors are opened often or for long periods of time.
• When the doors are opened often or for long periods of time, warm, humid air enters the
compartment. This raises the temperature and moisture level within the compartment. To
lessen the effect, reduce the frequency and duration of door openings.
Appliance is installed in a hot location.
• The appliance should not be operated in temperatures above 110 °F (43 °C).
A large amount of food or hot food was added to either compartment.
• Adding food warms the compartment requiring the cooling system to run. Allowing hot
food to cool to room temperature before putting it in the freezer will reduce this effect.
Problem Possible Cause & Solution

18 TROUBLESHOOTING
Parts & Features
Noises
Freezer section is too
warm.
Doors are not closed correctly.
• See the "Doors will not close correctly or pop open" section in the Troubleshooting.
Temperature control is not set correctly.
• If the temperature is too warm, adjust the control one increment at a time and wait for the
temperature to stabilize.
Defrost cycle has recently completed.
• During the defrost cycle, the temperature of each compartment may rise slightly and
condensation may form on the back wall. Wait 30 minutes and confirm the proper
temperature has been restored once the defrost cycle has completed.
Problem Possible Cause & Solution
Doors will not close
correctly or pop
open.
Food packages are blocking the door open.
• Rearrange food containers to clear the door and door shelves.
Ice bin, pans, shelves, door bins (some models), or baskets are out of position.
• Push bins (some models) all the way in and put pans, shelves and baskets into their correct
positions. See the Operation section for more information.
Appliance is not leveled properly.
• See Leveling in the Installation section.
Doors are difficult to
open.
The gaskets are dirty or sticky.
• Clean the gaskets and the surfaces that they touch. Rub a thin coat of appliance polish or
kitchen wax on the gaskets after cleaning.
Door was recently closed.
• When you open the door, warmer air enters the appliance. As the warm air cools, it can
create a vacuum. If the door is hard to open, wait one minute to allow the air pressure to
equalize, then see if it opens more easily.
Appliance wobbles or
seems unstable
Leveling legs are not adjusted properly.
• See Leveling in the Installation section.
Floor is not level.
• It may be necessary to add shims under the leveling legs or rollers to complete installation.
Lights do not work. LED interior lighting failure.
• The freezer compartment lamp is LED interior lighting, and service should be performed
by a qualified technician.
The interior of the
appliance is covered
with dust or soot.
The appliance is located near a fire source, such as a fireplace, chimney, or candle.
• Make sure that the appliance is not located near a fire source, such as a fireplace, chimney
or candle.
Problem Possible Cause & Solution
Rattling Rattling noises may come from the flow of refrigerant, the water line on the back of
the unit, or items stored on top of or around the appliance.
• Normal Operation
Problem Possible Cause & Solution

19TROUBLESHOOTING
ENGLISH
Rattling Appliance is not resting solidly on the floor.
• Floor is weak or uneven or leveling legs need to be adjusted. See Leveling in the
Installation section.
Appliance with linear compressor was jarred while running.
• Normal Operation
Whooshing Evaporator fan motor is circulating air through the freezer compartments.
• Normal Operation
Air is being forced over the condenser by the condenser fan.
• Normal Operation
Gurgling Refrigerant flowing through the cooling system.
• Normal Operation
Popping Contraction and expansion of the inside walls due to changes in temperature.
• Normal Operation
Sizzling Water dripping on the defrost heater during a defrost cycle.
• Normal Operation
Vibrating If the side or back of the appliance is touching a cabinet or wall, some of the normal
vibrations may make an audible sound.
• To eliminate the noise, make sure that the sides and back cannot vibrate against any wall
or cabinet.
Dripping Water running into the drain pan during the defrost cycle.
• Normal Operation
Pulsating or high-
pitched sound
Your appliance is designed to run more efficiently to keep your food items at the
desired temperature. The high efficiency compressor may cause your new appliance to
run longer than your old one, but it is still more energy efficient than previous models.
While the appliance is running, it is normal to hear a pulsating or high-pitched sound.
• Normal Operation
Problem Possible Cause & Solution

20 LIMITED WARRANTY
LIMITED WARRANTY
USA
TERMS AND CONDITIONS
ARBITRATION NOTICE: THIS LIMITED WARRANTY CONTAINS AN ARBITRATION PROVISION THAT
REQUIRES YOU AND LG ELECTRONICS (“LG”) TO RESOLVE DISPUTES BY BINDING ARBITRATION
INSTEAD OF IN COURT, UNLESS YOU CHOOSE TO OPT OUT. IN ARBITRATION, CLASS ACTIONS AND
JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING
DISPUTES” BELOW.
Should your LG Freezer ("Product") fail due to a defect in materials or workmanship under normal and
proper use, during the warranty period set forth below, LG will, at its option, repair or replace the Product.
This limited warranty is valid only to the original retail purchaser of the Product ("You") and applies only
when purchased lawfully and used within the United States including U.S. Territories.
• Replacement Products and parts are warranted for the remaining portion of the original warranty period
or ninety (90) days, whichever is greater.
• Replacement Products and parts may be new, reconditioned, refurbished, or otherwise factory
remanufactured.
• Replaced Product or part(s) will be the property of LG.
• Proof of original retail purchase specifying the Product model and date of purchase is required to obtain
warranty service under this limited warranty.
• Warranty start date will be ninety (90) days from manufacture date absent valid proof of purchase.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THE PRODUCT IS LIMITED IN
DURATION TO THE DURATION OF THE ABOVE LIMITED WARRANTY. UNDER NO CIRCUMSTANCES
SHALL LG OR ITS U.S. DISTRIBUTORS/DEALERS BE LIABLE FOR ANY INDIRECT, INCIDENTAL,
CONSEQUENTIAL, SPECIAL, OR PUNITIVE DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST
GOODWILL, LOST REVENUES OR PROFITS, WORK STOPPAGE, IMPAIRMENT OF OTHER GOODS, COST OF
REMOVAL AND REINSTALLATION OF THE PRODUCT, LOSS OF USE, OR ANY OTHER DAMAGES WHETHER
BASED IN CONTRACT, TORT, OR OTHERWISE. LG’S TOTAL LIABILITY, IF ANY, SHALL NOT EXCEED THE
PURCHASE PRICE PAID BY YOU FOR THE PRODUCT.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES OR LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU. THIS LIMITED WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
THIS LIMITED WARRANTY DOES NOT COVER:
• Service trips to deliver, pick up, or install, educate how to operate, correct wiring, or correct
unauthorized repairs.
WARRANTY PERIOD
Freezer
Sealed System
(Condenser, Dryer,
Connecting Tube and
Evaporator)
Compressor
One (1) year from the
date of original retail
purchase
Five (5) years from the
date of original retail
purchase
Five (5) years from the
date of original retail
purchase
Linear / Inverter
Compressor Only : Parts
Only for years 6-10 from
the date of original retail
purchase (Consumer will
be charged for labor)
Parts and Labor (internal
/ functional parts only)
Parts and Labor Parts and Labor
